Allied Telesis AT-IFS802SP User manual

613-001690 Rev.A
AT-IFS802SP
8x10/100TX POE Layer 2 Managed Industrial Switch
AT-IFS802SP Installation and
User’s Guide

Copyright ©2012 Allied Telesis, Inc.
All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesis, Inc.
Allied Telesis and the Allied Telesis logo are trademarks of Allied Telesis, Incorporated. All other product names, company names,
logos or other designations mentioned herein are trademarks or registered trademarks of their respective owners.
Allied Telesis, Inc. reserves the right to make changes in specifications and other information contained in this document without prior
written notice. The information provided herein is subject to change without notice. In no event shall Allied Telesis, Inc. be liable for
any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related
to this manual or the information contained herein, even if Allied Telesis, Inc. has been advised of, known, or should have known, the
possibility of such damages.

3
Electrical Safety and Emissions Standards
This product meets the following standards.
RFI Emissions FCC Class A, CE EN61000-4-2, CE EN61000-4-3, CE EN-61000-4-4, CE
EN61000-4-5, CE EN61000-4-6, CE EN61000-4-8, CE EN61000-4-11, CE
EN61000-4-12, CE EN61000-6-2, CE EN61000-6-4
Electrical Safety UL, cUL, CE/EN60950-1
Stability Testing IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock),
IEC60068-2-6 (Vibration)
U.S. Federal Communications Commission
Radiated Energy
Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15
of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with this instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
Note: Modifications or changes not expressly approved of by the manufacturer or the FCC, can void your right to operate
this equipment.
Industry Canada
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
Warning: In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.

4

5
Preface
This manual is the installation and management guide for the
AT-IFS802SP 8x10/100TX POE Layer 2 Managed Industrial Switch. The
instructions in this guide explain how to install the switch, start a
management session, and use the CLI and web management interfaces.
Allied Telesis Contact Information
If you need assistance with this product, you may contact Allied Telesis
technical support by going to the Support & Services section of the Allied
Telesis web site at www.alliedtelesis.com/support. You can find links for
the following services on this page:
❒24/7 Online Support - Enter our interactive support
center to search for answers to your questions in our
knowledge database, check support tickets, learn
about RMAs, and contact Allied Telesis technical
experts.
❒USA and EMEA phone support - Select the phone
number that best fits your location and customer type.
❒Hardware warranty information - Learn about Allied
Telesis warranties and register your product online.
❒Replacement Services - Submit a Return Merchandise
Authorization (RMA) request via our interactive support
center.
❒Documentation - View the most recent installation
guides, user guides, software release notes, white
papers and data sheets for your product.
❒Software Updates - Download the latest software
releases for your product.
For sales or corporate contact information, go to
www.alliedtelesis.com/purchase and select your region.

Preface
6

3AT-IFS802SP-80 User Manual
Content
Chapter 1 Introduction......................................................................... 6
1.1 Hardware Features ....................................................................................................................6
1.2 Software Features.......................................................................................................................8
1.3 Package Contents.......................................................................................................................9
Chapter 2 Hardware Description........................................................ 10
2.1 Physical Dimension.....................................................................................................................10
2.2 Front Panel...................................................................................................................................10
2.3 Top View........................................................................................................................................11
2.4 LED Indicators ............................................................................................................................12
Chapter 3 Hardware Installation......................................................... 13
3.1 Installation Steps......................................................................................................................... 13
3.2 DIN-Rail Mounting.....................................................................................................................14
3.3 Wall Mount Plate Mounting......................................................................................................15
3.4 Wiring the Power Inputs...........................................................................................................16
3.5 Wiring the Fault Alarm Contact..............................................................................................17
3.6 Cabling ..........................................................................................................................................18
Chapter 4 Network Application .......................................................... 20
4.1 X-Ring Application......................................................................................................................20
4.2 Coupling Ring Application ........................................................................................................21
4.3 Dual Homing Application..........................................................................................................22
Chapter 5 Console Management......................................................... 23
5.1 Connecting to the Console Port............................................................................................23
5.2 Pin Assignment ............................................................................................................................23
5.3 Login in the Console Interface ...............................................................................................24
5.4 CLI Management......................................................................................................................... 24
5.5 Commands Level........................................................................................................................ 25
Chapter 6 Web-Based Management ................................................... 26
6.1 About Web-based Management...............................................................................................26
6.2 Preparing for Web Management..............................................................................................26
6.3 System Login................................................................................................................................26
6.4 System Information.................................................................................................................... 27
6.5IPConguration..........................................................................................................................28
6.6 DHCP Server ..............................................................................................................................29
6.6.1Systemconguration .........................................................................................................29
6.6.2 Client Entries.......................................................................................................................30
6.6.3 Port and IP Bindings...........................................................................................................30
6.7 TFTP ..............................................................................................................................................31
6.7.1 Update Firmware................................................................................................................31
6.7.2RestoreConguration.......................................................................................................31
6.7.3BackupConguration........................................................................................................32
6.8 System Event Log .......................................................................................................................32
6.8.1SyslogConguration..........................................................................................................32
6.8.2SystemEventLog—SMTPConguration .....................................................................33
6.8.3SystemEventLog-EventConguration.......................................................................34

