alphainnoTec LW Series User manual

We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
HEAT PUMPS
Operating Manual
Inside installation
A IR / WAT ER
UK
LW 100 - LW 190
LW 150H(L)

2We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Please read rst
This operating manual provides important information
on the handling of the unit. It is an integral part of the
product and must be stored so that it is accessible in the
immediate vicinity of the unit. It must remain available
throughout the entire service life of the unit. It must be
handed over to subsequent owners or operators of the
unit.
Read the operating manual before working on or oper-
ating the unit. This applies in particular to the chapter
on safety. Always follow all instructions completely and
without restrictions.
It is possible that this operating manual may contain
instructions that seem incomprehensible or unclear. In
case of questions or uncertainty, contact the factory
customer service department or the manufacturer’s
local service partner.
Since this operating manual was written for several
different models of the unit, always comply with the
parameters for the respective model.
This operating manual is intended only for persons
assigned to work on or operate the unit. Treat all
constituent parts condentially. The information
contained herein is protected by copyright. No part
of this information may be reproduced, transmitted,
copied, stored in electronic data systems or translated
into another language, either wholly or in part, without
the express written permission of the manufacturer.
Symbols
The following symbols are used in the operating manual.
They have the following meaning:
Information for operators.
Information or instructions for qualied techni-
cians.
DANGER!
Indicates a immediate danger of serious
injuries or death.
WARNING!
Indicates a potentially dangerous situa-
tion that could result in serious injuries or
death.
CAUTION!
Indicates a potentially dangerous situation
that could result in medium or slight inju-
ries.
CAUTION.
Indicates a potentially dangerous situa-
tion, which could result in property dam-
age.
NOTICE.
Emphasised information.
€ENERGY SAVING TIP
Indicates suggestions that help to save en-
ergy, raw materials and costs.
Reference to other sections of the operating
manual.
Reference to other documents of the manufac-
turer.

3
Contents
INFORMATION FOR OPERATORS AND
QUALIFIED SPECIALISTS
PLEASE READ FIRST..................................................................2
SYMBOLS .....................................................................................2
INTENDED USE..........................................................................4
EXCLUSION OF LIABILITY......................................................4
EC CONFORMITY .....................................................................4
SAFETY.........................................................................................4
CUSTOMER SERVICE ................................................................5
WARRANTY
/ GUARANTEE..................................................5
DISPOSAL ....................................................................................5
INFORMATION FOR OPERATORS
FUNCTIONING PRINCIPLE OF HEAT PUMP SYSTEM......6
AREA OF UTILISATION............................................................6
HEAT QUANTITY RECORDING ............................................6
OPER ATION................................................................................6
CARE OF THE UNIT..................................................................7
MAINTENANCE OF THE UNIT...............................................7
Cleaning and rinsing of unit components..........................7
MALFUNCTIONS.......................................................................7
INSTRUCTIONS FOR QUALIFIED TECHNICIANS
SCOPE OF DELIVERY ................................................................8
INSTALLATION AND ASSEMBLY...........................................9
Installation location..............................................................9
Transport to installation location......................................9
Installation............................................................................10
Mounting the air ducts.......................................................11
Installation / connection to heating circuit ...................15
Condensate discharge........................................................16
PRESSURE RELIEF.....................................................................17
OVERFLOW VALVE..................................................................17
BUFFER TANK...........................................................................17
CIRCULATING PUMPS ...........................................................17
WATER HEATING ....................................................................17
HOT-WATER TANK.................................................................17
ELECTRICAL CONNECTIONS .............................................18
RINSING, FILLING AND BLEEDING THE SYSTEM ..........19
INSULATING THE HYDRAULIC CONNECTIONS ..........19
INSTALLATION OF THE CONTROL ELEMENT ...............19
INSTALLATION AND REMOVAL OF THE SCREEN.........20
COMMISSIONING ...................................................................22
Safety temperature limiter................................................22
DISMANTLING .........................................................................23
TECHNICAL DATA / SCOPE OF DELIVERY
LW 100 - LW 190................................................................24
LW 150H(L) .........................................................................26
PERFORMANCE CURVES
Heating capacity/COP / power consumption /
Heat pump pressure loss
LW 100 .................................................................................28
LW 120..................................................................................29
LW 150..................................................................................30
LW 190..................................................................................31
LW 150H(L) .........................................................................32
DIMENSIONAL DRAWINGS AND INSTALLATION PLANS
Dimensional drawings
LW 100, LW 120, LW 150H ..............................................33
LW 150HL ............................................................................34
Installation plans LW 100, LW 120, LW 150H(L)
Installation plan version 1 .................................................35
Installation plan version 2 .................................................36
Installation plan version 3 .................................................37
Installation plan version 4 .................................................38
Installation plan version 5 .................................................39
Dimensional drawings
LW 150 - LW 190............................................................... 40
Installation plans LW 150, LW 190
Installation plan version 1 .................................................41
Installation plan version 2 .................................................42
Installation plan version 3 .................................................43
Installation plan version 4 ................................................ 44
TERMINAL DIAGRAMS
LW 100 - LW 190. LW 150H(L)........................................45
CIRCUIT DIAGRAMS
LW 100, LW 120 .................................................................46
LW 150, LW 190..................................................................49
LW 150H(L) .........................................................................52
APPENDIX
EC DECLARATION OF CONFORMITY..............................55
GENERAL CHECKLIST ...........................................................57
COMPLETION REPORT FOR HEAT PUMP SYSTEMS ......59
SPACE FOR NOTES .................................................................61
CUSTOMER SERVICE
Addresses in the event of a service call..........................62
We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH

4We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Intended use
The unit may be used only for the intended purpose.
This means:
•for heating.
•for heating hot water.
The unit may be operated only within its technical
parameters.
Overview "Technical data / scope of delivery“.
NOTICE.
Notify the responsible power supply com-
pany of the use of a heat pump or heat
pump system.
Exclusion of liability
The manufacturer will not be liable for damage resulting
from unauthorised use of the unit.
The manufacturer’s liability will also be voided in the
following cases:
•if work is performed on the unit and its compo-
nents in a manner that does not comply with the
terms of this operating manual;
•if work is performed on the unit and its compo-
nents in an improper manner;
•if work is performed on the unit that is not
described in this operating manual, and this work
was not expressly approved in writing by the
manufacturer;
•if the unit or components in the unit are modied,
redesigned or removed without the express writ-
ten permission of the manufacturer.
EC conformity
The unit bears the CE mark of conformity.
EC declaration of conformity
Safety
The unit is operationally safe when used for the intended
purpose. The construction and design of the unit
conform to the state of the art, all relevant DIN/VDE
regulations and all relevant safety regulations.
Every person who performs work on the unit must have
read and understood the operating manual prior to
starting any work. This also applies if the respective per-
son has already worked with such a unit or a similar unit
or has been trained by the manufacturer.
Every person who performs work on the unit must com-
ply with the applicable accident prevention and safety
regulations. This applies in particular to the wearing of
personal safety gear.
DANGER!
Unit operates using high electric voltage!
DANGER!
Danger of fatal injury due to electric
shock!
Electrical connections may be installed
only by qualied electricians.
Before opening the unit, disconnect the
system from the power supply and secure
it from being switched back on!
DANGER!
Only qualied technicians (trained heating,
cooling, refrigerant and electrical techni-
cians) may perform work on the unit and
its components.
WARNING!
Observe safety labels on and in the unit.
WARNING!
Unit contains refrigerants!
Leaking refrigerant can result in personal
injury or material damage. Therefore:
– Shut down unit.
– Notify the manufacturer’s authorised
service center.
CAUTION.
For safety reasons:
Never disconnect the unit from the power
supply, unless the unit is being opened.

5
We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
CAUTION.
Install the heat pump only indoors and
operate only with outside air as the heat
source. The air ducts must discharge into
the open air. Do not restrict or block the
air ducts.
Dimensional drawing and installation plan for
respective model.
WARNING!
Switch on unit only if air ducts are mounted
on the unit.
Take measures on the fan side to pre-
vent injuries from the rotating fan (above-
ground air duct discharge: weather grille,
below-ground air-channel discharge: rain
guard – accessories not included in scope
of delivery).
CAUTION!
The integration of the heat pump in venti-
lation systems is not permissible. The use
of the cooled air for cooling purposes is
not permitted.
CAUTION!
In the air outlet area the air temperature
is ca. 5 K below the ambient temperature.
Under certain climatic conditions, there-
fore, an ice layer can form in the air out-
let area. Install the heat pump so that the
air blower does not blow in the direction
of footpaths.
Customer service
For technical assistance, please contact your qualied
technician or the manufacturer's local service partner.
Overview "Customer service".
Warranty / Guarantee
For warranty and guarantee conditions, please refer to
the purchase documents.
NOTICE.
Please contact your dealer concerning
warranties and guarantees.
Disposal
When decommissioning the unit, always comply with ap-
plicable laws, directives and standards for the recovery,
recycling and disposal of materials and components of
colling units.
Dismantling.

