Wren V5BT User manual

V5BT Setup Guide

2
Box Contents
Power Supply
Wren V5BT Speaker
Mini USB
Charging Cable
Micro USB
Charging Cable
Wren V5BT
Setup Guide
V5BT Setup Guide
Wren V5 Safety
Instructions & Warranty
AC Power Cord
V5BT Safety Instructions & Warranty

English
3
Please check that the following are true:
• Your source device is equipped with Bluetooth® 2.0 or higher.
• You have your source device within range (32 ft. or less) of your V5BT.
• The Bluetooth wireless feature on your source device is turned on.
Before You Begin Setup
Please Note: A comprehensive user manual is available for download from
wrensound.com/support. It is not included with your Wren V5BT.

4
Powering On Your Wren V5BT
Press power button.
The power indicator will blink
white until the system is ready.
When the system is ready, the
power indicator will remain white.
solid white
Connect AC power cord
to power supply.
Connect power supply to AC outlet.
Connect power supply to power
input on rear of speaker.
The power indicator in the center of the
power button will flash white for about
10 seconds, then turn o.

English
5
Connections
Setup Button
Used to pair the V5BT with Bluetooth devices
3.5mm Aux Input
Connects any audio source to your
Wren V5BT via a 3.5mm audio cable
Power Supply Input
Connects to the power supply
USB Charging Port
Charges most smartphones
and tablets.

6
Make sure your Bluetooth source
device and the V5BT are both
turned on and the Bluetooth
mode is selected as the source
on your V5BT.
Press the setup button on the
rear of your V5BT (Figure 1) until
the Bluetooth source indicator
blinks amber once every second
(Figure 2). This will place the
V5BT into « discoverable »
mode.
In the Bluetooth control section
of your source device, place the
source device into « discovery »
mode. « Wren Speaker » should
appear on the list of devices that
can be paired.
Pairing occurs when two Bluetooth devices “communicate” with each other and create a
connection. The Wren V5BT can “remember” the last six Bluetooth devices that have
paired with it. For best results, have your Bluetooth source device near your V5BT.
Note: Your V5BT will automatically enter pairing mode the first time you plug it in. The following
directions are for all subsequent pairings. If you are setting up the speaker for the first time, start
with step 3 below.
Pairing with your V5BT
blinking
amber
Figure 1 Figure 2

English
7
Problem connecting? Visit wrensound.com/support for additional help.
To play music on your
Wren V5BT, make sure that
Bluetooth is turned on and
the “Wren Speaker” has
been selected on your source
device. Then simply select
your favorite music on your
device and play.
Select “Wren Speaker.” If
your source device asks for a
passkey, enter “0000” (four
zeros) and press “OK.” The
Bluetooth indicator on the
V5BT will blink amber two
times per second when pairing
is in progress (Figure 3).
A message will appear on
your source device to indicate
when pairing is complete,
In addition, the Bluetooth
indicator on the V5BT will go
from blinking amber to solid
white (Figure 4). You are now
ready to play music wirelessly
on your V5BT. Figure 3 • Pairing
blinking
amber
Figure 4 • Connected
solid
white

8
As with all Bluetooth pairings with audio devices, the volume control of your
Wren V5BT functions as a “master” volume control. That means that the
volume control on the V5BT governs how loud your music can play. Once you
have set the volume level on the V5BT, the volume control on your source
device allows you to play music ranging from very low to as high as your V5BT
“master” volume setting allows.. For best results, we suggest setting the master
volume control on the V5BT at or near maximum volume. The best way to
determine where to set the volume on the V5BT is to use the following steps:
• Set the volume control on the V5BT at about half of maximum.
• Set the volume control on your source device at or just below maximum.
• Play music that you are familiar with.
• Raise the volume control on the V5BT in small steps until it is as loud as you
think you will want it to play.
• Turn the volume down on your source device. You will find that it goes from
the peak loudness you established all the way down through medium to
soft to inaudible.
• You can now use your source device to play music from very low to as
loud you have set the V5BT to play. This enables you to manage volume
remotely using your source device.
Important Note on Volume Control

English
9
How Does Bluetooth Work?
Bluetooth wireless technology is a small-area networking protocol that
removes the need for user intervention and keeps transmission power
extremely low to save battery power. Because it is ecient and easy to
use, Bluetooth wireless technology has been widely adopted as the most
popular (and familiar) way to enable devices like smartphones, tablets, and
computers to connect to and communicate with other popular devices
like audio headsets and speakers—all without cumbersome wires. The low
power limits the range of a Bluetooth device to about 10 meters (32 feet),
cutting the chances of interference between your computer system and
your portable telephone or television. Even with the low power, Bluetooth
doesn’t require line of sight between communicating devices. The walls in
your house won’t stop a Bluetooth signal. And because Bluetooth operates
by making only one connection to one device at a time, it is free from
interference and “confusion” among various Bluetooth-enabled devices.
Problem connecting? Visit wrensound.com/support for additional help.

