Allied Telesis AT-MC101XL User manual

AT-MC101XL
AT-MC102XL
AT-MC103XL
AT-MC103LH
Fast Ethernet Media Converters
Installation Guide
PN613-10771-00 Rev.C

Copyright 1998, 1999 Allied Telesyn International, Corp.
960 Stewart Drive Suite B, Sunnyvale CA USA 94086
All rights reserved. No part of this publication may be reproduced without prior written permission
from Allied Telesyn International, Corp.
Ethernet is a registered trademark of Xerox Corporation. All other product names, company names,
logos or other designations mentioned herein are trademarks or registered trademarks of their
respective owners.
Allied Telesyn International, Corp. reserves the right to make changes in specifications and other
information contained in this document without prior written notice. The information provided
herein is subject to change without notice. In no event shall Allied Telesyn International, Corp. be
liable for any incidental, special, indirect, or consequential damages whatsoever, including but not
limited to lost profits, arising out of or related to this manual or the information contained herein,
even if Allied Telesyn International, Corp. has been advised of, known, or should have known, the
possibility of such damages.

iii
Safety Warnings
STANDARDS:This product meets the following standards
RFI Emission EN55022 Class A!1
WARNING: In a domestic environment this product may cause radio interference in which case the user may be
required totake adequate measures. !2
Immunity EN50082-11997
WARNING: This product requires shielded cables to comply with emission and immunity standards. If it is used
with unshieldedcables,the user may be required totake measures to correct the interference problem at theirown
expense.
Electrical Safety TUV-EN60950, UL1950, CSA 950
Laser EN60825
IMPORTANT: Appendix A contains translated safetystatements for installing this equipment. When you see the
!, go to Appendix A for thetranslatedsafety statement in your language.
WICHTIG: Anhang A enthält übersetzte Sicherheitshinweise für dieInstallation dieses Geräts. Wenn Sie!
sehen, schlagen Siein Anhang Aden übersetzten Sicherheitshinweis in Ihrer Sprache nach.
VIGTIGT: Tillæg A indeholder oversatte sikkerhedsadvarsler, dervedrører installation af dette udstyr. NårDe ser
symbolet !, skal De slåop i tillægA og finde de oversatte sikkerhedsadvarsler i Deres eget sprog.
BELANGRIJK: Appendix A bevat vertaalde veiligheidsopmerkingen voorhet installeren van deze apparatuur.
Wanneer u de !ziet, raadpleeg Appendix A voor vertaalde veiligheidsinstructies in uw taal.
IMPORTANT: L'annexe A contient les instructions de sécurité relatives à l'installation de cet équipement. Lorsque
vous voyez le symbole !, reportez-vous à l'annexe A pour consulter la traduction deces instructions dans votre
langue.
TÄRKEÄÄ: LiiteA sisältää tämän laitteen asentamiseen liittyvät käännetytturvaohjeet. Kun näet !-symbolin,
katso käännettyäturvaohjettaliitteestä A.
IMPORTANTE: l’Appendice A contiene avvisi di sicurezza tradotti per l’installazione diquesta apparecchiatura. Il
simbolo !,indica di consultarel’AppendiceA per l’avviso di sicurezza nella proprialingua.
VIKTIG: TilleggAinneholderoversattsikkerhetsinformasjonforinstalleringavdetteutstyret.Nårduser!,åpner
du til Tillegg A for å finne den oversatte sikkerhetsinformasjonen på ønsket språk.
IMPORTANTE: OAnexoAcontémadvertênciasdesegurançatraduzidasparainstalaresteequipamento.Quando
vir o símbolo !, leia aadvertênciade segurançatraduzida no seuidioma noAnexo A.
IMPORTANTE: El ApéndiceA contiene mensajes de seguridad traducidos para la instalación de este equipo.
Cuando vea el símbolo !, vaya al Apéndice A para verel mensaje de seguridadtraducido a suidioma.
OBS! Bilaga A innehåller översatta säkerhetsmeddelanden avseende installationen av denna utrustning. När du
ser !, skall du gå till Bilaga A för att läsa detöversatta säkerhetsmeddelandet på ditt språk.
U.S. Federal Communications Commission
RADIATED ENERGY
Note: Thisequipment has been tested andfound to comply with the limitsfora Class Adigitaldevicepursuant to
Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energyand, if not installed and used inaccordance with this instruction manual, may cause
harmful interference toradio communications. Operation of this equipment in a residential area is likely to cause
harmful interferencein whichcase the user will be required to correct the interference at his own expense.
Note: Modifications or changes notexpressly approved of by the manufacturer or theFCC, can void your right to
operatethis equipment.
Industry Canad
This Class A digital apparatus meets all requirements ofthe CanadianInterference-Causing Equipment
Regulations.
Cet appareil numérique de la classe A respecte touteslesexigencesdu Règlement sur le matériel brouilleurdu
Canada.

