Allied Telesis www.alliedtelesis.com
Datasheet | Switches
AT-8000S/48
Layer 2 Stackable Fast Ethernet Switch
A
T-8000S/48
48 port stackable 10/100TX Layer 2 switch
with 2 active SFP bays (unpopulated) and
2standby 10/100/1000T ports (RJ-45)
Overview
One of a series of stackable switches from
Allied Telesis, the AT-8000S/48 provides high
performance Layer 2 switching in an affordable
fixed configuration platform.This switch offers
48 10/100 ports, two fixed 1Gbps SFP slots
plus two integrated stacking connectors that
deliver a total of 4Gbps stacking bandwidth.The
stacking capability integrated into this platform
is configured as a resilient ring topology
designed to provide high reliability and
simplified management for higher port density
applications.
Ideal Branch Office and Wiring
Closet Connectivity
Powerful line rate performance and stackability
make this switch ideal for branch offices or the
wiring closet of larger offices. The state-of-the-
artQoS capability of this product ensures
reliable delivery of advanced network services
such as voice while effectively controlling the
continually increasing traffic needs found in
today’s networks.
Easy Access Networking
Featuring an industrystandard CLI and Allied
T
elesis’ intuitive yet fully featured Web interface
the advanced features of the AT-8000S/48 are
accessible to a wide range of system
administrators. The well known CLI and Web
interfaces significantly reduce learning time and
minimize the cost of deployment.
SecureManagement
Only authorized administrators can access the
management interface of the 8000S series.
Protocols such as SSL, SSH and SNMPv3
facilitate this protection of your network with
local or remote connections.
Securing the Network Edge
To ensure the protection of your data, it is
important to control access to your network.
Protocols such as IEEE 802.1x port-based
authentication guarantee that only known users
are connected to the network. Unknown users
who physicallyconnect can be isolated to a
pre-determined part of your network offering
guests such benefits as Internet access while
ensuring the integrity of your private network
data.
Gigabit and Fast Ethernet SFP
Support
All switches in the 8000S family support both
Gigabit and Fast Ethernet Small Form-factor
Pluggables (SFPs).This makes the 8000S series
an ideal family for environments where Gigabit
fiber switches will be phased in over time.The
8000S familyallows for connectivity to the
legacy 100FX hardware until it is upgraded to
Gigabit. Support for both speeds of SFPs allows
organizations to staywithin budget as they
migrate to faster technologies.
Key Features
Easy,Well Known Management
•Industry standard CLI
•Simple intuitive, full featured Allied Telesis
Web Interface
•Secure encrypted Web and CLI management
with SSHv2 and SSL
•SNMP
•Twolevel access privileges
Affordable Truly Stackable 10/100
Switching Platform
•Single IP address stack management
•4Gig resilient ring stacking architecture
•Across stack link aggregation
•Across stack VLAN configuration
•Across stack portmirroring
•Redundant standbystack master
All the QoS Needed in the
Wiring Closet
for Today’s Voice and Data Networking
•Eight priorities assigned to four queues
•IEEE 802.1p for Layer 2 QoS
•DSCP (DiffServ) for Layer 3 QoS
•IEEE 802.1p to DSCP remarking traffic ready for
transport to the Layer 3 core of the network
•Layer 2 and Layer 3 ACL
Securing the Network at its Most
Vulnerable Point
•IEEE 802.1x and RADIUS network login: for
advanced control of user authentication and
accountability
•Guest VLAN: to ensure visitors or unauthorized
users connect only to services defined by IT e.g.
Internet
•TACACS+: for ease of management security
administration
•Layer 2 and Layer 3 ACL
•PortMACaddress security options

Allied T
elesis www.alliedtelesis.com
AT-8000S/48 |Layer 2 Stackable Fast Ethernet Switch
System Configuration
Dimensions 44cm x 25.7cm x 4.32cm
(W x D x H) (17.32” x 10.11” x 1.7”)
Weight 3.38kg (7.45lb)
Mounting 19” rack-mountable hardware
included
System Capacity
64MB RAM
16MB flash memory
400Mhz CPU
Up to 4,096 VLAN ID
8,000 MAC address
Performance
Wirespeed switching on all Ethernet ports for all packet
sizes
Throughput 13.09Mpps
Switching capacity 17.6Gbps
MTBF 314,322 hours
Store and forward mode
Non-blocking switch fabric
Auto MDI/MDI-X
Port speed
