Allied Telesis AT-9006T User manual

Gigabit
Ethernet
Switches
AT-9006T
AT-9006SX/SC
AT-9006LX/SC
!
Installation
Guide
®
PN 613-10851-00 Rev B

Copyright 2000 Allied Telesyn International, Corp.
960 Stewart Drive Suite B, Sunnyvale, CA 94085 USA
All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn
International, Corp.
CentreCom is a registered trademark of Allied Telesyn International, Corp.
All other product names, company names, logos or other designations mentioned herein are trademarks or registered trademarks
of their respective owners.
Allied Telesyn International, Corp. reserves the right to make changes in specifications and other information contained in this
document without prior written notice. The information provided herein is subject to change without notice. In no event shall
Allied Telesyn International, Corp. be liable for any incidental, special, indirect, or consequential damages whatsoever, including
but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied
Telesyn International, Corp. has been advised of, known, or should have known, the possibility of such damages.

iii
Electrical Safety and Emission
Statement
Standards: This product meets the following standards.
RFI Emission EN55022 Class A "1
Warning: In a domestic environment this product may cause radio interference inwhich case theuser may berequired totake
adequate measures. "2
Immunity EN50082-1 1997 "3
Electrical Safety EN60950, UL 1950, CSA 950 "4
Laser EN60825 "5
Important: Appendix Ccontains translated safetystatements for installing this equipment. When yousee the ",goto Appendix
C for the translated safety statementin your language.
Wichtig: Anhang C enthält übersetzte Sicherheitshinweise fürdie Installation dieses Geräts. Wenn Sie"sehen,schlagen Sie in
AnhangC den übersetztenSicherheitshinweisin Ihrer Sprache nach.
Vigtigt: TillægC indeholder oversatte sikkerhedsadvarsler, der vedrører installation afdette udstyr. Når Deser symbolet", skal
De slå op itillæg C og finde de oversatte sikkerhedsadvarsler iDeres eget sprog.
Belangrijk: Appendix Cbevat vertaalde veiligheidsopmerkingen voorhet installerenvandeze apparatuur. Wanneer ude "ziet,
raadpleeg Appendix C voor vertaalde veiligheidsinstructies in uw taal.
Important : L'annexe Ccontient les instructions de sécurité relativesà l'installation de cet équipement. Lorsque vous voyez le
symbole ", reportez-vous àl'annexe Cpour consulterla traduction de ces instructions dans votre langue.
Tärkeää: Liite C sisältää tämän laitteen asentamiseen liittyvät käännetyt turvaohjeet. Kun näet "-symbolin, katso käännettyä
turvaohjettaliitteestäC.
Importante: l’Appendice C contiene avvisidi sicurezza tradotti per l’installazione di questa apparecchiatura. Ilsimbolo", indica
di consultare l’Appendice C per l’avviso di sicurezza nella propria lingua.
Viktig: Tillegg C inneholderoversatt sikkerhetsinformasjon for installering av dette utstyret. Når du ser", åpner du til Tillegg C
for å finne denoversatte sikkerhetsinformasjonen på ønsketspråk.
Importante: OAnexo C contémadvertências de segurança traduzidas para instalar este equipamento. Quando vir osímbolo ",
leia a advertência de segurança traduzida no seu idioma no Anexo C.
Importante: ElApéndiceC contiene mensajes deseguridad traducidospara la instalación deeste equipo. Cuando vea elsímbolo
", vaya al Apéndice C para ver el mensaje de seguridad traducido a su idioma.
Obs! BilagaCinnehålleröversattasäkerhetsmeddelanden avseendeinstallationenav denna utrustning.Närduser", skall du gå
till Bilaga C föratt läsa det översatta säkerhetsmeddelandet på dittspråk.
U.S. FederalCommunications Commission
RADIATED ENERGY
Note:Thisequipmenthas beentested and foundto comply with thelimitsfora Class Adigital devicepursuantto Part15of the
FCC Rules. These limits aredesignedto providereasonable protection againstharmful interference when the equipment is
operated in a commercial environment. Thisequipment generates, uses, and can radiateradio frequency energy and, if not
installed and used inaccordance with this instruction manual, may cause harmful interferenceto radio communications.
Operationofthisequipmentina residentialareaislikelytocauseharmfulinterferenceinwhichcasetheuserwillberequired to
correct theinterference athis own expense.
Note: Modifications or changes not expressly approved by the manufacturer or the FCC can void your right to operate this
equipment.
CanadianDepartment ofCommunications
This Class A digital apparatus meets all requirements ofthe Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.

