Allied Healthcare EPV100 User manual

EPV100 Portable Ventilator
Battery Powered Ventilator
With Oxygen Source Required
St. Louis, MO 63110
Phone [phone]
Patent Pending
S168-556-001 Rev. C

2
Table of Contents:
Section
Description
Page
1
Product Description
3
2
Product Intended Use
3
3
Explanation of Warnings
3
4
Explanation of Abbreviations
3
5
Specifications
4
6
Features
5
7
Operating the Ventilator
6 - 8
8
Alarms
9
9
Battery Replacement
10
10
Cleaning
10-11
11
Maintenance and Schedule
11-12
12
Check-out procedure
13
13
Accessories
14
14
Warranty
14
15
Oxygen Cylinder Depletion Times
15 - 16
16
Symbols
16
17
Applicable Standards
17
18
Approximate settings based on height
18 - 19
19
Attaching EPV100 to equipment
20
Models: EPV100

3
1 Product Description:
The EPV100 is an internal battery powered, electronically controlled, portable ventilator
that requires a 50 psi oxygen source. The EPV100 has selectable Tidal Volume, BPM
and Inspiratory Times, based on the intended Patients’respiratory requirements.
2 Product Intended Use:
The EPV100 is intended to be used as an electronically controlled gas powered
emergency ventilator, which is designed to provide emergency respiratory support by
means of a face mask or tube inserted into the patient’s airway. The ventilator is
intended for use on patients weighing greater than 20kg (44 lbs). This ventilator is
intended to be used in the environments associated with emergency medical services
(EMS), inter-hospital transport and hospital facility usage. The ventilator is intended to
be used in temperatures of -9 to 50°C (15 to 122°F) and 5% - 95% relative humidity,
non condensing.
Biocompatibility testing has proven this unit safe for periods up to 14 days of continuous
use. Results beyond this length of time are not known.
CAUTION: Federal law restricts this device to sale by or on the order of a
physician.
CAUTION: The EPV100 should not be used on children with a weight of 20 kg
(44 lbs) or less.
3 Explanation of Warnings:
Warning: Potential injury to the patient or operator exists.
Caution: Potential damage to the ventilator, breathing circuit or other equipment may
result.
Warnings and cautions should be read and understood before operating the ventilator.
4 Explanation of Abbreviations:
Tv
Tidal Volume
BPM
Breaths per Minute
It
Inspiratory Time
Psi
Pounds per Square Inch
cm H2O
Centimeters of Water
kpa
kilopascal
ml
Milliliters
LPM
Liters per minute
mm
Millimeters
LED
Light emitting diode
CPR
Cardio Pulmonary Resuscitation
HPA
High pressure alarm
RH
Relative Humidity

4
5 Specifications:
A. Gas Supply Pressure: 280 kPa (40.6psi) to 600 kPa (87 psi) Oxygen DISS
B. Breaths per Minute (BPM): Accuracy: ±10%
BPM Range: 1 sec Inspiratory Time = 8 to 30
BPM Range: 2 sec Inspiratory Time = 8 to 20
C. Tidal Volume (Tv): Accuracy: ±10% with 100% Oxygen
Tidal Volume Range 1 Second Inspiratory Time = 200ml to 600ml
Tidal Volume Range 2 Second Inspiratory Time = 400ml to 1200ml
D. Inspiratory Time (It): Accuracy: ±10%
1 second or 2 second selection
E. Safety Pressure Relief: Fixed at a maximum of 60 cm H2O.
F. Low Source Gas Alarm: Activates at 275 to 241kPa (40 to 35 psi) source
pressure.
G. High Airway Pressure Alarm Electronic: Activates at 45 cm H2O
Alarm Sound Level is greater than 58 decibels
H. Breath Delivery Alarm: Activates if the Airway pressure does not go above 9
cm H2O during a span of 15 seconds.
I. Battery Life: Greater than 48 hours at room temperature (10 BPM & 2 sec It)
J. Oxygen Inlet Filter: 65 Micron sintered bronze.
K. Leakage: The unit shall be designed so that pressurized oxygen is not allowed
to leak through any seals or fittings.
L. Gauge: 0-99 cm H2O accuracy ± 5% or 1 cm H2O whichever is greater
M. Inspiratory and Expiratory Resistance: 5 cm H2O (.5kPa) maximum
N. Inadvertent PEEP: < 2 cm H2O
O. Inadvertent Continuing Expiratory Pressure: < 2 cm H2O
P. Dead Space: < 5.5% of minimum tidal volume
Q. Weight: 1.4 kg (3.1 lbs.) with batteries
R. Size: 3.5 x 7.0 x 9.3 (88.9 x 177.8 x 236.2 mm)
S. Operating Conditions: -9 to 50°C (15 to 122°F) 5% - 95% RH non condensing
T. Storage Conditions: -40 to 60°C (-40 to 140°F) 5% - 95% RH non condensing
U. Shipping Conditions: -40 to 60°C (-40 to 140°F) 5% - 95% RH non condensing
Latex Free: This product does not contain latex.

