Allied Telesis AT-RPS8000 User manual

AT-RPS8000
Redundant Power Supply for the
AT-8300 Series Switches
Quick Install Guide
PN 613-10816-00 Rev B

Copyright 1999, 2000 Allied Telesyn International, Corp.
960 Stewart Drive Suite B, Sunnyvale CA 94086, USA
All rights reserved. No part of this publication may be reproduced without prior written permission
from Allied Telesyn International, Corp.
Ethernet is a registered trademark of Xerox Corporation. All other product names, company names,
logos or other designations mentioned herein are trademarks or registered trademarks of their
respective owners.
Allied Telesyn International, Corp. reserves the right to make changes in specifications and other
information contained in this document without prior written notice. The information provided
herein is subject to change without notice. In no event shall Allied Telesyn International, Corp. be
liable for any incidental, special, indirect, or consequential damages whatsoever, including but not
limited to lost profits, arising out of or related to this manual or the information contained herein,
even if Allied Telesyn International, Corp. has been advised of, known, or should have known, the
possibility of such damages.

iii
Electrical Safety and Emission Compliance
Statement
Standards: Thisproduct meetsthe following standards
RFI Emission EN55022 Class A!1
WARNING: In a domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures. !2
Immunity EN50082-11997 !3
Electrical Safety EN60950,UL1950,CSA 950 !4
IMPORTANT: Appendix Acontains translated safetystatements for installing this equipment. When you see the
!, go to Appendix A for the translated safety statement in your language.
WICHTIG: Anhang A enthält übersetzte Sicherheitshinweise für dieInstallation dieses Geräts. Wenn Sie!
sehen, schlagenSiein Anhang A den übersetzten Sicherheitshinweis in Ihrer Sprachenach.
VIGTIGT: Tillæg A indeholder oversatte sikkerhedsadvarsler, der vedrører installation af dette udstyr. Når Deser
symbolet !, skal De slå op i tillæg A og finde de oversatte sikkerhedsadvarsler i Deres eget sprog.
BELANGRIJK: Appendix Abevat vertaalde veiligheidsopmerkingen voorhet installeren van deze apparatuur.
Wanneer u de !ziet, raadpleeg Appendix A voor vertaalde veiligheidsinstructies in uw taal.
IMPORTANT:L'annexe A contient les instructions de sécurité relatives à l'installationde cet équipement. Lorsque
vous voyez le symbole !, reportez-vous à l'annexe A pour consulter la traduction de ces instructions dans votre
langue.
TÄRKEÄÄ: LiiteA sisältää tämän laitteen asentamiseen liittyvät käännetyt turvaohjeet. Kun näet !-symbolin,
katso käännettyä turvaohjettaliitteestä A.
IMPORTANTE: l’Appendice A contiene avvisidi sicurezza tradotti per l’installazione di questa apparecchiatura. Il
simbolo !,indicadi consultarel’AppendiceA per l’avviso di sicurezza nella propria lingua.
VIKTIG: TilleggAinneholderoversattsikkerhetsinformasjonforinstalleringavdetteutstyret.Nårduser!,åpner
du til Tillegg A for å finne den oversatte sikkerhetsinformasjonenpå ønsket språk.
IMPORTANTE: OAnexoAcontémadvertênciasdesegurançatraduzidasparainstalaresteequipamento.Quando
vir o símbolo !, leia aadvertênciade segurança traduzida noseuidioma no Anexo A.
IMPORTANTE: El ApéndiceA contiene mensajes de seguridad traducidos para la instalación de este equipo.
Cuando vea el símbolo !, vaya al Apéndice A para verel mensajede seguridadtraducido a suidioma.
OBS! Bilaga A innehåller översatta säkerhetsmeddelanden avseende installationen av denna utrustning. När du
ser !, skall du gå till Bilaga A föratt läsa det översatta säkerhetsmeddelandet på dittspråk.
U.S. Federal Communications Commission
RADIATED ENERGY
Note: Thisequipment has been tested and found to comply with the limits for a Class A digital device pursuant
to Part 15of FCC Rules. These limitsare designedto provide reasonable protection against harmful
interference when the equipment is operatedin a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and,if not installed and used in accordance with this instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the interference at
his own expense.
Note: Modifications or changes not expresslyapprovedof by the manufacturer or the FCC, can void your right
to operate this equipment.
Industry Canad
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
Cetappareil numériquede laclasseArespecte toutes lesexigencesduRèglementsur lematériel brouilleur du
Canada.

