Alpinespas Gazebo User manual

Item No. Name Quantity
①bar table foot 2pcs
②bar table face 1pcs
③4pcs
4pcs
8pcs
tapping screw CT-M5*50
hexagon screw M8*50
Bar sideling board
Drawing①
①
②
①
hexagon screw M8*50
1.use M8*50 to connect bar table foot
and bar table face。
2.Link the sideling board between the
face and foot by screw CT-M5*50..
③
③
tapping screw CT-M5*50

Drawing②
The 4 corners can be employed universally.
The shutters and below blanking plate can be employed universally.

Drawing③
flange bolt M8*80
1.use screw M8*50 to connect connect bottom
and blind window。
2.use screw CT-M5*50 to connect bottom seal
plate and blind window。
3.use screw M8*50 to connect bar table and
corner。
4.Link the girde and conner by screw M8*50.
tapping screw CT-M5*50
Item No. Name Quantity
①corner 4pcs
②blind window 2pcs
③bottom seal plate 2pcs
④bar table 1pcs
⑤2pcs
40pcs
tapping screw CT-M5*50 12pcs
hexagon screw M8*50
beam
④
①②
③
⑤
hexagon screw M8*50
hexagon screw M8*50
flange nut M8*80
flange bolt M8*80

Drawing④
1.Link 4 PS 1.97M parts and tripods with
gazebo body by screw CT-M5*50.
tapping screw CT-M5*50
Big roof 8
Big roof 7

Drawing⑤
1.The left big roof:: Put the long and short crossband with left following
crossband A to the neck in the middle board and left backbone A. Them lock
them by screw CT-M5*50.
2.The right big roof: Put the long and short crossband with left following
crossband B to the neck in the middle board and left backbone B. Them lock
them by screw CT-M5*50.
3.Attention please when fit, after 3pcs crossband are put in the neck, you
should make flat the contact surface of backbone and middle board, and then
lock them by screw.
Keep the contact surface flat
The left crossband A
The left backbone A
The sink hole
is at the above
Screw CT-M5*50 The left big roof
A
The right big roof
The right backbone B
The sink hole
is at the above
The right following crossband B
B

Drawing⑥
1.Link two frames of big roof by
screw M8*90, then become four pairs
by eight frames.
2.Put two big roof on the gazebo
body.
Screw M8*90
Gazebo body
Big roof 8
Put the big roof on the gazebo,
then keep the level with gazebo body.

Drawing⑦
1.Put the orther 3 big roof on the
gazebo, then combine them by screw
M8*80 as picture.
2.Link the big roof with the frame on
the gazebo body.
3.Link the tripod with big roof by
screw CT-M5*60.
Screw CT-M5*60
Screw CT-M5*60
Screw M8*80
Put the big roof on the gazebo,
then keep the level with gazebo body.

Drawing⑧
1.Put the small frame on the big roof, then put the middle board to
the neck of the frame, lock them by screw CT-M5*50.
2.Please attention, the contact surface of the small frame and middle
board should be flat.
The neck location
keep the contact surface flat
big roof 6
Big roof 5
Big roof 4
Big roof 2
Big roof 3
Big roof 1
Screw CT-M5*50

Drawing⑨
1.Put the 90°hardware on the corner connection of
big roof, lock them by screw DB-M4*25.
2.Put the straight hardware on the middle
connection of big roof, lock them by screw big flat
screw DB-M4*25.
screw DB-M4*25
Straight hardware
90°hardware

Drawing⑩
1.The side of middle top roof should be keep
the level with the face of big roof.
2.The middle line of top roof should be at
the middle of big roof frame.
The right big roof
The left big roof
top roof
1,Put the middle top roof under the big roof as
the left installation at he left, then lock them
by screw DB-M4*25 and white shim as the
installation as the above.
2,Put the left and right triange top roof to the
middle one, then lock them on the big roof frame
by screw DB-M4*25.
3,Remark: when lock the big roof by screw, the
people can't stand on the top pf gazebo, should
be at side or inside of gazebo, then install the
orther three top roof on the frame.
big roof frame
top roof
70°
1.there is a row of screw hole,
you should keep straight to
the ground when installing,
then it should be 70°with the top roof.
90.0°
2.there is a row of screw hole,
you should keep 90°with top roof when installing.
white shim
screw DB-M4*25
left triangle top roof
right triangle top roof
left triangle top roof
middle top roof
Put the left triangle top
roof ti the middle one

Drawing⑾
1,Put the small roof on the gazebo top from the big roof frame, them put
the 151°hardware under big roof inside frame, lock them by screw
DB-M4*25.
2,Put 4pcs tillers to the big roof , lock them by screw DB-M4*50 abd white shim.
3,Remark: When install the screw of tiller, please install the screw in the middle
of the tiller.
Small roof
The inside frame of small roof
151°hardware
151°hardware at below of gazebo
Tiler
white shim
screw DB-M4*50
When top frame connected
with dovetail with iron wire
connection

Drawing⑿
Item No. Name Quantity
①short round bar
8pcs
②middle length
round board
4pcs
③
bar stool foot
8pcs
④
bar stool surface
2pcs
16pcs
32pcs
tapping screw CT-M4*25
long round bar
4pcs
⑤
the surface of pole key mapping should be
the same level with that of bar foot.
1.Put the short and long pole between the foot holes. The
location hole of long pole should be outside. the surface
of pole key mapping should be the same level with that of
bar foot,the location hole should be outside too.Then
lock them using screw CT-M4*25.
2.Splice two pair stool foot, connect them using the
middle and short poles,then lock them by CT-M4*25, the
location hole should be outside.The surface of pole key
mapping should be the same level with that of bar foot.
3.Put the foot frame on the surface, four corners of foot
stuck the four nuts, then join the foot and surface using
screw CT-M4*50.
long round bar
Do install the pole key
mapping with the middle
length between the middle
hole of bar foot.
Do install the pole key
mapping with the long length
between the under hole of bar foot.
tapping screw CT-M4*50
there are nuts in
the stool surface.
tapping screw CT-M4*50
the location nuts.
tapping screw CT-M4*25
the surface of pole key mapping should be
the same level with that of bar foot.
