Kinetix 3 Component Servo Drives
Catalog Numbers 2071-AP0, 2071-AP1, 2071-AP2, 2071-AP4, 2071-AP8, 2071-A10, 2071-A15
Summary of Changes
This publication contains new and updated information as indicated in the following table.
Topic Page
Summary of Changes 1
Catalog Number Explanation 2
Before You Begin 2
Safety Information 2
Product Dimensions 5
Connector Data 7
Power Wiring Requirements 12
Connectors and Cables 13
Ground Your Kinetix 3 Drive to the Subpanel 14
Kinetix 3 Drive Power and Ground Wiring 15
Motor Overload Protection 17
Fuse/Contactor Specifications 18
Additional Resources 19
Topic Page
Added an important statement to step 2 of the Mount the Kinetix 3 Drive procedure. 4
Updated the first paragraph under Fuse/Contactor Specifications 18

2Rockwell Automation Publication 2071-IN001F-EN-P - February 2017
Kinetix 3 Component Servo Drives
About the Kinetix 3 Drives
Kinetix® 3 component servo drives provide simple solutions for applications with output power
requirements in the range of 50…1500 W (0.6…9.9 A rms).
See the Kinetix 3 Component Drive User Manual, publication 2071-UM001, for detailed
information on how to wire, apply power, troubleshoot, and integrate with Micro800® or
MicroLogix™ controller platforms.
Catalog Number Explanation
This publication applies to the following Kinetix 3 drives.
Before You Begin
Remove all packing materials, wedges, and braces from within and around the components.
After unpacking, check the item nameplate catalog number against the purchase order.
Safety Information
Cat. No. Input Voltage Continuous Output Power Continuous Output Current (0-
pk)
2071-AP0
240V AC rms, 1 Ø
50 W 0.85 A
2071-AP1 100 W 1.56 A
2071-AP2 200 W 2.40 A
2071-AP4 400 W 4.67 A
2071-AP8 240V AC rms, 1 Ø or 3 Ø 800 W 7.07 A
2071-A10
220V AC rms, 3 Ø
1.0 kW 9.90 A
2071-A15 1.5 kW 13.99 A
SHOCK HAZARD: Capacitors retain charge for approximately 300 s after power is removed.
Disconnect incoming power and wait at least five minutes before touching the drive. There is a
status indicator on the front of the drive that shows there is charge on the capacitors. Failure to
observe this precaution could result in severe bodily injury or loss of life.

Rockwell Automation Publication 2071-IN001F-EN-P - February 2017 3
Kinetix 3 Component Servo Drives
Parts List
The Kinetix 3 drive ships with the following:
• A general-purpose power input (IPD) header, shunt resistor (BC) header, and motor
power (MP) header
• A connector tool for open wire clamps on the power connector
• A ground clamp and two #6-32 x 1 screws to provide ground and strain relief for the
motor power cable
• These installation instructions, publication 2071-IN001
Install the Kinetix 3 Drive
These procedures assume that you have prepared your panel, and understand how to bond your
system. For installation instructions regarding equipment and the accessories that are not
included here, refer to the instructions that came with those products.
WARNING: The opening of branch-circuit protective device can be an indication that a fault has
been interrupted. To reduce the risk of fire or electric shock, parts that carry current and other
components of the controller must be examined and replaced if damaged.
TIP The breakout boards for motor feedback (catalog number 2071-TBMF) and I/O connections
(catalog number 2071-TBIO) are not provided. See the Kinetix Servo Drives Specifications
Technical Data, publication GMC-TD003, for more information.
Control and configuration serial interface cables (catalog numbers 2090-CCMxxDS-xxAAxx)
and replacement connector sets (catalog number 2071-CONN1) are also available. See the
Kinetix Motion Accessories Specifications Technical Data, publication GMC-TD004, for more
information.
SHOCK HAZARD: To avoid hazard of electrical shock, mount and wire of the Kinetix 3 drive before
you apply power. Once power is applied, connector terminals can have voltage present even when
not in use.
ATTENTION: Plan the installation of your system so that you can cut, drill, tap, and weld with the
system that is removed from the enclosure. Because the system is of the open-type construction,
be careful to keep any metal debris from falling into it. Metal debris or other foreign matter can
become lodged in the circuitry and result in damage to components.