10
To pair additional devices with
your V5BT, simply follow the
instructions under “Pairing with
your V5BT” on pages 6-7.
When the Power button is pressed
to turn the speaker on from Sleep
or Standby mode, the V5BT will
look for the most recently paired
device that was connected to the
speaker. If that device is available,
the V5BT will reconnect to it. If the
last paired device is not available,
the V5BT will continue to search
for the next most recently paired
device. It will connect with the
most recently paired device that
it finds.
When you wish to connect to a
specific paired device, press and
hold the Source button on the
front of the speaker for three (3)
seconds. The Bluetooth indicator
will blink amber two times per
second indicating that the V5BT
is trying to connect to a paired
device. Select “Wren Speaker” on
the source device. The Bluetooth
indicator will change to solid
white when an active connection
is established (Figure 5).
Many households (and many individuals) have multiple Bluetooth-equipped devices that
they use for music. The Wren V5BT can “remember” pairings with up to six dierent
Bluetooth devices, eliminating the need to go through the initial pairing process every
time you switch devices.
Using multiple devices on your V5BT

English
11
Problem connecting? Visit wrensound.com/support for additional help.
To clear the V5BT’s memory
of all paired devices, press and
hold the Setup button on the
rear of your V5BT and, while
holding the Setup button, press
the Power button on the front
control panel. The Volume
indicator will blink amber
two times to indicate that the
memory has been cleared. When
the V5BT is powered on again,
it will be in pairing mode and
ready to pair with a Bluetooth
device (see “Pairing with your
V5BT” on page 6).
Note:After you have cleared your
V5BT’s memory, you must delete
“Wren Speaker” from your source
device’s list of available Bluetooth
devices before you can pair it
with the V5BT again. To delete
a previously paired Wren V5BT
from your source device’s memory,
follow the directions provided by
the manufacturer.
solid
white
Figure 5

12
aptX works within Bluetooth to deliver CD-quality audio over a Bluetooth wireless
connection. Simply establish a Bluetooth connection between your aptX-enabled
smartphone or tablet and your V5BT and experience high fidelity wireless audio.
aptX works automatically: If your source device is equipped with aptX, it will
automatically detect an aptX-equipped receiving device (like the Wren V5BT) and
you will enjoy CD-quality sound. If your source device does not have aptX, the V5BT
will default to standard Bluetooth audio.
It is important to note that aptX needs to be supported on both sides of the
Bluetooth connection. To determine if a Bluetooth-enabled device supports aptX,
just look for the aptX logo on the product’s packaging:
For an up-to-date list of devices equipped with aptX, go to the “Support” page on the Wren
website (www.wrensound.com/support), select “V5BT for Bluetooth” from the drop-down
menu, and click on the “aptX Compatibility” button.
Bluetooth audio on steroids!
Using CSR aptX®

English
13
Speaker Controls
* See the full user manual at wrensound.com/support for details.
Volume Adjustment Indicator
Indicates volume being adjusted.
Source Selector
Selects the desired audio
input source.
Bluetooth Indicator
Indicates Bluetooth
audio source is selected. Aux (3.5mm) Source Indicator
Indicates aux audio source is selected.

14
Troubleshooting Tips
Problem Possible Solutions
Cannot pair
the speaker
with my
Bluetooth®
device
• Make sure your V5BT is discoverable. Refer to “Pairing with your V5BT”
on page 6.
• Make sure the Bluetooth feature on your device is turned on.
• Your Bluetooth device may be out of range – try moving it closer to
the V5BT.
• Turn the V5BT o and back on.
• Make sure your Bluetooth device supports the A2DP (stereo Bluetooth)
profile.
• Make sure when connecting to a PC or Mac computer that you select
the “Wren Speaker” as the audio output device within the audio settings
menu of the computer. You may need to play an audio track to make the
connection.
Poor sound
quality from
a Bluetooth®
device
• Your Bluetooth device may be out of range. Try moving it closer to the V5BT.
• Make sure your Bluetooth device and/or you V5BT are not positioned near
other devices that generate electromagnetic interference, e.g., cordless
phones, microwave ovens, wireless routers, or other Bluetooth devices.
• Reduce the number of applications running on your Bluetooth device.
Running multiple applications can reduce the amount of internal resources
available to transmit audio. Closing non-essential applications may improve
audio quality.
• Try turning o your device’s Wi-Fi®.
• Try unpairing and then re-pairing your Bluetooth device to your V5BT.
• Turn the V5BT o and back on.
• Clear the memory of your V5BT following step 4 on page 11. The Bluetooth
source indicator on the control panel of your V5BT will blink amber
once every second to indicate that the “discoverable” mode is engaged.
Then re-pair your device following instructions on page 6.

