Datasheet | Switches
9400 SERIES
Managed Gigabit Ethernet Switches
with Enhanced Security and Layer 2-4 Intelligence
AT-9424T/GB-xx**
Layer 2+ switch with 24 ports of
10/100/1000T plus 2 combo GBIC slots
(unpopulated)
AT-9424T/SP-xx
Layer 2+ switch with 24 ports of
10/100/1000T plus 2 combo SF slots
(unpopulated)
AT-9408LC/SP-xx
Layer 2+ switch with 8 ports 1000SX
(LC connectors) plus 4 SF s (active) plus
memory flash card slot
Smarter, More Secure and More
Cost-effective
The 9400 series is an advanced Layer 2
managed Gigabit switch for the access edge that
brings enhanced security to Gigabit networks.
Many network administrators demand easy to
manage, cost-effective, intelligent switches at the
LAN edge, and the 9400 switch answers such
demands, with the optimal balance of features,
performance, and value. More intelligent than
simple Layer 2 switches, the cost-effective 9400
offers advanced attack detection and suppression
capabilities for increased security and advanced
QoS to support converged applications.
The 9400 series provides the perfect
solution for:
• Traditional Enterprise LAN (wiring closet)
• Service-provisioned leased offices or MTUs
• Security-conscious government institutions
• Security-conscious financial institutions
• Cost/security-conscious educational institutions
Management Stacking
Stacking provides CLI-based management of up
to 24 switches with the same effort as for one
switch. The Allied Telesis solution uses open
standards interfaces as stacking links so that
many switches can be stacked across different
sites.
Layer 2-4 Intelligence
The 9400 series packs a lot of features in one
rack unit. With advanced AlliedWare®technology
the 9400 switches allow network administrators
to configure the switch to examine packet formats
and content from Layer 2, Layer 3, or Layer 4
(also known as the MAC, I and TC /UD layers).
After these layer parameters are defined and
detected, network security can be improved with
Access Control lists (ACLs) and DoS attack
detection features. Rate limits can be established
for excessive bandwidth usage and converged
applications are supported.
Securing the LAN Edge
To address the heightened concern of network
attacks in the form of Denial of Services (DoS),
Allied Telesis now makes security features its
primary focus. Assisted by the Layer 2-4
intelligence, network administrators can deploy
9400 switches to complement WAN firewalls
and C anti-virus protections to fortify the
network against malicious attacks. The 9400
switches come pre-programmed to detect six
well-known DoS attacks. Coupled with security
features such as IEEE 802.1x (port-based
network access control) and Radius/ TACACS+,
the 9400 series provides tiered security on
each port. Deploying tiered security in
unsecured areas such as visitors’ meeting rooms
and lounges provide cost-effective protections at
the network layer.
Service Features for Revenue
Generation
In a global economic climate, network
administrators must focus on managing capital
spending—a concern that forces resource
utilization to center stage. Allied Telesis designed
the 9400 to allow smart management of
network resources with two key features:
• Ingress and egress rate-limiting to provision
bandwidth intelligently.
• QoS support with IEEE 802.1p and DSC for
priority traffic. The 9400 series also includes
CoS to DSC remarking, allowing Layer 2
QoS priorities to be preserved over the
WAN.
Network administrators can configure the
9400 to control bandwidth-wasting traffic—such
as music streaming to desktops—by dynamically
lowering the priority and limiting bandwidth to a
trickle. Such features benefit metropolitan
providers by enabling them to charge a fee to
provision different bandwidth and QoS priorities
as value-added services for customers.
