Introduction
Allied Telesis switches include a range of sophisticated security features at layer 2 and layer 3.
This How To Note describes these features and includes brief examples of how to configure
them.
The implementations shown in this How To Note should be thought of as industry-standard
best practices.
Contents
Introduction .............................................................................................................................................. 1
Which products and software versions does this information apply to? ................................... 2
Securing the device ................................................................................................................................. 3
Protecting the network .......................................................................................................................... 3
Protecting against packet flooding ................................................................................................ 3
Protecting against rapid MAC movement ................................................................................... 6
Controlling multicast traffic ........................................................................................................... 7
Managing the device securely ................................................................................................................ 9
Using Secure Shell (SSH) ................................................................................................................ 9
Using SSL for secure web access ................................................................................................ 10
Using SNMPv3 ................................................................................................................................ 10
Whitelisting telnet hosts .............................................................................................................. 12
Identifying the user ................................................................................................................................ 14
IP spoofing and tracking ................................................................................................................ 14
Rejecting Gratuitous ARP (GARP) ............................................................................................ 15
DHCP snooping ............................................................................................................................. 15
Using 802.
1 x port authentication ............................................................................................... 17
Protecting the user ................................................................................................................................ 18
Using private VLANs ..................................................................................................................... 18
Using local proxy ARP and MAC-forced forwarding ............................................................. 19
Using IPsec to make VPNs ........................................................................................................... 24
Protecting against worms ............................................................................................................. 25
Create A Secure Network With Allied Telesis
Managed Layer 3 Switches

Which products and software versions does this information apply to?
Create A Secure Network With Allied Telesis Managed Layer 3 Switches 2
Appendix: Configuration scripts for MAC-forced forwarding example ................................... 27
Edge switch
1 .................................................................................................................. 27
Edge switch 2 .................................................................................................................................. 28
Edge switch 3 .................................................................................................................................. 29
Access Router ................................................................................................................................. 30
For information about the AlliedWare firewall, see the Firewall chapter of your Software
Reference, and the following How To Notes:
zHow To Configure Some Basic Firewall And VPN Scenarios
zHow To Apply Firewall Policies And Rules
How To Notes are available from www.alliedtelesis.com/resources/literature/howto.aspx.
Which products and software versions does this
information apply to?
This How To Note applies to the following Allied Telesis switch series:
zAT-8600
zAT-8700XL
zAT-8800
zRapier i
zSwitchBlade
zAT-9800
zAT-8948 and x900-48
zAT-9900
zAT-9900s and x900-24
Some features are only available on some switches and/or some software versions.
Therefore, when this How To Note describes each feature, it lists the applicable switches and
versions.

Create A Secure Network With Allied Telesis Managed Layer 3 Switches 3
Securing the device
Securing the device
The first step towards making a secure network is to secure
the networking equipment itself.
There are two aspects to this. Firstly, physical security is
vital—lock your networking equipment away.
Secondly, straight after powering up any new piece of
networking equipment, change the default administrator user’s password. On an Allied
Telesis managed layer 3 switch, the default user is “manager”. To change the password, use
the following command:
set user=manager password=<new-password>
The default password is well-known. If you do not change it, anyone with physical or IP access
could reconfigure the switch.
Protecting the network
This section describes layer 2 based methods for controlling the negative impact of
misconfigured devices and misuse of the network. These solutions work at the Ethernet level
of a packet and cause no degradation in the switch's throughput.
You can protect your network against the following:
ztraffic storms (“Protecting against packet flooding” on page 3)
zexcessive MAC address learning (“Protecting against rapid MAC movement” on page 6)
zunwanted multicast traffic (“Controlling multicast traffic” on page 7)
Protecting against packet flooding
Service providers are often vulnerable to traffic storms, primarily when incorrectly
configured customer equipment is directly connected to the provider. Storms overwhelm a
subnet, and all of the switches in that subnet, with traffic. Such misconfiguration can quickly
lead to widespread outages and compromise guaranteed service levels.
Storms are a reality in any network. They can occur by accident, maliciously, or when a
network device fails. They occur naturally in a network where switches are connected more
than once to the same VLAN, so administrators must employ a method to prevent these
switch loops.
Spanning Tree Protocol based solutions are the most common method of preventing loops.
However, incorrect configuration or other network issues can cause STP to fail. For example,
if a single switch in the VLAN does not have STP enabled, the STP tree will not converge
properly. Spanning tree protocols can even fail if a broadcast storm drowns out STP
messages.
Products
All switches listed on page 2
Software Versions
All

