Amana APG14 M Series User manual
SS-APG14M www.amana-hac.com 11/14
Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P., Houston, Texas.
Cooling CapaCity: 23,000 – 57,500 BtU/h
heating CapaCity: 40,000 – 120,000 BtU/h
apg14M
paCkaged gas/eleCtriC
14 seer / 81% aFUe
®
Standard Features
• Heavy-duty Million-Air® stainless-
steel heat exchanger
• Energy-efcient compressor
• Aluminum tube/aluminum n coil
• Flowrater expansion device on 2- to 4-ton units;
TXV expansion device on 5-ton units
• X-13 type recirculating blower motor
• Fully charged R-410A system
• Redundant gas valve with easy
conversion to propane
Cabinet Features
• High-quality UV-resistant powder-paint nish
• Horizontal or downow application
• Convenient access panels
• One roof curb ts all units
• Fully insulated cabinet
• Bottom, 2” high base rails for easier handling
• When properly anchored, meets 2010 Florida Build-
ing Code unit integrity requirements for hurricane-
type winds (Anchor bracket kits available.)
• Power-assisted combustion
• Direct spark ignition system includes a microprocessor-based control for the entire ignition
sequence, all blower operation, and all safety circuits complete with self-diagnostics
• All models comply with California Low NOx standards
• AHRI Certied; ETL Listed
Contents
Nomenclature ....................................... 2
Product Specications .......................... 3
Expanded Cooling Data ........................ 7
Airow Data ........................................ 19
Dimensions ......................................... 24
Wiring Diagrams ................................ 25
Accessories .......................................... 28
* Complete warranty details available from your local dealer or at
www.amana-hac.com. To receive the Lifetime Heat Exchanger
Limited Warranty (good for as long as you own your home) plus
the 10-Year Parts Limited Warranty, online registration must be
completed within 60 days of installation. Online registration is
not required in California or Québec.
Product SPecificationS
2 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 3
noMenClatUre
Brand Electrical
A Amana®Brand 1 208230/1/60
3 208230/3/60
ProductCategory
P PackagedUnit Refrigerant
4R410A
UnitType
G Gas/Electric HeatInput
40 40MBTU/h
Efficiency 60 60MBTU/h
14 14SEER 15 15SEER 80 80MBTU/h
16 16SEER 100 100MBTU/h
120 120MBTU/h
NominalCapacity
24 2Tons 363Tons 484Tons
30 2½tons 423½Tons 605Tons
4
11
1
12
14
4,5
36
6,7
040
8,9,10
A
1
P
2
G
3
Product SPecificationS
2 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 3
SpecificationS —apG1424-30
APG1424
040M41AA
APG1424
060M41AA
APG1430
040M41AA
APG1430
060M41AA
Cooling Capacity
Total BTU/h 23,000 23,000 28,500 28,500
Sensible BTU/h 18,400 18,400 22,800 22,800
SEER / EER 14.0 / 11.0 14.0 / 11.0 14.0 / 11.0 14.0 / 11.0
Decibels 78 78 78 78
AHRI Reference #s 7505450 7505450 7505451 7505451
Heating Capacity
Input BTU/h 40,000 60,000 40,000 60,000
Output BTU/h 31,000 48,000 31,000 48,000
AFUE 81 81 81 81
Temperature Rise Range 25 - 55 30 - 60 25 - 55 30 - 60
No. of Burners 2323
Orice Size (Natural/Propane) 45 / 1.25MM 45 / 1.25MM 45 / 1.25MM 45 / 1.25MM
Evaporator Motor
Type EEM EEM EEM EEM
Wheel (D x W) 10” x 8” 10” x 8” 10” x 8” 10” x 8”
Indoor Nominal CFM 800 800 1,000 1,000
Motor Speed Tap (Cooling) T4 T4 T4 T4
RPM/Amps (Cooling) 1050/3.9 1050/3.9 1050/3.9 1050/3.9
Horsepower 1/2 1/2 1/2 1/2
Evaporator Coil
Face Area (²) 4.3 4.3 4.3 4.3
Rows Deep/Fins per Inch 3/14 3/14 3/14 3/14
Piston Size (Cooling) 0.057 0.057 0.062 0.062
Filter Size (²) 2.7 3.3 3.4 3.4
Drain Size (NPT) ¾” ¾” ¾” ¾”
Refrigerant Charge (oz.) 75 75 78 78
Condenser Fan / Coil
Horsepower - RPM 1/6 - 815 1/6 - 815 1/4 - 1,075 1/4 - 1,075
Diameter / # of Blades 22” / 3 22” / 3 22” / 3 22” / 3
Outdoor Nominal CFM 2,150 2,150 3,050 3,050
Face Area (²) 12.3 12.3 12.3 12.3
Rows Deep/Fins per Inch 1/24 1/24 1/24 1/24
Compressor
