allen MSP445 Application guide

OPERATIONS & PARTS MANUAL
MSP445 RIDING TROWEL
REVISION: 05.2018 | MANUAL PART #: 053430

053430; 01/11
This manual, or a copy of it, must be kept with the machine at all times.
There is a manual storage container located on the machine for your
convenience.

i
053430; 01/11
Riding Trowel
OPERATIONS-PARTS MANUAL
This manual covers the Riding Trowel model listed below:
Part No. Description
053300 RIDER, MSP445

ii 053430; 01/11
Limited Warranty
LIMITED WARRANTY and LIMITATION OF LIABILITY
Allen Engineering Corporation (“Allen”) warrants its products to be free of defects in material or workmanship for the following
periods:
A. New Machines and Parts .......................... One Year
B. New Gear Boxes ........................................ Two Years
The above listed warranty periods are effective for Allen Machines with a first day of use by End User on April 1, 2007 or later.
Warranty period begins on first day of use by End User. This first day of use is established by the date of a completed Allen
Warranty Card or a Bill of Sale to the End User. All warranty is based on the following limited warranty terms and conditions,
including the disclaimer of implied warranties and consequential damages.
1. Allen’s obligation and liability under this warranty is limited to repairing or replacing parts if, after Allen’s inspection,
there is determined to be a defect in material or workmanship. Allen reserves the choice to repair or replace.
2. If Allen chooses to replace the part, it will be at no cost to the customer and will be made available to the Allen Distributor,
Dealer, or Rental Center from whom the End User purchased the product.
3. Replacement or repair parts, installed in the product, are warranted only for the remainder of warranty period of the
product as though they were the original parts.
4. Allen does not warranty engines. Engine warranty claims should be made directly to an authorized factory service center
for the particular engine manufacturer.
5. Allen’s warranty does not cover the normal maintenance of products or its components (such as engine tune-ups and oil &
filter changes). The warranty also does not cover normal wear and tear items (such as belts and consumables).
6. Allen’s warranty will be void if it is determined that the defect resulted from operator abuse, failure to perform normal
maintenance on the product, modification to product, alterations or repairs made to the product without the written approval
of Allen. Allen specifically excludes from warranty any damage to any trowels resulting from an impact to the rotors.
7. Impact damage is not covered under the Allen Gear Box warranty.
8. Allen will pay shop labor on warranty items at the Allen Shop Labor Rate in existence on the date of the warranty claim. An
Allen Labor Chart will determine the time allowed to complete a repair and will govern the shop labor hours that will be
allowed.
9. Allen will pay freight on warranty replacement parts at worldwide standard ground rates. No warranty replacement parts
will be shipped air freight at the expense of Allen. Allen only pays outbound freight charges when sending warranty
replacement parts to the customer via ground service. Allen does not pay any inbound freight. However, if Allen deter-
mines
this to be a warranted item, only then will Allen reimburse the customer for inbound freight at standard ground rates.
10. ALLEN ENGINEERING CORPORATION’S WARRANTY POLICY WILL NOT COVER THE FOLLOWING: TAXES; SHOP
SUPPLIES; ENVIRONMENTAL SURCHARGES; AIR FREIGHT; TRAVEL TIME; LOSS OF TIME; INCONVENIENCE;
LOSS OF RENTAL REVENUE; RENTAL COSTS OF EQUIPMENT USED TO REPLACE THE PRODUCT BEING
REPAIRED; LOSS OF USE OF THE PRODUCT; COMMERCIAL LOSS; OR ANY OTHER CHARGES WHATSOEVER OR
ANY LIABILITIES FOR DIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGE OR DELAY.
11. ALLEN ENGINEERING CORPORATION MAKES NO OTHER WARRANTY, EXPRESSED OR IMPLIED. THIS LIMITED
WARRANTY IS IN LIEU OF THE WARRANTY OF MERCHANTABILITY AND FITNESS. THERE ARE NO OTHER
WARRANTIES THAT EXTEND BEYOND THE DESCRIPTION ON THIS DOCUMENT.
12. No Allen employee or representative is authorized to change this warranty in any way or grant any other warranty unless
such change is made in writing and signed by an officer of Allen Engineering Corporation.

