Allied Telesis SwitchBlade x3106 User manual

613-001786 Rev. D
SwitchBlade x3106
Access Edge Chassis Switch
AT-SBx31CFC960
Controller Fabric Card (AlliedWareNSP R6.18.0.2)
AT-SBx3106 Chassis
AT-SBx31GT24 Line Card
AT-SBx31GT40 Line Card
AT-SBx31GP24 PoE Line Card
AT-SBx31GS24 SFP Line Card
AT-SBx31GC40 SFP CSFP BiDi Line Card
AT-SBx31XZ4 XFP Line Card
AT-SBx31XS6 SFP+ Line Card
AT-SBxPWRSYS1 and AT-SBxPWRSYS2 System Power Supplies
AT-SBxPWRPOE1 PoE Power Supply
Installation Guide

Copyright ©2015 Allied Telesis, Inc.
All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesis,
Inc.
Allied Telesis and the Allied Telesis logo are trademarks of Allied Telesis, Incorporated. All other product names,
company names, logos or other designations mentioned herein are trademarks or registered trademarks of their respective
owners.
Allied Telesis, Inc. reserves the right to make changes in specifications and other information contained in this document
without prior written notice. The information provided herein is subject to change without notice. In no event shall Allied
Telesis, Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited
to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesis, Inc. has
been advised of, known, or should have known, the possibility of such damages.

3
Electrical Safety and Emissions Standards
This product meets the following standards.
EMI/RFI Emissions: FCC Class A, EN55022 Class A, EN61000-3-2, EN61000-3-3, CISPR Class A,
VCCI Class A, AS/NZS Class A
Immunity: EN55024
Electrical Safety: EN60950-1 (TUV), UL 60950-1 (CULUS), EN60825
Safety Agency Approvals: CULUS, TUV, C-TICK, CE
U.S. Federal Communications Commission
Radiated Energy
Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15
of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with this instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
Note: Modifications or changes not expressly approved of by the manufacturer or the FCC, can void your right to operate
this equipment.
Industry Canada
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
European Union Restriction of the Use of Certain Hazardous Substances
(RoHS) in Electrical and Electronic Equipment
This Allied Telesis RoHS-compliant product conforms to the European Union Restriction of the Use of Certain Hazardous
Substances (RoHS) in Electrical and Electronic Equipment. Allied Telesis ensures RoHS conformance by requiring
supplier Declarations of Conformity, monitoring incoming materials, and maintaining manufacturing process controls.
Warning: In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
Laser Safety EN60825

4
Translated Safety Statements
Important: The indicates that a translation of the safety statement is available in a PDF
document titled “Translated Safety Statements” on our web site at
http://www.alliedtelesis.com/support.

5
Preface ............................................................................................................................................................15
Safety Symbols Used in this Document ...........................................................................................................16
Contacting Allied Telesis..................................................................................................................................17
Chapter 1: Overview of the Chassis and Power Supplies .........................................................................19
SBx3106 Chassis.............................................................................................................................................20
Slots for the Ethernet Line and Controller Cards..............................................................................................23
Power Supplies and Power Supply Slots .........................................................................................................24
LEDs ..........................................................................................................................................................26
AT-SBxFAN06 Module.....................................................................................................................................29
LED............................................................................................................................................................29
Power Supply Interfaces (Opto-couplers).........................................................................................................30
LED............................................................................................................................................................30
Chapter 2: Overview of the Ethernet Line Cards ........................................................................................31
Ethernet Line Cards..........................................................................................................................................32
AT-SBx31GT24 Line Card................................................................................................................................33
LEDs ..........................................................................................................................................................33
AT-SBx31GT40 Line Card................................................................................................................................35
LEDs ..........................................................................................................................................................36
AT-SBx31GP24 PoE Line Card........................................................................................................................38
LEDs ..........................................................................................................................................................39
AT-SBx31GS24 SFP Line Card .......................................................................................................................41
LEDs ..........................................................................................................................................................41
AT-SBx31GC40 Line Card ...............................................................................................................................43
Port Numbers.............................................................................................................................................44
LEDs ..........................................................................................................................................................46
AT-SBx31XZ4 XFP Line Card..........................................................................................................................49
LEDs ..........................................................................................................................................................49
AT-SBx31XS6 SFP+ Line Card........................................................................................................................51
LEDs ..........................................................................................................................................................51
10/100/1000Base-T Twisted Pair Ports............................................................................................................53
Connector Type..........................................................................................................................................53
Speed.........................................................................................................................................................53
Duplex Mode..............................................................................................................................................53
Maximum Distance.....................................................................................................................................54
Cable Requirements ..................................................................................................................................54
Automatic MDIX Detection.........................................................................................................................55
Straight-through or Crossover Cabling.......................................................................................................55
Port Pinouts................................................................................................................................................56
Power over Ethernet on the AT-SBx31GP24 Line Card...................................................................................57
Powered Device Classes...........................................................................................................................57
Power Budgeting........................................................................................................................................58
PoE Wiring.................................................................................................................................................58
Contents