v
Table of Contents
Electrical Safety and Emission Compliance Statement ......................iii
AT-RPS8000 Redundant Power Supply .................................................... 1
Verifying the Package Contents ........................................................................ 2
Reviewing Safety Precautions ........................................................................... 3
Installing the AT-RPS8000 Unit ....................................................................... 4
Installing Additional AT-PWR8000 Modules.................................................... 6
R.P.S. Output Connector Specifications............................................................ 8
Appendix A
Translated Electrical Safety and Emissions Information ....................9
Appendix B
AT-RPS8000 Quick Install Guide Feedback .......................................... 21
Appendix C
Technical Support Fax Order ................................................................... 23
Incident Summary............................................................................................ 23
Appendix D
Where To Find Us ......................................................................................... 25

1
The AT-RPS8000 unit is designed to provide redundant power for the AT-8300
Series Ethernet switches. The redundant power supply shares the load of
poweringthe switch withthestandard power supply in the Ethernet switch. If
one power supply fails, the remaining unit supplies all power to the switch,
thereby preventing a system failure.
The AT-RPS8000 unit comes with one pre-installed power module
(AT-PWR8000) that can supply power to one Ethernet switch. The unit has
three expansion slots that can accommodate up to three additional power
modules. Each module supports one switch.
Features of the AT-RPS8000 unit include:
"Redundant power for AT-8300 Series switches
"A small 1.5U high, 19-inch rackmountable enclosure
"One pre-installed AT-PWR8000 module
"Three expansion slots for up to three additional AT-PWR8000
modules
"Load-sharing with no interruption of service if a power supply fails.
Figure 1 shows the front view of the AT-RPS8000 unit with one pre-installed
AT-PWR8000 module.
Figure 1 Front View of the AT-RPS8000 Unit
AT-RPS8000 Redundant Power Supply

2
Verifying the Package Contents
Make sure the following items are included in the AT-RPS8000 package. If any
of these items are missing or damaged, contact your Allied Telesyn
representative. Refer to Appendix D for Allied Telesyn locations.
"One AT-RPS8000 unit with one pre-installed AT-PWR8000 module
"Two mounting brackets
"Six flathead Phillips screws
"One AC power cord (Americas, EC, and UK only)
"One 18-inch DC power cord
"This Quick Install Guide
"Warranty card

AT-RPS8000 Quick Install Guide
3
Reviewing Safety Precautions
Please review the following safety precautionsbefore you begin the installation
procedure.
Caution
Electric Shock Hazard: To prevent ELECTRIC shock, do not remove
cover. No user-serviceable parts inside. This unit contains HAZARDOUS
VOLTAGES and should only be opened by a trained and qualified
technician. To avoid the possibility of ELECTRIC SHOCK disconnect
electric power to the product before connecting or disconnecting the LAN
cables. !5
Lightning Danger: DO NOT WORK on equipment or CABLES during
periods of LIGHTNING ACTIVITY. !6
CAUTION: POWER CORD IS USED AS A DISCONNECTION DEVICE.
TO DE-ENERGIZE EQUIPMENT, disconnect the power cord. !7
Electrical—Type Class 1 Equipment
This Equipment Must Be Earthed. Power plug must be connected to a
properly wired earth ground socket outlet. An improperly wired socket
outlet could place hazardous voltages on accessible metal parts. !8
Electrical—Cord Notice: Use power cord, maximum 4.5 meters long,
rated minimum 10 amp, 250V, made of HAR cordage molded IEC 320
connector on one end and on the other end a plug approved by the country
of end use. !9
Pluggable Equipment: The socket outlet shall be installed near the
equipment and shall be easily accessible. !10
Air vents must not be blocked and must have free access to the room
ambient air for cooling. !11
Operating Temperature: This product is designed for a maximum
ambient temperature of 40°C. !12
All Countries: Install product in accordance with local and National
Electrical Codes. !13

