Alliance Laundry Systems UD08F055 Owner's manual

Programming Supplement
www.comlaundry.com
Microprocessor
Control
Roll Heated Flatwork Finisher
Refer to Page 3 for Model Numbers
SPEED
SET +
_
Part No. 1300546R1
May 2006
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
© Copyright 2006, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
1300546 1
Table of
Contents
Model Identification ........................................................................... 3
Control Identification......................................................................... 5
Entering Programming Mode ........................................................... 7
How to Enter Programming Mode ....................................................... 7
Programming Control........................................................................ 9
Temperature Measurement Unit........................................................... 9
Maximum Preset Temperature ............................................................. 9
Operating Temperature......................................................................... 9
Temperature Regulation Hysteresis (Variance).................................... 10
Temperature for Automatic
Shut-down .......................................................................................... 10
Heating Type ........................................................................................ 10
Number of Resistor Groups Installed ................................................... 11
Resetting Parameters.......................................................................... 13
Programming Supplement

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
21300546
Notes
Programming Supplement

Programming Supplement
3
1300546 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Model Identification
Information in this manual is applicable to these
models:
UD08F055 UD20F075
UD13F063 UD20F098
UD13F078 UD20F126
UD13F079
UD13F126

Programming Supplement
1300546
4© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Notes

Programming Supplement
5
1300546 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Identification
Figure 1
1Stop Keypad 6Speed Display
2Increase Preset Temperature Keypad 7Increase Ironing Speed Keypad
3Decrease Preset Temperature Keypad 8Decrease Ironing Speed Keypad
4Display Preset Temperature Keypad 9Start Keypad
5Temperature Display
FWF1R
SPEED
SET +
_
6
7
8
9
1
2
3
4
5

Programming Supplement
1300546
6© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Notes

Programming Supplement
7
1300546 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Entering Programming Mode
For programming finisher parameters, it is necessary
to enter the Programming Mode.
How to Enter Programming Mode
1. Press the START and STOP keypads
simultaneously and turn finisher on.
2. The temperature display shows the value of the
first parameter to set, while the speed display
shows a letter or a number that identifies the
parameter. The temperature display blinks to
indicate that the value is ready to be changed.
3. Press the Display Preset Temperature keypad
(SET) until the desired option appears in the
temperature display.

Programming Supplement
1300546
8© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Notes

Programming Supplement
9
1300546 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming Control
This section offers a detailed description of all 7
options available to program.
Each description includes instructions on how to
program the option.
For more advanced users, a quick reference list of the
options available through the programming mode is in
<$elemtext<$elemtextTable 1<$elemtext.
Temperature Measurement Unit
This option allows the owner to select whether the
temperature will be displayed in Fahrenheit or Celsius.
How to Program Temperature Measurement Unit
1. Control must be in Programming Mode. Refer to
Entering Programming Mode section.
2. The current setting is shown on the Temperature
display, while “U” is shown on the Speed display.
Available values: °C / °F
Default value: °C
3. Press the Increase Preset Temperature keypad (+)
or Decrease Preset Temperature keypad (–) to
change the set value.
4. Press Display Preset Temperature keypad (SET)
to confirm the current value and proceed to the
next parameter.
How to Exit Programming Mode
To exit Programming Mode, press STOP keypad or
turn finisher off and on.
Maximum Preset Temperature
This option allows the owner to set the maximum
value the user may select when selecting an operating
temperature.
How to Program Maximum Preset Temperature
1. Control must be in Programming Mode. Refer to
Entering Programming Mode section.
2. The current value is shown in the Temperature
Display, while “M” is shown on the Speed
display.
Default value: 180 °C (356°F)
Parameter range: 1 - 180 °C (34 - 356 °F)
Precision: 1°C (1.8°F)
3. Press the Increase Preset Temperature keypad (+)
or Decrease Preset Temperature keypad (–) to
change the set value.
4. Press Display Preset Temperature keypad (SET)
to confirm the current value and proceed to the
next parameter.
How to Exit Programming Mode
To exit Programming Mode, press STOP keypad or
turn finisher off and on.
Operating Temperature
This option allows the owner to set the operating
temperature.
How to Program Operating Temperature
1. Control must be in Programming Mode. Refer to
Entering Programming Mode section.
2. The current value is shown in the Temperature
Display, while “r” is shown on the Speed display.
Default value: 130 °C (266°F)
Parameter range: 1 - 180 °C (34 - 356 °F)
Precision: 1°C (1.8°F)
3. Press the Increase Preset Temperature keypad (+)
or Decrease Preset Temperature keypad (–) to
change the set value.
4. Press Display Preset Temperature keypad (SET)
to confirm the current value and proceed to the
next parameter.
Programmable Options Available
Temperature Measurement Unit
Maximum Preset Temperature
Operating Temperature
Temperature Regulation Hysteresis (Variance)
Temperature for Automatic Shut-down
Heating Type
Number of Resistor Groups Installed
Table 1

