Foreword
The ALL-MC116SV is a VDSL2 CPE(slave) bridge with 2 x 10/100/1000Base-T LAN ports solution and using G.993.2 VDSL2
standard technology for data transmission
by a single copper wire pair. ALL-MC116SV is designed specifically to support G993.5 vectoring function for MDU/MTU application,
with standard VDSL2, there are 2 x 10/100/1000Base-T Ethernet ports and plus 1000Base-X SFP slot, for connecting to
IPDSLAM/LAN extender and providing a flexible solution to extend LAN network and it's perfect for MDU/MTU/FTTC/FTTdp
application, such as apartment, hotels, hospitals or any location outside the reach of 10/100/1000Base-T (Ethernet) or fiber optic.

4
Attention:
Be sure to read this manual carefully before using this product. Especially Legal Disclaimer, Statement
of Conditions and Safety Warnings.
Caution:
The ALL-MC116SV is for indoor applications only. This product does not have waterproof protection. Do not use in harsh
environments (Over temperature range: 0°C ~ 50°C (32°F ~ 122°F)).
Safety Warnings
For your safety, be sure to read and follow all warning notices and instructions before using the device.
DO NOT open the device or unit. Opening or removing covers can expose you to dangerous high voltage points or other
risks. ONLY qualified service personnel can service the device. Please contact your vendor for further information.
Use ONLY the dedicated power supply for your device. Connect the power cord or power adapter to the right supply voltage
(110VAC used for North America and 230VAC used for Europe).
DO NOT use the device if the power supply is damaged as it might cause electrocution. If the power supply is damaged,
remove it from the power outlet. DO NOT attempt to repair the power supply. Contact your local vendor to order a new
power supply.
Place connecting cables carefully so that no one will step on them or stumble over them. DO NOT allow anything to rest on
the power cord and do not locate the product where anyone can work on the power cord.
DO NOT install nor use your device during a thunderstorm. There may be a remote risk of electric shock from lightning.

5
DO NOT expose your device to dampness, dust or corrosive liquids.
DO NOT use this product near water, for example, in a wet basement or near a swimming pool.
Connect ONLY suitable accessories to the device. Make sure to connect the cables to the correct ports.
DO NOT obstruct the device ventilation slots, as insufficient airflow may harm your device.
DO NOT place items on the device.
DO NOT use the device for outdoor applications, and make sure all the connections are indoors. There may be a remote
risk of electric shock from lightning.
Be careful when unplugging the power, because the transformer may be very hot.
Keep the device and all its parts and accessories out of children’s reach.
Clean the device using a soft and dry cloth rather than liquid or atomizers. Power off the equipment before cleansing it.
This product is recyclable. Dispose of it properly.

6
Table of Contents
Copyright.............................................................................................................................................................1
Foreword.............................................................................................................................................................3
Safety Warnings..................................................................................................................................................4
Chapter 1. Unpacking Information.....................................................................................................................8
1.1 Check List ................................................................................................................................................................................ 8
Chapter 2. Installing the Device.........................................................................................................................9
2.1 Hardware Installation............................................................................................................................................................... 9
2.2 Pre-installation Requirements ................................................................................................................................................ 9
2.3 General Rules..........................................................................................................................................................................10
2.4 Connecting the Ethernet of RJ-45 Ports...............................................................................................................................11
2.5 Connecting the SFP Slot........................................................................................................................................................12
2.6 Connecting the Line of RJ-11 Port........................................................................................................................................12

7
2.7 Application Diagram...............................................................................................................................................................14
Chapter 3. Hardware Description.....................................................................................................................16
3.1Front Panel:..............................................................................................................................................................................16
3.2 Rear Panel:..............................................................................................................................................................................18
3.3 LED Indicators ........................................................................................................................................................................19
Appendix A: Cable Requirements....................................................................................................................20
Appendix B: Product Specifications ...............................................................................................................23
Appendix C: DIN-Rail mount installation ........................................................................................................25

8
Chapter 1. Unpacking Information
1.1 Check List
Carefully unpack the package and check its contents against the check list.
Package Contents:
1 x ALL-MC116SV
Accessory:
1 x Ethernet Cable, 4 x Rubber Feet, 1 x DC 12V Adapter
1 x SFP cover
Notes:
1. Please inform your dealer immediately for any missing or damaged parts. If possible, retain the carton including the
original packing materials. Use them to repack the unit in case there is a need to return for repair.
2. If the product has any issue, please contact your local supplier.
3. Do not use sub-standard power supply. Before connecting the power supply to the device, be sure to check
compliance with the specifications. The ALL-MC116SV uses a DC 12V/1A power supply.

