Allied Telesis AT-x930-28GTX User manual

613-002100 Rev. A
Installation Guide for Stand-alone
Switches
x930 Series
Gigabit Layer 3 Ethernet Switches
AT-x930-28GTX
AT-x930-28GPX
AT-x930-28GSTX
AT-x930-52GTX
AT-x930-52GPX

Copyright ©2015 Allied Telesis, Inc.
All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesis, Inc.
Allied Telesis, VCStack, and the Allied Telesis logo are trademarks of Allied Telesis, Incorporated. All other product names, company
names, logos or other designations mentioned herein are trademarks or registered trademarks of their respective owners.
Allied Telesis, Inc. reserves the right to make changes in specifications and other information contained in this document without prior
written notice. The information provided herein is subject to change without notice. In no event shall Allied Telesis, Inc. be liable for
any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related
to this manual or the information contained herein, even if Allied Telesis, Inc. has been advised of, known, or should have known, the
possibility of such damages.

3
Electrical Safety and Emissions Standards
This product meets the following standards.
RFI Emissions: FCC Class A, EN55022 Class A, EN61000-3-2, EN61000-3-3, VCCI Class A,
C-TICK, CE
EMC (Immunity): EN55024
Electrical Safety: EN60950-1 (TUV), UL 60950-1 (CULUS)
U.S. Federal Communications Commission
Radiated Energy
Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15
of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with this instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
Note: Modifications or changes not expressly approved of by the manufacturer or the FCC, can void your right to operate
this equipment.
Industry Canada
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
Warning: In a domestic environment this product may cause radio interference in which case
the user may be required to take adequate measures.
Laser Safety EN60825

4
Translated Safety Statements
Important: Safety statements that have the symbol are translated into multiple languages in the
Translated Safety Statements document at www.alliedtelesis.com/support.

5
Preface .............................................................................................................................................................................. 11
Document Conventions .......................................................................................................................................................12
Contacting Allied Telesis .....................................................................................................................................................13
Chapter 1: Overview ........................................................................................................................................................ 15
Models.................................................................................................................................................................................16
Features ..............................................................................................................................................................................17
x930 Models.................................................................................................................................................................17
10/100/1000 Mbps Twisted Pair Ports .........................................................................................................................17
Power Over Ethernet....................................................................................................................................................17
SFP Slots .....................................................................................................................................................................17
SFP+ Slots ...................................................................................................................................................................18
S1 and S2 Stacking Slots.............................................................................................................................................19
LEDs.............................................................................................................................................................................19
Installation Options.......................................................................................................................................................19
MAC Address Table .....................................................................................................................................................19
Management Software and Interfaces .........................................................................................................................19
Management Methods..................................................................................................................................................20
Power Supplies ............................................................................................................................................................20
Front and Back Panels ........................................................................................................................................................21
Management Panel .............................................................................................................................................................24
Power Supplies....................................................................................................................................................................25
Guidelines ....................................................................................................................................................................27
10/100/1000Base-T Twisted Pair Ports...............................................................................................................................29
Speed...........................................................................................................................................................................29
Duplex Mode ................................................................................................................................................................29
Wiring Configuration.....................................................................................................................................................29
Maximum Distance.......................................................................................................................................................30
Cable Requirements.....................................................................................................................................................30
Port Pinouts..................................................................................................................................................................30
Power Over Ethernet...........................................................................................................................................................31
PoE Standards .............................................................................................................................................................31
Powered Device Classes .............................................................................................................................................31
Cable Requirements.....................................................................................................................................................32
Power Budget...............................................................................................................................................................33
Port Prioritization..........................................................................................................................................................35
Wiring Implementation..................................................................................................................................................36
SFP Slots.............................................................................................................................................................................38
SFP+ Slots...........................................................................................................................................................................39
Stacking S1 and S2 SFP+ Slots..........................................................................................................................................40
Ethernet Management Port (NET MGMT)...........................................................................................................................41
NET MGMT LEDs ........................................................................................................................................................41
eco-friendly Button...............................................................................................................................................................42
LEDs....................................................................................................................................................................................43
LEDs for the Twisted Pair Ports...................................................................................................................................43
LEDs for the SFP Slots ................................................................................................................................................46
LEDs for the SFP+ Slots ..............................................................................................................................................47
LEDs for the Stacking Slots..........................................................................................................................................48
Switch ID LED ..............................................................................................................................................................49
Contents

