Altronix SMP5E Service manual

SMP5E
Power Supply/Charger Kit
Overview:
SMP5E High Current Power Supply/Charger converts a low voltage AC input to a low voltage DC output. This general
purpose power supply has a wide range of applications for access control, security, and CCTV system accessories that
require additional power.
Specifications:
Voltage Output/Transformer Selection Table:
Output Voltage Switch Position Transformer Requirements
(Recommended Altronix Part #’s)
SW1 SW2
6VDC ON OFF 16VAC / 40VA (TP1640)
12VDC OFF OFF 24VAC or 28VAC / 100VA (T2428100), or 16VAC / 100 VA (T16100)
24VDC OFF ON 28VAC / 175VA (T2428175)
Note: Transformers with higher power (VA) ratings may be used for all output voltages selected above
provided the input voltage does not exceed 28VAC or 45VDC.
Installation Instructions:
The SMP5E should be installed in accordance with The National Electrical Code and all applicable Local Regulations.
1. Mount the SMP5 board in enclosure (as shown on reverse).
2. Set DC output voltage with switches (refer to Voltage Output/Transformer Selection Table).
3. Connect proper transformer to terminals marked [AC] (see Voltage Output/Transformer Selection Table).
Use 18 AWG or larger for all power connections (Battery, DC output).
Keep power limited wiring separate from non-power limited wiring (115VAC / 60Hz Input, Battery Wires).
Minimum 0.25” spacing must be provided.
4. Measure output voltage before connecting devices. This helps avoid potential damage.
5. Connect devices to be powered to terminals marked [+ DC –].
6. When the use of stand-by batteries are desired, they must be lead acid or gel type.
Connect battery to terminals marked [+ BAT –] (battery leads included).
Use two (2) 12VDC batteries connected in series for 24VDC operation.
Note: When batteries are not used, a loss of AC will result in the loss of output voltage.
Input:
• 16VAC to 28VAC
(Voltage Output/Transformer Selection Table).
Output:
• 6VDC, 12VDC or 24VDC selectable output.
• 4A continuous supply current*.
• Thermal overload and short circuit protection.
• Filtered and electronically regulated output.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Maximum charge current 300mA.
• Automatic switch over to stand-by battery.
• Battery short circuit protection (PTC).
Additional Features:
• AC input and DC output LED indicators.
• Extremely compact design.
• Includes battery leads, nylon fastener and enclosure.
Board Dimensions (W x L x H approximate):
3” x 3.5” x 2” (76.2mm x 88.9mm x 50.8mm).
Enclosure Dimensions (H x W x D approximate):
8.5” x 7.5” x 3.5” (215.9mm x 190.5mm x 88.9mm).
• Fits one (1) 12VDC/7AH or two (2) 12VDC/4AH batteries.

LED Diagnostics:
Red (DC) Green (AC) Power Supply Status
ON ON Normal operating conditions
ON OFF Loss of AC. Stand-by battery supplying power.
OFF ON No DC output. Short circuit or thermal overload condition.
OFF OFF No DC output. Loss of AC. Discharged or no battery present.
Terminal Identification:
Terminal Legend Function/Description
AC/AC
Low voltage AC input (see voltage output/transformer selection table).
For 6VDC output use 16VAC or higher with 40VA power rating or higher.
For 12VDC output use 16VAC or higher with 85VA power rating or higher.
For 24VDC output use 28VAC with 175VA power rating or higher.
Caution: Do not apply voltage above 28 VAC or 45VDC (maximum input rating).
+ DC – 6VDC,12VDC or 24VDC @ 4A continuous output
+ BAT – Stand-by battery connections. Maximum charge rate 300mA.
STEP 1: Use these holes to mount SMP5 by
pushing the nylon circuit board fasteners
(Fig. 1) through the back of the
enclosure. Nylon fasteners will snap into place.
(Fig. 1)
Nylon Fastener
STEP 2: Mount SMP5 circuit board to nylon fasteners
by pressing down circuit board onto nylon fasteners.
Note: Springlock on fasteners is used to remove
SMP5 circuit board.
Note: Four (4) fasteners are provided in the SMP5 carton.
Springlock
Enclosure Dimensions(H x W x D approximate):
8.5” x 7.5” x 3.5” (215.9mm x 190.5mm x 88.9mm)
+ DC -- + BAT -- AC AC AC
DC
MADE IN U.S.A.
SW1
6 V12 V24 V
SW1 ON OFF OFF
SW2 OFF OFF ON
SW2
1 2
ON
