Allied Telesis AT-IMC1000TP/SFP User manual

613-001966 Rev A
AT-IMC1000TP/SFP
Industrial Gigabit PoE+ Media Converter
User Manual

2
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
Copyright © 2001-2014 Allied Telesis Holdings K. K. - all rights reserved.
Copyright © 2001-2011 Broadcom Corporation.
No part of this publication may be reproduced without prior written permission from Allied Telesis, Inc.
Allied Telesis and the Allied Telesis logo are trademarks of Allied Telesis, Incorporated. All other product names,
company names, logos or other designations mentioned herein are trademarks or registered trademarks of their
respective owners.
Allied Telesis, Inc. reserves the right to make changes in specifications and other information contained in this
document without prior written notice. The information provided herein is subject to change without notice. In no
event shall Allied Telesis, Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever,
including but not limited to lost profits, arising out of or related to this manual or the information contained herein,
even if Allied Telesis, Inc. has been advised of, known, or should have known, the possibility of such damages.

3
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
Preface
I FCC Warning
This Equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy. It may cause
harmful interference to radio communications if the equipment is not installed and used in accordance with the
instructions. However, there is no guarantee that interference will not occur in a particular installation. If this equip-
ment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following mea-
sures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
II CE Mark Warning
This is a Class-A product. In a domestic environment this product may cause radio interference in which case the
user may be required to take adequate measures.

4
AT-IMC1000T/SFP Industrial Gigabit PoE+ Media Converter User Manual
Table of Contents
Overview ............................................................................................................................5
Introduction .................................................................................................................... 5
Features........................................................................................................................... 6
Packing List.................................................................................................................... 7
Supported SFP................................................................................................................ 7
Safety Precaution............................................................................................................ 7
Hardware Description ......................................................................................................8
Front Panel...................................................................................................................... 8
Top View........................................................................................................................ 8
Wiring the Power Inputs................................................................................................. 9
LED Indicators ............................................................................................................. 10
SFP Speed DIP-Switch................................................................................................. 11
Ports.............................................................................................................................. 11
Mounting Installation .....................................................................................................14
DIN-Rail Mounting ...................................................................................................... 14
Wall-Mount Plate Fixing.............................................................................................. 16
Cabling Installation ........................................................................................................17
Installing Copper Ethernet Cable ................................................................................. 17
Installing SFP Module and Fiber Cable ....................................................................... 17
Hardware Installation ....................................................................................................18
Selecting a Location ..................................................................................................... 18
Installation Steps........................................................................................................... 18
Troubleshooting ...............................................................................................................22
Reviewing the Safety Guidelines ...................................................................................23

Overview Introduction
5
AT-IMC1000TP/SFP Gigabit PoE+ Industrial Media Converter
1. Overview
1.1 Introduction
The AT-IMC1000TP/SFP Industrial Media Converter is designed to convert Ethernet Gigabit copper networks to
Gigabit fiber networks by transparently converting Ethernet signals to optic signals. Furthermore, the AT-
IMC1000TP/SFP can work from -40° ~ 75° C. And with IP31 protection, the device can operate in harsh operating
environments where condensation may be present. It has one RJ45 port and one SFP slot.
The RJ45 copper port supports 802.3at (PoE+), and it can provide up to 30W on the copper port for a high power
PoE application. It also supports MDI/MDIX auto detection, so you don't need to use crossover wires.
The SFP slot provides more flexibility when planning and implementing Ethernet fiber optic networks. The advan-
tages of fiber optics are wide bandwidth, EMI immunity and long-distance transmission capability. Therefore, the
AT-IMC1000TP/SFP is an ideal solution for “fiber to building” applications at central offices or local sites.The SFP
slot accepts one of a range of SFP fiber modules which allows you to customize the speed (100M/1000M) and dis-
tance capability of the fiber optic port for your installation. That means you can easily change the transmission
mode and distance of the media converter by simply interchanging one SFP module for another. The SFP module
is hot-swappable, and there is a dip switch for adjust the Ethernet speed of the SFP port depending on which SFP
module that is installed.
1.1.1 Power Input
The device supports 48V DC for the AT-IMC1000TP/SFP itself and the PoE+ power.
1.1.2 Flexible Mounting
The AT-IMC1000TP/SFP is extremely compact and supports both DIN-Rail and wall-mount installations. It is suit-
able for space-constrained environment and flexible for user installation.
1.1.3 Wide Operating Temperature
The operating temperature of the AT-IMC1000TP/SFP is between -40° to 75°C. With such a wide temperature
range, you can use this media converter in harsh industrial environments.
1.1.4 Easy Troubleshooting
LED indicators make troubleshooting quick and easy. The 10/100/1000 Base-TX port has 2 LEDs that display the
link and speed status. The SFP port LED displays Link/ACT. There are also LED indicators for PoE activity and
Power which can help you in diagnosing issues as they arise.