Contents
6
Chapter 3: Overview of the AT-SBx31CFC960 Controller Fabric Card .................................................... 61
Controller Fabric Cards for the AT-SBx3106 Chassis...................................................................................... 62
Hardware Components on the AT-SBx31CFC960 Card..................................................................................64
Guidelines........................................................................................................................................................ 66
Dual Controller Cards ...................................................................................................................................... 68
SYS Status LEDs............................................................................................................................................. 69
eco-friendly Button........................................................................................................................................... 70
SBx Linecard Status LEDs............................................................................................................................... 71
SFP+ Slots....................................................................................................................................................... 72
Console (RS-232) Port..................................................................................................................................... 73
NET MGMT Port .............................................................................................................................................. 74
NET MGMT Port LED................................................................................................................................ 76
USB Port.......................................................................................................................................................... 77
Reset Button .................................................................................................................................................... 78
Release Activation and Feature Licenses........................................................................................................ 80
Chapter 4: Safety Precautions and Site Preparation ................................................................................. 81
Reviewing Safety Precautions ......................................................................................................................... 82
Selecting a Site for the SwitchBlade x3106 ..................................................................................................... 86
Installation Tools and Material ......................................................................................................................... 88
Chapter 5: Installing the Chassis on a Table or in an Equipment Rack .................................................. 89
Unpacking the AT-SBx3106 Chassis............................................................................................................... 90
Installing the Chassis on a Table..................................................................................................................... 92
Installing the Chassis in an Equipment Rack................................................................................................... 93
Required Tools and Material ..................................................................................................................... 93
Preparing the Equipment Rack.................................................................................................................. 93
Removing the Rubber Feet ....................................................................................................................... 95
Adjusting the Equipment Rack Brackets ................................................................................................... 96
Installing the Chassis in the Equipment Rack ........................................................................................... 99
Removing the Shipping Brace ....................................................................................................................... 102
Installing the Chassis Grounding Lug ............................................................................................................ 103
Chapter 6: Installing the Power Supplies ................................................................................................. 105
Protecting Against Electrostatic Discharge (ESD) ......................................................................................... 106
Installing the AT-SBxPWRSYS1 or AT-SBxPWRSYS2 AC System Power Supply....................................... 107
Installing the AT-SBxPWRPOE1 AC Power Supply ...................................................................................... 113
Installing the AT-SBxPWRSYS1 DC System Power Supply.......................................................................... 118
Chapter 7: Installing the AT-SBx31CFC960 Card and Ethernet Line Cards .......................................... 125
Guidelines to Handling the Controller and Line Cards................................................................................... 126
Installing the AT-SBx31CFC960 Controller Fabric Card................................................................................ 128
Installing the Ethernet Line Cards.................................................................................................................. 134
Installing the Blank Slot Covers ..................................................................................................................... 138
Chapter 8: Installing the Transceivers and Cabling the Ports ................................................................ 141
Guidelines to Cabling the Twisted Pair Ports on AT-SBx31GP24, AT-SBx31GT24, and AT-SBx31GT40
Line Cards...................................................................................................................................................... 142
Connecting Cables to the AT-SBx31GT40 Line Card............................................................................. 143
Guidelines to Installing SFP, SFP+, CSFP, and XFP Transceivers............................................................... 145
Installing SFP Transceivers in the AT-SBx31GS24 Line Card ...................................................................... 146
Installing SFP and CSFP Transceivers in the AT-SBx31GC40 Line Card..................................................... 149
Installing SFP+ Transceivers in the AT-SBx31XS6 Line Card.......................................................................154
Installing AT-SP10TW Cables in the AT-SBx31XS6 Line Card..................................................................... 158
Installing XFP Transceivers in the AT-SBx31XZ4 Line Card......................................................................... 160
Cabling the NET MGMT Port on the AT-SBx31CFC960 Card....................................................................... 164
Installing SFP or SFP+ Transceivers in the AT-SBx31CFC960 Card............................................................ 166