4
Installing the AT-RPS8000 Unit
This section contains the procedure for installing the AT-RPS8000 unit. You
can install the unit on a table or in a standard 19-inch rack. This procedure
does notrequirethatyouturnOFFthepowertotheEthernetswitchestowhich
you will be connecting the redundant power supply. To install the unit, follow
these steps:
1. Remove the AT-RPS8000 for the shipping package and store the
packing material in a safe place.
2. Place the unit on a secure, flat surface with the front facing you.
3. If you are installing the unit in a rack, perform the following:
a. Remove the snap-on plastic feet from the bottom of the unit, as
shown in Figure 2.
Figure 2 Removing the Rubber Feet
b. Attach the rackmounting brackets to each side of the unit using
the six flathead screws (provided) as shown in Figure 3.
Figure 3 Attaching the Rackmounting Brackets
c. Mount the unit in the rack using standard screws (not provided).

AT-RPS8000 Quick Install Guide
5
Note
Ensure that air flow is unrestricted around the AT-RPS8000 unit.
4. Attach the provided DC powercord to the DCoutput connector on the
back panel of the AT-RPS8000 unit, directly behind the pre-installed
AT-PWR8000. (Refer to Figure 4 for the DC output connector.)
Figure 4 Back Panel of the AT-RPS8000 Unit
5. Connect the other end of the DC power cord to the R.P.S. Input
connector on the back panel of theEthernet switch. (Refer to Figure 5
for the R.P.S. Input connector.)
Figure 5 Back Panel of the Ethernet Switch
6. Plug the AC power cord for the AT-RPS8000 into the AC connector on
the back panel of the unit. (Refer to Figure 4 for the AC connector.)
Note
The AT-RPS8000 unit and Ethernet switches should be connected to
power outletson separate circuits. This will protect the switches from
a loss of power should a power circuit fail.
7. Plug the other end of the AC power cord into a wall outlet.
ON/OFF
DC Power Output Connector
AC Power Connector
Switch
R.P.S. Input Connector for the DC Power Cord

6
8. Turn on the AT-RPS8000 using the switch on the back panel of the
unit. (Refer to Figure 4 for the ON/OFF switch.)
9. Make sure the LED on the front of the AT-PWR8000 module is solid
green.
10. Make sure the RPS LED on the front of the Ethernet switch is solid
green to indicate a good connection to the AT-PWR8000 module.
Installing Additional AT-PWR8000 Modules
The AT-RPS8000 can supply redundant power for up to four Ethernet
switches. Initially, itcontains onepre-installedAT-PWR8000 module. You
can purchase additional power modules from your Allied Telesyn
representative. Each additional AT-PWR8000 module comes with a DC
power cord.
To install additional AT-PWR8000 modules, perform the following steps.
Note
It is not necessary to power OFF the AT-RPS8000 unit or the
connected Ethernet switches to install a new AT-PWR8000 module.
1. Remove the AT-PWR8000 module from the shipping package and
store the packing material in a safe place.
2. Remove the blank faceplate from an empty expansion slot from the
front of the AT-RPS8000 unit by unscrewing the two captive screws
with a Phillips screwdriver.
3. Attach one end of the provided DC power cord to the connector on the
back panel of the AT-RPS8000 unit, directly behind the faceplate you
just removed. (Refer to Figure 6 for the DC connectors.)
Figure 6 DC Connector Locations
DC Power Connectors

AT-RPS8000 Quick Install Guide
7
4. Attach the other end of the DC power cord to the R.P.S. Input
connector on the back panel of theEthernet switch. (Refer to Figure 5
for the R.P.S. Input connector.)
5. Slide the new AT-PWR8000 module into the AT-RPS8000 unit. Use
the handle, shown in Figure 7, to guide the module into the unit.
Figure 7 Installing an Additional AT-PWR8000 Module
6. Once firmlyinstalled, usea Phillips screwdriverto tightenthe captive
screws on the module to secure it to the AT-RPS8000 unit.
7. Make sure the LED on the front of the AT-PWR8000 module is solid
green.
8. Make sure the RPS LED on the front of the Ethernet switch is solid
green to indicate a good connection to the AT-PWR8000 module.
Handle
Captive Screws

