Altronix ALTV2416300UL Operating and maintenance instructions

Rev. 040506 More than just power.TM
ALTV2416UL Series
CCTV Power Supplies
Installation Guide
Models Include:
ALTV2416ULX
- 24VAC @ 7A (170VA)
or 28VAC @ 6A (1705VA).
- Sixteen (16) Fuse Protected Outputs.
ALTV2416300UL
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Sixteen (16) Fuse Protected Outputs.
ALTV2416300ULM
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Sixteen (16) Fuse Protected Outputs.
ALTV2416600UL
- 24VAC @ 25A (600VA)
or 28VAC @ 20A (560VA).
- Sixteen (16) Fuse Protected Outputs.
ALTV2416ULCBX
- 24VAC @ 7A (170VA)
or 28VAC @ 6A (1705VA).
- Sixteen (16) PTC Protected Outputs.
ALTV2416300ULCB
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Sixteen (16) PTC Protected Outputs.
ALTV2416300ULCBM
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Sixteen (16) PTC Protected Outputs.
ALTV2416600ULCB
- 24VAC @ 25A (600VA)
or 28VAC @ 20A (560VA).
- Sixteen (16) PTC Protected Outputs.

- 2 - ALTV2416UL Series
Overview:
Altronix ALTV2416UL Series CCTV Power Supplies provide 24VAC or 28VAC distributed via sixteen (16)
fuse or PTC protected outputs for powering CCTV cameras, heaters and other video accessories.
Sixteen (16) Output ALTV2416UL Reference Chart:
Altronix
Model Number
Output Voltage Total Output Current (Power) Number of Outputs PTC Protected auto- resettable Outputs (Class 2 Rated power- imited for Dry locations, Class 3 for Wet locations) Fuse Protected Class 1 Outputs Individual Output Current (max per output, not to exceed total output current) Fuse Ratings Main Fuse Ratings Primary In-line Fuse Ratings 115VAC 60Hz Input Current Agency Listings
ALTV2416ULX
24VAC 7A 16
–P3.5A 3.5A
5A/
250V
3.5A/
250V
1.8A
28VAC 6A
ALTV2416ULCBX
24VAC 7A 16
P– 2.5A –
5A/
250V
3.5A/
250V
1.8A
28VAC 6A
ALTV2416300UL
24VAC 12.5A 16
–P3.5A 3.5A
15A/
32V
– 2.7A
28VAC
10A
ALTV2416300ULCB
24VAC 12.5A 16
P– 2.5A –
15A/
32V
– 2.7A
28VAC
10A
ALTV2416300ULM
24VAC 12.5A 16
–P3.5A 3.5A – – 2.7A
28VAC
10A
ALTV2416300ULCBM
24VAC 12.5A 16
P– 2.5A – – – 2.7A
28VAC
10A
ALTV2416600UL
24VAC 25A 16
–P3.5A 3.5A
15A/
32V
– 5.4A
28VAC
20A
ALTV2416600ULCB
24VAC 25A 16
P– 2.5A –
15A/
32V
– 5.4A
28VAC
20A
Specifications:
Agency Listings:
• UL Listed for Commercial CCTV Equipment
(UL 2044).
CUL Listed - CSA Standard C22.2 No.1-98,
Audio, Video and Similar Equipment.
• CE European Conformity.
Input:
• 115VAC, 50/60Hz.
Output:
• Sixteen (16) fuse or PTC protected outputs.
• 24VAC or 28VAC output
• Outputs are rated @ 3.5A (fused) or 2.5A (PTC).
• Surge suppression.
Features:
• AC power LED indicator.
• Power ON/OFF switch
(ALTV2416ULX, ALTV2416ULXCB).
• Illuminated power disconnect circuit breaker
with manual reset (all other models).
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates
costly labor.
• Spare fuses included (on fuse protected models).
Enclosure Dimensions (H x W x D):
• ALTV2416300ULM and ALTV2416300ULCBM:
8.5” x 7.5” x 3.875” (215.9mm x 191mm x 98.4mm).
• ALTV2416ULX, ALTV2416ULCBX,
ALTV2416300UL, ALTV2416300ULCB,
ALTV2416600UL and ALTV2416600ULCB:
13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm).
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, and with
all local codes and authorities having jurisdiction. Product is intended for indoor use only.
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes
in the enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place
the enclosure’s upper keyholes over the two upper screws, level and secure. Mark the position of the lower
two holes. Remove the enclosure. Drill the lower holes and install the three fasteners. Place the enclosure’s
upper keyholes over the two upper screws. Install the two lower screws and make sure to tighten all screws
(Enclosure Dimensions, pgs. 11 - 12). Secure enclosure to earth ground.

