Alto alpha COMP User manual

Service Manual
www.altoproaudio.com
Version: 1.1
Model: αCOMP
24x32 Bit Digital Compressor Module

CONTENTS
1. Specification
2. Block Diagram
3. Schematic Diagram
4. Printed Circuit Board
5. Wiring Diagram
6. Test Procedure
7. Electrical Parts List
8. Exploded Views & Mechanical Parts List
9. Notes

1. SPECIFICATION (aCOMP)
Electrical
Frequency Response: +0.5 / -1.5 dB from 20Hz to 20 kHz
S/N Ratio (process) 80 dB "A" wtg, 20 Hz-22kHz
S/N Ratio (bypass) >90 dB "A" wtg, 20 Hz-22kHz
THD+Noise: <0.008% @ 1kHz (0dBV, bypass)
Input
Number of Channels: 2
Format: 1/4" unbalanced
Maximum Level (bypass): +9 dBu
Impedance: >500 Kohms
A/D - D/A Conversions
A/D converter: 1 bit Sigma-Delta
D/A converter: 1 bit Sigma-Delta
Output
Number of Channels: 2
Format: 1/4" unbalanced
Maximum Level (bypass): +9 dBu
Output Impedance: <500 ohms
Front Panel
Controls Input/Output Levels (ANALOG)
PROGRAM selections (2 knobs)
Indicators Power, Signal clip LED
Rear Panel
IN/OUT levels (ANALOG) 1/4" 2-conductor (mono)
Output (LEFT, RIGHT) 1/4" 2-conductor (mono)
BYPASS 1/4" 2-conductor (auto-sense pedal type)
for momentary footswitches
Power 9 Volt AC Power Transformer
Processing and Memory
Processor Speed: 12 MIPs (million instructions per second)
Internal DSP resolution: 52 bit MPY accumulator
Main Preset Programs 16
Preset Total Combinations 256
Internal digital audio memory: 3000 milliseconds
Physical
Net Weight: 1kg(2.20lb)
Dimension(WxDxH): 200(mm) 150(mm) 45(mm)
(7.87" x 5.91"x 1.77")

1234
A B C D
4
321
D
C B A
POWERSUPPLY
VOLTAGEREGULATOR
AC9V INPUT
+5V
-5V
alphaverb BLOCK DIAGRAM
MEMORY (DRAM)
( U10,U11 )
DSP
ED0-ED7
( U8 TMS57002DPHA) EA0-EA9
AD0-AD7
MPU
( U9 P87C54UBAA)
PROGRAM
ENCODER A
SO0SI0
OUTPUT R OUTPUT L
FOOT
SWITCH
INPUTR INPUTL
PJ1 PJ2 PJ5
PJ3 PJ4
VARIATIONS ENCODER B
STEREOAUDIOCODEC
( U6 PCM3001E)
A/Dand D/A CONVERTER
Q1
11.0592MHZ
CLOCK DIVIDE ( U7 74HC393)
11.0592MHZ
FOOTSWITCH
CONTROL
(MONO INPUT)
INPUTBUFFER& AMPLIFIER
IN-R IN-L OUT-R OUT-L
INPUT LEVEL INPUT LEVEL
OUTPUTAMPLIFIER
OUTPUT LEVEL OUTPUT LEVEL
MIX CONTROL
LRCKIN=43.20KHZ BCK=1.382MHZ
2. Block Diagram

