Alto PS 2/2A User manual

LTO
R
www.altoproaudio.com
Version 1.1 Septemper 2005
English
User's Manual
PS 2/2A

1
SAFETY INSTRUCTIONS
1. Read Instructions
All the safety and operation instructions should be read before using the product and retain them for future reference.
2. Water & Moisture
This product should not be used near water and will be protect from atmospheric agents in fixed or temporary installations.
3. Heat
This product should be situated away from heat sources such as radiators, or other devices which produce heat.
4. Liquid Entry
Care should be taken so that liquids are not spilled into the product and that objects do not fall on.
5. Service Assistance
This product should be serviced only by qualified service personnel when :
a. Liquids has spilled or objects have fallen into this product, or
b. This product has been exposed to rain, or
c. This product does not appear to operate normally or exhibits change in performance, or been dropped or itshas
cabinet / chassis damaged.
6. Package
The package of this product has been tested, inspect the package before open, if any damage is found, notify to
your dealer.
7. Hearing
This product produce high acoustic levels may cause permanent hearing loss, (SPL in for a defined period of time).
8. Installations
This product should be installed on the floor with a specific stand, according to the max weight, or in suspension
with a five points included in the cabinet (M10 1.5PH Length 30mm).
The suspension of more speaker cabinet in a vertical array is NOT advised.
"Electric discharge"
This symbol, alert you to the presence of uninsulated dangerous voltage inside the product which constitutes aenclosure,
risk of electric shock.
"Exclamatory point"
This symbol, alert the user to the presence of important operating and maintenance instructions the owner's manualin
included to the product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Disposing of this product should not be placed in municipal waste and should Separate collection.be

2
1. PS 2 PASSIVE SPEAKER CABINET QUICK START
Stereo
Power Amplifier

3
2. PS 2A ACTIVE SPEAKER CABINET QUICK START
Signal Cable
Power Cord
Tripod
Mount
Main Mix
Left
Output
Mixer
Tripod
Mount
Power Cord
Right
Output
Main Mix

4
3. SUSPENSION POINT
4. TECHNICAL SPECIFICATIONS
Descriptions
System type
Continuos Power
Peak Power Rating
Sensitivity at 1W, 1mt
Max SPL at 1mt
Frequency Response
Impedance
Crossover Frequency
Lower - Frequency
High - Frequency
High Frequency Protection
Dimensions H W D
Net Weight /
Gross Weight lbs/kg
Shipping Volume
kg lbs
PS 2
2 - way vented box
120 Watt AES Standard
240 Watt Peak
96dB SPL
117dB SPL
60Hz / 20kHz +/- 10dB
8 ohm Nominal
2450Hz 12dB/Oct
10" / 266mm - 1.5" Voice Coil
1" Compression Driver -
1" Voice Coil
Electronic Dynamic Protection
595mm 320mm 334.5mm
(23.4" 12.6" 13.2")
9.27kg / 20.44lbs
12.45kg / 27.45lbs
3.68CFT
The AES 2 - 1984 Standard specification by Audio Engineering
Society, is representative and commonly used for the measure
in Professional Sound Reinforcement.
It is defined as the square of the RMS voltage generated with a
pre-defined and band-passed Pink Noise Signal, applied con-
tinuously for 2 hours, on the assembled speaker cabinet.
In this way, the declared power of ALTO passive speaker cabinet,
is comparable to the RMS voltage value, measured on the equiva-
lent power amplifier for the same value of impedance.
The PS 2/2A speaker cabinet also provides the suspension
points for fixed installation. How to use them?
First, open the dust covers, and the next, mount the flying
rings to the suspension points (M10 1.5PH LENGTH: 30mm).
For further details, please refer to the right illustration.
Descriptions
Powered System type
LOW Output Power
HIGH Output Power
Max SPL at 1m
Frequency Response
Impedance Low - High
Crossover Frequency
Protection Low - High
Low - Frequency
High - Frequency
Horn Coverage H V
Input Sensitivity
Input Impedance
Connectors
Plastic Reinforced Cabinet
Hardware Suspension
Amplifier Protections
External Control
Power Supply
Dimensions H W D
Net Weight /
Gross Weight lbs/kg
Shipping Volume
kg lbs
PS 2A
Bi-Amp. with analog processor
150W RMS Bridge Class AB
50W RMS Class AB
118dB SPL
55Hz / 20kHz +/- 10dB
Low 8Ohm - High 8Ohm
Complex EQ processor
Limiter / Compressor plus PTC
10" / 266mm - 1.5" voice coil
1"Compression Driver -
1" Voice Coil
90 H 45 V
Line + 4dB / 1.23V
30kohms Balanced -
15kohms Unbalanced
Input with Jack / Link with XLR
Trapezoidal & Monitor shape
Seven suspension points
Soft Start - Short Circuit -
DC voltage - Thermal Protection
Volume - Clip - Ground Switch
230Volt / 115Volt 50 /60Hz
595mm 320mm 334.5mm
(23.4" 12.6" 13.2")
11.60kg / 25.57lbs
14.78kg / 32.58lbs
3.68CFT
Suspension Point
Eyebolt
Dust Cover