5
6 Features:
Item #
Description
Item #
Description
1
Tidal Volume Control
8
Anti-Suffocation Valve
2
Inspiratory Time Control
9
Patient Circuit Connection
3
BPM Control
10
High Airway Pressure Alarm
4
Oxygen Inlet
11
Low Source Gas Alarm
5
Airway Pressure Display
12
Low Battery Alarm
6
Power On/Off Switch
13
Breath Delivery Alarm if
Flashing
7
Battery Compartment
14
BPM Display
3
5
5
2
12
11
10
13
6
5
4
5
1
5
7
5
9
5
8
5
14

6
7 Operating the Ventilator:
Warning: This device should only be operated by qualified personnel
under approved medical direction.
Warning: Use only as directed. Improper usage or unauthorized
modification of this product may result in user or patient injury.
Warning: Unit is not MRI compatible.
Warning: Not for use in Toxic Environment or in the presence of
flammable anesthetics.
Connecting to an Oxygen Source:
Located on the right side of the ventilator and marked with text is a diameter index
safety system (DISS) fitting. Connect a 50 psi oxygen source with a minimum of 40
LPM flow capacity to this fitting. The unit comes with a single use supply hose made of
PVC. A rubber reusable hose may be purchased and is recommended. See
accessories.
Warning: Proper tidal volumes may not be provided with a gas source
not meeting the specified requirements on page 4.
Warning: This device operates with medical gases under pressure,
including oxygen. Do not use this device while smoking or near open
flames. Do not use on this device or operate near flammable materials.
Caution: In order to provide optimal performance, check all gas
supplies to assure only clean, dry gas is used, free of contaminants
and/or liquids.
The gas source may also be a high flow air/oxygen blend meeting the flow and pressure
requirements.
Select the proper inspiratory time:
Press the ON/OFF button to activate the unit. The EPV100 has the options of a 2
second inspiratory time (this is used on adults with tidal volume requirements of more
than 600ml) and a 1 second inspiratory time (this is used on children or adults). Push
the appropriate Inspiratory time button and a green LED will show the selected
Inspiratory time
Select the desired Breaths per Minute, BPM:
The EPV100 has a BPM range of 8 to 20 with a 2 second inspiratory time and a BPM
range of 8 to 30 with a 1 second inspiratory time. Use the up and down arrows above
or below the text “BPM” to set the desired BPM. The BPM setting will be displayed in
the window above the selection arrows.
The American Heart Association Guidelines 2005 recommend a BPM rate of 8 to 12 for
an adult and 12 to 20 for a child. These are recommendations and you should always
follow your physicians or medical directors’ instructions.
Select the desired Tidal volume, Tv:
Turn the tidal volume knob to desired tidal volume. The flow to the patient is different
for each tidal volume.