1 2 3 4 5 6 78
A B C D
8
7654321
D
C B A
Title
Number RevisionSize
A3
Date: 8-Jan-2002 Sheet of File: D:\shung\PC27\ALTO\Digital\AlfaVerb\SCHPCB\alphaverb.ddbDrawn By:
SYPOL 1
BCK0 2
NC 3 NC 4
LRCK0 5
S00 6 S01 7
CAS 8 RAS 9
CLKSEL 10
CLKIN 11
VSS 12 VSS 13
WE 14
ED7 15 ED6 16 ED5 17 ED4 18 ED3 19 ED2 20 ED1 23
NC 21 NC 22
ED0 24
EA0
25 EA1
26 NC
27 EA2
28 NC
29 EA3
30 EA4
31 VSS
32 VCC
33 EA5
34 EA6
35 NC
36 EA7
37 TEST0
38 TEST1
39 TEST2
40
EA8
41 EA9 42 NC 43 NC 44 D0 45 D1 46 D2 47 D3 48 NC 49 D4 50 D5 51 VCC 52 VCC 53 D6 54 D7 55 PC0 56 BIO 57 OVFA 58 OVFM 59 RS 60 NC 61 NC 62 EMPTY 63 MUTE 64
CS 65
R/W 66
PLOAD 67
DREADY 68
CLOAD 69
STRB 70
NC 71
VCC 72
VSS 73
NC 74
BCKI 75
LRCKI 76
NC 77
SI0 78
SI1 79
SYNC 80
U7
TMS57002
P 1.0 2
P 1.1 3
P 1.2 4
P 1.3 5
P 1.4 6
P 1.5 7
P 1.6 8
P 1.7 9
P2.0/A8 24 P2.1/A9 25
P2.2/A10 26 P2.3/A11 27 P2.4/A12 28 P2.5/A13 29 P2.6/A14 30 P2.7/A15 31
P0.7/AD7
36 P0.6/AD6 37 P0.5/AD5 38 P0.4/AD4 39 P0.3/AD3 40 P0.2/AD2 41 P0.1/AD1 42 P0.0/AD0 43
RXD/P3.0
11 TXD/P3.1
13 INT0/P3.2
14
INT1/P3.3
15 T0/P3.4
16
T1/P3.5
17 WR/P3.6
18 RD/P3.7
19
NC 1
NC
12
NC 23 NC 34
RST 10
EA/VPP 35
VSS 22
VDD
44
ALE
33 PSEN
32
XTAL1
21 XTAL2 20
U8
P87C54UBAA OVM
BIO AD7
AD6 AD0 AD1 AD2 AD3 AD4 AD5
VINL
1VCC1 2AGND1 3
VREFL
4VREFR 5
VINR
6CINPR 7CINNR 8CINLN 9CINPL
10
VCOM
11 VOUTR 12
AGND2
13 VCC2 14 VOUTL 15
LRCIN 16 BCKIN 17
DIN 18
DOUT 19
XTI 20
XTO 21
CLKIO 22
VDD 23
DGND 24
FMT2 25 FMT1 26 FMT0 27 RSTB 28
U5
PCM3001E
I/00
1I/01 2
WE
3RAS 4A9 5
A0
9
A1
10 A2 11 A3 12 +5V 13 A4 14
A5 15 A6 16 A7 17 A8 18
OE 22
CAS 23
I/02 24 I/03 25
DGND 26
U9
GM71C4256BJ60 I/00
1I/01 2
WE
3RAS 4A9 5
A0
9
A1
10 A2 11 A3 12 +5V 13 A4 14
A5 15 A6 16 A7 17 A8 18
OE 22
CAS 23
I/02 24 I/03 25
DGND 26
U10
GM71C4256BJ60
5 6
U11C
74HC04D
89
U11D
74HC04D
10 11
U11E
74HC04D
12 13
U11F
74HC04D DGND
JP2
2P-2.5
D4
1N4148 R24
100K
C27
47uF/25V
DGND
C39
100nF
C40
100nF
C41
100nF
R25 4K7 R26 4K7 R27 4K7 R28 4K7
DGND
12
U11A
74HC04D
CLK 1
Q0
3Q1 4Q2 5Q3 6MR 2
U6A
74HC393D
CLK
13 Q0 11
Q1 10 Q2 9 Q3 8
MR
12
U6B
74HC393D
DGND
DGND
DGND
SO0 SO1
BCK
LRCKIN
INPUTL
INPUTR
C38 10uF
C37
10uF
C34
10uF
C36 470P
C35
470P
AGND C30
1uF C31
1uF
R30
100K R29
100K
AGND
OUTPUTLOUTPUTR
LRCKIN
BCK SO0
SI0
RS-CODEC
DGND Q1
11.0592MHz
C33
22P
C32 22P
DGNDDGND
ED0
ED2 ED3 ED4
ED5 ED6
ED7
ED1
DGND
3 4
U11B
74HC04D
DGND
EA0 EA1 EA2 EA3 EA4
EA5 EA6 EA7 EA8
EA9 EA0 EA1 EA2 EA3 EA4
EA5 EA6 EA7 EA8
EA9
LRCKIN
AD0 AD1 AD2 AD3 AD4 AD5 AD6 AD7
EA0
EA1
EA2
EA3
EA4
EA5
EA6
EA7
ED0 ED1 ED2 ED3 ED4 ED5 ED6 ED7
A15
SI0
SI1
+5V
+5V
+5V
1 2 3 4 5 6
ENCA
288S0121
D3 D0 D1 D2
COM COM
DGND
1 2 3 4 5 6
ENCB
288S0121
D3 D0 D1 D2
COM COM
ENCODERB4 ENCODERB1 ENCODERB2 ENCODERB3
ENCODERA1 ENCODERA2 ENCODERA3 ENCODERA4
C42
100nF
C43
100nF
C44
100nF
R32 4K7 R33 4K7 R34 4K7 R35 4K7
+5V
DGND
R31
100R
+5V
+5V
RS-CODEC
+5V
+5V
C28
100nF
C29 1uF
DGND DGND
INPUTR INPUTL OUTPUTR OUTPUTL
Analog Stage & Power supply
a-verbIO.SCH
147
U6C
74HC393D
147
U11G
74HC04D
+5V +5V
DGNDDGND
EA8 EA9
+5V
C99
100nF
C98
100nF
DGND DGND
C97
100nF C96
100nF
DGNDDGND
2 1 3
22 11 33
PJ5
LJB0661-6
FSP
R2
10K R3
1K
C7
100nF
+5V
DGND
Footswitch live
AGND2
R1
220R
DL1 RED
OVM
(OVER-LOAD)
R44
470R
+VCC
DL2
RED
(PWR ON)
DGND
INPUTR
INPUTL
OUTPUTR
OUTPUTL
C95 100nF DGND
C45 82P
DGND
SO0
Footswitch live
(AlphaComp:P87C52UBAA)
LINK LINK.SCH
WE
WE
BCKI
RST
F11.0592M
STRB CLOAD PLOAD
MUTE EMPTY
CLK-Q3
VOUTR
CAS
VOUTL
1/4W
+5V
+5V
R36 10K
R37 10K
DGND
R40 0R0 R39 0R0 R38 0R0
+5V
KEVIN LIN.
2002/01/06
L9
BLM21A102
R18
100R DGND
R17 4K7
DGND
A-VERBMAIN.SCH
MODEL:ALTO AlphaVERB
RS
3. Schematic Diagram

