ALMAC ATHENA 850-BL EVO Setup guide

ATHENA 850-BL EVO
Translationoforiginalinstructions
Prior to commissioning the machine read carefully this Use and
Maintenance Manual
Note: table of contents at the end of the manual
Edition
Date
00
23/02/2018
All manuals and user guides at all-guides.com

PAGE 2 ALMAC s.r.l.
1GENERAL INFORMATION
1.1 Documents supplied with each machine
•CE Declaration of conformity
•Instruction Manual (this manual)
•Spare Parts Manual
•Wiring diagrams and hydraulic layouts
•Report register
1.2 Details of Manual
•Instruction manual for Elevating work platform
•Version: ATHENA 850-BL EVO
Note: Some of the photos and illustrations may not refer specifically to the
version of the machine in your possession, but provide indications concerning
the purpose for which they have been included.
RECIPIENTS OF THIS MANUAL
•User
•Maintenance technician
Warning: the servicing personnel must be properly trained and experienced.
CAREFULLY READ this manual before performing any operation on the machine.
If in doubt, do not improvise. Call the assistance service.
All manuals and user guides at all-guides.com

PAGE 3 ALMAC s.r.l.
1.3 Ownership of the information
This document contains confidential information. All rights reserved.
This manual may be neither partially nor totally duplicated without the prior
written authorization of ALMAC s.r.l.
This document may only be used by the customer to whom the manual has been
supplied along with the machine, and only for the purpose of use and
maintenance of the machine to which the manual refers.
ALMAC s.r.l. hereby declares that the information in this manual was congruent
with the technical and safety specifications of the machine to which the manual
refers. The manufacturer declines all liability for direct or indirect damage to
persons, things or animals deriving from use of the machine in conditions
differing from those envisaged.
ALMAC s.r.l. reserves the right to make changes or improvements, without prior
notice, to the documentary material and to the machines, including marketed
machines of the same model as that to which this manual refers but with a
different serial number.
The information contained in this manual refers in particular to the machines
specified in "Identification data of the M.E.W.P." and related documentation.
1.4 Manufacturer's identification data
All manuals and user guides at all-guides.com

PAGE 4 ALMAC s.r.l.
1.5 MEWP identification data
The machine named ATHENA 850-BL EVO is defined according to the technical
standards in force (ref. UNI EN 280:2015), as:
Mobile Elevating Work Platform (MEWP), belonging to group B, type 3 (point
1.4-EN 280)
Meanings:
GROUP B: All types of mobile elevating work platforms other than "Group-A"
(mobile elevating work platforms where the vertical projection of
the centre of the platform area in all platform configurations at
the maximum frame inclination specified by the manufacturer is
always inside the tipping lines).
TYPE 3: mobile elevating work platforms where travelling with a raised
work platform is controlled from a point of control on the work
platform.
ASPAC GROUP
ELEVATING WORK PLATFORM
MANUFACTURER ALMAC s.r.l.
CAUTION. THIS PLATFORM IS NOT VOLTAGE INSULATED
YEAR OF
MANUFACTURE
DATE OF TEST
RATED LOAD INC. 2 OCCUPANT & TOOLS
MAX ALLOWABLE SIDE FORCE
MAX WIND SPEED
MAX PLATFORM HEIGHT
MAX WORKING HEIGHT
MAX HORIZONTAL WORKING OUTREACH
MAX UPPER GRADIENT IN RUNNING DIRECTION
COUNTRY OF MANUFACTURE
HYDRAULIC PRESSURE (TRAVEL)
HYDRAULIC PRESSURE (ELEVATING)
BATTERY VOLTAGE
MAX ALLOWABLE INCLINATION OF CHASSIS
THIS MACHINE COMPLIES WITH
STATE DESIGN REGISTRATION NUMBERS
NSW: VIC: SA: QLD:
Designed and Manufactured by: Distributed by:
Almac s.r.l. ASPAC GROUP
Via Ruggeri 6/A 3/84 Hallam South Road
42016 Guastalla (RE) Hallam Vic 3803
Italy Australia
12,5 m/s
ITALY
190 bar
1,01 mt
150 bar
12 V
1°
AS 1418.10.2011
250 kg
5,99 mt
7,99 mt
25° (47%)
40 daN
UNLADEN WEIGHT
WITH TRACKS
MODEL SERIAL
NUMBER
Kg
Identification plate
ATHENA 850-BL EVO
2018
ALM-000626
2060
All manuals and user guides at all-guides.com

PAGE 5 ALMAC s.r.l.
Refer to the data on the identification plate for an exact identification of the
MEWP.
All manuals and user guides at all-guides.com