Protecting the network
Create A Secure Network With Allied Telesis Managed Layer 3 Switches 4
Service providers need to prevent storms from disrupting services to customers. AlliedWare
offers the following options for mitigating storms:
zlimiting broadcasts and multicasts on a port (“Bandwidth limiting” on page 4)
zdetecting a storm and disabling that port or VLAN (“Using QoS policy-based storm
protection” on page 5)
Bandwidth limiting
ARP packets are the most frequent trigger for broadcast
storms. One ARP packet is flooded around and around a
network, crowding out all other traffic.
You can use a simple Quality of Service (QoS) configuration
to match ARP packets and make sure that when a broadcast
storm occurs, the effect is minimised.
Configuration To limit the bandwidth for ARPs:
1. Create a classifier to match ARP packets.
2. Create a QoS framework of policy, traffic class, and flow group. In the traffic class settings,
specify the maximum bandwidth for ARP traffic.
3. Apply the policy—and therefore the bandwidth limit—to one or more ports.
Example The following configuration limits ARP packets to 1 00kbps on port 48.
create classifier=1 protocol=0806 ethformat=ethii-untagged
create qos policy=1
create qos trafficclass=1 maxbandwidth=100
create qos flowgroup=1
add qos policy=1 trafficclass=1
add qos trafficclass=1 flowgroup=1
add qos flowgroup=1 classifier=1
set qos port=48 policy=1
Products
All switches listed on page 2
Software Versions
All
port
48
port
48
misconfigured
customer switch
misconfigured
customer switch flood of ARPs
flood of ARPs
flood of ARPs
flood of ARPs
ISP switch
ISP switch
When ISP switch has
no bandwidth control:
When ISP switch has
bandwidth limiting:
secure-switch-bandwidth.eps

Create A Secure Network With Allied Telesis Managed Layer 3 Switches 5
Protecting the network
Using QoS policy-based storm protection
Policy-based storm protection lets you specify one of a
range of actions for the switch to take when it detects a
broadcast storm. It is a part of the QoS functionality.
Policy-based storm protection is more powerful than simple
bandwidth limiting. It lets you restrict storm damage to
within the storming VLAN, and it gives you the flexibility to
define what traffic rate makes a broadcast storm.
Configuration To use storm protection:
1. Turn on the switch enhanced mode qoscounters, unless it is already enabled. After this,
you need to restart the switch.
2. Create a classifier to match the desired traffic. To match all broadcast packets specify a
destination MAC address of ff-ff-ff-ff-ff-ff.
3. Create a QoS traffic class and define the following storm protection settings in it:
zWindow (stormwindow) specifies how often the switch measures traffic to decide
whether to activate storm protection (in seconds).
zRate (stormrate) specifies the amount of traffic per second that must be exceeded
before the switch takes action.
zAction (stormaction) specifies what the switch does when it detects a storm:
Link Down (linkdown) makes the switch physically disable the port on which the
storm is occurring, so that the link goes down.
Port Disable (portdisable) makes the switch logically disable the port on which the
storm is occurring, leaving the link up.
VLAN Disable (vlandisable) makes the switch block traffic only on the VLAN on
which the storm is occurring.
zTimeout (stormtimeout) specifies the number of seconds that the port remains
disabled for.
4. Create the rest of the QoS framework: a flow group and policy. Add the classifier to the
flow group, the flow group to the traffic class, and the traffic class to the policy.
5. Apply the policy—and therefore the storm protection—to one or more ports.
The procedure above applies storm protection to classified traffic, and uses a classifier to
select all broadcast traffic. This is the most common approach. If you want to, you can instead
classify to select important non-broadcast traffic and apply storm protection to unmatched
traffic. Unimportant or unwanted unicast and multicast traffic then counts towards the storm
calculations.
To apply storm protection to unclassified traffic, configure storm protection on the default
traffic class in the QoS policy settings. Use the parameters dtcstormwindow,
dtcstormrate, dtcstormaction, and dtcstormtimeout.
Products
AT-8948
x900-48 Series
AT-9900 Series
AT-9924Ts
x900-24 Series
Software Versions
2.8. 1 and later