** Contact local sales representative for
availability
Key Features
Layer 2-4 Intelligence
•acket look-up at MAC, I , TC / UD layers
•For QoS, ACL, mirroring, rate-limiting
Advanced Security
•DoS attack protection
•Radius/ TACACS+
•ort security
•Secure Telnet
•IEEE 802.1x
•Layer 2-4 ACL
Advanced Services
•Rate limiting (ingress and egress)
•Eight levels of services
•IEEE 802.1p for MAC-based QoS
•DSC for I -based QoS
Layer 2 Redundancy
•IEEE 802.1s Multiple ST
(compatible with VST+)
•IEEE 802.3ad link aggregation (static)
•IEEE 802.1D Spanning-Tree
•IEEE 802.1w Rapid ST
Stacking
•Management stacking of up to 24 switches with
Enhanced StackingTM

Allied elesis www.alliedtelesis.com
9400 SERIES | Managed Gigabit Ethernet Switches with Enhanced Security
Hardware Specification
Physical Characteristics
Dimensions (H x W x D):
AT-9408 C/SP 4.4cm x 43.8cm x 22.2cm
(1.75” x 17.25” x 8.75”)
AT-9424T/GB 4.4cm x 43.8cm x 22.2cm
(1.75” x 17.25” x 8.75”)
AT-9424T/SP 4.4cm x 43.8cm x 22.2cm
(1.75” x 17.25” x 8.75”)
Weight:
AT-9408 C/SP 3.00kg (6.65 lb.)
AT-9424T/GB 3.11kg (6.85 lb.)
AT-9424T/SP 3.11kg (6.85 lb.)
Recommended minimum ventilation on all sides
10cm (4.0 in.)
System Capacity
32MB RAM
16MB flash memory
200MHz PowerPC CPU
4096 V ANs
16000 MAC addresses
8 megabytes file system
Performance
atency:
<81 microseconds latency between 10Mbps ports
<11 microseconds latency between 100Mbps ports
<4 microseconds latency between 1000Mbps ports
Wirespeed switching on all Ethernet ports
14,880pps for 10Mbps Ethernet
148,800pps for 100Mbps Fast Ethernet
1,488,000pps for 1000Mbps Gigabit
Ethernet throughput:
AT-9424TSP/GB 35.7Mpps
AT-9424TSP/SP 35.7Mpps
AT-9408 C/SP 17.8Mpps
Chipset switching capacity:
AT-9424TSP/GB 48Gbps (Full-duplex)
AT-9424TSP/SP 48Gbps (Full-duplex)
AT-9408 C/SP 24Gbps (Full-duplex)
Auto MDI/MDI-X
Software Specification
Interface Standards
IEEE 802.3 10T and 10F
IEEE 802.3u 100TX and 100FX
IEEE 802.3z 1000SX
IEEE 802.3ab 1000T
General Standards
IEEE 802.1d Bridging
IEEE 802.3ac V AN tag frame extension
IEEE 802.3x BackPressure/ flow control
Head of line blocking
Eight egress queues per port
Redundancy
IEEE 802.1D Spanning-Tree Protocol
IEEE 802.1w Rapid Spanning-Tree
IEEE 802.1s Multiple Spanning-Tree
(compatible with PVST+)
IEEE 802.3ad ACP link aggregation
(with three trunk groups and
up to eight port in a trunk)
Static port trunk
Router Redundancy Protocol (RRP) snooping
Quality of Services (QoS)
ayer 2, 3 and 4 criteria
Flow groups, traffic classes and policies
DSCP replacement
IEEE 802.1Q priority replacement
Type of Service replacement
Type of Service to IEEE 802.1Q priority replacement
IEEE 802.1Q priority to Type of Service replacement
Maximum bandwidth control
Burst size control
Support for ingress and egress ports
IEEE 802.1p Class of Service with strict and weighted
round robin scheduling
VLANs
IEEE 802.1Q V AN tagging
Port-based V ANs
Compliant and non-compliant IEEE 802.1Q V AN modes
Protected port V AN
MAC address-based V ANs (AT-9448Ts/XP only)
Selectable management V AN
GARP V AN Registration Protocol (GVRP)
Multicast
RFC 1112 IGMP snooping (v1)
RFC 2236 IGMP snooping (v2)
RFC 2710 Multicast istener Discovery
(M D) snooping (v1)
RFC 3810 Multicast istener Discovery
(M D) snooping (v2)
Management and Monitoring
RFC 1157 SNMPv1
RFC 1901 SNMPv2
RFC 3411 SNMPv3
RFC 1213 MIB-II
RFC 1215 TRAP MIB
RFC 1493 Bridge MIB
RFC 2863 Interfaces group MIB
RFC 1643 Ethernet-like MIB
RFC 1757 RMON 4 groups:
Stats, History, Alarms and Events
