Allied Telesis Rapier G6 User manual

RAPIER SWITCH
QUICK INSTALL GUIDE

Rapier Switch Quick Install Guide
Document Number C613-04017-01 REV G.
Copyright © 1999-2003 Allied Telesyn International, Corp.
19800 North Creek Parkway, Suite 200, Bothell, WA 98011, USA.
All rights reserved. No part of this publication may be reproduced without prior written
permission from Allied Telesyn.
Allied Telesyn International, Corp. reserves the right to make changes in specifications
and other information contained in this document without prior written notice. The
information provided herein is subject to change without notice. In no event shall Allied
Telesyn be liable for any incidental, special, indirect, or consequential damages
whatsoever, including but not limited to lost profits, arising out of or related to this
manual or the information contained herein, even if Allied Telesyn has been advised of,
known, or should have known, the possibility of such damages.
All trademarks are the property of their respective owners.

Quick Install Guide 3
C613-04017-01 REV G
Models Covered By This Guide
This Quick Install Guide includes information on the following models:
■Rapier G6
■Rapier G6F-LX/SC
■Rapier G6F-SX/SC
■Rapier G6F-SX/MT
■Rapier 8/8MT
■Rapier 8/8SC
■Rapier 16F-FX/MT
■Rapier 16Fi-FX/MT
■Rapier 16F-FX/SC
■Rapier 16Fi-FX/SC
■Rapier 24
■Rapier 24i
■Rapier 48
■Rapier 48i
Quick Install Guide updates can be downloaded from
www.alliedtelesyn.co.nz/support/rapier/.
Rapier Switch
Safety and Statutory Information
Quick Install Guide
Hardware Reference
Software Reference
Network Service Module
NSM Quick Install Guide
NSM Hardware Reference
Port Interface Card
PIC Quick Install Guide
PIC Hardware Reference
General Customer Support
Visit www.alliedtelesyn.co.nz for
the latest documentation, FAQ,
and support information
Uplink Module
Uplink Module Quick Install Guide
Uplink Module Hardware Reference
Printed Acrobat PDF Website
Documentation Roadmap
User Guide

4Rapier Switch
C613-04017-01 REV G
Package Contents
The following items are included with each Rapier Switch. Contact your sales
representative if any items are damaged or missing.
■One Rapier Switch.
■One AC power cord (AC models only).
■One serial cable for connecting the switch to a terminal or PC.
■One 19 inch rack-mount kit.
■One Rapier Switch Quick Install Guide.
■One Safety and Statutory Information booklet.
■One Rapier Switch Documentation and Tools CD-ROM (which includes
the complete Rapier Document Set and utilities).
■One warranty card.
Selecting a Site
The switch can be installed in a standard 19-inch rack or on a level surface such
as a desktop or bench. When installing the switch, choose a site that:
■Allows adequate airflow around the switch and its vents.
■Is free of dust and moisture.
■Will maintain an ambient temperature range of 0-40º C (32-104º F) and a
humidity range of 5-95% non-condensing.
■Has a reliable and earthed (grounded) power supply circuit, preferably
dedicated and filtered.
■Does not expose cabling to sources of electrical noise, such as radio
transmitters, broadband amplifiers, power lines, electric motors, and
fluorescent fixtures.
■Allows easy access to the switch’s power and cable connections.
■Will allow all related network devices to be connected to the switch
without exceeding maximum cable length limitations. See the Rapier Switch
Hardware Reference for cable length specifications.

