Alliance Laundry Systems 907003062 User manual

Installation
www.comlaundry.com
Part No. 70420801R8EN
November 2011
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Tumble Dryers
120 Pound Capacity
170 Pound Capacity
Starting Serial No. 0907003062
Refer to Page 5 for Model Identification
TMB1268
TMB1268C

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
70420801 (EN) 1
Installation must conform with local codes or, in the absence of local codes, with:
In the U.S.A., installation must conform to the latest edition of the American National Standard Z223.1/
NFPA 54 “National Fuel Gas Code” and Standard ANSI/NFPA 70 “National Electric Code.”
In Canada, installation must comply with Standards CAN/CSA-B149.1 or Natural Gas and Propane
Installation Code and CSA C22.1, latest edition, Canadian Electric Code, Part I.
In Australia and New Zealand, installation must comply with the Gas Installations Standard AS/NZS 5601
Part 1: General Installations.
IMPORTANT: Information must be obtained from a local gas supplier on instructions to be followed if the
user smells gas. These instructions must be posted in a prominent location. Step-by-step instructions of the
above safety information must be posted in a prominent location near the tumble dryer for customer use.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
• WHAT TO DO IF YOU SMELL GAS:
– Do not try to light any appliance.
– Do not touch any electrical switch; do not use any phone in your building.
– Clear the room, building or area of all occupants.
– Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s
instructions.
– If you cannot reach your gas supplier, call the fire department.
• Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
W052
FOR YOUR SAFETY, the information in this manual must be followed to minimize the risk
of fire or explosion or to prevent property damage, personal injury or death.
W033
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
270420801 (EN)
The following information applies to the state of Massachusetts, USA.
This appliance can only be installed by a Massachusetts licensed plumber or gas fitter.
This appliance must be installed with a 36 inch (91 cm) long flexible gas connector.
A "T-Handle" type gas shut-off valve must be installed in the gas supply line to this appliance.
This appliance must not be installed in a bedroom or bathroom.
• Installation of unit must be performed by a qualified installer.
• Install tumble dryer according to manufacturer’s instructions and local codes.
• DO NOT install a tumble dryer with flexible plastic venting materials. If flexible metal (foil
type) duct is installed, it must be of a specific type identified by the appliance manufacturer
as suitable for use with tumble dryer. Refer to section on connecting exhaust system.
Flexible venting materials are known to collapse, be easily crushed, and trap lint. These
conditions will obstruct tumble dryer airflow and increase the risk of fire.
W752R1
•
WARNING
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
W053

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
70420801 (EN) 3
© Copyright 2011, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
Table of
Contents
Introduction......................................................................................... 5
Model Identification ............................................................................. 5
Customer Service.................................................................................. 5
Wiring Diagram Location..................................................................... 5
Serial Plate Location............................................................................. 6
Safety Information.............................................................................. 7
Important Safety Instructions ............................................................... 8
Specifications and Dimensions........................................................... 10
120 Pound Tumble Dryer Dimensions and
Exhaust Outlet Locations ................................................................... 11
170 Pound Tumble Dryer Dimensions and
Exhaust Outlet Locations ................................................................... 12
Electric and Gas Connection Locations for Gas Models...................... 13
Electric and Steam Connection Locations for Steam Models .............. 14
Electric Connection Location for Electric Models ............................... 15
Installation........................................................................................... 16
Pre-Installation Inspection .................................................................... 16
Location Requirements......................................................................... 16
Position and Level the Tumble Dryer................................................... 18
Before Placing Tumble Dryer into Service .......................................... 18
Required for CE Models Only.............................................................. 19
Installing CE Gas Drying Tumble Dryers ............................................ 20
General Information......................................................................... 20
Basic Configuration ......................................................................... 22