ALTV2416UL Series - 3 -
2. Set power switch on power distribution board marked [PD] to OFF position for models
ALTV2416ULX or ALTV2416ULCBX (Figs. 1, 2, pgs. 4, 5). Set power disconnect circuit breaker
to OFF position for all other models (Figs. 3a - 8a, pgs. 6 - 10).
3. All units are factory set for 24VAC operation.
For 28VAC operation, adjust unit prior to mounting and applying power as follows:
Change the wire position so that the wire marked [28V] is connected to the terminal marked [P]
and the wire marked [24V] is connected to the terminal marked [S].
Note: ALTV2416ULCBX set for 28VAC operation is not Class 2 Rated, not power-limited.
4. Connect AC power to the black and white flying leads of the transformer(s) (Figs. 1 - 8, pgs. 4 - 10).
Use 18 AWG or larger for all power connections.
Keep power-limited (PTC protected outputs only) wiring separate from non power-limited
wiring. Minimum 0.25” spacing must be provided. Use separate knockouts.
5. Set power switch on power distribution board marked [PD] to ON position for models
ALTV2416ULX or ALTV2416ULCBX (Figs. 1, 2, pgs. 4, 5). Set power disconnect circuit breaker
to RESET (ON) position for all other models (Figs. 3a - 8a, pgs. 6 - 10).
6. Measure output voltage before connecting devices. This helps avoiding potential damage.
Terminals marked [1P - 16P] are of the same polarity.
CAUTION: Determine the maximum operating voltage of the equipment being powered
before adjusting the output voltage.
7. Set power switch on power distribution board marked [PD] to OFF position for models
ALTV2416ULX or ALTV2416ULCBX (Figs. 1, 2, pgs. 4, 5). Set power disconnect circuit breaker
to OFF position for all other models (Figs. 3a - 8a, pgs. 6 - 10).
8. Connect devices to terminals marked [1P - 1N] through [8P - 8N] on PD8 board (Figs. 1 - 4, pgs. 4-7,
Figs. 7 - 8, pgs. 9 - 10), or terminals marked [1P - 1N] through [16P - 16N] on PD16W/
PD16WCB board (Figs. 5 - 6, pg. 8), carefully observing polarity.
9. Set power switch on power distribution board marked [PD] to ON position for models
ALTV2416ULX or ALTV2416ULCBX (Figs. 1, 2, pgs. 4, 5). Set power disconnect circuit breaker
to RESET (ON) position for all other models (Figs. 3a - 8a, pgs. 6 - 10).
10. Green LED will illuminate when power is present.
11. Upon completion of the wiring, secure enclosure door with screws (supplied).
Installation of cam lock is optional.
Caution: Equipment to be installed/serviced by authorized/trained personnel only.
Shut branch circuit power before installing/servicing equipment.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture. This
installation should be made by qualified service personnel and should conform to the National Electrical
Code and all local codes. Use 75˚C or higher rated UL insulated wiring for connecting the unit to the
mains. Replace fuses with the same type and rating (refer to Sixteen (16) Output ALTV2416UL Reference
Chart, pg. 2).
Terminal Identification:
PD8/PD8CB - Distribution Module
1P - 8P AC output.
1N - 8N AC output.
PD16W/PD16WCB - Distribution Module
1P - 16P AC output.
1N - 16N AC output.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may
be of sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
CAUTION: To reduce the risk of electric shock do not open
enclosure. There are no user serviceable parts inside. Refer servicing
to qualified service personnel.

