AL600ULX Series
Power Supply/Charger
Installation Guide
Models Include:
•AL600ULX
- Single Output
•AL600ULPD4 •AL600ULPD4CB
- Four (4) Fused Outputs - Four (4) PTC Outputs
•AL600ULPD8 •AL600ULPD8CB
- Eight (8) Fused Outputs - Eight (8) PTC Outputs
•AL600ULXPD16 •AL600ULXPD16CB
- Sixteen (16) Fused Outputs - Sixteen (16) PTC Outputs
For a red enclosure, add an “R” suffix to the part # e.g. AL600ULPD8R
For a larger enclosure, add “XX” to the suffix to the part # e.g. AL600ULXX
Rev. 120612

- 2 - AL600ULX Series
Overview:
The AL600ULX is a power supply that converts a 115VAC / 60Hz input to a 12VDC or 24VDC regulating output (see
specifications below). The AL600ULX is the base power supply unit for the UL Listed multi-output power supply/charger
series: AL600ULPD4, AL600ULPD4CB, AL600ULPD8, AL600ULPD8CB, AL600ULXPD16, AL600ULXPD16CB
(Refer to AL600ULX Series Power Supply Configuration Reference Chart below).
AL600ULX Series Power Supply Configuration Reference Chart:
Altronix
Model Number Accessory Power Distribution Module(s) Number of Output(s) Class 2 Rated Power Limited Outputs Fused Outputs PTC Outputs Output Rating (amp) per Output Agency Listings UL Listings and File Numbers
AL600ULX
AL600ULXR
AL600ULXX
------ 1------ ------ ------ 6
UL File # S4707
UL 1481
UL Listed Power
Supplies for
Fire Protective
Signaling
Systems.
----------------------------------------
UL 294
UL Listed for
Access Control
System Units.
----------------------------------------
“Signal Equipment”
Evaluated to
CSA Standard C22.2
No.205-M1983
AL600ULPD4 PD4UL 4 ------ x------ 3.5
AL600ULPD4CB PD4ULCB 4 x -------- x 2.5
AL600ULPD8 PD8UL 8 ------ x------ 3.5
AL600ULPD8CB PD8ULCB 8 x ------ x 2.5
AL600ULXPD16 Two (2) PD8UL 16 ------ x------ 3.5
AL600ULXPD16CB Two (2) PD8ULCB 16 x ------ x 2.5
Do not exceed total output rating of 6 amp per unit.
AL600ULPD4/CB and AL600ULPD8/CB are available in larger enclosure. Add X to the model number
(eg. AL600ULXPD4/CB).
Specifications:
Output
Voltage
Type
Voltage
Output Current
Frequency Ripple
Voltage
Normal
Stand-by
Stand-by Battery
Minimum Operating Time
Maximum
(alarm)
Stand-by Battery
Minimum Operating Time
DC Output
12VDC & 24VDC DC See Stand-by Specifications pg. 3 N/A 300mV
Agency Listings:
• ULListedforAccessControlSystemUnits
(UL 294) and UL Listed Standard for Safety for
Fire Protective Signaling Systems (UL 1481).
• NFPA72compliant(Fire-ProtectiveSignalingService).
Input:
• Input115VAC/60Hz,3.5amp.
Output:
• 12VDCor24VDCselectableoutput(s).
• 6ampcontinuoussupplycurrentat12VDCor24VDC.
• Filteredandelectronicallyregulatedoutputs.
• Shortcircuitandthermaloverloadprotection.
Battery Backup:
• Built-inchargerforsealedleadacidorgeltypebatteries.
Battery Backup (cont’d):
• Automaticswitchovertostand-bybatterywhen
AC fails.
• Maximumchargecurrent0.7amp.
• Zerovoltagedropwhenswitchedoverto
battery backup.
Supervision:
• ACfailsupervision(form“C”contacts).
• Lowbatterysupervision(form“C”contacts).
• Batterypresencesupervision(form“C”contacts).
Additional Features:
• ACinput,DCoutputandBATtroubleLEDindicators.
•Powersupply,enclosure,camlockandbatteryleads.
• Allmodelsareavailableinredenclosure
(add an “R” suffix to the part # e.g. AL600ULPD8R).
Altronix Corp.
14058th St. Brooklyn, NY
California State
Fire Marshal
NYC Dept.
of Buildings
Factory
Mutual
Approved