6We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Functioning principle of heat
pump system
Heat pumps operate on the principle of a refrigerator:
the same technology, only with the opposite effect. The
refrigerator extracts heat from foods, which is released
into the room through ns on the back.
The heat pump extracts heat from our environment:
air, earth or ground water. The extracted heat is condi-
tioned in the unit and supplied to the heating water. Even
when it is extremely cold outside, the heat pump draws
enough heat to heat a house.
Example: drawing of a brine/water heat pump with oor
heating:
4⁄4= usable energy
ca. 3⁄4= environmental energy
ca. 1⁄4= external
electrical energy
Area of utilisation
Taking into consideration the ambient conditions, limits
of application and the applicable regulations, every heat
pump can be utilized in new or existing heating systems.
Overview "Technical data/scope of delivery".
Heat quantity recording
In addition to proof of the unit's efciency, heating
legislation also requires heat quantity recording (referred
to as WME in this manual). The WME is mandatory with
air/water heat pumps. With brine/ water and water/
water heat pumps, a WME is only required when the
feed temperature is ≥35 °C. The WME must record the
total warm energy release (heating and hot water) in
the building. In heat pumps with heat quantity recording,
the analysis is conducted by the regulator. The regulator
displays the thermal energy that is exchanged from the
heating system in kWh.
Operation
Your decision to purchase a heat pump or a heat pump
system is a long-term contribution to protecting the
environment through low emissions and reduced primary
energy use.
You can operate and control the heat pump system
with the control element of the heating and heat pump
regulator.
NOTICE.
Make sure that the control settings are
correct.
Operating manual of the heating and heat pump
regulator.
To ensure that your heat pump or heat pump system
operates efciently and ecologically, the following are
especially important:
€ENERGY SAVING TIP
Avoid unnecessarily high ow tempera-
tures.
A lower ow temperature on the hot wa-
ter side increases the efciency of the sys-
tem.
€ENERGY SAVING TIP
When letting in fresh air, do not leave
windows open for an extended period, thus
saving energy and reducing your heating
costs.

7
We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Care of the unit
The outer surfaces of the unit can be cleaned with a
damp cloth and household cleaning products.
Do not use cleaning or care products that contain
abrasives, acids and/or chlorine. Such products would
destroy the surfaces and could also damage the technical
components of the unit.
Maintenance of the unit
The cooling circuit of the heat pump requires no regular
maintenance.
According to EU regulation (EC) 842/2006 of May 17,
2006, leak inspections and maintenance of a log book
are required by law for certain heat pumps!
The criteria for conducting leak inspections and main-
taining a log book are based on the hermetic impermea-
bility of the cooling circuit and the refrigerant capacity of
the heat pump! No log book is required for heat pumps
with a refrigerant capacity of < 3kg. With all other heat
pumps, the log book is included with all other delivered
materials.
Log book for heat pumps, Section "Information
on use of the log book".
The components of the heating circuit and the heat
source (valves, expansion vessels, circulating pumps, l-
ters, dirt traps) should be inspected as well as cleaned as
needed - at the very least annually - by a qualied heating
or cooling system technician.
It is a good idea to have a maintenance contract with
a specialist company. The company will conduct the
required maintenance at regular intervals.
Cleaning and flushing of unit Components
CAUTION!
Unit components may be cleaned
and ushed only by customer service
personnel authorised by the manufacturer.
Use only liquids recommended by the
manufacturer.
Flushing of the liqueer with chemical
cleaning agents must be followed by
neutralisation of residue and intensive
rinsing with water. Always observe the
technical data of the manufacturer of the
heat exchanger.
Malfunctions
In the event of a malfunction, you can detect the cause of
the malfunction via the diagnostic program of the heating
and heat pump regulator.
Operating manual of the heating and heat pump
regulator.
DANGER!
Service and repair work on the compo-
nents of the unit may be performed only by
customer service personnel authorised by
the manufacturer.
Overview “Customer service”.
Note that no malfunction is displayed if the safety tem-
perature limiter on the electric heating element has been
triggered (depending on model).
“Commissioning”, “Safety temperature limiter”
section.

