Allied HO-PAC 4000 User manual

HOLE-HOG
Models
4000
and 4001
Construction Products, LLC
TECHNICAL
MANUAL
Manual Part No. 002052

ALLIED 4000 Series Hole-Hog
Allied Hole-Hog, Model 4000 Series
Document Change Notice
Date Page Change
Throughout Update to CE Compliance
and specifications
08/09/06 59 & 61 Coupling Revision
11/15/06 17 &18 Revise Section 6.2.8

ALLIED 4000 Series Hole-Hog
i
TABLE OF CONTENTS
Section Page
SECTION 1.0 GENERAL ..................................1
SECTION 2.0 OVERVIEW .................................3
2.1 Body/Anvil ......................................3
2.1.1 Expanded Body ..................................3
2.2 Striker ........................................ 3
2.3 Tail Assembly ....................................3
2.4 Differences Among Models Covered .......................3
SECTION 3.0 SPECIFICATIONS AND DECALS .....................5
3.1 Specifications.................................... 5
3.2 Minimum Recommended Operating Depths ..................5
3.3 DECAL IDENTIFICATION ..............................5
SECTION 4.0 GENERAL CONSTRUCTION SAFETY ..................9
4.1 Owner’s Responsibilities..............................9
4.2 General Construction Safety ...........................9
4.3 Federal, State, Local and OSHA Construction Guidelines and Regulations . . 9
4.4 General Safety Summary .............................9
4.4.1 CAUTIONS and WARNINGS.........................9
4.4.2 Personnel Precautions...........................10
4.5 Warranty Protection Summary .........................10
4.6 Allied Product Policies ..............................10
SECTION 5.0 HOLE-HOG SAFETY PRECAUTIONS ..................11
5.1 Receiving A New Hole Hog ............................11
5.2 Lifting and Blocking Precautions ........................11
5.3 Operating Precautions ..............................11
SECTION 6.0 OPERATION ................................13
6.1 Operating Overview ................................13
6.2 Operating Guidelines ...............................13
6.2.1 Safety Precautions .............................13
6.2.2 Select a Safe Piercing Path ........................13
6.2.3 Prepare Entrance Pit ...........................14
6.2.4 Prepare Exit Pit or Target .........................14

ALLIED 4000 Series Hole-Hog
ii
TABLE OF CONTENTS
Section Page
6.2.5 Prepare The Hole-Hog and Air Hose ...................14
6.2.6 Position and Aim The Hole-Hog .....................14
6.2.7 Piercing The Underground Hole .....................15
6.2.8 Reversing The Hole-Hog..........................16
6.2.9 Install Material in the Pierced Hole ...................16
6.2.10 Remove and Service Hole-Hog......................16
SECTION 7.0 LUBRICATION...............................17
7.1 Startup ....................................... 17
7.2 Normal Operation .................................17
7.3 De-Icing ...................................... 17
SECTION 8.0 DISASSEMBLY ..............................19
8.1 General ......................................19
8.2 Extent of Disassembly ..............................19
8.3 Whip Hose Replacement .............................19
8.4 Replacing The Body/Anvil ............................20
8.5 Removing Tail Assembly and Striker ......................20
8.6 Disassembling the Tail Assembly ........................21
8.6.1 Remove Whip Hose and End Cap.....................21
8.6.2 Disassemble Whip Hose and Quick Disconnect (Q.D.) Fittings ....22
8.6.3 Remove Valve and Bushing ........................24
8.6.4 Disassemble End Cap Components ...................25
SECTION 9.0 ASSEMBLY.................................27
9.1 General ......................................27
9.2 Whip Hose Replacement .............................27
9.3 Replacing The Body/Anvil Only .........................27
9.4 Assemble End Cap Components.........................27
9.5 Assemble Valve Stem Components .......................29
9.6 Assemble Whip Hose and Fittings........................30