8
R.P.S. Output Connector Specifications
Table 1 showsthe pin assignmentsfor the R.P.S. Output connectors located on
the back panel of the AT-RPS8000 unit.
Table 1 R.P.S. Output Connector Pin Assignments
Table 2showsthepinnumberingforthe R.P.S.Outputconnector.Pinnumbers
1through 8 are the bottom row on theconnector with pin 1 inthe bottom right
corner. Pin numbers 9 through 16 are the top row with pin 9 in the top right
position on the connector.
Table 2 AT-RPS8000 Output Pin Layout
Pin Number Function
1+12Vdc
2 Remote Sense (RS)+5V dc
3RSGround
4 RS +3.3V dc
5 Redundant Power Supply (RPS) present
6 Ground (+3.3V dc Return)
7 Ground (+5V dc Return)
8+5Vdc
9 Ground (+12V dc Return)
10 +3.3V dc
11 Ground (+3.3 dc Return)
12 +3.3V dc
13 Ground (+3.3V dc Return)
14 +3.3V dc
15 +5V dc
16 Ground (+5V dc Return)
16 15 14 13 12 11 10 9
87654321

9
Appendix A
Translated Electrical Safety and Emissions
Information
Standards: This product meets the following standards:
!1RFI Emission EN55022 Class A
!2WARNING: In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
!3Immunity EN50082-1 1997
!4Electrical Safety EN60950, UL1950, CSA 950
SAFETY
!5ELECTRICAL NOTICES
WARNING: ELECTRIC SHOCK HAZAR
To prevent ELECTRIC shock , do not remove the cover. No user-serviceable parts inside.
This unit contains HAZARDOUS VOLTAGES and should only be opened by a trained and
qualified technician. To avoid the possibility of ELECTRIC SHOCK, disconnect electric
power to the product before connecting or disconnecting the LAN cables.
!6LIGHTNING DANGER
DANGER: DO NOT WORK on equipment or CABLES during periods of LIGHTNING
ACTIVITY.
!7CAUTION: POWER CORD IS USED AS A DISCONNECTION DEVICE. TO DE-
ENERGIZE EQUIPMENT, disconnect the power cord.
!8ELECTRICAL - TYPE CLASS 1 EQUIPMENT
THIS EQUIPMENT MUST BE EARTHED. Power plug must be connected to a properly
wired earth ground socket outlet. An improperly wired socket outlet could place hazardous
voltages on accessible metal parts.
U.S. Federal Communications Commission
RADIATED ENERGY
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with this instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Note: Modifications or changes not expressly approved of by the manufacturer or the
FCC, can void your right to operate this equipment.
Industry Canada
This Class A digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le
matériel brouilleur du Canada.

10
!9ELECTRICAL - CORD NOTICE
Use power cord, maximum 4.5 meters long, rated 10 amp minimum, 250V, made of <HAR>
cordage molded IEC 320 connector on one end and on the other end a plug approved by the
country of end use.
!10 PLUGGABLE EQUIPMENT, the socket outlet shall be installed near the equipment and
shall be easily accessible.
!11 CAUTION: Air vents must not be blocked and must have free access to the room ambient
air for cooling.
!12 OPERATING TEMPERATURE: This product is designed for a maximum ambient
temperature of 40° degrees C.
!13 ALL COUNTRIES: Install product in accordance with local and National Electrical Codes.
Normen: Dieses Produkt erfüllt die Anforderungen der nachfolgenden Normen.
!1Hochfrequenzstörung EN55022 Klasse A
!2WARNUNG: Bei Verwendung zu Hause kann dieses Produkt Funkstörungen hervorrufen.
In diesem Fall müßte der Anwender angemessene Gegenmaßnahmen ergreifen.
!3Störsicherheit EN50082-1 1997
!4Elektrische Sicherheit EN60950, UL1950, CSA 950
SICHERHEIT
!5ACHTUNG: GEFÄHRLICHE SPANNUNG
DasGehäusenicht öffnen. DasGerät enthältkeine vom Benutzer wartbarenTeile. Das Gerät
stehtunterHochspannungunddarfnurvonqualifiziertemtechnischemPersonalgeöffnetwerden.
Vor Anschluß der LAN-Kabel, Gerät vom Netz trennen.
!6GEFAHR DURCH BLITZSCHLAG
GEFAHR: Keine Arbeiten am Gerät oder an den Kabeln während eines Gewitters
ausführen.
!7VORSICHT: DAS NETZKABEL DIENT ZUM TRENNEN DER STROMVERSORGUNG.
ZUR TRENNUNG VOM NETZ, KABEL AUS DER STECKDOSE ZIEHEN.
!8GERÄTE DER KLASSE 1
DIESE GERÄTE MÜSSEN GEERDET SEIN. Der Netzstecker darf nur mit einer
vorschriftsmäßig geerdeten Steckdose verbunden werden. Ein unvorschriftsmäßiger
Anschluß kann die Metallteile des Gehauses unter gefährliche elektrische Spannungen
setzen.
!9NETZKABEL
Das Netzkabel sollte eine maximale Länge von 4,5 Metern, einen Nennwert von mindestens
10 A und 250 V haben, aus HAR-Material hergestellt und mit einer gepreßten, IEC320
entsprechenden, Anschlußverbindung an einem Ende, und am anderen Ende mit einem im
Land des Endverbrauchers geprüften Stecker ausgestattet sein.
!10 STECKBARES GERÄT: Die Anschlußbuchse sollte in der Nähe der Einrichtung angebracht
werden und leicht zugänglich sein."
!11 VORSICHT
Die Entlüftungsöffnungen dürfen nicht versperrt sein und müssen zum Kühlen freien
Zugang zur Raumluft haben.
!12 BETRIEBSTEMPERATUR: Dieses Produkt wurde für den Betrieb in einer
Umgebungstemperatur von nicht mehr als 40° C entworfen.
!13 ALLE LÄNDER: Installation muß örtlichen und nationalen elektrischen Vorschriften
entsprechen.

