Software Maintenance Release Note
Version 89273-02
for AT-8900 and AT-9900 series switches
Introduction
This release note lists the issues addressed and enhancements made in version
89273-02 for Software Release 2.7.3 on existing models of AT-8900 and AT-9900
series switches. File details are listed in Table 1.
This release note should be read in conjunction with the following documents:
■Release Note: Software Release 2.7.3 for AT-9900, AT-8900, SwitchBlade,
AT-9800, AT-8800, Rapier, Rapier i, AT-8700XL, and AT-8600 Series
Switches and AR400 and AR700 Series Routers (Document Number C613-
10431-00 REV A) available from www.alliedtelesyn.com
■AT-8900 series switch Documentation Set for Software Release 2.6.2
available on the Documentation and Tools CD-ROM packaged with your
switch, or from www.alliedtelesyn.co.nz/documentation/documentation.html.
■AT-9900 series switch Documentation Set for Software Release 2.6.6
available on the Documentation and Tools CD-ROM packaged with your
switch, or from www.alliedtelesyn.com.
WARNING: Using a maintenance release for a different model or software
release may cause unpredictable results, including disruption to the network.
Information in this release note is subject to change without notice and does
not represent a commitment on the part of Allied Telesyn International. While
every effort has been made to ensure that the information contained within this
document and the features and changes described are accurate, Allied Telesyn
International can not accept any type of liability for errors in, or omissions
arising from the use of this information.
Table 1: File details for version 89273-02.
Base Software Release File 89-273.rez
Release Date 29 April 2005
Compressed File Name 89273-02.rez
Compressed File Size 4263880 bytes

2Patch Release Note
Software Maintenance Release note for Software Release 2.7.3
C613-10443-00 REV A
Some of the issues addressed in this Release Note include a level number. This
number reflects the importance of the issue that has been resolved. The levels
are:
Enabling and installing this Release
To use this maintenance release you must have a base release license for
Software Release 2.7.3. Contact your distributor or reseller for more
information.
To enable this release and install it as the preferred release, use the commands:
enable rel=89273-02.rez num=2.7.3
set install=pref rel=89273-02.rez
Features in 89273-02
Patch 89273-02 includes the following enhancements and resolved issues:
Level 1
A heavy processor load could lead to queuing RSTP BPDUs, which in turn
could lead to even more processor load, resulting in more queued BPDUs.
This issue has been resolved by improving the efficiency in the interaction
between RSTP TCN BPDUs and the hardware tables.
This issue has been resolved. (PCR number: 40672)
When failover occurred between a redundant pair of Load Balancing
devices, host ARP caches were not updated with the new Master's MAC
address, thus causing the hosts to lose connectivity until their ARP caches
timed out the stale entry. This issue has been resolved. (No PCR number.)
A reboot could occur while ageing out Firewall sessions when the device
was under heavy load and had many active Firewall sessions.
This issue has been resolved. (No PCR number.)
Level 1 This issue will cause significant interruption to network services, and
there is no work-around.
Level 2 This issue will cause interruption to network service, however there
is a work-around.
Level 3 This issue will seldom appear, and will cause minor inconvenience.
Level 4 This issue represents a cosmetic change and does not affect network
operation.
CR00005227 Module: SWI, RSTP, SWMX,
SWCX, SW56
Level: 1
CR00006609 Module: LB Level: 1
CR00007034 Module: Firewall Level: 1