SwitchBlade x3106 Chassis Switch and AT-SBx31CFC960 Card Installation Guide
7
Chapter 9: Powering On the Chassis ........................................................................................................171
Verifying the Installation .................................................................................................................................172
Powering On the AT-SBxPWRSYS1 or AT-SBxPWRSYS2 AC System Power Supply ................................173
Powering on the AT-SBxPWRPOE1 AC PoE Power Supply .........................................................................176
Powering On the AT-SBxPWRSYS1 DC System Power Supply ...................................................................179
Choosing a Method for Attaching the Grounding Wire.............................................................................181
Connecting the Grounding Wire with the Grounding Terminal.................................................................181
Connecting the Grounding Wire with Bare Wire ......................................................................................184
Choosing a Method for Attaching the Power Wires .................................................................................185
Connecting the DC Power Wires with the Straight Terminals..................................................................186
Connecting the DC Power Wires with the Right Angle Terminals............................................................193
Connecting Bare DC Power Wires...........................................................................................................199
Monitoring the Initialization Process...............................................................................................................203
Using the LEDs to Monitor the Initialization Process ...............................................................................204
Using the Console Port to Monitor the Initialization Process ...................................................................205
Chapter 10: Verifying the Hardware Operations of the Chassis .............................................................209
Using the LEDs to Verify the Chassis.............................................................................................................210
Using Local Management to Verify the Chassis.............................................................................................212
Starting a Local Management Session ....................................................................................................212
Entering the Management Software Commands.....................................................................................213
Running the Easy Startup Application............................................................................................................216
Chapter 11: Upgrading to the AT-SBx31CFC960 Card from the AT-SBx31CFC Card ..........................221
Guidelines.......................................................................................................................................................222
Upgrading the Controller Fabric Cards...........................................................................................................223
Chapter 12: Troubleshooting .....................................................................................................................227
AT-SBxPWRSYS1, AT-SBxPWRSYS2, or AT-SBxPWRPOE1 AC Power Supply........................................228
AT-SBxPWRSYS1 DC System Power Supply...............................................................................................230
Ethernet Line Cards........................................................................................................................................232
Twisted Pair Ports ..........................................................................................................................................234
Power Over Ethernet......................................................................................................................................236
Fiber Optic Transceivers ................................................................................................................................238
AT-SBx31CFC960 Controller Fabric Card .....................................................................................................240
AT-SBxFAN06 Fan Module............................................................................................................................243
Local (Out-of-Band) Management Session....................................................................................................244
Power Supply Interfaces (Opto-couplers).......................................................................................................245
Chapter 13: Replacing Modules .................................................................................................................247
Replacing the AT-SBxPWRSYS1, AT-SBxPWRSYS2, or AT-SBxPWRPOE1 AC Power Supply.................248
Replacing the AT-SBxPWRSYS1 DC Power Supply .....................................................................................254
Replacing Ethernet Line Cards.......................................................................................................................266
Replacing the AT-SBx31CFC960 Controller Fabric Card ..............................................................................269
Replacing the AT-SBxFAN06 Fan Module.....................................................................................................272
Removing the AT-SBxFAN06 Fan Module ..............................................................................................272
Installing a New AT-SBxFAN06 Fan Module...........................................................................................275
Appendix A: Technical Specifications ......................................................................................................279
Physical Specifications...................................................................................................................................279
Environmental Specifications .........................................................................................................................281
Power Specifications......................................................................................................................................282
Safety and Electromagnetic Emissions Certifications ....................................................................................285
Port Pinouts....................................................................................................................................................286

