Allied Telesis AT-PWR01 User manual

Installation Guide
Removable Power Supply and Fan
AT-PWR01
AT-PWR02
AT-PWR05
AT-FAN01
AT-FAN03

Removable Power Supply and Fan
Installation Guide
AT-PWR01
AT-PWR02
AT-PWR05
AT-FAN01
AT-FAN03
Download the complete document set from
www.alliedtelesis.com/support/software

Removable Power Supply and Fan
2
Removable Power Supply and Fan Installation Guide
Document Number C613-04057-00 REV Q
© 2009 Allied Telesis, Inc. All rights reserved. No part of this publication may be
reproduced without prior written permission from Allied Telesis, Inc.
Allied Telesis, Inc. reserves the right to change specifications and other
information in this document without prior written notice. The information
provided herein is subject to change without notice. In no event shall Allied
Telesis, Inc. be liable for any incidental, special, indirect, or consequential
damages whatsoever, including but not limited to lost profits, arising out of or
related to this manual or the information contained herein, even if Allied Telesis,
Inc. has been advised of, known, or should have known, the possibility of such
damages.
Allied Telesis, AlliedWare, AlliedWare Plus, and SwitchBlade are trademarks or
registered trademarks in the United States and elsewhere of Allied Telesis, Inc.
Adobe, Acrobat, and Reader are either registered trademarks or trademarks of
Adobe Systems Incorporated in the United States and/or other countries.
Microsoft and Visio are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries. Additional brands,
names and products mentioned herein may be trademarks of their respective
companies.

Installation Guide
3
Contents
About this Guide .............................................................................................................. 4
Compatible Switches ....................................................................................................... 4
Package Contents ............................................................................................................. 5
Installing a Power Supply Unit or Fan .......................................................................... 6
Connecting an AC power supply .................................................................................. 9
Connecting a PWR01 DC power supply .................................................................. 12
Connecting a PWR05 DC power supply .................................................................. 14
Checking LEDs ................................................................................................................ 16
Removing a Power Supply Unit or Fan ...................................................................... 19
Troubleshooting .............................................................................................................. 22
Obtaining Documentation and Resources ............................................................... 23
Standards .......................................................................................................................... 25
EC Declaration of Conformity .................................................................................... 26

Removable Power Supply and Fan
4
About this Guide
This Installation Guide describes how to install the following PSUs and fans:
■AT-PWR01 PSU, either AC or DC power supply unit
■AT-PWR02 PSU, AC only
■AT-PWR05 PSU, either AC or DC power supply unit
■AT-FAN01, fan-only module
■AT-FAN03, chassis fan module
Compatible Switches
The following table shows which models of PSUs and fans are appropriate for
individual switches.
You can download complete documentation for these switches from
www.alliedtelesis.com/support/software. For more information about the
documentation and other resources, see “Obtaining Documentation and
Resources” on page 23.
Switch PWR01 PWR02 PWR05 FAN01 FAN03
AT-8948 99
x900-48FE 99
x900-48FS 99
AT-9924T 99
AT-9924SP 99
AT-9924Ts 99
x900-24XT 99
x900-24XT-N 99
x900-24XS 99
SwitchBlade®x908 99

Installation Guide
5
Package Contents
Depending on the model, switches are shipped with a single supply unit (PSU),
either AC or DC. Some models also have fan-only modules (FOM), chassis fan
modules, or blanking plates.
■The AT-8948, AT-9924Ts, x900-24XT, x900-24XT-N, and x900-24XS
switches have a PSU and a FOM installed.
■The x900-48FE, x900-48FS, AT-9924T, and AT-9924SP switches have a PSU
and a blanking plate installed.
■The SwitchBlade®x908 is shipped with dual chassis fan modules and
blanking plates, but no PSUs.
The following items are included with each factory-installed PSU. Contact your
authorised Allied Telesis distributor or reseller if any are damaged or missing.
■one AC power cable (AC models)
■one power cable retaining clip (AC models)
■one warranty card
The following items are included with PSUs when purchased separately:
■one AC power cable (AC models)
■one power cable retaining clip (PWR01 and PWR02 AC models only)
■one clip-on ferrite core (PWR05 AC model only)
■one DC power cable (PWR05 DC model only - requiring termination to a
48V DC power supply by a suitably qualified person)
■this Installation Guide
■one warranty card
The following items are included with fans when purchased separately:
■this Installation Guide
■one warranty card