Protecting the network
Create A Secure Network With Allied Telesis Managed Layer 3 Switches 6
Example The following example applies storm protection to classified broadcast traffic on port 1 . If
there is a storm, it takes the link down for 60 seconds.
set switch enhancedmode=qoscounters
Reboot after turning on enhanced mode.
create classifier=1 macdaddr=ff-ff-ff-ff-ff-ff
create qos trafficclass=1 stormstatus=enable stormwindow=100
stormrate=100 stormaction=linkdown stormtimeout=60
The rest of the QoS configuration is as normal, so:
create qos flowgroup=1
add qos flowgroup=1 classifier=1
add qos trafficclass=1 flowgroup=1
create qos policy=1
add qos policy=1 trafficclass=1
set qos port=1 policy=1
You can view matching traffic at the port level with the command:
show qos port=1 count trafficclass
Protecting against rapid MAC movement
Rapid MAC movement protection detects excessive MAC
address learning on a specific switch port. Once excessive
learning is detected, the switch stops learning MAC
addresses via the affected port.
Rapid MAC movement mostly occurs because of a
broadcast storm, when one packet is storming around a
layer 2 network. Rapid MAC movement protection is
simpler to configure than QoS policy-based storm
protection but is not guaranteed to stop all the varieties of
broadcast storm.
Rapid MAC movement protection is on by default. The default action is to disable learning for
1 second. This gives the CPU of the switch some idle time, which may let a fast STP-type
protocol converge. You can change the amount of idle time to suit your network, or select a
different action.
Configuration
on one or
more ports
To customise the protection:
1. Set the parameters in the following command:
set switch port=<ports> thrashaction={learndisable|linkdown|none|
portdisable|vlandisable} thrashtimeout={none|1..86400}
vlanstatustrap={on|off}
The parameter thrashaction specifies the switch’s response to rapid MAC movement:
zlearndisable makes the switch temporarily disable learning on the port.
zlinkdown makes the switch physically disable the port, so that the link goes down.
zportdisable makes the switch logically disable the port, leaving the link up.
zvlandisable makes the switch block traffic on only the VLAN on which the rapid
learning occurred.
Products
AT-8948
x900-48 Series
AT-9900 Series
AT-9924Ts
x900-24 Series
Software Versions
2.8. 1 and later

Create A Secure Network With Allied Telesis Managed Layer 3 Switches 7
Protecting the network
2. Set the sensitivity in detecting rapid MAC movement, by using the following command to
tell the switch how many times a MAC address can move ports in one second:
set switch thrashlimit=5..255
Configuration
on trunk
groups
Rapid MAC movement protection also works with trunk groups. If one switch in a trunk fails,
the switches probably cannot negotiate STP or any other trunks that they belong to. This
immediately causes a broadcast storm. Rapid MAC movement protection on the other
switch in the trunk group detects such a storm because flooding of the same packet occurs
on all trunk ports connected to the failed switch.
For a static trunk, to make use of rapid MAC movement protection, create the trunk and
specify the optional thrashaction and thrashtimeout parameters:
create switch trunk=<name> port=<ports>
thrashaction={learndisable|linkdown|none|portdisable|
vlandisable} thrashtimeout={none|1..86400}
For a dynamic trunk using LACP, enable LACP, add ports, and set the optional thrashaction
and thrashtimeout parameters:
enable lacp
add lacp port=<ports>
set lacp thrashaction={learndisable|linkdown|none|portdisable|
vlandisable} thrashtimeout={none|1..86400}
Controlling multicast traffic
In a busy network, or one that has subscription-only access to multicast services, tight
per-port control of multicast traffic is required. IGMP makes multicasting fairly efficient, but
the extra control offered by AlliedWare helps increase efficiency.
When multicasting, it is essential to avoid filling the network with unnecessary multicast data
and to make sure that the clients who join a group are entitled to receive it. It is also
important to minimise delays in joining a group and to efficiently handle those who leave a
group.
The following sections outline some of the IGMP controls that are particularly relevant for
security. For detailed information on how to control IGMP in the network, see How To
Configure IGMP for Multicasting on Routers and Managed Layer 3 Switches. This How To Note is
available from www.alliedtelesis.com/resources/literature/howto.aspx.
IGMP snooping
IGMP snooping is enabled by default on Allied Telesis
managed layer 3 switches. IGMP snooping monitors the
streams and clients involved in each multicast group,
independent from IP itself. A snooping switch ensures that
only ports that are interested in a group are sent it. This
basic level of management works in tandem with the
subnetwork's IGMP querier and makes sure that the querier
gets notified of any client who wants to join the group.
Products
All switches listed on page 2
Software Versions
All

Protecting the network
Create A Secure Network With Allied Telesis Managed Layer 3 Switches 8
IGMP filtering
IGMP filtering lets you dictate exactly which multicast
groups a specific port can receive, by creating a filter list and
applying it to the port. Different ports may have different
filter lists applied to them.
If desired, you can select the type of message to filter. By
default, filters apply to IGMP reports. You can create extra
entries to also filter queries (type=query) and leave
messages (type=leave).
Configuration For each port:
1. Work out which groups you want users on the port to be able to join.
2. Create an IGMP filter.
3. Create entries to allow the appropriate groups (action=include).
Note: The order of entries in a filter is important. When IGMP tries to match a message
to a filter, it performs a linear search of the filter to find a matching entry. It tries
each entry in turn, and stops processing the filter after the first match it finds.
4. Create an entry to block all groups (action=exclude). Give this entry a higher entry
number than entries for the included groups.
5. Apply the filter to the port.
Example To stop the user attached to port 1 from joining any group except 224. 1 2. 1 3. 1 4:
create igmp filter=1
add igmp filter=1 entry=1 group=224.12.13.14 action=include
add igmp filter=1 entry=2 group=224.0.0.0-239.255.255.255
action=exclude
set switch port=1 igmpfilter=1
IGMP throttling
Throttling limits the number of multicast groups that an
individual port can join.
To limit port 2 to a total of 6 groups:
set switch port=2 igmpmaxgroup=6
igmpaction=replace
Products
All switches listed on page 2
that support 2.7.5 or later
Software Versions
2.7.5 or later
Products
All switches listed on page 2
that support 2.7.5 or later
Software Versions
2.7.5 or later
Example