4Rockwell Automation Publication 2071-IN001F-EN-P - February 2017
Kinetix 3 Component Servo Drives
Mount the Kinetix 3 Drive
Follow these steps to mount the drive.
1. Observe these clearance requirements when mounting the drive to the panel.
2. Mount the Kinetix 3 drive to the cabinet subpanel with M4 (#6-32) steel machine screws
that are torqued to 1.1 N•m (9.8 lb•in).
IMPORTANT Mount the module in an upright position as shown. Do not mount the module on
its side.
IMPORTANT The panel you install inside the enclosure for mounting your system components
must be on a flat, rigid, vertical surface that won’t be subjected to shock, vibration,
moisture, oil mist, dust, or corrosive vapors in accordance with pollution degree 2
(EN 61800-5-1).
50.0 (1.97)
30.0 (1.18)
50.0 (1.97)
10.0 (0.39)
Minimum
Panel Depth
235 (9.25)
Dimensions are in millimeters (inches)

Rockwell Automation Publication 2071-IN001F-EN-P - February 2017 5
Kinetix 3 Component Servo Drives
Product Dimensions
Catalog Numbers 2071-AP0, 2071-AP1, and 2071-AP2
Dimensions are in millimeters (inches). Drives are designed to metric dimensions; inches are a mathematical conversion.
Catalog Number 2071-AP4
Dimensions are in millimeters (inches). Drives are designed to metric dimensions; inches are a mathematical conversion.
141.0
(5.55)
153.4
(6.04)
155.0
(6.11)
50.0
(1.97)
53.0
(2.09)
48.3
(1.9)
145.0
(5.71)
5.0
(0.2)
5.0
(0.2)
Mounting hole (top) and slot
(bottom) require M4 x 10 bolts.
Chassis Ground
155.0
(6.11)
141.0
(5.55)
153.4
(6.04)
50.0
(1.97)
58.0
(2.29)
48.3
(1.9)
145
(5.71)
5.0
(0.2)
5.0
(0.2)
Mounting hole (top) and slot
(bottom) require M4 x 10 bolts. Chassis Ground Terminals (2)

6Rockwell Automation Publication 2071-IN001F-EN-P - February 2017
Kinetix 3 Component Servo Drives
Catalog Numbers 2071-AP8, 2071-A10, and 2071-A15
Dimensions are in millimeters (inches). Drives are designed to metric dimensions; inches are a mathematical conversion.
155.0
(6.11)
198.6
(7.82)
186.2
(7.34)
81.0
(3.19)
50.0
(1.97)
59.0
(2.32)
145.0
(5.71)
5.0
(0.2)
Mounting hole (top) and slot
(bottom) require M5 x 10 bolts.
Chassis Ground
Terminals (2)

Rockwell Automation Publication 2071-IN001F-EN-P - February 2017 7
Kinetix 3 Component Servo Drives
Connector Data
Use this illustration to identify the Kinetix 3 drive features and indicators.
Kinetix 3 Features and Indicators
Kinetix 3 Connectors
Item Description
1 Left/right and up/down keys
2 Analog output (A.out)
3 RS-485 communication termination switch
4 Input power (IPD)
5 Main power indicator
6Shuntpower(BC)
7 Motor power (MP)
8 Ground lug
9 Motor feedback (MF)
10 Input/output (I/O)
11 Serial interface (Comm0B) (down)
12 Serial interface (Comm0A) (up)
13 Enter key
14 Mode/set key
15 7-segment status indicator
Designator Description Connector
A.out Analog output 4-pin connector header
IPD AC and control power input 6-pin quick-connect terminal block
BC Shunt power 2-pin quick-connect terminal block
MP Motor power 3-pin quick-connect terminal block
CommOA Serial interface up 6-pin IEEE 1394 connector
CommOB Serial interface down 6-pin IEEE 1394 connector
IOD I/O 50-pin mini-D connector
MF Motor feedback 20-pin mini-D connector
I/O Motor Feedback
DC -
15
1
5
14
13
9
10
4
6
7
12
2
3
8
11