1
AT-MC101XL, AT-MC102XL, AT-MC103XL
AT-MC103LH Fast Ethernet Media Converters
The AT-MC101XL and AT-MC102XL convert IEEE 802.3u 100Base-TX to
100Base-FX multimode Fast Ethernet network connections. The
AT-MC103XL and AT-MC103LH convert to FX single mode. The 100Base-FX
interfaces are available in ST or SC connectors for multimode fiber cabling.
For single mode cabling, the 100Base-FX is available in SC connectors only.
The 100Base-TX interface uses an RJ45 shielded connector.
Figure 1 AT-MC101XL Front Panel (ST multimode connector)
Figure 2 AT-MC102XLFront Panel(SC multimode connector)
Figure 3 AT-MC103XL Front Panel (SC single mode connector)
100Base-FX
REC
LNK
100Base-TX
REC
LNK
PWR
NML
TX RX
MC101XL FAST ETHERNET MEDIA CONVERTER
MDI MDI-X
NML
LNKTST
100Base-FX
REC
LNK
100Base-TX
REC
LNK
PWR
NML
TX RX
MC102XL FAST ETHERNET MEDIA CONVERTER
MDI MDI-X
NML
LNKTST
REC
LNK
REC
LNK
PWR
NML
TX RX
MC103XL SINGLE MODE FIBER FAST ETHERNET MEDIA CONVERTER
MDI MDI-X
NML
LNKTST
CLASS 1
LASER LIGHT
DO NOT STARE
INTO BEAM
100Base-FX 100Base-TX

2
Figure 4 AT-MC103LH (SC single mode connector)
Key Features
The media converters have the following key features:
❑LEDs for unit and port status
❑MDI/MDI-X Switch
❑NML/LNK TST Switch
❑100Base-TX ports participate in auto-negotiation for 100 Mbps and
half- or full-duplex modes
❑MissingLinkprovides link fault detection on 100Base-TX and
100Base-FX segments
❑External AC-DC Power Adapter
❑Standard, compact size for use with AT-MCR12 rack-mount chassis
❑Low power consumption
Note
For definitions of technical terms associated with Allied Telesyn’s
products, refer to the Glossary on our website at
www.alliedtelesyn.com.
REC
LNK
REC
LNK
PWR
NML
TX RX
MC103LH SINGLE MODE FIBER
LONG HAUL
FAST ETHERNET MEDIA CONVERTER
MDI MDI-X
NML
LNK TST
CLASS 1
LASER LIGHT
DO NOT STARE
INTO BEAM
100Base-FX 100Base-TX