Programming Supplement
1300546
10 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
How to Exit Programming Mode
To exit Programming Mode, press STOP keypad or
turn finisher off and on.
Temperature Regulation Hysteresis
(Variance)
This option allows the owner to define the hysteresis
(variance) for the temperature regulation.
How to Program Temperature Regulation
Hysteresis (Variance)
1. Control must be in Programming Mode. Refer to
Entering Programming Mode section.
2. The current value is shown in the Temperature
Display, while “H” is shown on the Speed
display.
Default value: 2 °C
Parameter range: 1- 5 °C (2 - 9 °F)
Precision: 1°C (1.8°F)
NOTE: With electrical heating by two resistor
groups, the hysteresis (variance) only affects the
second group, while the first is controlled in the
usual manner.
3. Press the Increase Preset Temperature keypad (+)
or Decrease Preset Temperature keypad (–) to
change the set value.
4. Press Display Preset Temperature keypad (SET)
to confirm the current value and proceed to the
next parameter.
How to Exit Programming Mode
To exit Programming Mode, press STOP keypad or
turn finisher off and on.
Temperature for Automatic
Shut-down
This option allows the owner to set the maximum shut-
down temperature of the machine.
How to Program Temperature for Automatic Shut-
down
1. Control must be in Programming Mode. Refer to
Entering Programming Mode section.
2. The current value is shown in the Temperature
Display, while “0” is shown on the Speed display.
Default value: 80 °C (176°F)
Parameter range: 1 - 180 °C (34 - 356 °F)
Precision: 1°C (1.8°F)
3. Press the Increase Preset Temperature keypad (+)
or Decrease Preset Temperature keypad (–) to
change the set value.
4. Press Display Preset Temperature keypad (SET)
to confirm the current value and proceed to the
next parameter.
How to Exit Programming Mode
To exit Programming Mode, press STOP keypad or
turn finisher off and on.
Heating Type
This option allows the owner to establish whether the
heating is electrical or by gas/steam.
How to Program Heating Type
1. Control must be in Programming Mode. Refer to
Entering Programming Mode section.
2. The current value is shown in the Temperature
Display, while “C” is shown on the Speed
display.
Default value: EL (Electrical)
Available values: EL (Electrical) or
GAS (Gas/Steam)
3. Press the Increase Preset Temperature keypad (+)
or Decrease Preset Temperature keypad (–) to
change the set value.
4. Press Display Preset Temperature keypad (SET)
to confirm the current value and proceed to the
next parameter.
How to Exit Programming Mode
To exit Programming Mode, press STOP keypad or
turn finisher off and on.

Programming Supplement
11
1300546 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Number of Resistor Groups
Installed
This option allows the owner to set the number of
heating resistor groups installed on the finisher.
NOTE: This parameter is only displayed if the
electrical heating type (EL) was selected for the
Heating Type option.
How to Program Number of Resistor Groups
Installed
1. Control must be in Programming Mode. Refer to
Entering Programming Mode section.
2. The current value is shown in the Temperature
Display, while “n” is shown on the Speed display.
Default value: 2
Available values: 1 or 2
3. Press the Increase Preset Temperature keypad (+)
or Decrease Preset Temperature keypad (–) to
change the set value.
4. Press Display Preset Temperature keypad (SET)
to confirm the current value and proceed to the
next parameter.
5. When pressing SET after setting last parameter
(Number of Resistor Groups Installed), the first
parameter (Temperature Measurement Unit) is
shown again.
NOTE: The setting of the last parameter is only
stored if you have confirmed it by pressing SET
before leaving the parameter setting mode.
How to Exit Programming Mode
To exit Programming Mode, press STOP keypad or
turn finisher off and on.

Programming Supplement
1300546
12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Notes

Programming Supplement
13
1300546 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Resetting Parameters
If needed, the owner may reset the parameters to
standard values.
1. Press START and SET keypads simultaneously
to activate standard values.
2. The Temperature display shows "Pr" to confirm
the command and the control will remain in this
mode and will not be activated.
To return to the normal working condition, turn the
finisher off and on again.
The Default Parameter Values are listed in Table
2<$elemtext.
PARAMETER VALUE
Cylinder Speed 1
Temperature Measurement Unit °C
Maximum Preset Temperature 180°C (356°F)
Operating Temperature 130°C (266°F)
Temperature Regulation Hysteresis (Variance) 2°C
Temperature for Automatic Shut-down 80°C (176°F)
Heating Type Electrical
Number of Resistor Groups Installed 2
Finisher Status Stop
Table 2