Contents
8

9
Figures
Figure 1: AT-SBx3106 Chassis....................................................................................................................... 20
Figure 2: Front View of the AT-SBx3106 Chassis........................................................................................... 21
Figure 3: Rear View of the AT-SBx3106 Chassis............................................................................................ 21
Figure 4: AT-SBx3106 Chassis with Line Cards, Controller Cards, and Power Supplies ............................... 22
Figure 5: Slots for the Ethernet Line and Controller Cards.............................................................................. 23
Figure 6: Power Supply Units.......................................................................................................................... 24
Figure 7: Power Supply Slots.......................................................................................................................... 25
Figure 8: AT-SBxFAN06 Module..................................................................................................................... 29
Figure 9: Power Supply Interfaces (Opto-couplers) ........................................................................................ 30
Figure 10: Ethernet Line Cards ....................................................................................................................... 32
Figure 11: AT-SBx31GT24 Line Card ............................................................................................................. 33
Figure 12: Port LEDs on the AT-SBx31GT24 Line Card................................................................................. 34
Figure 13: AT-SBx31GT40 Line Card ............................................................................................................. 35
Figure 14: Port LEDs on an RJ Point 5 Cable Connector for the AT-SBx31GT40 Line Card ......................... 36
Figure 15: Link/Activity LED on an RJ Point 5 Cable Connector for the AT-SBx31GT40 Line Card............... 36
Figure 16: AT-SBx31GP24 PoE Line Card ..................................................................................................... 38
Figure 17: Port LEDs on the AT-SBx31GP24 PoE Line Card......................................................................... 39
Figure 18: AT-SBx31GS24 SFP Line Card..................................................................................................... 41
Figure 19: Port LEDs on the AT-SBx31GS24 SFP Line Card......................................................................... 42
Figure 20: AT-SBx31GC40 Line Card............................................................................................................. 43
Figure 21: Port Numbers for Slots with CSFP Transceivers ........................................................................... 45
Figure 22: Port Numbers for Slots with Standard SFP Transceivers .............................................................. 46
Figure 23: LEDs for the AT-SBx31GC40 Line Card........................................................................................ 46
Figure 24: LEDs for the AT-SBx31GC40 Line Card, with CSFP Transceivers ............................................... 47
Figure 25: LEDs for the AT-SBx31GC40 Line Card, with SFP Transceivers.................................................. 47
Figure 26: AT-SBx31XZ4 XFP Line Card........................................................................................................ 49
Figure 27: Transceiver Slot LEDs on the AT-SBx31XZ4 XFP Line Card........................................................ 50
Figure 28: AT-SBx31XS6 Line Card................................................................................................................ 51
Figure 29: SFP+ Slot LEDs on the AT-SBx31XS6 Line Card.......................................................................... 52
Figure 30: Controller Fabric Cards for the AT-SBx3106 Chassis.................................................................... 62
Figure 31: AT-SBx31CFC960 Controller Fabric Card ..................................................................................... 64
Figure 32: 100 - 125 VAC 125 V NEMA 5-20 Plug and Receptacle................................................................ 87
Figure 33: AT-SBx3106 Chassis Items ........................................................................................................... 90
Figure 34: AT-SBx3106 Chassis Items (Continued)........................................................................................ 91
Figure 35: Reserving Vertical Rack Space...................................................................................................... 94
Figure 36: Rack Mounting Hole Locations....................................................................................................... 95
Figure 37: Turning the Chassis Upside Down................................................................................................. 96
Figure 38: Removing the Rubber Feet ............................................................................................................ 96
Figure 39: Rack Mounting Bracket Locations.................................................................................................. 98
Figure 40: Rack Bracket Locations for Reverse Position of Chassis .............................................................. 98
Figure 41: Lifting the AT-SBx3106 Chassis into the Equipment Rack .......................................................... 100
Figure 42: Installing the Rack Mount Screws................................................................................................ 100
Figure 43: Tightening the Rack Mount Screws.............................................................................................. 101
Figure 44: Removing the Shipping Brace...................................................................................................... 102
Figure 45: Stripping the Grounding Wire....................................................................................................... 103