7
Tidal Volume Setting
Approximate Flow (LPM)
It= 1 second
It= 2 second
200
400
12
240
480
14.4
280
560
16.8
320
640
19.2
360
720
21.6
400
800
24
440
880
26.4
480
960
28.8
520
1040
31.2
560
1120
33.6
600
1200
36
Verify the Pressure Relief Setting:
This unit has a factory set pressure relief setting of less than 60cm H2O. The 60
cmH2O setting is a maximum regardless of vent settings. The pressure relief setting
will vary slightly with tidal volume setting. Lower tidal volumes will have a slightly lower
pressure relief point. Always verify the relief pressure after the vent settings have been
selected. To check the actual relief pressure, block the end of the ventilator breathing
circuit and observe the reading on the airway pressure gauge. This will be the
maximum airway pressure. You should hear an audible alarm and see a flashing light
as this maximum pressure is reached.
Warning: Preset tidal volumes may not be delivered when the
maximum pressure limit is reached. Inspiratory times will remain
constant, however no additional tidal volume will be delivered after the
pressure limit is reached.
Connecting the patient breathing circuit:
Located on the left side of the unit is a 22mm connection for a patient breathing circuit.
The patient breathing circuit has been design to fit with an oxygen mask (22mm outside
diameter) or endotracheal tube (15mm inside diameter). Install the corrugated tubing
over the connector so that it is on securely. Follow the established guidelines for
maintaining the patient’s airway.
Verify the patient is receiving good ventilation:
Once the patient is connected to the ventilator the patient should be observed to make
sure they have adequate chest rise and fall. The chest rise should be even and should
return to a normal position. If the patient does not have adequate chest rise check the
tidal volume setting, patient connections and examine the patient for a possible
obstruction of the airway or other injury. The patient should be monitored to make sure
they are receiving proper ventilation.

8
The airway pressure gauge should be observed to make sure the patient is receiving
adequate positive pressure ventilation. If the gauge reading is low during the delivery of
a breath and the chest rise is also low, check the tidal volume setting, patient
connections and examine the patient for a possible obstruction of the airway or other
injury. The gauge reading should also be observed to make sure it is not too high.
Common numbers used in practice are a maximum of 20 cm H2O for and unprotected
airway and 30 cm H2O for a protected airway. Higher pressures may be required
based on the patient’s condition and you should always follow the physician’s
instructions. A high reading with pressure limit alarm may indicate a blocked airway or
a stiff lung. If you are using a PEEP valve with the ventilator circuit the PEEP pressure
will not be displayed on the gauge (airway pressure display).
Spontaneous Breathing by the Patient:
Should the patient begin to breathe spontaneously the EPV100 will allow ambient air to
be pulled in through an anti-suffocation valve located in the breathing circuit connection
fitting. The EPV100 ventilator will not adjust its breath delivery if the patient breathes
spontaneously.
Warning: Do not cover or block Anti-suffocation valve.
Warning: Should a mechanical problem develop or the patient appears
to be experiencing difficulty breathing while connected to the unit,
disconnect the unit immediately and ventilate by other means.
Cold Temperature Operation
Operating time will be significantly reduced if the batteries are stored at low
temperatures. At 15°F (-9°C) the battery life will be approximately 9 hours (10 BPM and
2 second It) before the low battery indicator turns on. The low battery indicator will still
give about a 2 hour low battery warning. Batteries should be replaced when the low
battery indicator appears as run times are reduced at low temperatures. When the unit
stops operating you will receive a breath delivery alarm.
Warning: Batteries stored at temperatures below 15°F (-9°C) may not
have enough power to properly operate the solenoid valve in the unit
resulting in tidal volumes that are not the indicated value.