Create A Secure Network With Allied Telesis Managed Layer 3 Switches 9
Managing the device securely
Managing the device securely
In Ethernet and broadcast networks the privacy of traffic is not guaranteed. Hubs and
networks outside the administrator's control may leak sensitive data to unwanted recipients.
A hacker may even be able to force a switch to flood unicast traffic.
Because you cannot guarantee traffic privacy, you cannot be certain that management
sessions are private. Therefore, you should always use encrypted sessions when remotely
administering network equipment, even in networks that you know well. The simplest way to
achieve this is with Secure Shell (SSH).
This section describes secure management:
z“Using Secure Shell (SSH)” on page 9
z“Using SSL for secure web access” on page 10
z“Using SNMPv3” on page 10
Then the section ends by describing how to limit telnet access if you need to use telnet
instead of one of the recommended secure options (“Whitelisting telnet hosts” on page 12).
When you are using a secure management scheme, we recommend that you block all telnet
access to the switch, by disabling the telnet server:
disable telnet server
Using Secure Shell (SSH)
The Secure Shell (SSH) protocol is most simply described as
an encrypted form of Telnet.
1. Add a security officer to your switch’s list of users.
2. Create encryption keys for SSH to use.
3. Enable the SSH server.
4. Add the security officer to the list of SSH users and specify a password for it. Only users
in this list can use SSH to access the switch.
5. Enable system security.
Enabling system security makes telnet unavailable as an administrative interface—once you
have configured SSH, you have to use it.
Example To configure SSH access for the security officer called “secoff”:
add user=secoff password=securepass privilege=security telnet=yes
login=yes
create enco key=0 type=rsa length=1024 description="Host Key"
form=ssh
create enco key=1 type=rsa length=768 description="Server Key"
form=ssh
enable ssh server serverkey=1 hostkey=0 expirytime=1
logintimeout=60
add ssh user=secoff password=sameordifferentpassword
enable system security
Products
All switches listed on page 2
Software Versions
All
Configuration

Managing the device securely
Create A Secure Network With Allied Telesis Managed Layer 3 Switches 10
Using SSL for secure web access
If you prefer to configure the switch using the convenient
web-based GUI, then this is unencrypted by default. SSL lets
you use the GUI securely, by using HTTPS instead of HTTP.
1. Add a security officer to your switch’s list of users.
2. Create an encryption key for SSL to use.
3. Create a self-signed PKI certificate, or load a certificate
generated by a Certificate Authority (CA) if you have
one.
4. Add the certificate to the certificate database.
5. Turn security on for the HTTP server.
6. Enable system security.
Once you have configured SSL, HTTPS connections to the device are available only on
port 443.
Example To allow the security officer called “secoff” to browse securely to the GUI, using a self-signed
certificate:
add user=secoff password=secoff privilege=securityofficer
login=yes
create enco key=0 type=rsa length=1024
set system distinguishedname="cn=switch1,o=my_company,c=us"
create pki certificate=cer_name keypair=0 serialnumber=12345
subject="cn=172.30.1.105,o=my_company,c=us"
add pki certificate=cer_name location=cer_name.cer trust=yes
set http server security=on sslkey=0 port=443
enable system security
Using SNMPv3
Traditionally, SNMP has been a popular but insecure way to
monitor networks.
Allied Telesis devices are SNMPv3 compliant. By using
SNMPv3, you can authenticate SNMP users and restrict
their network access to parts of the network. SNMPv3 is
very flexible, as the examples in this section show.
Configuration 1. Enable SNMP.
2. Set up one or more SNMP views. Views list the objects in the MIB that users can see.
3. Set up one or more groups and add the groups to the views. Each group is a collection of
users who have the same access rights.
4. Set up one or more users and add them to the groups. Authentication parameters are set
here.
5. Set up a traphost profile, for trap messages to be remotely sent to. This is not compulsory
but we recommend it.
Products
All switches listed on page 2,
except AT-8948 and x900-48
Series which have no
graphical user interface
Software Versions
All
Configuration
Products
All switches listed on page 2
Software Versions
2.6.4 and later