9
4. The power supply included in the package is commercial-grade. Do not use in industrial-grade applications.
5. Please look for the QR code on the bottom of the product, the user can launch the QR code scanning program to
scan and download the user’s manual electronic format file. Above QR code icon is for reference.
Chapter 2. Installing the Device
2.1 Hardware Installation
This chapter describes how to install the bridge and establish the network connections. The ALL-MC116SV may be installed on
any level surface (e.g. a table or shelf or rail). However, please take note of the following minimum site requirements before one
begin.
2.2 Pre-installation Requirements
Before you start the actual hardware installation, make sure you can provide the right operating environment, including power
requirements, sufficient physical space, and proximity to other network devices that are to be connected.
Verify the following installation requirements:
Power requirements: DC 12V / 1A or above power supply.
The bridge should be located in a cool dry place, with at least 10cm/4in of space at the front and back for
ventilation.
Place ALL-MC116SV away from direct sunlight, heat sources, or areas with a high amount of
electromagnetic Interference.

10
Check if the network cables and connectors needed for installation are available.
Do not install phone lines strapped together withAC power lines, or telephone office line with voice signal.
Avoid installing this device with radio amplifying station nearby or transformer station nearby.
2.3 General Rules
Before making any connections to the bridge, please note the following rules:
SFP Port
All Fiber optical network connections to the SFP port must use Fiber 1.25G SFP transceiver.
Please note that SFP transceiver that you are using must be compatible to both side’s device.
Ethernet Port (RJ-45)
All network connections to the bridge Ethernet port must be made using Category 5e UTP/STP or above for 1000 Mbps,
Category 5 UTP/STP for 100Mbps.
No more than 100 meters of cabling may be use between the MUX or HUB and an end node.
VDSL2 Port (RJ-11)
All network connections to the RJ-11port must use 24~26 gauge with twisted pair phone wiring.
We do not recommend the use of the telephone line 28 gauge or above.
The RJ-11 connectors have six positions, two of which are wired. The device uses the center two pins. The pin out assignment
for these connectors is presented below.
Please note that the line port is no polarity, therefore user can reverse the two wires of the phone cable when installed.

11
RJ-11 Pin out Assignments
Pin#
MNEMONIC
FUNCTION
1
NC
Unused
2
NC
Unused
3
DSL
Used
4
DSL
Used
5
NC
Unused
6
NC
Unused
External Splitter installing
ALL-MC116SV need install external splitter depend on PBX systems such as POTS/ISDN, when connecting with pone set
and please make sure splitter which is compatible with local PBX system.
2.4 Connecting the Ethernet of RJ-45 Ports
ALL-MC116SV has two Ethernet ports which support connection to Ethernet operation. The devices attached to these ports
must support auto-negotiation or 10Base-TX, 100Base-TX or 1000Base-T unless they will always operate at half duplex. Use
any of the Ethernet ports to connect to devices such as Monitor system, Server, Switch, bridge or router.

12
2.5 Connecting the SFP Slot
There are multiple types of SFP transceiver in market, please ensure the SFP transceiver is compatible to both side of device;
otherwise, the connection can’t set up.
2.6 Connecting the Line of RJ-11 Port
The line port has 2 connectors: RJ-45 and terminal block. It is used to connect with IP DSLAM or other Master side using a
single pair phone cable to ALL-MC116SV (slave) bridge side (point to point solution). Take note that NV-320DP line port RJ-11
and terminal block cannot be used at the same time. Either RJ-11 port is connected or terminal block is connected using straight
connection (Figure 2.4) or cross-over connection (Figure 2.5)

13
When inserting a RJ-11 plug, make sure the tab on the plug clicks into position to ensure that it is properly seated.
Do not plug a RJ-11 phone jack connector into the Ethernet port (RJ-45 port). This may damage the bridge. Instead, use only
twisted-pair cables with RJ-45 connectors that conform to Ethernet standard.