11
AT-RPS8000 Quick Install Guide
Standarder: Dette produkt tilfredsstiller de følgende standarder.
!1Radiofrekvens forstyrrelsesemission EN55022 Klasse A
!2ADVARSEL: I et hjemligt miljø kunne dette produkt forårsage radio forstyrrelse. Bliver
det tilfældet, påkræves brugeren muligvis at tage tilstrækkelige foranstaltninger.
!3Immunitet EN50082-1 1997
!4Elektrisk sikkerhed EN60950, UL1950, CSA 950
SIKKERHED
!5ELEKTRISKE FORHOLDSREGLER
ADVARSEL: RISIKO FOR ELEKTRISK STØD
For at forebygge ELEKTRISK stød, undlad at åbne apparatet. Der er ingen indre dele, der
kan repareres af brugeren. Denne enhed indeholder LIVSFARLIGE
STRØMSPÆNDINGER og bør kun åbnes af en uddannet og kvalificeret tekniker. For at
undgå risiko for ELEKTRISK STØD, afbrydes den elektriske strøm til produktet, før LAN-
kablerne monteres eller afmonteres.
!6FARE UNDER UVEJR
FARE: UNDLAD at arbejde på udstyr eller KABLER i perioder med LYNAKTIVITET.
!7ADVARSEL: DEN STRØMFØRENDE LEDNING BRUGES TIL AT AFBRYDE
STRØMMEN. SKAL STRØMMEN TIL APPARATET AFBRYDES, tages ledningen ud af
stikket.
!8ELEKTRISK - KLASSE 1-UDSTYR
DETTE UDSTYR KRÆVER JORDFORBINDELSE. Stikket skal være forbundet med en
korrekt installeret jordforbunden stikkontakt. En ukorrekt installeret stikkontakt kan
sætte livsfarlig spænding til tilgængelige metaldele.
!9ELEKTRISK - LEDNING
Anvend ledning af maksimum 4,5 meters længde, med en kapacitet på minimum 10 amp.,
250 v, bestående af en IEC 320 connector med indstøbt <HAR> ledning i den ene ende og et
stik i den anden ende, der er godkendt af myndighederne i brugerlandet.
!10 UDSTYR TIL STIKKONTAKT, stikkontakten bør installeres nær ved udstyret og skal være
lettilgængelig.
!11 ADVARSEL: Ventilationsåbninger må ikke blokeres og skal have fri adgang til den
omgivende luft i rummet for afkøling.
!12 BETJENINGSTEMPERATUR: Dette apparaterkonstrueret til en omgivende temperatur
på maksimum 40 grader C.
!13 ALLE LANDE: Installation af produktet skal ske i overensstemmelse med lokal og national
lovgivning for elektriske installationer.

