Alltech Manual Barrier User manual

Manual Barrier
Product Description:
The Manual Barrier provides positive, dependable access control for all vehicles entry and
exit scenarios. The Boom arm is aluminium with a white powder coating, which is then
taped red at 500mm intervals
Applications:
Mines
Car parks
Hospitals
Drive:
Manually driven
Materials
Post Mild Steel Powder Coated
Counter weight: Mild Steel Powder Coated
Boom Pole: Aluminium
Technical Features
Engineered for long term reliability, fast on-site maintenance and durability
Technical Data
Dimensions: See drawing
Operating Temperature: 0 - 55˚C
Flow Rates (approx.)
Manually Operation
Number per Minute
Manual lift
8

Models Available
3m Manual Barrier
4m Manual Barrier
5m Manual Barrier
6m Manual Barrier
Optional
Tip Support
Site Preparation
Product Delivered as sub-assemblies and may require lifting equipment
(For installation details, please refer to the installation Manual)

Important
The dimensions given in this Product Data Sheet are for Information only. In order to
prepare the installation site, please refer to the installation manual or ask
conformation
It is the customer’s responsibility to ensure the structural integrity and strength of the
installation
Concrete slab & floor site preparation
Concrete base to specification at least fck (cube) 300N/mm2 of resistance
Base to be flat and level to +/- 5mm over footprint area.
Dimensions to be 1400 x 800 x 158 deep min. (Units in mm)
