Altronix ALTV615DC48CBM220 Operating and maintenance instructions

Rev. 032306 More than just power.TM
ALTV615DC220 Series
CCTV Power Supplies
Installation Guide
Models Include:
ALTV615DC44M220 ALTV615DC44CBM220
- 6-15VDC @ 4A - 6-15VDC @ 4A
- Four (4) Fuse Protected Outputs. - Four (4) PTC Protected Outputs.
ALTV615DC48M220 ALTV615DC48CBM220
- 6-15VDC @ 4A - 6-15VDC @ 4A
- Eight (8) Fuse Protected Outputs. - Eight (8) PTC Protected Outputs.
ALTV615DC416220 ALTV615DC416CB220
- 6-15VDC @ 4A - 6-15VDC @ 4A
- Sixteen (16) Fuse Protected Outputs. - Sixteen (16) PTC Protected Outputs.
ALTV615DC616220 ALTV615DC616CB220
- 6-15VDC @ 6A - 6-15VDC @ 6A
- Sixteen (16) Fuse Protected Outputs. - Sixteen (16) PTC Protected Outputs.
ALTV615DC1016220 ALTV615DC1016CB220
- 6-15VDC @ 10A - 6-15VDC @ 10A
- Sixteen (16) Fuse Protected Outputs. - Sixteen (16) PTC Protected Outputs.

- 2 - ALTV615DC220 Series
Overview:
Altronix ALTV615DC220 Series DC CCTV Power Supplies provide 6-15VDC distributed via fuse or PTC
protected outputs for powering CCTV cameras, heaters, and other video accessories.
ALTV615DC220 Reference Chart:
Altronix
Model Number
Output
Voltage
Total
Output
Current
(Power)
Number
of
Outputs
PTC Protected
Outputs
(auto-resettable)
Fuse
Protected
Outputs
Output
Current
(max per
output)
220VAC
50/60Hz
Input
Current
ALTV615DC44M220 6-15VDC 4A 4 – P3.5A 0.5A
ALTV615DC44CBM220 6-15VDC 4A 4 P– 2.5A 0.5A
ALTV615DC48M220 6-15VDC 4A 8 – P3.5A 0.5A
ALTV615DC48CBM220 6-15VDC 4A 8 P– 2.5A 0.5A
ALTV615DC416220 6-15VDC 4A 16 – P3.5A 0.5A
ALTV615DC416CB220 6-15VDC 4A 16 P– 2.5A 0.5A
ALTV615DC616220 6-15VDC 6A 16 – P3.5A 1A
ALTV615DC616CB220 6-15VDC 6A 16 P– 2.5A 1A
ALTV615DC1016220 6-15VDC 10A 16 – P3.5A 1A
ALTV615DC1016CB220 6-15VDC 10A 16 P– 2.5A 1A
Specifications:
Installation Instructions:
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes
in the enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place
the enclosure’s upper keyholes over the two upper screws, level and secure. Mark the position of the lower
two holes. Remove the enclosure. Drill the lower holes and install the three fasteners. Place the enclosure’s
upper keyholes over the two upper screws. Install the two lower screws and make sure to tighten all screws
(Enclosure Dimensions, pg. 7, 8).
2. Remove Power Distribution Module and isolation barrier (models with “M” suffix only).
3. Connect unswitched AC circuit (220VAC, 50/60Hz) as follows: Green branch wire (ground) connects to the
terminal marked , Line connects to the terminal marked [L], and Neutral connects to the terminal marked
[N] of the Inlet Appliance Connector. (Figs. 1-3, pgs. 4-6). Use 18 AWG or larger for all power connections.
Units with line cord installed skip Instruction #3.
Use 18 AWG or larger for all power connections.
Connect green ground lead to earth ground (Fig. 1-3, pgs. 4-6).
Keep power-limited wiring separate from non power-limited wiring.
Minimum 0.25” spacing must be provided. Use separate knockouts.
4. Adjust output voltage (unit is factory set at 12VDC): use the trimpot on the power supply board
prior to connecting CCTV devices (Figs. 1a, pg. 4; Fig, 2a, pg. 5; Fig. 3a, pg. 6).
5. Measure output voltage before connecting devices. This helps avoiding potential damage.
CAUTION: Determine the maximum operating voltage of the equipment being powered before
adjusting the output voltage.
Agnecy Listing:
• CE European Conformity.
Input:
• 220VAC (working range 198VAC-256VAC),
50/60Hz.
Output:
• Four (4), eight (8), or sixteen (16) individual outputs.
• 6VDC to 15VDC field adjustable.
• Outputs are rated @ 3.5A (fused) or 2.5A (PTC).
• Filtered and electronically regulated outputs.
Features:
• AC input and DC output LED indicators.
• Power ON/OFF switch.
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates
costly labor.
Enclosure Dimensions (H x W x D approx.):
ALTV615DC44M220, ALTV615DC44CBM220,
ALTV615DC48M220, ALTV615DC48CBM220:
8.5” x 7.5” x 3.875” (215.9mm x 191mm x 98.4mm)
All other models:
13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm)
POWER
SUPPLY
BOARD
Trimpot
TRIMPOT
Transformer
Input
220VAC, 50/60Hz, 0.5A
BARRIER
1P 1N 2P 2N 3P 3N 4P 4N
POWER DISTRIBUTING UNIT
PD4A
MAIN FUSE
Output Wiring
PTC
used on
ALTV615DC44CBM220