English
15
Questions? Visit wrensound.com/support for additional help.
Problem Possible Solutions
Paired
Bluetooth®
device will not
connect
• If your device requires a passkey, make sure you entered 0000
(four zeroes).
• Turn the V5BT o and on again.
• Clear the speaker memory (see Step 4 on page 11). Remove the Wren
speaker from the list of paired devices on your Bluetooth device.
Then pair the device and the Wren speaker again.
Speaker
indicates a
connection,
but is not
playing music
• Turn o or disable Bluetooth on all other paired devices nearby,
then reconnect the source device you want to hear.
• Turn the V5BT o and on again.
• Make sure the transport controls of the audio device are set to
playback audio.
• Make sure your Wren V5BT is not muted, and the volume is up.
• Make sure your Bluetooth®-enabled device is playing audio.
No audio
from a
Bluetooth®
device
• Make sure your Bluetooth device and/or your V5BT are not positioned near
other devices that generate electromagnetic interference, e.g., cordless
phones, microwave ovens, wireless routers, or other Bluetooth devices.
• Refer to the owner’s guide or technical support for your Bluetooth device
to make sure you know how it pairs with other Bluetooth devices.
• Make sure your Wren V5BT is not muted, and the volume is up.
• Make sure your Bluetooth®-enabled device is playing audio.
• Your Bluetooth device may be out of range – try moving it closer to
your V5BT.
• Turn the V5BT o and back on.

© 2013 Wren Sound Systems, LLC V5BT.080113.USC
Contact Information
Wren Sound Systems | Customer Service/Technical Support
Phone: 1-855-GET-WREN (438-9736)
Email: [e-mail]
Web: wrensound.com/support
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by Wren Sound Systems, LLC is under license. Other trademarks and trade names are those of their
respective owners.
© 2012 CSR plc and its group companies. The aptX® mark and the aptX logo are trade marks of CSR plc or one
of its group companies and may be registered in one or more jurisdictions.
La palabra, marca y logos Bluetooth® son marcas comerciales registradas pertenecientes a Bluetooth SIG, Inc.
y todo uso de ellos por parte de Wren Sound Systems, LLC se hace bajo licencia. Otras marcas comerciales y
nombres comerciales pertenecen a sus respectivos dueños.
© 2012 CSR plc y las compañías de su grupo. La marca aptX® y el logo aptX son marcas comerciales de CSR plc
o de una de las compañías de su grupo y pueden estar registradas en una o más jurisdicciones.
Les mot et logo Bluetooth® est une marque déposée et est la propriété de Bluetooth SIG, Inc. et toute utilisation
de cette marque par Wren Sound Systems, LLC est sous licence. Toutes marques et noms commerciaux
déposés sont ceux de leur propriétaire respectif.
© 2012 CSR plc et ses sociétés de groupe. La marque et le logo aptX sont des marques déposées de CSR plc
ou d’une des ses sociétés de groupe et peut être enregistrées dans un ou plusieurs champs d’applications.