Contents
6
USB Port............................................................................................................................................................................. 51
Console Port....................................................................................................................................................................... 52
Chapter 2: Beginning the Installation ............................................................................................................................53
Reviewing Safety Precautions............................................................................................................................................ 54
Choosing a Site for the Switch............................................................................................................................................ 59
Unpacking the Switch ......................................................................................................................................................... 60
Chapter 3: Installing the Power Supplies ......................................................................................................................63
Installing the Power Supplies.............................................................................................................................................. 64
Installing a Blank Power Supply Slot Cover........................................................................................................................ 70
Chapter 4: Installing the Switch on a Table ...................................................................................................................73
Chapter 5: Installing the Switch in an Equipment Rack ...............................................................................................75
Required Items ................................................................................................................................................................... 76
Installing the Switch in an Equipment Rack........................................................................................................................ 77
Chapter 6: Installing the Switch on a Wall .....................................................................................................................81
Switch Orientation on the Wall............................................................................................................................................ 82
Recommended Minimum Wall Area Dimensions................................................................................................................ 83
Plywood Base for a Wall with Wooden Studs..................................................................................................................... 85
Installation Guidelines......................................................................................................................................................... 87
Tools and Material....................................................................................................................................................... 87
Installing the Plywood Base................................................................................................................................................ 89
Installing the Switch on the Plywood Base ......................................................................................................................... 90
Installing the Switch on a Concrete Wall............................................................................................................................. 93
Chapter 7: Wiring the DC Connector on the AT-PWR250-80 Power Supply ..............................................................97
Chapter 8: Powering On the Switch .............................................................................................................................101
Powering On AC Power Supplies..................................................................................................................................... 102
Powering On the AT-PWR250-80 DC Power Supply ....................................................................................................... 106
Monitoring the Initialization Processes.............................................................................................................................. 108
Chapter 9: Configuring the Switch for Stand-alone Operation .................................................................................111
Determining the Status of the Switch................................................................................................................................ 112
Starting a Local Management Session............................................................................................................................. 113
Disabling VCStack............................................................................................................................................................ 115
Specifying Ports in the Command Line Interface for Stand-alone Switches..................................................................... 118
Chapter 10: Cabling the Networking Ports ..................................................................................................................119
Cabling the Twisted Pair Ports.......................................................................................................................................... 120
Guidelines to Handling SFP or SFP+ Transceivers.......................................................................................................... 122
Installing SFP or SFP+ Transceivers................................................................................................................................ 123
Chapter 11: Troubleshooting ........................................................................................................................................127
Appendix A: Technical Specifications .........................................................................................................................131
Physical Specifications ..................................................................................................................................................... 132
Environmental Specifications............................................................................................................................................ 134
Power Specifications......................................................................................................................................................... 135
Certifications..................................................................................................................................................................... 137
RJ-45 Twisted Pair Port Pinouts....................................................................................................................................... 138
RJ-45 Style Serial Console Port Pinouts .......................................................................................................................... 140