Create A Secure Network With Allied Telesis Managed Layer 3 Switches 11
Managing the device securely
Examples To allow the user “steve” full read, write and notify SNMP access to the switch:
enable snmp
add snmp view=full oid=1.3.6.1 type=include
add snmp group=super-users securitylevel=authPriv readview=full
writeview=full notifyview=full
add snmp user=steve group=super-users authprotocol=md5
authpassword=cottonsox privprotocol=des privpassword=woollytop
To also give the user “jane” read and notify access to everything on the switch, add the
following commands:
add snmp group=users securitylevel=authNoPriv readview=full
notifyview=full
add snmp user=jane group=users authprotocol=md5
authpassword=redjeans
To also give the user “paul” unauthenticated read access to everything on the switch except
BGP, add the following commands:
add snmp view=restricted oid=1.3.6.1 type=include
# exclude bgp by specifying either mib=bgp or oid=1.3.6.1.2.1.15:
add snmp view=restricted mib=bgp type=exclude
add snmp group=restricted-users securitylevel=noAuthNoPriv
readview=restricted
add snmp user=paul group=restricted-users
To also send traps securely to the PC with IP address 1 92. 1 68. 11 .23 for user “steve” to see,
add the following commands:
add snmp targetparams=netmonpc securitylevel=authPriv user=steve
add snmp targetaddress=nms ip=192.168.11.23 udp=162
params=netmonpc
For more information about the above examples, see How To Configure SNMPv3 On Allied
Telesis Routers and Managed Layer 3 Switches, available from www.alliedtelesis.com/resources/
literature/howto.aspx. This How To Note also explains SNMPv3 concepts in detail, including
users, groups and views.

Managing the device securely
Create A Secure Network With Allied Telesis Managed Layer 3 Switches 12
Whitelisting telnet hosts
For any remote management of a network device, Allied Telesis recommends you use SSH,
Secure HTTP (SSL), or SNMPv3. Therefore, we recommend you block all telnet access to
the switch by disabling the telnet server. However, if you persist with telnet, you should make
a whitelist of the hosts that are permitted to telnet to the switch. This does not make telnet
secure, but it does reduce the associated risks.
Building a whitelist through layer 3 filters
On Rapier, Rapier i, AT-8800, AT-8700XL and AT-8600
Series switches, use layer 3 filters to build a whitelist.
1. Create a filter match definition that specifies destination
IP address, protocol and destination TCP port as the
criteria that the filter will match. The switch
automatically assigns this filter an ID of
1 (unless other
layer 3 filters already exist).
2. Create a filter entry that specifies the switch’s IP address
as the destination address, TCP as the protocol and 23
as the port. Give it an action of deny.
3. Create another filter match definition with source and destination IP addresses, both with
32-bit masks.
4. Create filter entries for the second filter. In each entry, specify a permitted host as the
source and the switch’s IP address as the destination. Give the entries an action of nodrop.
The first filter blocks (action=deny) any incoming telnet packets with the switch’s
destination IP address. The second filter reverses the first filter by undoing the previous
denial of IP access to the switch—but only for the permitted source IP addresses.
Example To permit only the host with IP address 1 72.30. 1 . 1 44 to telnet to the switch 1 72.28.40.70:
add switch l3filter match=dipaddress,protocol,tcpdport dclass=32
add switch l3f=1 entry protocol=tcp dipaddress=172.28.40.70
tcpdport=23 action=deny
add switch l3filter match=dipaddress,sipaddress sclass=32
dclass=32
add switch l3filter=2 entry sipaddress=172.30.1.144
dipaddress=172.28.40.70 action=nodrop
Products
AT-8600 Series
AT-8700XL Series
Rapier i Series
Rapier Series
AT-8800 Series
Software Versions
All
Configuration

Create A Secure Network With Allied Telesis Managed Layer 3 Switches 13
Managing the device securely
Building a whitelist through QoS
On AT-8948, AT-9900, AT-9900s, and x900 Series switches,
use classifiers to build a whitelist and QoS to apply it.
1. Create classifiers to match telnet traffic from permitted
IP addresses to the switch’s IP address.
2. Create a classifier to match all telnet traffic to the
switch’s IP address.
3. Create a flow group and add the classifiers for permitted
traffic to it.
4. Create a second flow group with a higher ID number and
add the classifier that matches all telnet traffic to it.
5. Create the rest of the QoS framework—traffic class and policy.
6. Apply the policy to all ports to stop telnet from all directions.
QoS is an incredibly versatile hardware-level packet filtering mechanism. For more
information about setting up QoS on these switches, see How To Configure QoS On AT-8948,
AT-9900, AT-9900s And x900 Series Switches. This How To Note is available from
www.alliedtelesis.com/resources/literature/howto.aspx.
Example To permit only the host with IP address 1 72.30. 1 . 1 44 to telnet to the switch 1 72.28.40.70:
create classifier=1 ipsa=172.30.1.144/32 ipda=172.28.40.70/32
tcpd=23
create classifier=2 ipda=172.28.40.70/32 tcpd=23
create qos flowgroup=1 action=forward
create qos flowgroup=2 action=discard
create qos trafficclass=1
create qos policy=1
add qos flowgroup=1 classifier=1
add qos flowgroup=2 classifier=2
add qos trafficclass=1 flowgroup=1
add qos trafficclass=1 flowgroup=2
add qos policy=1 trafficclass=1
set qos port=all policy=1
Products
AT-8948
x900-48 Series
AT-9900 Series
AT-9924Ts
x900-24 Series
Software Versions
2.7.3 and later
Configuration