V5 Safety Instructions & Warranty

English
Consumer Product Safety Guide:
1. Read these instructions.
2. Keep these instructions.
3. Follow all instructions.
4. Heed all warnings.
5. Water and Moisture
• Do not use near water (bathtub, washbowl,
kitchen sink, laundry tub, swimming pool or
in a wet basement).
6. Ventilation
• The unit should be situated so that its
location or position does not interfere with
its proper ventilation.
• For example, it should not be situated on
a bed, sofa, rug or similar surface that may
block ventilation openings.
• Also, it should not be placed in a built-in
installation, such as a bookcase or cabinet,
which may impede the flow of air through
the ventilation openings.
7. Heat
• The unit should be situated away from heat
sources such as radiators, heat registers,
stoves or other appliances (including amplifiers)
that produce heat.
8. Power Sources
• The unit should be connected to a power
supply only of the type described in the
operating instructions or as marked on
the appliance.
9. Power Cable Protection
• Power supply cables should be routed so that
they are not likely to be walked on or pinched
by items placed on or against them.
• It is always best to have a clear area from where
the cable exits the unit to where it is plugged
into an AC socket.
10. Cleaning
• The unit should be cleaned only as
recommended.
• See the Maintenance section of this manual
for cleaning instructions.
11. Objects and Liquid Entry
• Care should be taken so that objects do not fall
and liquids are not spilled into any openings or
vents located on the product.
12. Attachments
• Do not use attachments not recommended by
the product manufacturer.
13. Lightning and Power Surge Protection
• Unplug the unit from the wall socket and
disconnect the antenna or cable system during
a lightning storm or when it is left unattended
and unused for long periods of time. This will
prevent damage to the product due to lightning
and power-line surges.
14. Overloading
• Do not overload wall sockets, extension cords,
or integral convenience receptacles as this can
result in a risk of fire or electric shock.
15. Servicing
• The user should not attempt to service the unit
beyond those methods described in the user’s
operating instructions.
• Service methods not covered in the User
Manual should be referred to Wren.
The unit should be serviced by
qualified service personnel when:
• The power supply cable or plug has been
damaged.
• Objects have fallen into or liquid has been
spilled into the enclosure.
• The unit has been exposed to rain.
• The unit has been dropped or the enclosure
damaged.
• The unit exhibits a marked change in
performance or does not operate normally.
16. Antenna
• Do not connect an external antenna to the
Wren V5AP.
17. Periods of Non-Use
• To prevent damage or corrosion, unplug the
power cable from the speaker if the unit is to
be left unused for an extended period of time,
such as a month or longer.

FCC Radiation Exposure Statement:
FCC ID: R48-V5AP IC:7190A-V5AP
FCC ID: R48-V5PF IC:7190A-V5PF
FCC ID: R48-V5BT IC:7190A-V5BT
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference
received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
FCC Caution: Any changes or modifications not expressly
approved by the party responsible for compliance could
void the user’s authority to operate this equipment.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
This equipment should be installed and operated
with minimum distance 20cm between the radiator
& your body.
Industry Canada Statement:
This device complies with RSS-210 of the Industry
Canada Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference
received, including interference that may cause
undesired operation.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure
limits set forth for an uncontrolled environment.
This equipment should be installed and operated
with minimum distance 20cm between the radiator
& your body.
WEEE Notice:
Note: This mark applies only to countries within the
European Union (EU) and Norway
This appliance is labeled in accordance
with European Directive 2002/96/EC
concerning waste electrical and electronic
equipment (WEEE). This label indicates
that this product should not be disposed
of with household waste. It should be deposited at an
appropriate facility to enable recovery and recycling.
The exclamation point, within an
equilateral triangle, is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the product.
The lightning flash with arrowhead
symbol within an equilateral triangle
alerts the user to the presence of
uninsulated “dangerous voltage” within
the product’s enclosure that may be
of sufficient magnitude to constitute a risk of electric
shock to persons.
WARNING: To reduce the risk of fire or electrical shock,
do not expose this apparatus to rain or moisture.

English
Note: This mark applies only to countries within the
European Union (EU) and Norway.
This appliance is labeled in accordance with European
Directive 2002/96/EC concerning waste electrical and
electronic equipment (WEEE). This lebel indicates that
this product should not be disposed of with household
waste. It should be deposited at an appropriate facility
to enable recovery and recycling.
The exclamation point, within an equilateral triangle,
is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the product.
The lightning flash with arrowhead symbol within an
equilateral triangle alerts the user to the presence of
uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
WARNING: To reduce the risk of fire or electrical shock,
do not expose this apparatus to rain or moisture.
No naked flame sources - such as candles - should be
placed on the product.
Place the equipment near a main power supply outlet
and make sure that you can easily access the power
breaker switch.
WARNING: This product is intended to be operated ONLY
from the AC Voltages listed on the back panel or included
power supply of the product. Operation from other voltages
other than those indicated may cause irreversible damage
to the product and void the products warranty. The use
of AC Plus Adapters is cautioned because it can allow the
product to be plugged into voltages in which the product
was not designed to operate. If the product is equipped
with a detachable power cord, use only the type provided
with your product or by your local distributor and/or
retailer. If you are unsure of the correct operational voltage,
please contact your local distributor and/or retailer.