ALLIED 4000 Series Hole-Hog
iii
TABLE OF CONTENTS
Section Page
9.6.1. Assemble Q.D. Socket Fittings ......................30
9.6.2. Assemble Q.D. Plug to Whip Hose ....................32
9.6.3. Attach Valve Nut to Whip Hose .....................33
9.7 Assemble Whip Hose & Tail Assembly .....................34
9.8 Assemble Body/Anvil, Striker and Tail Assembly ...............36
SECTION 10.0 MAINTENANCE .............................39
10.1 Daily Maintenance ...............................39
10.2 Preventive Maintenance ............................39
10-3. Conditional Maintenance ...........................39
SECTION 11.0 FIELD MAINTENANCE .........................41
11.1 Field Replacement of the Whip Hose .....................41
11.2 Repair Preparations ...............................41
11.3 Remove Tail Assembly..............................41
11.4 Remove Whip Hose Assembly .........................42
11.5 Disassemble Whip Hose and Quick Disconnect (Q.D.) Fittings .......43
11.6 Assemble Whip Hose and Fittings .......................45
11.6.1. Assemble Q.D. Socket Fittings .....................45
11.6.2. Attach Q.D. Plug to Whip Hose .....................47
11.6.3. Attach Valve Nut to Whip Hose.....................48
11.7 Attach The Assembled Whip Hose Components to The Tail Assembly . . . 49
11.8 Clean Components ...............................49
11.9 Body/Anvil and Tail Assembly .........................50
SECTION 12.0 HOLE-HOG TROUBLESHOOTING CHART ..............53
SECTION 13.0 PARTS & WARRANTY INFORMATION ................55

ALLIED 4000 Series Hole-Hog
iv
LIST OF FIGURES
Figure Page
Figure 2-1. Major Components: Hole-Hog, Models 4000 and 4001 ...........4
Figure 3-1. Hole-Hog Decal Location ...........................6
Figure 8-1. Spanner Wrench 834017. ...........................19
Figure 8-2. Loosening the End Cap. ...........................20
Figure 8-3. Removing Tail Assembly............................20
Figure 8-4. Access the Striker with a Hook. .......................20
Figure 8-5. Tilting the body/anvil to Access the Striker. ................20
Figure 8-6. Striker Removed from Body/Anvil. .....................21
Figure 8-7. Place End Cap in Vise. ............................21
Figure 8-8. Thread the Valve Nut from the Valve Stem. ................21
Figure 8-9. Remove the Hose Socket and Whip Hose from the Valve Stem......22
Figure 8-10. Separate End Cap and Valve Stem Assemblies...............22
Figure 8-11. Quick Disconnect Components.......................22
Figure 8-12. Remove Q.D. Gasket.............................22
Figure 8-13. Whip Hose, Socket and Q.D. Plug. .....................23
Figure 8-14. Q.D. Socket and Hose ............................23
Figure 8-15. Valve Nut Assembly .............................23
Figure 8-16. Valve Nut and Whip Hose in Vise .....................24
Figure 8-17. Valve and Components in Press. ......................24
Figure 8-18. Press Valve Stem from Bushing. ......................25
Figure 8-19. Press Bushing from Valve. .........................25
Figure 8-20. Removing the Valve Seal from the End Cap. ...............25
Figure 8-21. End Cap in Arbor Press. ..........................26
Figure 8-22. Remove Valve Body Nut from the End Cap. ...............26
Figure 8-23. Cutting Pattern to Remove Shock Absorber from End Cap .......26
Figure 9-1. End Cap and Shock Absorber in Press ...................28
Figure 9-2. Press the Valve Body Nut into the Shock Absorber. ............28
Figure 9-3. Press Valve Seal onto the Valve Body Nut . ................28
Figure 9-4. Press Bushing into Valve ...........................29
Figure 9-5. Lubricate Bushing and Valve Stem. .....................29
Figure 9-6. Press Valve and Bushing onto Valve Stem. .................29

