Preliminary Installation Information
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Subject 200 Pound Tumble Dryer
Use With 70420801 Installation Manual
Model Identification
Includes models with the following control suffixes:
Gas Steam/Thermal Oil
200 Pound
DR200G2-BA200L
DR200G2-BA200N
DR200G2-BT200L
DR200G2-BT200N
DR200G2-BU200L
DR200G2-BU200N
CA200L
CA200N
CT200L
CT200N
CU200L
CU200N
HA200L
HA200N
HT200L
HT200N
HU200L
HU200N
IT200L
IT200N
SA200L
SA200N
ST200L
ST200N
SU200L
SU200N
UA200L
UA200N
UT200L
UT200N
UU200L
UU200N
DR200S2-BT200S
DR200S2-BT200T
DR200S2-BU200S
DR200S2-BU200T
CT200S
CT200T
CU200S
CU200T
HT200S
HT200T
HU200S
HU200T
IT200S
IT200T
ST200S
ST200T
SU200S
SU200T
UT200S
UT200T
UU200S
UU200T
R3 – reversing DX4 OPL RE – reversing OPL Micro RQ – reversing dual digital timer
RD – reversing DMP OPL RM – reversing OPL Micro RU – reversing UniLinc OPL
Part No. 70470101R1
April 2012

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Page 2 of 12
Specifications and Dimensions
N/A = Not Applicable
Specifications 200 Pound
Noise level measured during operation at operator position of 3.3 feet
(1 meter) in front of machine and 5.2 feet (1.6 meters) from floor. 66 dBA
Cylinder Size: Inches (mm) 50.75 x 50
(1289 x 1270)
Cylinder Capacity dry weight: Pounds (kg) 200
(90.7)
Cylinder Motor Horsepower 0.75
Fan Motor Horsepower 3
Air Outlet Diameter: Inches (mm) 12
(300)
Maximum Static Back Pressure: W.C.I. (mbar) 0.3
(0.8)
Maximum Airflow: C.F.M (L/sec.) 2450
(1156)
Gas Models
Net Weight (approximate): Pounds (kg) 1707
(774)
Gas Connection 1 in. NPT
Gas Burner Rating: Btu/hr. (Mj/hr.) 425,000
(448)
Steam Models
Net Weight (approximate): Pounds (kg) 1807
(820)
Steam Connection 3/4 in. NPT inlet
1 in. NPT outlet
Steam Coil Rating at 100 psig:Boiler Horsepower (Btu/hr.)
(recommended operating pressure 80-100 psig) 18.8 (648,000)
Electric Models
Heating Element Rating:Kilowatts (kW) N/A

Page 3 of 12
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
200 Pound Tumble Dryer
Dimensions and Exhaust Outlet
Locations
Refer to Position and Level the Tumble Dryer to temporarily reduce the heights of these models.
TMB2363N
TMB2363N
A
B
C
D
W
H
F
Y
X
V
TOP VIEW OF
EXHAUST
DUCT
EG
I
Cabinet Dimensions
Models A B C D E F G H I
200L/N/S 32.1 in.
(815 mm) 35.6 in. (904 mm) 58 in. (1473 mm) 59.25 in. (1505 mm) 76.68 in. (1948 mm) 52.12 in. (1324 mm) 53.12 in. (1349 mm) 94 in. (2388 mm) 75.12 in. (1908 mm)
Exhaust Outlet Dimensions and Locations
Models V W X Y
200L/N/S 67.19 in.
(1707 mm) 7.03 in. (179 mm) 9 in. (229 mm) 7 in. (178 mm)

Page 4 of 12
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Electric and Gas Connection
Locations for Gas Models
NOTE: These figures are approximate dimensions only.
TMB2357N
C
A
BD
Models Electrical Connection Gas Connection
ABCDDiameter
200L/N 21 in.
(533 mm) 81 in. (2057 mm) 13.7 in. (348 mm) 77.4 in. (1966 mm) 1 in. NPT

Page 5 of 12
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Electric and Steam Connection
Locations for Steam Models
TMB2358N
A1
B1
B2
A2
DEF
C
Models Steam Inlet
Diameter A1 A2 F
200S 3/4 in. NPT 37.625 in.
(956 mm) 15.25 in. (387 mm) 88 in. (2235 mm)
Models Steam Outlet
Diameter B1 B2 D
200S 1 in. NPT 44.625 in.
(1133 mm) 8.75 in. (222 mm) 71.75 in. (1822 mm)
Models Electrical Connection
CE
200S 21 in.
(533 mm) 81 in. (2057 mm)

Page 6 of 12
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Position and Level the Tumble Dryer
The tumble dryer may be moved with or without the
skid. To remove the skid, unscrew the four shipping
bolts, and discard them.
To fit a 200 pound tumble dryer (with shipping skid)
through an 8 foot (2.43 meters) high door, you must
remove the front access panel. The upper 3 inches
(76 mm) of the stove must also be removed on
200 pound gas tumble dryers. Removing the entire gas
or steam heater assembly and the shipping skid will
reduce the height to 75 inches (1905 mm).
Level the tumble dryer to within 0.125 inch (3 mm)
from front-to-rear (level on cylinder rib), and side-to-
side (level on top panel). Shim under corners to level
and stabilize unit. Tumble dryer must not rock.
Make-Up Air
Table 1
Required Make-Up Air Opening
(to the outside) for Each Tumble Dryer
Models Opening
200 Pound 525 in.2(3710 cm2)
free air