14
Notes:
1. Be sure each twisted-pair cable (RJ-45 Ethernet cable) does not exceed 100 meters (333 feet).
2. We advise using Category 5~7 UTP/STP cables for Cable Bridge or Bridge connections to avoid any confusion
or inconvenience in the future when you attached to high bandwidth devices.
3. Line port use AWG24 ~ 26 twisted pair phone wiring, we do not recommend 28 gauge or above.
4. The Slave device (CPE) must be connected to the Master device (CO) through the telephone wire.
The Slave cannot be connected to another Slave, and the Master cannot be connected to another Master.
Please confirm both side mode correct before the link is established.
2.7 Application Diagram

15
Figure 2.2 Application Diagram

16
Chapter 3. Hardware Description
This section describes the important parts of ALL-MC116SV. It features the front panel and rear panel.
3.1Front Panel:
The front panel provides SFP Slot, RJ-45 Connector, RJ-11 connector and LED indicators of ALL-MC116SV.
Front panel indicator: There are 7 LED indicators on front panel, the following Table shows the description.
Figure 3.1 Front Panel

17
Tip: With only a glance of the front panel’s LED indicators, the converter status will be fully aware.
Table 3-1 Description of the front interface
Port Name
Connector type
Description
E1 / E2
RJ-45
For connecting to a 10/100/1000-T Networking device.
SFP
SFP slot
For small form-factor pluggable transceiver.
LINE
RJ-11
For connecting to VDSL2 device. (Do not use RJ11 and Terminal Block at the same time.)
Reminder: Please use SFP transceiver which is compatible to Fiber 1.25G SFP slot , otherwise, the connection cannot set
up.

18
3.2 Rear Panel:
Figure 3.2 Rear Panel

19
3.3 LED Indicators
The ALL-MC116SV has 7 LED indicators. The following Table shows the description. (Table 3-3)
Table 3-3 LED Indicators Description and Operation
Remark: 1. Except for Fiber SFP transceiver, SFP LED indicator will light up right away when the SFP
transceiver insert into SFP slot.
LEDs
Color
Status
Description
PWR
Green
ON
Power Good
OFF
Power OFF
E1/E2
Green
ON (Steady)
Ethernet port on Link status
Blinking
Data transmission
OFF
No Connection
SFP
Green
ON
SFP on Link Status
LINE
ON (Steady)
Line port on Link status
Green
Slow Blinking
1. Device has detected a master device and ready to
connect.
2. Data transmission
Fast Blinking
Device on handshaking status
OFF
No connection

20
2. CO = Master / CPE =Slave.
Appendix A: Cable Requirements
A.1 Ethernet Cable
A CAT 5~7 UTP (unshielded twisted pair) cable is typically used to connect the Ethernet device to the Modem. A: 10/100TX cable
often consists of four pairs of wires, two of which are used for transmission. The connector at the end of the 10/100TX cable is
referred to as a RJ-45 connector and it consists of eight pins. The Ethernet standard uses pins 1, 2, 3 and 6 for data transmission
purposes. (Table A-1 10/100TX)
B: 1000TX cable often consists of four pairs of wires, all of which are used for transmission. The connector at the end of the 1000TX
cable is referred to as a RJ-45 connector and it consists of eight pins. The Ethernet standard uses pins 1, 2, 3, 4, 5 and 6 for data
transmission purposes. (Table A-1 1000TX)
Table B-1 RJ-45 Ethernet Connector PinAssignments
PIN #
10/100TX
1000TX
Figure A-1 Standard RJ-45 plug/connector
Signal
Media Dependant
interface
Signal
Media Dependant
interface-cross
1
TX+
Transmit Data+
BI_DA+
Bi-directional pair A+
2
TX-
Transmit Data-
BI_DA-
Bi-directional pair A-
3
RX+
Receive Data+
BI_DB+
Bi-directional pair B+
4
NC
Unused
BI_DC+
Bi-directional pair C+
5
NC
Unused-
BI_DC-
Bi-directional pair C-
6
RX-
Receive Data-
BI_DB-
Bi-directional pair B-
7
NC
Unused
BI_DD+
Bi-directional pair D+