8We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Scope of delivery
Example of scope of delivery:
View 1:
View 2:
Compact unit with a completely
hermetically enclosed compressor,
all safety-related components for
monitoring of the cooling circuit,
integrated heating and heat pump
regulator, sensors mounted in the
unit for the monitoring of hot gas,
heating water forward ow and
return ow temperatures, as well
as a hose for condensate discharge
(connected to heat pump side)
Proceed as follows:
Inspect delivery for outwardly visible signs of
damage.
Check to make sure that delivery is complete.
Any defects or incorrect deliveries must be claimed
immediately.
NOTICE.
Note the model. Check the air blow-out
direction of the unit.
– Units with the abbreviation L in the
model designation blow the air out to
the left (when viewed from the control
side).
Overview "Technical data / scope of delivery".
aCCessories neCessary for operation
CAUTION.
Use only original accessories from the
manufacturer of the unit.
Air ducts (with air duct accessories) must be ordered
separately.
additional aCCessories
The installation accessories (vibration decouplers) for
air/water indoor installation heat pumps must be ordered
separately.

9
We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Installation and assembly
Observe the following when performing all work:
NOTICE.
Always comply with applicable accident
prevention regulations, statutory regula-
tions, ordinances and directives.
WARNING!
The heat pump or heat pump system may
be installed and assembled only by a quali-
ed technician!
NOTICE.
Observe the sound levels of the respective
model.
Overview “Technical data / scope of delivery”,
“Sound” section.
installation loCation
CAUTION.
Install the unit only indoors.
The installation area must be frost-free and dry. It must
meet the requirements of DIN EN 378. It must also fulll
applicable local regulations.
Dimensional drawing and installation plan for
respective model.
transport to installation loCation
To prevent damage during transport, always transport
the unit to nal installation location in its original packag-
ing, using a lifting truck.
If it is not possible to transport the unit to the nal instal-
lation location using a lifting truck, you can also transport
the heat pump using a hand truck or with pipes.
DANGER!
Several people are required to transport
the unit. Do not underestimate the weight
of the unit.
Overview “Technical data / scope of delivery”,
“General unit data” section.
DANGER!
Unit is not fastened to the wooden pallet.
Danger of tipping over during transport!
This can result in personal injury and dam-
age to the unit.
– Take suitable precautionary measures
to eliminate the danger of tipping.
DANGER!
Make sure to secure unit against slipping
during transport.
CAUTION.
Never use components and hydraulic
connections on the unit for purposes of
transport.
CAUTION.
Do not damage the hydraulic connections
under any circumstances.
CAUTION.
Do not tilt the unit more than a maximum
of 45° (in any direction).

10 We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
lifting the unit with pipes
The units can be lifted with 3/4" and/or 1" pipes (provided
by customer) that are suitable for the weight of the
respective unit. Special holes are provided in the frame
for this purpose.
Remove lower facing panels on the switch cabinet
side (= operator side) of the unit. To do so, loosen
quick-release screws. Turn counter-clockwise 90°...
1 Quick-release screws
2 Lower facing panel
Pull lower facing panel upwards and outwards,
detach and set securely to the side...
On the back of the unit, remove the sealing
grommet...
installation
Set the unit on a stable, solid and level, preferably
sound-insulated surface. Make sure that the foundation
is designed for the weight of the heat pump.
CAUTION.
In the air outlet area the air temperature
is ca. 5 K below the ambient temperature.
Under certain climatic conditions, there-
fore, an ice layer can form in the air outlet
area.
Install the heat pump so that the air
blower does not blow in the direction of
footpaths.
DANGER!
Several people are required to install the
unit.
CAUTION.
Do not tilt the unit more than a maximum
of 45° (in any direction).
NOTICE.
Always observe the installation plan for
the respective model. Note the size and
minimum clearances.
Installation plan for respective model.
Set up the unit so that the switch cabinet side (= operat-
ing side) is accessible at all times.