ALTV615DC220 Series - 3 -
6. Reinstall isolation barrier and Power Distribution Module (models with “M” suffix only).
7. Connect devices to terminals marked [1P - 1N] through [4P - 4N] on PD4/PD4CB board,
[1P - 1N] through [8P - 8N] on PD8/PD8CB, [1P - 1N] through [16P - 16N] on PD16W/PD16WCB/PD16CB
board, carefully observing correct polarity (Figs. 1-3, pgs. 4-6).
Terminals marked [1P - 16P] are positive (+) and terminals marked [1N - 16N] are negative (–).
8. Green LED will illuminate when unit is powered.
9. Upon completion of the wiring, secure enclosure door with screws (supplied).
Caution: Equipment to be installed / serviced by authorized / trained personnel only.
Shut branch circuit power before installing / servicing equipment.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to the National
Electrical Code and all local codes.
Terminal Identification:
Power Supply Board
Terminal Legend Function/Description
AC/AC Low voltage AC input.
+ DC – 6VDC-15VDC output.
PD4/PD4CB - Distribution Module
1P - 4P Positive DC outputs.
1N - 4N Negative DC outputs.
PD8/PD8CB - Distribution Module
1P - 8P Positive DC outputs.
1N - 8N Negative DC outputs.
PD16W/PD16WCB/PD16CB - Distribution Module
1P - 16P Positive DC outputs.
1N - 16N Negative DC outputs.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may
be of sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying
the appliance.
CAUTION: To reduce the risk of electric shock do not open
enclosure. There are no user serviceable parts inside.
Refer servicing to qualified service personnel.

- 4 - ALTV615DC220 Series
POWER
SUPPLY
BOARD
Trimpot
TRIMPOT
Transformer
Input
220VAC, 50/60Hz, 0.5A
BARRIER
1P 1N 2P 2N 3P 3N 4P 4N
POWER DISTRIBUTING UNIT
PD4A
MAIN FUSE
Output Wiring
PTC
used on
ALTV615DC44CBM220
Fig. 1 - ALTV615DC44M220 and ALTV615DC44CBM220
Fig. 1a
CAUTION: De-energize unit prior to servicing.
For continued protection against fire hazard replace fuse with the same type and rating.
Do not expose unit to rain or moisture.

ALTV615DC220 Series - 5 -
POWER
SUPPLY
BOARD
Trimpot
TRIMPOT
Transformer
Input
220VAC, 50/60Hz, 0.5A
BARRIER
Output Wiring
INPUT
MAIN FUSE
FUSED POWER OUTPUTS
COMMON POWER OUTPUTS
N
PPD8
ON OFF
1 2 3 4 5 6 7 8
N P S
PTC
used on
ALTV615DC48CBM220
Fig. 2 - ALTV615DC48M220 and ALTV615DC48CBM220
Fig. 2a
CAUTION: De-energize unit prior to servicing.
For continued protection against fire hazard replace fuse with the same type and rating.
Do not expose unit to rain or moisture.

- 6 - ALTV615DC220 Series
Fig. 3 - ALTV615DC416220 • ALTV615DC416CB220 • ALTV615DC616220 • ALTV615DC61CB220
ALTV615DC1016220 • ALTV615DC1016CB220
PTC
used on
models with CB suffix.
Example:
ALTV615DC416CB220
N
PD16W
XFMR INPUT SP
P N
312 45678
PROTECTED
OUTPUTS
OUTPUTS
COMMON
111091213
P
161514
N
3.5A 250V
DC OUTPUTS
Illuminated
Power Switch
POWER SUPPLY
BOARD
AC
DC
+ DC - AC AC
TRIMPOT
Input
220VAC, 50/60Hz
CAUTION: De-energize unit prior to servicing.
For continued protection against fire hazard replace fuse with the same type and rating.
Do not expose unit to rain or moisture.
Fig. 3a

ALTV615DC220 Series - 7 -
Enclosure Dimensions for:
• ALTV615DC44M220 • ALTV615DC44CBM220 • ALTV615DC48M220 • ALTV615DC48CBM220
8.5” x 7.5” x 3.875” (215.9mm x 191mm x 98.4mm)
3.63”
(92.2mm)
7.25”
(184.15mm)
7.25”
(
184.15mm
)
1”
(25.4mm)
1”
(25.4mm) 1”
(25.4mm)
1.75”
(44.45mm)
8.13”
(206.5mm)
8.13”
(206.5mm)
3.85”
(97.79mm)
1”
(25.4mm)
1”
(25.4mm)
1”
(25.4mm)
3.85”
(97.79mm)
1”
(25.4mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
3.85”
(97.79mm)
0.6”
(15.24mm)
0.6”
(15.24mm) 0.6”
(15.24mm)
0.6”
(15.24mm)
0.9”
(22.86mm)
0.9”
(22.86mm)

- 8 - ALTV615DC220 Series
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: [phone] | fax: [phone]
website: www.altronix.com | e-mail: [email protected] | Lifetime Warranty | Made in U.S.A.
IIALTV615DC220 Series E15R MEMBER
1.40”
(36mm)
1.40”
(36mm)
4.85”
(123mm)
4.85”
(123mm)
1.40”
(36mm)
1.40”
(36mm)
5.10”
(130mm)
5.10”
(130mm)
13.0”
(330mm)
5.10”
(130mm)
6.5625”
(167mm)
1.20”
(31mm)
1.20”
(31mm) 1.20”
(31mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
1.0”
(25mm)
1.0”
(
25mm
)
10.5”
(
267mm
)
1.0”
(
25mm
)
1.0”
(25mm)
0.75”
(19mm)
0.75”
(19mm)
0.9375”
(24mm)
0.9375”
(24mm)
11.0”
(279mm)
12.5”
(318mm)
Enclosure Dimensions for:
• ALTV615DC416220 • ALTV615DC416CB220 • ALTV615DC616220
• ALTV615DC616CB220 • ALTV615DC1016220 • ALTV615DC1016CB220
13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm)
