Allied Telesis AT-MC101XL User manual

Datasheet | Media Converters
AT-MC101XL
TX to FX Fast Ethernet media converter with
multi-mode ST fiber connectors
AT-MC102XL
TX to FX Fast Ethernet media converter with
multi-mode SC fiber connectors
AT-MC103XL
TX to FX Fast Ethernet media converter with
single-mode 15km SC fiber connectors
AT-MC103LH
TX to FX Fast Ethernet media converter with
single-mode 40km SC fiber connectors
Fiber Connections
The Allied Telesis range of Fast Ethernet Media
convertersprovides a complete family of
conversion devices, allowing users to extend the
sizeof UTP networks with the use of fiber
cabling. Supporting both SC and ST fiber
connectors, these converters can be used to
extend networks with up to 2km of multi-mode
fiber or 40km of single-mode fiber.
Auto-Negotiation and MissingLink™
The MissingLink™ feature enables the fiber
optic ports on the media converter to pass the
‘Link’ status of their connections to each other.
When the media converter detects a problem
with one of the ports, such as the loss of
connection to an end-node, the media
converter shuts down the connection to the
other port, thus notifying the node that the
connection has been lost.
Simple Installation
All the media converters feature Auto
MDI/MDI-X, allowing the converter to be
connected to either a PC, hub or switch with a
simple UTP cable.The media converters also
allow the installer to test the integrity of fiber
connection, by forcing the converters to
communicate over the fiber cable.This ‘Link Test’
feature allows installersto check for cable faults
without the need for expensive fiber optic test
equipment.
Standalone or Rack-mounted
Each small media converter is powered by an
external power supply unit for use in standalone
applications. Where multiple media converters
are being used, up to 12 standalone devices can
be inserted into a low-cost rack-mount chassis,
allowing all the converters to be powered by a
single internal power supply. In critical
applications, asecond load sharing internal
power supply can be installed into the rack-
mount chassis.
Hassle Free Support
Allied Telesis Fast Ethernet media converters
offer free technical support, ensuring trouble-
free installation.
Key Features
•Half and full-duplex operation
•Transparent to IEEE 802.1Q packets
•Rack-mountable using optional
AT-MCR12,AT-TRAY4 or AT-TRAY1 chassis
•Wall-mountable using AT-WLMT
•Auto MDI/MDI-X
•MissingLink™
•Link Test
•RoHS Compliant
MC10x series
Fast Ethernet Media Converters
Allied T
elesis www.alliedtelesis.com

Ordering Information
AT-MC101XL-xx
UTP to multi-mode ST (2km) fiber
AT-MC102XL-xx
UTP to multi-mode SC (2km) fiber
AT-MC103XL-xx
UTP to single-mode SC (15km) fiber
AT-MC103LH-xx
UTP to single-mode long-haul SC (40km) fiber
Where xx = 10 (US power adapter)
20 (European power adapter)
30 (UK power adapter)
40 (Australian power adapter)
Associated Products
AT-TRAY1
Rack-mounting tray for one Media Converter
AT-TRAY4
Rack-mounting trayfor up to four Media Converters
AT-WLMT
Wall-mount bracket for one Media Converter
AT-MCR12
12 slot AC/DC powered chassis for Media Converters
MC10x series |Fast Ethernet Media Converters
USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: [phone] |F: [phone]
European Headquarters |Via Motta 24 |6830 Chiasso |Switzerland |T: +41 91 69769.00 |F: +41 91 69769.11
Asia-Pacific Headquarters |11 T
ai Seng Link |Singapore |534182 |T: [phone] |F: [phone]
www.alliedtelesis.com
©2007 Allied T
elesis Inc.All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the proper ty of their respective owners. 617-00275-00 Rev G
Link Test
The link test is a fast and easy way for you to test the
connections between the media converter ports and the
end-nodes that are connected to the ports. If a network
problem occurs, you can perform a link test to
determine which port is experiencing a problem, and be
able to focus your troubleshooting efforts on the cable
or end-node where the problem resides.
MissingLinkTM
The MissingLinkTM feature enables the two ports on the
media converter to pass the ‘Link’ status of their
connections to each other. When the media converter
detects a loss of connection to an end-node, the media
converter shuts down the connection to the other port,
thus notifying the end-node that the connection has
been lost.
Technical Specifications
Status Indicators
Front Panel
Power Indicates power is applied to the
converter
Link (2) Indicates a valid receive link exists
Activity (2) Indicates TX/RX on the port
FDX Indicates full-duplex operation
ML Indictaes MissingLinkTM enabled
Switches
ML - Link Test Enable MissingLinkTM
A/N Enable Auto-negotiation
Packet Transmission Characteristics
Round Trip Delay 0.4µs Maximum
Bit Error Rate (BER) <10-12
Twisted Pair Interface
Min. Typical Max.
UTP Differential
Output Voltage 950mv 980mv 1050mv
Overshoot Voltage 4% 5%
Single Amplitude
Symmetry 0.98 1.0062 1.02
Rise and Fall Time
Rise 3.0ns 4.6ns 5.0ns
Fall 3.0ns 4.2ns 5.0ns
Rise and Fall Time
Symmetry0.4ns 0.5ns
Power Characteristics
External Power Supply 120V AC, 60Hz (US model)
240V AC, 50Hz
(European models)
Input Supply Voltage 12vDC
Max Current 500mA
Power Consumption 6W
Environmental Specifications
Operating Temp 0°C to 40°C
(32°F to 104°F)
Storage Temp. –20°C to 80°C
Relative Humidity 5% to 95% non-condensing
Operating Altitude 0 to 10,000 feet
RoHS Compliant
Physical Characteristics
Dimensions: 10.5cm x 9.5cm x 2.5cm
(W x D x H) (4.12” x 3.75” x 1.0”)
Weight: 294g (10.4oz)
Electrical/Mechanical Approvals
EMC FCC Class B
Safety compliant UL-Cul, CSA/CSA, NRTL,
TUV, CE compliant
Port Type
(Connector)
Cable
Distance
Optical
Frequency
Launch Power (dBm) Receive Power (dBm)
Max. Avg. Min. Min.
Sensitivity
Typical
Sensitivity Saturation
100FX MMF (2km) 2km 1310nm -14.0 -16.8 -19.0 -31.8 -34.5 -14.0
100FX SMF (15km) 15km 1310nm -8.0 -11.5 -15.0 -31.0 -31.0 -8.0
100FX SMF (40km) 40km 1310nm 0.0 -3.0 -5.0 -35.0 -38.0 0.0