1 2 3 4
A B C D
4
321
D
C B ATitle
Number RevisionSize
A4
Date: 8-Jan-2002 Sheet of File: D:\shung\PC27\ALTO\Digital\AlfaVerb\SCHPCB\alphaverb.ddbDrawn By:
AlphaVerb Analog Stage/Power Supply (Included AlphaComp)
2 1 3 22 11 33
PJ1
LJB0661-6 L4
LF22uH VR1A
A10K
C12
47uF/25V
AGNDAGND2
3 21
U1A
TL074CD
C8
47uF/25V
R7 1K C13
47uF/25V
INPUTR
12 13 14
U1D
TL074CD
R6
2K2
R4 1K
AGND
10
98
U4C
TL074CD
R5
1M
OUTPUTR
VR2A
B1K
VR3A
A10K
AGND
R20
270R
3 21
U4A
TL074CD
R11 4K7
C23
680P
AGND
L1
LF22uH
2 1 3
22 11 33
PJ3
LJB0661-6
AGND2
R-OUT
OUTPUT-A
MIXER-A
INTPUT-A
R-INPUT
AGND
L-OUT
L-INPUT
411
U4E
TL074CD
411
U1E
TL074CD
-5V -5V
+5VA +5VA
J1 1
3
4 5 62
SW1
PWR SW
C10
2200uF/25V
C11
220uF/25V
U2 LM7805
U3 LM79L05
C4
100uF/25V C6
10uF/16V
C3
100uF/25V C5
10uF/16V L2
LF22uH
L3
330uH -5VSGND
SGND
SGND SGND SGND SGND
SGNDSGNDSGND
D2
IN4002
D3
IN4002
AC 9V INPUT
C9
220P
AGND
C14
10nF
+5V
2 1 3 22 11 33
PJ2
LJB0661-6 L5
LF22uH VR1B
A10K
C16
47uF/25V
AGNDAGND2
5 67
U1B
TL074CD
C15
47uF/25V
R15 1K C17
47uF/25V
INPUTL
10
98
U1C
TL074CD
R14
2K2
R12 1K
AGND
12 13 14
U4D
TL074CD
R13
1M
OUTPUTL
VR2B
B1K
VR3B A10K
AGND
R23
270R
5 67
U4B
TL074CD
R19 4K7
C24
680P
AGND
L6
LF22uH
2 1 3
22 11 33
PJ4
LJB0661-6
AGND2
OUTPUT-B
MIXER-B
INTPUT-B
AGND
C25
220P
AGND
C26
10nF
C18
100nF
C19
100nF AGND
C20
100nF
C21
100nF AGND
C2
100uF/25V
C1
100uF/25V
SGND SGND
C22
100nF
SGND
R21
10K
R22
10K
(opt. alfacomp)
AGND AGND
(opt alfacomp)
2
1 3
5
4 6
SW2 DPDT
UP=compressor effect DOWN=bypass
+VCC
(MONO IN)
C46
47P
C47
47P
C48
47P
C49
47P
KEVIN LIN.
L7
BLM21A102
L8
BLM21A102
AGND2AGND
P1 STARTGND
SGND
61
3 4
L10
PLT09H-2003R
L12
BLM21A102
DGND
L11
BLM21A102
PS1
RX110
2002/01/06
A-VERBIO.SCH
MODEL:ALTO AlphaVERB
AS1 AS2
AS3 AS4
AS5 AS6
-5VO