Specific Conversion Procedures ...................................................... 23
Exhaust Requirements ....................................................................... 25
Layout ................................................................................................... 25
Make-Up Air......................................................................................... 25
Venting ................................................................................................. 25
Individual Venting ........................................................................... 27
Manifold Venting............................................................................. 27
Gas Requirements............................................................................... 31
Gas Supply Pipe Sizing and Looping ................................................... 33
High Altitude Orifice Sizing................................................................. 35
Electrical Requirements..................................................................... 36
Grounding Instructions ......................................................................... 36
For CE Models Only........................................................................ 37
Service/Ground Location...................................................................... 38
To Connect Electrical Service to the Tumble Dryer........................ 40
Jumper Configuration Instructions ....................................................... 41
Ferrite Ring Installation........................................................................ 41
Electrical Requirements........................................................................ 42

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
470420801 (EN)
Steam Requirements........................................................................... 43
Piping Recommendations ..................................................................... 43
Installing Steam Trap and Making Condensate
Return Connections ............................................................................ 44
Thermal Oil Prep .................................................................................. 44
120 Pound Tumble Dryers.................................................................... 45
170 Pound Tumble Dryers.................................................................... 46
Adjustments......................................................................................... 47
Gas Burner Air Shutter ......................................................................... 47
Airflow Switch...................................................................................... 48
Loading Door Strike ............................................................................. 48
Loading Door Switch............................................................................ 48
Belt Drive.............................................................................................. 49
Removing Tumble Dryer from Service............................................. 50

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 5
70420801 (EN)
Introduction
Model Identification
Information in this manual is applicable to these models.
Includes models with the following control suffixes:
Customer Service
If literature or replacement parts are required, contact
the source from which the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name and address of the nearest authorized
parts distributor.
For technical assistance, call [phone].
Wiring Diagram Location
The wiring diagram is located in the junction or
contactor box.
The wiring diagram part number is in the lower
portion of the electrical data on the serial plate.
Gas Steam/Thermal Oil Electric
120 Pound
DR120G2-BA120L
DR120G2-BA120N
DR120G2-BT120L
DR120G2-BT120N
DR120G2-BU120L
DR120G2-BU120N
CA120L
CA120N
CT120L
CT120N
CU120L
CU120N
HA120L
HA120N
HT120L
HT120N
HU120L
HU120N
IT120L
IT120N
SA120L
SA120N
ST120L
ST120N
SU120L
SU120N
UA120L
UA120N
UT120L
UT120N
UU120L
UU120N
XT120L
XT120N
XU120L
XU120N
YT120L
YT120N
DR120S2-BT120S
DR120S2-BT120T
DR120S2-BU120S
DR120S2-BU120T
CT120S
CT120T
CU120S
CU120T
HT120S
HT120T
HU120S
HU120T
IT120S
IT120T
ST120S
ST120T
SU120S
SU120T
UT120S
UT120T
UU120S
UU120T
XT120S
XT120T
XU120S
XU120T
YT120S
YT120T
YU120S
YU120T
DR120E2-BT120E
DR120E2-BU120E
CT120E
CU120E
HT120E
HU120E
IT120E
ST120E
SU120E
UT120E
UU120E
YU120E
170 Pound
DR170G2-BA170L
DR170G2-BA170N
DR170G2-BT170L
DR170G2-BT170N
DR170G2-BU170L
DR170G2-BU170N
CA170L
CA170N
CT170L
CT170N
CU170L
CU170N
HA170L
HA170N
HT170L
HT170N
HU170L
HU170N
IT170L
IT170N
SA170L
SA170N
ST170L
ST170N
SU170L
SU170N
UA170L
UA170N
UT170L
UT170N
UU170L
UU170N
XT170L
XT170N
XU170L
XU170N
YT170L
YT170N
DR170S2-BT170S
DR170S2-BT170T
DR170S2-BU170S
DR170S2-BU170T
CT170S
CT170T
CU170S
CU170T
HT170S
HT170T
HU170S
HU170T
IT170S
IT170T
ST170S
ST170T
SU170S
SU170T
UT170S
UT170T
UU170S
UU170T
XT170S
XT170T
XU170S
XU170T
YT170S
YT170T
Not Applicable
R3 – reversing DX4 OPL RE – reversing OPL Micro RQ – reversing dual digital timer
RD – reversing DMP OPL RM – reversing OPL Micro RU – reversing UniLinc OPL

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
70420801 (EN)
6
Serial Plate Location
When calling or writing for information about your
product, be sure to mention model and serial numbers.
