Altigen MultiSite Configurator User manual

M ULTI S ITE C ONFIGURATOR
This document provides instructions on configuring and using the MultiSite Configurator
application to configure several distributed AltiServ systems from a single system.
Contents
ClientSystemRequirements.....................................................2
InstallationandSetup ..........................................................2
MapTable....................................................................3
MapTable.................................................................3
RemovingaServerfromtheMapTable..........................................4
SavingtheMapTable........................................................5
MultiSite Configurator Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
SitesDownload.............................................................6
Check/UncheckSelected......................................................7
Synchronize................................................................8
Map......................................................................9
Print.....................................................................10
MultiSiteConfiguratorFields.................................................10
Troubleshooting..............................................................10
Related Documentation
•AltiWare OE System Installation and Administration Manual

MultiSite Configurator 2
Client System Requirements
The client or server system must meet the following minimum requirements. For server system
requirements, refer to the AltiWare OE System Installation and Administration Manual.
• IBM/PC AT compatible system
• Intel 166 MHz Pentium
• Windows 2000, NT Server 4.0 (Server or Workstation) with Service Pack 6 (or higher)
•64MBDRAM
• SVGA Monitor (800 x 600) with 256 color display
• Keyboard and mouse
• ALL AltiWare OE 4.5 (or higher) Server installed in the LAN in which the application runs.
Overview
MultiSite Configurator is an application that allows you to configure multiple system
synchronously. MultiSite Configurator allows administrators to quickly structure and
simultaneously configure several AltiWares from a single system, or “home server” using call
routing for extensions and workgroups.
Home server refers to the concept of designating one server out of several distributed sites as the
main server, a single point of contact where users can accept calls and listen to voicemail through an
extension connected to the main server.
Installation and Setup
Before installing the MultiSite Configurator application onto your PC, please make sure that
AltiWare OE 4.5 (Build 18 or higher) has been installed on the LAN/VPN in which the MultiSite
Configurator application will run.
The MultiSite Configurator package consists of the following files:
•MSC_setup.exe - main executable
•MultiSite.pdf - the MultiSite Configurator user guide
To run MultiSite Configurator, download the MultiSite Configurator application from AltiGen’s
Dealer web site, then launch the MSC_setup.exe file. After installation, you can run the program by
going to Start>AltiGen MultiSite Configurator>AltiGen MultiSite Configurator. Upon initial
launch, the user must first create a Map table, which the Configurator uses to reference the servers
that are part of the synchronization.

MultiSite Configurator 3
Map Table
CreatingtheMapTable
To create the Map table:
1. Click the Map button in the main interface to open the Map Table Edit window.
Figure 1. Default Map Table Edit Window
2. Click Add to open the Add New Server dialog box (see Figure 2). Enter the Server Name and
the IP Address, then click OK.
Figure 2. Add New Server
3. The server name and IP address you enter appears in the Servers window.
4. One by one, continue adding all the server sites you want to download.
5. When you are finished adding the servers, click OK. The information is saved as *.map files
into the work directory of the application. For example, the file for a Server named AltiServ1
will be saved as ALTISERV1.map.

MultiSite Configurator 4
IMPORTANT! Extensions must have the same last name, first name and email name in the
two different servers in order for MultiSite Configurator to identify the extension. If names are
not consistent, MultiSite Configurator will not synchronize the extensions.
Note: If you want to run the program in another computer, all *.map files in the program file
directory should be copied together with the program file.
Figure 3. Modified Map Table Edit Window
Once two or more servers have been inserted and saved, the server that shows in theServerswindow
(see Figure 3) will also appear in the line “Routing information for calls and voicemails from
<server name> to the servers listed below:.” The remaining servers and their respective
information (name and IP address) appear in the fields below the routing information list.
6. For each server, the Mail Forwarding Suffix and Forward Access Code columns are empty,
so the user must input data directly into the fields.
•Mail Forwarding Suffix - insert the server’s IP address or postfix (information thatfollows
the character “@” in the email address), e.g. “altigen.com” into the field. Do not include the
“@” character, e.g. “@altigen.com.”
•Forward Access Code - insert the server’s forward access code for trunk access. For IP
trunks, insert trunk access code + system ID, such as 81.
7. When finished, click OK.
Removing a Server from the Map Table
To delete a server from the map table, select the server in the server list and select Remove.This
removes not only the server information, but also the relative entries in other servers corresponding
to the removed server.

