Alto 560 B User manual

Operator's
Manual
Model
560 B
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read this
bookpriortooperatingorattemptinganyserviceormaintenanceproceduretoyourALTOmachinecould
result in injury to you or to other personnel; damage to the machine or to other property could occur as
well. You must have training in the operation of this machine before using it. If your operator(s) cannot
read English, have this manual explained fully before attempting to operate this machine.
Si Ud. o sus operadores no pueden leer el Inglés, se hagan explicar este manual completamente antes
de tratar el manejo o servicio de esta máquina.
All directions given in this book are as seen from the operator’s position at the rear of the machine.
For new books write to: ALTO U.S. Inc., 2100 Highway 265, Springdale, Arkansas 72764.
Form No. 999836 3/99 Clarke Technology Printed in theU.S.A.

Page -8- Clarke Technology Operator's Manual Model 560 B
CLARKETECHNOLOGYModel560B
Assembly Drawing 3/99
50
51

ClarkeTechnologyOperator'sManualModel560 B Page -9-
1 30037A Cover 1
2 51600A Bumper 1
3 920688 Nut, Plastic 1
4 56205A Nut, M7 Left 1
5 87608A Washer 1
6 54711A Impeller 1
7 964037 Screw 4
8 58546A Spacer 1
9 51910A Clamp, Strap 2
10 52958A Chamber, Fan 1
11 57878A Mount, Rubber 2
12 961025 Screw, Wing 2
13 964007 Screw, 6 x 12 2
14 980607 Washer 8
15 54801A Housing, Blower 1
16 58008A Screw, 4 x 8 2
17 980603 Washer 2
18 667201 Retainer 1
19 54304A Gasket 1
20 912311 Switch 1
21 964048 Screw, 4 x 18 2
22 664807 Insulation, Switch 1
23 54802A Plate, Bottom 1
24 54379A Gasket 1
25 56806A Plate,Sealing 1
26 53010A Ring Retainer 1
27 980933 Washer 1
28 961021 Screw 1
29 54302A Gasket 1
30 666612 Nozzle Plate 1
31 980935 Washer Spring 2
32 662004 Lever 2
33 961027 Shoulder Screw 2
34 42217A Power Cord 1
35 964006 Screw, 3 x 16 4
36 912313 Terminal Block 1
37 54701A Insulation 1
38 57318A Strain Relief 1
39 57303A Rivet, Plastic 1
40 58601A Spring 1
41 924003 Nut M6 1
42 56808A Foot Pedal 1
Ref.
No. Description
Part No. Part No.
Ref.
No.
No.
Req’d. No.
Req’d.
Description
43 56807A Foot Plate 1
44 56810A RollPin 1
45 56809B Pivot, Handle 1
46 961022 Screw 1
47 668101 Strain Relief 1
48 44708B Motor 1
49 50295A Carbon Brush 2
50 662005 Clamp 1
51 53167A Insulating Disc 1
52 58327A Shaft, Belt 1
53 51994A Circuit Breaker 1
54 59905A Wheel 4
55 660502 Axle 4
56 51924A Clip, Locking 4
57 52704A Cover, Hinged 1
58 661507 Cap, Brush End 1
59 663602 Thread, Guard 1
60 902648 Bearing 2
61 51406A Brush Segment 4
62 964047 Screw, 4 X 12 8
63 660905 Brush Assembly 1
64 663703 Handle Grip 1
65 663906 Handle Tube, Upp 1
66 664506 Cable Guide 1
67 924004 Nut M5 2
68 664507 Cable Guide 1
69 662104 Bag Clip 1
70 964004 Screw, 5 x 16 2
71 668310 Spring 1
72 964062 Screw, 8 x 25 2
73 662411 Connector 1
74 662412 Connector 1
75 662001 Dustbag Clip 1
76 660603 Paper Filter Bag 1
77 662801 Elbow 1
78 664102 Hose 1
79 663909 Handle Tube Low 1
80 660609 Cloth Filter Bag 1
81 663409 Gasket 1
82 660201 Adaptor 1
83 903404 Belt 1
84 54803A Housing Asm. 1
CAUTION: Repairs by qualified personnel only.
ACHTUNG: Reparaturen nur durch Facharbeiter.
PRECAUTION: Reparations par personnel specialize seulement.
PRECAUTUION: Unicamente personal calificado deberian hacer reparaciones.
CLARKETECHNOLOGYModel560B
Parts List 3/99