Quanty / Type 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll
Stage Single Single Single Single
Compressor RLA/LRA 13.5 / 58.3 13.5 / 58.3 14.1 / 73 14.1 / 73
Electrical Data
Voltage-Phase (60 Hz) 208/230-1 208/230-1 208/230-1 208/230-1
Indoor Blower FLA 3.9 3.9 3.9 3.9
Outdoor Fan FLA/LRA 1.1 / 1.7 1.1 / 1.7 1.4 / 2.9 1.4 / 2.9
Total Unit Amps 18.5 18.5 19.4 19.4
Min. Circuit Ampacity 21.9 21.9 22.9 22.9
Max. Overcurrent Protecon 35 amps 35 amps 35 amps 35 amps
Entrance Size Power Supply 1⅛” 1⅛” 1⅛” 1⅛”
Entrance Size Control Voltage ⅞” ⅞” ⅞” ⅞”
Operang / Ship Weights (lbs) 412 / 435 417 / 439 415 / 438 420 / 442
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² Must use me-delay fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
Product SPecificationS
4 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 5
SpecificationS —apG1436-42
APG1436
040M41AA
APG1436
060M41AA
APG1436
080M41AA
APG1442
060M41AA
APG1442
080M41AA
Cooling Capacity
Total BTU/h 34,200 34,200 34,200 40,000 40,000
Sensible BTU/h 27,600 27,600 27,600 30,000 30,000
SEER / EER 14.0 / 11.0 14.0 / 11.0 14.0 / 11.0 14.0 / 11.0 14.0 / 11.0
Decibels 78 78 78 78 78
AHRI Reference #s 7505452 7505452 7505452 7505453 7505453
Heating Capacity
Input BTU/h 40,000 60,000 80,000 60,000 80,000
Output BTU/h 31,000 48,000 64,000 48,000 64,000
AFUE 81 81 81 81 81
Temperature Rise Range 25 - 55 30 - 60 30 - 60 30 - 60 30 - 60
No. of Burners 2 3 4 3 4
Orice Size (Natural/Propane) 45 / 1.25MM 45 / 1.25MM 45 / 1.25MM 45 / 1.25MM 45 / 1.25MM
Evaporator Motor
Type EEM EEM EEM EEM EEM
Wheel (D x W) 10” x 9” 10” x 9” 10” x 9” 10” x 9” 10” x 9”
Indoor Nominal CFM 1,200 1,200 1,200 1,300 1,300
Motor Speed Tap (Cooling) T4 T4 T4 T4 T4
RPM/Amps (Cooling) 1050/3.9 1050/3.9 1050/3.9 1050/5.7 1050/5.7
Horsepower 1/2 1/2 1/2 3/4 3/4
Evaporator Coil
Face Area (²) 4.3 4.3 4.3 4.3 4.3
Rows Deep/Fins per Inch 4/14 4/14 4/14 4/14 4/14
Piston Size (Cooling) 0.068 0.068 0.068 0.072 0.072
Filter Size (²) 4.0 4.0 4.4 4.3 4.4
Drain Size (NPT) ¾” ¾” ¾” ¾” ¾”
Refrigerant Charge (oz.) 62 62 62 88 88
Condenser Fan / Coil
Horsepower - RPM 1/4 - 830 1/4 - 830 1/4 - 830 1/4 - 1,075 1/4 - 1,075
Diameter / # of Blades 22” / 3 22” / 3 22” / 3 22” / 3 22” / 3
Outdoor Nominal CFM 2,250 2,250 2,250 2,850 2,850
Face Area (²) 8.8 8.8 8.8 11.1 11.1
Rows Deep/Fins per Inch 2/27 2/27 2/27 2/27 2/27
Compressor
Quanty / Type 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll
Stage Single Single Single Single Single
Compressor RLA/LRA 14.1/77.0 14.1/77.0 14.1/77.0 17.9 / 112 17.9 / 112
Electrical Data
Voltage-Phase (60 Hz) 208/230-1 208/230-1 208/230-1 208/230-1 208/230-1
Indoor Blower FLA/LRA 3.9 3.9 3.9 5.7 5.7
Outdoor Fan FLA/LRA 1.5 / 3.0 1.5 / 3.0 1.5 / 3.0 1.4/ 2.9 1.4/ 2.9
Total Unit Amps 19.5 19.5 19.5 22.3 22.3
Min. Circuit Ampacity 23 23 23 26.8 26.8
Max. Overcurrent Protecon 35 amps 35 amps 35 amps 40 amps 40 amps
Entrance Size Power Supply 1⅛” 1⅛” 1⅛” 1⅛” 1⅛”
Entrance Size Control Voltage ⅞” ⅞” ⅞” ⅞” ⅞”
Operating / Ship Weights (lbs) 449 / 470 453 / 475 458 / 480 493 / 515 496 / 520
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² Must use me-delay fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
Product SPecificationS
4 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 5
SpecificationS —apG1448-60
APG1448
060M41AA
APG1448
080M41AA
APG1448
100M41AA
APG1460
080M41AA
APG1460
100M41AA
APG1460
120M41AA
Cooling Capacity
Total BTU/h 46,500 46,500 46,500 57,500 57,500 57,500
Sensible BTU/h 36,700 36,700 36,700 44,000 44,000 44,000
SEER / EER 14.0 / 11.0 14.0 / 11.0 14.0 / 11.0 14.2 / 10.1 14.2 / 10.1 14.2 / 10.1
Decibels 80 80 80 78 78 78
AHRI Reference #s 7505454 7505454 7505454 7505455 7505455 7505455
Heating Capacity
Input BTU/h 60,000 80,000 100,000 80,000 100,000 120,000
Output BTU/h 48,000 64,000 80,000 63,000 78,000 94,000
AFUE 81 81 81 81 81 81
Temperature Rise Range 30 - 60 30 - 60 35 - 65 30 - 60 35 - 65 35 - 65