Model and serial numbers are located on the serial
plate as shown.
TMB2288N
1Serial Plate
Conversion Table
Multiply By To Obtain Multiply By To Obtain
Btu 0.252 kCal Pounds/sq. inch 0.06895 Bars
Btu 1055 Joules Pounds/sq. inch 0.070 kg/sq. cm
Inch 25.4 Millimeters Pounds (lbs.) 0.454 Kilograms
Inches W.C. 0.036 Pounds/sq. inch Boiler Horsepower 33,479 Btu/hr.
Inches W.C. 0.249 kPa Boiler Horsepower 34.5 lbs. steam/hr.
lb./inch2(psi) 6.895 kPa CFM 0.471 liters/second
ft.328.32 Liters kW 3414 Btu/hr.
TMB2288N
120 POUND Tumble Dryer
1
1
170 POUND Tumble Dryer

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 7
70420801 (EN)
Safety Information
Precautionary statements (“DANGER,” “WARNING,”
and “CAUTION”), followed by specific instructions,
are found in this manual and on machine decals. These
precautions are intended for the personal safety of the
operator, user, servicer, and those maintaining the
machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
NOTE: The WARNINGS and IMPORTANT
instructions appearing in this manual are not
meant to cover all possible conditions and
situations that may occur. It must be understood
that common sense, caution and carefulness are
factors which CANNOT be built into this tumble
dryer. These factors MUST BE supplied by the
person(s) installing, maintaining or operating the
tumble dryer.
Always contact your dealer, distributor, service agent
or the manufacturer on any problems or conditions you
do not understand.
DANGER – Indicates an imminently
hazardous situation that, if not avoided,
will cause severe personal injury or
death.
DANGER
WARNING – Indicates a hazardous
situation that, if not avoided, could cause
severe personal injury or death.
WARNING
CAUTION – Indicates a hazardous
situation that, if not avoided, may cause
minor or moderate personal injury or
property damage.
CAUTION
Failure to install, maintain, and/or operate
this machine according to manufacturer’s
instructions may result in conditions which
can produce serious injury, death and/or
property damage.
W051R1
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
70420801 (EN)
8
Save These Instructions
Important Safety Instructions
1. Read all instructions before using the tumble
dryer.
2. Refer to the Grounding Instructions for the
proper grounding of the tumble dryer.
3. Do not dry articles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry cleaning solvents, other flammable
or explosive substances as they give off vapors
that could ignite or explode.
4. Do not allow children on or in the tumble dryer.
This appliance is not intended for use by young
children or infirm persons without supervision.
Young children should be supervised to ensure
that they do not play with the appliance.
5. Before the tumble dryer is removed from service
or discarded, remove the door to the drying
compartment and the door to the lint
compartment.
6. Do not reach into the tumble dryer if the cylinder
is revolving.
7. Do not install or store the tumble dryer where it
will be exposed to water and/or weather.
8. Do not tamper with the controls.
9. Do not repair or replace any part of the tumble
dryer, or attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that you understand and have the
skills to carry out.
10. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
11. To reduce the risk of fire, DO NOT DRY plastics
or articles containing foam rubber or similarly
textured rubberlike materials.
12. Always clean the lint filter daily.
13. Keep area around the exhaust opening and
adjacent surrounding area free from the
accumulation of lint, dust and dirt.
14. The interior of the tumble dryer and the exhaust
duct should be cleaned periodically by qualified
service personnel.