5
Table of Contents
Table of Contents .................................................................................................................................................................................................5
Preface ......................................................................................................................................................................................................................7
Audience ...................................................................................................................................................................................................................7
How This Guide is Organized .............................................................................................................................................................................7
DocumentConventions ......................................................................................................................................................................................8
Where to Find Web-based Guides ...................................................................................................................................................................9
Contacting Allied Telesyn .................................................................................................................................................................................10
Online Support............................................................................................................................................................................................. 10
Telephone and Fax Support.................................................................................................................................................................... 10
E-mail Support.............................................................................................................................................................................................. 10
Returning Products .............................................................................................................................................................................................11
FTP Server ...............................................................................................................................................................................................................12
For Sales or Corporate Information ...............................................................................................................................................................13
Tell Us What You Think ......................................................................................................................................................................................14
Chapter 1
ProductDescription .........................................................................................................................................................................................15
Summary ofFeatures ..........................................................................................................................................................................................16
Switch Models .......................................................................................................................................................................................................17
Features and Components ...............................................................................................................................................................................18
Six Twisted Pair 100/1000 Mbps Ports (AT-9006T).......................................................................................................................... 18
Six Fiber Optic 1000 Mbps Ports (AT-9006SX/SC and AT-9006LX/SC)..................................................................................... 19
RS232 Connector......................................................................................................................................................................................... 19
System and Port LEDs................................................................................................................................................................................ 19
Reset Button.................................................................................................................................................................................................. 20
ACPower Connector.................................................................................................................................................................................. 20
Redundant Power Supply Connector.................................................................................................................................................. 20
Expansion Slots............................................................................................................................................................................................ 21
MAC Address Table..................................................................................................................................................................................... 21
AT-S26 Management Software and Omega Management Interface....................................................................................... 22
IEEE 802.3u Auto-Negotiation................................................................................................................................................................ 23
Spanning Tree Protocol (STP) ................................................................................................................................................................. 23
Quality of Service (QOS)............................................................................................................................................................................ 24
BOOTP and Dynamic Host Configuration Protocol (DHCP)......................................................................................................... 25
Port Mirroring ............................................................................................................................................................................................... 25
Virtual LANs (VLANs) .................................................................................................................................................................................. 25
Network Topologies ............................................................................................................................................................................................27
Where to Go Next .................................................................................................................................................................................................28

Table ofContents
6
Chapter 2
Installation ...........................................................................................................................................................................................................29
Verifying the Package Contents .....................................................................................................................................................................30
Reviewing Safety Precautions .........................................................................................................................................................................31
Selecting a Site for theSwitch ........................................................................................................................................................................32
Planning the Installation ...................................................................................................................................................................................33
Installing the Switch on a Desktop ...............................................................................................................................................................34
Installing the Switch in a Rack ........................................................................................................................................................................36
Installing an Expansion Module .....................................................................................................................................................................38
Starting a Local Omega Management Session .........................................................................................................................................41
Warranty Registration ........................................................................................................................................................................................42
Where to Go Next ................................................................................................................................................................................................43
Chapter 3
Troubleshooting ................................................................................................................................................................................................45
At the First Sign of a Problem .........................................................................................................................................................................46
How the Switch Reports Problems ................................................................................................................................................................47
Common Problems .............................................................................................................................................................................................48
Link /Activity LED on Any Port is OFF.................................................................................................................................................. 48
Power LED is OFF........................................................................................................................................................................................ 48
Fault LED is ON ............................................................................................................................................................................................ 49
Calling Technical Support ................................................................................................................................................................................50
AppendixA
Technical Specifications ................................................................................................................................................................................51
Physical Specifications .......................................................................................................................................................................................51
Dimensions................................................................................................................................................................................................... 51
Weight ............................................................................................................................................................................................................ 51
Required Ventilation on All Sides.......................................................................................................................................................... 51
Environmental Specifications .........................................................................................................................................................................52
Operating Temperature ........................................................................................................................................................................... 52
Storage Temperature................................................................................................................................................................................ 52
Operating Humidity................................................................................................................................................................................... 52
Operating Altitude Range........................................................................................................................................................................ 52
Power Specifications ..........................................................................................................................................................................................53
Maximum Power Consumption ............................................................................................................................................................ 53
AC Input Voltage......................................................................................................................................................................................... 53
Frequency...................................................................................................................................................................................................... 53
DC Redundant Power Voltage............................................................................................................................................................... 53
Safety and Electromagnetic Emissions Certifications ............................................................................................................................54
Safety............................................................................................................................................................................................................... 54
EMI.................................................................................................................................................................................................................... 54
Immunity....................................................................................................................................................................................................... 54
Quality and Reliability............................................................................................................................................................................... 54
Pin Assignment ....................................................................................................................................................................................................55
AppendixB
Switch Default Settings ..................................................................................................................................................................................57
AppendixC
Translated Electrical Safetyand Emission Information .................................................................................................................59

