Allied Telesis AT-WDRPS-10 User manual

Overview
The AT-WDRPS-10 is an AC Redundant Power Supply (RPS) for theAT-WD1008
Multiplexerchassis.When installed,theunit sharesthe load of poweringthe
chassis with the standard power supply that comes pre-installed inthe chassis. If a
power supply fails, the remaining unit provides all power tothe system, thereby
preventing a network failure. The power supply is hot-swappable, meaning that
you can install it while the chassis is powered ON.
POWER
FAULT
AT-WDRPS-10
Related Documents
The Allied Telesyn web site at www.alliedtelesyn.com provides you with an easy
waytoaccessthemost recentdocumentation,software, andtechnical information
for all of our products. For details on the features and functions ofyour Allied
Telesyn AT-WD1008 chassis and modules, refer to the following manuals from our
web site:
❑AT-WD1008 Gigabit Ethernet WavelengthDivision Multiplexer
Installation Guide
PN 613-50367-00
❑AT-S47 Management Software User’s Guide
PN 613-50371-00
Package Contents
Make sure the following items are included in the shipping package. If any itemis
missing or damaged, contact your Allied Telesyn sales representative for
assistance.
❑One AT-WDRPS-10 Redundant Power Supply (AC) Module
❑One AC Power Cord
❑This installation guide
❑Warranty card
Installing the AT-WDRPS-10 Power Supply
Caution
Before installing the module, refer to the AT-WD1008InstallationGuide for
electrical safety and emission information.
Caution
Do not install the AT-WDRPS-10 module in an AT-WD1008 chassis designed
forDC power. AnAC powered chassishas two ACpower socketsonthe back
panel.
To install the AT-WDRPS-10, perform the following procedure:
Note
The AT-WDRPS-10 unit can be installed while the multiplexer is powered ON.
You do not need topower OFFthe multiplexer to install the RPS.
1. Loosen the two thumbscrews that secure theblank faceplate over the right-
handredundantpowersupplyexpansionslot located onthefrontpanelof the
AT-WD1008 Multiplexer and removethe cover.
2. Remove the AT-WDRPS-10 unit from its shipping package.
3. Slide the AT-WDRPS-10 unitinto the RPS expansion slot.
LNKTST
TX
RX
LNKTST
TX
RX
EAST
TX
SNMPMODULE
ST
TX
RX
RX TX
CH5
TX
RX
RX TX
CH6
TX
RX
RX TX
CH7
TX
RX
RX TX
CH8
TX
RX
FANA
FAN B
POWER
SUPPLYB
WEST EAST
NORMAL
LNKTST
LNKTST
TX
RX
LNKTST
TX
RX
EAST
TX
SNMP MODULE
ST
TX
RX
RXT
X
CH 5
TX
RX
RXTX
CH 6
TX
RX
RXTX
CH 7
TX
RX
RXTX
CH 8
TX
RX
FANA
FANB
POWER
SUPPLYB
WESTEAST
NORMAL
LNKTST
POWER
FAULT
AT-WDRPS-10
AT-WDRPS-10
Redundant Power Supply (AC)
Installation Guide
Allied Telesyn, Inc.
960 Stewart Drive, Suite B
Sunnyvale,CA94085USA
Tel [phone] • Fax [phone]
Visit our web site at:www.alliedtelesyn.com
PN 613-50369-00 Rev A 123

4. SecuretheAT-WDRPS-10unittotheAT-WD1008chassisbytighteningthetwo
thumbscrews.
Note
If you are installing theAT-WD1008 Multiplexer for thefirst time, refer tothe
AT-WD1008Installation Guide for instructions on how to complete the
installation.
5. Connectthepowercord to theRPSAC powerconnector,locatedin thebackof
the multiplexer, and the other end of the cord to an appropriate AC power
source.
6. Turn the RPS power switch to the ON position.
7. Check that thePOWER LED on the front of the RPS module isgreen. If the
POWERLEDis OFForthe FAULTLEDis ON,referto theAT-WD1008Installation
Guide for troubleshooting instructions.
Note
For added power protection to the multiplexer, the two AC power cords
should be connected to power sources that are operating from different
power circuits. This will protect the multiplexer from a power loss should one
of the power circuits fail.
This completes the installation procedure forthe AT-WDRPS-10 unit.
LNKTST
TX
RX
LNKTST
TX
RX
EAST
TX
SNMPMODULE
ST
TX
RX
RX TX
CH5
TX
RX
RX TX
CH6
TX
RX
RX TX
CH7
TX
RX
RX TX
CH8
TX
RX
FAN A
FAN B
POWER
SUPPLYB
WEST EAST
NORMAL
LNKTST
POWER
FAULT
AT-WDRPS-10
AT-WDFAN01
Power ON/OFF
Switch for AC Power Inlet
the Optional
RPS Module for the Optional RPS Module
AC Power Inlet
for the Standard
Power Module
Power ON/OFF
Switch for
the Standard
Power Module
TechnicalSpecifications
Electrical Rating
Input Voltage 100 - 240 V AC, 3.2A maximum
ACInput Frequency: 47-63Hz
Power Comsumption 75 watts maximum
Environment
Operating Temperature: 0° C to 40° C (32° F to 104° F)
Storage Temperature: -25° C to 70°C (-13° F to 158° F)
OperatingRelativeHumidity: 5%to 90% RH (non-condensing)
Storage Relative Humidity: 5% to 95% RH (non-condensing)
Operating Altitude Range: Up to 3,000 m (9,843 ft)
Electrical Safety and Emission Statement
Standards: This product meets the following standards when installed in compliant host equipment.
Emission FCC Class A, EN55022Class A, VCCI ClassA, EN6100-3-2, EN6100-3-3
WARNING: Ina domestic environment thisproduct may causeradio interference inwhich casetheuser may be
required to take adequate measures.
Immunity EN55024
ElectricalSafety UL60950 (cULus), EN60950 (TUV)
Copyright2003 Allied Telesyn, Inc. All rights reserved.
No part of this publication may be reproduced without prior written permission from Allied Telesyn Inc.
U.S. Federal Communications Commission
RADIATED ENERGY
Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to
Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with this instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
Note: Modifications or changes not expressly approved of by the manufacturer or the FCC, can void your right to
operate this equipment.
Industry Canada
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du
Canada.