Installation Guide
3
LEDs
The PWR LED in the upper right corner of the front panel lights when the
media converter is receiving power. Status LEDs are located on the front
panel next to each port and described in Table 1.
Table 1 LEDs
MDI/MDI-X Switch
The MDI/MDI-X (Media Dependent Interface/Media Dependent Interface with
Crossover) switch, located on the front panel, is a straight-through or
crossover cable selection switch. It enables the RJ45 port to be connected to a
repeater or DTE device without using a special crossover cable. The default
positionof the switch is MDI-X,which means you can connect the RJ45 port to
a workstation or to any other DTE device using a straight-through cable.
NML/LNK TST Switch
The NML/LNK TST (Normal/Link Test) switch, located on the front panel,
establishes a fiber/twisted pair link in the test position.
The default position of the switch is IN, which is the normal (NML) operating
mode and enables the MissingLink feature. With the switch in the OUT or
Link Test mode (LNK TST) position, the MissingLink feature is disabled and
the optical transmitter TX is forced on. The NML LED lights when the NML/
TST LNK switch is in the default (IN) operating position.
Note
Using the Link Test mode does not interfere with the media converter’s
ability to pass network traffic.
LED Color State Description
PWR Green ON Power isapplied.
NML Green ON
OFF
Unit is operating in normal mode.
Unit is in Link Test mode.
REC Green ON Data is being received on the port.
LNK Green ON Link established on the port.

4
Auto-Negotiation
The 100Base-TX ports participate in IEEE 802.3u Standard auto-negotiation
with its local link partner.
Note
End stations used with the media converter must operate in the same
duplex mode (either both full-duplex or both half-duplex).
Note
The media converters have an additional feature, allowing the unit to
operate in 100 Mbps half-duplex mode. Certain applications require this
mode, for example, two media converters installed in a back-to-back
configuration (fiber-to-fiber) which are attached to unmanaged repeaters
and/or switches that auto-negotiates with the other. Forinstructions on
how to set up the media converter for this application, contact Allied
Telesyn Technical Support.
MissingLink
MissingLink gives the host (router, server, switch) attached to each end of the
converter critical information about the status of the other (remote) segment
link. If either link fails, the converter interacts with both hosts, making each
instantly aware of the link fault. Either host can then execute
preprogrammed, redundant transmission path selection.
External AC-DCPower Adapter
An external AC-to-DC power adapter is included with the fast switch for
standalone operation (see Figure 5). The power adapter supplies 12 volts DC
to the media converter. Allied Telesyn supplies an approved safety compliant
AC power adapter for the 120 and 240 V AC versions with an unregulated
output of 12 V DC at 1 A. The power required for the media converter is 12 V
DC, 500 mA.
Figure 5 External AC-DC Power Adapter (North American version)

Installation Guide
5
Package Contents
Make sure the media converter package contains the following items:
❑AT-MC101XL, AT-MC102XL, AT-MC103XL, or AT-MC103LH Fast
Ethernet Media Converter
❑Four Protective Feet (for standalone use only)
❑External AC-DC Power Adapter
❑This Installation Guide
Contact your sales representative if any items are missing or damaged.
Installing the Media Converter
Read the warnings below before beginning any installation.
Warning
Do not stare into the laser beam when installing the media converters.
!
!!
!5
LIGHTNING DANGER: DO NOT WORK on equipment or CABLES
during periods of LIGHTNING ACTIVITY!
!!
!6
DO NOT BLOCK AIR VENTS !
!!
!7
The following steps are for a standalone installation. To install media
converters in a rack mount chassis, see “Rack mount Chassis Installation” on
page 7. For information concerning back-to-back converter configuration, see
“Back-to-Back Installation” on page 7.
Standalone Installation
1. Remove all equipment from the package and store the packaging in a safe
place
2. Attach the four rubber feet to the base of the unit, placing one rubber foot
in each corner.For rack-mount installation, do not attach the four rubber
feet.
3. Plug the AC-DC power adapter into an appropriate AC power outlet and
insert the power plug into the DC receptacle located on the rear panel.
Figure 6 12 V DC Connector onRear Panel
12VDC