Identifying the user
Create A Secure Network With Allied Telesis Managed Layer 3 Switches 14
Identifying the user
This section describes methods for authorising and tracking users and preventing them from
changing their identity on the network.
IP spoofing and tracking
Unknown users who attempt to change IP address—to circumvent billing or to hide their
identity—can be a problem for administrators.
Changing IP address for malicious reasons is most commonly called IP spoofing, and is also
known as ARP spoofing, ARP poisoning, and ARP poison routing (APR). The net result is the
same for all of these: the victim ends up with false information in its ARP table.
The trouble with ARP
IP Spoofing takes advantage of the inherently insecure design of ARP. In an Ethernet network,
a client may use a Gratuitous ARP (GARP), or merely send an ARP request or reply with
false information, to announce a phoney identity to the local subnet.
A phoney announcement may be made in a number of ways for a number of reasons. The
following table briefly explains these factors.
The techniques for protecting the network are the same for all these phoney
announcements: reject gratuitous ARPs, and control access to ports with DHCP snooping
and ARP security. The following sections describe these solutions in detail.
If the ARP or GARP packet contains... Then...
MAC that does not exist on network and
IP address that does not exist on network
the attacker may be trying to fill up the IP ARP table
so that the subnet’s router cannot learn more
addresses. As a result, return (routed) traffic may
not be forwarded.
MAC that is owned by attacker and
IP address that does not exist on network
the attacker is using an IP address that the
administrator has not assigned and so may be trying
to avoid traceability.
MAC that is owned by attacker and
IP address that is owned by another host
the attacker is trying to intercept traffic destined for
this host.
MAC that is owned by attacker and
IP address that is owned by the subnet router
the attacker is trying to intercept all traffic leaving
the subnet.
MAC does not exist on network and
IP address that exists on network
the attacker is trying to cause traffic to this IP
address to flood to all hosts in the subnet. However,
hosts disregard the flooded traffic because it is not
addressed with any host’s MAC address. This means
that the attacker receives the traffic and its intended
recipient ignores it.

Create A Secure Network With Allied Telesis Managed Layer 3 Switches 15
Identifying the user
Rejecting Gratuitous ARP (GARP)
Hosts can use GARP to announce their presence on a
subnet. It is a helpful mechanism, particularly when there is
a chance of duplicate addresses. However, attackers can use
GARP to penetrate the network by adding themselves to
the switch’s ARP table.
You can configure Allied Telesis switches and routers to ignore GARP packets. Ignoring
GARPs does not completely prevent IP spoofing, but it does shut down one easy avenue for
an attacker.
Example To ignore GARPs on VLAN 1 :
set ip interface=vlan1 gratuitousarp=off
Note: We do not recommend disabling GARP reception if a server with teamed network
cards is attached to the switch. In a teamed-NIC redundancy set-up, another card
takes over if a card fails. In many implementations, the NIC that takes over sends a
GARP to inform the switch of the port and MAC address change.
DHCP snooping
The AlliedWare DHCP snooping feature is a series of layer 2
techniques. It works with information from a DHCP server
to:
ztrack the physical location of hosts
zensure that hosts only use the IP addresses assigned to
them
zensure that only authorised DHCP servers are accessible.
In short, DHCP snooping ensures IP integrity on an L2-
switched domain.
With DHCP snooping, only a whitelist of IP addresses may
access the network. You configure this whitelist at the switch
port level, and the DHCP server manages the access control. Only specific IP addresses with
specific MAC addresses on specific ports may access the IP network.
DHCP snooping also stops attackers from adding their own DHCP servers to the network.
An attacker could set up a server to wreak havoc in the network or even control it.
There are a number of options for DHCP snooping. You can:
zlet the switch snoop DHCP packets and decide who is authorised to access the IP
network. See “Setting up DHCP snooping” on page 16.
zstatically bind IP address and MAC combinations to switch ports. See “Using static binding
for rigid control” on page 16.
zuse option 82 to track users. See “Using DHCP snooping to track clients” on page 17.
zuse ARP security to reject ARP messages unless they come from an IP address in the
DHCP snooping database. See “Using ARP security” on page 17.
Products
All switches listed on page 2
Software Versions
2.5.1 and later
Products
AT-8600 Series
AT-8700XL Series
Rapier i Series
Rapier Series
AT-8800 Series
AT-8948
x900-48 Series
AT-9900 Series
Software Versions
2.7.6 and later