15. If not installed, operated and maintained in
accordance with the manufacturer’s instructions
or if there is damage to or mishandling of this
product’s components, use of this product could
expose you to substances in the fuel or from fuel
combustion which can cause death or serious
illness and which are known to the State of
California to cause cancer, birth defects or other
reproductive harm.
16. Tumble dryer will not operate with the loading
door open. DO NOT bypass the door safety
switch to permit the tumble dryer to operate with
the door open. The cylinder will stop rotating
when the door is opened. Do not use the tumble
dryer if the cylinder does not stop rotating when
the door is opened or starts rotating without
pressing or turning the START mechanism.
Remove the tumble dryer from use and call for
service.
17. Tumble dryer will not operate with lint panel
open. DO NOT bypass lint panel safety switch to
permit tumble dryer to operate with the lint panel
open.
18. Do not put articles soiled with vegetable or
cooking oil in the tumble dryer, as these oils may
not be removed during washing. Due to the
remaining oil, the fabric may catch on fire by
itself.
19. To reduce the risk of fire, DO NOT put clothes
which have traces of any flammable substances
such as machine oil, flammable chemicals,
thinner, etc. or anything containing wax or
chemicals such as in mops and cleaning cloths, or
anything dry-cleaned at home with dry-cleaning
solvent in the tumble dryer.
20. Use the tumble dryer only for its intended
purpose, drying fabrics.
21. ALWAYS disconnect the electrical power to the
tumble dryer before servicing. Disconnect power
by shutting off appropriate breaker or fuse.
Hazardous Voltage. Can cause shock, burn
or cause death. Allow machine power to
remain off for two minutes prior to working
in and around AC inverter drive.
W359
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
9
70420801 (EN)
22. Install this tumble dryer according to this
Installation Manual. All connections for
electrical power, grounding and gas supply must
comply with local codes and be made by licensed
personnel when required.
23. Remove laundry immediately after tumble dryer
stops.
24. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of reach of children at all times
(preferably in a locked cabinet).
25. Do not tumble fiberglass curtains and draperies
unless the label says it can be done. If they are
dried, wipe out the cylinder with a damp cloth to
remove particles of fiberglass.
26. Always follow the fabric care instructions
supplied by the garment manufacturer.
27. Never operate the tumble dryer with any guards
and/or panels removed.
28. DO NOT operate the tumble dryer if it is
smoking, grinding, has missing or broken parts.
29. DO NOT bypass any safety devices.
30. Failure to install, maintain, and/or operate this
machine according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
31. Solvent vapors from dry-cleaning machines
create acids when drawn through the heater of the
unit. These acids are corrosive to the tumble
dryer as well as to the laundry load being dried.
Be sure make-up air is free of solvent vapors.
To reduce the risk of serious injury, install
lockable door(s) to prevent public access
to rear of tumble dryers.
W055R1
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70420801 (EN)
10
Specifications and Dimensions
N/A = Not Applicable
Specifications 120 Pound 170 Pound
Noise level measured during operation at
operator position of 3.3 feet (1 meter) in
front of machine and 5.2 feet (1.6 meters)
from floor.
66 dBA 66 dBA
Cylinder Size:
Inches (mm)
44 x 41
(1118 x 1041)
50.75 x 42.5
(1289 x 1080)
Cylinder Capacity dry weight:
Pounds (kg)
120
(54.4)
170
(77.1)
Standard Packaging
Weight: Pounds (kg)
Gas and Electric 1338
(607)
1667
(756)
Steam 1446
(656)
1776
(806)
Standard Packaging Shipping Dimensions:
Inch (mm)
48.5 x 72 x 90
(1232 x 1829 x 2286)
58 x 74.5 x 99
(1473 x 1892 x 2515)
Slat Crate Packaging
Weight: Pounds (kg)
Gas and Electric 1447
(656)
1791
(812)
Steam 1547
(702)
1891
(858)
Slat Crate Shipping Dimensions:
Inch (mm)
51.5 x 74 x 90.75
(1308 x 1880 x 2305)
61 x 76.5 x 99.75
(1549 x 1943 x 2534)
Cylinder Motor Horsepower 0.75 0.75
Fan Motor Horsepower 13
Air Outlet Diameter:
Inches (mm)
10
(254)
12
(300)
Maximum Static Back Pressure:
W.C.I. (mbar)
0.3
(0.8)
0.3
(0.8)
Maximum Airflow:
C.F.M (L/sec.)