6
4. Verify that the PWR LED lights green.
5. Set the unit in Link Test mode
6. Remove the dust cap from the fiber optic connectors.
7. Plug the appropriate fiber cable into the connector. See Table 3 for IEEE
802.3u cabling specifications
8. Connect the other end of the fiber cable to the desired end station. Verify
that the link LED is ON.
9. If you are making a direct connection to a workstation using straight-
throughcable, setthe MDI/MDI-X switch to the MDI-X position. (MDI-X is
the default position.)
If you are connecting the media converter to a hub, switch, or another
media converter with a straight-through cable, set the MDI/MDI-X switch
to the MDI position. See Figure 7.
Figure 7 MDI/MDI-X Switch
10. Plug a Category 5 twisted pair cable into the RJ45 connector.Connect the
other end of the twisted pair cable to the desired end station. Verify that
the Link LED is ON
11.Set the unit to Normal (NML) Mode for normal operation.
Note
End stations used with the media converter must operate in the same
duplex mode (either both full-duplex or both half-duplex).
100Base-FX
REC
LNK
100Base-TX
REC
LNK
PWR
NML
TX RX
MC101XL FAST ETHERNET MEDIA CONVERTER
MDI MDI-X
NML
LNK TST
C
KMDI MDI-X

Installation Guide
7
Note
The media converters have an additional feature, allowing the unit to
operate in 100 Mbps half-duplex mode. Certain applications require this
mode, for example, two media converters installed in a back-to-back
configuration (fiber-to-fiber) which are attached to unmanaged repeaters
and/or switches that auto-negotiates with the other. Forinstructions on
how to set up the media converter for this application, contact Allied
Telesyn Technical Support.
Back-to-Back Installation
Review the following before doing a back-to-back installation. See Figure 10
for an illustration of a back-to-back-media converter configuration.
❑During installation, setup, and testing of back-to-back media
converters, make sure each media converter is in the Link Test mode.
❑When two media converters are connected back-to-back with no UTP/
STP cables connected and when the NML/LNK TST switch is in the
OUT position (Link Test mode), the fiber REC LEDs on each converter
may flash. This is normal and will not affect the normal operation of
the converters.
❑When operatingtwomediaconvertersina back-to-backconfiguration,
Allied Telesyn recommends that the MissingLink feature on one or
both of the converters be disabled. The MissingLink feature can be
disabled by placing the NML/LNK TST switch in the OUT position
(LNK TST mode). Disabling the Link Test mode does not interfere
with the converter’s ability to pass network traffic.
Rack mount Chassis Installation
To install the media converter in the rack-mount chassis, refer to the
“AT-MCR12 Media Converter Chassis Installation Manual” or visit the
Technical Support area of Allied Telesyn’s website at
www.alliedtelesyn.com. Figure 8 shows the AT-MCR12 rack-mount
chassis.
Figure 8 AT-MCR12 Rack-mount Chassis
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
MCR12

8
Configurations
Figure 9 shows a typical network configuration with a workstation connected
to a switch.
Figure 9 Connectionto Workstation and Switch
Figure 10 shows two media converters in a back-to-back configuration.
Figure 10 AT-MC101XL Back-to-Back Configuration
RS-232
TERMINALPORT
STATUS
10BASE-T/ 10 0BASE-TX
FASTETHERNETSWITCH
PORTACT IVITY
10BASE-T/ 100BASE-TX
AT-8124XL 10/100 Switch
AT-MC101XL
Workstation
100Base-FX
100Base-TX
Legend
10 Mbps
100 Mbps
100 Mbps (Fiber)
MMF
RS-232
TERMINALPORT
STATUS
10BASE-T/100BASE-TX
FASTETHERNET SWITCH
PORTACTIVITY
10BASE-T/100BASE-TX
RS-232
TERMINALPORT
STATUS
10BASE-T/100BASE-TX
FASTETHERNET SWITCH
PORTACTIVITY
10BASE-T/100BASE-TX
Workstation
100Base-TX
10Base-T
AT-MC101XL AT-8124XL 10/100 Switch
Legend
10 Mbps
100 Mbps
100 Mbps (Fiber)
AT-MC101XL
AT-8124XL 10/100 Switch
100Base-TX
100Base-FX
MMF