Removable Power Supply and Fan
6
Installing a Power Supply Unit or Fan
Use these instructions to install PSUs, chassis fan modules and FOMs.
■Do not combine AC and DC PSUs in the same switch.
■Do not combine PWR01 and PWR02 PSUs in the same switch.
Before you begin
■Read the safety information for the switch.
Safety information is in the x900 Series Switch and SwitchBlade®x908
Installation and Safety Guide. You can download this document from
www.alliedtelesis.com/support/software.
■Gather necessary tools and equipment.
Youwillneedanappropriateflat-bladedorPhillips(#1)screwdrivertotighten
or loosen the captive screws.
■Verify the package contents if you have not already done so.
See “Package Contents” on page 5. Contact your authorised Allied Telesis
distributor or reseller if items are damaged or missing.
■Remove the unit from its packing material in an anti-static environment.
Caution Follow correct anti-static procedures. Failure to do so could
damage the PSU, fan, or switch. If you are unsure about correct procedures,
contact your authorised Allied Telesis distributor or reseller.
Caution When adding or replacing power supplies, keep your hands and
fingers out of the power supply bays. After installing a PWR05 power supply,
use a screwdriver to tighten the captive screw such thata screwdriver will be
required to remove the PSU at a later date.

Installation Guide
7
Installing a PWR01, PWR02, or FAN01
1. If there is a PSU, fan or blanking plate in the bay you wish to install the unit,
first remove the old unit, following the steps described in section
“Removing a Power Supply Unit or Fan” on page 19.
2. Insert the new PSU or fan unit, and carefully slide it into the bay.
Insert it slowly, being sure to keep it straight. Firmly press the unit until the
faceplate engages, or nearly engages, the chassis. Forcing a misaligned unit
into the bay is likely to damage both the unit and chassis.
Note that when you have only one PSU installed in the AT-9924T and
AT-9924SP switches, it must be installed in bay 2 to optimise cooling.
3. Secure the unit in the switch by tightening the captive screws on the
faceplate.
Captive screw
Captive screw
PSU
Switch

Removable Power Supply and Fan
8
Installing a PWR05 or FAN03
1. If there is a PSU, fan or blanking plate in the bay you wish to install the unit,
first remove the old unit, following the steps described in section
“Removing a Power Supply Unit or Fan” on page 19.
2. Insert the new PSU or chassis fan module, and carefully slide it into the bay.
If you are installing a PSU, unlock the latch on the PSU first by loosening the
captive screw.
Insert the PSU or fan module slowly, being sure to keep it straight. Firmly
press the unit until the faceplate engages, or nearly engages, the chassis.
Forcing a misaligned unit into the bay may damage both the unit and chassis.
3. Secure the unit in the switch by tightening the captive screw(s) on the
faceplate. On the PWR05, use a screwdriver to tighten the captive screw
such that a screwdriver will be required to remove the PSU at a later date.
Captive screw
PSU bays
PSU
Captive screw
Chassis fan
Service
access
panels

Installation Guide
9
Connecting an AC power supply
Follow these instructions to connect an AT-PWR01, AT-PWR02, or AT-PWR05
AC PSU to an AC power supply:
Warning The AT-PWR01 AC PSU has a fuse rating of 250VAC, 5A for FH101
and FH102.
Warning The AT-PWR01 AC PSU has double pole/neutral fusing. Electric
shock is possible since there are dual primary fuses, one on the phase circuit and
one on the neutral circuit. If the neutral opens, the phase may still be live.
Warning When x900-24 units are connected with VCS stacking cables (XEM-
STK-CBL) ensure that all the PSUs are appropriately grounded. This is to avoid
large circulating ground currents that could damage the stacking cables. To
achieve this ensure that:
■AT-PWR01 AC is grounded by the 3-pin AC power connector
■All grounding points are at the same ground level. That is, all power
connectors share a common power distribution unit.
Warning For SwitchBlade x908 units with AC PSUs, the grounding stud on the
rear of the device is provided for situations where an additional ground is
required. The device must be powered from a grounded 3 wire AC source via the
AC power cable and connector.
Warning When SwitchBlade x908 units are connected with VCS stacking
cables (either HS-STK-CBL or XEM-STK-CBL), each individual stack member
chassis must be additionally grounded by using the rear grounding-terminal on
each device. In order to avoid large circulating ground currents, thewires of each
grounding cable must be 18 AWG (0.8mm2) or thicker.

