Allen-Bradley Kinetix 5000 User manual

Installation Instructions
Kinetix 5000 AC Line Filters
Catalog Numbers 2198-DB08-F, 2198-DB20-F, 2198-DB42-F, 2198-DB80-F,
2198-DB290-F
About the AC Line Filters
This publication provides wiring and installation instructions for the AC line filters used with
the Kinetix® 5000 servo drive families. For more information on installing and wiring your
Kinetix 5500 or Kinetix 5700 servo drive, refer to the drive-family user manual listed in
Additional Resources on page 8.
Topic Page
About the AC Line Filters 1
Important User Information 2
Before You Begin 3
Wire the AC Line Filter 3
AC Line Filter Specifications 8
Additional Resources 8