PAGE 6 ALMAC s.r.l.
1.6 Performance
Below are the configurations that the mobile elevating work platform can have
during operation and transport.
F2F1 A4
D3
D1
1940
1630
A3
E
D4
D2
C2 C3 C1
B
A1A2
D6
D5
Dismantle only for special transport situations; before commissioning, the
machine must be reconfigured by skilled and authorised personnel,
according to the certified diagram, following the manufacturer's
instructions
All manuals and user guides at all-guides.com

PAGE 7 ALMAC s.r.l.
MAXIMUM WORKING HEIGHT, TRAVELLING NOT PERMITTED
H1 H2
G3
H3 H4
G4
G1
L1
G2
All manuals and user guides at all-guides.com

PAGE 8 ALMAC s.r.l.
Characteristic dimensions
Machine length
With work platform retracted
A1
mt
2.14
Machine length
With work platform extended
A2
mt
2.68
Length of work platform
With work platform retracted
A3
mt
1.50
Length of work platform
With work platform extended
A4
mt
2.24
Maximum width
Widened track
C1
mt
1.50
Maximum width
Narrow track
C2
mt
1.30
Height of crawler
B
mm
360
Width of crawler
C3
mm
250
Min height of floor surface
Widened track
D1
mt
1.34
Minimum height
Widened track
D2
mt
2.50
Min height of floor surface
Narrow track
D3
mt
1.64
Minimum height
Narrow track
D4
mt
2.80
Minimum height (transport only)
Widened track / railings closed
D5
mt
1.99
Minimum height (transport only)
Narrow track / railings closed
D6
mt
2.29
Width of work platform
E
mt
0.79
Distance between the crawler and the edge of
the work platform in width
Narrow track
F1
mm
260
Distance between the crawler and the edge of
the work platform in width
Widened track
F2
mm
360
Maximum work height
G1
mt
7.88
Min height of floor surface
G2
mt
5.88
Maximum work space in width
G3
mt
1.70
Maximum work space in length
G4
mt
3.25
Useful work distance in width
H1
mm
200
Useful work distance in width
H2
mm
200
All manuals and user guides at all-guides.com

PAGE 9 ALMAC s.r.l.
Useful work distance in length
H3
mm
70
Useful work distance in length
H4
mm
1140
Extension of work platform
L1
mt
0.74
Technical data
Capacity of work platform
kg
250
Number of operators on work platform
2
Lifting time (with 250Kg on the platform)
s
31
Lowering time
s
35/40
Hydraulic side-shift pressure
bar
200
Hydraulic lifting pressure
Bar
160
Oil tank capacity
l
20
Climb angle
°
25
Maximum side slope of the terrain
°
15
Maximum longitudinal slope of the terrain
°
20 / 16
Maximum travelling speed
km/h
2.0
Maximum speed with platform lifted
km/h
0.4
Overall weight
kg
2060
Max wind force
m/s
12.5
Starter battery voltage and capacity
V/Ah
12/50
Weight of starter battery
kg
15
Sound power LwA
dBA
104
Sound level at operator position Lp (indoor industrial environment)
dBA
84.5 ± 2.6
Sound level at operator position Lp (outdoor environment on
asphalt)
dBA
79.5 ± 2.6
Max peak level Lppeak
dBC
106.0
Vibrations transmitted to hand / arm system (operator hand
rest)
m/s2
< 2.5
Whole-body vibration (platform-measured on flat terrain)
m/s2
0.52 ± 0.10 *
Vibrations transmitted to hand / arm system (operator hand
rest)
m/s2
0.59 ± 0.12 **
* values referred to raised platform (operating height)
*** values referred to platform at the transport height limit
All manuals and user guides at all-guides.com

PAGE 10 ALMAC s.r.l.
All manuals and user guides at all-guides.com

PAGE 11 ALMAC s.r.l.
Maximum transport height allowed
(manual levelling and the adjustment of the travel speed is allowed)
Maximum travel height allowed
(manual levelling and the adjustment of the travel speed is not allowed)
All manuals and user guides at all-guides.com

PAGE 12 ALMAC s.r.l.
Standard equipment
Optional equipment
Proportional electrohydraulic controls
Electrical engine 230 V / 50
Hz
Internal combustion engine (KUBOTA Z482)
Sine wave inverter 1000W
Automatic accelerator
Cable remote control
Radio control
CANBUS display to manage working hours and
alarms
Dual speed gear motors
Warning buzzer
Anchorage points for lifting-lowering
Harness anchorage points
Doubled capacity on the lifting cylinder
Electric starter on work platform
Overload control
Dynamic levelling system of the machine
Electronic anti-shearing protection
Electronic tilt control
Proactive levelling system
Engine specifications
Z602-E3B TIER 4
Dry weight
53.1 kg
Type of engine
VERTICAL, 4-CYCLE LIQUID COOLED
Swept volume
479 cm3
Net power
9.9 kW @ 3600 rpm
Net torque
30 Nm @ 2500 rpm
Q.ty engine oil
2.5 Lt
Fuel tank capacity
30 Lt
Engine specifications
Electrical
Dry weight
14 kg
Installed power
2.2 kW
Torque
10.2 Nm
Rpm
1400
Power supply
230 V / 50 Hz
IEC Size
90
All manuals and user guides at all-guides.com