12
Eisen: Dit product voldoet aan de volgende eisen.
!1RFI Emissie EN55022 Klasse A
!2WAARSCHUWING: Binnenshuis kan dit product radiostoring veroorzaken, in welk geval
de gebruiker verplicht kan worden om gepaste maatregelen te nemen.
!3Immuniteit EN50082-1 1997
!4Electrische Veiligheid EN60950, UL1950, CSA 950
VEILIGHEID
!5WAARSCHUWINGEN MET BETREKKING TOT ELEKTRICITEIT
WAARSCHUWING: GEVAAR VOOR ELEKTRISCHE SCHOKKEN
Verwijder het deksel niet, teneinde ELEKTRISCHE schokken te voorkomen. Binnenin
bevinden zich geen onderdelen die door de gebruiker onderhouden kunnen worden. Dit
toestel staat onder GEVAARLIJKE SPANNING en mag alleen worden geopend door een
daartoe opgeleide en bevoegde technicus. Om het gevaar op ELEKTRISCHE SCHOKKEN te
vermijden, moet u het toestel van de stroombron ontkoppelen alvorens de LAN-kabels te
koppelen of ontkoppelen.
!6GEVAAR VOOR BLIKSEMINSLAG
GEVAAR: NIET aan toestellen of KABELS WERKEN bij BLIKSEM.
!7WAARSCHUWING: HET TOESTEL WORDT UITGESCHAKELD DOOR DE
STROOMKABEL TE ONTKOPPELEN.OM HET TOESTEL STROOMLOOS TE MAKEN:
de stroomkabel ontkoppelen.
!8ELEKTRISCHE TOESTELLEN VAN KLASSE 1
DIT TOESTEL MOET GEAARD WORDEN. De stekker moet aangesloten zijn op een juist
geaarde contactdoos. Een onjuist geaarde contactdoos kan de metalen onderdelen waarmee
de gebruiker eventueel in aanraking komt onder gevaarlijke spanning stellen.
!9ELEKTRISCHE SNOEREN
Gebruik een elektrisch snoer, maximum 4,5 meter lang, berekend voor ten minste 10
ampåçère, 250 V, uit HAR vervaardigd, met aan het ene uiteinde een gevormd IEC 320
aansluitstuk en aan het andere uiteinde een stekker die goedgekeurd is door het land waar
het toestel gebruikt zal worden.
!10 AAN TE SLUITEN APPARATUUR, de contactdoos wordt in de nabijheid van de apparatuur
geïnstalleerd en is gemakkelijk te bereiken."
!11 OPGELET: De ventilatiegaten mogen niet worden gesperd en moeten de omgevingslucht
ongehinderd toelaten voor afkoeling.
!12 BEDRIJFSTEMPERATUUR: De omgevingstemperatuur voor dit produkt mag niet meer
bedragen dan 40 graden Celsius.
!13 ALLE LANDEN: het toestel installeren overeenkomstig de lokale en nationale elektrische
voorschriften.

13
AT-RPS8000 Quick Install Guide
Normes: ce produit est conforme aux normes de suivantes:
!1Emission d’interférences radioélectriques EN55022 Classe
!2MISE EN GARDE : dans un environnement domestique, ce produit peut provoquer des
interférences radioélectriques. Auquel cas, l’utilisateur devra prendre les mesures
adéquates.
!3Immunité EN50082 - 1 1997
!4Sécurité électrique EN60950, UL1950, CSA 950
SÉCURITÉ
!5INFORMATION SUR LES RISQUES ÉLECTRIQUES
AVERTISSEMENT: DANGER D’ÉLECTROCUTION
Pour éviter toute ÉLECTROCUTION, ne pas ôter le revêtement protecteur du matériel. Ce
matériel ne contient aucun élément réparable par l’utilisateur. Il comprend des TENSIONS
DANGEREUSES et ne doit être ouvert que par un technicien dûment qualifié. Pour éviter
tout risque d’ÉLECTROCUTION, débrancher le matériel avant de connecter ou de
déconnecter les câbles LAN.
!6DANGER DE FOUDRE
DANGER: NE PAS MANIER le matériel ou les CÂBLES lors d’activité orageuse.
!7ATTENTION: LE CORDON D’ALIMENTATION SERT DE MISE HORS CIRCUIT. POUR
COUPER L’ALIMENTATION DU MATÉRIEL, débrancher le cordon.
!8ÉQUIPEMENT DE CLASSE 1 ÉLECTRIQUE
CE MATÉRIEL DOIT ÊTRE MIS ALA TERRE. La prise de courant doit être branchée dans
une prise femelle correctement mise à la terre car des tensions dangereuses risqueraient
d’atteindre les pièces métalliques accessibles à l’utilisateur.
!9INFORMATION SUR LE CORDON ÉLECTRIQUE
Utiliser un cordon secteur de 4.5 mètres de long maximum, calibré à 10 ampères minimum,
250V, fabriqué en câblage <HAR> avec connecteur IEC 32C moulé à une extrémité, et à
l’autre extrémité, une prise de courant mâle répondant aux normes du pays d’utilisation.
!10 EQUIPEMENT POUR BRANCHEMENT ELECTRIQUE, la prise de sortie doit être placée
près de l’équipement et facilement accessible".
!11 ATTENTION: Ne pas bloquer les fentes d’aération, ceci empêcherait l’air ambiant de
circuler librement pour le refroidissement.
!12 TEMPÉRATURE DE FONCTIONNEMENT: Ce matériel est capable de tolérer une
température ambiante maximum de ou 40 degrés Celsius.
!13 POUR TOUS PAYS: Installer le matériel conformément aux normes électriques nationales
et locales.