4 AT-IFS802SP-80 User Manual
6.9 Fault Relay Alarm........................................................................................................................36
6.10SNTPConguration................................................................................................................36
6.11 IP Security..................................................................................................................................39
6.12 User Authentication..................................................................................................................40
6.13 Port Statistics ............................................................................................................................ 40
6.14 Port Control .............................................................................................................................41
6.15 Port Trunk ..................................................................................................................................42
6.15.1 Aggregator setting ............................................................................................................42
6.15.2 Aggregator Information...................................................................................................44
6.15.3 State Activity......................................................................................................................47
6.16 Port Mirroring...........................................................................................................................48
6.17 Rate Limiting .............................................................................................................................49
6.18VLANconguration.................................................................................................................50
6.18.1 Port-based VLAN .............................................................................................................50
6.18.2 802.1Q VLAN.................................................................................................................... 52
802.1QConguration .......................................................................................................53
6.19 Rapid Spanning Tree.................................................................................................................55
6.19.1RSTPSystemConguration...........................................................................................55
6.19.2PortConguration...........................................................................................................56
6.20SNMPConguration ...............................................................................................................57
6.20.1SystemConguration......................................................................................................57
6.20.2TrapConguration ...........................................................................................................58
6.20.3SNMPV3Conguration ..................................................................................................59
6.21QoSConguration ..................................................................................................................60
6.21.1 QoS Policy and Priority Type.........................................................................................60
6.21.2 Port-based Priority ..........................................................................................................61
6.22IGMPConguration ................................................................................................................62
6.21.3COSConguration..........................................................................................................62
6.21.4TOSConguration ...........................................................................................................62
6.23 X-Ring.........................................................................................................................................63
6.24LLDPConguration.................................................................................................................65
6.25Security—802.1X/RadiusConguration.............................................................................65
6.25.1SystemConguration......................................................................................................65
6.25.2PortConguration...........................................................................................................66
6.25.3MiscConguration...........................................................................................................67
6.26 MAC Address Table..................................................................................................................67
6.26.1 Static MAC Address.........................................................................................................67
6.26.2 MAC Filtering....................................................................................................................68
6.26.3 All MAC Addresses ..........................................................................................................69
6.26.4 MAC Address Table—Multicast Filtering.....................................................................69
6.27 Factory Default.........................................................................................................................71
6.28SaveConguration...................................................................................................................71
6.29 System Reboot ........................................................................................................................71
Troubles shooting................................................................................... 72
Appendix A—RJ-45 Pin Assignment ..................................................... 73
Appendix B—Command Sets............................................................... 76
System Commands Set......................................................................................................................76
Port Commands Set ..........................................................................................................................78
Trunk Commands Set........................................................................................................................80

5AT-IFS802SP-80 User Manual
VLAN Commands Set.......................................................................................................................81
Spanning Tree Commands Set .........................................................................................................83
Commands Set...................................................................................................................................85
SystemLog, SMTP and Event Commands Set...............................................................................94
SNTP Commands Set........................................................................................................................96
X-ring Commands Set.......................................................................................................................97