Installation Guide
9
Troubleshooting
To troubleshoot your media converter, perform the following:
1. Set the unit in the Link Test mode.
2. End stations used with the media converter must operate in the same
duplex mode (either both full-duplex or both half-duplex).
3. Verify that the twisted pair cable is Category 5.
4. Verify that proper fiber cable is being used: multimode for the
AT-MC101XL and AT-MC102XL, and single mode for the AT-MC103XL
and AT-MC103LH. Refer to Table 3 on page 10 for cable specifications
5. Verify that the near end node transmitter (TX) is connected to the far end
node receiver (RX) and vice versa on the fiber segment.
Technical Specifications
Table 2 lists the media converter technical specifications.
Table 2 Media Converter Technical Specifications
Specifications
Dimensions 4.125 in W x 3.75 in D x 1.0 in H
(10.5 cm W x 9.5 cm D x 2.5 cm H)
Max. Operating temperature 0° C to 40° C (32° F to 104° F)
Max. Storage temperature -20 oC to 80o C (-4° F to 176° F)
Operating altitude up to 10,000 ft (3,048 m)
Humidity 5% to 80% (noncondensing)
EMI/RFI meets FCC Class A, EN55022 Class A
Safety EN60950, UL 1950, CSA 950
EN60825
Immunity EN50082-1 Immunity Standard
Power
Input supplyvoltage
Max. current
Power consumption
12 V DC +/-5%
500 mA
6W

10
Recommended Cables and Cable Specifications
Table 3 lists the IEEE 802.3u cabling specifications for the media converters.
Refer to Table 3 for cabling recommendations.
Note 1. Single-mode fibertransmitter israted as a Class 1 laser.
Note 2. Each Media Converter used inline within a single collision domain will reducethe overall segmentlength by
40 m (131.24 ft) of fiber.
Note 3. Applies only to the AT-MC103XL, Single Mode Fiber OpticTransmitter/Receiver.
Note 4. Applies only to theAT-MC103LH, SingleMode Fiber Optic Transmitter/Receiver.
Table 3 IEEE 802.3u Cabling Specifications for Media Converters
100Base-FX 100Base-TX
Media 1300nm multimode fiber, 50/125 micron
1300nm multimode fiber, 62.5/125 micron
1300 nm single-mode fiber, 9/125 micron
(see Note 1)
Unshielded/
ShieldedTwisted
Pair Category 5 only
Topology Star, Tree Star, Tree
External
Devices NetworkAdapterCard, Repeater,Switch,Router,or Bridge Network Adapter Card, Repeater,
Switch, or Router
Maximum
Segment
Length
100BaseFX Full-Duplex operation:
Multimode fiber (MMF), 2 km (1.2 mi)
Single mode fiber (SMF), 15 km (9.32 mi) (XL
model only, see Note 3.)
Singlemodefiber(SMF),40km(24.9mi)(LHmodel
only, see Note 4.)
100BaseFX Half-Duplexoperation:
The total distance of all fiber runs cannot exceed
thefollowing limits: (see Note 2)
with one Media Converter inline:
Switch to Switch = 372 m (1221 ft)
Work Station to Switch = 372 m (1221 ft)
Switch to Class II Repeater = 185 m (607 ft)
Switch to Class I Repeater = 137 m (450 ft)
with two Media Converters inline:
Switch to Switch = 332 m (1089 ft)
Work Station to Switch = 332 m (1089 ft)
Switch to Class II Repeater =145 m (476 ft)
Switch to Class I Repeater = 97 m (318 ft)
328 ft (100 m)

Installation Guide
11
Technical Support and Service
You can contact the reseller or distributor where you purchased your product
for local assistance. If local support is unable to resolve the problem, Allied
Telesyn offers technical support via fax, e-mail or telephone.
Refer to Appendi xD, for technical support telephone and fax numbers or
www.alliedtelesyn.com for current world-wide office locations.
Warranty
The media converters have a lifetime warranty. The power adapter has a one
year warranty.

