Alva MONDO User manual

Manufactur .alva.co.za
2 BURNER ALVA
MONDO

BBQ ASSEMBLY
1

Finally
2

3

4
PARTS LIST BBQ
ITEM
1
2
3
4
5
6
NAME
LID
HANDEL
BBQ
DRIP TRAY
COOKING GRILLS
SHELVING

PARTS LIST TABLE/ BASE
5

PARTS LIST TABLE/ BASE
ITEM
1
2
3
4
5
6
NAME
TABLE
CONDIMENT TRAY
FRONT COVER
CYLINDER HOOK
LEFT REAR LEG
LEFT FRONT LEG
7
8
9
10
11
12
RIGHT REAR LEG (WITH AXEL HOLE)
RIGHT FRONT LEG (WITH AXEL HOLE)
BASE
BOLT
WHEEL
NUT
G SPLIT CLIP
6

ASSEMBLY INSTRUCTIONS
7

M6 X 50mm bolt (M)
and Nut (N) x4
Spanner (R) x1
Allen Key (Q) x1
STEP 1
8
Turn the TABLE (1) upside down onto a stable flat surface.
Insert the four LEGS (5),(6),(7) and (8) as shown so that the legs all lean
outwards.
The RIGHT SIDE LEGS (7) and (8) with the axle holes need to both be on the
same side as indicated
Secure each leg with one M6 x 50mm BOLT (M) and one M6 NUT (N).
DO NOT fully tighten yet.

STEP 2
M6 X 15mm bolt (ML)
x4
9
Fit the BOTTOM BASE (9) using four M6 x 15mm BOLTS (L).
Once all bolts are in place, fully tighten using a Phillips Head screwdriver.
Now tighten the bolts and nuts from the previous step as well.

Thread the AXLE (I) WHEEL (H
Then through a SPACER (O)
SPACER (O WHEEL (H)
SPLIT PIN (P) HUBCAPS (G) to the
Spacer (O) x2
Split Pin (P) x1
STEP 3
10
Thread the BOLT (10) through the wheel (11) and spacer (E) and leg of the
table and secure in place with split pin (G)
SPLIT PIN

M6 x 20mm BOLT
(S) x4
Allen Key (Q) x1
STEP 4
11
M6 x
15mm BOLT (S)
ALLEN KEY (Q).

CONDIMENT TRAY (J)
Screw the CYLINDER HOOK (K)
M6 x 20mm BOLT
(S) x4
Allen Key (Q) x1
STEP 5
12
CONDIMENT
TRAY (J)
into table

STEP 6
13
LEG LOCKING

STEP 7
14