List of Figures
10
Figure 46: Removing the Grounding Lug....................................................................................................... 103
Figure 47: Attaching the Grounding Wire to the Grounding Lug.................................................................... 104
Figure 48: Installing the Grounding Lug and Wire ......................................................................................... 104
Figure 49: ESD Socket and Wrist Strap......................................................................................................... 106
Figure 50: Power Supply Slots....................................................................................................................... 107
Figure 51: Removing the Blank Slot Cover from Power Supply Slot C.......................................................... 108
Figure 52: Items Included with the AT-SBxPWRSYS1 or AT-SBxPWRSYS2 AC System Power Supply..... 109
Figure 53: Raising the Handle on the Power Supply ..................................................................................... 110
Figure 54: Inserting the AT-SBxPWRSYS1 AC or AT-SBxPWRSYS2 Power Supply................................... 110
Figure 55: Lowering the Handle on the AT-SBxPWRSYS1 or AT-SBxPWRSYS2 AC Power Supply........... 111
Figure 56: Removing the Blank Slot Cover from Power Supply Slot A.......................................................... 113
Figure 57: Items Included with the AT-SBxPWRPOE1 Power Supply Module.............................................. 114
Figure 58: Raising the Handle on the AT-SBxPWRPOE1 AC Power Supply................................................ 115
Figure 59: Inserting the AT-SBxPWRPOE1 AC Power Supply...................................................................... 115
Figure 60: Locking the Handle on the AT-SBxPWRPOE1 AC Power Supply................................................ 116
Figure 61: Removing the Blank Slot Cover from Power Supply Slot C.......................................................... 119
Figure 62: Items Included with the AT-SBxPWRSYS1 DC System Power Supply Module........................... 120
Figure 63: Loosening the Handle locking Screw on the AT-SBxPWRPOE1 DC System Power Supply....... 121
Figure 64: Raising the Handle on the AT-SBxPWRPOE1 DC System Power Supply................................... 121
Figure 65: Inserting the AT-SBxPWRSYS1 DC System Power Supply......................................................... 122
Figure 66: Locking the Handle on the AT-SBxPWRSYS1 DC System Power Supply................................... 123
Figure 67: Aligning a Card in a Slot ............................................................................................................... 127
Figure 68: Slots 4 and 5 for the AT-SBx31CFC960 Card.............................................................................. 128
Figure 69: Items Included with the AT-SBx31CFC960 Controller Fabric Card.............................................. 129
Figure 70: Removing the AT-SBx31CFC960 Controller Fabric Card from the Anti-static Bag...................... 129
Figure 71: Removing the Battery Insulator .................................................................................................... 130
Figure 72: Opening the Locking Handles on the AT-SBx31CFC960 Controller Fabric Card......................... 130
Figure 73: Aligning the AT-SBx31CFC960 Card in the Chassis Slot............................................................. 131
Figure 74: Closing the Locking Levers on the AT-SBx31CFC960 Controller Fabric Card............................. 132
Figure 75: Tightening the Thumb Screws on the AT-SBx31CFC960 Card.................................................... 133
Figure 76: Removing an Ethernet Line Card from an Anti-static Bag............................................................ 135
Figure 77: Aligning an Ethernet Line Card in a Chassis Slot......................................................................... 135
Figure 78: Seating an Ethernet Line Card on the Backplane Connector....................................................... 136
Figure 79: Tightening the Thumb Screws on an Ethernet Line Card............................................................. 137
Figure 80: Installing a Blank Slot Cover......................................................................................................... 138
Figure 81: Tightening the Thumbscrews on a Blank Slot Cover.................................................................... 139
Figure 82: RJ Point 5 Cable Connector for AT-SBx31GT40 Line Card......................................................... 143
Figure 83: Connecting Cables to Ports on the AT-SBx31GT40 Line Card.................................................... 144
Figure 84: Removing the Dust Cover from an SFP Slot in the AT-SBx31GS24 Line Card ........................... 146
Figure 85: Handle on SFP Transceiver.......................................................................................................... 146
Figure 86: Inserting an SFP Transceiver in the AT-SBx31GS24 Line Card .................................................. 147
Figure 87: Removing the Dust Cover from the SFP Transceiver in the AT-SBx31GS24 Line Card.............. 147
Figure 88: Attaching a Fiber Optic Cable to an SFP Transceiver in the AT-SBx31GS24 Line Card............. 148
Figure 89: Removing the Dust Cover from a Transceiver Slot on the AT-SBx31GC40 Line Card................ 149
Figure 90: Labels on SFP and CSFP Transceivers....................................................................................... 150
Figure 91: Inserting an SFP or a CSFP Transceiver...................................................................................... 150
Figure 92: Removing the Dust Cover from an SFP or a CSFP Transceiver.................................................. 151
Figure 93: Attaching a Fiber Optic Cable....................................................................................................... 152
Figure 94: Removing a Dust Cover From an SFP+ Slot in the AT-SBx31XS6 Line Card ............................. 154
Figure 95: Handle on SFP+ Transceiver........................................................................................................ 155
Figure 96: Installing an SFP+ Transceiver in the AT-SBx31XS6 Line Card.................................................. 155
Figure 97: Removing the Dust Cover from an SFP+ Transceiver in the AT-SBx31XS6 Line Card............... 156
Figure 98: Attaching a Fiber Optic Cable to an SFP+ Transceiver in the AT-SBx31XS6 Line Card ............. 157
Figure 99: Release Tab on the AT-SBx31XS6 Line Card.............................................................................. 158
Figure 100: Installing the AT-SP10TW Cable in the AT-SBx31XS6 Line Card.............................................. 159

