Altronix VertiLine3DV Series User manual

VertiLine3DV
- 12VDC @ 8A
- Eight (8) PTC protected outputs
VertiLine6DV
- 24VDC @ 8A
- Eight (8) PTC protected outputs
VertiLine3DV Series
Rack Mount Power Supplies
Models Include:
Rev. 090111 More than just power.TM
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
Installation Guide

- 2 - VertiLine3DV / VertiLine6DV Installation Guide
Overview:
Altronix VertiLine Rack Mount Power Supplies provide eight (8) filtered and electronically regulated power outputs
in a space saving 1U EIA 19” rack mount chassis. The units are available with either 12VDC or 24VDC power
outputs. VertiLine Rack Mount Power Supplies are also available in sixteen (16) outputs.
Specifications:
Agency Listing:
• CE European Conformity.
Input:
• 220VAC (working range 190VAC - 256VAC),
50/60Hz.
Output:
VertiLine3DV:
• Eight (8) PTC protected 12VDC outputs rated @ 8A
total current max. (1.0A per device, 2.5A max.).
VertiLine6DV:
• Eight (8) PTC protected 24VDC outputs rated @ 8A
total current max. (1.0A per device, 2.5A max.).
• Filtered and electronically regulated outputs.
Features:
• Eight (8) power LED indicators.
• Illuminated master power disconnect
circuit breaker with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
• Removable terminal blocks with locking
screw flange.
Mechanical:
• Units can be rack, wall or shelf mounted.
• Modular 1U standard EIA 19” rack mount chassis.
• Enclosure Dimensions (H x W x D approx.):
1.625” x 19.125” x 8.5”
(41.3mm x 486mm x 216mm).
Eight (8) Output Rack Mount Configuration Reference Chart:
Altronix
Model Number
Output
Voltage
Total
Output
Current
(Power)
Number of
Outputs
Output
Protection
Current (max.
per output)
220VAC
50/60Hz
Input Current
VertiLine3DV 12VDC 8A 8 PTC 2.5A 0.75A
VertiLine6DV 24VDC 8A 8 PTC 2.5A 1.75A
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or
moisture. This installation should be made by qualified service personnel and should
conform to the National Electrical Code and all local codes.

VertiLine3DV / VertiLine6DV Installation Guide - 3 -
Installation Instructions:
1. Attach mounting brackets to VertiLine unit for desired rack or wall mount installation (Figs. 4-5, pg. 7).
Affix rubber pads to VertiLine for shelf installation (Fig. 6, pg. 7).
2. Secure the unit into rack, mount unit to wall or place unit on a shelf as desired (unit should be spaced at
least 3” from any video monitors). When installing the unit in a rack, allow for one half U spacing above
the unit for ventilation.
3. Insert and secure removable terminal blocks to unit (Fig. 1e, pg. 4).
4. Plug the grounded AC line cord (included) into the IEC 320 connector of the VertiLine unit (Fig. 1d, pg. 4).
Insert the plug end of the line cord into a grounded AC receptacle.
5. Set illuminated master power disconnect circuit breaker to the (ON) position (Fig. 1c, pg. 4).
6. Measure output voltage before connecting devices. This helps avoiding potential damage.
7. Set illuminated master power disconnect circuit breaker to the (OFF) position (Fig. 1c, pg. 4).
8. Connect the power output of terminals marked [+ 1 –] to the power input of device (Fig. 1b, pg. 4).
Repeat this step for each additional device (Outputs 2-8).
9. Upon completion of wiring, set illuminated master power disconnect circuit breaker to the ON (RESET)
position (Fig. 1c, pg. 4).
10. The power LEDs on the faceplate for Outputs 1-8 will illuminate when AC power is present (Fig. 1a, pg. 4).
Note: If any of the power LEDs are not illuminated the cause may be due to the following:
a. AC mains fail.
b. Illuminated master power disconnect circuit breaker is OFF or tripped.
c. One (1) or more power output PTCs are tripped due to a short circuit or overload condition.
To reset the PTC:
1. Set illuminated master power disconnect circuit breaker to the (OFF) position (Fig. 1c, pg. 4).
2. Eliminate the trouble condition (short circuit or overload).
3. Allow 1 minute for PTC to cool off (reset).
4. Set illuminated master power disconnect circuit breaker to the (ON) position (Fig. 1c, pg. 4).
5. All power LEDs will illuminate indicating power has been restored to all outputs (Fig. 1a, pg. 4).

