Vestil MRR Series User manual

rev. 7/12/2016
MRR & MPR Series.docx
Copyright 2016 Vestil Manufacturing Corp. Page 1 of 7
VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN
46703
Telephone: [phone] -or-Toll Free [phone]
MRR- SERIES &MPR SERIES,MULTIPURPOSE RAMPS
INSTRUCTION MANUAL
MPR-2410
MPR-2313-G
MRR-2310
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the packaging and
maintains the orientation of the product in the packaging; then inspect the product closely to determine whether it
sustained damage during transport. If damage is discovered during the inspection, immediately record a
complete description of the damage on the bill of lading. If the product is undamaged, discard the packaging.
Notes:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where the product is
used is exclusively the responsibility of the owner/end-user.
2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either: a) the
instructions in this manual; or b) information provided on labels affixed to the product. Neither is Vestil responsible for
any consequential damages sustained as a result of failing to exercise sound judgment while assembling, installing,
using or maintaining this product.
Table of Contents
Hazard identification: explanation of signal words…………………………………………………...……………..…….
2
Safety Guidelines……………………………………………………………………………………………………….........
2
Operation…………………………………………………………………………………………………...……….…………
3
Inspections & Maintenance………………………………………………………………………………………………….
6
Limited warranty…………………………………………………………………………………………………...…..……..
7

rev. 7/12/2016
MRR & MPR Series.docx
Copyright 2016 Vestil Manufacturing Corp. Page 2 of 7
HAZARD IDENTIFICATION: explanation of signal words
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the probable
seriousness of those injuries, if the product is misused in the ways described. Other signal words call attention to
uses of the product likely cause property damage.
The signal words used appear below along with the meaning of each word:
Each person who assembles, installs, uses, or maintains this product should read the entire manual and fully
understand the directions in advance. If after reading the manual you do not understand an instruction, ask
your supervisor or employer for clarification, because failure to adhere to the directions in this manual might
result in serious personal injury.
SAFETY GUIDELINES
Vestil diligently strives to identify foreseeable hazards associated with the use of its products. However, material
handling is inherently dangerous and no manual can address every conceivable risk. The end-user ultimately is
responsible for exercising sound judgment at all times.
Electrocution might result if any part of the product contacts electrified wires. Reduce the likelihood of
electrocution by applying common sense:
DO NOT contact electrified wires with any part of this device, your body, or clothing.
DO NOT use or store the product where contact with electrified wires is likely.
1. Always inspect the usage area before using the product & implement precautions that account for conditions.
If this product is used improperly or carelessly, the operator and/or bystanders might sustain serious
personal injuries or even be killed. To reduce the likelihood of injury:
Failure to read and understand the entire manual before assembling, installing, using or servicing the
product is a misuse of the product.
Read the manual to refresh your understanding of proper use and maintenance procedures.
DO NOT attempt to resolve any problem(s) with the product unless you are both authorized to do so and certain
that it will be safe to use afterwards.
DO NOT modify the product in any way UNLESS you first obtain written approval from Vestil. Unauthorized
modifications automatically void the Limited Warranty and might make the product unsafe to use.
DO NOT exceed the maximum rated load (see Label 287 on product).
Inspect the product before each use.
A. DO NOT use this product if the inspection reveals structural damage. Examples of structural damage
include, but are not limited to, the following: 1) Cracked, broken or significantly deformed load-bearing
members; 2) cracked welds; 3) missing or deformed safety chain/strap; 3) corrosion, severe wear, or other
condition that affects the ability of the product to support weight or itself. Replace each part that fails to
pass an inspection, and DO NOT use the product until it is fully restored to normal condition.
B. DO NOT use the product if any unusual noise or movement is observed. If a malfunction occurs, remove
the unit from service and notify your supervisor & maintenance personnel about the issue.
DO NOT use this device UNLESS all product labels (see “Label Placement Diagram”) are readable and
undamaged.
Proper use, maintenance, and storage are essential for this product to function properly.
oAlways use this product in accordance with the instructions in this manual and consistent with any training
relevant to machines, devices, etc. used in conjunction with this product.
oKeep the product clean & dry. Lubricate moving parts.
oFOR HYDRAULIC UNITS: Do not use brake fluid or jack oils in the hydraulic system. If oil is needed, use an anti-
wear hydraulic oil with a viscosity grade of 150 SUS at 100°F, (ISO 32 cSt @ 40°C), or Dexron transmission fluid.
oContact the manufacturer for MSDS information.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that
might damage the product.