RFC 2674 IEEE 802.1Q MIB
AlliedTelesis Private MIB
RFC 1866 HTM
RFC 2068 HTTP
RFC 2616 HTTPS
RFC 854 Telnet server
RFC 1350 TFTP client
IP address allocation:
RFC 951 / RFC1542 BOOTP client
RFC 2131 DHCP client
Manual
RFC 2030 SNTP, Simple Network Time Protocol
Syslog client
Dual software images, dual configuration files
Two event logs:
4,000 event capacity in temporary memory
2,000 event capacity in permanent memory
Management Access Methods
Enhanced Stacking
Two 10Gbps full-duplex stacking port per port
Single IP address for management
Resilient bi-directional ring architecture
Out of band management (serial port)
In-band management (over the network) using Telnet,
web browser or SNMP
Management Interfaces
Menus
Command line
Web browser
SNMPv1/ v2/ v3
Security
RFC 1492 TACACS+
RFC 2865 RADIUS Client
RFC 2866 RADIUS Accounting
IEEE 802.1x Port-based network aaccess control
with multiple supplicants per port
Ingress and egress control of broadcast, multicast
and unknown unicast traffic
Ingress rate limiting
MAC address security/lockdown
ayer 2/3/4/ Access Control ists (AC s)
SSHv2 for Telnet mgmt
SS v3 for Web mgmt
Management access control list
Fault Protection
DoS attack protection
Smurf
SYN flood
Teardrop
and
IP option
Ping of Death
SNMP attack
Bad cable detection
Broadcast storm control

USA Headquarters |19800 North Creek Parkway |Suite 100 |Bothell |WA 98011 |USA |: [phone] |F: [phone]
European Headquarters |Via Motta 24 |6830 Chiasso |Switzerland |: +41 91 69769.00 |F: +41 91 69769.11
Asia-Pacific Headquarters |11 ai Seng Link |Singapore |534182 |: [phone] |F: [phone]
www.alliedtelesis.com
© 2010 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-00601 Rev. O
9400 SERIES | Managed Gigabit Ethernet Switches with Enhanced Security
Ordering Information
A-9424 /GB-xx**
ayer 2+ switch with 24 ports of 10/100/1000T plus
2 combo GBIC slots (unpopulated)
A -9424 /SP-xx
ayer 2+ switch with 24 ports of 10/100/1000T plus
2 combo SFP slots (unpopulated)
A -9408LC/SP-xx
ayer 2+ switch with 8 ports 1000SX
plus 4 SFP slots (active)
Where xx = 10 for US power cord
20 for no power cord
30 for UK power cord
40 for Australian power cord
50 for European power cord
Accessories
Redundant Power Supply
A -RPS3204 Chassis for up to 4 redundant
power supplies
(chassis includes one power
supply and one cable)
A -PWR3202 Additional 200w redundant
power supply with cable
GBICs
A -G8 1000T GBIC Copper
A -G8SX-01 550m SX GBIC, based on
50 Micron fiber 220m SX GBIC,
based on 62.5 micron fiber
Small Form Plugga les (SFPs)
A -SPSX Multi-mode fiber, GbE Small
Form-factor Pluggable (SFP)
850nm
A -SPLX10 Single-mode fiber, 10km,
GbE SFP, 1310nm
A -SPLX40 Single-mode fiber, 40km,
GbE SFP, 1310nm
A -SPLX40/1550 Single-mode fiber, 40km,
GbE SFP, 1550nm
A -SPZX80 Single-mode fiber, 80km,
GbE SFP, 1550nm
Miscellaneous Specifications
Power Characteristics
Voltage 100-240V AC
Current 4.0/2.0A
Frequency 50-60Hz
Maximum power consumption:
AT-9408 C/SP 58 watts
AT-9424T/GB 54 watts
AT-9424T/SP 54 watts
Environmental Specifications
Operating temp. 0°C to 40°C
(32°F to 104°F)
Storage temp. -25°C to 70°C
(-13°F to 158°F)
Operating humidity 5% to 90% non-condensing
Storage humidity 5% to 95% non-condensing
Maximum operating altitude
3,048m (10,000ft)
Electrical/Mechanical Approvals
Safety U 60950-1, CSA C22.2 No. 60950-1-03,
EN60950, EN60825 (TUV)
EMI FCC Class A, EN55022 Class A, VCCI Class A,
C-TICK, EN61000-3-2, EN61000-3-3
Immunity EN55024
Country of Origin
China