1600
(755)
2450
(1156)
Gas Models
Net Weight (approximate):
Pounds (kg)
1275
(580)
1575
(716)
Gas Connection 3/4 in. NPT 1 in. NPT
Gas Burner Rating:
Btu/hr. (Mj/hr.)
270,000
(285)
395,000
(421)
Steam Models
Net Weight (approximate):
Pounds (kg)
1375
(625)
1675
(761)
Steam Connection 3/4 in. NPT inlet
3/4 in. NPT outlet
3/4 in. NPT inlet
1 in. NPT outlet
Steam Coil Rating at 100 psig:
Boiler Horsepower (Btu/hr.)
(recommended operating
pressure 80-100 psig)
11.7
(405,000)
18.8
(648,000)
Electric Models
Heating Element Rating:
Kilowatts (kW)
60 kW N/A

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
11
70420801 (EN)
120 Pound Tumble Dryer
Dimensions and Exhaust Outlet
Locations
Refer to Position and Level the Tumble Dryer to temporarily reduce the heights of these models.
TMB2326N
TMB2326N
A
B
C
D
U
V
X
H
F
Z
Y
W
TOP VIEW OF
EXHAUST
DUCT
EG
I
Cabinet Dimensions
ModelsABCDEFGH I
120L/N/E 31.38 in.
(797 mm)
32.5 in.
(826 mm)
48.91 in.
(1242 mm)
49.91 in.
(1268 mm)
67.92 in.
(1725 mm)
45.38 in.
(1153 mm)
46.38 in.
(1178 mm)
85.7 in.
(2177 mm)
70 in.
(1778 mm)
120S 31.38 in.
(797 mm)
32.5 in.
(826 mm)
48.91 in.
(1242 mm)
49.91 in.
(1268 mm)
67.92 in.
(1725 mm)
45.38 in.
(1153 mm)
46.38 in.
(1178 mm)
83.5 in.
(2121 mm)
70 in.
(1778 mm)
Exhaust Outlet Dimensions and Locations
Models U V W X Y Z
120L/N/E 63.45 in.
(1612 mm)
8.44 in.
(214 mm)
5 in.
(127 mm)
8.18 in.
(208 mm)
6.82 in.
(173 mm)
8.18 in.
(208 mm)
120S 60.7 in.
(1542 mm)
8.44 in.
(214 mm)
5 in.
(127 mm)
8.18 in.
(208 mm)
6.82 in.
(173 mm)
8.18 in.
(208 mm)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
70420801 (EN)
12
170 Pound Tumble Dryer
Dimensions and Exhaust Outlet
Locations
Refer to Position and Level the Tumble Dryer to temporarily reduce the heights of these models.
TMB2327N
TMB2327N
A
B
C
D
WH
F
Y
X
V
TOP VIEW OF
EXHAUST
DUCT
EG
I
Cabinet Dimensions
Models A B C D E F G H I
170L/N/S 33.86 in.
(860 mm)
32.5 in.
(826 mm)
50.75 in.
(1289 mm)
51.75 in.
(1314 mm)
68.85 in.
(1749 mm)
52.12 in.
(1324 mm)
53.12 in.
(1349 mm)
94 in.
(2388 mm)
75.12 in.
(1908 mm)
Exhaust Outlet Dimensions and Locations
Models V W X Y
170L/N/S 42.38 in.
(1076 mm)
6.75 in.
(171 mm)
6 in.
(152 mm)
7 in.
(178 mm)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
13
70420801 (EN)
Electric and Gas Connection
Locations for Gas Models
NOTE: These figures are approximate dimensions only.