SwitchBlade x3106 Chassis Switch and AT-SBx31CFC960 Card Installation Guide
11
Figure 101: Removing the Dust Cover From an XFP Slot on the AT-SBx31XZ4 Line Card......................... 160
Figure 102: Handle on the XFP Transceiver ................................................................................................. 161
Figure 103: Installing an XFP Transceiver in the AT-SBx31XZ4 Line Card.................................................. 161
Figure 104: Removing the Protective Cover from an XFP Transceiver in the AT-SBx31XZ4 Line Card...... 162
Figure 105: Attaching a Fiber Optic Cable to an XFP Transceiver in the AT-SBx31XZ4 Line Card ............. 163
Figure 106: Removing a Dust Cover from a Transceiver Slot in the AT-SBx31CFC960 Controller Fabric
Card............................................................................................................................................................... 166
Figure 107: Handle on an SFP or SFP+ Transceiver.................................................................................... 167
Figure 108: Installing an SFP or SFP+ Transceiver in the AT-SBx31CFC960 Controller Fabric Card......... 167
Figure 109: Removing the Dust Cover from an SFP or SFP+ Transceiver in the AT-SBx31CFC960
Controller Fabric Card................................................................................................................................... 168
Figure 110: Attaching a Fiber Optic Cable to an SFP or SFP+ Transceiver in the AT-SBx31CFC960
Controller Fabric Card................................................................................................................................... 168
Figure 111: AC Sockets on the AT-SBx3106 Chassis Rear Panel ............................................................... 173
Figure 112: Connecting the AC Power Cord for the AT-SBxPWRSYS1 or AT-SBxPWRSYS2 AC System
Power Supply ................................................................................................................................................ 174
Figure 113: Securing the Power Cord for the AT-SBxPWRSYS1 or AT-SBxPWRSYS2 AC System Power
Supply to an Anchor...................................................................................................................................... 175
Figure 114: Connecting the AC Power Cord for the AT-SBxPWRPOE1 Power Supply ............................... 176
Figure 115: Securing the Power Cord for the AT-SBxPWRPOE1 Power Supply to an Anchor.................... 177
Figure 116: Dress and Secure AC Power Cords........................................................................................... 178
Figure 117: Components of the AT-SBxPWRSYS1 DC Power Supply......................................................... 180
Figure 118: Grounding Wire Terminal........................................................................................................... 181
Figure 119: Stripping the Stranded Grounding Wire ..................................................................................... 181
Figure 120: Attaching the Stranded Grounding Wire to the Grounding Terminal.......................................... 181
Figure 121: Removing the Nut and Washer from the Grounding Post.......................................................... 182
Figure 122: Installing the Grounding Wire..................................................................................................... 183
Figure 123: Stripping the solid or Stranded Grounding Wire......................................................................... 184
Figure 124: Attaching the Bare Grounding Wire to the Grounding Post........................................................ 184
Figure 125: Securing the Bare Grounding Wire to the Grounding Post ........................................................ 185
Figure 126: Power Wire Terminals................................................................................................................ 185
Figure 127: Stripping the Power Wires.......................................................................................................... 186
Figure 128: Attaching the Power Wires to the Power Terminal Lugs............................................................ 187
Figure 129: On/Off Switch On the AT-SBxPWRSYS1 DC Power Supply..................................................... 187
Figure 130: Opening the Plastic Cover.......................................................................................................... 188
Figure 131: Removing the Terminal Screws ................................................................................................. 188
Figure 132: Connecting the Positive (+) Power Wire with a Straight Terminal.............................................. 189
Figure 133: Connecting the Negative (-) Power Wire with a Straight Terminal............................................. 190
Figure 134: Closing the Plastic Cover over the Terminal Connectors........................................................... 191
Figure 135: Tightening the Handle Locking Screw........................................................................................ 192
Figure 136: Stripping the Power Wires.......................................................................................................... 193
Figure 137: Attaching the Power Wires to the Right Angle Terminals........................................................... 193
Figure 138: Removing the Plastic Cover....................................................................................................... 194
Figure 139: Removing the Terminal Screws ................................................................................................. 195
Figure 140: Connecting the Positive (+) Power Wire with a Right Angle Terminal........................................ 196
Figure 141: Connecting the Negative (-) Power Wire with a Right Angle Terminal....................................... 197
Figure 142: Tightening the Handle Locking Screw........................................................................................ 198
Figure 143: Stripping Solid or Stranded DC Power Wires............................................................................. 199
Figure 144: Connecting the Positive Wire..................................................................................................... 200
Figure 145: Connecting the Negative Lead Wire........................................................................................... 201
Figure 146: Switch Initialization Messages.................................................................................................... 205
Figure 147: Switch Initialization Messages (Continued)................................................................................ 206
Figure 148: Switch Initialization Messages (Continued)................................................................................ 207
Figure 149: Connecting the Management Cable to the Console RS-232 Port.............................................. 212
Figure 150: SHOW PSU Command .............................................................................................................. 213