PAGE 13 ALMAC s.r.l.
1.7 CE Declaration of Conformity
See facsimile of CE declaration of conformity enclosed with this manual.
The machine described in this manual complies with the following standards:
•Directive 2006/42/EC – Machinery Directive that amends Directive
95/16/EC
•Legislative Decree D.Lgs 17/2010 – Implementation of Machinery Directive
2006/42/EC
•UNI EN 280:2015 - Mobile elevating work platforms - Design calculations -
Stability criteria - Construction - Safety - Examinations and tests
•*UNI EN 349:2008 – Minimum gaps to avoid crushing parts of the human
body
•EN ISO 12100:2010 Safety of machinery -General principles for design -
Risk assessment and reduction
All parts available on the market and “partly completed machinery” installed on
the platform conform to the aforementioned Directives and those that
specifically govern the product.
*For the scissor lifting devices, the anti-shearing function has been used, as
provided for in section 5.4.3 of UNI EN 280:2015 with permanent warning signs.
1.8 Warranty
ALMAC S.r.l. guarantees the equipment it manufactures and undertakes to
replace, free of charge and within the shortest possible time, those parts that,
in its opinion, possess manufacturing and/or material defects.
Work under guarantee must only be performed by workshops authorized by
ALMAC S.r.l. and only when the Customer is up to date with the payments.
The Customer will not be entitled to work under guarantee unless he consigns
the equipment for repair within 30 days from the date of the first complaint, to
be made in writing.
With the exception of fraud or gross negligence, ALMAC S.r.l. is relieved of all
liability towards the Customer for damage deriving from flaws/defects in the
traded equipment.
The warranty with which the Customer is provided becomes void if modifications
are made to the machines without prior written authorization from ALMAC S.r.l.
or should the Customer make incorrect/improper use of the machines.
All manuals and user guides at all-guides.com

PAGE 14 ALMAC s.r.l.
1.8.1 Request for interventions during warranty period and formalities
ALMAC S.r.l. must be notified of requests for spare parts or technical
interventions under guarantee as soon as a defect is discovered.
Always indicate the type of machine and its serial number when requesting
spare parts under guarantee or technical interventions under guarantee. This
information is given on the identification plate of the equipment.
1.9 Assistance
As far as the optimum use of the machine and extraordinary maintenance are
concerned, this manual does not replace the expertise of the Technical
Assistance sent by ALMAC S.r.l. (refer also to the Maintenance Chapter).
1.9.1 Request for assistance and repairs
To request ALMAC S.r.l. specialized Assistance Service, the Customer may
contact:
In case of intervention request, specify the machine version and serial number;
the data is indicated on the identification plate attached to the machine.
All manuals and user guides at all-guides.com

PAGE 15 ALMAC s.r.l.
1.10 Use of the manual
Note: Keep this manual in an accessible place known to all users (operators and
maintenance workers).
Note: This manual must be kept in a protected place inside the compartment
provided on the work platform so that it can be easily accessed for consultation
throughout the entire technical life of the machine.
Note: If this manual is lost or damaged, a new copy must be ordered from the
manufacturer. Specify the serial number of the machine (given on the relative
identification plate) when requesting a new copy of the manual. The
manufacturer undertakes to provide a new copy.
Note: When selling used equipment, this manual and the related attachments
must be included and the manufacturer must be informed of the new owner (see
Appendix 3 - Transfer of Ownership)
Read carefully Chapter 1 General Information, Chapter 2 Safety information,
Chapter 3 Description of the Machine and Performance, Chapter 4 Operating
instructions, Chapter 5 Emergency Procedures.
Always consult the relative chapter when using, servicing the machine or when
it is demolished.
All manuals and user guides at all-guides.com

PAGE 16 ALMAC s.r.l.
1.11 Intended use and improper uses
1.11.1 Intended use
The machine described in this manual is a self-propelled elevating work platform
designed to lift personnel and equipment to perform the following jobs:
•professional gardening and general work
•installation of systems and equipment
•cleaning
•painting and paint removal
The maximum allowed capacity for this model is 250 kg. Consider the following:
•2 (two) persons each weighing 80 kg
•90 kg of equipment
An electronic control system prevents the work platform from lifting to any
position when the load exceeds approx. 20% of the rated load given in the
technical specifications.
The platform was designed and built to be driven only from the console located
on the work platform.
The push-button is of the removable type and can only be used by the operator
to control the platform exclusively in transport position.
The controls on the ground on the rear side are for EMERGENCY use or
MAINTENANCE by qualified personnel.
Warning: NEVER exceed the machine's established maximum capacity.
Warning: It is FORBIDDEN to transport large slabs or materials since this could
increase wind resistance to a considerable extent and cause the machine to tip
over.
Warning: It is FORBIDDEN to apply horizontal loads to the platform when the
machine is moving (e.g. the operators on board must not pull ropes or cables…)
Warning: It is FORBIDDEN to use the machine to tow other equipment or
vehicles.
All manuals and user guides at all-guides.com