11
We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Insert the pipes through the holes in the frame on
the switch cabinet side (= operator side)...
1 Holes in the frame
2 Inserted pipes
Make sure that pipes do not damage cable assem-
blies and components in the unit. Guide pipes care-
fully past cable assemblies and components in the
unit...
Guide pipes through the marked openings on the
back side of the unit...
Lift the unit on the pipes with at least four people
and carry it to its nal installation location...
NOTICE.
Carry the unit horizontally and secure it
against slipping.
Put the unit in its nal installation location. Make
sure that the frame of the unit is in full contact with
the underlying surface...
Remove the pipes and re-place the sealing grom-
mets on the back side of the unit...
If the electrical connections will not be carried out
directly thereafter, mount the lower facing panel on
the operating side.
mounting the air duCts
NOTICE.
Note the air blow-out direction of the
unit.
– Units with the abbreviation L in the
model designation blow the air out to
the left (when viewed from the control
side).
CAUTION.
Use only original accessories or air ducts
recommended by the manufacturer (bre-
glass lightweight concrete ducts).
Mount air ducts only according to the
installation plan for the respective unit.
Installation plan for respective model.
wall duCt(s) assembly
Proceed as follows:
Remove the parts necessary for the assembly of the
wall duct(s) from their respective boxes...
Next, interlock the 2 pieces of the wall duct(s) that
belong together, as illustrated in the following draw-
ing. Use the lubricant supplied upon delivery to help
in this process...

12 We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Afx an additional part as illustrated...
Rotate the already-interlocked parts 90° and afx
the nal piece at the bottom...
Rotate the already-interlocked parts by 90° once
again and set up the nal connection...
Stabilise the wall duct from the inside using the chip-
board included with delivery...
Install the wall duct in the masonry from the
house exterior. This can either be done during
the construction phase (by means of sealing)...
NOTICE.
Mount the wall ducts 1 cm above the n-
ished outer facade.
1 Masonry of the house exterior
2 Insert the wall duct in the
masonry (1 cm above the
nished outer facade)
or retrot (using foam in the masonry):
1 Finished outer facade
NOTICE.
Wall ducts x wall openings, help avoid
cold air transmission in the masonry as
well as assist in the assembly of weather /
rain guards and wire mesh grilles

13
We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
seCuring the air duCt into the wall duCt
Proceed as follows:
Pull the roll seal included with delivery over the end
of the air duct...
Push this end of the air duct into the wall duct.
1 Wall duct
2 Air duct
3 Roll seal
4 Bentonite waterproong tape
(apply only after assembling the
unit's connection fastener)
NOTICE.
After the other end of the air duct has
been secured to the heat pump, close the
opening between the wall duct and the air
duct using the bentonite waterstop tape
included with delivery.
air duCts assembly
Proceed as follows:
Remove the parts necessary for the assembly of the
air duct(s) from their respective boxes...
The interlocking of the air ducts is carried out
as described in the section – entitled "Wall
duct(s) assembly".

14 We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
sCreen frame assembly
Screw the screen frame to the wall ducts on both the air
intake and output sides.
NOTICE.
The screen frame has no function, it is
included solely to provide an optically
attractive transition to the wall duct.
wire mesh grille and weather / rain guards
assembly
Proceed as follows:
Remove the wire mesh grille and the weather / rain
guards as well as the assembly frame and fastening
material from their respective boxes...
From the outside of the house inwards, insert the
assembly frame into the wall duct on the air intake
side and secure with screws...
8 x
seCuring the air duCt on the heat pump
Proceed as follows:
Clip on the assembly rail and secure it using special
screws to the spots on the air duct designated as
the air intake side...
Stick the adapter base included with delivery on the
edge of the air duct...
Position the air duct on the respective opening of
the air intake side...
Hook the tension springs included with delivery
into the holes provided for them on the air intake
side of heat pump 4...
Hook the tension springs into the assembly tail that
has been screwed on to the air duct...
Secure a protective cap over the assembly rail...
Repeat – the process on the air output side.
NOTICE.
Don't forget:
After the air ducts have been secured to
the heat pump, close the opening between
the wall duct and the air duct using the
bentonite waterstop tape included with
delivery.
NOTICE.
Secure the air ducts to the cover using
appropriate measures.