Identifying the user
Create A Secure Network With Allied Telesis Managed Layer 3 Switches 16
For more information about setting up DHCP snooping, see How To Use DHCP Snooping,
Option 82 and Filtering on Rapier, AT-8800 and AT-8600 Series Switches or How To Use DHCP
Snooping, Option 82 and Filtering on x900 Series Switches. These How To Notes are available
from www.alliedtelesis.com/resources/literature/howto.aspx.
Setting up DHCP snooping
This section describes a minimal configuration for DHCP snooping. With this configuration,
the switch snoops DHCP packets to build a database of allowed IP addresses, only sends
DHCP messages to the port with the official DHCP server, and limits the number of clients
attached to each port.
Configuration 1. Enable DHCP snooping.
2. Identify the port that your DHCP server is attached to, and configure this as a trusted port
for DHCP snooping. The switch only sends DHCP discover and request packets to trusted
ports. If a malicious user attaches a DHCP server to an untrusted port, that server will
never receive DHCP requests. This prevents DHCP server spoofing.
3. Set the number of leases permitted on each port.
4. For AT-8948, x900-48, and AT-9900 switches, add classifiers and a quality of service (QoS)
configuration to permit and filter addresses.
Example To limit each port on a 24-port switch to 1 lease, when the DHCP server is on port 24:
enable dhcpsnooping
set dhcpsnooping port=24 trusted=yes
set dhcpsnooping port=1-23 maxlease=1
On AT-8948, x900-48 and AT-9900 switches, also add the following commands:
create classifier=50 macsaddr=dhcpsnooping prot=ip
ipsaddr=dhcpsnooping
create classifier=51 protocol=ip
create qos policy=1
create qos trafficclass=1
create qos flow=50 action=forward
create qos flow=51 action=discard
add qos policy=1 trafficclass=1
set qos port=1-23 policy=1
add qos trafficclass=1 flow=50
add qos trafficclass=1 flow=51
add qos flow=50 classifier=50
add qos flow=51 classifier=51
Using static binding for rigid control
If there is no DHCP server, or if there is a host with a static IP address, then you can bind the
IP address to the port to which it is attached.
Example To specify that the host with MAC address 00-00-00-00-00- 1 2 can legitimately use the IP
address
1 72. 1 6.0. 1 2 on port 1 2, use the following command in addition to the configuration
given in “Setting up DHCP snooping”, above.
add dhcpsnooping binding=00-00-00-00-00-12 ip=172.16.0.12
interface=vlan1 port=12

Create A Secure Network With Allied Telesis Managed Layer 3 Switches 17
Identifying the user
Using DHCP snooping to track clients
If your DHCP server supports it, you can use “option 82” to record more information about
DHCP clients. This enhances your ability to track users. The switch can pass option 82
information to the DHCP server so that the server can record the switch MAC, switch port,
VLAN number and subscriber-ID that the client is a member of.
Example To pass option 82 information to the server, including the information that port 1 is room
1 0 1 , use the following commands in addition to the configuration given in “Setting up DHCP
snooping” on page 16.
enable dhcpsnooping option82
set dhcpsnooping port=1 subscriberid="Room 101"
Using ARP security
When you enable ARP security, the switch drops ARP packets received on non-trusted
(client) ports unless the packets originate from an IP address that is registered in the DHCP
snooping database.
ARP security stops clients that are directly attached to the switch from using IP spoofing or
ARP poisoning. It also protects directly-attached clients from IP spoofing and ARP poisoning.
Example To turn on ARP security, use the following command in addition to the configuration given in
“Setting up DHCP snooping”, above.
enable dhcpsnooping arpsecurity
Using 802. 1 x port authentication
With 802. 1 x port authentication, hosts must authenticate
themselves when they attempt to access a network through
an Ethernet port.
Unlike DHCP snooping, 802.
1 x only authenticates users
when they access the port. It cannot track them afterwards.
A network controller, such as a RADIUS server, controls the authentication. The Allied
Telesis switch facilitates the host to server communication and takes note of success or
failure. Essentially, the host is completely denied access to the Ethernet until the switch sees
the host successfully authenticate with the server. After that, the switch allows packets to
and from the host to pass through the 802.
1 x controlled port.
802.
1 x can also dynamically assign the host to a VLAN.
Examples For examples of 802. 1 x authentication, see the following How To Notes:
zHow to Configure A Secure School Network Based On 802. 1 x
zHow To Use 802. 1 x VLAN Assignment
zHow To Use 802. 1 x EAP-TLS or PEAP-MS-CHAP v2 with Microsoft Windows Server 2003 to
Make a Secure Network
zHow To Use 802. 1 x Security with AT-WA7400 APs, AT-8624PoE Switches, and Linux’s
freeRADIUS and Xsupplicant
Most of the above Notes describe how to configure the authentication server and the host,
as well as the switch.
Products
All switches listed on page 2
Software Versions
2.6.1 and later

