Allview D1 Flip User manual

1
D1 Flip
User manual……………………………..
4
Manual de usuario……………………………
22
Felhasznaloi kezikonyv……………………..
36
Instrukcja obsługi……………………….
51
Manual de utilizare…………………….
64

2

3
EN
ES
HU
PL
RO
1
Power button
1
Botón de encendido
1
Bekapcsoló gomb
1
Przycisk zasilania
1
Buton pornire
2
Speaker
2
Altavoz
2
Hangszóró
2
Głośnik
2
Difuzor
3
Radio
3
Radio
3
Radio
3
Radio
3
Radio
4
Flashlight button
4
Botón de luz del flash
4
Zseblámpa gomb
4
Przycisk latarki
4
Buton lanternă
5
Volume buttons
5
Botones del volumen
5
Hangerőszabályzó gombok
5
Przyciski głośności
5
Butoane volum
6
Flashlight
6
Luz del flash
6
Zseblámpa
6
Dioda latarki
6
Lanternă
7
Back
7
Atrás
7
Vissza
7
Cofnij
7
Înapoi
8
Camera
8
Cámara
8
Kamera
8
Aparat
8
Cameră
9
Hang rope hole
9
Agujero para cuerda
9
Karpánt rögzítő
9
Otwór na linkę
9
Orificiu șnur
10
SOS button
10
Botón SOS
10
SOS gomb
10
Przycisk SOS
10
Buton SOS
11
Earphones plug
11
Enchufe
11
Fülhallgató plug
11
Złącze słuchawkowe
11
Mufa casti
12
Micro USB plug
12
Enchufe micro USB
12
Micro USB
12
Złącze micro USB
12
Mufa Micro USB
13
OK
13
OK
13
OK
13
OK
13
OK

4 En
User Manual
FOR YOUR SAFETY
Read these simple guidelines. Not following them may be dangerous or illegal.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the device off near medical equipment. Do not use thedevice where blasting
is in progress.
Please keep this cell phone away from children, as they could mistake it for a toy, and hurt themselves with
it. Don’t try to modify the phone except by the professional. Warning! Only use the authorized spare parts,
otherwise it may damage the phone and the warranty will not work. And it may be dangerous.
SWITCH OFF WHEN REFUELING
Don’t use the phone at a refueling point. Don’t use near fuel or chemicals.
SIM CARD AND T-FLASH CARD ARE PORTABLE
Pay attention to these small things to avoid children eating them.
Notice: The T-Flash Card can be used as a Memory Disk, the USB cable is necessary.

5 En
BATTERY
Please do not destroy or damage the battery, it can be dangerous and cause fire. Please do not throw battery
in fire, it will be dangerous When battery cannot be used, put it in the special container.
Do not open the Battery.If the battery or the charger is broken or old, please stop using them.
USE QUALITY EQUIPMENT
Use our authorized equipment or it will cause dangers
ROAD SAFETY COMES FIRST
Give full attention while driving; Pull off the road or park before using your phone if driving conditions so
require.
INTERFERENCE
All wireless devices may be susceptible to cause interference, which could affect performance.
SWITCH OFF IN AIRCRAFT
Wireless devices can cause interference in aircraft. It’s not only dangerous but also illegal to use mobile
phone in an aircraft. Warning: We take no responsibility for situations where the phone is used other than
as provided in the manual. Our company reserves the right to make changes in the content of the manual
without making this public. These changes will be posted on the company website to the product it amends.
The contents of this manual may be different from that in the product. In this last case will be considered.

6 En
GETTING STARTED
Battery Install Notice
Before you install or change battery, please ensure you already turned off the phone.
Install or change SIM card
1. Before you change SIM card, please make sure to turn off the phone and take out battery.
2. Insert the SIM card according to the instructions, place battery back and power on the phone.
Charge the battery
1. Before charging the battery, please make sure that the battery is installed properly in the phone.
2. Connect the charger lead to the phone socket, and then connect the charger to the AC socket.
3. If the phone is off when it’s charging, charging indicator is displayed on the screen. If the phone is
on when it’s charging, user can use it while charging. When the battery is fully charged, the charging
indicator on the screen is full and stops twinkling. While using the handset for the first time, please
completely discharge and then completely charge the battery. Repeat the process for three times to
achieve the full performance of the battery.
4. Long period unused or some other reasons may cause low battery pressure, so at the beginning of
charging the screen is black and it may take a while before the charging indicator appears.
Warning: When charging, in order to avoid serious damage to phone circuitry, donot remove or dispose
the battery.