7
Figure 1: Front Panels of the AT-x930-28GTX and AT-x930-28GPX Switches...................................................................21
Figure 2: Front Panels of the AT-x930-28GSTX, AT-x930-52GTX, and AT-x930-52GPX Switches....................................22
Figure 3: Back Panel............................................................................................................................................................23
Figure 4: Management Panel ...............................................................................................................................................24
Figure 5: AT-PWR250 Power Supply...................................................................................................................................25
Figure 6: AT-PWR250-80 Power Supply..............................................................................................................................26
Figure 7: AT-PWR800 Power Supply...................................................................................................................................26
Figure 8: AT-PWR1200 Power Supply.................................................................................................................................27
Figure 9: LEDs for the 10/100/1000Base-T Ports on the AT-x930-28GTX AT-x930-52GTX Switches................................43
Figure 10: LEDs for the 10/100/1000Base-T Ports on the AT-x930-28GPX and AT-x930-52GPX Switches ......................45
Figure 11: SFP Slot LEDs ....................................................................................................................................................46
Figure 12: SFP+ Slot LEDs ..................................................................................................................................................47
Figure 13: Switch ID LED.....................................................................................................................................................49
Figure 14: Switch ID LED.....................................................................................................................................................49
Figure 15: Switch ID LEDs in the Low Power Mode.............................................................................................................50
Figure 16: Accessory Kit.......................................................................................................................................................60
Figure 17: Pre-installed Items...............................................................................................................................................61
Figure 18: Removing the AT-PNL250 Blank Panel ..............................................................................................................65
Figure 19: Power Supply Accessory Items...........................................................................................................................66
Figure 20: Installing a Power Supply....................................................................................................................................67
Figure 21: Improper Installation of a Power Supply..............................................................................................................68
Figure 22: Tightening the Captive Screws on the Power Supply..........................................................................................68
Figure 23: Installing the Power Cord Retaining Clip.............................................................................................................69
Figure 24: Installing a Blank Panel on a Power Supply Slot.................................................................................................70
Figure 25: Tightening the Captive Screws on the Power Supply Blank Panel .....................................................................71
Figure 26: Installing the Bumper Feet...................................................................................................................................73
Figure 27: Attaching the Equipment Rack Brackets.............................................................................................................78
Figure 28: Attaching the Equipment Rack Brackets (Continued) .........................................................................................79
Figure 29: Installing the Switch in an Equipment Rack.........................................................................................................80
Figure 30: Positions of the Switch on the Wall.....................................................................................................................82
Figure 31: Minimum Wall Area Dimensions with the Front Panel on the Left.......................................................................83
Figure 32: Minimum Wall Area Dimensions with the Front Panel on the Right....................................................................84
Figure 33: Switch on the Wall with a Plywood Base.............................................................................................................85
Figure 34: Steps to Installing the Switch with a Plywood Base ............................................................................................86
Figure 35: Installing the Brackets to the Switch for Wall Installation ....................................................................................90
Figure 36: Mounting Holes ...................................................................................................................................................91
Figure 37: Securing the Switch to the Plywood Base...........................................................................................................92
Figure 38: Marking the Locations of the Bracket Holes on a Concrete Wall ........................................................................94
Figure 39: Installing the Switch on a Concrete Wall.............................................................................................................95
Figure 40: On/Off Switch on AT-PWR250-80 Power Supply................................................................................................98
Figure 41: DC Terminal Block...............................................................................................................................................98
Figure 42: Stripped Wire.......................................................................................................................................................99
Figure 43: Connecting the Ground Wire to the DC Terminal Block......................................................................................99
Figure 44: Raising the Power Cord Retaining Clip.............................................................................................................103
Figure 45: Connecting the AC Power Cord ........................................................................................................................104
Figure 46: Lowering the Power Cord Retaining Clip...........................................................................................................105
Figure 47: On/Off Switch on the AT-PWR250-80 DC Power Supply..................................................................................106
Figure 48: Switch Initialization Messages...........................................................................................................................108
Figure 49: Switch Initialization Messages (Continued).......................................................................................................109
Figures