6 AT-IFS802SP-80 User Manual
Chapter 1 Introduction
The 8 10/100TX + 2 10/100/1000T/SFP Combo with X-Ring L2 Managed Industrial Switch is a cost-effective
solution and meets the high reliability requirements demanded by industrial applications.The 8 10/100TX +
2 10/100/1000T/SFP Combo with X-Ring L2 Managed Industrial Switch can be easily managed through the
WebGUI.Usingberportcanextendtheconnectiondistancethatincreasesthenetworkelasticityand
performance. It also provides the X-Ring function that can prevent the network connection failure.
1.1 Hardware Features
Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX
IEEE802.3ab 1000Base-T
IEEE802.3zGigabitber
IEEE802.3x Flow Control and Back Pressure
IEEE802.3ad Port trunk with LACP
IEEE802.1d Spanning Tree/ IEEE802.1w Rapid Spanning Tree
IEEE802.1p Class of Service
IEEE802.1Q VLAN Tag
IEEE 802.1x User Authentication (Radius)
IEEE802.1ab LLDP
Switch
Architecture
Back-plane (Switching Fabric): 5.6Gbps
Packet throughput ability(Full-Duplex): 8.3Mpps @64bytes
Transfer Rate
14,880pps for Ethernet port
148,800pps for Fast Ethernet port
1,488,000pps for Gigabit Fiber Ethernet port
Packet Buffer 1Mbits
MAC Address 8K MAC address table
Flash ROM 4Mbytes
DRAM 32Mbytes
Connector
10/100TX: 8 x RJ-45
10/100/1000T/ SFP Combo: 2 x RJ-45 + 2 x
100/1000 SFP sockets
RS-232 connector: RJ-45 type

7AT-IFS802SP-80 User Manual
Network Cable
10Base-T: 2-pair UTP/STP Cat. 3, 4, 5/ 5E cable
EIA/TIA-568 100-ohm (100m)
100Base-TX: 2-pair UTP/STP Cat. 5/ 5E cable
EIA/TIA-568 100-ohm (100m)
1000Base-TX: 2-pair UTP/STP Cat. 5/ 5E cable
EIA/TIA-568 100-ohm (100m)
Optical Fiber
Multi-mode: 50/125um~62.5/125um
Single mode: 9/125um
Available distance: 2km (Multi-mode)/30km (Single-mode)
Wavelength: 1310nm (Multi-mode/Single -mode)
Protocol CSMA/CD
LED
Per unit: Power (Green), Power 1 (Green), Power 2 (Green), Fault (Red), Master (Green)
8 10/100TX : Link/Activity (Green), Full duplex/Collision (Amber)
Gigabit Copper: Link/Activity (Green), Speed (1000Mbps Green)
SFP: Link/Activity (Green)
Power Supply DC 12 ~ 48V (Source Input should be lower than 240W), Redundant power with
polarity reverse protect function and removable terminal block
Power 8.064Watts
Consumption
Operating
Humidity 5% to 95% (Non-condensing)
Operating
Temperature
Standard: -10oC ~ 60oC
Wide Operating Temperature: -40oC ~ 75oC
Storage
Temperature -40oC ~ 85oC
Case Dimension IP-30, 72mm (W) x 105mm (D) x 152mm (H)
Fan Number 0
Installation DIN rail and wall mount ear
EMI
FCC Class A, CE EN61000-4-2 (ESD), CE EN61000-4-3 (RS), CE EN-61000-4-4
(EFT),
CE EN61000-4-5 (Surge), CE EN61000-4-6 (CS), CE EN61000-4-8, CE EN61000-
4-11,
CE EN61000-4-12, CE EN61000-6-2, CE EN61000-6-4
Safety UL, cUL, CE/EN60950-1
Stability Testing IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock), IEC60068-2-6 (Vibration)