List of Figures
12
Figure 151: SHOW FANMODULE Command................................................................................................ 214
Figure 152: SHOW CARD Command............................................................................................................ 214
Figure 153: Disconnecting the AC Power Cord from the AC Socket on the Back Panel............................... 249
Figure 154: Lifting the Locking Handle on the Power Supply ........................................................................ 250
Figure 155: Removing the Power Supply from the Chassis........................................................................... 251
Figure 156: Installing a Blank Power Supply Slot Cover................................................................................ 252
Figure 157: Lowering the Locking Handle on the Power Supply Slot Cover.................................................. 253
Figure 158: Loosening the Screw on the Locking Handle ............................................................................. 255
Figure 159: Opening the Plastic Window on the Terminal Block................................................................... 256
Figure 160: Removing the Negative Lead Wire............................................................................................. 257
Figure 161: Removing the Positive Lead Wire from the Terminal Block........................................................ 258
Figure 162: Reinstalling the Screws on the Positive and Negative Terminals............................................... 259
Figure 163: Closing the Plastic Cover............................................................................................................ 260
Figure 164: Removing the Grounding Wire ................................................................................................... 261
Figure 165: Reinstalling the Nut and Washer on the Grounding Post ........................................................... 262
Figure 166: Lifting the Locking Handle and Removing the Power Supply..................................................... 263
Figure 167: Installing a Blank Power Supply Slot Cover................................................................................ 264
Figure 168: Lowering the Locking Handle on the Power Supply Slot Cover.................................................. 265
Figure 169: Loosening the Screw on the AT-SBxFAN06 Fan Module........................................................... 273
Figure 170: Loosening the AT-SBxFAN06 Fan Module from the Backplane Connector............................... 273
Figure 171: Withdrawing the AT-SBxFAN06 Fan Module 25 mm (1 in.) from the Chassis ........................... 274
Figure 172: Removing the AT-SBxFAN06 Fan Module from the Chassis..................................................... 275
Figure 173: Installing a New AT-SBxFAN06 Fan Module.............................................................................. 276
Figure 174: Securing the AT-SBxFAN06 Fan Module on the Backplane Connector..................................... 277
Figure 175: Tightening the Screw on the AT-SBxFAN06 Fan Module........................................................... 277
Figure 176: Pin Numbers for RJ-45 and RJ Point 5 Ports ............................................................................. 286

13
Table 1. LEDs on the AT-SBxPWRSYS1 and AT-SBxPWRSYS2 AC System Power Supplies .................... 27
Table 2. LEDs on the AT-SBxPWRSYS1 DC System Power Supply ............................................................ 27
Table 3. LEDs on the AT-SBxPWRPOE1 AC PoE Power Supply ................................................................. 28
Table 4. AT-SBxFAN06 Module LED ............................................................................................................. 29
Table 5. Power Supply Interface LED ............................................................................................................ 30
Table 6. Port LEDs on the AT-SBx31GT24 Line Card ................................................................................... 34
Table 7. Port LEDs for the AT-SBx31GT40 Line Card ................................................................................... 37
Table 8. Port LEDs on the AT-SBx31GP24 PoE Line Card ........................................................................... 39
Table 9. Port LEDs on the AT-SBx31GS24 SFP Line Card ........................................................................... 42
Table 10. Transceiver Slot LEDs on the AT-SBx31GC40 Line Card ............................................................. 48
Table 11. Transceiver Slot LEDs on the AT-SBx31XZ4 XFP Line Card ........................................................ 50
Table 12. SFP+ Slot LEDs on the AT-SBx31XS6 Line Card .......................................................................... 52
Table 13. Twisted Pair Cable for the AT-SBx31GT24 and AT-SBx31GT40 Line Cards ................................ 54
Table 14. Twisted Pair Cable for the AT-SBx31GP24 Line Card ...................................................................55
Table 15. IEEE802.3af and IEEE802.3at Powered Device Classes .............................................................. 57
Table 16. Maximum Number of Powered Devices ......................................................................................... 58
Table 17. Differences Between the AT-SBx31CFC and AT-SBx31CFC960 Controller Fabric Cards ............ 62
Table 18. Components on the AT-SBx31CFC960 Controller Fabric Card ..................................................... 64
Table 19. SYS (System) Status LEDs ............................................................................................................ 69
Table 20. SBx Linecard Status LEDs ............................................................................................................. 71
Table 21. LEDs for the SFP+ Slots on the AT-SBx31CFC960 Controller Card ............................................. 72
Table 22. Management Features Requiring Network Access ........................................................................74
Table 23. NET MGMT Port LED ..................................................................................................................... 76
Table 24. Front Panel to Rack Rail Dimensions ............................................................................................. 97
Table 25. Switch Initialization Phases .......................................................................................................... 204
Table 26. Product Dimensions ..................................................................................................................... 279
Table 27. Product Weights ........................................................................................................................... 279
Table 28. Environmental Specifications ....................................................................................................... 281
Table 29. Acoustic Noise Test Components ................................................................................................ 281
Table 30. AC Voltage and Frequency Requirements ................................................................................... 282
Table 31. DC Voltage Requirement .............................................................................................................. 282
Table 32. Typical Power Savings in eco-friendly Mode ................................................................................ 282
Table 33. Maximum Power Consumption ..................................................................................................... 282
Table 34. Maximum Power Efficiency .......................................................................................................... 283
Table 35. Heat Dissipation ........................................................................................................................... 283
Table 36. Available Power Over Ethernet with One PoE Power Supply ...................................................... 284
Table 37. Available Power Over Ethernet with Two PoE Power Supplies ................................................... 284
Table 38. PoE Mode ..................................................................................................................................... 284
Table 39. Safety and Electromagnetic Emissions ........................................................................................ 285
Table 40. MDI Pin Signals (10Base-T or 100Base-TX) ................................................................................ 286
Table 41. MDI-X Pin Signals (10Base-T or 100Base-TX) ............................................................................ 286
Table 42. 1000Base-T Connector Pinouts ................................................................................................... 287
Tables