Removable Power Supply and Fan
10
Connecting a PWR01 or PWR02
1. Plug the supplied AC power cable into the power inlet on the PSU and
attach the retaining clip.
2. Connect the power cable to the main power source.
3. The PSU LED on the front panel of the switch lights green. If the LED does
not light, refer to the Hardware Reference for troubleshooting information.
Connecting a PWR05 (AC version only)
The rear grounding-terminal is not necessary for the SwitchBlade x908 when
using AC PSUs because the chassis is grounded through the power cable.
1. Form a loop in the supplied AC power cable at the PSU end and clip the
ferrite core over the looped cable, as shown in the following illustration.
This keeps the ferrite core in its correct position, close to the PSU.
Looped power cable
Ferrite core

Installation Guide
11
2. Plug the AC power cable into the power inlet on the PSU.
3. Connect the power cable to the main power source.
4. Check that the Run/Standby switch is set to the Run position (1). Both the
AC IN and DC OUT LEDs should be lit.
Note that when the Run/Standby switch is set to the Standby position (O),
the AC IN LED lights and the fan spins, but the DC OUT LED does not
light and the PSU does not deliver power to the device.
5. The PSU LED on the front panel of the switch lights green. If the LED does
not light green, check the Run/Standby switch. See the Hardware Reference
for more troubleshooting information.
AC
IN
LED
RUN/STANDBY
SWITCH
CAPTIVE
SCREW
DC
OUT
LED
FAULT
LED

Removable Power Supply and Fan
12
Connecting a PWR01 DC power supply
Follow these instructions to connect an AT-PWR01 DC PSU to a DC power
supply. Only trained and qualified personnel should connect a DC power supply.
You need an appropriate DC power source, DC supply cable, ring connectors, a
crimp tool and an appropriate screwdriver to tighten the terminal screws.
For centralised DC power connection, the switch should be installed in
restricted access areas only (such as dedicated equipment rooms or
equipment closets) in accordance with Articles 110-16, 110-17, and 110-18 of
the National Electrical Code, ANSI/NFPA 70.
Power supply specifications:
■functional range 40 to 60V, 48V nominal
■supports either positive grounded or negative grounded operation
■a 15Amp certified/listed circuit breaker is required for circuit protection
Supply cable specifications:
■tray cable should be UL listed Type TC tray cable (or equivalent)
■three-core cable is required
■minimum core size: 3.3mm2(12 AWG) high strand count copper wire
■minimum cable rating: 600V, 90 degrees C
Warning Disconnect the power supply cable before starting this procedure.
1. Remove the transparent protective terminal cover.
2. Strip the supply cable wires to expose 7.5mm (0.31 in.) of bare conductor.
Terminate the wire with a nylon insulated solderless ring tongue terminal,
JST FN5.5-5 or equivalent, using a crimp tool.
3. Connect the ground wire to the ground terminal. Use the diagram on the
rear panel of the switch to identify terminals. Tighten the terminal to
between 2.4 and 4.0 Nm (21.3 and 35.4 lbf in).
Warning When x900-24 units are connected with VCS stacking cables (XEM-
STK-CBL) ensure that all the PSUs are appropriately grounded. This is to avoid
large circulating ground currents that could damage the stacking cables. To
achieve this ensure that:
• AT-PWR01 DC is grounded at the GND terminal. In order to avoid
large circulating ground currents, the wires of each grounding cable
must be 18 AWG (0.8mm2) or thicker.