7 En
CALLS
Key Explanation
* Key and # Key:
Functions vary in different situations or function menus:
- In inputting status, “*” for symbols.
- In inputting status, “#” to switch inputting methods.
- In standby mode, hold “#” to switch the phone in silent mode.
- In standby mode, input “+” for an international call; in dial status, input “P” for calling number with
extension phone.
Main Menu Explanation
When you press Menu key, you will enter main menu. Press up, down, left and right keys to select different
functions.
Make a Call
Making a call by dialing numbers:
1. In standby mode, enter the phone number. If you want to change the numbers, press left and right
direction key to move the cursor and press〈Clear〉to delete a number. Press and hold 〈Clear 〉to
delete all characters.
2. Press the call key to call the number.

8 En
Making a call using the Phonebook:
You can enter the phonebook list from functional menu, choose or input the needed letter (phonetic) to
search. Choose the number; press the call key to dial out.
Call the Dialled calls, Received calls, Missed calls:
1. In standby mode, press the call key to view the call log list.
2. Choose a number and press the call key to dial.
Making a call using the menu:
1. In standby mode, enter the menu, choose Call logs;
2. Choose from missed calls, dialled calls, and received calls.
3. Choose the needed number and press the call key to make a call.
Answer an Incoming Call
Press the Call key to answer an incoming call.
Call Options
Offer numerous in call functions (some of these functions needa subscription with the service provider).
During the call, press->Option and choose between the following options :
Hold: Pause the call.
End single call: End the present call.
New call: To make a new call.

9 En
Phonebook: Same as phonebook list in the function menu.
Call history: Same as call history in the function menu.
Messaging: To explore the Messaging Menu.
Sound recorder: Record the sound.
Mute: Enable the mic of phone not work.
DTMF (Dual-tone Multi-frequency): You can choose on/off, which is to send dual-tone multi-frequency
sound, this can offer dialing to the telephone numbers with extensions. Volume: To adjust the volume of
the call.
INPUT METHOD
Overview
Your phone offers multiple input methods.
Keypad Definition - The definition of keypad is as follow:
Left key: Enter and OK
Right key: Back and Cancel
Navigate Keys: Cursor move or choose word.
# Key: Switch input methods.
2-9 key: Input the letter on the keys when input.
* Key: Input symbols

10 En
FUNCTION LIST
Phonebook
You can save the contacts in the mobile phone and SIM card; it depends on the SIM card memory
capacity. When you select a contact, you can do the following operations:
View: To view the contact
Send text message: Send text message to the current number.
Call: To Call the current number.
Edit: To edit the current contact.
Delete: To delete the current contact.
Copy:To copy the contact from phone to SIM card /phone or from SIM card to SIM card /phone or copy to
file.
Phonebook settings: To set the Phonebook.
Call logs
In this function menu, you can check the All calls, Dialled calls, Received calls, Missed calls, and You
can perform the following operations:
View: To check the call history.
Send text message: Send SMS to the Dialled calls, Received calls or Missed calls.
Call: To call the Dialled calls, Received calls or Missed calls.
Save to Phonebook: You can add the number to the phonebook or replace existing contacts.

11 En
Edit before call: Edit the number before you call
Delete.
File manager
Press left key option to enter functional menu, the following options are available:
- Open: See the files in the different folders of your phone
Camcorder
The built-in camera allows you to take photos and adjust the camera settings. The options menu contains
the following choices:
•Switch to: Switch phone to video recorder.
•Photos: See all the photos.
•Camera Settings: Select to open many advantage setting items.
•Image settings: Select to change the size and the quality of the image
•Storage: Select the place where the photos will be stored.
Multimedia
•Viewing images
•Recording videos
•Play video
•Playback audio files

12 En
•Register sounds
•FM Radio
Image Viewer
The options for image viewer are as follows:
•View: To view a photo.
•Send: Transformthe photos by different ways, such as multimedia message or via Bluetooth.
•Use as: This photo can be used as wallpaper.
•Rename: To rename the selected image or photo.
•Delete: To delete the selected photo.
•Image information: You can view the image information.
Audio Player
This phone comes with an inbuilt audio player that plays all your favorite songs. It gives you a host of setting
options to make your listening experience interesting.
1. Play: To start playing the audio file.
2. Details: To show the details of the selected file.
3. Refresh list: To refresh the audio file list.
4. Settings: To set parameters for audio playing.