BOTTOM SOLDER MASK
BOTTOM LAYER
4. Print Circuit Board

TOP SILKSCREEN
BOTTOM SILKSCREEN

Tool Hole Size Hole Count Plated
---------------------------------------------------------------------------
T1 31mil(0.80mm) 203
T2 39mil(1.00mm) 13
T3 47mil(1.20mm) 42
T4 59mil(1.50mm) 30
T5 98mil(2.50mm) 1
T6 118mil(3.00mm) 3
T7 138mil(3.50mm) 2
---------------------------------------------------------------------------
Totals 294
DRILL DRAWING

G1 Test Procedures (aCOMP)
Required Equipment
Audio Precision System 2 with APWin software
100 Mhz oscilloscope connected to APS2 Analyzer Signal Monitor outputs (Ch. A and Ch. B)
Connection Mode
Use Audio Precision System 2 analog unbalanced (BNC) inputs/outputs.

Test Procedures for AlphaComp
Amplitude response test
On PC:
-Load file: alfacomp_amplitude (APWin File menu / Open / Test )
Test Connections:
-Output A of Audio Precision System Two --> LEFT input of the device under test.
-LEFT output of the device under test --> A input of Audio Precision System Two
-RIGHT output of the device under test --> B input of Audio Precision System Two
On the Alphacomp:
-Turn on the power switch.
-Set INPUT volume to maximum.
-Set OUTPUT volume to maximum.
-Set PROGRAM to AGC PURE.
-Set VARIATION to 1.
Start the sweep (F9) and control the results (Page3 – Graph) in the following conditions:
-hardware bypass switch pressed.
-hardware bypass switch released.
Audio Precision 05/22/02 14:07:53
alfacomp_amplitude.at2c
Color Line Style Thick Data Axis
Cyan Solid 1Anlr.Level A Left
Green Solid 1Anlr.Level B Right
Yellow Solid 1An l r .Am p l Left
-10
+10
-7.5
-5
-2.5
+0
+2.5
+5
+7.5
d
B
V
-10
+10
-7.5
-5
-2.5
+0
+2.5
+5
+7.5
d
B
V
20 20k50 100 200 500 1k 2k 5k 10k
Hz