14
Standardit: Tämä tuote on seuraavien standardien mukainen.
!1Radioaaltojen häirintä EN55022 Luokka A
!2VAROITUS:Kotiolosuhteissatämälaitevoi aiheuttaa radioaaltojen häiröitä,missätapauksessa
laitteen käyttäjän on mahdollisesti ryhdyttävä tarpeellisiin toimenpiteisiin.
!3Kestävyys EN500821-1 1997
!4Sähköturvallisuus EN60950, UL1950, CSA 950
TURVALLISUUS
!5SÄHKÖÖN LIITTYVIÄ HUOMAUTUKSIA
VAROITUS: SÄHKÖISKUVAARA
Estääksesi SÄHKÖISKUN älä poista kantta. Sisällä ei ole käyttäjän huollettavissa olevia
osia. Tämä laite sisältää VAARALLISIA JÄNNITTEITÄ ja sen voi avata vain koulutettu ja
pätevä teknikko. Välttääksesi SÄHKÖISKUN mahdollisuuden katkaise sähkövirta
tuotteeseen ennen kuin liität tai irrotat paikallisverkon (LAN) kaapelit.
!6SALAMANISKUVAARA
HENGENVAARA: ÄLÄ TYÖSKENTELE laitteiden tai KAAPELEIDEN KANSSA
SALAMOINNIN AIKANA.
!7HUOMAUTUS: VIRTAJOHTOA KÄYTETÄÄN VIRRANKATKAISULAITTEENA. VIRTA
KATKAISTAAN irrottamalla virtajohto.
!8SÄHKÖ - TYYPPILUOKAN 1 LAITTEET
TÄMÄ LAITE TÄYTYY MAADOITTAA. Pistoke täytyy liittää kunnollisesti maadoitettuun
pistorasiaan. Virheellisesti johdotettu pistorasia voi altistaa metalliosat vaarallisille
jännitteille.
!9SÄHKÖ - JOHTOON LIITTYVÄ HUOMAUTUS
Käytä seuraavanlaista virtajohtoa: maksimipituus 4,5 metriä, minimiteho 10 ampeeria,
250 V, valmistettu <HAR> -johdostosta, muovattu IEC 320 -liitin toisessa päässä ja
käyttömaassa hyväksytty pistoke toisessa päässä.
!10 PISTORASIAAN KYTKETTÄVÄ LAITE; pistorasia on asennettava laitteen lähelle ja siihen
on oltava esteetön pääsy."
!11 HUOMAUTUS: Ilmavaihtoreikiä ei pidä tukkia ja niillä täytyy olla vapaa yhteys
ympäröivään huoneilmaan, jotta ilmanvaihto tapahtuisi.
!12 KÄYTTÖLÄMPÖTILA: Tämä tuote on suunniteltu ympäröivän ilman
maksimilämpötilalle 40°C.
!13 KAIKKI MAAT: Asenna tuote paikallisten ja kansallisten sähköturvallisuusmääräysten
mukaisesti.
