D U E T O O N G O N G P R O D U C T M P R O V E M E N T,S P E C F C AT O N S A R E S U B J E C T T O C H A N G E W T H O U T N O T C E .P R N T E D N U .S.A. #424 - 05/07
ITEM NO. _______________________
COMBITHERM®
●Cook by internal product temperature or time with temperature variable
steam, convection heat, or a combination of both to roast, steam, bake, or
oven-fry in a single piece of equipment.
●Provides increased food quality and expands menu options while
increasing production efficiency and speed by as much as 70-percent
compared to conventional cooking methods.
●EcoSmart™technology reduces energy cost by using less electricity
and water during both normal operation and the cleaning function.
●Gold-n-Brown™ feature provides the operator with the ability to add
additional product color.
●AutoClean™ feature simplifies the cleaning process to a single
oven function.
●Standard and Deluxe control offers 2-speed fan, a cool-down feature,
additional moisture injection, Delta-T cooking, multiple language
display, and other control features.
●Enhanced safety feature includes automatic steam venting
immediately before cooking time expires. PATENT PEND NG
610ES
ELECTRIC COMBINATION OVEN/STEAMER
W164 N9221 Water Street • P.O. Box 450 • enomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FAX: [phone].329.8744 U.S.A.ONLY
WEBSITE: www.alto-shaam.com
®
MODEL 6•10ES DELU E
CAPACITY OF SI (6) FULL-SIZE OR GN 1/1 PANS,
SI (6) HALF-SIZE SHEET PANS
SHOWN WITH OPTIONAL MOBILE STAND 5006188
ANSI/NSF 4
ODELS:
■■6•10ES: STANDARD
■■6•10ES: DELUXE
■■6•10ES: S-CONTROL
SHORT FOR SPECIFICATIONS:
Provide Alto-Shaam Combitherm®Model 6•10ES combination oven/steamer designed with EcoSmart™ technology for reduced energy
and water usage and include operational modes for steam, convection, and a combination of steam and convection heat. Standard
features to include patented, automatic steam venting; Gold-n-Brown™ browning function; and a self-adjusting, flush-mounted rotary
door handle with a steam venting safety stop. Control to include 2-speed fan, cool-down function, and automatic decalcification
program. Oven cavity is to be constructed of 18 gauge stainless steel, include an attached spray hose with backflow preventer, and
automatic cleaning function. The oven is to accommodate up to 6 half-size sheet pans or 6 full-size hotel pans, include a removable door
gasket for easy replacement, and standard right-hand door hinging.
STANDARD CONTROL: To include removable quick-connect internal product temperature probe in the oven interior.
DELUXE CONTROL: To include removable quick-connect internal product temperature probe in the oven interior
and programming capability with Rapid-Touch™ operational quick-keys.
S-CONTROL: To include removable quick-connect internal product temperature probe in the oven interior as an option.
STANDARD FEATURES AND ACCESSORIES
• Three (3) stainless steel shelves
• Two (2) stainless steel side racks with
Six (6) non-tilt pan support rails
21-1/16" (535mm) horizontal width between rails
2-5/8" (65mm) vertical spacing between rails
• Four (4) adjustable legs
• One (1) hand-held shower with backflow preventer PATENT PEND NG
• One (1) flush-mounted rotary door latch with steam venting position
• Single-point detachable temperature probe
(OPT ONAL ON S-CONTROL MODELS)

#424 - 05/07 D U E T O O N G O N G P R O D U C T M P R O V E M E N T, S P E C F C A T O N S A R E S U B J E C T T O C H A N G E W T H O U T N O T C E .WEBS TE: www.alto-shaam.com
ELECTRIC COMBINATION OVEN/STEAMER 610ES
C A PA C I T Y
FULL-S ZE PANS: 20" x 12" x 2-1/2" Six (6)
GN 1/1: 530 x 325 x 65mm Six (6)
HALF-S ZE SHEET PANS:* 18" x 13" x 1" Six (6)
ON WIRE SHELVES ONLY
72 lb (33 kg) MAX MUM
VOLUME MAX MUM: 45 QUARTS (57 L TERS)
C L E A R A N C E R E Q U I R E M E N T S
LEFT: 6" (152mm) PLUS SERVICE ACCESS: 18" (457mm) RECOMMENDED
20" (508mm) F R O M H E AT P R O D U C I N G E Q U I P M E N T
RIG H T : 4" (102mm)
BA C K : 4" (102mm)
COUNTER-TOP NSTALLAT ONS MUST MA NTA N 4" (102mm) M N MUM CLEARANCE FROM THE COUNTER SURFACE.