Figures
8
Figure 50: Switch Initialization Messages (Continued).......................................................................................................110
Figure 51: Connecting the Management Cable to the Console Port ..................................................................................113
Figure 52: User Exec Mode Prompt....................................................................................................................................115
Figure 53: SHOW STACK Command.................................................................................................................................115
Figure 54: Moving to the Global Configuration Mode .........................................................................................................116
Figure 55: Confirmation Prompt for the NO STACK ENABLE Command..........................................................................116
Figure 56: Disabling VCStack.............................................................................................................................................117
Figure 57: Returning to the Privileged Exec Mode .............................................................................................................117
Figure 58: Saving the Changes with the WRITE Command...............................................................................................117
Figure 59: PORT Parameter in the Command Line Interface.............................................................................................118
Figure 60: Removing the Dust Plug from an SFP Slot........................................................................................................123
Figure 61: Installing an SFP Transceiver............................................................................................................................124
Figure 62: Removing the Dust Cover from an SFP or SFP+ Transceiver..........................................................................124
Figure 63: Positioning the SFP or SFP+ Handle in the Upright Position............................................................................125
Figure 64: Connecting a Fiber Optic Cable to an SFP or SFP+ Transceiver .....................................................................126
Figure 65: RJ-45 Socket Pin Layout (Front View)...............................................................................................................138

9
Tables
Table 1: Models and Basic Features ...................................................................................................................................16
Table 2: Twisted Pair Cable for the 10/100/1000Base-T Ports ...........................................................................................30
Table 3: IEEE Powered Device Classes ..............................................................................................................................32
Table 4: Twisted Pair Cable Requirements for the 10/100/1000Base-T Ports at 10 or 100Mbps .......................................32
Table 5: Twisted Pair Cable Requirements for the 10/100/1000Base-T Ports at 1000Mbps ..............................................33
Table 6: Power Supply Budgets of the Power Supplies ......................................................................................................33
Table 7: Power Budgets of the AT-PWR800 Power Supply ................................................................................................34
Table 8: Power Budgets of the AT-PWR1200 Power Supply ..............................................................................................35
Table 9: NET MGMT Port LED ............................................................................................................................................41
Table 10: LEDs on the 10/100/1000Base-T Ports on the AT-x930-28GTX and AT-x930-52GTX Switches .......................44
Table 11: LEDs on the 10/100/1000Base-T Ports on the AT-x930-28GPX and AT-x930-52GPX Switches .......................45
Table 12: SFP Slot LEDs on the AT-x930-28GSTX Switch .................................................................................................47
Table 13: SFP+ Slot LEDs ...................................................................................................................................................48
Table 14: Stacking Slot LEDs ..............................................................................................................................................48
Table 15: Accessory Items Included with the Power Supplies ............................................................................................66
Table 16: Product Dimensions ...........................................................................................................................................132
Table 17: Product Weights ................................................................................................................................................132
Table 18: Ventilation Requirements ...................................................................................................................................133
Table 19: Environmental Specifications .............................................................................................................................134
Table 20: Maximum Power Consumption with the AT-PWR250 or AT-PWR250-80 Power Supply .................................135
Table 21: Maximum Power Consumption with the AT-PWR800 Power Supply ................................................................135
Table 22: Maximum Power Consumption with the AT-PWR1200 Power Supply ..............................................................135
Table 23: Input Voltages ....................................................................................................................................................136
Table 24: Product Certifications .........................................................................................................................................137
Table 25: Pin Signals for 10 and 100 Mbps .......................................................................................................................138
Table 26: Pin Signals for 1000 Mbps .................................................................................................................................138
Table 27: RJ-45 Style Serial Console Port Pin Signals .....................................................................................................140

Tables
10

11
Preface
This guide contains the installation instructions for the x930 Series of
Layer 3, Gigabit Ethernet switches. This preface contains the following
sections:
“Document Conventions” on page 12
“Contacting Allied Telesis” on page 13
Note
This guide explains how to install the switches as stand-alone units.
For instructions on how to build a stack with Virtual Chassis Stacking
(VCStack™), refer to the x930 Series Installation Guide for Virtual
Chassis Stacking.