13
Appendix A
Electrical Safety and Installation
Requirements
STANDARDS:This productmeets the following standards
STANDARDS:This productmeets the following standards
!1 RFI Emission EN55022 Class A
!2
WARNING: In a domestic environment this product may cause radio interference in which case the user may be
required totake adequate measures.
!3Immunity EN50082-11997
!4 WARNING: This product requires shielded cables to comply with emission and immunity standards. If it is used with
unshielded cables, the user may be required to take measuresto correct the interference problem at their own
expense.
Electrical Safety TUV-EN60950, UL1950, CSA 950
Laser EN60825
Warning Class1Laser product.
!5WarningDo not stareinto the Laser beam.
At time of installation, theFiber Optic Laserscomply with FDA Radiation Performance Standard 21CFRSubchapter
J,applicableatdate of manufacture.
Useofcontrolsoradjustmentsofperformanceorproceduresotherthanthosespecifiedhereinmayresultinhazardous
radiation exposure.
SAFETY
!6 LIGHTNING DANGER
DANGER: DO NOTWORK on equipment or CABLES during periods of LIGHTNING ACTIVITY.
!7DO NOTBLOCK AIR VENTS
Power tothe hub must be sourced only from the adapter.
USA/CANADA
Use a UL Listed/CSA Certified AC adapter of DC 12V, 500mA.
EUROPE - EU
Use TÜVlicensed AC adapter of DC 12V,500mA.
UK
Use a UK Safety Approved AC adapter ofDC 12V, minimum 500mA.
U.S. Federal Communications Commission
RADIATED ENERGY
Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to
Part 15 of FCC Rules. These limitsare designedto provide reasonable protection againstharmful interference
when the equipment is operated in a commercialenvironment. Thisequipmentgenerates, uses, andcan radiate
radiofrequency energy and,if notinstalled and used in accordancewith this instruction manual, maycause harmful
interference to radio communications.Operation of this equipment in aresidential area islikely to cause harmful
interference in which case the user will be required to correct theinterference at his own expense.
Note: Modifications or changes notexpressly approved of by the manufacturer or theFCC, can void your right to
operate this equipment.
Industry Canada
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
Cetappareilnumérique dela classe A respecte toutesles exigences duRèglement surle matériel brouilleurdu
Canada.

14
OPERATING TEMPERATURE
This product is designed for a maximum ambient temperature of 40 degrees C.
ALL COUNTRIES: Install product in accordance with local and National Electrical Codes.
NORMEN: Dieses Produkt erfüllt die Anforderungen der nachfolgenden Normen
!1 Hochfrequenzstörung EN55022 Klasse A
!2
WARNUNG: Bei Verwendung zu Hausekann dieses Produkt Funkstörungenhervorrufen.In diesem Fall müßteder
Anwender angemessene Gegenmaßnahmen ergreifen.
!3Störsicherheit EN50082-11997
!4ACHTUNG: Für diesesProduktsind abgeschirmteKabelerforderlich, damit den Richtlinienfür Emissionund
Interferenzschutz entsprochen wird. Falls das Produkt mit nicht abgeschirmten Kabeln verwendet wird, können
weitergehende Maßnahmen für die Korrektur vonInterferenzproblemen auf Kosten desBenutzers notwendig werden.
Elektrische Sicherheit TUV-EN60950, UL1950, CSA 950
Laser EN60825
Warnung Laserprodukt der Klasse 1.
!5WarnungNicht direkt in den Strahl blicken.
SICHERHEIT
!6 GEFAHR DURCH BLITZSCHLAG
GEFAHR: Keine Arbeiten am Gerät oder an den Kabeln während eines Gewitters ausführen
!7ENTLÜFTUNGSÖFFNUNGEN NICHTVERSPERREN
Der Buchsedarf nur aus demAdapter Stromzugeführt werden.
EUROPE - EU
Gebrauchen Sieeinen vonTÜV zugelassenen Wechselstromadapter fürGleichstrom12 V, 500 mA.
BETRIEBSTEMPERATUR
Dieses Produkt wurde für den Betrieb in einerUmgebungstemperatur von nicht mehr als40° C entworfen.
ALLE LÄNDER: Installation muß örtlichen undnationalen elektrischen Vorschriften entsprechen.
STANDARDER: Dette produkt tilfredsstiller de følgende standarder
!1 Radiofrekvens forstyrrelsesemission EN55022 Klasse A
!2
ADVARSEL: I et hjemligt miljø kunne dette produktforårsageradio forstyrrelse. Bliver det tilfældet, påkræves
brugeren muligvisat tage tilstrækkeligeforanstaltninger.
!3Immunitet EN50082-11997
!4ADVARSEL: Dette produkt skal bruges med afskærmede kabler for at overholde bestemmelserne vedrørende
udstrålingogstøjimmunitet. Hvisdetbrugesmeduafskærmedekabler,kandetblivepåkrævetafbrugerenatkorrigere
interferensproblemerfor egen regning.
Elektrisk sikkerhed. TUV-EN60950, UL1950, CSA 950
Laser EN60825
Advarsel Laserprodukt av klasse 1.
!5 Advarsel Stirr ikkepå strålen.
SIKKERHED
!6 FARE UNDER UVEJR
FARE: UNDLAD at arbejde på udstyr eller KABLER i perioder medLYNAKTIVITET.
!7VENTILATIONSÅBNINGERNE MÅ IKKE BLOKERES
Strømforsyningen til apparatet må udelukkende tages fra tilpasningstransformatoren.
EUROPE - EU
Brug kun TÜV godkendt vekselstrømstransformator på 12 V jævnstrøm,500 mA.
BETJENINGSTEMPERATUR
Dette apparat er konstrueret til en omgivende temperatur på maksimum 40grader C.