List of Tables
14

15
Preface
This guide contains the hardware installation instructions for the
SwitchBlade x3106 switch. This preface contains the following sections:
“Safety Symbols Used in this Document” on page 16
“Contacting Allied Telesis” on page 17
Note
This version of the installation guide applies to release 6.18.0.2 or
later of the AlliedWareNSP Management Software. The latest
release of the management software is available from the Restricted
Software Downloads web page on the Allied Telesis web site, at
www.alliedtelesis.com/support/software/restricted.

Preface
16
Safety Symbols Used in this Document
This document uses the following conventions.
Note
Notes provide additional information.
Caution
Cautions inform you that performing or omitting a specific action
may result in equipment damage or loss of data.
Warning
Warnings inform you that performing or omitting a specific action
may result in bodily injury.
Warning
Laser warnings inform you that an eye or skin hazard exists due to
the presence of a Class 1 laser device.
Warning
Fan warnings inform you of danger from hazardous moving fan
blades.

SwitchBlade x3106 Chassis Switch and AT-SBx31CFC960 Card Installation Guide
17
Contacting Allied Telesis
If you need assistance with this product, you may contact Allied Telesis
technical support by going to the Support & Services section of the Allied
Telesis web site at www.alliedtelesis.com/support. You can find links for
the following services on this page:
24/7 Online Support — Enter our interactive support center to
search for answers to your product questions in our knowledge
database, to check support tickets, to learn about RMAs, and to
contact Allied Telesis technical experts.
USA and EMEA phone support — Select the phone number that
best fits your location and customer type.
Hardware warranty information — Learn about Allied Telesis
warranties and register your product online.
Replacement Services — Submit a Return Merchandise
Authorization (RMA) request via our interactive support center.
Documentation — View the most recent installation and user
guides, software release notes, white papers, and data sheets for
your products.
Software Downloads — Download the latest software releases for
your managed products.
For sales or corporate information, go to www.alliedtelesis.com/
purchase.

Preface
18

19
Chapter 1
Overview of the Chassis and Power
Supplies
This chapter contains an overview of the hardware components of the AT-
SBx3106 Chassis and power supplies. The sections in the chapter are
listed here:
“SBx3106 Chassis” on page 20
“Slots for the Ethernet Line and Controller Cards” on page 23
“Power Supplies and Power Supply Slots” on page 24
“AT-SBxFAN06 Module” on page 29
“Power Supply Interfaces (Opto-couplers)” on page 30
Note
This version of the installation guide applies to release 6.18.0.2 or
later of the AlliedWareNSP Management Software. The latest
release of the management software is available from the Restricted
Software Downloads web page on the Allied Telesis web site, at
www.alliedtelesis.com/support/software/restricted.

Chapter 1: Overview of the Chassis and Power Supplies
20
SBx3106 Chassis
The SBx3106 product is a modular Gigabit and 10 Gigabit Ethernet
switch. The main components are the AT-SBx3106 Chassis, Ethernet
cards, a controller card, a system power supply, a Power over Ethernet
Plus (PoE+) power supply, and a fan module.
The chassis is shown in Figure 1.
Figure 1. AT-SBx3106 Chassis
The chassis has slots for the following components:
Four or five Ethernet line cards
Two AT-SBx31CFC960 Controller Fabric Cards
Two AC or DC system power supplies
Two Power over Ethernet Plus (PoE+) power supplies
One AT-SBxFAN06 Fan Module
Note
The maximum number of Ethernet line cards depends on the
number of controller cards. The chassis can accommodate four
Ethernet line cards when there are two controller cards in the unit
and five Ethernet line cards when there is one controller card.
The chassis components are identified in Figure 2 on page 21 and Figure
3 on page 21.