- 4 - VertiLine3DV / VertiLine6DV Installation Guide
1a LED(s) 1-8: Power LED indicators. 1b Power Outputs: 12VDC or 24VDC. 1c Illuminated master power disconnect circuit breaker (switch): • OFF position Circuit breaker tripped Switch not illuminated. • RESET (ON) position Switch illuminated. 1d IEC 320 Connector: 220VAC (working range 190VAC - 256VAC), 50/60Hz. (grounded line cord included). 1e Removable Terminal Block.
Fig. 1
VertiLine3DV and VertiLine6DV (front) VertiLine3DV and VertiLine6DV (rear)
1a 1b 1c
1d 1e
Removable Terminal Block

VertiLine3DV / VertiLine6DV Installation Guide - 5 -
Fig. 2 Typical Application Drawing:
12VDC (VertiLine3DV)
or 24VDC (VertiLine6DV)
Power Outputs to Devices

- 6 - VertiLine3DV / VertiLine6DV Installation Guide
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may be of
sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying
the appliance.
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside.
Refer servicing to qualified service personnel.
Fig. 3
Power switch with built-in circuit breaker:
OFF position - Switch not illuminated. Outputs not powered.
RESET (ON) position - Switch illuminated. Outputs powered.
Circuit breaker tripped - Switch not illuminated.
Power LEDs on faceplate are not illuminated. Outputs not powered.
To reset circuit breaker set power switch to the ON (RESET) position (Fig. 3, pg. 6).
(ON)
1.625" (41.3mm)
REAR
FRONT
TOP & BOTTOM
8.5" (216mm)
0.75" (19.05mm)
19.125" (486mm)
17.625" (447.7mm)
1U EIA 19” Rack Mount Chassis
Mechanical Drawing and Dimensions (H x W x D):
1.625” x 19.125” x 8.5” (41.3mm x 486mm x 216mm)

VertiLine3DV / VertiLine6DV Installation Guide - 7 -
Mounting Options:
Rack Mount Installation
1. Remove factory installed screws from both sides of the rack chassis (Fig. 4a).
2. Install mounting brackets (A) on the left and right side of rack chassis using the
two (2) flat head screws (B) (included) (Fig. 4b).
3. Place unit into desired EIA 19” rack position and secure with mounting screws (not included) (Fig. 4c).
Fig. 4
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Wall Mount Installation
1. Install mounting brackets (A) on the left and right side of rack chassis using
two (2) flat head screws (B) (included) (Fig. 5a).
2. Place unit at desired location and secure with mounting screws (not included) (Fig. 5b).
Caution: It is necessary to make sure mounting screws are securely fastened to a beam when installing.
Fig. 5
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Shelf Installation
1. Position and affix rubber pads (C) (included) at
each corner on the bottom of the unit (Fig. 6).
2. Place unit in desired location.
Fig. 6
A
B
Fig. 4a
Fig. 5a Fig. 5b
Fig. 4b Fig. 4c
Top Top Top
Front
Left
Front
Left Front Left
Remove
A
B
B
A
C
Mounting Hardware (Included):
C
Left Side
Rubber Pad
Two (2) mounting brackets
Six (6) flat head screws
for mounting brackets.
Four (4) rubber pads.

- 8 - VertiLine3DV / VertiLine6DV Installation Guide
Notes:
Altronix is not responsible for any typographical errors.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