PAGE 17 ALMAC s.r.l.
Warning: the machine is designed to be driven around within public or private
areas. It is not designed for road circulation
Warning: The machine IS NOT SET FOR OPERATION IN ATEX CLASSIFIED
ATMOSPHERES
ALL LOADS must be positioned inside the work platform. NEVER LIFT LOADS
HANGING FROM THE PLATFORM, from the lifting structure or from the railings.
If the machine is used in places open to the public or in construction sites where
persons may transit or remain in the vicinity, the WORK AREA MUST BE
CORDONED OFF in a suitable way (e.g. chains and posts).
All manuals and user guides at all-guides.com

PAGE 18 ALMAC s.r.l.
1.11.2 Improper uses
Any other use not specifically indicated in 1.11.1 Intended use.
•The improper uses established for this MEWP include lifting and lowering
persons to/from different storeys within space (typical use of elevators).
•It is also forbidden to drive the platform to the ground using the mobile
push-button panel with an operator on the work platform.
The platform was designed and built to be driven only from the console
located on the work platform. The controls on the ground on the rear side
are for EMERGENCY use or MAINTENANCE by qualified personnel.
The push-button panel is of the removable type and can only be used by
the operator to control the platform exclusively in transport position.
1.11.3 Cases that relieve the manufacturer from liability
The manufacturer declines all liability in the following cases:
•Use not indicated in this manual
•Improper use of the machine or its use by untrained personnel
•Use that fails to comply with the specific standards
•Lack of scheduled maintenance
•Unauthorized changes or interventions
•Removal of seals
•Use of non-original replacement parts
•Total or partial failure to comply with the instructions
•Failure to perform the Routine Inspections required by the laws in force
All manuals and user guides at all-guides.com

PAGE 19 ALMAC s.r.l.
2SAFETY INFORMATION
2.1 Notification of commissioning and routine inspections
The work equipment indicated in Annex VII to Legislative decree D.Lgs 81/2008
and successive amendments must be subjected to REGISTRATION and ROUTINE
INSPECTIONS by the competent authorities, i.e. INAIL, the National Institute for
Insurance Against Industrial Accidents (former ISPESL, Higher Institute for
Prevention in the Workplace), the Local Health Authority and other public and
private bodies established by the criteria laid down in Ministerial decree DM
11/04/2011.
•The User or Employer must notify Commissioning to the territorially
competent National Institute for Insurance Against Industrial Accidents
(INAIL) for the purpose of registering the platform.
•Once the platform has been registered, ROUTINE INSPECTIONS must begin.
The FIRST of these is performed by INAIL within 45 days (since 21 August
2013) from the date on which the platform is put into service.
•The successive inspections, to be carried out at the frequency indicated in
Annex VII to Legislative Decree D.Lgs 81/2008, are carried out by the Local
Health Departments (ASL) or, when permitted by the regional laws, by ARPA
(Regional Agency for the Protection of the Environment) or by Public or
Private undertakings, as freely decided by the Employer or User and in
accordance with the established formalities.
Attached are a few EXAMPLES of "notice of commissioning" and "routine
inspections". Users should check them each time in the www.inail.it portal,
according to the installation site in question.
All manuals and user guides at all-guides.com

PAGE 20 ALMAC s.r.l.
2.2 Fitness of the personnel
The operators who use the machine must be properly trained, informed,
instructed on how to use the machine in safe conditions and must possess a
training certificate issued in accordance with the laws in force at the time of
use*.
The operators who use the machine must be over 18 years of age and be
recognized as psychophysically fit for the task in question. The following
requirements must be ascertained before the operators are allowed to drive the
machine:
•sight and hearing in good conditions
•absence of changes induced by use of alcohol or drugs
•psychological equilibrium, absence of depression or stress
Operators who use the machine for professional purposes must undergo health
surveillance as required by Legislative decree D.Lgs 81/2008 and successive
amendments, particularly with regard to alcohol addiction and alcohol
concentration tests.
*The law that currently governs health control and surveillance of workers is
the Provision of the State-Regions Permanent Conference of 16 March 2006.
Note: ALMAC S.r.l. declines all liability for damage to persons, animals and
things deriving from:
•failure to comply with the safety regulations
•use of the machine by unqualified operators
•failure to comply with the recommendations in the documentation supplied
All manuals and user guides at all-guides.com
