Alpine KTX-GM8-K User manual

Mobile
Media
Solutions
Perfect
Fit For
Select
2007-2013
Chevrolet/
GMC
Truck
and
SUV Installation Manual
KTX-GM8-KIKTX-GM8W-KIKTX-GM8S-K
GM Trim Panel x 1
(Panel 7307) Left
Bracket
x 1
(Panel 7309) Right Bracket x 1
(Panel 7308) Spacers x
2
Extended Mounting
Screws
for
Factory
A/C
x4
Introduction
This KTX-GM8-K/KTX-GM8W-K/KTX-GM8S-K Perfect Fit installation kit is
for
Select 2007-2013
Chevrolet Truck/SUV's. Refer
to
the individual instruction sections
of
this manual to remove
your
vehicle's
factory
radio and assemble the kit.
Caution!
Disconnect
your
vehicle's
negative
battery
terminal
before
the
installation
to
help
prevent
electrical
damage.
We
recommend
the
use
of
a
digital
multimeter
to
check
vehicle
wiring.
Do
not
use
a
test
light!
A
test
light
or
grounded
wire
probe
can
cause
damage
to
the
vehicle's
computer
and/or
diagnostic
systems.
Avoid
all
factory
airbag
wiring.
Airbags
can
accidentally
deploy
causing
serious
injury
or
even
death.
Notes:
• See
your
vehicle's instructions
for
any special tools
your
installation
might
require.
• Read all instructions accompanying
your
car
stereo
for
proper
wiring and mounting
instructions.
Liability Disclaimer
Due
to
changes in design and manufacturing that may
occur
with
your
specific vehicle,
it
is
important
that
you
do
not
rely solely on vehicle information contained in this installation manual,
such as dash disassembly, wire harness, and codes. Such infonnation should be confirmed
with
the vehicle manufacturer. Alpine Electronics, Inc. and its affiliated companies is
not
responsible
for
damage
that
may
occur
to
you
or
your
automobile during the installation
of
the Perfect Fit Kit.
If you have any
further
questions, feel free
to
contact
Alpine Tech
Support
at
1-800-NAV-HELP.
ALPINE
ELECTRONICS
OF
AMERICA,
INC.,
19145
Gramercy Place, Torrance, CA
90501,
U.S.A
Do
not
send
products
to
this
address.
Call the toll free
number
or
visit the website to locate a service center.
1

Compatibility List
Chevrolet
Avalanche 2007-2012
Silverado 2007-2012**
Suburban 2007-2012
Tahoe 2007-2012
GMC
Sierra 2007-2012**
Yukon 2007-2012
Yukon XL 2007-2012
Factory Stereo Removal ·
1. Use a Panel Removal Tool
to
carefully unsnap
dash/stereo bezel. These clips snap in very
tight
so
be careful!
**Not
applicable
to
Fleet
trucks
or
Upper
-
dash
OEM
stereo loc
at
ions
,.,·
2.
Extract
(4)
9/32"-7mm
screws securing the
Factory
stereo,
disconnect
and remove. Extract
(4)
9/32"-7mm
screws
securing
the
Factory HVAC/Aux control
as-
sembly
and pull slightly away from dash.
Mounting The Stereo . .
1. Attach brackets 7309 and 7308
to
the
Al-
pine head
unit
using
the
supplied ISO
screws
(that
come
with
the
head unit).
2

Mounting
The
Stereo Continued
2.
Connect
and
mount
the stereo in the dash.
(Re-use the
Factory
OEM stereo hardware.)
4. Snap
the
7307 Perfect Fit bezel around
the
stereo and HVAC unit.
3.
Place spacers behind the
Factory
HVAC/
Aux
switch
control
assembly
and re-install
it
using the
longer
screws
provided in the
kit.
3

Mobile
Media
Solutions
~ERFECT
s
o
crJJ~N
s
KIT D' INSTALLATION PERFECT
FIT™
• •
KTX-GMSS-K
2007-2013
SELECT
GM
VEHICLES
INSTALLATION KIT

• PERFECT SHAPE AND COLOR MATCH TO OEM DASH FOR FACTORY FIT
•INCLUDES ALPINE-TO-VEHICLE HARNESS FOR PLUG-AND-PLAY INSTALLATION
• INCLUDES RETAINING CLIPS
• INSTRUCTION MANUALWITH STEP-BY-STEP INSTALLATION OF
ALL
COMPONENTS
• CORRESPONDANCE PARFAITE AVEC
LA
FORME ET COULEUR DU TABLEAU DE BORD
DE
L'EQUIPEMENTIER POUR
UN
ASPECT SORTIE D'USINE
• COMPREND UN HARNAIS POUR CONNECTER L'UNITE ALPINE
AU
VEHICULE POUR UNE INSTALLATION
PR~TE
A
L'EMPLOI
• COMPREND LES CLIPS DE MAINTIEN
• MANUEL D'INSTRUCTIONS DETAILLANT L'INSTALLATION PAS
A
PAS DE TOUS LES COMPOSANTS
Mobile
Media
Solutions

ALPINE ELECTRONICS OF AMERICA, INC.
www.alpine.com
DRIVING MOBILE MEDIA SOLUTIONS
KTX-GMSS-K
2007-2013
SELECT GM VEHICLES
INSTALLATION KIT
Mobile Media Solutions

Alpine, Alpine
Mobile
Media Solutions, Driving
Mobile
Media Solutions are registered trademarks
of
Alpine Electronics,
Inc.
Alpine, Alpine
Mobile
Media Solutions, Driving
Mobile
Media Solutions sont
des
marques deposees
d'Aipine
Electronics,
Inc.
MADE IN CHINA
FABRIOUE EN CHINE