ALLIED 4000 Series Hole-Hog
v
LIST OF FIGURES
Figure Page
Figure 9-7. Whip Hose Components and Quick Disconnect Fittings. .........30
Figure 9-8. Install Gasket in Q.D. Socket. ........................30
Figure 9-9.Hose Socket and Hose in Vise. ........................31
Figure 9-10. Thread Tapered End of Q.D. Socket into Hose Socket...........31
Figure 9-11. Hose Socket and Hose in Vise. .......................32
Figure 9-12. Thread Tapered End of Q.D. Plug into Hose Socket. ...........32
Figure 9-13. Valve Nut and Roll Pin ...........................33
Figure 9-14. Valve Nut and Hose in Vise ........................33
Figure 9-15. Valve Nut Secured to Valve Stem and Whip Hose. ............33
Figure 9-16. Valve Stem in Vise..............................34
Figure 9-17. Align Valve Body Nut with the Tapered End of the Valve Stem. ....34
Figure 9-18. End Cap Threaded onto Valve Stem ....................34
Figure 9-19. Align Valve Nut on Valve Stem. ......................35
Figure 9-20. Tighten Valve Nut on Valve Stem. .....................35
Figure 9-21. Valve Nut Secured to Valve Stem and Whip Hose. ............35
Figure 9-22. Blocking the Body/Anvil ..........................36
Figure 9-23. Install Striker into Body/Anvil. .......................36
Figure 9-24. Prepare Tail Assembly and Body Anvil for Assembly. ..........36
Figure 9-25. Insert Valve into Striker. ..........................36
Figure 9-26. Secure End Cap to Body/Anvil. .......................37
Figure 9-27. Tighten End Cap. ..............................37
Figure 11-1. Loosening the End Cap ...........................41
Figure 11-2. Removing Tail Assembly ..........................42
Figure 11-3. Place End Cap in Vise. ...........................42
Figure 11-4. Thread the Valve Nut from the Valve Stem. ...............42
Figure 11-5. Whip Hose Components and Quick Disconnect Fittings. ........43
Figure 11-6. Quick Disconnect Components.......................43
Figure 11-7. Remove Q.D. Gasket. ............................43
Figure 11-8. Remove Q.D. Plug. ..............................43
Figure 11-9. Q.D. Socket and Hose ............................44

ALLIED 4000 Series Hole-Hog
vi
LIST OF FIGURES
Figure Page
Figure 11-10. Valve Nut Assembly ............................44
Figure 11-11. Valve Nut and Whip Hose in Vise.....................44
Figure 11-12. Whip Hose Components and Quick Disconnect Fittings. ........45
Figure 11-13. Install Gasket in Q.D. Socket. .......................45
Figure 11-14. Hose Socket and Hose in Vise.......................46
Figure 11-15. Thread Tapered End of Q.D. Socket into Hose Socket. .........46
Figure 11-16. Hose Socket and Hose in Vise. ......................47
Figure 11-17. Thread Tapered End of Q.D. Plug into Hose Socket. ..........47
Figure 11-18. Valve Nut and Roll Pin...........................48
Figure 11-19. Valve Nut and Hose in Vise........................48
Figure 11-20. Valve Nut Secured to Valve Stem and Whip Hose ...........48
Figure 11-21. Align Valve Nut on Valve Stem. ......................49
Figure 11-22. Tighten Valve Nut on Valve Stem. ....................49
Figure 11-23. Valve Nut Secured to Valve Stem and Whip Hose ...........49
Figure 11-24. Blocking the Body/Anvil..........................50
Figure 11-25. Install Striker into Body/Anvil. ......................50
Figure 11-26. Prepare Tail Assembly and Body Anvil for Assembly. ..........50
Figure 11-27. Insert Valve into Striker. .........................50
Figure11-28. Secure End Cap to Body/Anvil........................51
Figure 11-29. Tighten End Cap. ..............................51
Figure 13-1. Model 4000 Hole-Hog Complete Assembly ................56
Figure 13-2. Model 4001 Hole-Hog Complete Assembly ................58

SECTION 1.0 INTRODUCTION
This manual contains important informa-
tion for the safe use and maintenance of
the Allied Hole-Hog. Read this manual
thoroughly before installing, operating or
servicing the Hole-Hog. This manual must
be easily accessible to operators or service
and transport personnel. Store this man-
ual in a convenient location.
Pay careful attention to all instructions
and follow all governing regulations. Oper-
ation or service other than in accordance
with these instructions may subject the
Hole-Hog to conditions beyond its design
capability. Improper operation, service or
the use of non-Allied parts may result in
Hole-Hog failure or personnel injury.
1.1 Safety Information
When using the Hole-Hog, underground
safety procedures such as the location of
existing underground service lines, cables
and conduit must be followed. See Sections
4.0 and 5.0 for further safety guidelines.
Pay particular attention to WARNINGS
and CAUTIONS, identified with this sym-
bol.
~
These instructions are important for per-
sonnel safety and full service life of the
Hole-Hog. Follow them carefully.
1.2 Warranty Information
Warranty coverage of the Allied Hole-Hog,
depends on proper maintenance and opera-
tion of the Hole-Hog as detailed in this
manual. Improper maintenance or opera-
tion shall void Hole-Hog warranty cover-
age. Immediately upon receipt of the
Hole-Hog, read all Allied warranty docu-
ments delivered with the unit for a thor-
ough understanding of warranty coverage.
Record the Hole-Hog Serial Number in the
space provided above.
1.3 Allied Product Policies
Allied reserves the right to make modifica-
tions to the design or changes to the specifi-
cations without prior notice.
ALLIED 4000C Series Hole-Hog
1
Hole-Hog Technical Manual: Part Number 002052
This Technical Manual is applicable to Hole-Hog:
Models: 4000 and 4001
Years of Manufacture: 1993 and beyond
Serial Number(s)_________________________________________

