Altronix SMP7 User manual

Voltage Output/Transformer Selection Table:
Output VDC Switch Position Max. Load DC Transformer Requirements
(Recommended Altronix Part #’s)
12VDC SW1 ON 6A 24VAC or 28VAC / 175VA (T2428175)
24VDC SW1 OFF 6A 24VAC or 28VAC / 175VA (T2428175)
Installation Instructions:
SMP7 should be installed in accordance with The National Electrical Code and all applicable Local Regulations.
1. Mount SMP7 in the desired location/enclosure (mounting hardware included).
2. Set SMP7 to the desired DC output voltage by setting the SW1 switch (Fig. 1a, pg. 2) to the appropriate
position (Voltage Output/Transformer Selection Table).
Adjust output voltage by using the trimpot on the power supply board (Fig. 1a, pg. 2) prior to connecting devices.
3. Connect proper transformer to terminals marked [AC] (Voltage Output/Transformer Selection Table).
Use 18 AWG or larger for all power connections (Battery, DC output).
Keep power-limited wiring separate from non power-limited wiring
(115VAC / 60Hz Input, Battery Wires). Minimum 0.25” spacing must be provided.
CAUTION: Do not touch exposed metal parts. Shut branch circuit power before installing or
servicing equipment. There are no user serviceable parts inside.
Refer installation and servicing to qualified service personnel.
4. Measure output voltage before connecting devices. This helps avoiding potential damage.
5. Connect devices to be powered to terminals marked [– DC +].
6. When the use of stand-by batteries is desired, they must be lead acid or gel type. Connect battery to the
terminals marked [– BAT +] on the board (battery leads included). Use two (2) 12VDC batteries connected in
series for 24VDC operation.
Note: When batteries are not used, a loss of AC will result in the loss of output voltage.
SMP7
Power Supply/Charger
Installation Guide
Overview:
Altronix SMP7 power supply/charger converts converts a low voltage AC input into 12VDC or 24VDC output with a
6A continuous supply current.
Specifications:
Input:
• Input 28VAC
(Voltage Output/Transformer Selection Table).
Output:
• 12VDC or 24VDC selectable output.
• 6A supply current.
• Output fuse is rated 15A/32V.
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries.
• Maximum charge current 0.7A.
• Zero voltage drop when switching over
to battery backup.
Indicators:
• AC input and DC output LED indicators.
Board Dimensions (W x L x H approximate):
7” x 4.25” x 1.25”
(177.8mm x 107.9mm x 31.75mm).

LED Diagnostics:
Red (DC) Green (AC) Power Supply Status
ON ON Normal operating condition.
ON OFF Loss of AC. Stand-by battery is supplying power.
OFF ON No DC output.
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
Terminal Identification:
Terminal Legend Function/Description
AC/AC Low voltage AC input (24VAC or 28VAC / 175VA).
– DC + 12VDC / 24VDC @ 6A continuous output.
– BAT + Stand-by battery connections. Maximum charge rate 0.7A.
--- DC + --- BAT +
AC AC
15
AC DC
OFF 24VDC
ON 12VDC
ON
Fig. 1
Fig. 1a
--- DC + --- BAT +
AC AC
15
AC DC
OFF 24VDC
ON 12VDC
ON
Altronix is not responsible for any typographical errors.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
140 58th Street, Brooklyn, New York 11220 USA | phone: [phone] | fax: [phone]
website: www.altronix.com | e-mail: [email protected] | Lifetime Warranty
IISMP7 - Rev. 110606 H17U MEMBER