15
We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Position the wire mesh grille in the assembly
frame...
Set the weather / rain guards on the assembly frame
in the wall duct and screw down...
8 x
NOTICE.
If the wall duct is positioned above ground
level, attach the weather guard.
If the wall duct is positioned in a light
well (below ground level), attach the rain
guard.
Repeat – the process on the air output side.
installation / ConneCtion to heating CirCuit
CAUTION.
Connect the unit to the heating circuit
according to the hydraulic diagram for the
respective model.
“Hydraulic connection” instructions.
NOTICE.
Check to make sure that the diameters
and lengths of the pipes for the heating
circuit are sufciently dimensioned.
NOTICE.
Circulating pumps must be multi-stage.
They must be able to deliver at least the
minimum hot water ow rate required for
your model.
Overview “Technical data / scope of delivery”,
“heating circuit” section.
CAUTION.
The hydraulic system must be equipped
with a buffer tank, the required volume of
which depends on the model of your unit.
Overview “Technical data / scope of delivery”,
“heating circuit, buffer tank” section.
CAUTION.
When installing the connections, always
secure the connections on the unit from
twisting, in order to prevent damage to
the copper pipes in the interior of the
unit.
Proceed as follows:
Rinse heating circuit thoroughly prior to connecting
the unit to the heating circuit...
NOTICE.
Contamination and deposits in the heating
circuit can cause malfunctions.

16 We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Condensate disCharge
The condensation water that accumulated from the air
must be drained via the pre-mounted hose in the unit for
condensate discharge. To do so, connect the hose for
condendate discharge with a water drain.
For positioning of the connection for conden-
sate discharge, see dimensional drawings for the
respective model.
1 Hose for condensate discharge
in interior of unit
2 Connection for the condensate
discharge on the outside of the unit
CAUTION!
Guide the pre-mounted hose in the unit
for condensate discharge in the interior of
the unit as a siphon, as shown in the illus-
tration.
Discharge of the condensate into the sewage system is
permitted only via a funnel siphon, which must be acces-
sible at all times.
Install shut-off devices for the hot water outow
(forward ow) and hot water inow (return ow)
on the heat pump side.
NOTICE.
During installation of the shut-off devices,
the liqueer of the heat pump can be
ushed, if necessary.
CAUTION!
The condenser may be ushed only by
customer service personnel authorised by
the manufacturer .
Connect the unit to the pipes of the heating cir-
cuit via vibration decouplers. They must be installed
in order to prevent damage from vibrations to the
pipes.
NOTICE.
Vibration decouplers are available as
accessories.
The connections for the heating water outow (forward
ow) and the hot water inow *(return ow) are marked
accordingly.
For positioining of the connections, reference
the dimensional drawing for the respective
model.

17
We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Circulating pumps
CAUTION.
Always note the model.
Do not use regulated circulating pumps.
Circulating pumps and domestic hot water
circulation pumps must be multi-stage
pumps.
Water heating
Water heating with the heat pump requires an additional
hot water circuit, parallel to the heating circuit. Make
sure that the heating water charge is not channelled
through the buffer tank of the heating circuit.
“Hydraulic connection” instructions.
Hot-water tank
If the heat pump is to be used for heating hot water, you
must integrate special hot-water tanks in the heat pump
system. The storage volume must be sufcient so that
the required hot water quantity is available even during
a power cut.
NOTICE.
The heat exchanger surface of the hot
water tank must be dimensioned so that
the heating capacity of the heat pump is
transferred with minimal spreading.
We offer a variety of hot-water tanks for you to choose
from. They are optimised for use with your heat pump.
NOTICE.
Integrate the hot-water tank in the heat
pump system according to the hydraulic
diagram for your system.
“Hydraulic connection” instructions.
Pressure relief
Equip the heating circuit in accordance with local stand-
ards and directives with a safety valve and an expansion
tank.
Also install lling and emptying devices, shut-off devices
and non-return valves in the heating circuit.
Overow valve
Always use an overow valve to ensure the minimum
ow rate of the heating circuit volume ow through the
heat pump. The overow valve must be dimensioned so
that the minimum ow rate of the volume ow through
the heat pump is ensured when the heating circuit is shut
off.
Buffer tank
The hydraulic connection of the heat pump requires a
buffer tank in the heating circuit. It ensures a minimum
operating time of the heat pump when the heating cir-
cuit valves are closed. The required volume of the buffer
tank is calculated based on the following formula:
VBuffer tank = minimum ow rate of heat circuit volume ow / hour
10
For the minimum ow rate of the heat circuit vol-
ume ow, see overview “Technical data / Scope
of delivery”, “Heating circuit” section.
In mono-energetic air/water systems, integrate the
buffer tank in the heating water outow (forward ow)
before the overow valve.