8 AT-IFS802SP-80 User Manual
1.2 Software Features
Management SNMP v1 v2c, v3/ Web/Telnet/CLI/NS-View
SNMP MIB RFC 1215 Trap, RFC1213 MIBII, RFC 1157 SNMP MIB, RFC 1493 Bridge MIB,
RFC 2674 VLAN MIB, RFC 1643 , RFC 1757, RSTP MIB, Private MIB, LLDP MIB
VLAN
Port Based VLAN
IEEE 802.1Q Tag VLAN (256 entries)/ VLAN ID (Up to 4K,VLAN ID can be
assigned from 1 to 4096.)
GVRP (256 Groups)
Port Trunk with
LACP LACP Port Trunk: 4 Trunk groups/Maximum 4 trunk members
LLDP SupportsLLDPallowingswitchtoadvertiseitsidenticationandcapabilityon
the LAN
Spanning tree IEEE802.1d spanning tree
IEEE802.1w rapid spanning tree.
X-Ring Supports X-ring, Dual Homing and Couple Ring Topology Provides redundant
backup feature and the recovery time below 20ms
Class of Service Supports IEEE802.1p class of service, per port provides 4 priority queues
Port Security Supports 100 entries of MAC address for static MAC and another 100 for MAC
lter
Port Mirror Supports 3 mirroring types:“RX,TX and Both packet”.
IGMP Supports IGMP snooping v1,v2, 256 multicast groups and IGMP query
IP Security Supports 10 IP addresses that have permission to access the switch management
and to prevent unauthorized intruder.
Login Security Supports IEEE802.1X Authentication/RADIUS
Bandwidth
Control
Supportsingresspacketlterandegresspacketlimit
The egress rate control supports all of packet type and the limit rates are
100K~250Mbps
IngresslterpackettypecombinationrulesareBroadcast/Multicast/Unknown
Unicast packet, Broadcast/Multicast packet, Broadcast packet only and all of
packet.Thepacketlterratecanbesetfrom100kto250Mbps
Flow Control Supports Flow Control for Full-duplex and Back Pressure for Half-duplex
System Log Supports System log record and remote system log server
SMTP Supports SMTP Server and 6 e-mail accounts for receiving event alert

9AT-IFS802SP-80 User Manual
Relay Alarm
Provides one relay output for port breakdown, power fail
Alarm Relay current carry ability: 1A @ DC24V
SNMP Trap
Up to 3 Trap stations
Cold start, Port link up, Port link down,Authentication Failure, Private Trap for
powerstatus,PortAlarmconguration,Faultalarm,X-Ringtopologychange
DHCP Provides DHCP Client/ DHCP Server functions
DNS Provides DNS client feature and supports Primary and Secondary DNS server
SNTP Supports SNTP to synchronize system clock in Internet
Firmware Update SupportsTFTPrmwareupdate,TFTPbackupandrestore.
Conguration
Upload/
Download
Supportsbinaryformatleforcongurationbackupandrestore
ifAlias Each port allows importing 128bits of alphabetic string of word on SNMP and
CLI interface
1.3 Package Contents
Please refer to the package content list below to verify them against the checklist.
8 10/100TX + 2 10/100/1000T/SFP Combo with X-Ring L2 Managed Industrial Switch x 1•
Pluggable Terminal Block x 1•
Mounting plate x 2•
RJ-45 to DB9-Female cable x 1•
Compare the contents of the industrial switch with the standard checklist above.If any item is damaged
or missing, please contact the local dealer for service.

10 AT-IFS802SP-80 User Manual
Chapter 2 Hardware Description
In this paragraph, it will describe the Industrial switch’s hardware spec, port, cabling information, and wiring
installation.
2.1 Physical Dimension
8 10/100TX + 2 10/100/1000T/SFP Combo with X-Ring L2 Managed Industrial Switch dimension (W
x D x H) are 72mm x 105mm x 152mm.
2.2 Front Panel
The Front Panel of the 8 10/100TX + 2 10/100/1000T/SFP Combo with X-Ring L2 Managed Industrial
Switch is shown as below:
Front Panel of the industrial switch

11AT-IFS802SP-80 User Manual
2.3 Top View
The top panel of the 8 10/100TX + 2 10/100/1000T/SFP Combo with X-Ring L2 Managed Industrial
Switch has one terminal block connector of two DC power inputs and one fault alarm.
Top Panel of the industrial switch