9
8 Alarms:
This ventilator contains several alarms. These alarms are high airway pressure, low
source gas, low battery and a breath delivery failure alarm.
The high airway alarm is an audible alarm with a red LED that is actuated when the
airway pressure during inspiration reaches 45 cm H2O. The safety pressure relief will
actuate at pressures between the alarm setting and 60 cm H2O.
Warning: Preset tidal volumes may not be delivered when the
maximum pressure limit is reached. Inspiratory times will remain
constant, however no additional tidal volume will be delivered after the
pressure limit is reached.
This alarm is automatically cleared when 25 seconds pass without a high airway
pressure being detected.
Low source gas alarm is an audible alarm with a red LED that activates when the
source gas pressure drops below 40 to 35 psi. This is an indication that the unit will
stop functioning soon and that the unit may not be delivering proper tidal volumes.
Warning: Preset tidal volumes may not be delivered when the low
source gas pressure is reached.
This alarm clears when proper source gas pressure is restored for 15 seconds.
The low battery alarm is a red LED that indicates the battery is running low. The unit
will operate about 2 hours after the alarm first turns on. The batteries should be
replaced when the low battery alarm turns on.
Warning: The displays on the unit will stay on after the unit has
stopped delivering breaths. Batteries should be replaced when a low
battery condition is encountered.
This alarm clears when the batteries have proper battery voltage.
The breath delivery alarm is a flashing red LED. This alarm uses the same light as
the high airway pressure alarm. The breath delivery alarm will sound when the airway
pressure does not reach 9 cm H2O in 15 seconds. This alarm may indicate that the
patient has become disconnected from the unit or the unit has stopped delivering
breaths. This alarm clears when airway pressure exceeds 9 cm H2O.
Silence Button –When there is an alarm, the user may press the button for the
currently selected inspiratory time for 3 seconds to silence the alarm. This will turn off
the buzzer for 110 seconds as long as there are no other alarms. Pressing this button
will not clear the alarm LED’s.

10
9 Battery Replacement:
The batteries are replaced by loosening the 4 thumbscrews on the battery door located
on the front of the unit. The batteries should be removed by gently prying the top (+) of
the battery up and towards the bottom of the unit. Replace the batteries with 2 “D” size
alkaline batteries only. Do not mix new and old batteries when installing in unit. The
batteries must be inserted with the positive (+) end of the battery towards the top of the
unit. For ease of installation, install the bottom (-) of the battery first. Replace the
battery door and tighten the 4 thumbscrews.
Turn the unit on and verify that the displays turn on. Connect a 50 psi oxygen source to
the unit and verify that the unit does deliver breaths. The breath delivery alarm will
sound if the unit is not connected to a test lung. This is normal and not a concern. The
ventilator is now ready for use. Always turn the ventilator off when not in use to
preserve battery life. The ventilator does not turn off automatically.
Warning: Do not recharge alkaline batteries.
10 Cleaning:
The EPV100 should be cleaned after each use. To clean the EPV100 keep the gas
supply hose on the unit to prevent contamination of the oxygen circuit.
Warning: Cleaning procedures should be performed in an environment
free of oil and petroleum based products.
The EPV100 has been designed to be water resistant but the unit cannot be submerged
or sprayed down for cleaning.
Wipe the unit down with a damp rag containing a mild detergent to remove any residue
from the surface. Once the residue has been removed the unit may be wiped with
isopropyl alcohol or a cold disinfecting solution to kill bacteria. The unit should be wiped
down with water to remove any film left by the cold disinfecting solution. Make sure the
unit is dry before putting the unit away. The following is a list of tested cleaning
solutions
Loosen
Screws on
Battery
Door
4 Places
Positive (+) end of battery
towards the top of the unit.

11
1. Isopropyl Alcohol : 70% IPA
2. Alconox: 1 Tablespoon Alconox to 1 Gallon H2O
3. Cetylcide: 2 Tablespoon Cetylcide to 1 Gallon H2O
4. Bleach: 10% Bleach in H2O
Dispose of single patient use items per local biohazard standards.
11 Maintenance and Schedule:
The EPV100 should be checked annually to insure proper function. Batteries should be
replaced if they are beyond the expiration date on the battery. Replace with “D” sized
alkaline batteries.
Year 1:
Perform Yearly Verification and Calibration procedure, check battery expiration date,
replace as necessary.
Year 2:
Perform Yearly Verification and Calibration procedure, check battery expiration date,
replace as necessary. Replace disposable O2inlet hose with 6 ft Oxygen hose, see
accessories.
Replace main valve with piston, o-ring, and spring for units manufactured before April
2009. The manufacturing date is coded into the serial number for each unit. The first
four digits identify the year of manufacture, the next two digits identify the month of
manufacture. As an example, the serial number 20090403001 was manufactured in the
year 2009 and in the month of April. All repairs should be performed by Allied
Healthcare Products trained and certified technicians.
Year 3:
Perform Yearly Verification and Calibration procedure, check battery expiration date,
replace as necessary
Year 4:
Perform Yearly Verification and Calibration procedure, check battery expiration date,
replace as necessary
Year 5:
Perform Yearly Verification and Calibration procedure, check battery expiration date,
replace as necessary.
The unit has a life expectancy of 5 years based on normal usage and proper
maintenance. A comprehensive rebuild will be necessary at this time, and should be
performed by Allied Healthcare Products trained and certified technicians.