iii
053430; 01/11
Table of Contents
Sect No. Title Page
... Limited Warranty ............................................ii
... Information Contained In This Manual ............................v
... Dealer Information ...........................................vi
... Ordering Parts .............................................vii
... Model Number - Serial Number Codes ..........................viii
... Unit Identification ............................................ix
... Technical Specificatons .......................................x
... Engine Specifications ........................................xvi
... Machine Dimensional Specifications ............................xiii
... Sound And Vibration Specifications .............................xiv
1.0 Safety................................................... 1-1
... State Regulations .......................................... 1-2
... Federal Regulations ........................................ 1-3
1.1 General Safety Precautions .................................. 1-4
1.2 Spark Arrestor Notice....................................... 1-5
1.3 Operating Safety .......................................... 1-6
1.4 Engine Safety ............................................. 1-8
1.5 Servicing Safety ........................................... 1-9
1.6 Safety And Operation Labels ................................ 1-10
2.0 Operations............................................... 2-1
2.1 Introduction............................................... 2-3
2.2 Start Up Procedures........................................ 2-4
2.3 Operating Instructions ...................................... 2-6
3.0 Service.................................................. 3-1
3.1 Periodic Maintenance....................................... 3-2
3.2 Trowel Gearbox ........................................... 3-3
3.3 Drive Belt ................................................ 3-4
3.4 Control Lever Adjustment.................................... 3-8
3.5 Right Hand Control Lever Adjust ............................. 3-10
3.6 Lift Lever Adjustment ...................................... 3-12
3.7 Transporting Trowel ....................................... 3-14
3.8 Battery Jump Start ........................................ 3-18
3.9 Winterizing Retardant System ............................... 3-20

iv 053430; 01/11
4.0 Parts.................................................... 4-1
... Factory Service Information .................................. 4-2
... Replacement Part Procedure................................. 4-3
4.1 Upper Frame Unit, Front View ................................ 4-4
4.2 Upper Frame Unit, Rear View ................................ 4-6
4.3 Instrumentation-Control System............................... 4-8
4.4 Lower Frame Unit, Front View ............................... 4-10
4.5 Lower Frame Unit, Rear View ............................... 4-12
- Frame Design............................................ 4-14
4.6 Fuel Sytem .............................................. 4-15
4.7 Electrical System ......................................... 4-17
4.8 Steering System .......................................... 4-19
4.9 Retardant Spray System ................................... 4-21
4.10 Pitch Control Assembly .................................... 4-23
4.11 Gas Power Unit .......................................... 4-25
4.12 Engine System ........................................... 4-27
4.13 Engine Mounting System ................................... 4-29
4.14 Driveline System ......................................... 4-31
4.15 Air Cleaner System ....................................... 4-33
4.16 Cooling System .......................................... 4-35
4.18 Right Hand 20:1 Rotor Assembly............................. 4-37
4.19 Left Hand 20:1 Rotor Assembly .............................. 4-39
4.20 Right Hand Spider Assembly ................................ 4-41
4.21 Left Hand Spider Assembly ................................. 4-43
4.22 RH 20:1 Super Heavy Duty Gearbox.......................... 4-45
4.23 LH 20:1 Super Heavy Duty Gearbox .......................... 4-47
4.24 Identification and Marking Decals, Front View................... 4-49
4.25 Identification and Marking Decals, Rear View ................... 4-51
4.26 Accessory - Pro Dolly Jack System ........................... 4-53
4.27 Accessory - Non-Standard Items ............................. 4-55
4.28 Tools - Service ........................................... 4-57
4.29 Lighting Electrical Schematic ................................ 4-59
4.30 Power/Control Electrical Schematic ........................... 4-60
Table of Contents, continued

v
053430; 01/11
Information Contained in this
Manual
This manual provides information and procedures to safely operate and maintain the Allen
Machine.
For your own safety and protection from personal injury, carefully read, understand, and
observe the safety instructions described in this manual. Keep this manual or a copy of it with
the machine at all times.
Always operate this machine in accordance with the instructions described in this manual. A
well maintained piece of equipment will provide many years of trouble free operation.
This manual is divided into the following sections:
SECTION 1
SAFETY
SECTION 3
SERVICE
SECTION 2
OPERATIONS
Complete any warranty requirements as specified by the engine manufacturer in their instructions
found inside the manual box located on the back of the riding trowel operator’s seat.
Your engine and clutch is not manufactured by Allen Engineering Corporation, Inc, and therefore
is not covered under Allen Engineering Corporation, Inc warranty.
Your engine manufacturer should be contacted if you wish to purchase a parts manual or a repair
manual for your engine.
Refer to enclosed owners engine manual for complete O&M instructions. See your battery man-
ufacturer for battery warranty.
SECTION 4
PARTS

vi 053430; 01/11
Your Dealer has Allen Engineering Corporation trained mechanics and original Allen replacement
parts. Always contact the Allen Dealer who sold you this machine for Allen Certified repairs and
replacement parts.
Place Allen Dealer information below for future reference.
Dealer Information
Dealer Name: ______________________________________________________________
Phone #: (____) - ____ - ______________________________________________________
Address: _________________________________________________________________
City: ____________________________________ State:________ Zip:_____________
Salesman: _______________________________ Mobile Phone __________________
Additional Comments: _____________________________________________________
_________________________________________________________________________
_________________________________________________________________________
_________________________________________________________________________