No. of Burners 3 4 5 4 5 6
Orice Size (Natural/Propane) 44 / 1.25MM 44 / 1.25MM 44 / 1.25MM 44 / 1.25MM 44 / 1.25MM 44 / 1.25MM
Evaporator Motor
Type EEM EEM EEM EEM EEM EEM
Wheel (D x W) 11” x 10” 11” x 10” 11” x 10” 11” x 10” 11” x 10” 11” x 10”
Indoor Nominal CFM 1,525 1,525 1,525 1300 L/1810 H 1300 L/1810 H 1300 L/1810 H
Motor Speed Tap (Cooling) T4 T4 T4 T3 L / T4 H T3 L / T4 H T3 L / T4 H
RPM/Amps (Cooling) 1,050/5.7 1,050/5.7 1,050/5.7 1,050/7.0 1,050/7.0 1,050/7.0
Horsepower 3/4 3/4 3/4 1 1 1
Evaporator Coil
Face Area (²) 5.7 5.7 5.7 5.7 5.7 5.7
Rows Deep/Fins per Inch 4/14 4/14 4/14 4/14 4/14 4/14
Piston Size (Cooling) 0.078 0.078 0.078 TXV TXV TXV
Filter Size (²) 5.1 5.1 5.1 6.0 6.0 6.0
Drain Size (NPT) ¾” ¾” ¾” ¾” ¾” ¾”
Refrigerant Charge (oz.) 99 99 99 100 100 100
Condenser Fan / Coil
Horsepower - RPM 1/4 - 1,075 1/4 - 1,075 1/4 - 1,075 1/4 - 1,075 1/4 - 1,075 1/4 - 1,075
Diameter / # of Blades 22” / 3 22” / 3 22” / 3 22” / 3 22” / 3 22” / 3
Outdoor Nominal CFM 3,300 3,300 3,300 3,000 3,000 3,000
Face Area (²) 15.4 15.4 15.4 11.3 11.3 11.3
Rows Deep/Fins per Inch 1/24 1/24 1/24 2/27 2/27 2/27
Compressor
Quanty / Type 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll
Stage Single Single Single Two Two Two
Compressor RLA/LRA 19.9/109 19.9/109 19.9/109 27.1 / 152.9 27.1 / 152.9 27.1 / 152.9
Electrical Data
Voltage-Phase (60 Hz) 208/230-1 208/230-1 208/230-1 208/230-1 208/230-1 208/230-1
Indoor Blower FLA 5.7 5.7 5.7 7.0 7.0 7.0
Outdoor Fan FLA/LRA 1.4/ 2.9 1.4/ 2.9 1.4/ 2.9 1.4/ 2.9 1.4/ 2.9 1.4/ 2.9
Total Unit Amps 27.0 27.0 27.0 35.5 35.5 35.5
Min. Circuit Ampacity 32 32 32 42.3 42.3 42.3
Max. Overcurrent Protecon 50 amps 50 amps 50 amps 60 amps 60 amps 60 amps
Entrance Size Power Supply 1⅛” 1⅛” 1⅛” 1⅛” 1⅛” 1⅛”
Entrance Size Control Voltage ⅞” ⅞” ⅞” ⅞” ⅞” ⅞”
Operating / Ship Weights (lbs) 518 / 540 523 / 545 528 / 550 533 / 555 538 / 560 543 / 565
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² Must use me-delay fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
Product SPecificationS
6 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 7
expanded coolinG data — apG1424***M41**
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
889
MBh 22.7 23.5 25.8 - 22.2 23.0 25.2 - 21.7 22.4 24.6 - 21.1 21.9 24.0 - 20.1 20.8 22.8 - 18.6 19.3 21.1 -
S/T 0.81 0.68 0.47 - 0.84 0.70 0.48 - 0.86 0.72 0.50 - 0.89 0.74 0.51 - 0.92 0.77 0.53 - 0.93 0.77 0.54 -
∆T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -
kW 1.44 1.47 1.51 - 1.55 1.58 1.64 - 1.65 1.69 1.74 - 1.74 1.78 1.84 - 1.81 1.86 1.92 - 1.88 1.92 1.99 -
Amps 6.6 6.8 6.9 - 7.1 7.2 7.4 - 7.6 7.7 8.0 - 8.0 8.2 8.4 - 8.5 8.7 8.9 - 8.9 9.1 9.4 -
HI PR 236 254 269 - 265 286 302 - 302 325 343 - 344 370 391 - 387 416 439 - 427 460 485 -
LO PR 113 120 131 - 119 127 138 - 124 132 144 - 130 138 151 - 136 145 158 - 141 150 164 -
792
MBh 22.0 22.8 25.0 - 21.5 22.3 24.5 - 21.0 21.8 23.9 - 20.5 21.3 23.3 - 19.5 20.2 22.1 - 18.0 18.7 20.5 -
S/T 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.88 0.73 0.51 - 0.88 0.74 0.51 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 16 12 -
kW 1.42 1.46 1.50 - 1.54 1.57 1.62 - 1.64 1.67 1.73 - 1.72 1.76 1.82 - 1.80 1.84 1.90 - 1.86 1.91 1.97 -
Amps 6.6 6.7 6.9 - 7.0 7.2 7.4 - 7.5 7.7 7.9 - 8.0 8.1 8.4 - 8.4 8.6 8.8 - 8.8 9.0 9.3 -
HI PR 234 252 266 - 263 283 299 - 299 322 340 - 340 366 387 - 383 412 435 - 423 455 481 -
LO PR 111 119 129 - 118 125 137 - 122 130 142 - 129 137 149 - 135 143 157 - 139 148 162 -
694
MBh 20.3 21.1 23.1 - 19.9 20.6 22.6 - 19.4 20.1 22.0 - 18.9 19.6 21.5 - 18.0 18.6 20.4 - 16.7 17.3 18.9 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
∆T 20 17 13 - 20 18 13 - 20 18 13 - 20 18 13 - 20 17 13 - 19 16 12 -
kW 1.39 1.42 1.47 - 1.50 1.53 1.58 - 1.60 1.63 1.69 - 1.68 1.72 1.78 - 1.75 1.79 1.85 - 1.82 1.86 1.92 -
Amps 6.4 6.6 6.7 - 6.9 7.0 7.2 - 7.4 7.5 7.7 - 7.8 7.9 8.2 - 8.2 8.4 8.6 - 8.6 8.8 9.1 -