MultiSite Configurator 5
Saving the Map Table
Selecting the OK button will save the map table into *.map files. When running MultiSite
Configurator again, the map files will be ready to create the map table automatically. The program
only reads the map files from the current directory or the work directory.
MultiSite Configurator Screen
Once you execute the MultiSite Configurator, the main interface (see Figure 4) is displayed and can
be operated by using the mouse. The extension numbers and accompanying fields will be listed after
combining all servers.
Figure 4. Main Interface
The main commands located at the top of the screen are as follows:

MultiSite Configurator 6
Sites Download
BEFORE using the Sites Download feature, please configure the map table to first identify which
servers will be included in the synchronize. (See “Map Table” on page 3.)
When the Sites Download button is selected, the Select Servers (see Figure 5) dialog box opens.
Figure 5. Select Servers to Synchronize dialog box
If no servers are mapped in the map table, no server items will be shown in the Name field.
1. To begin downloading extension information, select two or more servers to search and type in
the Password assigned to each server. Highlight the desired servers by clicking on the name and
the CTRL button (or Shift button) at the same time.
2. Click Save password to save the password of the server.
Click Automatically download again after synchronized to download data again from the
servers after synchronization.
Click OK to initiate the download.
3. The Configurator downloads all the extension information of the selected servers, the
synchronization status and home server for each extension (see Figure 6). The status field
message at the bottom will show “Ready for synchronization.”

MultiSite Configurator 7
Figure 6. Ready for Synchronization
Note: If XXXXXX appears in the First Name/Last Name fields of an extension, this means the
name assigned to that extension doesn’t match in all servers.
If a Site name changes to blank, this also means the name assigned to that extension doesn’t
match in all servers.
Check/Uncheck Selected
After combining all extension information, the synchronization status of each extension will be
shown in the extension list. The check box preceding every extension represents the current state of
that extension, which can be one of the four states as follows:
- the extension is not synchronized; it can be synchronized.
- the extension has been checked; it has not been synchronized.
- the extension cannot/need not be synchronized.
- the extension has been synchronized in this session of MultiSite Configurator. Once
MultiSite Configurator is restarted, the icon changes to the third icon. If the Auto
Download option is checked, extensions in this state will change to “the extension cannot/
need not be synchronized.”
You can check or uncheck the desired extensions to be synchronized. The Check/UncheckSelected
button only affects selected extensions, and will check /uncheck boxes for previously selected
extensions.

MultiSite Configurator 8
The Check/Uncheck Selected button is grayed out if you are not connected to any servers.
Note: If the configurator cannot determine the home server of the extension, it will show
“Unknown” in the HOME column and display the third check box icon.
To change the home server of the extension, the user can click the HOME field of the
selected extension to view and select a HOME server from the list. If the selected server acts
as the Home server, the check box icon will then change to the first one (the extension is not
synchronized; it can be synchronized).
Synchronize
When Synchronize button is selected, the extension numbers that have been checked will be
synchronized. The results of the synchronization are shown in the bottom field of the MultiSite
Configurator screen.
Figure 7. Select Servers

MultiSite Configurator 9
Synchronization Rules
Use the following table of rules as guidelines for synchronizing your extensions.
Figure 8. Synchronization Rules Table
Map
When the Map button is selected, the Map Table Edit screen appears. The Map Table should
display the information inputted during setup. If the Map Table has not been created, please follow
the step listed for “Map Table” on page 3.
Changing the Map Table
The user can modify the map information (Mail Forwarding Suffix and Forward Access Code) by
directly accessing the appropriate fields and retyping the new information.
Click the OK button to keep the changes for the next configuration and synchronization.
Physical/IP
Extension Virtual Extension Workgroup No Extension
Physical/IP
Extension
!"!"
Virtual Extension ""*""
Workgroup !"!"
No Extension """N/A
Ext in Server 1
!= can’t sync "= can sync "* = need to specify Home Server
Ext in Server 2

MultiSite Configurator 10
Print
Selecting the Print button prints the extension information in the extension list, including extension
number, name, email, synchronization status and HOME server name.
Note: Before printing, make sure A4 sized paper is available in your printer.
Help
Selecting the Help button opens the MultiSite Configurator Help file.
MultiSite Configurator Fields
The following, self-explanatory fields are displayed below the main toolbar commands:
•Ext.No
•Type - either “Extension” or “Workgroup”
•First Name
•Last Name
•Email Name
•Sync. Status - either “Synchronized” or “Unsynchronized”
•Home Server
NOTE!
Editing the Home Server field
The Home Server field cannot be modified in the Map Table Edit window. To edit the Home
Server field, go directly to the extension through the main screen, and right-click and select
context menu in the HOME SERVER field for that extension to open a drop-down list of
servers.
•#ofPhysicalExt
Troubleshooting
Use this table for troubleshooting error messages encountered while running MultiSite Configurator.
Error Message Solution
Map Table Warning: Mail Forwarding Suffix
from Server XXX to Server XXX is invalid! Confirm the Mail Forwarding Suffix between servers are the same.
Map Table Warning: Forward Access Code from
server XXX to XXX is invalid! Confirm the Forward Access Code between servers are the same.