7
Preface
This guide contains instructions on how to install the AT-9006T,
AT-9006SX/SC, and AT-9006LX/SC Gigabit Ethernet Switches.
Audience
This guide is intended for network administrators who are responsible
for installing and managing the switches. Network administrators
should be familiar with Ethernet switches, Ethernet and Fast Ethernet
technology, bridging,and the Spanning Tree Protocol (STP).
How This Guide is Organized
This manual contains the following chapters and appendices:
Chapter 1, Hardware Description, describes the features and
components ofthe Gigabit switches.
Chapter 2, Installation, contains the installation procedures.
Chapter 3, Troubleshooting, provides information on how to resolve
common problems that might occur with the switches.
Appendix A, Technical Specifications,containsthe specifications of
theswitches.
Appendix B, Switch Default Settings,lists the factory default settings
for the switch.
Appendix C, TranslatedElectrical Safety and Emission Information,
contains translations of the warnings and cautions in the manual.

Preface
8
Document Conventions
This documentuses several conventions that youshould become
familiar with before youbegin to install the product.
Note
Notes provideadditional information.
Warning
Warningsinform you that performingor omitting a specificaction
may result in bodily injury.
Caution
Cautions inform you that performing or omitting a specific action
may result in equipment damage or loss of data.

AT-9006 Series Installation Guide
9
Where to Find Web-based Guides
The Allied Telesyn web site at www.alliedtelesyn.com offers you an easy
waytoaccessthemostrecentdocumentationandtechnicalinformation
for all Allied Telesyn International products. All web-based
documentation for this product and other Allied Telesyn products can
be downloaded from the web site in PDF format.
You will need thefollowing manual in addition to this guidein orderto
managethe GigabitEthernetswitch. The manualcontainsinstructions
on how to use the AT-S26 management software to manage and
configure the switch. The manual is available from the Allied Telesyn
web site:
❑AT-S26 Management Software User’s Guide,
PN 613-10852-00

Preface
10
Contacting Allied Telesyn
There are several ways that you can contact Allied Telesyn technical
support: online, telephone, fax and e-mail.
Online Support You can request technical support online by filling out the Online
Technical Support Form at www.alliedtelesyn.com/forms/support.htm.
Telephone and
Fax Support
E-mail Support United States and Canada
[e-mail]
LatinAmerica, Mexico, Puerto Rico, Caribbean, and Virgin Islands
[e-mail]
United Kingdom, Sweden, Norway, Denmark, andFinland
[email protected]
Americas
United States, Canada, Mexico,
Central America, South America
Tel: [phone],option4
Fax: [phone]
Germany
Germany, Switzerland, Austria, Eastern
Europe
Tel: [phone]
Fax: [phone]
Asia
Singapore, Taiwan, Thailand, Malaysia,
Indonesia,Korea, Philippines, China,
India,Hong Kong
Tel: [phone]
Fax: [phone]
Italy
Italy,Spain, Portugal, Greece, Turkey,Israel
Tel: [phone]
Fax: [phone]
Australia
Tel: [phone]
Fax: [phone]
Japan
Tel: [phone]
Fax: [phone]
France
France, Belgium, Luxembourg,
The Netherlands,MiddleEast,
Africa
Tel: [phone]
Fax: [phone]
United Kingdom
United Kingdom, Denmark, Norway,
Sweden,Finland
Tel: [phone]
Fax: [phone]