TMB2255N
A C
C
A
DB
BD
120L/N 170L/N
Models Electrical Connection Gas Connection
ABCDDiameter
120L/N 18.34 in.
(466 mm)
77.84 in.
(1977 mm)
12.5 in.
(318 mm)
70.5 in.
(1791 mm)
3/4 in. NPT
170L/N 21 in.
(533 mm)
81 in.
(2057 mm)
14.85 in.
(377 mm)
77.4 in.
(1966 mm)
1 in. NPT

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
70420801 (EN)
14
Electric and Steam Connection
Locations for Steam Models
TMB2256N
A1
B1
120S 170S
A2
B2
DEF
A1
B1
B2
A2
D
EF
C
C
Models Steam Inlet
Diameter A1 A2 F
120S 3/4 in. NPT 35.875 in.
(911 mm)
13.375 in.
(340 mm)
82.75 in.
(2102 mm)
170S 3/4 in. NPT 37.625 in.
(956 mm)
15.25 in.
(387 mm)
88 in.
(2235 mm)
Models Steam Outlet
Diameter B1 B2 D
120S 3/4 in. NPT 34.625 in.
(879 mm)
13.125 in.
(333 mm)
68.5 in.
(1740 mm)
170S 1 in. NPT 44.625 in.
(1133 mm)
8.75 in.
(222 mm)
71.75 in.
(1822 mm)
Models Electrical Connection
CE
120S 18.34 in.
(466 mm)
77.84 in.
(1977 mm)
170S 21 in.
(533 mm)
81 in.
(2057 mm)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
15
70420801 (EN)
Electric Connection Location for
Electric Models
TMB2336N
A
B
Models A B
120E 35.81 in.
(910 mm)
85.64 in.
(2175 mm)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70420801 (EN)
16
Installation
Pre-Installation Inspection
Upon delivery, visually inspect the crate, carton and
parts for any visible shipping damage. If the crate,
carton or cover is damaged or signs of possible
damage are evident, have the carrier note the condition
on the shipping papers before the shipping receipt is
signed, or advise the carrier of the condition as soon as
it is discovered.
Remove the crate and protective cover as soon as
possible and check the items listed on the packing list.
Advise the carrier of any damaged or missing articles
as soon as possible. A written claim should be filed
with the carrier immediately if articles are damaged
or missing.
IMPORTANT: Warranty is void unless tumble
dryer is installed according to instructions in this
manual. Installation should comply with minimum
specifications and requirements detailed in this
manual and applicable local gas fitting regulations,
municipal building codes, water supply regulations,
electrical wiring regulations, and any other
relevant statutory regulations. Due to varied
requirements, applicable local codes should be
thoroughly understood and all pre-installation
work arranged for accordingly.
IMPORTANT: Keep tumble dryer area clear and
free from combustible materials, gasoline and other
flammable vapors and liquids.
Location Requirements
The tumble dryer must be installed on a level floor.
Floor covering materials such as carpeting or tile must
be removed.
To assure compliance, consult local building code
requirements. The tumble dryer must not be installed
or stored in area where it will be exposed to water and/
or weather.
IMPORTANT: DO NOT block the airflow at the
rear of the tumble dryer with laundry or other
articles. Doing so would prevent adequate air
supply to the combustion chamber of the tumble
dryer.
A typical tumble dryer enclosure is shown in Figure 1.
Note the minimum and maximum dimensions. Local
codes and ordinances must be complied with.
Materials Required (Obtain locally)
All Models One Single Pole fused disconnect
switch or circuit breaker on 1 Phase
models.
Circuit breaker on 3 Phase models.
Gas Models One gas shut-off valve for gas
service line to each tumble dryer.
Steam Models One steam shut-off valve for steam
service line to be connected upstream
of solenoid steam valve.
Two steam shut-off valves for each
condensate return line.