WEIGHT
NET 285 lb EST. (129 kg) EST.
SHIP 415 lb EST. (188 kg) EST.
CRATE 40" X48" X40" EST.
DI ENSIONS:(1016 x 1219 x 1016mm)
E L E C T R I C A L
VOLTAGE PHASE CYCLE/HZ AWG A PS kW
at 208 1* 50/60 2 Wire plus ground 40.5 8.4
at 240 AWG 6 47.0 11.2
at 208 3 50/60 3 Wire plus ground 23.5/ph 8.4
at 240 AWG 8 27.0/ph 11.2
at 380 3 50/60 4 Wire plus ground 13.0/ph 8.4
at 415 AWG 12 16.0/ph 11.2
at 440 3* 50/60 3 Wire plus ground 24.0/ph 10.8
at 480 AWG 8 26.0/ph 12.7
* ELECTRICAL SERVICE CHARGE APPLIES
WAT E R R E Q U I R E M E N T S
TWO (2) COLD WATER INLETS - DRINKING QUALITY
ONE (1) TREATED WATER INLET: 3/4" NPT
ONE (1) UNTREATED WATER INLET: 3/4" NPT
LINE PRESSURE:30 to 90 psi
2.8 to 6.2 bar
REFER TO PUBL SHED SPEC F C WATER REQU REMENTS
WATER DRAIN: 1-1/4" NPT WITH AIR GAP
I N S TA L L AT I O N R E Q U I R E M E N T S
Oven must be installed level.
Hood installation is required.
Water supply shut-off valve and back-flow preventer.
208-240 208-240
380-415
440-480
®
31-3/8" (796mm)
34-1/16" (864mm)
17-15/16"
(456mm)
7-9/16"
(191mm)
WATER
DRAIN
33-1/8" (840mm) 4-15/16"
(125mm)
Steam Vent (Top)
60-9/16" (1538mm)
Water Drain
(Side Back)
Treated Water
Intake (Bottom)
Untreated Water
Intake (Bottom)
Electrical Connection
(Bottom)
30" (761mm)
4-3/4" (120mm)
3-3/16" (80mm)
11-15/16"
(303mm)
6-3/8" (161mm)
41-15/16" (1064mm)
43-7/8" (1114mm)
2" (50mm)
49-1/8" (1247mm)
21-3/4"
(551mm)
14-3/4"
(373mm)
35-3/16" (893mm)
27-11/16"
(702mm)
7-9/16"
(192mm)
Decalcification
Port
D I M E N S I O N S : H x W x D
EXTERIOR:
35-3/16" x 43-7/8" x 34-1/16" (893mm x 1114mm x 864mm)
EXTERIOR WITH RETRACTABLE DOOR:
35-3/16" x 47-7/8" x 34-1/16" (893mm x 1216mm x 864mm)
INTERIOR:
17-3/4" x 23-1/2" x 21-1/16" (450mm x 597mm x 535mm)
TOP: 20" (508mm) FOR A R MOVEMENT
BOTTO : 5-1/8" (130mm) FOR LEGS
*ADD T ONAL W RE SHELVES REQU RED FOR MAX MUM CAPAC TY

#424 - 05/07 D U E T O O N G O N G P R O D U C T M P R O V E M E N T, S P E C F C A T O N S A R E S U B J E C T T O C H A N G E W T H O U T N O T C E .WEBS TE: www.alto-shaam.com
S - C o n t ro l
The Combitherm S-Control
includes all basic combination oven
operational modes with the use of
rotary dials. The S-Control also
features the Gold-n-Brown™
automatic browning function, an
automatic cleaning setting, an oven
cool-down function, and a half-
speed fan position. S-Control
models can also be furnished with a
Core Temperature option package.
S t a n d a rd C o n t ro l
The Combitherm standard control
includes all operational functions
shown to steam, bake, and roast by
time or internal product temperature.