rev. 7/12/2016
MRR & MPR Series.docx
Copyright 2016 Vestil Manufacturing Corp. Page 3 of 7
Operation
Ramp Application
Do not exceed the ramp’s load rating. The ramp would fail to perform and could result in
equipment damage or personal injury. Reference the Exploded Parts diagram below.
The floor surface should be smooth so the entire ramp sets firmly on the floor. The loads are
distributed across this surface. If the surface is not smooth, the load stresses in the ramp may
exceed the ramp’s capacity and break and result in equipment damage and/or personal injury.
If the ramp’s height and the step’s height need to be the same. A difference in height may result
in a user mis-stepping and result in equipment damage and/or personal injury.
Bridge Application
Do not exceed the bridge’s load rating. The bridge would fail to perform and could result in
equipment damage or personal injury. Reference the Exploded Parts diagram below.
The floor surface should be smooth so the entire bridge sets firmly on the floor. The loads are
distributed across this surface. If the surface is not smooth, the load stresses in the ramp may
exceed the ramp’s capacity and break and result in equipment damage and/or personal injury.
The bridge should not set on or compress the cords, pipe or object(s) being bridged. The objects
should move freely while bridge is in use to prevent their damage.
Curb
Curb
Ramp properly positioned
to curb or step
Curb
Curb
Curb
Curb
Ramp improperly positioned
to curb or step
Ramp below Curb
Ramp above Curb
Gap between Ramp and Curb

rev. 7/12/2016
MRR & MPR Series.docx
Copyright 2016 Vestil Manufacturing Corp. Page 4 of 7
Exploded Parts Diagram and Bill of Materials
MPR Series

rev. 7/12/2016
MRR & MPR Series.docx
Copyright 2016 Vestil Manufacturing Corp. Page 5 of 7
MRR Series

rev. 7/12/2016
MRR & MPR Series.docx
Copyright 2016 Vestil Manufacturing Corp. Page 6 of 7
Inspections & Maintenance
Each Use:
Inspect the ramp for cracks, evidence of yields or stretch plastic/rubber.
Inspect the hardware for bridged ramps. The fasteners should be tight and secure to perform their function.
Inspect the bridge features. The walls should be undamaged so cords, pipes and objects can freely move while the
bridge is in use.
If rust is present on the bracket, prepare the surface and paint.
If rust is present on the fasteners, replace with new hardware.

rev. 7/12/2016
MRR & MPR Series.docx
Copyright 2016 Vestil Manufacturing Corp. Page 7 of 7
LIMITED WARRANTY
Vestil Manufacturing Corporation (“Vestil”) warrants this product to be free of defects in material and workmanship
during the warranty period. Our warranty obligation is to provide a replacement for a defective original part if the part is
covered by the warranty, after we receive a proper request from the warrantee (you) for warranty service.
Who may request service?
Only a warrantee may request service. You are a warrantee if you purchased the product from Vestil or from an
authorized distributor AND Vestil has been fully paid.
What is an “original part”?
An original part is a part used to make the product as shipped to the warrantee.
What is a “proper request”?
A request for warranty service is proper if Vestil receives: 1) a photocopy of the Customer Invoice that displays the
shipping date; AND 2) a written request for warranty service including your name and phone number. Send requests
by any of the following methods:
Mail Fax Email
Vestil Manufacturing Corporation [phone] [email protected]
2999 North Wayne Street, PO Box 507 Phone
Angola, IN 46703 [phone]
In the written request, list the parts believed to be defective and include the address where replacements should be
delivered.
What is covered under the warranty?
After Vestil receives your request for warranty service, an authorized representative will contact you to determine
whether your claim is covered by the warranty. Before providing warranty service, Vestil may require you to send the
entire product, or just the defective part or parts, to its facility in Angola, IN. The warranty covers defects in the
following original dynamic components: motors, hydraulic pumps, electronic controllers, switches and cylinders. It also
covers defects in original parts that wear under normal usage conditions (“wearing parts”): bearings, hoses, wheels,
seals, brushes, batteries, and the battery charger.
How long is the warranty period?
The warranty period for original components is 30 days. The warranty period begins on the date when Vestil ships the
product to the warrantee. If the product was purchased from an authorized distributor, the period begins when the
distributor ships the product. Vestil may extend the warranty period for products shipped from authorized distributors
by up to 30 days to account for shipping time.
If a defective part is covered by the warranty, what will Vestil do to correct the problem?
Vestil will provide an appropriate replacement for any covered part. An authorized representative of Vestil will contact
you to discuss your claim.
What is not covered by the warranty?
1. Labor;
2. Freight;
3. Occurrence of any of the following, which automatically voids the warranty:
Product misuse;
Negligent operation or repair;
Corrosion or use in corrosive environments;
Inadequate or improper maintenance;
Damage sustained during shipping;
Collisions or other incidental contacts causing damage to the product;
Unauthorized modifications: DO NOT modify the product IN ANY WAY without first receiving written
authorization from Vestil. Modification(s) might make the product unsafe to use or might cause excessive
and/or abnormal wear.
Do any other warranties apply to the product?
Vestil Manufacturing Corp. makes no other express warranties. All implied warranties are disclaimed to the extent
allowed by law. Any implied warranty not disclaimed is limited in scope to the terms of this Limited Warranty.