12
Yearly Verification and Calibration:
Equipment Required
Certified gas flow analyzer, capable of measuring, BPM, Inspiratory time and
Tidal volume.
Regulated 50 PSI Oxygen source
New batteries
36 inches of 22 mm Corrugated tubing, or the allied patient circuit provided.
Procedure
Connect the 50 PSI Oxygen source to the Oxygen inlet connector.
Connect the 22mm corrugated tubing to the Patient circuit connection valve, and
the other end to the gas analyzer.
Turn the tidal volume, Inspiratory time and BPM to the values indicated in the
table below. Monitor the values to evaluate acceptability of the unit.
Inspiratory
Time
setting
(seconds)
Inspiratory
Time acceptable
Values
(seconds)
BPM
setting
BPM
Acceptable
value
Tidal
Volume
Setting
(ml)
Tidal
Volume
Acceptable
Value
(ml)
2.0
1.8 - 2.2
20
18 -22
400
360 - 440
2.0
1.8 - 2.2
10
9 - 11
800
720 - 880
2.0
1.8 - 2.2
10
9 - 11
1200
1080 -1320
1.0
0.9 –1.1
30
27 - 33
200
180 - 220
1.0
0.9 –1.1
20
18 - 22
400
360 - 440
1.0
0.9 –1.1
20
18 - 22
600
540 - 660
To test pressure relief, turn tidal volume to 640 ml, block the patient end of the
22 mm corrugated tubing or patient circuit while monitoring the airway pressure
display. The airway pressure should not exceed 60 cm-H2O. The High Airway
Pressure alarm should sound and a red LED should be activated.
To test the Breath Delivery Alarm, remove all obstructions from the Patient circuit
connection valve and allow the ventilator to cycle. The Breath Delivery Alarm
should sound, and a red LED should be flashing.
To test the Low Source Gas alarm, reduce the inlet pressure source below 35
PSI. The Low Source Gas alarm should sound and a red LED should be
flashing.
Should the unit fail any of these tests contact Allied Healthcare Products, Inc., technical
support center at 1-800-411-5136

13
12 Check-out Procedure :
The unit should be checked for proper operation before each use. This can be done
after cleaning to prepare the unit for the next use.
Set the ventilator to the following settings:
BPM = 10
Tidal Volume = 640
Inspiratory time = 2 seconds
General Operation Check:
1. Connect a 50 PSI Oxygen source to the unit, turn the power on and it should
begin to cycle.
2. Using a stop watch count the number of breaths delivered in 1 minute (60
seconds).
Confirm that between 9 and 11 breaths have been delivered.
Confirm that the inspiratory time is significantly shorter than the expiratory
time. (At the settings noted above, ventilator should provide a 2.0 second
inspiratory time and a 4.0 second expiratory time)
3. Connect the 22 mm tubing or the allied patient circuit provided, to the patient
circuit connection port. (See Item 9 Under Features Page 5). Block the patient
end of the corrugated tubing.
Confirm that the airway pressure does not exceed 60 cm-H2O, by monitoring
the “Airway pressure display” on the face of the EPV100 ventilator.
An alarm will sound at approximately 45 cm-H2O
4. Visually inspect the anti-suffocation valve in the patient circuit connection port to
verify that the valve is flush to the contour of the round inner surface and no gap
exists.
Alarm Mode Check
1. Low source gas:
Reduce the source gas pressure below 35 PSI and monitor the red LED
display turns on and an audible alarm sounds. Return the source gas
pressure to 50 PSI, and the alarm should clear in 15 seconds
2. High Airway pressure:
Block the patient circuit connection port, and monitor the red LED display for
“High airway Pressure” and an audible alarm will sound. The mechanical
pressure relief should limit the airway pressure to less than 60cm-H2O
3. Breath Delivery:
Clear the patient circuit connection port and allow the EPV to cycle for at least
20 seconds. The Airway Pressure display should not exceed 9 cm-H2O for
15 seconds. Monitor that the red LED is flashing on the “Breath delivery
Alarm” and an audible alarm will sound.
Should the unit fail any of these tests contact Allied Healthcare Products, Inc., technical
support center at 1-800-411-5136.