Preface
12
Document Conventions
This document uses the following conventions:
Note
Notes provide additional information.
Caution
Cautions inform you that performing or omitting a specific action
may result in equipment damage or loss of data.
Warning
Warnings inform you that performing or omitting a specific action
may result in bodily injury.

x930 Series Installation Guide for Stand-alone Switches
13
Contacting Allied Telesis
If you need assistance with this product, you may contact Allied Telesis
technical support by going to the Support & Services section of the Allied
Telesis web site at www.alliedtelesis.com/support. You can find links for
the following services on this page:
24/7 Online Support — Enter our interactive support center to
search for answers to your product questions in our knowledge
database, to check support tickets, to learn about RMAs, and to
contact Allied Telesis technical experts.
USA and EMEA phone support — Select the phone number that
best fits your location and customer type.
Hardware warranty information — Learn about Allied Telesis
warranties and register your product online.
Replacement Services — Submit a Return Merchandise
Authorization (RMA) request via our interactive support center.
Documentation — View the most recent installation and user
guides, software release notes, white papers, and data sheets for
your products.
Software Downloads — Download the latest software releases for
your managed products.
For sales or corporate information, go to www.alliedtelesis.com/
purchase and select your region.

Preface
14

15
Chapter 1
Overview
This chapter contains the following sections:
“Models” on page 16
“Features” on page 17
“Front and Back Panels” on page 21
“Management Panel” on page 24
“Power Supplies” on page 25
“10/100/1000Base-T Twisted Pair Ports” on page 29
“Power Over Ethernet” on page 31
“SFP Slots” on page 38
“SFP+ Slots” on page 39
“Stacking S1 and S2 SFP+ Slots” on page 40
“Ethernet Management Port (NET MGMT)” on page 41
“eco-friendly Button” on page 42
“LEDs” on page 43
“USB Port” on page 51
“Console Port” on page 52
Note
This guide explains how to install the switches as stand-alone units.
For instructions on how to build a stack with Virtual Chassis Stacking
(VCStack™), refer to the x930 Series Installation Guide for Virtual
Chassis Stacking.

Chapter 1: Overview
16
Models
Table 1 lists the models and basic features of the x930 Series of stackable
Gigabit Layer 3 switches.
Additional information is listed here:
The switches do not come with power supplies. The power
supplies must be ordered separately. For more information, refer
to “Power Supplies” on page 25.
The power budgets of the AT-x930-28GPX and AT-x930-52GPX
Switches for PoE+ powered devices depend on the number and
types of power supplies installed in theunits. For more information,
refer to “Power Budget” on page 33.
You may use the VCStack feature to stack the switches with either
the S1 and S2 ports, which come standard with the units, or with
the optional AT-StackQS card. For more information, refer to the
x930 Series Installation Guide for Virtual Chassis Stacking.
The twisted pair ports and SFP slots on AT-x930-28GSTX Switch
are paired together. Only one port or slot in a pair is operational at
a time. For more information, refer to “SFP Slots” on page 38.
Table 1. Models and Basic Features
Model 10/100/1000 Base-T
Ports SFP Slots SFP+ Slots PoE+ VCStack
AT-x930-28GTX 24 0 4 No Yes
AT-x930-28GPX 24 0 4 Yes Yes
AT-x930-28GSTX 24 24 4 No Yes
AT-x930-52GTX 48 0 4 No Yes
AT-x930-52GPX 48 0 4 Yes Yes

x930 Series Installation Guide for Stand-alone Switches
17
Features
Here are the switches and their features:
x930 Models Here are the switches in the x930 Series:
AT-x930-28GTX
AT-x930-28GPX
AT-x930-28GSTX
AT-x930-52GTX
AT-x930-52GPX
10/100/1000
Mbps Twisted
Pair Ports
Here are the basic features of the 10/100/1000 Mbps twisted pair ports:
24 or 48 ports per switch
10Base-T, 100Base-TX, and 1000Base-T compliant
IEEE 802.3u Auto-Negotiation compliant
Auto-MDI/MDIX
100 meters (328 feet) maximum operating distance
IEEE 802.3x flow control in 10/100Base-TX full-duplex mode
IEEE 802.3x backpressure in 10/100Base-TX half-duplex mode
IEEE 802.3ab 1000Base-T
Jumbo frames up to 13KB
RJ-45 connectors
Power Over
Ethernet Here are the basic features of Power over Ethernet (PoE) on the twisted
pair ports on the AT-x930-28GPX and AT-x930-52GPX Switches:
Supported on ports 1 to 24 on the AT-x930-28GPX Switch and
ports 1 to 48 on the AT-x930-52GPX Switch
Supports PoE (15.4 watts maximum) and PoE+ (30 watts
maximum) powered devices
Supports powered device classes 0 to 4
Port prioritization
Mode A wiring
SFP Slots Here are the basic features of the twenty four SFP slots on the AT-x930-
28GSTX Switch:
Supports 100Base-FX, 1000Base-T, and 1000Base-SX/LX SFP
transceivers