HI PR 227 244 258 - 255 274 290 - 290 312 329 - 330 355 375 - 371 400 422 - 410 442 466 -
LO PR 108 115 126 - 114 122 133 - 119 126 138 - 125 133 145 - 131 139 152 - 135 144 157 -
75
889
MBh 23.1 23.8 25.7 27.6 22.6 23.2 25.1 27.0 22.0 22.7 24.5 26.3 21.5 22.1 23.9 25.7 20.4 21.0 22.7 24.4 18.9 19.5 21.1 22.6
S/T 0.92 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.98 0.87 0.66 0.43 1.00 0.90 0.68 0.44 1.00 0.94 0.71 0.46 1.00 0.94 0.71 0.46
∆T 22 20 17 11 22 20 17 12 22 20 17 12 22 21 17 12 21 20 17 12 20 19 16 11
kW 1.45 1.48 1.53 1.58 1.56 1.60 1.65 1.71 1.66 1.70 1.76 1.82 1.75 1.79 1.85 1.92 1.83 1.87 1.94 2.00 1.90 1.94 2.01 2.08
Amps 6.7 6.8 7.0 7.2 7.1 7.3 7.5 7.7 7.7 7.8 8.0 8.3 8.1 8.3 8.5 8.8 8.5 8.7 9.0 9.3 9.0 9.2 9.5 9.8
HI PR 239 257 271 283 268 288 305 318 305 328 346 361 347 374 395 412 391 420 444 463 432 464 490 512
LO PR 114 121 132 141 120 128 140 149 125 133 145 154 131 140 152 162 138 146 160 170 142 151 165 176
792
MBh 22.4 23.1 25.0 26.8 21.9 22.5 24.4 26.2 21.4 22.0 23.8 25.6 20.9 21.5 23.2 24.9 19.8 20.4 22.1 23.7 18.4 18.9 20.5 22.0
S/T 0.88 0.78 0.59 0.38 0.91 0.81 0.61 0.40 0.93 0.83 0.63 0.41 0.96 0.86 0.65 0.42 1.00 0.89 0.68 0.43 1.00 0.90 0.68 0.44
∆T 23 21 17 12 23 21 17 12 23 21 17 12 23 21 18 12 23 21 17 12 21 20 16 11
kW 1.44 1.47 1.52 1.57 1.55 1.58 1.64 1.69 1.65 1.69 1.74 1.80 1.74 1.78 1.84 1.90 1.82 1.86 1.92 1.99 1.88 1.92 1.99 2.06
Amps 6.6 6.8 6.9 7.2 7.1 7.2 7.4 7.7 7.6 7.7 8.0 8.2 8.0 8.2 8.4 8.7 8.5 8.7 8.9 9.2 8.9 9.1 9.4 9.7
HI PR 237 255 269 280 265 286 302 315 302 325 343 358 344 370 391 407 387 416 439 458 427 460 486 506
LO PR 113 120 131 139 119 127 138 147 124 132 144 153 130 138 151 161 136 145 158 168 141 150 164 174
694
MBh 20.7 21.3 23.1 24.8 20.2 20.8 22.5 24.2 19.7 20.3 22.0 23.6 19.2 19.8 21.5 23.0 18.3 18.8 20.4 21.9 16.9 17.4 18.9 20.3
S/T 0.84 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42
∆T 23 21 17 12 23 22 18 12 23 22 18 12 24 22 18 12 23 21 18 12 22 20 16 11
kW 1.40 1.43 1.48 1.53 1.51 1.54 1.60 1.65 1.61 1.65 1.70 1.76 1.70 1.73 1.79 1.85 1.77 1.81 1.87 1.93 1.83 1.87 1.94 2.00
Amps 6.5 6.6 6.8 7.0 6.9 7.1 7.3 7.5 7.4 7.6 7.8 8.0 7.8 8.0 8.2 8.5 8.3 8.5 8.7 9.0 8.7 8.9 9.1 9.5
HI PR 229 247 261 272 257 277 293 305 293 315 333 347 333 359 379 395 375 404 426 445 414 446 471 491
LO PR 109 116 127 135 115 123 134 143 120 128 139 148 126 134 146 156 132 140 153 163 137 145 159 169
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
6 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 7
expanded coolinG data — apG1424***M41** (cont.)
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
889
MBh 23.5 24.0 25.7 27.4 23.0 23.5 25.1 26.8 22.4 22.9 24.5 26.2 21.9 22.3 23.9 25.5 20.8 21.2 22.7 24.2 19.2 19.7 21.0 22.5
S/T 1.00 0.95 0.77 0.57 1.00 1.00 0.80 0.60 1.00 1.00 0.82 0.61 1.00 1.00 0.84 0.63 1.00 1.00 0.88 0.65 1.00 1.00 0.88 0.66
∆T 24 23 20 16 24 24 21 17 23 24 21 17 23 23 21 17 21 22 21 16 20 20 19 15
kW 1.46 1.49 1.54 1.59 1.58 1.61 1.66 1.72 1.68 1.72 1.77 1.83 1.77 1.81 1.87 1.94 1.85 1.89 1.95 2.02 1.91 1.96 2.02 2.09
Amps 6.7 6.9 7.1 7.3 7.2 7.3 7.5 7.8 7.7 7.9 8.1 8.4 8.2 8.3 8.6 8.9 8.6 8.8 9.1 9.4 9.1 9.3 9.5 9.9
HI PR 241 260 274 286 271 291 308 321 308 331 350 365 351 377 399 416 395 425 448 468 436 469 495 517
LO PR 115 122 133 142 121 129 141 150 126 134 147 156 133 141 154 164 139 148 161 172 144 153 167 178
792
MBh 22.8 23.3 24.9 26.6 22.3 22.8 24.3 26.0 21.8 22.2 23.8 25.4 21.2 21.7 23.2 24.8 20.2 20.6 22.0 23.5 18.7 19.1 20.4 21.8
S/T 0.96 0.90 0.73 0.55 1.00 0.93 0.76 0.57 1.00 0.96 0.78 0.58 1.00 0.99 0.80 0.60 1.00 1.00 0.84 0.62 1.00 1.00 0.84 0.63
∆T 25 24 21 17 26 25 21 17 25 25 22 17 25 25 22 17 23 24 21 17 22 22 20 16
kW 1.45 1.48 1.53 1.58 1.56 1.60 1.65 1.71 1.66 1.70 1.76 1.82 1.75 1.79 1.86 1.92 1.83 1.87 1.94 2.00 1.90 1.94 2.01 2.08
Amps 6.7 6.8 7.0 7.2 7.1 7.3 7.5 7.7 7.7 7.8 8.0 8.3 8.1 8.3 8.5 8.8 8.5 8.7 9.0 9.3 9.0 9.2 9.5 9.8