THD test
On PC:
-Load file: alfacomp_THD (APWin File menu / Open / Test )
Test Connections:
-Output A of Audio Precision System Two --> LEFT input of the device under test.
On the Alphacomp:
-Turn on the power switch.
-Set INPUT volume to maximum.
-Set OUTPUT volume to maximum.
-Set PROGRAM to AGC PURE.
-Set VARIATION to 1.
Start the sweep (F9) and control the results (Page3 – Graph) in the following conditions:
-LEFT output of the device under test --> A input of Audio Precision System Two / hardware
bypass switch released.
-RIGHT output of the device under test --> B input of Audio Precision System Two /
hardware bypass switch released.
Audio Precision 05/22/02 14:10:23
alfacomp_THD.at2c
Color Line Style Thick Data Axis
Cyan Solid 1Anlr.THD+N Ratio Left
Green Solid 1Anlr.THD+N Ratio Left
0.1
1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
%
20 6k50 100 200 500 1k 2k
Hz

S/N test
On PC:
-Load file: alfacomp_SN (APWin File menu / Open / Test )
Test Connections:
-Output A of Audio Precision System Two --> LEFT input of the device under test.
On the Alphacomp:
-Turn on the power switch.
- With hardware bypass switch in COMP position and both outputs connected to the Audio
Precision, increase the INPUT level until the device`s outputs clip, and after reduce the INPUT
level itself until the outputs exit from clipping state.
-Set OUTPUT volume to maximum.
-Set PROGRAM to AGC PURE.
-Set VARIATION to 1.
Start the sweep (F9) and control the results (Page3 – Graph) in the following conditions:
-LEFT output of the device under test --> A input of Audio Precision System Two / hardware
bypass switch pressed.
-RIGHT output of the device under test --> B input of Audio Precision System Two /
hardware bypass switch pressed.
Audio Precision 05/22/02 14:13:55
alfacomp_SN.at2c
Color Line Style Thick Data Axi s
Cyan Solid 1An l r .Am p l Left
Green Solid 1An l r .Am p l Left
-120
+20
-100
-80
-60
-40
-20
+0
d
B
V
-1000.000 +0-900 -800 -700 -600 -500 -400 -300 -200 -100
dBV
PROCESSBYPASS

Dynamics test
On PC:
-Load file: alfacomp_dyn (APWin File menu / Open / Test )
Test Connections:
-Output A of Audio Precision System Two --> LEFT input of the device under test.
On the Alphacomp:
-Turn on the power switch.
-Set INPUT volume to maximum.
-Set OUTPUT volume to maximum.
-Set PROGRAM to AGC PURE.
-Set VARIATION to 1.
Start the sweep (F9) and control the results (Page3 – Graph) in the following conditions:
-LEFT output of the device under test --> A input of Audio Precision System Two / hardware
bypass switch pressed.
-RIGHT output of the device under test --> B input of Audio Precision System Two /
hardware bypass switch pressed.
Audio Precision 05/22/02 14:17:59
alfacom p_dyn.at2c
Color Line Style Thick Data Axi s
Cyan Solid 1Anlr.THD+N Ratio Left
Green Solid 1Anlr.Level A Right
Green Solid 1Anlr.THD+N Ratio Left
Yellow Solid 1Anlr.Level A Right
-7.5
+10
-5
-2.5
+0
+2.5
+5
+7.5
d
B
u
-0
16
2
4
6
8
10
12
14
%
-26 -14-24 -22 -20 -18 -16
dBu
BYPASS
BYPASS
PROCESS

Stability test
On PC:
-Load file: alfacomp_stability (APWin File menu / Open / Test )
Test Connections:
-Output A of Audio Precision System Two --> LEFT input of the device under test.
-LEFT output of the device under test --> A input of Audio Precision System Two
-RIGHT output of the device under test --> B input of Audio Precision System Two
On the Alphacomp:
-Turn on the power switch.
-Set OUTPUT volume to maximum.
-Set PROGRAM to AGC PURE.
-Set hardware bypass switch to BYPASS (released).
-Set VARIATION to 1.
Test:
Move the input level knob from 0 to maximum 3 times and control the output waveforms:
NO PERMANENT SINE WAVEFORMS should be visible. IF PERMANENT
WAVEFORMS WITH FREQUENCY > 20 kHz should become visible on whatever output
channel, THE UNIT IS TO BE INSPECTED.