vii
053430; 01/11
Section 4.0 contains illustrated drawings and parts lists for help in ordering replacement parts for
your machine. Follow the instructions below when ordering parts to insure prompt and accurate
delivery:
1. All orders for service parts - include the serial number for the machine. Shipment
will be delayed if this information is not available.
2. Include correct description and part number from the “PARTS” section of this
manual.
3. Specify exact shipping instructions, including the preferred routing and complete
destination address.
4. DO NOT return parts to AEC without receiving written authorization from AEC. All
authorized returns must be shipped pre-paid.
5. When placing an order, please contact the AEC dealer nearest you.
All information, specifications, and illustrations in this manual
are subject to change without notice and are based
on the latest information at the time of publication.
Ordering Parts

viii 053430; 01/11
Model Number - Serial Number Codes
Manufacturer’s Codes:
When ordering parts or requesting service information, you will always be asked to specify the
model and serial numbers of the machine. The legends below specifically defines each
significant character or group of characters of the Model Number and Serial Number codes.
Serial Number
The serial number found on the identification plate is a ten digit format. The model number
identifies your machine and will ensure that you receive the correct replacement parts.
445 01 11 001
Production Sequence
Model Number
MSP 44 5 - 40KO
MODEL
Year Mfd
Month Mfd
HP & ENGINE MAKE
KO = Kohler
Series/Model
SERIES
GASOLINE VERSION

ix
053430; 01/11
Unit Identification
Model Number: ________________________
Serial Number: ________________________
Date Purchased: ______________________
Purchased From: ______________________
Unit Identification Plate Location:
An identification plate listing the model number and the serial number is attached to each unit
and is located on the rear lower left side of mainframe. Refer to Figure 1 for serial number and
model number location. This plate should not be removed at any time.
Please record the information found on this plate below so it will be available should the
identification plate become lost or damaged. When ordering parts or requesting service
information, you will always be asked to specify the model and serial numbers of the machine.
FILL IN FOR FUTURE REFERENCE
Figure 1
Serial Number Location
SERIAL NUMBER
MODEL SERIES

x053430; 01/11
Technical Specifications
Measurements in this manual are in U.S. units and their customary metric units (i.e., metric units
contained within brackets [8 mm]). The machine RIGHT-HAND and LEFT-HAND sides are deter-
mined by sitting on machine (SOM) facing in the direction the machine will travel when going
forward.
Machine Features:
•Dimensions - NOL (L x W x H) inch [mm] .............101.5x50.5x59.5
(guardrings/top of seat) ...........................[2578.1x1282.7x1511]
• Operating Weight lb [kg] ..........................
• Panning Path Width inch [mm] .....................95 [2413]
• Two Rotors (Diameter) inch [mm] ...................46 [1168]
• Rotor Speed (RPM) ..............................165 - 170
• Finish Blade (10) inch [mm]........................6 x 18 [15x45]
• Gearbox (2) ....................................Super Heavy Duty (SHD)
• Welded Guard Ring ..............................Standard
• Flip-Up Seat Frame ..............................Standard
• Operator Control Panel ...........................Standard
• Powered Retardant Spray System ..................Standard
• Spray System Capacity gal [L]. . . . . . . . . . . . . . . . . . . . . .6 [23]
• Steering System.................................Dual Levers
• Gearbox Rotation................................Standard
• Battery ........................................12 V
• Safety Shutdown Switch ..........................Operator Seat
• Fuel Capacity gal [L] .............................6 [23]

xi
053430; 01/11
Technical Specifications, continued
• Run Time (Approximate) hr ........................2.5
• Transmission Type...............................Continual Variable Transmission
...........................................(CVT)
• Drive Belt Type .................................Kevlar Cogged Vee
• Hour Meter Type ................................Digital Read-out
CE MARKING Compliance:
AEC hereby declares under our sole responsibility that the machine identified within this
manual complies with the provisions in accordance with Machinery Directive 98/37/EC. AEC
has applied the following normative documents:
• 2000/14/EC; Noise Emission Of Outdoor Equipment Directive
• EN 294:1992; Safety Of Machinery-Safety Distance Of Danger Zones
• EN 574:1996; Safety Of Machinery-Two-hand Control Devices

xii 053430; 01/11
Engine Specifications
Engine Information
Your MSP445 Riding Trowel mode is equipped with a liquid cooled 40 HP Kohler Gasoline
engine. Refer to the applicable engine OEM owner’s manual for specific instructions regarding
engine operation. This manual is included with the riding trowel at the time of shipping from AEC.
Petrol Engine Features:
Max Power @3600 RPM hp (kW)......................40 (29.8)
Displacement cu in (cc)..............................61 (999)
Bore in (mm) ......................................3.5 (90)
Stroke in (mm).....................................3.1 (78.5)
Peak Torque @ Maximum lbs ft (Nm) ..................61.5 (83.4)
Compression Ratio .................................8.8:1
Dry Weight lbs (kg) .................................132 (59)
Oil Capacity U.S. quarts (L) ..........................2.9 (2.75)
Lubrication........................................Full pressure w/full-flow filter
Dimensions L x W x H in.............................15.3 x 19.0 x 27.5