HI PR 239 257 271 283 268 288 305 318 305 328 346 361 347 374 395 412 391 420 444 463 432 464 490 512
LO PR 114 121 132 141 120 128 140 149 125 133 145 155 131 140 152 162 138 146 160 170 142 151 165 176
694
MBh 21.1 21.5 23.0 24.6 20.6 21.0 22.5 24.0 20.1 20.5 21.9 23.4 19.6 20.0 21.4 22.9 18.6 19.0 20.3 21.7 17.2 17.6 18.8 20.1
S/T 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.98 0.92 0.75 0.56 1.02 0.95 0.78 0.58 1.05 0.99 0.81 0.60 1.06 1.00 0.81 0.61
∆T 26 25 22 17 26 25 22 17 26 25 22 17 26 25 22 18 26 25 22 17 24 23 20 16
kW 1.41 1.44 1.49 1.54 1.52 1.56 1.61 1.66 1.62 1.66 1.71 1.77 1.71 1.75 1.81 1.87 1.78 1.82 1.89 1.95 1.85 1.89 1.95 2.02
Amps 6.5 6.7 6.8 7.1 7.0 7.1 7.3 7.5 7.5 7.6 7.8 8.1 7.9 8.1 8.3 8.6 8.3 8.5 8.8 9.1 8.8 9.0 9.2 9.5
HI PR 232 249 263 275 260 280 295 308 296 318 336 351 337 362 383 399 379 408 431 449 419 451 476 496
LO PR 110 117 128 136 117 124 135 144 121 129 141 150 127 135 148 157 133 142 155 165 138 147 160 171
85
889
MBh 23.9 24.4 25.5 27.2 23.4 23.8 24.9 26.6 22.8 23.2 24.3 26.0 22.2 22.7 23.7 25.3 21.1 21.5 22.6 24.1 19.6 20.0 20.9 22.3
S/T 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.98 0.79 1.00 1.00 1.00 0.82 1.00 1.00 1.00 0.85 1.00 1.00 1.00 0.86
∆T 25 25 24 21 24 25 25 21 24 24 25 21 23 23 25 21 22 22 23 21 20 21 22 20
kW 1.47 1.50 1.55 1.61 1.59 1.62 1.68 1.74 1.69 1.73 1.79 1.85 1.78 1.83 1.89 1.95 1.86 1.91 1.97 2.04 1.93 1.97 2.04 2.11
Amps 6.8 6.9 7.1 7.3 7.2 7.4 7.6 7.8 7.8 7.9 8.2 8.4 8.2 8.4 8.6 8.9 8.7 8.9 9.1 9.4 9.1 9.3 9.6 9.9
HI PR 244 262 277 289 273 294 311 324 311 335 353 369 354 381 403 420 399 429 453 472 440 474 500 522
LO PR 116 123 135 144 123 130 142 152 127 136 148 158 134 142 155 166 140 149 163 174 145 154 169 179
792
MBh 23.2 23.7 24.8 26.4 22.7 23.1 24.2 25.8 22.1 22.6 23.6 25.2 21.6 22.0 23.1 24.6 20.5 20.9 21.9 23.4 19.0 19.4 20.3 21.6
S/T 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.93 0.76 1.00 1.00 0.96 0.78 1.00 1.00 1.00 0.81 1.00 1.00 1.00 0.82
∆T 27 27 25 22 26 27 26 22 26 26 26 22 25 26 26 22 24 24 25 22 22 23 24 21
kW 1.46 1.49 1.54 1.59 1.58 1.61 1.66 1.72 1.68 1.72 1.77 1.83 1.77 1.81 1.87 1.94 1.85 1.89 1.95 2.02 1.91 1.96 2.02 2.09
Amps 6.7 6.9 7.1 7.3 7.2 7.3 7.5 7.8 7.7 7.9 8.1 8.4 8.2 8.3 8.6 8.9 8.6 8.8 9.1 9.4 9.1 9.3 9.5 9.9
HI PR 241 260 274 286 271 291 308 321 308 331 350 365 351 377 399 416 395 425 448 468 436 469 495 517
LO PR 115 122 133 142 121 129 141 150 126 134 147 156 133 141 154 164 139 148 161 172 144 153 167 178
694
MBh 21.4 21.8 22.9 24.4 20.9 21.3 22.3 23.8 20.4 20.8 21.8 23.3 19.9 20.3 21.3 22.7 18.9 19.3 20.2 21.6 17.5 17.9 18.7 20.0
S/T 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.97 0.79
∆T 28 27 26 22 28 27 26 22 27 27 26 22 26 27 26 23 25 26 26 22 23 24 24 21
kW 1.42 1.45 1.50 1.55 1.54 1.57 1.62 1.68 1.64 1.67 1.73 1.79 1.72 1.76 1.82 1.89 1.80 1.84 1.90 1.97 1.86 1.91 1.97 2.04
Amps 6.6 6.7 6.9 7.1 7.0 7.2 7.4 7.6 7.5 7.7 7.9 8.2 8.0 8.1 8.4 8.6 8.4 8.6 8.8 9.1 8.8 9.0 9.3 9.6
HI PR 234 252 266 277 263 283 298 311 299 321 339 354 340 366 387 403 383 412 435 454 423 455 481 501
LO PR 111 119 129 138 118 125 137 146 122 130 142 151 129 137 149 159 135 143 156 167 139 148 162 172
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
8 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 9
expanded coolinG data — apG1430***M41**
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1164
MBh 29.7 30.8 33.7 - 29.0 30.1 32.9 - 28.3 29.4 32.2 - 27.6 28.6 31.4 - 26.3 27.2 29.8 - 24.3 25.2 27.6 -
S/T 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.85 0.71 0.49 - 0.88 0.73 0.51 - 0.91 0.76 0.53 - 0.92 0.77 0.53 -
∆T 19 16 12 - 19 16 12 - 19 16 13 - 19 17 13 - 19 16 12 - 18 15 12 -
kW 1.98 2.03 2.09 - 2.13 2.18 2.25 - 2.26 2.31 2.39 - 2.38 2.43 2.51 - 2.48 2.53 2.61 - 2.56 2.62 2.71 -
Amps 8.2 8.4 8.6 - 8.8 9.0 9.2 - 9.5 9.7 9.9 - 10.0 10.2 10.6 - 10.6 10.8 11.2 - 11.2 11.4 11.8 -