AL600ULX Series - 3 -
Door
CAUTION: De-energize unit prior to servicing. For continued protection against risk of electric shock and
fire hazard replace fuse with the same type and rating. Do not expose to rain or moisture.
Wire
Strap
(from
Enclosure
to Door)
Battery & AC
Supervision
Circuit
(power-limited)
Class 1
Power
Distribution
Module(s)
INPUT
Divider
Earth
Ground
+ DC ---
BAT FAIL NC C NO NC C NO
+ BAT ---
AC FAIL
DCAC BAT
LG N
5A 250V
OPEN - 24V
CLOSED - 12V
AC Delay
OPEN - 24V
CLOSED - 12V
Battery
connection
(non power-limited) (non power-limited)
(non
power-
limited)
CAUTION: Optional rechargeable stand-by batteries must match the power supply output
voltage setting.
Keep power-limited wiring separate from non power-limited. Use minimum 0.25" spacing.
Optional Rechargeable
Stand-by Battery
Optional Rechargeable
Stand-by Battery
Power Supply Output Specifications:
Output Switch Position
12VDC SW1 - CLOSED (Fig. 1b, pg. 3)
24VDC SW1 - OPEN (Fig. 1b, pg. 3)
Stand-by Specifications (total current shown):
Output 4 hr. of Stand-by &
5 Minutes of Alarm
24 hr. of Stand-by &
5 Minutes of Alarm
60 hr. of Stand-by &
5 Minutes of Alarm
12VDC / 40AH Battery Stand-by = 6.0 amp
Alarm = 6.0 amp
Stand-by = 1.0 amp
Alarm = 6.0 amp
Stand-by = 300mA
Alarm = 6.0 amp
24VDC / 12AH Battery -------- Stand-by = 200mA
Alarm = 6.0 amp --------
24VDC / 40AH Battery Stand-by = 6.0 amp
Alarm = 6.0 amp
Stand-by = 1.0 amp
Alarm = 6.0 amp
Stand-by = 300mA
Alarm = 6.0 amp
Installation Instructions:
WiringmethodsshallbeinaccordancewiththeNationalElectricalCode/NFPA70/NFPA72/ANSI,andwithalllocal
codes and authorities having jurisdiction. Product is intended for indoor use only.
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
 enclosure.Installtwoupperfastenersandscrewsinthewallwiththescrewheadsprotruding.Placetheenclosure’s
upper keyholes over the two upper screws; level and secure. Mark the position of the lower two holes. Remove the
 enclosure.Drillthelowerholesandinstalltwofasteners.Placetheenclosure’supperkeyholesoverthe two upper
 screws.Installthetwolowerscrewsandmakesuretotightenallscrews(Enclosure Dimensions, pg. 7-8).
Fig. 1
Fig. 1a
Fig. 1b

- 4 - AL600ULX Series
2. The power supply is pre-wired to the ground (chassis). Connect main incoming ground to the provided green
grounding conductor lead. Connect unswitched AC power (115VAC / 60 Hz) to the terminals marked [L, N]
(Fig. 1, pg. 3). Use 14 AWG or larger for all power connections (Battery, DC output, AC input). Use 22 AWG to
18 AWG for power-limited circuits (AC Fail/Low Battery reporting).
Keep power-limited wiring separate from non-power limited wiring (115VAC / 60Hz Input, DC Output,
Battery Wires). Minimum 0.25” spacing must be provided.
For Fire Alarm applications the outputs are “Special Applications” only, see list (refer to Appendix A, pg. 6).
3. Set the unit to the desired DC output voltage by setting SW1 (Fig. 1b, pg. 3) to the appropriate position
(Power Supply Voltage Output Selections Chart, pg. 2).
4. Measureoutputvoltagebeforeconnectinganydevicestoensureproperoperation.Improperorhighvoltagewill 
damage these devices. When servicing the unit, AC mains should be removed.
5. Connect device(s) to be powered:
a. For AL600ULX(R) Power Supply: connect devices to the terminals marked [+ DC -] (Fig. 1, pg. 3).
b. For other Power Distribution Models: connect devices to be powered to the terminal pairs 1 to 4 marked
[1P & 1N through 4P & 4N] (Fig. 2a & 2b, pg. 5) or 1 to 8 marked [1P & 1N through 8P & 8N] (Fig. 3a & 3b,
pg. 5), carefully observing correct polarity.
6. For Access Control applications batteries are optional. When batteries are not used, a loss of AC will result in the
loss of output voltage. When the use of stand-by batteries is desired, they must be lead acid or gel type.
7. Connectappropriatesignalingnotificationdevicestotheterminalsmarked[ACFAIL&BATFAIL](Fig. 1, pg. 3)
supervisory relay outputs.
Note: When used in fire alarm or access control applications, “AC Fail” relay should be utilized
to visually indicate that AC power is on. To delay report for 6 hours cut “AC Delay” jumper (Fig. 1a, pg. 3).
8. Please ensure that the cover is secured with the provided Key Lock.
Wiring:
Use 14 AWG or larger for all power connections.
Note: Take care to keep power-limited circuits separate from non-power limited wiring (115VAC, Battery).
Maintenance:
Unit should be tested at least once a year for the proper operation as follows:
Output Voltage Test: Under normal load conditions the DC output voltage should be checked for proper voltage level
(Power Supply Voltage Output Specifications Chart, pg. 3).
Battery Test: Under normal load conditions check that the battery is fully charged, check specified voltage both at the
battery terminal and at the board terminals marked [+ BAT –] to ensure that there is no break in the battery
connection wires.
Note: Maximum charging current under discharges is 0.7 amp.
Note: Expected battery life is 5 years; however, it is recommended changing batteries in 4 years or less if needed.
LED Diagnostics:
Power Supply Board
Red (DC) Green (AC) Power Supply Status
ON ON Normal operating condition.
ON OFF Loss of AC. Stand-by battery supplying power.
OFF ON No DC output.
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
Red (Bat) Battery Status
ON Normal operating condition.
OFF Battery fail/low battery.
Power Distribution Module
Green (AC) Power Distribution Module Status
ON Normal operating condition.
OFF No Power Output.