SEKAKU ELECTRON INDUSTRY CO.,LTD
IEBO_P02 IEBO_P02
Multi-Level BOM Structure Listing
Report No.: IEBO_P02 Date 2003/08/20
Prepared by 000011[YAFEN] Page No.: 1/9
Item No. PF00076 Version UNIT: PCS
DESCRIPTI
O
aCOMP Date: 2002/04/16
aCOMP_ALTO_230V_歐規_無
Version Item No Loss % Ver. Unit Cardinal Effective Date
Item Description Usage Rat
e
@:Phantom Layer
Component Remark Attrition Rate
├0001--------------------------------- MA02918 1.0000 2002/04/16
││ panel(white) PCS 1 N
││ αComp ▲LTO 0.00 %
├0002--------------------------------- MB01615 1.0000 2002/04/16
││ bottom board PCS 1 N
││ a verb 0.00 %
├0003--------------------------------- MC00371 1.0000 2002/04/16
││ top cover PCS 1 N
││ aVERB 0.00 %
├0004--------------------------------- MB01957 1.0000 2002/04/16
││ rear board PCS 1 N
││ a verb 0.00 %
├0005--------------------------------- NI00363 1.0000 2002/04/16
│plastic knob PCS 1 N
│φ21*16 0.00 %
├0006--------------------------------- NI00362 3.0000 2002/04/16
│plastic knob PCS 1 N
│(COOL GRAY 8C/white) 0.00 %
├0007--------------------------------- NI00896 3.0000 2002/04/16
│knob cover-ABS PCS 1 N
│φ8.5*4 bule 072C 0.00 %
├0008--------------------------------- NI00307 1.0000 2002/04/16
│power sw bottom PCS 1 N
│φ15*12 0.00 %
├0009--------------------------------- NI01160 1.0000 2002/04/16
│power switch cap PCS 1 N
│φ14.5*10 YELLOW C 0.00 %
├0010--------------------------------- NI00314 1.0000 2002/04/16
│power sw bottom PCS 1 N
│φ6.5*16(inner 3.3*3.3)black 0.00 %
├0011--------------------------------- MG00025 10.0000 2002/04/16
│screw PCS 1 N
│M3*6 0.00 %
├0012--------------------------------- MG00163 2.0000 2002/04/16
│Ni-screw PCS 1 N
│M3*8 0.00 %
├0013--------------------------------- MG00045 4.0000 2002/04/16
│screw PCS 1 N
│M3*7 0.00 %
├0014--------------------------------- NI00002 5.0000 2002/04/16
│nut of plastic-HC00108 Appendix PCS 1 N
│φ7/16"*G20/15*4.8(hexagon) 0.00 %
├0015--------------------------------- MF00014 2.0000 2002/04/16
│outter gear washer PCS 1 N
│φ3*φ6.5*0.5t 0.00 %

SEKAKU ELECTRON INDUSTRY CO.,LTD
IEBO_P02 IEBO_P02
Multi-Level BOM Structure Listing
Report No.: IEBO_P02 Date 2003/08/20
Prepared by 000011[YAFEN] Page No.: 2/9
Item No. PF00076 Version UNIT: PCS
DESCRIPTI
O
aCOMP Date: 2002/04/16
aCOMP_ALTO_230V_歐規_無
Version Item No Loss % Ver. Unit Cardinal Effective Date
Item Description Usage Rat
e
@:Phantom Layer
Component Remark Attrition Rate
├0016--------------------------------- HA01388 1.0000 2002/04/16
│row-wire connector wiring PCS 1 N
│2P 100 0.00 %
├0017--------------------------------- NC00131 5.0000 2002/05/05
│washer PCS 1 N
│1*φ11.3*φ15.3 red 0.00 %
├0018--------------------------------- SA00065 1.0000 2002/05/05
│L.E.D PCS 1 N
│LG2043 green 0.00 %
├0019--------------------------------- NI00240 2.0000 2002/05/05
││ sleeving flame retardant PCS 1 N
││ φ2.5*10mm 0.00 %
├0020--------------------------------- TG00023 1.0000 2002/05/05
│voltage transformer PCS 1 N
│230V/50Hz_AC9V/300mA_ET-35_CE 0.00 %
├0021--------------------------------- NF00124 1.0000 2002/05/05
││ instruction PCS 1 N
││ aCOMP 0.00 %
├0022--------------------------------- HJ00002 1.0000 2002/05/05
│desiccant PCS 1 N
│10g 0.00 %
├0023--------------------------------- NA00122 1.0000 2002/05/05
│PE bag PCS 1 N
│0.04t*350*230mm KG 0.00 %
├0024--------------------------------- NA00137 1.0000 2002/05/05
│clip-chain bag PCS 1 N
│5*7 0.00 %
├0025--------------------------------- NI01825 1.0000 2002/05/05
││ ZD-cushion-aVERB-10 PCS 1 N
││ 0.5*φ3.3*φ8.3 aVERB 0.00 %
├0026--------------------------------- NA00146 1.0000 2002/05/05
│bubble bag PCS 1 N
│13*16 0.00 %
├0027--------------------------------- NI00501 4.0000 2002/05/05
│foot cushion PCS 1 N
│12.7*9*3t(SF-004) 0.00 %
├0028--------------------------------- NI02085 1.0000 2002/07/19
│power switch fixed sleeve PCS 1 N
│φ22*9.69 072C blue 0.00 %
├0029--------------------------------- NE03118 1.0000 2002/07/19
││ program adhesive paper 12*9mm PCS 1 N
││ aCOMP CKS:C47F 0.00 %
├0030--------------------------------- NB01480 1.0000 2002/07/19
│colour box PCS 1 N
│aCOMP ALTO 0.00 %