- 4 - ALTV2416UL Series
Primary
In-line Fuse
Primary
In-line Fuse
Black Lead Black Lead White Lead White Lead
Black Lead
White Lead
Input 115VAC,
50/60Hz
non power-limited
Green Lead (ground)
LED
INPUT
ON OFF
MAIN FUSE
COMMON POWER OUTPUTS FUSED POWER OUTPUTS
NPS
1234 56 78
P N
LED
INPUT
ON OFF
MAIN FUSE
COMMON POWER OUTPUTS FUSED POWER OUTPUTS
NPS
1234 56 78
P N
24VAC or 28VAC Output 1
Follow same procedure
using terminals
2P & N through 8P & N
for outputs 2 through 8)
Class 1
Outputs
Class 1
Outputs
Fig. 1 - ALTV2416ULX
NP S
NP S
24VAC
Output
28VAC
Output
28V24V
24V28V
Voltage Selection
Configuration

ALTV2416UL Series - 5 -
Primary
In-line Fuse
Primary
In-line Fuse
Black Lead Black Lead White Lead White Lead
Input 115VAC,
50/60Hz
non power-limited
Black Lead
White Lead
Green Lead (ground)
24VAC or 28VAC Output 1
Follow same procedure
using terminals
2P & N through 8P & N
for outputs 2 through 8)
LED
INPUT
ON OFF
MAIN FUSE
COMMON POWER OUTPUTS FUSED POWER OUTPUTS
NPS
1234 56 78
P N
LED
INPUT
ON OFF
MAIN FUSE
COMMON POWER OUTPUTS FUSED POWER OUTPUTS
NPS
1234 56 78
P N
24VAC
configuration
Class 2 Not Wet/
Class 3 Wet
28VAC
configuration
Class 1
24VAC
configuration
Class 2 Not Wet/
Class 3 Wet
28VAC
configuration
Class 1
Fig. 2 - ALTV2416ULCBX
NP S
NP S
24VAC
Output
28VAC
Output
28V24V
24V28V
Voltage Selection
Configuration

- 6 - ALTV2416UL Series
Illuminated Power Disconnect
Circuit Breaker with manual reset
Black Lead
White Lead
Input
115VAC,
50/60Hz
Green Lead
(ground)
non power-limited
non power-limited
LED
INPUT
MAIN FUSE
COMMON POWER OUTPUTS FUSED POWER OUTPUTS
NPS
1234 56 78
P N
LED
INPUT
MAIN FUSE
COMMON POWER OUTPUTS FUSED POWER OUTPUTS
NPS
1234 56 78
P N
Class 1 Outputs
Class 1 Outputs
24VAC or 28VAC Output 1
Follow same procedure using terminals 2P & N
through 8P & N for outputs 2 through 8)
24VAC or 28VAC Output 1
Follow same procedure using terminals 2P & N
through 8P & N for outputs 2 through 8)
Fig. 3 - ALTV2416300UL
NP S
NP S
24VAC
Output
28VAC
Output
28V24V
24V28V
Voltage Selection
Configuration
Fig. 3a

ALTV2416UL Series - 7 -
Illuminated Power Disconnect
Circuit Breaker with manual reset
Black Lead
White Lead
Input
115VAC,
50/60Hz
Green Lead
(ground)
non power-limited
non power-limited
24VAC or 28VAC Output 1
Follow same procedure using terminals 2P & N
through 8P & N for outputs 2 through 8)
24VAC or 28VAC Output 1
Follow same procedure using terminals 2P & N
through 8P & N for outputs 2 through 8)
LED
INPUT
MAIN FUSE
COMMON POWER OUTPUTS FUSED POWER OUTPUTS
NPS
1234 56 78
P N
LED
INPUT
MAIN FUSE
COMMON POWER OUTPUTS FUSED POWER OUTPUTS
NPS
1234 56 78
P N
Class 2 Not Wet / Class 3 Wet
Class 2 Not Wet / Class 3 Wet
Fig. 4 - ALTV2416300ULCB
NP S
NP S
24VAC
Output
28VAC
Output
28V24V
24V28V
Voltage Selection
Configuration
Fig. 4a

- 8 - ALTV2416UL Series
Illuminated Power Disconnect
Circuit Breaker with manual reset
Transformer
underneath
power distribution
board
N
XFMR INPUT SP
P N
312 45678
PROTECTED
OUTPUTS
OUTPUTS
COMMON
111091213
P
161514
N
3.5A 250V
Input
115VAC,
50/60Hz
Green Lead
(ground)
Illuminated Power Disconnect
Circuit Breaker with manual reset
Transformer
underneath
power distribution
board
N
XFMR INPUT SP
P N
312 45678
PROTECTED
OUTPUTS
OUTPUTS
COMMON
111091213
P
161514
N
3.5A 250V
Green Lead
(ground)
Input
115VAC,
50/60Hz
Fig. 5 - ALTV2416300ULM
Fig. 5a
Fig. 6a
Fig. 6 - ALTV2416300ULCBM