AT-9006 Series Installation Guide
11
Returning Products
Products for return or repair must first be assigned a Return Materials
Authorization (RMA) number. A product sent to Allied Telesyn without a
RMA number will bereturned to the senderat the sender’sexpense.
To obtain an RMA number, contact Allied Telesyn’s Technical Support at
one of the following locations:
North America
2124Zanker road
SanJose,CA 95131
Tel: [phone],option 4
Fax: [phone]
European CustomerSupport Centre
10/11BridgemeadClose
Westmead Industrial Estate
Swindon, Wiltshire SN5 7YT
England
Tel: [phone]
Fax: [phone]
Latin America, the Caribbean,
VirginIslands
Tel: internationalcode+ 425-481-3852
Fax: internationalcode+ 425-483-9458
MexicoandPuertoRico
Tel: [phone],ext3852or
1-800-424-4284,ext3852
Mexico only:95-800-424-5012,ext 3852
Fax: internationalcode + 425-489-9191

Preface
12
FTP Server
If you needmanagement software for an Allied Telesyn device and you
knowthenameof themanagementsoftwarefile,youcandownloadthe
software by connecting directly to our FTP server at
ftp://gateway.centre.com.
At login, enter ‘anonymous’. Enter your e-mail address for the password
as requestedby the server at login.

AT-9006 Series Installation Guide
13
For Sales or Corporate Information
Allied Telesyn International, Corp.
19800 NorthCreek Parkway,Suite 200
Bothell, WA 98011
Tel: [phone]
Fax: [phone]
AlliedTelesyn International, Corp.
960 Stewart Drive, Suite B
Sunnyvale,CA 94085
Tel: [phone] (USA and Canada)
Fax: [phone]

Preface
14
Tell Us What You Think
Ifyouhaveanycommentsorsuggestionsonhowwemightimprovethis
or other Allied Telesyn documents, please fill out the Send Us Feedback
Form at www.alliedtelesyn.com/forms/feedback.htm.

15
Chapter 1
Product Description
The AT-9006 Series Gigabit Ethernet Switches allow you to build a
flexible network topology suited to the demands of your network
environment. The switches provide non-blocking architecture and full-
wire speed performance on all ports. They can serve as high speed
workgroup switches with dedicated links to workstations, printers, and
servers,or as links to additional hubs and switches to forma highspeed
infrastructure for large networks.The switches offer a wide range of
features, including IEEE 803.3u Auto-Negotiation, spanning tree
protocol, and IEEE 802.1p Quality of Service. The switches are also IEEE
802.1Q compliant and supportboth port-based and tagged VLANs.

Product Description
16
Summary of Features
#Six 100Base-T/1000Base-TX ports with RJ-45 connectors
(AT-9006T)
#Six 1000Base-SX ports with dual SC connectors (AT-9006SX/SC)
#Six 1000Base-LXportswith dualSC connectors (AT-9006LX/SC)
#12 K MAC address tablewith automatic aging
#2MB SGRAM packet memory perport
#3 MB flash memory for software upgrades
#1.5u high chassis
#Porttrunking
#Portmirroring
#BOOTP and DHCP support
#AT-S26managementsoftware
#Omegamanagement interface
#IEEE803.3u Auto-Negotiation
#Spanning tree protocol
#IEEE802.1p Qualityof Service
#IEEE 802.1Q compliant tagged VLANs
#Two packet priority queues

AT-9006 Series Installation Guide
17
Switch Models
Table 1 lists the switch models.
Table 1 AT-9006 Series Switches
Model1Number of
Ports Type of Port Type of Connector Maximum Distance
AT-9006T 6 100Base-T /
1000Base-TX RJ-45 100 m (328 ft)
AT-9006SX/SC 6 1000Base-SX Dual SC 550 m (1804 ft)2
AT-9006LX/SC 6 1000Base-LX Dual SC 10 km (6.25 mi)3
1. All models include two expansion slots.
2. Assumes 50/125 micron fiber optic cable with arating of 500 MHz/Km.
3. Assumes 9/125 micron single-mode fiber optic cable. Also assumes the port is connected to another AT-9006LX/SX switch or to a
compatible GBIC module.