HI PR 245 263 278 - 275 295 312 - 312 336 355 - 356 383 404 - 400 431 455 - 442 476 502 -
LO PR 111 118 129 - 117 124 136 - 122 129 141 - 128 136 148 - 134 142 155 - 138 147 161 -
1037
MBh 28.8 29.9 32.8 - 28.2 29.2 32.0 - 27.5 28.5 31.2 - 26.8 27.8 30.5 - 25.5 26.4 28.9 - 23.6 24.5 26.8 -
S/T 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.84 0.70 0.48 - 0.87 0.73 0.50 - 0.88 0.73 0.51 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
kW 1.97 2.01 2.07 - 2.12 2.16 2.23 - 2.25 2.29 2.37 - 2.36 2.41 2.49 - 2.46 2.51 2.59 - 2.54 2.60 2.68 -
Amps 8.2 8.3 8.6 - 8.7 8.9 9.2 - 9.4 9.6 9.9 - 9.9 10.2 10.5 - 10.5 10.7 11.1 - 11.1 11.3 11.7 -
HI PR 242 261 275 - 272 293 309 - 309 333 351 - 352 379 400 - 396 426 450 - 438 471 497 -
LO PR 110 117 127 - 116 123 135 - 120 128 140 - 126 135 147 - 133 141 154 - 137 146 159 -
910
MBh 26.6 27.6 30.2 - 26.0 26.9 29.5 - 25.4 26.3 28.8 - 24.8 25.7 28.1 - 23.5 24.4 26.7 - 21.8 22.6 24.7 -
S/T 0.74 0.61 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.84 0.70 0.48 - 0.85 0.71 0.49 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 16 12 -
kW 1.92 1.96 2.02 - 2.07 2.11 2.17 - 2.19 2.24 2.31 - 2.30 2.35 2.43 - 2.40 2.45 2.53 - 2.48 2.53 2.62 -
Amps 8.0 8.1 8.4 - 8.5 8.7 8.9 - 9.2 9.3 9.6 - 9.7 9.9 10.2 - 10.3 10.5 10.8 - 10.8 11.0 11.4 -
HI PR 235 253 267 - 264 284 300 - 300 323 341 - 342 368 388 - 384 414 437 - 425 457 482 -
LO PR 106 113 124 - 112 120 130 - 117 124 136 - 123 130 142 - 129 137 149 - 133 141 154 -
75
1164
MBh 30.2 31.1 33.7 36.1 29.5 30.4 32.9 35.3 28.8 29.7 32.1 34.5 28.1 28.9 31.3 33.6 26.7 27.5 29.8 31.9 24.7 25.5 27.6 29.6
S/T 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.97 0.87 0.65 0.42 1.00 0.89 0.68 0.43 1.00 0.93 0.70 0.45 1.00 0.93 0.71 0.46
∆T 22 20 16 11 22 20 17 11 22 20 17 11 22 20 17 12 21 20 16 11 20 19 15 11
kW 2.00 2.04 2.10 2.17 2.15 2.20 2.26 2.34 2.28 2.33 2.41 2.48 2.40 2.45 2.53 2.61 2.50 2.55 2.64 2.72 2.58 2.64 2.73 2.82
Amps 8.3 8.5 8.7 9.0 8.9 9.0 9.3 9.6 9.5 9.7 10.0 10.4 10.1 10.3 10.6 11.0 10.7 10.9 11.3 11.6 11.3 11.5 11.9 12.3
HI PR 247 266 281 293 277 298 315 329 315 339 358 374 359 387 408 426 404 435 459 479 447 481 507 529
LO PR 112 119 130 138 118 126 137 146 123 131 143 152 129 137 150 160 135 144 157 167 140 149 162 173
1037
MBh 29.3 30.2 32.7 35.1 28.6 29.5 31.9 34.3 28.0 28.8 31.2 33.4 27.3 28.1 30.4 32.6 25.9 26.7 28.9 31.0 24.0 24.7 26.8 28.7
S/T 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.92 0.83 0.62 0.40 0.95 0.85 0.64 0.41 0.99 0.88 0.67 0.43 1.00 0.89 0.67 0.43
∆T 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 21 20 16 11
kW 1.98 2.03 2.09 2.15 2.13 2.18 2.25 2.32 2.26 2.31 2.39 2.46 2.38 2.43 2.51 2.59 2.48 2.53 2.62 2.70 2.56 2.62 2.71 2.80
Amps 8.2 8.4 8.6 8.9 8.8 9.0 9.2 9.5 9.5 9.7 9.9 10.3 10.0 10.2 10.6 10.9 10.6 10.8 11.2 11.5 11.2 11.4 11.8 12.2
HI PR 245 263 278 290 275 296 312 325 312 336 355 370 356 383 404 422 400 431 455 474 442 476 502 524
LO PR 111 118 129 137 117 124 136 145 122 129 141 150 128 136 148 158 134 142 155 166 138 147 161 171
910
MBh 27.1 27.9 30.2 32.4 26.4 27.2 29.5 31.6 25.8 26.6 28.8 30.9 25.2 25.9 28.1 30.1 23.9 24.6 26.7 28.6 22.2 22.8 24.7 26.5
S/T 0.84 0.75 0.57 0.36 0.87 0.78 0.59 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.65 0.41 0.96 0.86 0.65 0.42
∆T 23 21 17 12 23 21 17 12 23 21 18 12 23 22 18 12 23 21 17 12 22 20 16 11
kW 1.94 1.98 2.04 2.10 2.08 2.13 2.19 2.26 2.21 2.26 2.33 2.40 2.32 2.37 2.45 2.53 2.42 2.47 2.55 2.63 2.50 2.56 2.64 2.73
Amps 8.0 8.2 8.4 8.7 8.6 8.8 9.0 9.3 9.2 9.4 9.7 10.0 9.8 10.0 10.3 10.6 10.3 10.6 10.9 11.3 10.9 11.1 11.5 11.9
HI PR 237 255 270 281 266 287 303 316 303 326 344 359 345 371 392 409 388 418 441 460 429 462 487 508
LO PR 107 114 125 133 113 121 132 140 118 125 137 146 124 132 144 153 130 138 151 161 134 143 156 166
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
8 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 9
expanded coolinG data — apG1430***M41** (cont.)