Quick Install Guide 5
C613-04017-01 REV G
Installing the Switch
All AC and DC versions of this equipment must be earthed.
Follow these steps to install the switch:
1. Before installing the switch, read the safety information
For safety information, see the Safety and Statutory Information booklet. A
copy of this booklet is supplied with each switch, and can also be found on
the Documentation and Tools CD-ROM or at www.alliedtelesyn.co.nz/
support/rapier/.
2. Gather the tools and equipment you will need
If installing a DC version of the switch, you will need a DC power source,
DC supply cable, and wire strippers (see step 7).
If the switch is to be connected to a redundant power supply, you will need
a redundant power supply unit and cable (see step 9).
3. Unpack the switch
Verify the package contents. If any items are damaged or missing, contact
your sales representative.
4. Install expansion options
If you purchased optional Uplink Modules, a Network Service Module
(NSM), or Port Interface Cards (PICs), install them now by following their
individual installation guides. These guides can be found on the
Documentation and Tools CD-ROM.
5. Place the switch in its operating location
See the previous "Selecting a Site" section for guidelines on choosing a
suitable location. If installing the switch in a rack:
• Remove the rubber feet.
• Attach the rack-mounting brackets.
• Mount the switch in the rack.
6. Apply AC power to the switch (for AC models)
Plug the power cord into the AC power connector on the switch’s rear
panel (see Figure 1). The Fault LED should flash for approximately 10
seconds as the switch runs internal tests. If the LED continues to flash or
remains lit, refer to the Rapier Switch Hardware Reference for troubleshooting
information.

6Rapier Switch
C613-04017-01 REV G
Figure 1: Rapier front panel and rear panel with AC power inlet.
7. Apply DC power to the switch (for DC models)
Read the Safety and Statutory Information booklet before connecting a DC
power supply. A copy of this booklet is included with each switch. It is also
included on the Documentation and Tools CD-ROM, or can be
downloaded from www.alliedtelesyn.co.nz/support/rapier/.
Only trained and qualified personnel should connect a DC power supply. Due
to exposed terminals, DC powered switches should be installed only in
Restricted Access Areas.
DC supply cable specifications:
• Number of wires (cores): 3
• Minimum size: 2.1mm2(14 AWG)
• Minimum cable rating: 600V, 90 degrees Celsius
DC power supply specifications:
• 48 VDC (39-60 VDC is acceptable)
• Either positive grounded or negative grounded
Circuit protection:
• Use a 10 Amp circuit breaker
To connect the DC supply:
a) Ensure the supply cable is not live
b) Strip the supply cable wires to expose 8mm (0.31 in.) of bare conductor
c) At the switch, connect the ground wire to the ground terminal. These
terminals can be identified by the diagram on the switch’s rear panel
(see Figure 2). Tighten the terminal to between 0.6 and 0.8 Nm (0.041 to
0.055 pound-force per foot)
STATUS
RESET
FAULT
PWR
RPS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
10BASE-T / 100BASE-TX
1X3X5X7X
2X4X6X8X
9X11X13X15X
10X12X14X16X
17X19X21X23X
18X20X22X24X
25
26
RS-232
TERMINAL PORT
100M LINK / ACTIVITY 10M LINK / ACTIVITY
HALF DUP/ COL
FULL DUP
PORT ACTIVITY
L/A
L/A
D/C
D/C
L/A
D/C
ASYN0
Layer 3 Fast Ethernet Switch
NSM 0
Hot Swap
In Use
Swap
Front panel
Uplink Module Bays 10/100 BASE Ports Port LEDs System
LEDs
RS-232 Terminal Port
Rear panel
100-240 VAC
Power Inlet
RPS Inlet for
AT-PWR8000
NSM BAY NSM Hot Swap
Button and LEDs