ALTV2416UL Series - 9 -
Illuminated Power Disconnect
Circuit Breaker with manual reset
Black Lead
White Lead
Input
115VAC,
50/60Hz
Green Lead
(ground)
non power-limited
non power-limited
non power-limited
24VAC or 28VAC Output 1
Follow same procedure using terminals 2P & N
through 8P & N for outputs 2 through 8)
LED
INPUT
MAIN FUSE
COMMON POWER OUTPUTS FUSED POWER OUTPUTS
NPS
1234 56 78
P N
LED
INPUT
MAIN FUSE
COMMON POWER OUTPUTS FUSED POWER OUTPUTS
NPS
1234 56 78
P N
Class 1 Outputs
Class 1 Outputs
Fig. 7 - ALTV2416600UL
Fig. 7a
NP S
NP S
24VAC
Output
28VAC
Output
28V24V
24V28V
Voltage Selection
Configuration

- 10 - ALTV2416UL Series
Illuminated Power Disconnect
Circuit Breaker with manual reset
Black Lead
White Lead
Input
115VAC,
50/60Hz
Green Lead
(ground)
non power-limited
non power-limited
non power-limited
24VAC or 28VAC Output 1
Follow same procedure using terminals 2P & N
through 8P & N for outputs 2 through 8)
LED
INPUT
MAIN FUSE
COMMON POWER OUTPUTS FUSED POWER OUTPUTS
NPS
1234 56 78
P N
LED
INPUT
MAIN FUSE
COMMON POWER OUTPUTS FUSED POWER OUTPUTS
NPS
1234 56 78
P N
Class 2 Not Wet / Class 3 Wet
Class 2 Not Wet / Class 3 Wet
Fig. 8 - ALTV2416600ULCB
Fig. 8a
NP S
NP S
24VAC
Output
28VAC
Output
28V24V
24V28V
Voltage Selection
Configuration

ALTV2416UL Series - 11 -
Enclosure Dimensions (H x W x D):
• ALTV2416300ULM • ALTV2416300ULCBM
8.5” x 7.5” x 3.875” (215.9mm x 191mm x 98.4mm)
3.63”
(92.2mm)
7.25”
(184.15mm)
7.25”
(
184.15mm
)
1”
(25.4mm)
1”
(25.4mm) 1”
(25.4mm)
1.75”
(44.45mm)
8.13”
(206.5mm)
8.13”
(206.5mm)
3.85”
(97.79mm)
1”
(25.4mm)
1”
(25.4mm)
1”
(25.4mm)
3.85”
(97.79mm)
1”
(25.4mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
3.85”
(97.79mm)
0.6”
(15.24mm)
0.6”
(15.24mm) 0.6”
(15.24mm)
0.6”
(15.24mm)
0.9”
(22.86mm)
0.9”
(22.86mm)

- 12 - ALTV2416UL Series
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: [phone] | fax: [phone]
website: www.altronix.com | e-mail: [email protected] | Lifetime Warranty | Made in U.S.A.
IIALTV2416UL Series D04R MEMBER
Enclosure Dimensions (H x W x D) for:
• ALTV2416ULX • ALTV2416ULCBX
• ALTV2416300UL • ALTV2416300ULCB
• ALTV2416600UL • ALTV2416600ULCB
13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm)
1.40”
(36mm)
1.40”
(36mm)
4.85”
(123mm)
4.85”
(123mm)
1.40”
(36mm)
1.40”
(36mm)
5.10”
(130mm)
5.10”
(130mm)
13.0”
(330mm)
5.10”
(130mm)
6.5625”
(167mm)
1.20”
(31mm)
1.20”
(31mm) 1.20”
(31mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
1.0”
(25mm)
1.0”
(
25mm
)
10.5”
(
267mm
)
1.0”
(
25mm
)
1.0”
(25mm)
0.75”
(19mm)
0.75”
(19mm)
0.9375”
(24mm)
0.9375”
(24mm)
11.0”
(279mm)
12.5”
(318mm)