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1164
MBh 30.7 31.4 33.6 35.9 30.0 30.7 32.8 35.0 29.3 30.0 32.0 34.2 28.6 29.2 31.2 33.4 27.2 27.8 29.7 31.7 25.2 25.7 27.5 29.4
S/T 1.00 0.94 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.81 0.61 1.00 1.00 0.84 0.62 1.00 1.00 0.87 0.65 1.00 1.00 0.87 0.65
∆T 24 23 20 16 24 24 20 16 23 24 20 16 23 23 21 16 21 22 20 16 20 20 19 15
kW 2.02 2.06 2.12 2.19 2.17 2.21 2.28 2.36 2.30 2.35 2.43 2.50 2.42 2.47 2.55 2.64 2.52 2.58 2.66 2.75 2.61 2.66 2.75 2.84
Amps 8.3 8.5 8.8 9.0 8.9 9.1 9.4 9.7 9.6 9.8 10.1 10.4 10.2 10.4 10.7 11.1 10.8 11.0 11.4 11.7 11.4 11.6 12.0 12.4
HI PR 250 269 284 296 280 301 318 332 319 343 362 378 363 391 412 430 408 439 464 484 451 485 513 535
LO PR 113 120 131 140 119 127 139 148 124 132 144 153 130 139 151 161 137 145 159 169 141 150 164 175
1037
MBh 29.9 30.5 32.6 34.8 29.2 29.8 31.8 34.0 28.5 29.1 31.1 33.2 27.8 28.4 30.3 32.4 26.4 27.0 28.8 30.8 24.4 25.0 26.7 28.5
S/T 0.95 0.89 0.73 0.54 0.99 0.93 0.75 0.56 1.00 0.95 0.77 0.58 1.00 0.98 0.80 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.83 0.62
∆T 25 24 21 17 26 24 21 17 25 24 21 17 25 25 21 17 23 24 21 17 22 22 20 16
kW 2.00 2.04 2.10 2.17 2.15 2.20 2.26 2.34 2.28 2.33 2.41 2.48 2.40 2.45 2.53 2.61 2.50 2.55 2.64 2.72 2.59 2.64 2.73 2.82
Amps 8.3 8.5 8.7 9.0 8.9 9.0 9.3 9.6 9.5 9.7 10.0 10.4 10.1 10.3 10.6 11.0 10.7 10.9 11.3 11.6 11.3 11.5 11.9 12.3
HI PR 247 266 281 293 277 299 315 329 315 339 358 374 359 387 408 426 404 435 459 479 447 481 508 529
LO PR 112 119 130 138 118 126 137 146 123 131 143 152 129 137 150 160 135 144 157 167 140 149 162 173
910
MBh 27.6 28.2 30.1 32.2 26.9 27.5 29.4 31.4 26.3 26.8 28.7 30.7 25.6 26.2 28.0 29.9 24.3 24.9 26.6 28.4 22.6 23.0 24.6 26.3
S/T 0.92 0.86 0.70 0.52 0.95 0.89 0.73 0.54 0.98 0.91 0.74 0.56 1.01 0.94 0.77 0.57 1.05 0.98 0.80 0.60 1.05 0.99 0.80 0.60
∆T 26 24 21 17 26 25 22 17 26 25 22 17 26 25 22 17 26 25 21 17 24 23 20 16
kW 1.95 1.99 2.05 2.12 2.10 2.14 2.21 2.28 2.23 2.28 2.35 2.42 2.34 2.39 2.47 2.55 2.44 2.49 2.57 2.66 2.52 2.58 2.66 2.75
Amps 8.1 8.3 8.5 8.8 8.7 8.8 9.1 9.4 9.3 9.5 9.8 10.1 9.9 10.1 10.4 10.7 10.4 10.7 11.0 11.3 11.0 11.2 11.6 12.0
HI PR 240 258 272 284 269 290 306 319 306 329 348 363 349 375 396 413 392 422 446 465 433 466 492 513
LO PR 109 115 126 134 115 122 133 142 119 127 138 147 125 133 145 155 131 140 152 162 136 144 158 168
85
1164
MBh 31.3 31.9 33.4 35.6 30.6 31.1 32.6 34.8 29.8 30.4 31.8 34.0 29.1 29.7 31.1 33.1 27.6 28.2 29.5 31.5 25.6 26.1 27.3 29.2
S/T 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.77 1.00 1.00 0.97 0.79 1.00 1.00 1.00 0.81 1.00 1.00 1.00 0.84 1.00 1.00 1.00 0.85
∆T 25 25 24 21 24 25 24 21 24 24 24 21 23 23 25 21 22 22 23 21 20 21 22 20
kW 2.03 2.07 2.14 2.21 2.18 2.23 2.30 2.38 2.32 2.37 2.45 2.53 2.44 2.49 2.57 2.66 2.54 2.60 2.68 2.77 2.63 2.69 2.77 2.87
Amps 8.4 8.6 8.8 9.1 9.0 9.2 9.5 9.8 9.7 9.9 10.2 10.5 10.3 10.5 10.8 11.2 10.9 11.1 11.4 11.8 11.5 11.7 12.1 12.5
HI PR 252 271 287 299 283 305 322 335 322 346 366 381 367 394 417 434 412 444 469 489 456 490 518 540
LO PR 114 121 133 141 121 128 140 149 125 133 146 155 132 140 153 163 138 147 160 171 143 152 166 176
1037
MBh 30.4 31.0 32.4 34.6 29.7 30.2 31.7 33.8 29.0 29.5 30.9 33.0 28.3 28.8 30.2 32.2 26.8 27.4 28.7 30.6 24.9 25.3 26.5 28.3
S/T 1.00 0.96 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.99 0.80 1.00 1.00 1.00 0.81
∆T 27 26 25 22 26 27 25 22 26 26 25 22 25 26 25 22 24 24 25 22 22 22 23 20
kW 2.02 2.06 2.12 2.19 2.17 2.21 2.28 2.36 2.30 2.35 2.43 2.50 2.42 2.47 2.55 2.64 2.52 2.58 2.66 2.75 2.61 2.66 2.75 2.84
Amps 8.3 8.5 8.8 9.0 8.9 9.1 9.4 9.7 9.6 9.8 10.1 10.4 10.2 10.4 10.7 11.1 10.8 11.0 11.4 11.7 11.4 11.6 12.0 12.4