Overview Features
6
AT-IMC1000TP/SFP Gigabit PoE+ Industrial Media Converter
1.2 Features
Standard IEEE802.3 10BASE-T
IEEE 802.3ab 1000BASE-T
IEEE802.3u 100BASE-TX/100BASE-FX
IEEE802.3x Flow Control and Back pressure
IEEE 802.3z 1000BASE-X
IEEE 802.3at PoE Plus
LED Indicators Power, PoE Power, Fault
FDX/COL for Fiber, LNK/ACT for Fiber
100M for RJ45, LNK/ACT for RJ45
Connectors 1 x SFP slot
1 x RJ45
2-pin removable terminal blocks
PoE Ports 1
Max PoE Output
Power 30W
Max Available Power 33.525W
Alternative Mode A
PoE Polarity MDI
Switch Architecture Store and Forward
Power Input 48VDC power input
Power Consumption 32.725W
Operating Tempera-
ture -40°C to 75°C
Operating Humidity 5% to 95% (non-condensing)
Storage Environment -40°C to 85°C
Dimensions Metal case, IP-31
36.7mm (W) x 108.4mm (H) x 94.5mm (D)
Installation DIN-Rail, Wall-mount (optional)

Overview Packing List
7
AT-IMC1000TP/SFP Gigabit PoE+ Industrial Media Converter
1.3 Packing List
•1 x AT-IMC1000TP/SFP Industrial Gigabit Media Converter
•1 set of Wall Mount kit (2 brackets and 4 screws)
•1 x ATI Product Insert and China-RoHS HS/TS Substances Concentration Chart
1.4 Supported SFP
For a list of supported transceivers, refer to the AT-IMC1000TP/SFP Data Sheet which can be found on the AT-
IMC1000TP/SFP 2-Port Gigabit Ethernet PoE+ Industrial Media Converter product page at alliedtelesis.com.
1.5 Safety Precaution
Warning: Please use a protection devices on the inputs of the power supplies that supply DC voltage to the AT-
IMC1000TP/SFP Gigabit PoE+ Industrial Media Converter.
EMC •FCC Class A
•EN61000-6-4
•EN61000-6-2
•EN61000-4-2 (ESD)
•EN61000-4-3 (RS)
•EN61000-4-4 (EFT)
•EN61000-4-5 (Surge)
•EN61000-4-6 (CS)
•EN61000-4-8 (Magnetic Field)
•EN55022
•EN55024
Safety •UL-508/CSA C22.2
•ICE-61850-3
Stability Testing IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)

Hardware Description Front Panel
8
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
2. Hardware Description
In this section, we will introduce the Industrial Gigabit Media Converter’s hardware spec, port, cabling information,
and wiring installation.
2.1 Front Panel
The Front Panel of the AT-IMC1000TP/SFP Industrial Gigabit Media Converter is shown as below.
FIGURE 2-1 Front Panel of the Industrial Gigabit Media Converter
2.2 Top View
For IP31 rating, the top panel of the device is without terminal block. The terminal block connector of DC power
input is located in the bottom of device.

Hardware Description Wiring the Power Inputs
9
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
FIGURE 2-2 Top Panel of the Industrial Gigabit Media Converter
2.3 Wiring the Power Inputs
Please follow the steps below to insert the power wire.
FIGURE 2-3 Location of V+ and V- Contacts
1. There is a silk print for user to recognize the location of V+ and V- contacts on the device.
2. Insert the positive and negative wires into the V+ and V- contacts on the terminal block connector.
Note: The wire gauge for the terminal block should be in the range between 12~ 24 AWG
3. To tighten the wire-clamp screws located at the bottom of the unit (see above picture) highlighted in red for pre-
venting DC wires loosing

Hardware Description LED Indicators
10
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
FIGURE 2-4 Securing Connector with Two Outside Screws
4. Tighten the two screws on each end of the connector to secure it to the chassis.
2.4 LED Indicators
The LEDs located on the front panel of the AT-IMC1000TP/SFP display power status and network status. Each of
them has its own specific meaning as below table.
Table 2-1: Industrial Media Converter LED Definition
LED
Indicator Label Color Description
System Power PWR Green On Power on
Off Power off
PoE Power PoE Green On PoE power input OK
Off No PoE power input
RJ-45 (P1)
SPD Amber On Link to 1000 Mbps network
Off Not connected to network or not working at speed
of 1000M
L/A Green On Connected to network
Blink Networking is active
Off Not connected to network
SFP (P2) L/A Green On When there is a secure SFP connection
Blink When there is transmission or reception of data
occurring at speed of 100/1000Mbps
Off No SFP connection detected