12 AT-IFS802SP-80 User Manual
2.4 LED Indicators
The diagnostic LEDs that provide real-time information of system and optional status are located on
the front panel of the industrial switch.The following table provides the description of the LED status
and their meanings for the switch.
LED Color Status Meaning
PWR Green On The switch unit is power on
Off No power
R.M. Green On The industrial switch is the master of X-Ring group
Off The industrial switch is not a ring master in X-Ring group
PWR1 Green On Power 1 is active
Off Power 1 is inactive
PWR2 Green On Power 2 is active
Off Power 2 is inactive
FAULT Red On Power or port failure
Off No failure
P9, P10 (RJ-
45)
Green
(Upper
LED)
On A network device is detected.
Blinking The port is transmitting or receiving packets from the TX device.
Off No device attached
Green
(Lower
LED)
On 1000M
Off 10/100M
Link/Active
(P9, P10 SFP) Green
On The SFP port is linking
Blinks The port is transmitting or receiving packets from the TX device.
Off No device attached
P1 ~ P8
Green
On A network device is detected.
Blinking The port is transmitting or receiving packets from the TX device.
Off No device attached
Amber
On The port is operating in full-duplex mode.
Blinking Collision of Packets occurs.
Off The port is in half-duplex mode or no device is attached.

13AT-IFS802SP-80 User Manual
Chapter 3 Hardware Installation
In this paragraph, we will describe how to install the 8 10/100TX + 2 10/100/1000T/SFP Combo with
X-Ring L2 Managed Industrial Switch and the installation points attended to it.
3.1 Installation Steps
Unpack the Industrial switch1.
Check if the DIN-Rail is screwed on the Industrial switch or not. If the DIN-Rail is not screwed on2.
the Industrial switch, please refer to DIN-Rail Mounting section for DIN-Rail installation. If users
want to wall mount the Industrial switch, please refer to Wall Mount Plate Mounting section for
wall mount plate installation.
To hang the Industrial switch on the DIN-Rail track or wall.3.
Power on the Industrial switch. Please refer to the Wiring the Power Inputs section for knowing4.
the information about how to wire the power.The power LED on the Industrial switch will light
up. Please refer to the LED Indicators section for indication of LED lights.
Prepare the twisted-pair, straight through Category 5 cable for Ethernet connection.5.
Insert one side of RJ-45 cable (category 5) into the Industrial switch Ethernet port (RJ-45 port)6.
and another side of RJ-45 cable (category 5) to the network device’s Ethernet port (RJ-45 port),
ex: Switch PC or Server.The UTP port (RJ-45) LED on the Industrial switch will light up when the
cable is connected with the network device. Please refer to the LED Indicators section for LED
light indication.
When all connections are set and LED lights all show in normal, the installation is complete.7.
[note] Make sure that the connected network devices support MDI/MDI-X. If it does
not support, use the crossover category-5 cable.

14 AT-IFS802SP-80 User Manual
3.2 DIN-Rail Mounting
The DIN-Rail is screwed on the industrial switch when out of factory. If the DIN-Rail is not screwed
on the industrial switch, please see the following pictures to screw the DIN-Rail on the switch. Follow
the steps below to hang the industrial switch.
1. First, insert the top of DIN-Rail into the track. 2. Then, lightly push the DIN-Rail into the track.
3. Check if the DIN-Rail is tightened on the track or not.
4.To remove the industrial switch from the track, reverse above steps.

15AT-IFS802SP-80 User Manual
3.3 Wall Mount Plate Mounting
Follow the steps below to mount the industrial switch with wall mount plate.
Remove the DIN-Rail from the industrial switch; loose the screws to remove the DIN-Rail.1.
Place the wall mount plate on the rear panel of the industrial switch.2.
Use the screws to screw the wall mount plate on the industrial switch.3.
Use the hook holes at the corners of the wall mount plate to hang the industrial switch on the4.
wall.
To remove the wall mount plate, reverse the above steps.5.

16 AT-IFS802SP-80 User Manual
3.4 Wiring the Power Inputs
Please follow the steps below to insert the power wire.
Insert AC or DC power wires into the contacts 1 and 2 for power 1, or 5 and 6 for power.1.
Tighten the wire-clamp screws for preventing the wires from loosing.2.
[note] The wire gauge for the terminal block should be in the range between 12 ~ 24
AWG.