8Rockwell Automation Publication 2071-IN001F-EN-P - February 2017
Kinetix 3 Component Servo Drives
Input Power (IPD) Connector
IPD Pin Description Signal
L1 Main AC power L1
L2 Main AC power L2
L3 Main AC power(1) L3
L1C L1C - Control power L1C
L2C L2C - Control power L2C
DC DC bus negative DC- (not supported)
(1) L3 is not used for single phase drives.
Shunt Power (BC) Connector
BC Pin Description Signal
B1 Shunt resistor +
DC bus positive
B1
(not supported)
B2 Shunt resistor - B2
Motor-power (MP) Connector
MP Pin Description Signal
UMotorpowerU U
VMotorpowerV V
WMotorpowerW W
Motor Feedback (MF) Connector
MF Pin Description Signal
1 Encoder power ground ECOM
2 Thermal sensor input TS
3 A positive differential input A+
4 A negative differential input A-
5 B positive differential input B+
6 B negative differential input B-
7 Index positive differential input I+
8 Index negative differential input I-
9 Negative limit sensor input LMT-
10 Serial positive
Hall feedback S1
SD+
S1

Rockwell Automation Publication 2071-IN001F-EN-P - February 2017 9
Kinetix 3 Component Servo Drives
11 Shield drain GND
12 Reserved –
13 Serial negative SD-
14 Hall feedback S2 S2
15 Reserved –
16 Hall feedback S3 S3
17 Positive limit sensor input LMT+
18 BAT+ for motor side BAT+
19 BAT- for motor side BAT-
20 Encoder +5 input power EPWR
Serial Interface (Comm0A, up) and (Comm0B, down) Connector
CommOA and
CommOB Pin
2071-Axx (Series A) 2071-Axx (Series B)
Description Signal Description Signal
1 RS-232 transmit XMT RS-232 transmit XMT
2 RS-232 receive RCV RS-232 receive RCV
3 Reserved – +5V DC +5V DC
4 +5V power ground GND +5V power ground GND
5 RS-485 + DX+ RS-485 + DX+
6 RS-485 - DX- RS-485 - DX-
I/O (IOD) Connector
IOD Pin Description Signal
1 24V input +24V PWR
2 24V input +24V PWR
3 Digital input 1 (/SV-ON) INPUT1
4 Digital input 2 (P-OT) INPUT2
5 Digital input 3 (N-OT) INPUT3
6 Digital input 4 (/P-CON) INPUT4
7 Digital input 5(/A-RST)) INPUT5
8 Digital input 6 (/N-TL) INPUT6
9 Digital input 7 (/P-TL) INPUT7
Motor Feedback (MF) Connector
MF Pin Description Signal

10 Rockwell Automation Publication 2071-IN001F-EN-P - February 2017
Kinetix 3 Component Servo Drives
10 E-stop (default: disable) ESTOP
11 Follower input A+ PLUS +
12 Follower input A- PLUS -
13 Follower input B+ SIGN +
14 Follower input B- SIGN -
15 High frequency pulse input A+ HF_PULS +
16 High frequency pulse input A- HF_PULS -
17 Encoder z-pulse Z-PULSE+
18 Encoder z-pulse Z-PULSE-
19 Velocity command input+ VCMD+
20 Velocity command input- VCMD-
21 Current command input+ ICMD+
22 Current command input- ICMD-
23 High-frequency pulse input B+ HF_SIGN +
24 High-frequency pulse input B- HF_SIGN -
25 O/C for sign of 24V level 24V_SIGN +
26 Digital input 8 INPUT8
27 Digital input 9 INPUT9
28 Digital input 10 INPUT10
29 Buffered encoder channel A+ AM+
30 Buffered encoder channel A- AM-
31 Buffered encoder channel B+ BM+
32 Buffered encoder channel B- BM-
33 Buffered encoder channel Z+ IM+
34 Buffered encoder channel Z- IM-
35 Serial data of absolute encoder PS+
36 Serial data of absolute encoder PS-
37 Alarm output 1
Digital output 4
FAULT1
OUTPUT4
38 Alarm output 2
Digital output 5
FAULT2
OUTPUT5
39 Alarm output 3
Digital output 6
FAULT3
OUTPUT6
I/O (IOD) Connector (continued)
IOD Pin Description Signal