Quick Install Guide 7
C613-04017-01 REV G
d) At the switch, connect the positive feed to the + (positive) terminal and
the negative feed to the - (negative) terminal. Tighten the terminals to
between 0.6 and 0.8 Nm (0.041 to 0.055 pound-force per foot)
e) Ensure there are no exposed conductor strands
f) Secure the supply cable (to the rack framework or similar object) so the
connections are isolated from any force applied to the cable
g) Ensure the circuit breaker is in the Off position
h) Connect the supply-cable wires to the circuit breaker
i) Energise the circuit breaker
Figure 2: DC Power inlet terminals on a Rapier 24.
The Fault LED should flash for approximately 10 seconds as the switch
runs internal tests. If the LED continues to flash or remains lit, refer to the
Rapier Switch Hardware Reference for troubleshooting information.
8. Check that the Power LED on the switch’s front panel lights green
If the LED fails to light, refer to the Rapier Switch Hardware Reference for
troubleshooting information.
9. Connect the Redundant Power Supply (Optional)
AC models of Rapier Switches have a Redundant Power Supply (RPS)
connector on their rear panel (see Figure 1).
The Switch is designed to operate with the AT-RPS8000 RPS, which can be
purchased separately. Contact your authorised Allied Telesyn distributer
or reseller for more information.
10. Connect the data cables
Use straight-through or cross-over Ethernet patch cables to connect the
required device(s) to the switch’s ports. Make sure each cable connection is
secure. The switch will now perform basic Layer 2 switching functions. By
default, all switch ports are members of VLAN1.
NSM 0
Hot Swap
In Use
Swap
38-75VDC , 2A
FOR CENTRALIZED DC
POWER CONNECTION,
INSTALL ONLY IN A
RESTRICTED AREA
DC Power inlet
DC INPUT

8Rapier Switch
C613-04017-01 REV G
Configuring the Switch
Some configuration is necessary if you wish to enable the switch’s advanced
switching capabilities. The switch can be configured by using the Command
Line Interface (CLI) or Graphical User Interface (GUI).
Using the CLI to configure a switch
1. Connect a terminal or PC to the Terminal Port (ASYN0)
Using the supplied RS-232 DB9 straight-through cable, connect a VT100-
compatible terminal or the COM port of a PC running a terminal
emulation program such as Windows Terminal, to the RS-232 Terminal
Port on the switch’s front panel.
2. Set the communication parameters
Set the communication parameters on your terminal or terminal emulation
program to:
• Baud rate: 9600
• Data bits: 8
•Parity:None
•Stopbits:1
• Flow control: Hardware
3. Log in and set the password
After the switch has booted, the log-in prompt appears. If the log-in
prompt doesn’t appear, press [Enter] two or three times.
When the switch boots for the first time it automatically creates an account
with manager privileges. The account has the log in name “manager” and
the password is “friend”.
At the log in prompt, enter the log in name and password.
Login: manager
Password: friend
The switch’s command prompt appears and you can now configure the
switch using the command line interface.
Change the password as soon as possible. Leaving the manager account with
the default password is a serious security risk. Make sure you remember the
new password as there is no way to retrieve it if it is lost.
Use the following command to change the account password:
set password
The Command Help lists available commands for each protocol, and their
syntax. To display a list of help topics, enter:
help
To display help on a specific topic, enter:
help topic
Alternatively, type a question mark (?) at the end of a partially completed
command to see a list of valid options.

Quick Install Guide 9
C613-04017-01 REV G
See the Rapier Switch Software Reference for more information on start-up
and configuration procedures (including a list of message definitions).
Using the GUI to configure a switch
This section describes how to access the GUI from a PC via VLAN1, in
order to configure the switch. It assumes that the PC and the switch are in
the same subnet. By default, all switch ports are members of VLAN1.
The GUI requires a PC and web browser. Supported browsers are Internet
Explorer 5.0 and greater, or Netscape 6.2.2 or 6.2.3, with JavaScript enabled.
Internet Explorer can be found on the Documentation and Tools CD-ROM
that is bundled with your switch.
1. Connect the PC to a switch port.
The PC can be connected directly, or through your LAN.
To connect the PC directly to the switch, use a straight-through Ethernet
cable to connect an Ethernet card on the PC to any one of the switch ports.
Note the PC’s IP address and mask.
To connect via a LAN, use an Ethernet cable to connect the switch port(s) to
the device(s) on the LAN. Select the LAN PC from which you wish to
configure the switch. The PC should be in the same subnet as the part of
the LAN that contains the switch (for example, the PC could be connected
to a hub or Layer 2 switch that is directly connected to one of the switch’s
ports). Note the PC’s IP address and mask.
2. Access the CLI on the switch.
Follow the instructions in the previous "Using the CLI to configure a
switch" section.
3. Enable IP.
At the CLI, enter the command:
ENABLE IP
4. Assign an IP address to VLAN1.
Assign the VLAN1 interface an IP address in the subnet that the PC uses,
using the command:
ADD IP INTERFACE=vlan1 IP=ipaddress MASK=mask
Rapier