Version 89273-02 for AT-8900 and AT-9900 series switches 3
Software Maintenance Release note for Software Release 2.7.3
C613-10443-00 REV A
When either the Firewall was enabled or multiple L2TP tunnels were
configured, and a default route existed over an L2TP tunnel, it was possible
for an infinite internal packet loop to be created when a packet was sent
over the L2TP tunnel after the underlying interface route to the remote IP
had gone down. This caused a reboot to occur.
This issue has been resolved. (No PCR number.)
Level 2
Previously, the forwarding database was flushed instead of being aged out
when an STP topology change notification was received.
This issue has been resolved. (PCR number: 40185)
Previously, when a port or ports was moved from one VLAN to another, the
switch would reset both STP/RSTP instances that control the VLANs. This
behaviour is now changed to only reset the STP process on the STP instance
that the port(s) is joining. The switch will now also retain the port(s) edge-
port setting during the moving process.
This issue has been resolved.
A switch, lock-up could occur after enabling the use of QoS Counters via the
command SET SWITCH ENHANCEDMODE=QOSCOUNTERS.
This issue has been resolved.
When IP NAT was configured, a restart could occur if a TCP RST packet was
received with flags in addition to ACK.
This issue has been resolved.( PCR number: 40728)
The "SET IPV6 MLD ?" command was not displaying the correct parameters
on the command-line.
This issue has been resolved.
PPP TCP mss clamping was always fixing the mss to 1372. This issue is now
fixed, so that if the MTU or MRU is less than 1472, then mss clamping
clamps the mss to the correct size.
This issue has been resolved.
PPPoE has been modified so that a single host can be attached to multiple
access concentrators without a conflict of session ID's.
CR00007695 Module: PPP Level: 1
CR00002290 Module: STP, SWI Level: 2
CR00002662 Module: STP Level: 2
CR00004964 Module: CORE, PSS, QOS, SWI
SWMX,
Level: 2
CR00005983 Module: IPNAT Level: 2
CR00006521 Module: IPv6 Level: 2
CR00006554 Module: PPP Level: 2
CR00006769 Module: PPP Level: 2

4Patch Release Note
Software Maintenance Release note for Software Release 2.7.3
C613-10443-00 REV A
A change was made in the 2.6.1 software release to reset the PPP idle timer
for received traffic as well as transmitted traffic to avoid a PPP link idling
out when receiving unidirectional traffic. However, this has undesirable
side effects as it is not possible to control the received traffic. This change
has been removed. Users can avoid a PPP link idling out for received
unidirectional traffic by setting the value of the IDLE parameter to OFF, or
in the case of received multicast traffic, setting the IDLE parameter to a
value greater than the multicast hello timer.
When PPP was configured over L2TP over PPPoE, and the firewall was
enabled, a restart could occur in some circumstances.
This issue has been resolved.
If RIP was configured to explicitly exchange packets with a neighbour in
another subnet, the RIP packets from that neighbour were dropped.
This issue has been resolved.
When routers and switches were using CIDR addressing, with a unicast
address coinciding with a network broadcast address of class A, B, or C,
then they could incorrectly forward traffic as directed broadcasts, even
though the traffic was unicast (only).
This issue has been resolved. (PCR number: 50069)
When the router was acting as an L2TP Access Concentrator (LAC) it would
fail to negotiate a Virtual tunnel to another vendor’s LNS. This was due to
invalid Proxy LCP AVPs being used within the ICCN message.
This issue has been resolved. (No PCR number.)
In some 8924/9924 network configurations deploying QoS and IPMC
traffic, the QoS may have periodically miss-classified the traffic.
This issue has been resolved.
When the firewall was configured and the firewall ident proxy feature was
disabled, or if the firewall was disabled, TCP port 113 was still left open.
This issue has been resolved.
QoS was incorrectly misclassifying packets for small periods of time.
This issue has been resolved
CR00007005 Module: PPP Level: 2
CR00007078 Module: PPP Level: 2
CR00007291 Module: IPG Level: 2
CR00007341 Module: IPG Level: 2
CR00007436 Module: L2TP Level: 2
CR00007477 Module: SWMX Level: 2
CR00007493 Module: FIREWALL Level: 2
CR00007605 Module: SWMX, PSS Level: 2