The control features the Gold-n-
Brown™automatic browning
function, a Retherm Mode for plate
regeneration, plus a wide variety of
auxiliary functions and operational
settings. This control is offered for
operators that do not require
programming capability.
D e l u x e C o n t r o l
(PICTURED)
The Combitherm deluxe control
includes all the operational functions
of the standard control and adds a
programming function. Program
memory can accept up to 250
procedures, each with up to 20 steps
in any combination of cooking
modes. The deluxe control also
features a set of 8 Rapid-Touch™
keys to assign frequently used
programs to cook at the touch of a
single button.
Steam Mode
A
utomatic steaming at 212°F (100°C)
Quick steaming between 213°F and
248°F (101°C and 120°C)
Low temp steaming between 86°F and
211°F (30°C and 99°C)
Combination Mode
Steam and convection cooking with a
temperature range of 212°F to 482°F
(100°C to 250°C)
Convection Mode
Cooking without steam at a
temperature range of 86°F to 482°F
(30°C to 250°C)
Retherm Mode
Food or plated meal reheating with
automatic steam injection at a
temperature range of 248°F to 320°F
(120°C to 160°C)
Core Temperature Mode
Cooking by sensing internal
product temperature in any
selected cooking mode
Gold-n-Brown
™
An automatic browning function
to be set or programmed as needed
to add additional product color in
the combination or convection mode
of operation.
®
610ES
ELECTRIC COMBINATION OVEN/STEAMER

#424 - 05/07 D U E T O O N G O N G P R O D U C T M P R O V E M E N T, S P E C F C A T O N S A R E S U B J E C T T O C H A N G E W T H O U T N O T C E .WEBS TE: www.alto-shaam.com
®
610ES
ELECTRIC COMBINATION OVEN/STEAMER
FA C T O RY I N S TA L L E D O P T I O N S
(MAY REQU RE ADD T ONAL LEAD T ME)
■■ Recessed Door [5005695]
NCREASES OVEN W DTH BY 4" (102mm)
■■ Left-Hand Door Swing [5005696]
Single-point removable temperature probe (PATENT PEND NG)
NCLUDED ON STANDARD AND DELUXE OVENS
■■ OPT ONAL ON S-CONTROL OVENS [5005679]
■■ Multi-point, ard-wired internal product temperature probe [5005678]
■■ Security Devices [5005680]
FOR CORRECT ONAL FAC L TY USE
NCLUDES CONTROL SECUR TY PANEL, DOOR LOCK, TAMPER-PROOF SCREW PACKAGE,
FLANGED LEGS FOR FLOOR OR COUNTER BOLT NG (PADLOCKS NOT NCLUDED)
■■ Ventless Hood VHES-10 [5005690]
NOT AVA LABLE ON STACKED CONF GURAT ONS
■■ Stacking Combinations
MUST BE SPEC F ED AT T ME OF ORDER
SEE ND V DUAL STACK NG COMB NAT ON SPEC F CAT ONS SHEETS
■■6•10ES OVER 6•10ES, STAT ONARY
■■6•10ESiOVER 6•10ES, STAT ONARY
■■6•10ES OVER 10•10ES, STAT ONARY
■■6•10ESiOVER 10•10ES, STAT ONARY
■■6•10ES OVER 7•14ES, STAT ONARY
■■6•10ESiOVER 7•14ES, STAT ONARY
■■6•10ES OVER 10•18ES, STAT ONARY
■■6•10ESiOVER 10•18ES, STAT ONARY
■■ADD T ONAL MOB LE STACK NG STAND
■■ Computer Software Options [5005676]
Not available on S-Control Models.