Page 7 of 12
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Exhaust Requirements
Figure 1
TMB2019N
1 NOTE: Where the exhaust duct pierces a
combustible wall or ceiling, the opening
MUST be sized per local codes.
2Outlet Duct Diameter
345° Typical
LKJ I HG F
EDCBA
3
1
2
ONE MANIFOLD ASSEMBLY
Duct
Stations 200 Pound
12 in. (305 mm) Duct
A12 in. (305 mm)
B17 in. (432 mm)
C21 in. (533 mm)
D24 in. (610 mm)
E27 in. (686 mm)
F30 in. (762 mm)
G32 in. (813 mm)
H34 in. (864 mm)
I36 in. (914 mm)
J38 in. (965 mm)
K40 in. (1016 mm)
L42 in. (1067 mm)
Table 2

Page 8 of 12
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
TMB2018N
1 NOTE: Where the exhaust duct pierces a
combustible wall or ceiling, the opening
MUST be sized per local codes.
2Outlet Duct Diameter
345° Typical
Figure 2
Duct
Stations 200 Pound
12 in. (305 mm) Duct
A17 in. (432 mm)
B24 in. (610 mm)
C30 in. (762 mm)
D34 in. (864 mm)
E38 in. (965 mm)
F42 in. (1067 mm)
G45 in. (1143 mm)
H45 in. (1143 mm)
I52 in. (1321 mm)
J54 in. (1372 mm)
K57 in. (1448 mm)
L60 in. (1524 mm)
Table 3
TMB2018N
1
2
3
LKJI
L
K
J
I
CONTINUE
TO A CONTINUE
TO A
TWO MANIFOLD ASSEMBLIES

Page 9 of 12
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Gas Requirements
For converting Non-CE Models from Natural Gas to
L.P. Gas:
200 Pound Models - M4975P3
High Altitude Orifice Sizing
For proper operation at altitudes above 2000 feet (610
meters), the gas orifice size must be reduced to ensure
complete combustion. Refer to Table 4.
For CE models, consult local gas supplier.
Non-CE Models
Model Gas Altitude Orifice New
Rate
feet m No. inches mm Quantity Part No. (Btu/hr.)*
200L/N
Natural
Gas
2001 – 4000 610 – 1220 19 .1660 4.2
5
M402995 391,000
4001 – 6000 1221 – 1830 20 .1610 4.1 M401002 357,000
6001 – 8000 1831 – 2440 22 .1570 4.0 M402996 323,000
8001 – 10,000 2441 – 3050 24 .1520 3.9 M402980 289,000
L.P.
Gas
2001 – 4000 610 – 1220 33 .1130 2.9
4
M401022 391,000
4001 – 6000 1221 – 1830 34 .1110 2.8 M411512 357,000
6001 – 8000 1831 – 2440 7/64 .1094 2.8 70070902 323,000
8001 – 10,000 2441 – 3050 37 .1040 2.6 M401024 289,000
* Btu/hr. derate of 4% per 1000 ft. (305 m) of altitude.
Table 4

Page 10 of 12
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Electrical Requirements
For 200 Pound Tumble Dryer Models
Serial Plate Rating Terminal Block
Connections Required Rated Current* Breaker Rating Recommended Wire Size
200-208V/60Hz/3ph L1, L2, L3 and ground 14 20A - 3 pole 12 AWG (3.31 mm2)
240V/60Hz/3ph L1, L2, L3 and ground 14 20A - 3 pole 12 AWG (3.31 mm2)
380V/50 or 60Hz/3ph L1, L2, L3 and ground 8 15A - 3 pole 14 AWG (2.08 mm2)
400-415V/50Hz/3ph L1, L2, L3 and ground 8 15A - 3 pole 14 AWG (2.08 mm2)
440V/60Hz/3ph L1, L2, L3 and ground 7 15A - 3 pole 14 AWG (2.08 mm2)
460-480V/60Hz/3ph L1, L2, L3 and ground 7 15A - 3 pole 14 AWG (2.08 mm2)
* Current ratings vary slightly depending on model; refer to serial plate.
Table 5

Page 11 of 12
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Steam Requirements
Figure 3
TMB2024N
NOTE: Refer to Table 6 for sizing of steam lines. Piping must also be sized accordingly for length of runs and number
of elbows.
1Risers 12 in. (305 mm) 618 in. Drop (457 mm)
2Shut-Off Valve 7Steam Bonnet
3Check Valve 8Solenoid Valve (Supplied with machine)
4Vacuum Breaker (optional) 9Union
5Condensate Return Line from Supply Line 10 Trap with Built-In Strainer
TMB2024N
SUPPLY
2
1
9
3
RETURN
2
3
710
4
5
8
6
Model Steam Pressure
PSI (bar) Minimum Supply Pipe Diameter Steam Trap Size * (Pounds Condensate/Hour)
200S 80-100 (5.3-6.9) 1-1/4 in. NPT 517
* Based on maximum psi.
Table 6

Page 12 of 12
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Loading Door Strike
The loading door strike must be adjusted to have
sufficient tension to hold loading door closed against
force of load tumbling against it. Proper adjustment is
when 8-15 pounds (35.6-66.7 N) pull is required to
open door.
If adjustment is required, refer to Figure 4 and proceed
as follows:
To adjust, open door, loosen adjustment screws and
position strike for desired magnet engagement.
retighten screws.
Figure 4
Belt Drive
NOTE: Proper tensions for new belts are
45-55 pounds for the motor belt, 55-65 pounds for
the final drive and 65-70 pounds for 200 pound
blower, measured with a Borroughs Belt Tension
Gauge. Using a Browning Belt Tension Gauge, the
motor belt deflection should be 0.31 inch at five
pounds pressure, and final drive belt deflection
should be 0.25 inch at five pounds pressure.
TMB2359N
1Door Strike
2Adjustment Screws
1
2