Installation Guide
15
ALLE LANDE: Installation af produktet skal skei overensstemmelse med lokal og national lovgivning for elektriske
installationer.
EISEN: Dit productvoldoet aandevolgende eisen.
!1 RFI Emissie EN55022 Klasse A
!2
WAARSCHUWING: Binnenshuis kan dit product radiostoring veroorzaken, inwelk geval de gebruiker verplicht kan
wordenom gepaste maatregelente nemen.
!3Immuniteit EN50082-11997
!4 WAARSCHUWING: Om te voldoen aan de emissie- en immuniteitsnormen dient dit apparaat te zijn voorzien van
afgeschermdekabels.Als het metniet-afgeschermde kabels wordtgebruikt, kanhet zijn dat de gebruiker maatregelen
moet treffen om interferentieproblemen voor eigen rekening op te lossen.
Electrische Veiligheid TUV-EN60950, UL1950, CSA 950
Laser EN60825
Waarshuwing Klasse-1 laser produkt.
!5 Waarchuwing Neit in de straal staren.
VEILIGHEID
!6GEVAAR VOOR BLIKSEMINSLAG
GEVAAR: NIET aan toestellen of KABELS WERKEN bij BLIKSEM.
!7VENTILATIEGATEN NIET BLOKKEREN
Stroom mag alleen via de adapter naar het apparaat toegevoerd worden.
EUROPE - EU
Gebruik een doorTÜV gekeurde wisselstroomadapter van 12Volt gelijkstroom, 500 milliampères.
BEDRIJFSTEMPERATUUR
De omgevingstemperatuur voor dit produkt mag niet meer bedragen dan 40 graden Celsius.
ALLE LANDEN: het toestel installeren overeenkomstig de lokale en nationale elektrische voorschriften.
NORMES: ce produit est conforme aux normes de suivantes
!1 Emission d'interférences radioélectriques EN55022 Classe A
!2
MISEENGARDE:dansunenvironnementdomestique,ceproduitpeutprovoquerdesinterférencesradioélectriques.
Auquel cas, l'utilisateur devra prendre les mesures adéquates.
!3Immunité EN50082 -1 1997
!4 AVERTISSEMENT: Il faut utiliser des câbles blindés pour ce produit afin de respecter les normes d’émission et
d’immunité. Sil’utilisateur choisit d’utiliser des câbles non blindés, il sera peut-être contraint de prendre les mesures
nécessaires pourcorriger les problèmes d’interférences, ainsique d’assumer le coût correspondant.
Sécurité électrique TUV-EN60950, UL1950, CSA 950
Laser EN60825
Attention Producit laser di classe1.
!5 Attention Ne pas fixerle faisceau desyeux.
SÉCURITÉ
!6 DANGER DE FOUDRE
DANGER: NE PAS MANIER le matérielou les CÂBLES lors d'activitéorageuse.
!7NE PAS BLOQUER LES FENTES D'AÉRATION
L'alimentation du concentrateur doit être uniquement fournie par l'adaptateur.
EUROPE - EU
Utiliser un adaptateur secteurconforme TÜV de 12 V, 500 mA en courant continu.
TEMPÉRATURE DE FONCTIONNEMENT
Ce matériel est capablede tolérerunetempérature ambiante maximum de 40 degrés Celsius.
POUR TOUS PAYS:Installer lematérielconformément aux normesélectriques nationales et locales.