Flexible steam hoses with a 125 psig
(pounds per square inch gauge)
(8.79 kg/sq. cm) working pressure
for connecting steam coils. Refer to
Figure 14 and Figure 15 or sizing
and connection configurations.
Three steam traps for steam coil
outlet to condensate return line.
Optional – Three vacuum breakers
for condensate return lines.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
17
70420801 (EN)
IMPORTANT: Install tumble dryers with sufficient
clearance for servicing and operation. Refer to
Figure 1.
Figure 1
To reduce the risk of serious injury, install
lockable door(s) to prevent public access
to rear of tumble dryers.
W055R1
WARNING
TMB2020N
NOTE: Shaded areas indicate adjacent structure.
10.5 in. (13 mm) recommended between machines for removal or installation.
2Allow 2-4 in. (51-102 mm) opening at top of machine to aid in removal or installation. A removable trim piece
may be used to conceal the opening; zero clearance allowed for trim.
34 in. (102 mm) maximum header thickness
4Minimum clearance permitted for remainder: Gas 4 in. (102 mm), Steam 12 in. (305 mm)
5Guard
6Provision for Make-Up Air
724 in. (610 mm) minimum, 36 in. (914 mm) recommended for maintenance purposes
80.25 in. (6 mm) recommended for removal or installation purposes, zero clearance allowed
TMB2020N
4
1
5
6
7
3
WARNING
To reduce the risk of severe injury, clearance of tumble dryer cabinet from combustible
construction must conform to the minimum clearances.
W056R1
8
2

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
70420801 (EN)
18
Position and Level the Tumble Dryer
The tumble dryer may be moved with or without the
skid. To remove the skid, unscrew the four shipping
bolts, and discard them.
To fit a 170 pound tumble dryer (with shipping skid)
through an 8 foot (2.43 meters) high door, you must
remove the front access panel. The upper 3 inches
(76 mm) of the stove must also be removed on
170 pound gas tumble dryers. Removing the entire gas
or steam heater assembly and the shipping skid, will
reduce the height of the 120 pound tumble dryer to 70
inches (1778 mm), and the 170 pound tumble dryer to
75 inches (1905 mm).
Level the tumble dryer to within 0.125 inch (3 mm)
from front-to-rear (level on cylinder rib), and side-to-
side (level on top panel). Shim under corners to level
and stabilize unit. Tumble dryer must not rock.
Before Placing Tumble Dryer into
Service
1. Remove or open all panels and check accessible
bolts, nuts, screws, terminals and fittings for
tightness.
2. Check V-belt tension and adjust if necessary.
Refer to appropriate paragraphs in Adjustments
Section.
3. Replace all panels and guards.
4. Turn on electrical supply to tumble dryer.
5. Open supply valve for gas or steam heated
tumble dryers.
6. After performing the previous checks, start
the tumble dryer by pressing START (hold for
approximately 3 seconds). Release the start
button and open the loading door. The cylinder
should stop rotating within 7 seconds after the
door is opened.
7. Gas tumble dryers: Start the tumble dryer and
check the burner flame. Adjust the gas inlet
shutter as required. Refer to Adjustments section.
IMPORTANT: The Electronic Ignition system will
attempt to light the gas by sparking for the “trial
for ignition” period. If gas does not ignite within
this period, the ignition control will go into a safety
lockout and the valve will no longer open until the
control is reset. Refer to Tabl e 1. It may be
necessary to restart several times to bleed air out of
gas lines. To reset, open and close loading door,
then start.
If lockout condition persists, check that the manual
gas shut-off valve is in the open position and that
the gas service is properly connected. If condition
still persists, remove tumble dryer from service.
8. Load the cylinder with a full load of clean rags
and run to remove oil or dirt from cylinder.
Location
Prepurge
Time
(seconds)
Trial for
Ignition
(seconds)
Reset
Lockout
Condition
By:
CE and
Australia 18 10
Press and
hold reset
button on
junction box
until light
goes out.
All others 1-3 10 Open loading
door.
Table 1