Version 89273-02 for AT-8900 and AT-9900 series switches 5
Software Maintenance Release note for Software Release 2.7.3
C613-10443-00 REV A
NSSA areas were not able to form adjacencies with some other vendors’
equipment.
This has been resolved.
Some SSH Clients do not limit the length of the SSH username. Under some
special circumstances, when the AlliedWare ™ SSH server received a
username of 186 characters, the device would restart unexpectedly. This
was fixed to limit a SSH username to be less than 64 characters and
returning a failure message if the username was 64 or more characters.
Restarts could occur when the firewall parsing process was searching for
the character ‘/’ in a string.
This issue has been resolved.
Under some circumstances the SSH listen port would be closed.
This issue has been resolved.
Add firewall policy list would overwrite the low memory 0x0.
This issue has been resolved.
When a URL contains an IP address instead of a Domain name and the
inverse DNS lookup for resolving the domain name failed, the proxy server
could block the cookies incorrectly. Also the Proxy server could parse an
HTTP message incorrectly if the URL field of the HTTP message contained
non-ASCII characters.
These issues have been resolved
Triggers based on memory resource were not activated when the specified
memory level was reached.
This issue has been resolved.
The COPY command returned an error message saying the input filename
was invalid, even if a valid filename was given.
This issue has been resolved
ARP requests received that matched a static ARP entry would overwrite the
hardware switching tables for that entry. The static ARP in software (SHOW
IP ARP) would remain as defined by the user, however. Now, if an ARP
CR00007888 Module: OSPF Level: 2
CR00007948 Module: SSH Level: 2
CR00007991 Module: FIREWALL Level: 2
CR00007992 Module: SSH Level: 2
CR00008008 Module: Firewall Level: 2
CR00008068 Module: HTTP Level: 2
CR00008080 Module: TRG Level: 2
CR00008101 Module: FILE Level: 2
CR00008117 Module: IPG, VRRP Level: 2

6Patch Release Note
Software Maintenance Release note for Software Release 2.7.3
C613-10443-00 REV A
entry has been added statically, the hardware switching tables are not
updated by the dynamic ARP information.
The flash file system could sometimes have duplicate copies of a file.
This issue has been resolved.
If an IP interface was assigned its IP address dynamically, and the IP that it
was assigned matched the Network address of another interface on the
device, then the device would drop packets destined for the remotely
assigned IP interface.
This issue has been resolved. PCR40549
A reboot could occur if a device had an extremely large boot script.
This issue has been resolved
Level 3
The DNS relay has been changed to allow the relay of resource record types
between 0x1d and 0xff. Previously packets with these types of resource
records were dropped.
This issue has been resolved (No PCR number.)
DVMRP packets were being dropped due to packet length inconsistencies
from other vendor devices.
This issue has been resolved. (No PCR number.)
Previously, when changing the password on a log output/receive definition
to a shorter string, the log message exchange could fail.
This issue has been resolved. (PCR number: 50070)
A slight change has been made to the Mirror ports tagged mode. If all
mirroring ports are untagged then the Mirror port will transmit only
untagged packets. If at least one mirroring port is tagged then the Mirror
port will always transmit tagged packets.
Previously, the Mirror port would always transmit tagged packets
regardless of the mirroring port(s) tagging mode.
The 9924/8948 could reboot when attempting to display the ASIC LED
control register.
This issue has been resolved
CR00008176 Module: FFS, FILE Level: 2
CR00008184 Module: IPG Level: 2
CR00008266 Module: CORE Level: 2
CR00007476 Module: IPG Level: 3
CR00007521 Module: IPG Level: 3
CR00007716 Module: LOG Level: 3
CR00008098 Module: CORE, SWMX Level: 3
CR00008123 Module: SWI Level: 3

Version 89273-02 for AT-8900 and AT-9900 series switches 7
Software Maintenance Release note for Software Release 2.7.3
C613-10443-00 REV A
Level 4
There was not enough information displayed to the user when the
ACTIVATE FLASH COMPACTION command was entered at the same time
as Flash was compacting.
This issue has been resolved. (No PCR number.)
Enhancements
Previously ISAKMP NAT-T was enabled by default on every ISAKMP
policy created. NAT-T is now disabled by default on every ISAKMP policy.
(No PCR number.)
The ability to configure Van Jacobson Header Compression over dynamic
PPP interfaces has been added. To this end, the command parameter
'VJC={ON|OFF}' has been added to the CREATE and SET PPP TEMPLATE
commands. (No PCR number.)
Add support for the MG8T (Agilent QBCU-5730R) to support 10/100/1000
modes of operation.
Support has been added for VoIP services using SIP (port 5060) where the
VOIP phone's session setup is 5 packets or less and the keepalive is greater
than 5 min.
Note: If the keepalive is greater than the default udpTimeout of 20 minutes, then this
will need to be configured for the firewall policy.
Features in 89273-01
No release.
CR00006093 Module: FFS Level: 4
CR00006652 Module: IKMP, IPSEC
CR00006953 Module: PPP
CR00008045 Module: SWMX
CR00008367 Module: FIREWALL