18 We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
•
Cut out the rubber sockets on the facing panel...
For positioning of the rubber sockets for insert-
ing the wires, see "dimensional drawing" for the
respective model.
•
Insert the cables through the rubber sockets in the
unit...
The wires inside the unit are guided in a closed wire
duct to the terminals on the switch plate.
Install electric connections according to the termi-
nal diagram that applies to your model...
Terminal diagram for respective model.
CAUTION.
Ensure clockwise rotary eld of the load
power supply (compressor).
– An incorrect rotary eld of the
compressor during operation can
cause serious, irreparable damage to
the compressor.
CAUTION.
Make sure to equip the power supply of
the heat pump with a 3-pole automatic
cut-out with at least 3 mm contact gap.
Note the level of the release current.
Overview “Technical data / scope of delivery”,
“Electric” section.
NOTICE.
Factory setting for the electric heating
element in units with integrated electic
heating elements is 6 kW (9 kW). It can
be changed at contactor for 2 (3) or 4 kW
(6kW).
For further information, see the adhesive label
on the electric heating element.
NOTICE.
Using a suitable network cable, the
control element of the heat and heat
pump regulator can be connected with
a computer or a network allowing the
heating and heat pump regulator to be
controlled from there.
Electrical connections
Observe the following when performing all work:
DANGER!
Danger of fatal injury due to electric
shock!
Electrical connections may be installed
only by qualied electricians.
Before opening the unit, disconnect the
system from the power supply and secure
it from being switched back on!
DANGER!
Observe the relevant EN-, VDE and/or
applicable local safety regulations during
installation and during all electrical work.
Comply with any technical connection re-
quirements laid down by the responsible
power supply company!
NOTICE.
All live wires must be stripped before they
are installed in the cable duct of the switch
cabinets!
power ConneCtion
If the unit is closed, open the facing panels on the
operating side...
"Installation".
Open electrical switch cabinet of unit...
Example of open
electrical switch cabinet...
Lead 230 V power cable, power cable for circulat-
ing pumps and cable for external temperature sen-
sor through the rubber sockets on the facing panel
in the unit...

19
We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Installation of the control
element
DANGER!
Danger of fatal injury due to electric
shock!
Electrical connections may be installed
only by qualied electricians.
Before opening the unit, disconnect the
system from the power supply and secure
it from being switched back on!
Situated at different heights in the front panel of the unit
are four-pin sockets for fastening the control element:
1 four upper recesses
2 four lower recesses
Four hooks are located on the back side of the control
element and can be used to hang the control element on
the front facade of the unit:
If such a connection is desired, lay a
category 6 screened network cable with
RJ-45 plug through the unit parallel to the
heating and heat pump regulator control
cable already present when making the
connections, and lead it through the front
panel of the unit.
Close electrical switch cabinet of unit....
Attach the lower facing panels.
Flushing, lling and bleeding
the system
Flush, ll and bleed the heating circuit...
In addition, bleed the condenser of the heat pump...
•
Open the lower facing panel...
•
Open the bleed valve...
Following bleeding, close the lower facing panel.
Insulating the hydraulic
connections
Insulate the vibration decouplers and the pipes of the
heating circuit.
NOTICE.
Insulate in accordance with applicable
local standards and directives.

20 We reserve the right to modify technical specifications without prior notice.
UK830304/190810 © Alpha-InnoTec GmbH
Proceed as follows:
Hang the control element's hooks on the recesses
of the front facade (either in the upper or lower
recesses)...
Example:
Control element in upper recesses
Push the control element down until it locks into
position...
Stick the heating and heat pump regulator's control
cable into the right bushing on the bottom of the
control element...
NOTICE.
A connection to a computer or a network
can be installed via the left bushing on the
bottom of the control element, allowing
the heating and heat pump regulator to be
controlled remotely. One pre-condition is
that a screened network cable (category
6) be installed through the unit when
installing the unit.
Operating manual for the heating and heat pump
regulator, version "Qualied technician", “Web
server” section.
If this network cable is available, insert
the network cable's RJ-45 plug into the left
bushing of the control element.
NOTICE.
The network cable can be exchanged at
any time. In order to be able to connect it,
the screen must rst be removed.
Installation and removal of the
screen
installing the sCreen
NOTICE.
The screen is provided at the time of
delivery so that the control element may
be inserted in the upper recesses of the
front facade.
If the control element has been inserted in
the lower recesses of the front facade, you
must rst remove the screen's temporary
cover and then reinsert it above the logo.