AL600ULX Series - 5 -
Terminal Identification:
Power Supply Board
Terminal
Legend Function/Description
L, G, N Connect 115VAC 60 Hz. to these terminals: L to hot, N to Neutral. Do not use the [G] terminal.
+ DC --- 12VDC or 24VDC @ 6 amp continuous non power-limited output.
AC Fail
NC, C, NO
Indicates loss of AC power, e.g. connect to audible device or alarm panel. Relay normally energized
when AC power is present. Contact rating 1 amp @ 28VDC. AC or brownout fail is reported within 1
minute of the event. To delay reporting for up to 6 hrs., cut “AC delay” jumper and reset power to unit.
Bat Fail
NC, C, NO
Indicateslowbatterycondition,e.g.connecttoalarmpanel.RelaynormallyenergizedwhenDCpower
is present. Contact rating 1 amp @ 28VDC.
+ BAT --- Stand-by battery connections. Maximum charge current 0.7 amp.
Power Distribution Module
Terminal Legend PD4UL/PD4ULCB Terminal Legend PD8UL/PD8ULCB Function/Description
1P to 4P 1P to 8P Positive DC power outputs.
1N to 4N 1N to 8N Negative DC power outputs.
INPUT
LED
PD4UL
POWER DISTRIBUTING UNIT
ALTRONIX CORP. BROOKLYN, NY 11220
MADE IN USA
1P, 2P, 3P, 4P = FUSED OUTPUTS
1N, 2N, 3N, 4N = COMMON OUTPUTS
F1 F2 F3 F4
COMMON POWER OUTPUTS
1P 1N 2P 2N 3P 3N 4P 4N
From Power Supply
Board
(Factory Installed)
Replace fuses with the same type and rating 3.5A, 250V.
Non Power-Limited
DC Output to devices
1P-4P Power Outputs,
1N-4N Common Outputs
( )
Fig. 2a
Fig. 3a
N
COMMON POWER OUTPUTS
P
FUSED POWER OUTPUTS
1 2 3 4 5 6 7 8
D1
INPUT
R1 LED
From Power Supply
Board
(Factory Installed)
Replace fuses with the same type and rating 3.5A, 250V.
Non Power-Limited
DC Output to devices
1P-8P Power Outputs,
1N-8N Common Outputs
( )
PD8UL
POWER DISTRIBUTING UNIT
INPUT
LED
F1 F2 F3 F4
POWER OUTPUTS
1P 1N 2P 2N 3P 3N 4P 4N
Class 2 Rated Power-Limited
DC Output to devices
1P-4P Power Outputs,
1N-4N Common Outputs
From Power Supply
Board
(Factory Installed)
( )
PD4ULCB
POWER DISTRIBUTING UNIT
Fig. 2b
Fig. 3b
N
COMMON POWER OUTPUTS
P
FUSED POWER OUTPUTS
1 2 3 4 5 6 7 8
D1
INPUT
R1 LED
From Power Supply
Board
(Factory Installed)
Class 2 Rated Power-Limited
DC Output to devices
1P-8P Power Outputs,
1N-8N Common Outputs
(
)
PD8ULCB
POWER DISTRIBUTING UNIT