Installation Guide
13
• All grounding points are at the same ground level. That is, all power
connectors share a common power distribution unit.
Warning Whenmountingoneortwo AT-PWR01DC PSUstoa groundedrack,
ensure that the ground level of the rack and the DC power connector are the
same.
4. Connect the positive feed to the + (positive) terminal and the negative feed
to the - (negative) terminal. Tighten the terminals to between 2.4 and
4.0Nm (21.3 and 35.4 lbf in).
Note that the DC return input terminal must be connected as an Isolated
DC return (DC-I).
Warning In orderto avoid damaging the PSU, make sure that thePSU terminals
are wired to the correct polarity.
5. Ensure that there are no exposed cable strands.
6. Replace the cover. You must replace the transparent plastic terminal cover
before continuing.
7. Secure the supply cable to the rack framework or a similar object to ensure
that connections are isolated from any force applied to the cable.
8. Ensure that the circuit breaker for the supply circuit and the Run/Standby
switch on the PSU are off. Press and release the Run/Standby switch so that
it is not pushed in (which is the Off position).
9. Connect the supply cable wires to the circuit breaker.
10. Turn on the PSU by pushing in the Run/Standby switch.
11. Confirm that the switch is receiving power.
Check that at least one of the PSU LEDs on the front panel of the switch is
lit green. If no LEDs light, refer to the Hardware Reference for
troubleshooting information.

Removable Power Supply and Fan
14
Connecting a PWR05 DC power supply
Follow these instructions to connect an AT-PWR05 DC PSU to a DC power
supply. Only trained and qualified personnel should connect a DC power supply.
You need to connect the supplied DC power cable to an appropriate DC power
source.
For centralised DC power connection, the switch should be installed in
restricted access areas only (such as dedicated equipment rooms or
equipment closets) in accordance with Articles 110-16, 110-17, and 110-18 of
the National Electrical Code, ANSI/NFPA 70.
Warning Whenmountingoneortwo AT-PWR05DC PSUstoa groundedrack,
ensure that the ground level of the rack and the DC power connector are the
same .
Power supply specifications:
■functional range 40 to 60V DC, 48V nominal
■supports either positive grounded or negative grounded operation
■a 30Amp certified/listed circuit breaker is required for circuit protection
Warning When SwitchBlade x908 devices are connected with VCS stacking
cables (either HS-STK-CBL or XEM-STK-CBL), each individual stack member
chassis must be additionally grounded by using the rear grounding-terminal on
each device. In order to avoid large circulating ground currents, thewires of each
grounding cable must be 18 AWG (0.8mm2) or thicker.
DC
IN
LED
RUN/STANDBY
SWITCH
CAPTIVE
SCREW
DC
OUT
LED
FAULT
LED
N/C GREEN
( GND )
RED
( + )
BLACK
( - )

Installation Guide
15
1. Ensure that the circuit breaker for the supply circuit and the Run/Standby
switch on the PSU are off (slide to position O).
2. Plug the DC power cable into the power inlet on the PSU.
3. Connect the supply cable wires to the circuit breaker and switch the circuit
breaker ON.
4. Turn on the PSU by sliding in the Run/Standby switch to position 1.
5. Confirm that the switch is receiving power.
Check that the PSU LED on the front panel of the switch corresponding to
the the PSU bay lights green. If the LED does not light green, check the
Run/Standby switch. See the Hardware Reference for more
troubleshooting information.

Removable Power Supply and Fan
16
Checking LEDs
LEDs on PSUs, fans, and the front panels of switches indicate the operational
status of the devices. After you have installed a PSU or fan and have powered on
the switch, check the LEDs to verify operation by using the following tables.
PWR01
PWR02 The following table describes LEDs on the PWR01 and PWR02 power supply
units.
PWR05 The following is a diagram of the LEDs in the PWR05 power supply units:
LED State Description
FAULT Red The temperature on the PSU has exceeded the limit of
75º C (167º F), or the fan failed.
PWR
GOOD Green A PSU is installed in the switch and is delivering power.
IN
LED
POWER
CONNECTOR
OUT
LED
FAULT
LED