Rockwell Automation Publication 2071-IN001F-EN-P - February 2017 11
Kinetix 3 Component Servo Drives
40 Alarm output
Digital outputs ground
FCOM
OUT COM
41 Digital output 1 + (P_COM+) OUTPUT1+
42 Digital output 1 – (P_COM-) OUTPUT1-
43 Digital output 2 + (TG_ON+) OUTPUT2+
44 Digital output 2 – (TG_ON-) OUTPUT2-
45 Servo alarm + FAULT+
46 Servo alarm - FAULT-
47 Digital output 3 + (BK+) OUTPUT3+
48 Digital output 3 – (BK-) OUTPUT3-
49 O/C for pulse of 24V level 24V_PULS +
50 Reserved –
I/O (IOD) Connector (continued)
IOD Pin Description Signal

12 Rockwell Automation Publication 2071-IN001F-EN-P - February 2017
Kinetix 3 Component Servo Drives
Power Wiring Requirements
The wires must be copper with 75 °C (167 °F) minimum rating. The phase connections of the
main AC power are arbitrary and earth ground connection is required for safe and proper
operation.
Drive Cat. No. Description
Terminals Recommended
Wire Size
mm2 (AWG)
Strip
Length
mm (in.)
Torque Value
N•m (lb•in)
Pin Signal
2071-AP0
2071-AP1
2071-AP2
2071-AP4
Input and control
power
IPD-L1
IPD-L2
IPD-L1C
IPD-L2C
L1
L2
L1C
L2C
2.5 (14) 8 (0.3)
N/A
Ground screw Ground 1.25 (11)
2071-AP8
IPD-L1
IPD-L2
(IPD-L3)
IPD-L1C
IPD-L2C
L1
L2
(L3)
L1C
L2C
N/A
Ground screw Ground 1.25 (11)
2071-A10
2071-A15
IPD-L1
IPD-L2
IPD-L3
IPD-L1C
IPD-L2C
L1
L2
L3
L1C
L2C
N/A
Ground screw Ground 1.25 (11)
2071-xxx Motor power
MP-U
MP-V
MP-W
U
V
W
N/A
Ground screw GND 1.25 (11)
2071-xxx Shunt resistor (1)
(1) Use only for shunt resistor connection.
BC-B1
BC-B2
B1
B2 N/A
ATTENTION: To avoid personal injury and equipment damage, be sure of the following:
• Installation complies with specifications regarding wire types, conductor sizes, branch circuit
protection, and disconnect devices. The National Electrical Code (NEC) and local codes outline
provisions for safely installing electrical equipment.
• Motor power connectors are used only for connection purposes. Do not use motor power
connector to turn the unit on and off.
• Shielded power cables are grounded to help prevent potentially high voltages on the shield.

Rockwell Automation Publication 2071-IN001F-EN-P - February 2017 13
Kinetix 3 Component Servo Drives
Connectors and Cables
Connector Type of Connector Wire Size Cat. No.
Input Power Single-row, spring clamp
connectors spaced 7.5 mm
(0.30 in.)
2.5…0.08 mm2
(12…28 AWG)
8 mm (0.31 in.) of wire
that is exposed
2071-CONN1 (1)
(1) The tool (Wago 231-131) for opening individual cage-clamp power connectors is supplied with the drive. You can purchase the replacement tool
separately.
Output (Motor) Power
Input/output 50-pin mini-D 0.25…0.05 mm2
(24…30 AWG)
2071-TBIO
Motor Feedback 20-pin mini-D 2071-TBMF
Connector Type of Mating Cable Cable
Serial Interface
Comm0A, Comm0B
Configuration
2090-CCMPCDS-23AA01
2090-CCMPCDS-23AA03
Control
2090-CCMCRDS-48AA01
2090-CCMCRDS-48AA03
Drive to drive control
2090-CCMDSDS-48AA01
2090-CCMDSDS-48AAP3
Drive to 1203-USB converter (1)
(1) For use with Kinetic lication3 drives series B and later.
2090-CCMUSDS-48AA01
2090-CCMUSDS-48AA03

14 Rockwell Automation Publication 2071-IN001F-EN-P - February 2017
Kinetix 3 Component Servo Drives
Ground Your Kinetix 3 Drive to the Subpanel
Bond the Kinetix 3 drive to the cabinet ground bus. To ground, attach a braided ground strap or
0.4 mm2(12 AWG) solid-copper wire, 100 mm (3.9 in.) long between the top mounting screw
and the bonded cabinet ground.
Item Description
1 Mounting screw
2 Braided ground strap
3 Bonded cabinet-ground bus
4 Ground grid or power distribution ground
5 2071-AP4 Kinetix 3 drive shown
3
4
2
1
5