xiii
053430; 01/11
Machine Dimensional Specifications
All information, specifications, and illustrations on this page in this manual are subject to
change without notice and are based on the latest information at the time of publication.
101.5 [2578.1 mm]
LENGTH
50.5 [1282.7 mm]
WIDTH
59.5 [1511 mm]
HEIGHT

xiv 053430; 01/11
Sound And Vibration Data
Sound Pressure Level Information:
Sound pressure is “A” weighted . Measured at the operators ear position while the ride-on trowel
is operating at full throttle on concrete in a manner most often experienced in “normal ” circum-
stances. Sound pressure may vary depending upon the condition of the concrete. Hearing
protection is always recommended.
Vibration Level Information:
The vibration level indicated is the maximum RMS (Root Mean Square) velocity value obtained
at the handle grip while operating the ride-on trowel on curing concrete in a manner most often
experienced in “normal ” circumstances. Values were obtained from all three axes of motion. The
values shown represent the maximum RMS value from these measurements.
Summary Data Of Sound And Vibration Testing for CE Marking
Test
Machine
Engine
Type
Distant
Sound
Press
Operator
Ear SPL
Sound
Power Level
Seat
Vibration
Overall
Foot
Vibration
Overall
Hand
Vibration
Maximum
MSP445 Kohler
40 hp TBD TBD TBD TBD TBD TBD
This information was acquired from extensive sound and vibration analysis tests conducted at
Allen Engineering Corporation test facilities.

1-1
053430; 01/11
Section 1
SAFETY
Section 1
SAFETY

1-2
Section 1
SAFETY
053430; 01/11
CALIFORNIA PROPOSITION 65
WARNING
Gasoline engine exhaust from this product contains chemicals
known to the State of California to cause cancer, birth defects and
other reproductive harm.
State Regulations

1-3
053430; 01/11
Section 1
SAFETY
Federal Regulations
SILICOSIS WARNING
Grinding/cutting/drilling of masonry, concrete, metal and other
materials with silica in their composition may give off dust or
mists containing crystalline silica. Silica is a basic component
of sand, quartz, brick clay, granite and numerous other min-
erals and rocks. Repeated and/or substantial inhalation of air-
borne crystalline silica can cause serious or fatal respiratory
diseases, including silicosis. In addition, California and some
other authorities have listed respirable crystalline silica as a
substance known to cause cancer. When cutting such mate-
rials, always follow the respiratory precautions mentioned
above.
RESPIRATORY HAZARDS
Grinding/cutting/drilling of masonry, concrete, metal and other
materials can generate dust, mists and fumes containing
chemicals known to cause serious or fatal injury or illness,
such as respiratory disease, cancer, birth defects or other
reproductive harm. If you are unfamiliar with the risks associ-
ated with the particular process and/or material being cut or
the composition of the tool being used, review the material
safety data sheet and/or consult your employer, the mate-
rial manufacturer/supplier, governmental agencies such as
OSHA and NIOSH and other sources on hazardous materi-
als. California and some other authorities, for instance, have
published lists of substances known to cause cancer, repro-
ductive toxicity, or other harmful effects.
Control dust, mist and fumes at the source where possible.
In this regard use good work practices and follow the recom-
mendations of the manufacturers or suppliers, OSHA/NIOSH,
and occupational and trade associations. Water should be
used for dust suppression when wet cutting is feasible. When
the hazards from inhalation of dust, mists and fumes cannot
be eliminated, the operator and any bystanders should
always wear a respirator approved by NIOSH/MSHA for the
materials being used.

1-4
Section 1
SAFETY
053430; 01/11
1.1
General Safety Precautions
1.1.1 Safety-Alert Signs
This manual contains Safety-Alert Signs, as defined below, which must be followed
to
reduce the possibility of improper service damage to the equipment or personal
injury. Read and follow all Safety-Alert Signs included in this manual.
NOTE defines an operating procedure,
condition, etc. which is essential to
highlight that contains useful or
important information.
EMERGENCY is used for the identification of safety equipment,
first aid, or emergency egress locations.
NOTICE used to convey safety information on labels and signs.
CAUTION is indicative of a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury.
Potentially hazardous situations that could result in death
or serious injury are indicated by the word WARNING.
DANGER indicates an imminently hazardous situation which,
if not avoided, will result in death or serious injury.