10 Rapier Switch
C613-04017-01 REV G
5. Browse to the GUI.
If you access the Internet through a proxy server, set your browser to
bypass the proxy for the IP address you just assigned to the VLAN1
interface.
Point your web browser at the IP address of the VLAN interface.
6. Log in and set the password.
At the log in prompt, enter the log in name and password. Passwords are
case sensitive.
User Name: manager
Password: friend
The system status page appears and you can now use the GUI to configure
the switch.
To ensure configuration settings are saved correctly, use the GUI menus and buttons to
navigate, not your browser’s buttons.
As a security precaution, change the password as soon as possible.
To change the password, select Management > Users from the sidebar
menu. Select the Manager account and click Modify.
7. To access context-sensitive help in the GUI.
Click on the Help Button [Help]. The Help button is located at the top of
the sidebar menu or on any popup page.
System LEDs
System LEDs
LED State Function
Power Green The switch is receiving power and the voltage
is within the acceptable range
Fault Red The switch or management software is
malfunctioning
1 flash A switch fan has failed. (The LEDs will not
indicate an RPS fan failure.)
3 flashes If an RPS is connected, the switch’s PSU (Power
Supply Unit) has failed
4 flashes If RPS monitoring is enabled, the RPS PSU has
failed
5 flashes If RPS monitoring is enabled, an RPS is not
connected or is not operational

Quick Install Guide 11
C613-04017-01 REV G
1. DC models of the Rapier Switch do not have an RPS connector and the RPS LED will not function.
2. Not included on the Rapier 48, G6, G6F-SX/SC, G6F-LX/SC, or G6F-SX/MT-RJ.
3. Hot swapping is supported by Software Release 2.3.1 or later. AT-AR021 (S) BRI-S/T, AT-AR021 (U)
BRI-U, and AT-AR023 SYN PICs can be hot swapped.
The Rapier Switch Hardware Reference has further troubleshooting information,
including information on Switch Port and Uplink Module LEDs.
Documentation and Tools CD-ROM
The Documentation and Tools CD-ROM bundled with each Rapier Switch
contains the complete Documentation Set for your switch and its expansion
options, as well as tools for managing the switch. This includes:
■The Rapier Switch Statutory and Safety booklet, which provides safety and
statutory information for the Rapier Switch and its expansion options.
■The Rapier Switch Hardware Reference, which provides detailed information
on the hardware features of Rapier Switches.
■This Quick Install Guide.
■The Rapier Switch Software Reference, which provides detailed information
on configuring the switch and its software.
■The Rapier Switch User Guide, which provides an introduction to the
switch’s Graphical User Interface and its Layer 2 switching features.
■The Network Service Module Quick Install Guide, which outlines the
procedure for installing an NSM; and the Network Service Module Hardware
Reference, which provides detailed information on NSMs.
■The Port Interface Card Quick Install Guide, which outlines the procedure for
installing PICs; and the Port Interface Card Hardware Reference, which
provides detailed information on PICs.
RPS1(Redundant
Power Supply)
Green An RPS is connected to the switch
In use2(Rear panel) Green An NSM is installed, is receiving power, and is
operational. The NSM and its PICs are not
ready to be hot swapped
Off No NSM is installed, or the NSM is not installed
correctly (the switch unit has not recognised
the NSM)
Swap2 (Rear panel) Green The NSM and its PICs are ready to be hot
swapped
Off The Hot Swap button must be pressed before
the NSM or PICs can be hot swapped, or the
software release does not support hot
swapping3
System LEDs
LED State Function

12 Rapier Switch
C613-04017-01 REV G
■The Uplink Module Quick Install Guide, which outlines the procedure for
installing an Uplink Module; and the Uplink Module Hardware Reference,
which provides detailed information on Uplink Modules.
■AT-TFTP Server for Windows for downloading software releases.
■Adobe Acrobat Reader for viewing online documentation.
■Microsoft Internet Explorer.