Rockwell Automation Publication 2071-IN001F-EN-P - February 2017 15
Kinetix 3 Component Servo Drives
Kinetix 3 Drive Power and Ground Wiring
This installation applies to a TL-Series™ (Bulletin TL) motor with 2090-DANPT-16Sxx cable.
Terminate the input-power ground wire with a ring lug. Attach input power and motor power
grounds to ground screws, and torque to 1.25 N•m (11 lb•in).
Item Description
1 2071-AP4 Kinetix 3 drive shown
2 Input power cable
3 Control power cable
4 Motor power cable
5Ringlug
6 Ground screw (1)
(1) 2071-AP0, 2071-AP1, and 2071-AP2 drives have one grounding screw on the heatsink.
2071-AP4, 2071-AP8, 2071-A10, and 2071-A15 drives have two ground screws on the heatsink.
2
4
56
1
3

16 Rockwell Automation Publication 2071-IN001F-EN-P - February 2017
Kinetix 3 Component Servo Drives
This installation applies to TL-Series™ (Bulletin TLY) rotary motors, LDC-Series™ and LDL-
Series™ linear motors, and MP-Series™ (Bulletin MPAS), TL-Series (Bulletin TLAR), and
LDAT-Series actuators.
Terminate the input-power ground wire with a ring lug as shown. Attach input power and motor
power grounds to ground screws, and torque to 1.25 N•m (11 lb•in).
Item Description
1 2071-AP4 Kinetix 3 drive shown
2 Motor-power ground clamp
3 Motor power cable
4 Expose 25 mm (1 in.) of cable shield
5 If panel is painted, remove paint to provide metal-to-metal contact
6Subpanel
7Ringlug
8 Ground screw (1)
(1) 2071-AP0, 2071-AP1, and 2071-AP2 drives have one grounding screw on the heatsink.
2071-AP4, 2071-AP8, 2071-A10, and 2071-A15 drives have two ground screws on the heatsink.
50…75
(2…3)
50…75
(2…3)
34.0
(1.34)
25
(1.0)
12.7
(0.50)
3
6
7
1
4
5
2
8
Dimensions are in mm (in.)

Rockwell Automation Publication 2071-IN001F-EN-P - February 2017 17
Kinetix 3 Component Servo Drives
Motor Overload Protection
This servo drive uses solid-state motor overload protection that operates in accordance with
UL 508C. Motor overload protection algorithms (thermal memory) that predict actual motor
temperature that is based on operating conditions as long as control power is continuously
applied. However, when control power is removed, thermal memory is not retained.
This drive also provides an input for an external temperature sensor or thermistor device, which
is embedded in the motor, to support the UL requirement for motor overload protection.
The drive supports some motors that do not contain temperature sensors or thermistors;
therefore, motor overload protection against excessive consecutive motor overloads followed by
power-up is not supported.
This servo drive meets the following UL 508C requirements for solid-state overload protection.
See your servo drive user manual for the interconnect diagram that illustrates the wiring between
your motor and drive.
Motor Overload Protection Trip Point Value
Ultimately 100% overload
Within 8 minutes 200% overload
Within 20 seconds 600% overload
ATTENTION: Avoid overheat damage to your motor from excessive and successive motor
overload faults by following the motor and drive-combination wiring diagram that is provided in
the user manual.

18 Rockwell Automation Publication 2071-IN001F-EN-P - February 2017
Kinetix 3 Component Servo Drives
Fuse/Contactor Specifications
The Kinetix 3 drives use internal solid-state motor short-circuit protection and, when protected
by suitable branch circuit protection, are rated for use on a circuit capable of delivering up to
100,000 A. Fuses or circuit breakers, with adequate withstand and interrupt ratings, as defined in
NEC or applicable local codes, are permitted.
The following fuse examples are recommended for use with Kinetix 3 drives.
Fuse and Contactor Specifications
Drive Cat. No. AC Input Power (1) (2) (3)
Recommended Fuse
(1) Fuses that are specified are Bussmann fuses.
(2) FNQ-R fuses are described as time-delay fuses, Class CC.
(3) LPJ fuses are described as dual-element time-delay fuses, Class J.
Control Power (2) (4)
Recommended Fuse
(4) FRS-R fuses are described as dual-element time-delay fuses, Class RK5.
Contactor (5)
(5) For contactors: xrepresents coil voltage, yrepresents the number of contacts.
2071-AP0
FNQ-R-7
FRS-R-2-1/2
FNQ-R-7-1/2
LPJ-6
100-K05xy
2071-AP1
2071-AP2 100-K09xy
2071-AP2 FNQ -R-10 100-K12xy
2071-AP8 FNQ-R-20
LPJ-20 100-C16xy
2071-A10
2071- A15 FNQ-R-30
LPJ-30 100-C23xy