14
13 Accessories:
Description
Part Number
6 ft Oxygen Hose
L535026
Oxygen Regulator
L270-220
3 ft Ventilator Circuit
with Swivel, adult
mask and filter
case of 10
L599-130
Adult Oxygen Mask
Case of 10
L595161-10
Child Oxygen Mask
Case of 10
L595162-10
PEEP Valve*
Case of 12
LPEEP
Hook and Loop Strap
Case of 15
L770-CPR-VEL
*When using a PEEP valve the airway pressure display will not show the PEEP
pressure.
14 Warranty:
LIMITED ONE (1) YEAR WARRANTY
Allied Healthcare Products, Inc.(Allied) warrants this product to be free from
Disclaimer of Other Warranties:
defects in material and workmanship for a period of (1) year from the date of
manufacture. This Warranty is expressly conditioned on compliance with all
THIS WARRANTY IS IN PLACE AND IN LIEU OF ALL OTHER
inspection and preventative maintenance requirements as set by applicable
WARRANTIES OR REPRESENTATIONS, EXPRESSED OR IMPLIED,
government agencies and as specified by Allied.
INCLUDING, BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR SPECIFIC PURPOSE, BY OPERATION OF LAW OR.
This Warranty is extended by Allied only to the first purchaser of the product
OTHERWISE.
from either Allied or from an authorized Allied distributor.
This Warranty does not apply to malfunction or damage resulting from
ALLIED’S OBLIGATIONS AND PURCHASER’S REMEDIES UNDER THIS
accident, alteration, misuse of the product, improper preventative maintenance,
WARRANTY ARE LIMITED AS FOLLOWS: In the event of a defect, malfunction, or
storage at extreme temperatures or extreme environments beyond design limits, or,
failure to conform to this Warranty, purchaser shall return this product to Allied with
where appropriate, improper use of the product by untrained persons. This Warranty
shipping charges prepaid, within a reasonable time after discovery of such defect,
does not apply to any plastic or rubber components since they can be affected
malfunction or failure to conform. Allied shall repair or replace (at Allied’s option)
adversely by undue exposures to heat, sun, water, ozone, or to other deteriorative
this product if it is defective, malfunctions or fails to conform to this Warranty, and
elements.
shall return it to purchaser with shipping charges prepaid and without any additional
charges due to costs of repair or replacement.
Allied has not authorized any other firm or person to make any representations
concerning this product nor to assume on Allied’s behalf any liability in any way
In the event the product returned by purchaser is not defective, has not
connected with the sale or use of this product.
malfunctioned and does conform to this Warranty, Allied shall not be obligated to
repair or replace the product and shall not be obligated for shipping charges for
This Warranty becomes void immediately should any repairs of, or alterations
return of the product to the purchaser.
to this warranted product be made without authorization by Allied.
Allied shall in no event be liable for any consequential damages, nor for loss,
damages or expenses directly or indirectly arising from the use of this product.