In this manual, Allied recommends
Hole-Hog applications, maintenance and
service consistent with industry practices.
Allied takes no responsibility for the re-
sults of actions not recommended in this
manual and specifically the results of:
•Operation in non-recommended applica-
tions
•Incorrect operation
•Improper maintenance
•Use of service parts not approved or sup-
plied by Allied.
These exclusions apply to damage to the
Hole-Hog, associated equipment, and in-
jury to personnel.
2
ALLIED 4000 Series Hole-Hog

SECTION 2.0 OVERVIEW
The Allied 4000 Series Hole-Hog is a pneu-
matically propelled, reversible, ground
piercing tool designed to pierce continu-
ous, blind horizontal, inclined and vertical
holes in compressible soils. With optional
attachments, the Hole-Hog can also be
used to install or remove rigid pipe from
the ground.
The tool consists of three primary sections:
Body/Anvil, Striker and Tail Assembly. A
simple reversing mechanism allows the op-
erator to easily change the tool’s direction
from forward to reverse.
2.1 Body/Anvil
The body/anvil forms the majority of the
Hole-Hog’s exterior. It consists of the anvil
and the body. Refer to Figure 2-1. The
body/anvil is the ground contact surface.
Wear of this component is expected and
normal. The body is internally threaded at
the rear for attaching the Tail Assembly.
The anvil is the conical surface that forms
the front of the body/anvil. The anvil is
pressed into the body, and cannot be re-
moved from the assembled body/anvil.
2.1.1 Expanded Body
As shown in Figure 2-1, some Hole-Hogs
have expanded bodies. These models pierce
a larger diameter hole through the ground.
The smaller portion of the body pierces a
pilot hole and the larger portion of the body
expands the hole.
2.2 Striker
The striker is moved by air pressure back
and forth within the body. Internally, the
striker impacts either the anvil in the front
or the tail assembly in the rear to propel
the Hole-Hog and push the ridig pipe
through the ground.
2.3 Tail Assembly
Except for the Striker, the Tail Assembly
contains all internal operating compo-
nents, including the reversing mechanism .
The external threads of the Tail Assem-
bly’s End Cap secure the Tail Assembly to
the Body/Anvil. The Whip Hose attaches to
the other end of the Tail Assembly.
Hole-Hog service and repair require re-
moval of the tail assembly to access the ser-
viceable parts.
2.4 Differences Among Models Covered
This manual covers two Allied Hole-Hog
Models: 4000 and 4001.
All information in this manual applies to
both models unless specifically noted oth-
erwise. These two models are identical ex-
cept for the Body/Anvil:
·Model 4000 has a Standard Body.
·Model 4001 has an Expanded Body.
3
ALLIED 4000 Series Hole-Hog

SECTION 3.0 SPECIFICATIONS AND DECALS
3.1 Specifications
Outside Diameter:
4000 ...........6in.(98mm)
4001 ..........8in.(203mm)
Weight:
4000 .........282lbs. (128kg)
4001 .........310lbs. (141kg)
Overall Length: . . . 68 in. (1727mm)
Working Air PSI *: 90 psi (6.3 kg./cm2)
Air Consumption/Min.: . . . 240 scfm
(scmm)
Whip Hose
(inside diameter): . . 1-1/2 in. (38mm)
Recommend Delivery Hose
(inside diameter): . .1-1/2 in. (38 mm)
Percussion Rate Per Minute: . . . 400
* Pressure required at the tool. Allow 5 psi
(0.4 kg/cm2) pressure drop for each 100 ft.
(30m) of hose. Pressure above 100 psi (7
kg./cm2) at the tool decreases the life of the
Hole-Hog.
3.2 Minimum Recommended Operating
Depths
Hard Glacial Clay ........48in.
Clay/Sand Mix..........48in.
Wet/Dry Sand ..........60in.
Cultivated Soil .........60in.
Clay/Loam Mix .........60in.
The Hole-Hog operates best in compac-
table soils. The minimum depth of opera-
tion varies with soil conditions and the
length of the hole. The chart above is in-
tended as a guide only. Specifications sub-
ject to change without notice.
ALLIED 4000C Series Hole-Hog
4
Body
/
Anvil Tail Assembly
End Cap Whip Hose Quick
Disconnect
Coupling
Body/Anvil Tail Assembly
End Cap Whip Hose Quick
Disconnect
Coupling
Expanded Body
Figure 3-1. Major Components: Hole-Hog, Models 4000 and 4001