16
STANDARDI : Tämä tuote on seuraavien standardien mukainen
!1 Radioaaltojen häirintä EN55022 Luokka A
!2
VAROITUS: Kotiolosuhteissa tämä laite voi aiheuttaa radioaaltojen häiröitä, missä tapauksessa laitteen käyttäjän on
mahdollisesti ryhdyttävä tarpeellisiin toimenpiteisiin.
!3 Kestävyys EN50082-11997
!4VAROITUS: Tämä tuote vaatii suojattuja kaapeleita toimiakseen emissio- ja häiriönsietostandardien mukaisesti. Jos
tuotettakäytetään ilman suojattuja kaapeleita,käyttäjävoi joutua korjaamaan häirinnänaiheuttaman ongelman omalla
kustannuksellaan.
Sähköturvallisuus TUV-EN60950, UL1950, CSA 950
Laser EN60825
Varoitus Luokan 1Lasertuote.
!5VariotusÄlä katso säteeseen.
TURVALLISUUS
!6 SALAMANISKUVAARA
ENGENVAARA: ÄLÄ TYÖSKENTELE laitteiden taiKAAPELEIDEN KANSSA SALAMOINNIN AIKANA.
!7ÄLÄ TUKI ILMAREIKIÄ
Tähtipisteeseen (hub) syötettävän virran pitää tulla ainoastaan sovittimesta.
EUROPE - EU
Käytä TÜV-lisenssillä valmistettua verkkosovitinta,jonka tasajännitteen nimellisarvot ovat DC 12 V, 500 mA
(milliampeeria).
KÄYTTÖLÄMPÖTILA
Tämä tuote on suunniteltu ympäröivän ilmanmaksimilämpötilalle 40° C.
KAIKKI MAAT: Asenna tuotepaikallisten ja kansallisten sähköturvallisuusmääräysten mukaisesti.
STANDARD: Questo prodotto èconformeai seguenti standard
!1 Emissione RFI (interferenza di radiofrequenza) EN55022 Classe A
!2
AVVERTENZA: in ambientedomestico questoprodottopotrebbe causare radiointerferenza.Inquestocasopotrebbe
richiedersiall'utente di prendere gliadeguati provvedimenti.
!3Immunità EN50082-11997
!4 AVVERTENZA: questo prodotto, se utilizzato con cavi schermati, è conforme alle norme sulle emissioni e
sull’immunità.Incasodiusosenzacavischermati,l’utentepuòdoveradottarea propriespesemisure correttive contro
le interferenze.
Sicurezza elettrica TUV-EN60950, UL1950, CSA 950
Laser EN60825
Avvertenza Prodotto laser di Classe 1.
!5AvertenzaNon fissare ilraggio congliocchi.
NORME DI SICUREZZA
!6PERICOLO DI FULMINI
PERICOLO: NON LAVORARE sul dispositivo osui CAVI durantePRECIPITAZIONITEMPORALESCHE.
!7NON OSTRUIRE LE PRESE D'ARIA
Questo dispositivo deve essere alimentato solo mediante l’adattatore.
EUROPE - EU
Utilizzare l’adattatore per c.a. da 12 V c.c. e 500 mA conforme alla normativa TÜV.
TEMPERATURA DI FUNZIONAMENTO
Questo prodotto è concepito per una temperatura ambientale massima di40gradi centigradi.
TUTTI I PAESI: installare il prodotto in conformità dellevigenti normativeelettriche nazionali.