15
15 Oxygen Cylinder Depletion Times:
These times are approximate and assume full cylinder capacity. Always monitor the
cylinder pressure and low pressure alarm to make sure you do not run out of oxygen.
E Cylinder
Capacity =
682
Liters Oxygen Capacity
(4.6 Liter Water Capacity)
Breaths per Minute
8
9
10
12
14
15
18
20
22
24
26
28
30
1200
67
60
54
46
39
37
1000
80
72
65
54
47
44
800
98
88
80
67
58
54
600
127
115
104
88
76
72
60
54
50
46
42
39
37
500
149
135
123
104
90
85
72
65
59
54
50
47
44
400
180
163
149
127
111
104
88
80
73
67
62
58
54
300
225
206
189
163
143
135
115
104
96
88
82
76
72
200
293
274
256
225
200
189
163
149
137
127
119
111
104
Tidal
Volume
Jumbo D Cylinder
Capacity =
637
Liters Oxygen Capacity
(4.0 Liters Water Capacity)
Breaths per Minute
8
9
10
12
14
15
18
20
22
24
26
28
30
1200
63
56
51
43
37
34
1000
75
67
61
51
44
41
800
92
82
75
63
54
51
600
119
107
97
82
71
67
56
51
46
43
40
37
34
500
139
126
115
97
85
79
67
61
55
51
47
44
41
400
168
152
139
119
104
97
82
75
68
63
58
54
51
300
210
192
177
152
134
126
107
97
89
82
76
71
67
200
274
256
239
210
187
177
152
139
128
119
111
104
97
Tidal
Volume

16
D Cylinder
Capacity =
414.6
Liters Oxygen Capacity
(2.8 Liters Water Capacity)
Breaths per Minute
8
9
10
12
14
15
18
20
22
24
26
28
30
1200
41
37
33
28
24
22
1000
49
44
39
33
29
27
800
60
54
49
41
35
33
600
77
70
63
54
46
44
37
33
30
28
26
24
22
500
91
82
75
63
55
52
44
39
36
33
31
29
27
400
109
99
91
77
67
63
54
49
44
41
38
35
33
300
137
125
115
99
87
82
70
63
58
54
50
46
44
200
178
166
155
137
122
115
99
91
84
77
72
67
63
Tidal
Volume
16 Symbols:
Degree of protection against electric shock: Type BF
Caution, Consult accompanying documents
5 to 95%
Non-condensing
% Relative Humidity: 5 to 95%
Storage Temperature Range: -40°F to 140°F
On/Off

17
17 Applicable Standards:
This equipment has been tested and found to comply with the EMC limits for the Medical Device
Directive 93/42/ECN (EN 55011 and EN 60601-1-2). These limits are designed to provide
reasonable protection against harmful interference in a typical medical installation. There is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference with other devices, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving device
Increase the separation between the equipment
Connect the equipment into an outlet on a circuit different from that which the
other device(s) is connected.
Consult the manufacturer or field service technician for help
The EPV100 is intended to provide emergency respiratory support for children and adults. The
product is intended to meet the following safety and performance standards:
Performance and Safety Requirements
ASTM F920 –Performance and Safety Requirements for Resuscitators Intended for use
with Humans
ISO 10651-3 –Lung Ventilators for Medial Use –Particular Requirements for
Emergency and Transport Ventilators
Electrical Safety Requirements
IEC 60601-1 –Medical Electrical Equipment –General Requirements for basic safety
and Essential Performance
Transportation and Storage Requirements
MIL-STD-810E –Shock, Vibration and Storage Requirements
The above listing of standards is not intended to be a complete listing of standards reviewed and
tested during the development of this product. It also may not reflect latest versions as standards
change. Allied Healthcare Products, Inc. regularly reviews the standards and updates the
products to ensure compliance as necessary.
For the latest revision of the instruction manual, please refer to the company website at
www.alliedhpi.com
This manual is also available in other languages. Please call 314-771-2400 for more
information on obtaining this manual in other languages.