3.3 DECAL IDENTIFICATION
5
ALLIED 4000 Series Hole-Hog
IMPORTANT! Read Technical Manual.
Follow Instructions, Cautions and Warnings.
USA
Made in USA

ALLIED 4000C Series Hole-Hog
6
Hole-Hog Patent Numbers.
The ALLIEDLOGOdecal is the Allied brand identifier and is a registered trademark of
Allied Construction Products, LLC

7
ALLIED 4000 Series Hole-Hog
321
Figure 3-2. Hole-Hog Decal Location
Hole-Hog CE Serial Number Plate

8
ALLIED 4000 Series Hole-Hog
Hole-Hog Decal Kit
Part No. 833295
ITEM
NO. QTY.
PART
NO. DESCRIPTION
1 1 676984 Decal - Read Instructions
2 1 833291 Decal - Hole-Hog Patents
3 1 815696 Decal - Made in USA

SECTION 4.0 GENERAL CONSTRUCTION SAFETY
4.1 Owner’s Responsibilities
The equipment owner shall:
•Provide this technical manual to the
Hole-Hog operators.
•Train all operating personnel and en-
force the procedures explained in this
manual, especially regarding safety to
personnel and equipment.
•Adapt these general instructions to spe-
cific applications.
4.2 General Construction Safety
Follow standard safety precautions ex-
pected and required of those working in
construction, including but not limited to:
locating existing underground service and
utility lines, establishing pedestrian barri-
ers and using personnel protection equip-
ment, etc.
4.3 Federal, State, Local and OSHA
Construction Guidelines and
Regulations
Use the Hole-Hog in accordance with all
federal, state and local regulations regard-
ing construction practices and public
safety. Identification of, and compliance to,
governing regulations are the responsibil-
ity of the owner and operator.
In the United States, comply with the rec-
ommendations of the Occupational Safety
and Health Administration standards of
the U.S. Department of Labor. For OSHA
construction guidelines contact your local
federal government office or write:
U.S. Government Printing Office
Superintendent of Documents
P.O. Box 371954
Pittsburgh, Pa. 15250
Ask for Construction Industry OSHA
Standards Stock #869-034-00107-6.
4.4 General Safety Summary
The safe and effective use of any heavy con-
struction equipment depends upon proper
installation, operation, maintenance and
repair. Operational safety must encompass
all of these factors. Section 5.0 includes
minimum safety policies the Hole-Hog
owner shall establish for all Hole-Hog in-
stallations. The operational safety pro-
gram must be tailored by the Hole-Hog
owner to the specific site and application.
Such a program will result in increased
equipment life and performance and re-
duced downtime. Most importantly, it will
reduce the risk of equipment damage and
personnel injuries.
4.4.1 CAUTIONS and WARNINGS.
Throughout this manual detailed CAU-
TIONS and WARNINGS are included with
the instructions and procedures. Even ex-
perienced service technicians are to review
these CAUTIONS and WARNINGS prior
to performing a procedure. These are high-
lighted by the symbol shown here.
~
ALLIED 4000 Series Hole-Hog
9

~WARNING
Instructions preceeded by this sym-
bol identify hazards to personnel.
WARNING instructions must be fol-
lowed to ensure safe handling and
operation. These instructions shall
be followed at all times. Improper
operation or servicing can result in
personal injury. Read this manual
thoroughly before operating or main-
taining the Hole-Hog.
~CAUTION
Instructions identified with this sym-
bol are important to prevent dam-
age to equipoment and to maintain
full service life of the Hole-Hog. Fol-
low them carefully. Operation or ser-
vice not in accordance with these
instructions may subject the
Hole-Hog to conditions beyond its
design capability. Read this manual
thoroughly before operating or main-
taining the Hole-Hog.
4.4.2 Personnel Precautions
•Always wear safety glasses, and protec-
tive clothing when operating or handling
the Hole-Hog.
•All personnel in the immediate area
must wear ear protection.
ALLIED 4000 Series Hole-Hog
10