Protecting the user
Create A Secure Network With Allied Telesis Managed Layer 3 Switches 18
Protecting the user
This section describes the following methods of protecting users from other users on the
network:
z“Using private VLANs” on page 18. This feature isolates switch ports in a VLAN from
other switch ports in the same VLAN.
z“Using local proxy ARP and MAC-forced forwarding” on page 19. These features force all
traffic in a network to go via an access router.
z“Using IPsec to make VPNs” on page 24. This feature creates secure tunnels through an
insecure network.
z“Protecting against worms” on page 25. These methods reduce the damage worms do to
users of the network.
Using private VLANs
Private VLANs are an excellent way of preventing hosts on
a subnet from attacking each other. Essentially, each switch
port is isolated from other ports in the VLAN, but can
access another network through an uplink port or uplink
trunk group. All traffic between private ports is blocked, not
just Layer 2 traffic.
Private VLANs are reasonably flexible. A
private port can be a member of multiple
private VLANs. However, a port cannot be a
private port in some VLANs and a non-private
port in others.
On AT-8600, AT-8700XL, Rapier i and AT-8800
Series switches running 2.9.
1 or later, each
private VLAN can have multiple uplink ports.
This allows you to use private VLANs on
switches that are connected in a ring topology. Also, you can group private
ports together on these switches, which allows the ports in a group to
communicate with each other but not with other ports in the VLAN.
Note that ports are only isolated from ports on the same physical switch, not
from ports on other switches reached through an uplink port.
Configuration 1. Create the VLAN, specifying that it is private.
2. Add the uplink port, or the ports in the uplink trunk group, to the VLAN. For a trunk
group, the ports must already be trunked together, and you must specify all the ports in
the trunk group. Note that on Rapier 48i and AT-8748XL switches, the uplink and private
ports must be in the same switch instance. See the Switching chapter of the Software
Reference for more information about switch instances.
3. Add the private ports to the VLAN.
Products
AT-8600 Series
AT-8700XL Series
Rapier i Series
Rapier Series
AT-8800 Series
AT-8948
x900-48 Series
AT-9900 Series
AT-9924Ts
x900-24 Series
Software Versions
All
switch
uplink port
hacker legitimate
customer

Create A Secure Network With Allied Telesis Managed Layer 3 Switches 19
Protecting the user
Example To create a private VLAN with ports 2-6 in it, with an uplink trunk group of ports 24 and 25:
create vlan=example vid=2 private
add vlan=2 port=24-25 frame=tagged uplink
add vlan=2 port=2-6
To remove ports from the VLAN:
# remove port 4:
delete vlan=2 port=4
# remove all private ports and the uplink ports:
delete vlan=2 port=all
Using local proxy ARP and MAC-forced forwarding
Both these features ensure the integrity of ARP in your network and let you take granular
control of IP traffic flows. They do this by forcing traffic that would have been dropped by
private VLANs to go via an access router. Both features stop hosts from learning the MAC
addresses of other hosts in their subnet—they learn the MAC address of the access router
instead.
You can use these features, for example, to allow customers to use VoIP to telephone each
other while blocking any video, data, or management traffic between customers.
MAC-forced forwarding (page 23) requires more configuration than local proxy ARP
(page 20) but is more powerful. MAC-forced forwarding:
zensures that all ARP replies are generated by the directly-connected switch (not the access
router). This removes the ARP process from the access router, minimises the distance
ARPs travel through the network, and protects against ARP Denial of Service attacks.
zdynamically determines the appropriate access router for a host by snooping DHCP
packets.
zbypassing the access router for traffic between application servers and their clients.
With software versions 291-05 and later, you can use MAC-forced forwarding without
configuring private VLANs. However, we recommend you use it with private VLANs for
maximum security.

Protecting the user
Create A Secure Network With Allied Telesis Managed Layer 3 Switches 20
The following figure shows a network that can use either local proxy ARP or MAC-forced
forwarding—the examples in both the following sections refer to this network.
Local proxy ARP
In a network configuration like the previous figure, each
edge switch uses private VLANs to stop clients from talking
directly to each other. Private VLANs stop the edge switch
from flooding broadcast traffic, including clients’ ARP
requests. Instead, the switch sends ARP requests out its
uplink port to the access router.
If local proxy ARP is configured on the access router, then the access router responds to
ARP requests with its own MAC address, instead of the destination device’s MAC address.
This combination of private VLANs and local proxy ARP forces the clients to send all their
traffic to the access router. When the access router sees traffic from a client, it checks a list
of filters to determine whether to forward the traffic or drop it.
On each client residential gateway, you need to enable tagged VLANs on the connection to
the edge switch for the VLANs that the client should be able to access.
Internet
Edge
Switch 1
Edge
Switch 2
Edge
Switch 3
Residential
Gateway 1
Residential
Gateway 2
Residential
Gateway 3
Client 1
Client 2
Client 3
Access
Router
Management
PC
SIP and Multicast
server
LACP
12
12
49 50
49
50 49
14
50
15
15
20
5
24
macff.eps
Products
All switches listed on page 2
Software Versions
2.9. 1 or later