Product Description
18
Features and Components
Figure 1 illustrates the frontpanel components.
Figure 1 Front Panel (Model AT-9006SX/SC)
Figure 2 showsthe location of the AC connector andthe Redundant
Power Supply (RPS) input connector on the back panel of the switch.
Figure 2 Back Panel
Six Twisted Pair
100/1000 Mbps
Ports
(AT-9006T)
The AT-9006TGigabit Ethernet Switch featuressix twisted pairports
withRJ-45 connectors.Eachportcanoperateateither100Mbpsor1000
Mbps and, when operating at 100 Mbps, in either half- or full-duplex
mode. Youcan either setthe speed and duplex mode manually oryou
can allow the switch todo it automatically through auto-negotiation.
Each port has a maximum operating distance of 100 m (328 ft.). The
switch requires Category5 or Enhanced Category5 twisted pair cabling.
Each port is IEEE 802.3ab compatible and can operate as either MDI or
MDI-X. The ports are configured automatically when connected to an
end node. No crossover cables are required.
STATUS
RESET
FAULT
RPS
PWR
1000BASE-SX
A
B
RS-232
TERMINAL PORT
PORT ACTIVITY
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
LINK ACTIVITY
FULL DUP
L/A
D/C
HALF DUP
COL
1
RXTX
4
RXTX
2
RXTX
5
RXTX
3
RXTX
6
RXTX
AT-9006SX/SC
1000BASE-SX GIGABIT ETHERNET SWITCH
CLASS 1
LASER PRODUCT
DO NOT STARE
INTO BEAM
Expansion Module Slots Reset Button
RPS LED
RS232 Connector
1000Base-SX ports
PortLEDs LEDColorFunctionKeyFaultLED
Power LED
RPS
AC Power
Connector Connector

AT-9006 Series Installation Guide
19
Six Fiber Optic
1000 Mbps Ports
(AT-9006SX/SC
and
AT-9006LX/SC)
The AT-9006SX/SCand AT-9006LX/SC Gigabit EthernetSwitches feature
six fiber optic ports with dual SC connectors. The ports operate at 1000
Mbps in full-duplex mode. (The ports can be configured as half-duplex,
but since all 1000 Mbps network devices operate at full-duplex, there
should be no reason to set one of the ports to half-duplex.)
Each port on theAT-9006SX/SC Switch has a maximum operating
distanceof550metersusingmultimodefiberopticcabling.Theportson
the AT-9006LX/SC offer a maximum operating distance of 550 m using
multimode cabling or 2 km using single-mode fiber optic cabling.
RS232 Connector The RS232, DB-9 female connector provides out-of-band local
management for the switch. You can use eithera VT100terminal or a
personalcomputerwithaterminalemulationprogramtoconnecttothe
RS232 port. The connector uses astraight-through cable.
System and Port
LEDs The switch features a series of system and portLEDs that you can useto
monitorand troubleshootthe switch.Table2 describes thesystem LEDs.
Table2 System LEDs
LED State Description
Fault OFF Normal operation.
Solid Red The switch or management software is malfunctioning.
Flashing Red The switch is booting, running diagnostic tests, writing
messages to FLASH, or transferring files using XMODEM.
RPS Solid Green An RPS is connected tothe switch. Toverify that theRPS is
operating correctly, refer to your RPS manual. (AT-9006SX/
SC and AT-9006LX/SC only.)
Power Solid Green The switch is receiving power.

Product Description
20
Table 3 describes the port LEDs.
Reset Button This button resets the switch. You might need to reset the switch to
resolveaswitchproblem,toactivatenewparametersontheswitchorto
reset the switch statistics storedby the AT-S26 management software.
You can also resetthe switch using the Omegamanagement interface,
as explained in theAT-S26 Management Software User’sGuide.
AC Power
Connector The switch has a single ACpower supply socket on theback panel,
which has autoswitch AC inputs. Refer to Appendix A, Technical
Specifications, for the input voltage range. The power cord acts as an
ON/OFF switch.
Redundant Power
Supply Connector The R.P.S. Input connector on the back panel of the AT-9006SX/SC and
AT-9006LX/SCSwitchesconnectstheunitstoaredundantpowersupply
(RPS), such as the AT-RPS8000 Redundant Power Supply from Allied
Telesyn.ContactyourAlliedTelesynrepresentativeformoreinformation
on available RPS units.
Note
The AT-9006T Switch does not support an RPS unit.
Table3 PortLEDs
LED State Description
Link/Activity Solid Green This indicates a 1000 Mbps linkhas been
established between the port andthe end node.
Flashing Green Thisindicates1000 Mbps activityon theport.
Solid Amber This indicates a 100 Mbps link has been
established between the port andthe end node
(AT-9006T only).
Flashing Amber This indicates 100 Mbps activity on the port
(AT-9006T only).
Duplex Solid Green The port is operating in full-duplex mode.
Solid Amber The port is operating at half-duplex mode (AT-
9006T only).
Flashing Amber Collisions are occurring on the line (AT-9006T
only).