Chapter 1: Overview
18
Supports single-port BiDi 100Base-FX and 1000Base-LX SFP
transceivers
Supports 1000Base-ZX SFP transceivers
Note
The SFP slots and twisted pair ports on the AT-x930-28GSTX
Switch are paired together. Only one slot or port in a pair is active at
a time. For more information, refer to “SFP Slots” on page 38.
Note
SFP transceivers must be purchased separately. For a list of
supported transceivers, contact your Allied Telesis distributor or
reseller.
SFP+ Slots Here are the basic features of the four SFP+ slots on the switches:
Supports 10Gbps, 10GBase-SR/LR fiber optic transceivers
Supports 10Gbps AT-SP10TW direct connect twinax cables with
SFP+ transceiver-style connectors
Supports 1000Base-SX/LX SFP transceivers
Supports single-port BiDi 1000Base-LX SFP transceivers
Supports 1000Base-ZX SFP transceivers
Note
The SFP+ slots do not support 100Mbps 100Base-FX transceivers.
Note
The slots support full-duplex mode only.They do not support half-
duplex mode.
Note
SFP and SFP+ transceivers must be purchased separately. For a
list of supported transceivers, contact your Allied Telesis distributor
or reseller.

x930 Series Installation Guide for Stand-alone Switches
19
Note
SFP+ slots 27/S1 and 28/S2 on the 28-port switches and slots 51/S1
and 52/S2 on the 52-port switches are initially configured as stacking
slots for the VCStack feature. If you plan to use the switch as a
stand-alone unit, you may disable the VCStack feature and use the
slots with standard SFP or SFP+ transceivers. The configuration
instructions are provided later in this guide, in Chapter 9,
“Configuring the Switch for Stand-alone Operation” on page 111.
S1 and S2
Stacking Slots SFP+ slots 27/S1 and 28/S2 on the 28-port switches and slots 51/S1 and
52/S2 on the 52-port switches can be used with the VCStack feature to
build a stack of up to eight switches. For instructions on the VCStack
feature, refer to the x930 Series Installation Guide for Virtual Chassis
Stacking.
LEDs Here are the port LEDs:
Link/activity and duplex mode LEDs for the twisted pair ports on
non-PoE switches
Link/activity and PoE status LEDs for the twisted pair ports on PoE
switches
Link/activity LEDs for SFP and SFP+ slots
Stack ID number LED
eco-friendly button turns off the LEDs to conserve electricity
Installation
Options Here are the installation options for the switches:
19-inch equipment rack
Desk or tabletop
Wall
MAC Address
Table Here are the basic features of the MAC address tables of the switches:
Storage capacity of 61,440 dynamic and static entries
Automatic learning and aging
Management
Software and
Interfaces
Here are the management software and interfaces:
AlliedWare Plus Management Software
Command line interface
Web browser interface

Chapter 1: Overview
20
Management
Methods Here are the methods for managing the switches:
Local management through the Console port
Remote Telnet and Secure Shell management
Remote HTTP and HTTPS web browser management
SNMPv1, v2c, and v3
Power Supplies Here are the power supplies:
AT-PWR250
AT-PWR250-80
AT-PWR800
AT-PWR1200