REFER TO HACCP SPEC F CAT ON SHEET #9015
FOR APPL CABLE PART NUMBERS
■■ HACCP Documentation
■■ HACCP Documentation wit Kitc en Management
■■ Wireless HACCP Documentation wit Kitc en Management
IEEE 802.11b STANDARDS

Six (6) Chicken Roasting Rack
(PAN NOT NCLUDED)SH-23000
Fry Basket BS-26730 Grilling Grate SH-26731
Stationary Stand with Shelf & Skirt
5006186
Mobile Stand with Shelf & Skirt
5006190
®
610ES
ELECTRIC COMBINATION OVEN/STEAMER
#424 - 05/07 D U E T O O N G O N G P R O D U C T M P R O V E M E N T, S P E C F C A T O N S A R E S U B J E C T T O C H A N G E W T H O U T N O T C E .WEBS TE: www.alto-shaam.com
Stationary Stand with Shelf
5006184
Mobile Stand with Shelf
5006188
Stationary Stand with Pan Slides & Shelf
5006185
Mobile Stand with Pan Slides & Shelf
5006189

OPTIONS & ACCESSORIES
■■CHICKEN GREASE TRAY W TH DRA N: 1-1/2" (38mm) DEEP 4757
CHICKEN ROASTING RACKS:
■■6CH CKEN CAPAC TY — F TS FULL-S ZE PAN: 2 RACKS PER OVEN SH-23000
■■8CH CKEN CAPAC TY — F TS FULL-S ZE PAN: 2 RACKS PER OVEN SH-23619
■■CO BIGUARD™ TRIPLE-GUARD WATER FILTRATION SYSTE (NCLUDES 1 CARTR DGE) F -23014
■
■CO BIGUARD™REPLACE ENT FILTER F -26356
■■FRY BASKET, 12" X20" (325mm x 530mm) BS-26730
■■GRILLING GRATE, 12" X20" (325mm x 530mm) SH-26731
■■OVEN CLEANER — SPEC ALLY FORMULATED FOR COMB THERM OVENS
➥TWELVE (12) CONTA NERS/CASE, 1 QUART (C. 1 L TER) EACH CE-24750
■■RACK ANAGE ENT TROLLEY SYSTE CONTACT FACTORY
NCLUDES RACK-TRACK ASSEMBLY, SL DE-N-PAN RACK ASSEMBLY, AND TROLLEY BASE ASSEMBLY
■■SCALE FREE™(C TRUS BASED, NON-CORROS VE DEL M NG PRODUCT) CE-27889
■■SERVICE START-UP CHECK AVAILABLE THROUGH AN ALTO-SHAA FASTEA CENTER SPEC FY AS REQU RED
■■SHELF, STAINLESS STEEL WIRE SH-2903
STAND, STAINLESS STEEL (HXWXD):
■■➥STAT ONARY W TH SHELF (*REQU RED FOR RACK MANAGEMENT)
28-15/16" X35-7/16" X20-5/16" (735mm x 900mm x 516mm) 5006184
■■➥STAT ONARY W TH PAN SL DES & SHELF (*REQU RED FOR RACK MANAGEMENT)
28-15/16" X35-7/16" X20-5/16" (735mm x 900mm x 516mm 5006185
■■➥STAT ONARY W TH SHELF & SK RT (*REQU RED FOR RACK MANAGEMENT)
28-15/16" X35-7/16" X20-5/16" (735mm x 900mm x 516mm 5006186
■■➥STAT ONARY W TH PAN SL DES, SHELF, & SK RT (*REQU RED FOR RACK MANAGEMENT)
28-15/16" X35-7/16" X20-5/16" (735mm x 900mm x 516mm 5006187
■■➥MOB LE W TH SHELF
33-7/8" X35-7/16" X20-5/16" (859mm x 900mm x 516mm) 5006188
■■➥MOB LE W TH PAN SL DES & SHELF
33-7/8" X35-7/16" X20-5/16" (859mm x 900mm x 516mm) 5006189
■■➥MOB LE W TH SHELF & SK RT
33-7/8" X35-7/16" X20-5/16" (859mm x 900mm x 516mm) 5006190
■■➥MOB LE W TH PAN SL DES, SHELF, & SK RT
33-7/8" X35-7/16" X20-5/16" (859mm x 900mm x 516mm) 5006191
■■➥STAT ONARY 38-1/4" X35-7/16" X20-5/16" (971mm x 900mm x 515mm) 5006181
®
610ES
ELECTRIC COMBINATION OVEN/STEAMER
D U E T O O N G O N G P R O D U C T M P R O V E M E N T, S P E C F C AT O N S A R E S U B J E C T T O C H A N G E W T H O U T N O T C E .P R N T E D N U .S.A. #424 - 05/07
W164 N9221 Water Street • P.O. Box 450 • enomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FAX: [phone].329.8744 U.S.A. ONLY
WEBSITE: www.alto-shaam.com
®