Hardware Description SFP Speed DIP-Switch
11
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
2.5 SFP Speed DIP-Switch
The DIP-Switch is used to configure the speed of SFP Port (P2). The default value of DIP-switch is 100M.
2.6 Ports
RJ-45 ports (Auto MDI/MDIX): The RJ-45 ports are auto-sensing for 10Base-T, 100Base-TX or 1000Base-T
devices connections. Auto MDI/MDIX means that you can connect to another switch or workstation without chang-
ing straight through or crossover cabling. See figures as below for straight through and crossover cable schematic.
2.6.1 RJ-45 Pin Assignments
Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair.
All ports on this industrial media converter support automatic MDI/MDI-X operation, you can use straight-through
cables (See Figure below) for all network connections to PCs or servers, or to other switches or hubs. In straight-
through cable, pins 1, 2, 3, and 6, at one end of the cable, are connected straight through to pins 1, 2, 3 and 6 at
the other end of the cable. The table below shows the 10BASE-T/ 100BASE-TX /1000Base-T MDI and MDI-X port
pin outs.
Table 2-2: SFP Speed DIP-Switch Definition
Status Description
100 SFP Port (P2) Speed -
100M
1000 SFP Port (P2) Speed -
1000M
Table 2-3: MDI Pin Assignments
Pin Number Assignment
1Tx+
2Tx-
3Rx+
6Rx-
Table 2-4: MDI/MDI-X Pin Assignments
Pin MDI-X Signal Name MDI Signal Name
1 Receive Data plus
(RD+) Transmit Data plus (TD+)
2 Receive Data minus
(RD-) Transmit Data minus (TD-)

Hardware Description Ports
12
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
FIGURE 2-5 MDI Connections
FIGURE 2-6 MDI/MDI-X Connections
2.6.2 1000 Base-T Pin Assignments
3 Transmit Data plus
(TD+) Receive Data plus (RD+)
6 Transmit Data minus
(TD-) Receive Data minus (RD-)
Table 2-5: 1000 Base-T Pin Assignments
Pin MDI-X Signal Name Signal Definition
1 TRD+(0) Transmit and receive data 0 (positive lead)
2 TRD-(0) Transmit and receive data 0 (negative lead)
3 TRD+(1) Transmit and receive data 1 (positive lead)
4 TRD+(2) Transmit and receive data 2 (positive lead)
5 TRD-(2) Transmit and receive data 2 (negative lead)
6 TRD-(1) Transmit and receive data 1 (negative lead)
7 TRD+(3) Transmit and receive data 3 (positive lead)
8 TRD-(3) Transmit and receive data 3 (negative lead)
Table 2-4: MDI/MDI-X Pin Assignments
Pin MDI-X Signal Name MDI Signal Name
Media Converter Router or PC
3 TD+
6 TD-
1 RD+
2 RD-
3 TD+
6 TD-
1 RD+
2 RD-
Media Converter Router or PC
3 TD+
6 TD-
1 RD+
2 RD-
3 TD+
6 TD-
1 RD+
2 RD-

Hardware Description Ports
13
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
2.6.3 Fiber Port
The small form-factor pluggable (SFP) is a compact optical transceiver used in optical communications for both
telecommunication and data communication applications.
Fiber segment using single-mode connector type must use 9/125μm single-mode fiber cable. You can connect two
devices in the distance supported by SFP modules. Fiber segment using multi-mode connector type must use 50/
125 or 62.5/125μm multi-mode fiber cable. You can connect two devices up to 550m distances.

Mounting Installation DIN-Rail Mounting
14
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
3. Mounting Installation
3.1 DIN-Rail Mounting
The DIN-Rail is screwed on the industrial switch when out of factory. If the DIN-Rail is not screwed on the industrial
switch, please see the following figure to screw the DIN-Rail on the switch. Follow the below steps to hang the
industrial switch.
1. Use the screws to screw on the DIN-Rail clip on the industrial switch.
2. To remove the DIN-Rail clip, reverse step 1.
FIGURE 3-1 DIN-Rail Bracket Mounting Screw Location
3. First, insert the top of DIN-Rail bracket onto the top of the DIN-Rail track.

Mounting Installation DIN-Rail Mounting
15
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
FIGURE 3-2 Align top of DIN-Rail Bracket on Top of DIN-Rail
4. Then, lightly push the button of DIN-Rail into the track.
FIGURE 3-3 Bottom of DIN-Rail Bracket Attached to Bottom of DIN-Rail
5. Check the DIN-Rail clip is tightly fixed on the track.
6. To remove the industrial switch from the track, reverse the steps above.