SECTION 5.0 HOLE-HOG SAFETY PRECAUTIONS
5.1 Receiving A New Hole Hog
The Hole-Hog is delivered assembled, lu-
bricated, and factory tested. Inspect for
possible shipping damage. Pay particular
attention to the hose.
~WARNING
Ensure that the End Cap is properly
tightened. A loose End Cap could
blow out with damaging force caus-
ing injury to the operator and by-
standers. Before operation, check
the tightness of the end cap using
the proper tools and torque (Sec-
tion 9.13, Steps 10, 11, and 12).
~CAUTION
If the end cap becomes loose at
any time, do not retighten. Remove
end cap and clean thoroughly. Pay
special attention to cleaning the
threads of end cap and body. Lubri-
cate threads as instructed in the
maintenance section, then re-
assemble according to Section 9.8
It is recommended that the air
hose be connected to an air com-
pressor of sufficient capacity and
the Hole-Hog operated above
ground momentarily.
5.2 Record The Serial Number
Upon receipt of the Hole-Hog, record the
Serial Number, as listed on the shipping
papers, in the space provided in Section
3.1.
5.3 Hole-Hog Use
The Allied Hole-Hog is an underground
peircing tool used to pierce underground
holes and to drive pipe. Do not use the
Hole-Hog in any manner not described in
this manual. Personal injury may result
from improper use of the Hole-Hog.
5.4 Lifting and Blocking Precautions
Each of the Hole-Hog Models covered in
this manual are heavy; refer to Section 3.0
Specifications. Even when disassembled,
component parts like the Body/Anvil and
Striker are heavy enough to cause serious
bodily injury if not handled with caution.
When handling and lifting these
Hole-Hogs, follow all precautions normal
to the lifting and operating of heavy equip-
ment with particular attention to the fol-
lowing.
•Always use sufficient blocking to prevent
accidental or sudden movement of the
Hole-Hog or its components.
•Always prevent the Hole-Hog and/or its
components from rolling when they are
placed on a horizontal surface.
•Always use suitable lifting equipment
that will assure the safety of personnel
and not damage the Hole-Hog or its com-
ponents.
•Any unit over 88 pounds (40kg) cannot
be lifted manually. Use slings on either
end of the Hole-Hog as shown in Figure
6-1 to lift the Hole-Hog in and out of the
trench.
ALLIED 4000 Series Hole-Hog
11

•Never stand under Hole-Hog being low-
ered into trench.
•Always wear gloves and keep hands and
feet away from pinch points.
•Hole-Hog surface may be extremely hot
or cold. Always wear gloves or burns may
result.
•Always wear a hard-hat when any part of
the Hole-Hog will be lifted above waist
level.
•When manually handling the Hole-Hog
or its components, make sure enough
personnel are used to safely distribute
the strain among them. Make sure they
are wearing the following safety items.
·Steel-toed shoes suitable to protect
the arch as well as the toes.
·Kidney belt wide enough and tight
enough to protect against herniating
internal organs and lower back.
5.5 Operating Precautions
•Daily, before operation, check the tight-
ness of the end cap using the proper tools
and tightening method as described in
Section 9.8, Step 9. A loose end cap could
blow out with damaging force, injuring
the operator or bystanders.
•Observe all safety precautions outlined
in the air compressor operating manual.
•The owner/operator/contractor is re-
sponsible for locating underground utili-
ties.
•Do not attempt to pierce a hole in frozen
ground.
•Entrance and exit pits may be unstable
and dangerous. These trenches must be
shored to meet federal, state and local
guidelines. Allied’s TrenShore is recom-
mended.
•The work site must be properly illumi-
nated to provide enough light to work
safely.
•There shall be a safety person at the
compressor to shut the unit down in case
of emergency. The operator and safety
person shall have agreed upon hand sig-
nals to indicate the necessity of immedi-
ate shut down.
•Be aware of Hole-Hog travel distance by
marking air supply hose. Place marking
tape at two foot intervals on the hose to
monitor travel.
•Check air supply hose periodically for fit-
ting and hose damage.
•Serious injury from flying debris may re-
sult if personnel are in line with the
Hole-Hog exhaust. Stand clear.
•Never stand directly over the Hole-Hog
air supply hose. Retain hoses to protect
against whipping in case of failure.
•Never pull on whip hose or air compres-
sor hose to move or position Hole-Hog.
Injury could result from broken or sepa-
rated hoses.
ALLIED 4000 Series Hole-Hog
12
