CLARKE TECHNOLOGY Operator's Manual LV-30 Page 9
LV-30
LV-30H
Section II
Parts and Service Manual
(78043D)
Order Parts Here:
www.ivie-ent.com/parts
Ph:[phone]

Page 10 CLARKE TECHNOLOGY Operator's Manual LV-30
Model LV-30 & LV-30H
Assembly Drawing - 6/99
79A
84A
89
83
84A
90
50
52
53
55 69 6667
68 69
70
19
71
73
72
65
74
75
77
76
78 83
85 86
87
84
82
81
80
10
79
64
60 63
62
61
59
58
57
42
54
51
49
47
46
45
10 80
43 44
41
39
40
24
22
23
19
19
25
26
27
28
19
21
20
19
17
16
15
14
18
1213
10
11
88
77
9
87
4
12
356
29
33
30 31
32
38
3536
37
34
48

CLARKE TECHNOLOGY Operator's Manual LV-30 Page 11
Ref. Part No. Description Qty.
45 50035A Engine - Gas 5.5 hp Tecumseh 1
* 53808A Engine- Gas 5.5 hp Honda 1
46 215110 Label - Caution, Spanish 1
47 215103 Label - Caution 1
48 962158 Screw - 5/16 - 18 x 7/8 Hex 4
* 962324 Screw - 5/16-18 x 1.5 Hx Hd 4
49K760660 Bag - Filter Plain 1
50 765044 Knob - Throttle Control - Svc. Only 1
51 34267A Gasket - Muffler Mtg. (Honda Only) 1
52 215104 Label - Warning 1
53 215106 Label - Warning 1
55 62812A Extension Assembly Honda 1
57 755721 Nipple - 1/4-18 Short 1
58 822806 Elbow - 90° Street 1
59 170266 Coupling - 1/4 NPT 1
60 ref. Drain Plug (part of engine) 1
61 85702A Screw - 1/4-20 x 1 5/8 Hex St. Cap 2
62 85701A Screw - 1/4-20 x 1 1/2 Hex St. Mach 2
63 764541 Hook - Bag Right 1
64 766740 Pin - Locking 2
65 920284 Nut - 1/4-20 Stop 4
66 763740 Grip - Handle 2
67 761340 Brace - Handle 1
68 764540 Hook - Bag Left 1
69 763940 Handle 2
70 763701 Grip - Handle 1
71 761140 Bushing - Handle 1
72 962009 Screw #10-24 x 1 1/4 Rd St. Mach 1
73 763840 Guide - Handle 1
74 763946 Handle - Upper 1
75 766744 Pin - Locking 1
76 Plate - Serial 1
77 930112 Rivet - 1/8 Pop 4
78 805160 Label - Inspection 1
79 763264 Frame Assembly- Small Wheel 1
79a 763263 Frame Assembly - Large Wheel 1
80 920208 Nut - 1/4-20 8
81 920110 Nut - 5/16-18 Elastic Stop 4
82 980651 Washer - 5/16 Plain 4
83 925006 Pin - 1/8 x 1 1/4 Lg. Cotter 2
84 980679 Washer - 13/16 x 1 1/4 x 1/8 Flat 2
85 768244 Spacer - Wheel 2
86 769701 Wheel - Assembly 2
87 194446 Cap Hub w/Retainer 2
88 765141 Label - Caution 1
89 769740 Wheel - Large 2
90 761541 Hub - Cap 2
Model LV-30 & LV-30H
Parts List - 6/99
* Indicates parts that are for the LV 30H (Honda engine) only.
Ref. Part No. Description Qty.
1 920196 Nut 1/2 - 13 Hex Jam 2
2 980626 Washer - 1/2 Lock 2
3 760842 Bracket - Caster Support Asm. 2
4 766742 Pin Assembly - Disconnect 2
5 769744 Caster - Front Support 2
6 60050A Cover - Intake 1
7 762043 Clamp - Rear R.H. 1
8 768542 Scraper - R.H. 1
9 15711B Housing Assembly - Intake 1
10 980646 Washer - 1/4" 15
11 920180 Nut - Acorn 1/4 - 20 7
12 760741 Blade - Door 1
13 762047 Clamp - Door Blade 1
14 962483 Screw #10-24 x 5/8 1
15 980982 Washer #10 x 1/2 1
16 763945 Handle - Lower 1
17 768242 Spacer - Handle 1
18 73364A Label 1
19 920296 Nut - #10-24 Elastic Stop 16
20 84808A Screw #10-24 x 3/4 Rd. Hd. 10
21 962109 Screw #10-24 x 5/8 4
22 762045 Clamp - R.H. Shield 1
23 762046 Clamp - L.H. Shield 1
24 767841 Shield 2
25 768543 Scraper - L.H. 1
26 762044 Clamp - Rear L.H. 1
27 930086 Rivet - 3/16 x .450 4
28 682006 Lid Clamp Assembly 2
29 763444 Gasket - Intake Hsg. Flange 1
30 66909A Retainer Assembly 1
31 66908A Retainer Assembly 1
32 66907A Retainer Assembly 1
33 763443 Gasket - Impeller Housing 1
34 930113 Rivet - Pop 1/8 5
35 962241 Screw - #10-24 x 1/2 4
36 962747 Screw - 3/8-24 x 3/4 Nylok Hex Hd 1
* 962867 Screw 7/16 - 20 x 1 Hex Head 1
37 762050 Washer - Clamp Special 1
* 980013 Washer - Clamp Honda 1
38 35210B Housing - Impeller 1
39 764842 Impeller Tecumseh 1
* 764841 Impeller Honda 1
40 962593 Screw - 1/4-20 x 3/8 Nylok 1
41 962603 Screw - 5/16 - 24 x 1 1/4 Hex. 4
42 766664 Plate Assembly - Flange 1
43 980652 Washer - 5/16 Standard Lock 4
44 915570 Key - 1/4 x 1/4 x 2 1/4 Square 1
NOTE: Kindicates a change has been made since last
publication of this manual.