- 6 - AL600ULX Series
Appendix A - UL Listed Compatible Devices
A.1 Four (4) Wire Smoke Detectors
Table A-1 below lists four (4) wire smoke detectors compatible with AL600ULX output.
System Sensor
Smoke Detector/Base Detector Type Max Stand-by Current (mA)
Alarm
Current (mA)
B112LP Base 0.12 36
B114LP Base * *
B404B Base * *
DH100ACDC Photoelectric 0.15 0.70
DH100ACDCLP Photoelectric 0.15 0.70
DH100ACDCLPW Photoelectric 0.15 0.70
DH400ACDCI IonizationDuct 25 95
DH400ACDCP Photoelectric Duct 25 95
1112/24/D Ionization 0.05 50
1424 Ionization 0.10 41
1451 (w/B402B Base) Ionization 0.10 39
2112/24ATR Photoelectric 0.50 60/70
2112/24AITR Photoelectric 0.50 60/70
2112/24/D Photoelectric 0.05 50
2112/24T/D Photoelectric w/135oThermal 0.05 50
2112/24TSRB Photoelectric w/135oThermal Supervisory Relay 15 45
2312/24TB Photoelectric 0.12 50
2412 (12 volt) Photoelectric 0.12 77
2424 Photoelectric 0.10 41
2451 Photoelectric 0.10 39
2451TH (with/B402B Base) Photoelectric 0.10 39
2W-MOD Loop Test/Maintenance Mod. 30 50
4W-B (12/24 volt) PhotoelectricI30.05 23
4WT-B (12/24 volt) PhotoelectricI3w/Therm 0.05 23
4WTA-B (12/24 volt) I3 Photo w/Therm/Sounder 0.05 35
4WTR-B (12/24 volt) I3 Photo w/Therm/Relay 0.05 35
4WITAR-B(12/24volt) I3 Photow/IsolatedTherm/Sounder/Relay 0.05 50
2W-MOD2 I3 Loop Test/Maintenance Mod. 0.05 *
RRS-MOD I3 Reversing Relay/Sync Module 0.05 *
6424 Projected Beam 10 28.4
Beam 1224(S) Projected Beam 17 38.5
* Contact manufacturer for current draws.
A.2 Relays
Table A-2 below lists relays compatible with AL600ULX output.
Manufacturer Model Current (mA) Manufacturer Model Current (mA)
System Sensor
PR-1
PR-2
PR-3
EOLR-1
R-10T
R-14T
15
30
30
30
23
23
System Sensor
R-20T
R-24T
R-10E
R-14E
R-20E
R-24E
40
40
23
23
40
40

AL600ULX Series - 7 -
Enclosure Dimensions (BC300):
AL600ULX, AL600ULPD4, AL600ULPD4CB, AL600ULPD8 and AL600ULPD8CB
13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.55mm)
1.40”
(36mm)
1.40”
(36mm)
4.85”
(123mm)
4.85”
(123mm)
1.40”
(36mm)
1.40”
(36mm)
5.10”
(130mm)
5.10”
(130mm)
13.0”
(330mm)
5.10”
(130mm)
6.5625”
(167mm)
1.20”
(31mm)
1.20”
(31mm) 1.20”
(31mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
1.0”
(25mm)
1.0”
(
25mm
)
10.5”
(
267mm
)
1.0”
(
25mm
)
1.0”
(25mm)
0.75”
(19mm)
0.75”
(19mm)
0.9375”
(24mm)
0.9375”
(24mm)
11.0”
(279mm)
12.5”
(318mm)

- 8 - AL600ULX Series
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: [phone]
web site: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
IIAL600ULXSeries A30N
Enclosure Dimensions (BC400):
AL600ULXX, AL600ULXPD4, AL600ULXPD4CB, AL600ULXPD8, AL600ULXPD8CB, AL600ULXPD16 and
AL600ULXPD16CB
15.5” x 12” x 4.5” (393.7mm x 304.8mm x 114.3mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
5.0”
(127.0mm)
5.0”
(127.0mm)
1.5”
(38.1mm)
2.0”
(50.8mm)
2.0”
(50.8mm)
1.75”
(44.45mm)
1.75”
(44.45mm)
4.5”
(114.3mm)
1.25”
(31.75mm)
4.5”
(114.3mm) 1.25”
(31.75mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
1.1”
(27.94mm)
1.1”
(27.94mm)
0.79”
(20.06mm)
1.1”
(27.94mm)
0.91”
(23.114mm)
0.91”
(23.114mm)
1.375”
(34.925mm)
1.125”
(28.575mm)
15.5”
(393.7mm)
4.615”
(117.22mm)
12.23”
(310.64mm)
4.615”
(117.22mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
4.615”
(117.22mm)
4.615”
(117.22mm)
MEMBER