13 En
Video Player
The Video Player plays all your video files stored in the phone (Phone Memory or on the Memory Card).
The video player gives you the following options:
1. Play: To start playing the video file.
2. Send: Send the video via Bluetooth or MMS.
3. Rename: To rename the video.
4. Delete: To delete the video.
5. Storage: Allow you to set the location of the videos.
Sound Recorder
You can record sound/voice on your phone. Just select sound recorder, go to options and press “New
record”. Select Stop to save it. Select pause to ‘pause’ the recording and ‘continue’ to resume the recording.
FM Radio
•Channel list: List out all the current channels. You can enter channel list, edit it and display the
searched channel list.
•Manual input : Input the desired broadcasting channel manually
•Auto Search: Search and create the channel’s list automatically.
Flashlight
Whenever you need a flashlight and do not have it handy, D1 Flip can take over this function.

14 En
Messaging
Your phone supports various messaging services. You can create, send, receive, edit and organize
text messages.
Messages contain the following folders:
•Write Message: On selecting Write Message, you can input the contents of the message using
different input methods.
•Drafts: You can save a message you edit in the drafts.
•Delete messages: Delete all the unwanted messages.
•Message Settings: Message settings store all the different settings responsible for sending and
receiving messages.
Bluetooth
The following options are available in the Bluetooth menu:
1. Power: On/Off
2. Visibility: On/Off
3. My device: Inquiry new device or display paired devices and take the options.
4. Search audio device: Search for audio devices.
5. My name :You can change the name of the Bluetooth.

15 En
Calendar
You can use the calendar to keep track of important meetings. After entering the calendar function
menu you can select year, month and date using direction keys. On a selected date you can select to
view:
Jump to date: To input the date to enter the calendar, then move the cursor to the specified date.
Go to today: Go to check today.
Start of week: You can select from Sunday or Monday.
Alarm
The Alarm can be set to ring at a specific time on several days. There are five different default alarms.
You can set these alarms to alarm you at different time in specific day(s) of a week.
To set an alarm:
1. Press edit to enter alarm settings menu.
2. Select edit option using up and down direction keys
•ON/OFF: Select alarm on or off using left and right direction key
•Alarm time: Input alarm time
•Repeat Setting: Press navigation keys to select alarm types which consists of one time,
everyday and custom.
•Alarm tone: You can select the alarm tone.

16 En
Settings
Under settings, the phone gives you the option to change the settings for various features of the phone.
The following list is available in Settings:
Phone Settings
You have following options listed under phone setup:
Time and date: Let you set the Time and date on the phone.
Schedule power on/off: Let you set the phones powering on/off.
Language: To select language for the phone.
Display: Under Display setup, you can set wallpaper, etc.
Flight mode
Network Settings Network setup gives the user the ability to select a desired network and addition of a
new network to the network list. The network setup gives you the follow options:
SIM1/2 network settings:
1. Network Selection: new search, select network, selection mode –automatic/manual
2. Preferences: Will list down all the network IDs (depending on the SIM card used)
GPRS transfer preferences: data or call
Security Settings
Under Security Setup, you can change the security settings of SIM1 or SIM2.
SIM1/2 Security Settings:
•PIN Lock: PIN Lock protects illegal usage of the SIM card.
•Change PIN: You can change the PIN password.