Rockwell Automation Publication 2071-IN001F-EN-P - February 2017 19
Kinetix 3 Component Servo Drives
Additional Resources
These documents contain additional information concerning related products from Rockwell
Automation.
You can view or download publications at http://www.rockwellautomation.com/global/
literature-library/overview.page. To order paper copies of technical documentation, contact your
local Allen-Bradley distributor or Rockwell Automation sales representative.
Resource Description
Kinetix 3 Component Servo Drive User Manual,
publication 2071-UM001
Information on how to install, configure, start up, and troubleshoot
your Kinetix 3 servo drive system.
Kinetix Servo Drives Specifications Technical Data,
publication GMC-TD003 Information on the specifications for the Kinetix 3 drive
Motor Feedback Breakout Board Installation Instructions,
publication 2071-IN003
Information on how to install and wire a Kinetix 3 motor feedback
breakout board.
I/O Breakout Board Installation Instructions, publication
2071-IN002
Information on how to installand wire a Kinetix 3 motor I/O breakout
board.
Serial Communication Cables Installation Instructions,
publication 2090-IN019
Information on how to install and the schematics for the serial
communication cables that are used with a Kinetix 3 drive.
MicroLogix 1100 Programmable Controllers Installation
Instructions, publication 1763-IN001
Information on how to assemble and mount the controller, how to
upgrade firmware, and controller technical specifications.
MicroLogix 1400 Programmable Controllers Installation
Instructions, publication 1766-IN001
Micro810® Programmable Controllers Users Manual,
publication 2080-UM001
Micro830® and Micro850® Programmable Controllers
User Manual, publication 2080-UM002
Kinetix 3 Component Servo Drive Serial Host Command
Reference Manual, publication 2071-RM001
Information on the serial communication commands, both ASCII and
ModBus, for interfacing a motion controller with the Kinetix 3 drive.
Industrial Automation Wiring and Grounding Guidelines,
publication 1770-4.1
Provides general guidelines for installing a Rockwell Automation®
industrial system.
Product Certifications website,
http://www.rockwellautomation.com/global/
certification/overview.page
Provides declarations of conformity, certificates, and other
certification details.

Allen-Bradley, Kinetix, LDC-Series, LDL-Series, Micro810, Micro830, Micro850, MicroLogix, MP-Series, Rockwell Automation, Rockwell Software, and TL-Series are trademarks of
Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
Rockwell Otomasyon Ticaret A.Ş., Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: [phone]
Rockwell Automation maintains current product environmental information on its website at
http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page.
Publication 2071-IN001F-EN-P - February 2017
Supersedes Publication 2071-IN001E-EN-P - August 2014 Copyright © 2017 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
Rockwell Automation Support
Use the following resources to access support information.
Documentation Feedback
Your comments will help us serve your documentation needs better. If you have any suggestions
on how to improve this document, complete the HowAre We Doing? form at http://
literature.rockwellautomation.com/idc/groups/literature/documents/du/ra-du002_-en-e.pdf.
Technical Support
Center
Knowledgebase Articles,
How-to Videos, FAQs, Chat,
User Forums, and Product
Notification Updates.
https://rockwellautomation.custhelp.com/
Local Technical
Support Phone
Numbers
Locate the phone number
for your country.
http://www.rockwellautomation.com/global/support/get-support-
now.page
Direct Dial Codes
Find the Direct Dial Code
for your product. Use the
code to route your call
directly to a technical
support engineer.
http://www.rockwellautomation.com/global/support/direct-dial.page
Literature Library
Installation Instructions,
Manuals, Brochures, and
Technical Data.
http://www.rockwellautomation.com/global/literature-library/
overview.page
Product
Compatibility and
Download Center
(PCDC)
Get help determining how
products interact, check
features and capabilities,
and find associated
firmware.
http://www.rockwellautomation.com/global/support/pcdc.page