SEKAKU ELECTRON INDUSTRY CO.,LTD
IEBO_P02 IEBO_P02
Multi-Level BOM Structure Listing
Report No.: IEBO_P02 Date 2003/08/20
Prepared by 000011[YAFEN] Page No.: 3/9
Item No. PF00076 Version UNIT: PCS
DESCRIPTI
O
aCOMP Date: 2002/04/16
aCOMP_ALTO_230V_歐規_無
Version Item No Loss % Ver. Unit Cardinal Effective Date
Item Description Usage Rat
e
@:Phantom Layer
Component Remark Attrition Rate
├0031--------------------------------- NB02141 1.0000 2002/12/05
│outter carton 8 hole PCS 8 N
│aVERB aCOMP aMICTUBE ALTO 0.00 %
├0032--------------------------------- MI00408 1.0000 2002/07/19
││ conduct electricity board PCS 1 N
││ aVERB 0.00 %
├0033--------------------------------- NE05008 4.0000 2002/07/19
││ ZC-bar shape code abhesive paper 30*11
m
PCS 1 N
││ ACOMP 0.00 %
├0034--------------------------------- NE05004 4.0000 2002/07/19
│number bar shape adhevise paper 30*11m
m
PCS 1 N
│ALTO PF 0.00 %
├0035--------------------------------- HK00337 1.0000 2002/07/19
││ PC board PCS 1 N
││ P-aCOMP-DIP 0.00 %
│├0001------------------------------- RA00204 1.0000 2002/04/16
││ fixed resistor 1/4W PCS 1 N
││ 470ΩM type 0.00 %
R44
│├0002------------------------------- CB00009 3.0000 2002/04/16
││ electrolytic capacitor PCS 1 N
││ 1uF/50V ψ4*7mm 0.00 %
C29 C30 C31
│├0003------------------------------- CB00024 5.0000 2002/04/16
││ electrotytic capacitor PCS 1 N
││ 10uF/16V ψ4*7mm 0.00 %
R34 R37 R38 R5 R6
│├0004------------------------------- CB00040 6.0000 2002/04/16
││ electrotytic capacitor PCS 1 N
││ 47uF/25V φ5*11mm 0.00 %
C12 C13 C15 C16 C17 C8
│├0005------------------------------- CB00039 1.0000 2002/04/16
││ electrotytic capacitor PCS 1 N
││ 47uF/25V φ5*11mm 0.00 %
C27
│├0006------------------------------- CB00047 4.0000 2002/04/16
││ electrotytic capacitor PCS 1 N
││ 100uF/25V φ6*11mm 0.00 %
C1 C2 C3 C4
│├0007------------------------------- CB00056 1.0000 2002/04/16
││ electrolytic capacitor PCS 1 N
││ 220uF/25V φ8*11mm 0.00 %
C11
│├0008------------------------------- CB00080 1.0000 2002/04/16
││ electrotytic capacitor PCS 1 N
││ 2200uF/25V φ16*25mm 0.00 %