17 En
•Change PIN2: You can change the PIN2 password
Phone security: Enables you to lock/unlock your phone with a password.
Connectivity Choose the phone networks.
Restore Settings Selecting this option will ask you to enter the password to restore the phone to factory
settings. The default password is ‘1234’.
WARNINGS AND NOTES
Operational Warnings
IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. Read this information before
using your phone. For the safe and efficient operation of your phone, observe these guidelines:
Potentially explosive at atmospheres: Turn off your phone when you are in any areas with a
potentially explosive atmosphere, such as fueling areas (gas or petrol stations, below deck on boats),
storage facilities for fuel or chemicals, blasting areas and areas near electrical blasting caps, and areas
where there are chemicals or particles (Such as metal powders, grains, and dust) in the air.
Interference to medical and personal Electronic Devices: Most but not all electronic equipment is
shielded from RF signals and certain electronic equipment may not be shielded against the RF signals
from your phone.

18 En
Audio Safety: This phone is capable of producing loud noises which may damage your hearing. When
using the speaker phone feature, it is recommended that you place your phone at a safe distance from
your ear.
Other Media Devices, hospitals: If you use any other personal medical device, consult the
manufacture of your device to determine if it is adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this information. Turn your phone OFF in health care
facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care
facilities may be using equipment that could be sensitive to external RF energy.
Product statement on handling and use: You alone are responsible for how you use your phone and
any consequences of its use.
You must always switch off your phone wherever the use of a phone is prohibited. Use of your phone is
subject to safety measures designed to protect users and their environment.
Always treat your phone and its accessories with care and keep it in a clean and dust-free place Do not
expose your phone or its accessories to open flames or lit tobacco products. Keeping the side cover
closed assures protection against liquids or dust.
Do not expose your phone or its accessories to liquid, moisture, or high humidity. Do not
drop, throw, or try to bend your phone or its accessories
Do not use harsh chemicals, cleaning solvents, or aerosols to clean the device or its accessories.
Do not attempt to disassemble your phone or its accessories; only authorized personnel must do so.

19 En
Do not expose your phone or its accessories to extreme temperatures, minimum 32° and maximum 113°
F (0 to 45° C).
Battery: Your phone includes an internal lithium-ion or lithium-polymer battery. Please note that use of
certain data applications can result in heavy battery use and may require frequent battery charging.
Any disposal of the phone or battery must comply with laws and regulations pertaining to lithium-ion or
lithiumion polymer batteries.
Faulty and damaged products: Do not attempt to disassemble the phone or its accessory. Only
qualified personnel must service or repair the phone or its accessory.
For more product details visit www.allviewmobile.com. Do not cover the antenna with your hand or other
objects Failure to comply resulting in connectivity issues and rapid discharge of the battery.
All applications provided by third parties and installed in this device, may be modified and/or stopped at
any moment. Visual Fan Ltd will not be responsible in any way for modifications of the services or content
of these applications. Any request or question regarding third party applications may be addressed to
owners of these applications.

22 Es
Medidas de seguridad
IMPORTANTE! Por favor, lea atentamente estas instrucciones y sígalas por defecto, en caso de
situaciones peligrosas.
Seguridad en la conducción: Se recomienda que no utilice su teléfono mientras está conduciendo. Si
usted necesita usarlo, siempre use el "manos libre" al conducir.
Apague su teléfono cuando estás en el avión. Interferencia causada por los teléfonos móviles
afectan la seguridad aérea y, como tal, es ilegal usarlo en el avión. Por favor asegúrese que su
teléfono móvil esté apagado cuando estás en el avión.
En el hospital: Cuando usas el teléfono en un hospital, tienes que respetar las normas especificadas
por el hospital.
Talleres aprobados: Sólo los talleres aprobados pueden reparar los teléfonos móviles. Si abre el
teléfono y trate de repararlo usted mismo perderá la garantía del producto.
Accesorios y baterías: Pueden utilizarse únicamente accesorios y baterías aprobadas por el fabricante.
Llamadas de emergencia: Asegúrese de que el teléfono esté encendido y activado si desea hacer
una llamada de emergencia al 112, pulse la tecla llamar y confirmar la localización, por favor explique
lo que sucedió y no cuelgue.
La batería y su carga: Se recomienda cargar la batería antes del primer uso. No exponga la batería a
temperaturas superiores a + 40°C. No arroje las baterías al fuego o al azar.