18 Approximate settings based on patient height:
Flow Rates and I : E Ratios
By Tidal Volume and Breaths per
Minute
2 Second Inspiratory Time
Tidal Volume
400
480
560
640
720
800
880
960
1040
1120
1200
Height Male
=((IBW-50)/2.3)+60
inch
56
4”8”
(142.2)
59
4’11”
(149.9)
63
5’3”
(160.0
66
5’6”
(167.6)
70
5’10”
(177.8)
73
6’1”
(185.4)
77
6’5”
(195.6)
80
6’8”
(203.2)
83
6’11”
(210.8)
87
7’3”
(220.9)
90
7’6”
(228.6)
@10 ml/Kg
(cm)
Height Female
=((IBW-
45.50)/2.3)+60 inch
58
4' 10
(147.3)
61
5' 1"
(154.9)
65
5' 5"
(165.1)
68
5' 8"
(172.7)
72
6' 0"
(182.9)
75
6' 5"
(190.5)
78
6' 8"
(198.1)
82
6' 10"
(208.3)
85
7’1”
(215.9)
89
7’5”
(226.1)
92
7’8”
(233.7)
@10 ml/Kg
(cm)
Flow Rate
12
14.4
16.8
19.2
21.6
24
26.4
28.8
31.2
33.6
36
8
BPM = I:E (1 TO - )
2.8
2.8
2.8
2.8
2.8
2.8
2.8
2.8
2.8
2.8
2.8
9
BPM = I:E (1 TO - )
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
10
BPM = I:E (1 TO - )
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
11
BPM = I:E (1 TO - )
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
12
BPM = I:E (1 TO - )
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
13
BPM = I:E (1 TO - )
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
14
BPM = I:E (1 TO - )
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
15
BPM = I:E (1 TO - )
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
16
BPM = I:E (1 TO - )
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
17
BPM = I:E (1 TO - )
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
18
BPM = I:E (1 TO - )
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
19
BPM = I:E (1 TO - )
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
20
BPM = I:E (1 TO - )
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
Ideal Body Weight
Kg
@10 ml/Kg
40.0
48.0
56.0
64.0
72.0
80.0
88.0
96.0
104.0
112.0
120.0
18

19
1 Second Inspiratory Time
Tidal Volume
200
240
280
320
360
400
440
480
520
560
600
Height Male
=((IBW-50)/2.3)+60
inch
47
3' 11"
(119.4)
49
4' 1"
(124.9)
50
4' 2"
(127.0)
52
4' 4"
(132.1)
54
4' 6"
(137.2)
56
4' 8"
(142.2)
57
4' 9"
(144.8)
59
4' 11"
(149.9)
61
5' 1"
(154.9)
63
5' 3"
(160.0)
64
5’4”
(162.6)
@10 ml/kg
(cm)
Height Female
=((IBW-
45.50)/2.3)+60 inch
49
4' 1"
(124.5)
51
4' 3"
(129.5)
52
4' 4"
(132.1)
54
4' 6"
(137.2)
56
4' 8"
(142.2)
58
4' 10"
(147.3)
59
4' 11"
(149.9)
61
5' 1"
(154.9)
63
5' 3"
(160.0)
65
5' 5"
(165.1)
66
5' 6"
(167.6)
@10 ml/kg
(cm)
Flow Rate
12
14.4
16.8
19.2
21.6
24
26.4
28.8
31.2
33.6
36
8
BPM = I:E (1 TO - )
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
9
BPM = I:E (1 TO - )
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
10
BPM = I:E (1 TO - )
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
11
BPM = I:E (1 TO - )
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
12
BPM = I:E (1 TO - )
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
13
BPM = I:E (1 TO - )
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
14
BPM = I:E (1 TO - )
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
15
BPM = I:E (1 TO - )
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
16
BPM = I:E (1 TO - )
2.8
2.8
2.8
2.8
2.8
2.8
2.8
2.8
2.8
2.8
2.8
17
BPM = I:E (1 TO - )
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
18
BPM = I:E (1 TO - )
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
19
BPM = I:E (1 TO - )
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
20
BPM = I:E (1 TO - )
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
21
BPM = I:E (1 TO - )
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
22
BPM = I:E (1 TO - )
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
23
BPM = I:E (1 TO - )
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
24
BPM = I:E (1 TO - )
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
25
BPM = I:E (1 TO - )
1.4
1.4
1.4
1.4
1.4
1.4
1.4
1.4
1.4
1.4
1.4
26
BPM = I:E (1 TO - )
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
27
BPM = I:E (1 TO - )
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
28
BPM = I:E (1 TO - )
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
29
BPM = I:E (1 TO - )
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
30
BPM = I:E (1 TO - )
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Ideal Body Weight
Kg
@10 ml/Kg
20.0
24.0
28.0
32.0
36.0
40.0
44.0
48.0
52.0
56.0
60.0

19 Attaching EPV100 to equipment
Using two Hook and Loop straps, see accessories, the EPV100 can be looped around hospital or
other equipment as shown.
20