Installation Guide
17
PWR05
AC The following table describes LEDs on the PWR05 AC power supply unit.
PWR05
DC The following table describes LEDs on the PWR05 DC power supply unit.
FAN01 The following table describes LEDs on the FAN01 fan-only module.
LED State Description
~
IN Green AC input voltage is within 90-264VAC, 47-63Hz.
Off AC input voltage is outside the acceptable range.
OUT Green DC output voltage is within 12VDC +/- 10%.
Off DC output voltage is outside the acceptable range, or
the Standby switch is Off. If a fault occurs then the
FAULT LED will display and the OUT LED will be Off.
FAULT
Red A fault has occurred. There is either a fan failure, or the
temperature has exceeded its limit of 70ºC (158ºF).
Off No fault conditions detected.
LED State Description
IN Green DC input voltage is within 40VDC to 60 VDC.
Off DC input voltage is outside the acceptable range.
OUT Green DC output voltage is within 12VDC +/- 10%.
Off DC output voltage is outside the acceptable range, or
the Standby switch is Off. If a fault occurs then the
FAULT LED will display and the OUT LED will be Off.
FAULT
Red A fault has occurred. There is either a fan failure, or the
temperature has exceeded its limit of 70ºC (158ºF).
Off No fault conditions detected.
LED State Description
FAULT Red The fan has failed.

Removable Power Supply and Fan
18
FAN03 The following table describes LEDs on the FAN03 chassis fan module.
Switch The following table describes how LEDs on the switch report operations and
faults with installed PSUs and FOMs.
LED State Description
FAN
STATUS Red The fan has failed.
LED State Description
PSU 1
and
PSU 2
Green ThePSUisinstalledandsupplyingpowertotheswitch.
The voltage output is within specification.
Red One of the following:
•The PSU is installed in the switch, and a fan has
failed or the PSU has exceeded its recommended
temperature threshold of 70ºC (158º F).
•AFOMis installedinthe switchand afanhas failed.
Notethatthe x900-12XT/SandSwitchBlade x908
switches do not support FOMs.
•The bay is empty. Applies to AT-8948, AT-9924Ts,
x900-24XT, x900-24XT-N, and x900-24XS
switches which require a FOM when only one PSU
is installed.
•Dual PSUs are installed, but the PSU is not
receiving power.
•The standby switch is off
(PWR01 DC, PWR05 AC, or PWR05 DC).
Off One of the following:
•A FOM is installed and operating at an acceptable
speed. Note that the x900-12XT/S and
SwitchBlade x908 switches do not support FOMs.
•On x900-48FE, x900-48FS, AT-9924T and AT-
9924SP switches there is no PSU or FOM in this
bay.
•On a SwitchBlade x908 switch there is no PSU in
this bay.

Installation Guide
19
Removing a Power Supply Unit or Fan
Follow these instructions to remove a PSU, chassis fan module, FOM or blanking
plate.
Before you begin
■Read the safety information for the switch.
Safety information is in the x900 Series Switch and SwitchBlade®x908
Installation and Safety Guide. You can download this document from
www.alliedtelesis.com/support/software.
■Gather necessary tools and equipment.
Youwillneedanappropriateflat-bladedorPhillips(#1)screwdrivertotighten
or loosen the captive screws.
Caution Follow correct anti-static procedures. Failure to do so could
damage the PSU, fan, or switch. If you are unsure about correct procedures,
contact your authorised Allied Telesis distributor or reseller.
Caution Keep your hands and fingers out of the power supply bays.
To remove a PSU, chassis fan module or FOM
1. If you are removing a PSU, disconnect the power supply.
For AC PSUs, turn off the main power source to the PSU and disconnect
the power cable.
For PWR01 DC PSUs, push and release the Run/Standby switch to the
Standby (off) position. The Run/Standby switch is in the Run (on) position
when it is depressed, and in the Standby (off) position when it is not
depressed. Disconnect the DC power supply then disconnect the supply
cable wires from the circuit breaker.
For PWR05 DC PSUs, slide the Run/Standby switch to the O (off) position.
Disconnect the power supply cable from the power supply.
2. Using a screwdriver, loosen the captive screws until fully loosened.
The following is a diagram of PWR01, PWR02 or FAN01