Mounting Installation Wall-Mount Plate Fixing
16
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
3.2 Wall-Mount Plate Fixing
Follow the steps below to mount the industrial switch with the wall mount plates included.
Note: Use # 1 Phillips screwdriver head.
1. Remove the DIN-Rail clip from the industrial switch by unscrewing the three DIN-Rail clip mounting screws.
2. Remove the four end plate chassis screws next to the rear panel of the chassis.
3. Position the wall-mount plates on the rear panel of the industrial switch.
4. Use the screws provided to secure the wall-mount plates on the industrial switch.
5. Use the hook holes at the corners of the wall-mount plates to hang the industrial switch on the wall.
6. To remove the wall-mount plates, reverse the steps above.
FIGURE 3-4 Attaching Wall Mount Plates

Cabling Installation Installing Copper Ethernet Cable
17
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
4. Cabling Installation
This section describes the cable installation for the AT-IMC1000TP/SFP.
4.1 Installing Copper Ethernet Cable
Insert a Category 5e cable into copper RJ-45 port (P1) and the other end of the cable into the network link-part-
ner’s copper RJ-45 port, ex: switch, PC, or Server. The cable between the link partner (switch, hub, workstation,
etc.) and the converter must be less than 100 meters (328 ft.) long and comply with the IEEE 802.3ab
1000Base-T standard for Category 5e or above.
When the AT-IMC1000TP/SFP is powered on and the link partner network device is active, the copper RJ-45
port (P1) LED will light up indicating a link or link activity. Please refer to the LED Indicators section for LED light
meaning.
4.2 Installing SFP Module and Fiber Cable
Insert the proper SFP module and connect fiber cabling as explained in steps 7 and 8 of paragraph 5.2.1. The
SFP port (P2) LED on the unit will light up when the AT-IMC1000TP/SFP is powered on and the link partner net-
work device is active,. Please refer to the LED Indicators section for LED light meaning.

Hardware Installation Selecting a Location
18
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
5. Hardware Installation
5.1 Selecting a Location
Here are the guidelines for choosing a location for the media converter:
•The AT-IMC1000TP/SFP media converter may be installed on a wall or on a DIN-Rail.
•The power outlet should be located near the unit and be easily accessible.
Caution: The AT-IMC1000TP/SFP industrial media converter must be powered only by a UL Listed power supply
marked either “LPS” (or Class 2) rated 48Vdc, Max. 1.5A.
Caution: The AT-IMC1000TP/SFP industrial media converter must NOT be operated from Centralized battery.
•The site should provide easy access to the ports on the front of the chassis so that you can easily connect and
disconnect the network cables, as well as view the unit’s LEDs.
•Air flow around the unit and through the side and rear vents should be unrestricted.
•Do not place objects on top of the chassis.
•Do not expose the device to moisture or water.
•Make sure that the site is in a dust-free environment.
•Use dedicated power circuits or power conditioners to supply reliable electrical power to the network devices.
•Keep the media converter chassis and the twisted pair cable away from sources of electrical noise, such as
radios, electric motors, transmitters, broadband amplifiers, power lines, and fluorescent fixtures.
5.2 Installation Steps
5.2.1 Physical Installation
1. Unpack the unit packing.
2. Check that the DIN-Rail clip is attached to the unit. If the DIN-Rail clip is not attached to the unit, please refer to
the DIN-Rail Mounting section for DIN-Rail installation. If you want to wall-mount the unit, then please refer to
the Wall-Mount Plate Fixing section.
3. Connect Ground Wire to the Ground screw located on the rear of the chassis to the DIN-Rail bracket.
4. To hang the unit on the DIN-Rail track or wall, please refer to the Mounting Installation section.
5. Power on the AT-IMC1000TP/SFP and the power LED indicator on the unit will light up. Please refer to the Wir-
ing the Power Inputs section on how to wire the power. Please refer to the LED Indicators section for meaning
of LED lights.
6. Prepare the twisted-pair, straight through Category 5 cable for Ethernet connection.

Hardware Installation Installation Steps
19
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
7. Insert the transceiver into the SFP module. Notice that the triangle mark is the bottom of the module.
FIGURE 5-1 Insertion of a transceiver into the SFP module
FIGURE 5-2 Transceiver inserted

Hardware Installation Installation Steps
20
AT-IMC1000TP/SFP Industrial Gigabit PoE+ Media Converter
8. Insert the fiber cable of LC connector into the transceiver.
FIGURE 5-3 LC connector to the transceiver
5.2.2 Removing the LC connector from the transceiver
1. Press the upper side of the LC connector from the transceiver and pull it out to release
FIGURE 5-4 Remove the LC connector