10/100TX RJ-45
10/100/1000T RJ-45
100FX, 1000SX, 1000LX SFP slot
RS232 DB9 pin, male port
Internal power supply and fan
Interface Standards
IEEE 802.3 10T and 10FL
IEEE 802.3u 100TX and 100FX
IEEE 802.3z 1000SX
IEEE 802.3ab 1000T
General Standards
IEEE 802.1D Bridging
IEEE 802.3x BackPressure/ flow control
Redundancy Standards
IEEE 802.1D Spanning-Tree Protocol
IEEE 802.1W Rapid Spanning-Tree
IEEE 802.1s Multiple Spanning-Tree
IEEE 802.3ad LACP link aggregation
(with up to eight members per
group and up to eight groups per
device)
Static porttrunk
Quality of Services (QoS)
QoS in Layer 2 (IEEE 802.1p compliant Class of
Service)
Traffic prioritization using IEEE 802.1p, ToS, DSCP fields
Map IEEE 802.1p priorities to CoS queues to prioritize
traffic at egress
Strict Scheduling and Weighted Round Robin
VLANs
IEEE 802.1Q VLAN tagging
Up to 256 VLANs
Port-based VLANs
MAC-based VLANs
Private VLANs
GARP VLAN Registration Protocol (GVRP)
Multicast Standards
RFC 1112 IGMP snooping (ver. 1)
RFC 2236 IGMP snooping (ver. 2)
RFC 3376 IGMP snooping (ver. 3)*
RFC 3376 IGMP querier
*Future release
Management and Monitoring
WEB, CLI, Serial
RFC 1157 SNMPv1/v2c
RFC 2570 SNMPv3
RFC 1213 MIB-II
RFC 1573 Evolution of MIB-II
RFC 1215 TRAP MIB
RFC 1493 Bridge MIB
RFC 2863 Interfaces group MIB
RFC 1643 Ethernet like MIB
RFC 1757 RMON 4 groups:
Stats, History, Alarms, Events
RFC 2674 IEEE 802.1Q MIB
RFC 1866 HTML
RFC 2068 HTTP
RFC 854 Telnet
RFC 783 TFTP
IP address allocation
RFC 951/ RFC 1542 BootP/ DHCP
Manual
RFC 2030 SNTP, Simple Network Time Protocol
Syslog event
Dual software images
Stacking
Up to six units
Single system appearance
Single IP management
Backup master
Full-duplexlink with 2Gbps performance
Link aggregation/trunking across stack
Portmirroring across stack
VLAN across stack
Security
Management security: username and password protection
SSHv2 for Telnet management
SSLv3 for Web management
RFC 1492 TACACS+
RFC 2138 RADIUS Authentication
IEEE 802.1x Port-based network access control
Guest VLANs
RFC 2865 IEEE 802.1x port-based network
access control
MAC-based network access control
ACL - Access Control Lists
Fault Protection
Broadcast storm control

USA Headquarters |19800 North Creek Parkway |Suite 100 |Bothell |WA 98011 |USA |T: [phone] |F: [phone]
European Headquarters |Via Motta 24 |6830 Chiasso |Switzerland |T: +41 91 69769.00 |F: +41 91 69769.11
Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: [phone] |F: [phone]
www.alliedtelesis.com
©2008 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000176 Rev. H
AT-8000S/48 |Layer 2 Stackable Fast Ethernet Switch
Power Characteristics
Voltage input 100- 240V AC
Voltage output 12vDC
Current 1.5A
Power consumption 54W
Heat dissipation 184.41 BTU/hour
Clock Frequency 166MHz
Environmental Specifications
Operating temp 0°C to 45°C (32°F to 113°F)
Storage temp -25°C to 70°C (-13°F to 158°F)
Relative humidity 10% to 90% non-condensing
Storage humidity 5% to 95% non-condensing
Operating altitude Maximum 3,000m (9,843ft)
Electrical/ Mechanical Approvals
Safety UL 1950 (UL/cUL), EN60950 (TUV)
EMI FCC Class A, EN55022 Class A,
VCCI Class A, C-Tick, EN61000-3-2,
EN61000-3-3
Immunity EN55024
RoHS compliant
Package Description
One AT-8000S/48 switch
Power cord AC
Rack-mount kit
Rubber feet for desktop installation
RS232 management cable
Stacking cable
Install guide and user guide in CD
Country of Origin
China
Ordering Information
AT-8000S/48-xx
48port stackable 10/100TX Layer 2 switch with
2active SFP bays (unpopulated) and 2 standby
10/100/1000T ports (RJ-45)
Where xx = 10 for US power cord
20 for no power cord
30 for UK power cord
40 for Australian power cord
50 for European power cord
Accessories
Small Form Pluggables (SFPs)
AT-SPFX/2
Multi-mode Fiber, 2km, 100FX, SFP, 1310nm
AT-SPFX/15
Single-mode Fiber, 15km, 100FX, SFP, 1310nm
AT-SPFX/40
Single-mode Fiber, 40km, 100FX, SFP, 1310nm
AT-SPTX
Copper, GbE Small Form-factor Pluggable (SFP)
AT-SPSX
Multi-mode Fiber, GbE Small Form-factor Pluggable (SFP)
850nm
AT-SPLX10
Single-mode Fiber, 10km, GbE SFP, 1310nm
AT-SPLX40
Single-mode Fiber, 40km, GbE SFP, 1310nm
AT-SPLX40/1550
Single-mode Fiber, 40km, GbE SFP, 1550nm
AT
-SPZX80
Single-mode Fiber, 80km, GbE SFP, 1550nm
AT-SPZX80/xxxx
Single-mode Fiber, CWDM, 80km GbE SFP
CWDM wavelengths:
Where xxxx = 1470
1490
1510
1530
1550
1570
1590
1610