HI PR 250 269 284 296 280 301 318 332 319 343 362 378 363 391 412 430 408 439 464 484 451 485 513 535
LO PR 113 120 131 140 119 127 139 148 124 132 144 153 130 139 151 161 137 145 159 169 141 150 164 175
910
MBh 28.0 28.6 29.9 31.9 27.4 27.9 29.2 31.2 26.7 27.2 28.5 30.4 26.1 26.6 27.8 29.7 24.8 25.3 26.4 28.2 22.9 23.4 24.5 26.1
S/T 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.96 0.78
∆T 27 27 25 22 28 27 26 22 27 27 26 22 26 27 26 22 25 26 26 22 23 24 24 21
kW 1.97 2.01 2.07 2.14 2.12 2.16 2.23 2.30 2.25 2.29 2.37 2.44 2.36 2.41 2.49 2.57 2.46 2.51 2.59 2.68 2.54 2.60 2.68 2.77
Amps 8.2 8.3 8.6 8.8 8.7 8.9 9.2 9.5 9.4 9.6 9.9 10.2 9.9 10.2 10.5 10.8 10.5 10.7 11.1 11.4 11.1 11.3 11.7 12.1
HI PR 242 261 275 287 272 292 309 322 309 333 351 366 352 379 400 417 396 426 450 469 438 471 497 519
LO PR 110 117 127 136 116 123 134 143 120 128 140 149 126 134 147 156 132 141 154 164 137 146 159 169
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
10 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 11
expanded coolinG data — apG1436***M41**
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1329
MBh 34.8 36.1 39.5 - 34.0 35.2 38.6 - 33.2 34.4 37.7 - 32.4 33.6 36.8 - 30.8 31.9 34.9 - 28.5 29.5 32.4 -
S/T 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.84 0.70 0.49 - 0.87 0.73 0.50 - 0.90 0.75 0.52 - 0.91 0.76 0.53 -
∆T 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 16 12 -
kW 2.39 2.44 2.51 - 2.57 2.63 2.71 - 2.73 2.79 2.88 - 2.87 2.94 3.03 - 2.99 3.06 3.16 - 3.10 3.17 3.27 -
Amps 10.0 10.2 10.5 - 10.7 10.9 11.2 - 11.5 11.7 12.1 - 12.2 12.5 12.8 - 12.9 13.2 13.6 - 13.6 13.9 14.3 -
HI PR 249 268 283 - 280 301 318 - 318 342 361 - 362 390 412 - 407 438 463 - 450 484 512 -
LO PR 111 119 129 - 118 125 137 - 122 130 142 - 129 137 149 - 135 143 157 - 139 148 162 -
1184
MBh 33.8 35.0 38.4 - 33.0 34.2 37.5 - 32.2 33.4 36.6 - 31.4 32.6 35.7 - 29.9 31.0 33.9 - 27.7 28.7 31.4 -
S/T 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.87 0.72 0.50 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 18 13 - 20 17 13 - 19 16 12 -
kW 2.37 2.42 2.49 - 2.55 2.60 2.69 - 2.71 2.77 2.86 - 2.85 2.91 3.01 - 2.97 3.03 3.13 - 3.07 3.14 3.24 -
Amps 9.9 10.1 10.4 - 10.6 10.8 11.1 - 11.4 11.6 12.0 - 12.1 12.4 12.7 - 12.8 13.1 13.5 - 13.5 13.8 14.2 -
HI PR 247 265 280 - 277 298 315 - 315 339 358 - 359 386 407 - 403 434 458 - 446 480 507 -
LO PR 110 117 128 - 117 124 135 - 121 129 141 - 127 135 148 - 133 142 155 - 138 147 160 -
1038
MBh 31.2 32.3 35.4 - 30.5 31.6 34.6 - 29.7 30.8 33.8 - 29.0 30.1 33.0 - 27.6 28.6 31.3 - 25.5 26.5 29.0 -
S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.84 0.70 0.48 -
∆T 20 17 13 - 20 18 13 - 20 18 13 - 21 18 14 - 20 18 13 - 19 16 12 -
kW 2.31 2.36 2.43 - 2.49 2.54 2.62 - 2.64 2.70 2.79 - 2.78 2.84 2.93 - 2.90 2.96 3.06 - 3.00 3.06 3.16 -
Amps 9.7 9.9 10.1 - 10.3 10.6 10.9 - 11.1 11.4 11.7 - 11.8 12.1 12.4 - 12.5 12.7 13.1 - 13.1 13.4 13.8 -
HI PR 239 258 272 - 269 289 305 - 305 329 347 - 348 374 395 - 391 421 445 - 432 465 491 -
LO PR 107 114 124 - 113 120 131 - 118 125 137 - 124 131 143 - 129 138 150 - 134 142 155 -
75
1329
MBh 35.4 36.4 39.5 42.3 34.6 35.6 38.5 41.4 33.8 34.8 37.6 40.4 32.9 33.9 36.7 39.4 31.3 32.2 34.9 37.4 29.0 29.8 32.3 34.7
S/T 0.90 0.81 0.61 0.39 0.93 0.84 0.63 0.41 0.96 0.86 0.65 0.42 0.99 0.88 0.67 0.43 1.00 0.92 0.69 0.45 1.00 0.93 0.70 0.45
∆T 22 20 17 11 22 21 17 12 22 21 17 12 23 21 17 12 22 20 17 12 20 19 16 11
kW 2.41 2.46 2.53 2.62 2.59 2.65 2.73 2.82 2.75 2.81 2.90 3.00 2.90 2.96 3.06 3.16 3.02 3.09 3.19 3.30 3.12 3.19 3.30 3.41
Amps 10.1 10.3 10.6 10.9 10.8 11.0 11.3 11.7 11.6 11.8 12.2 12.6 12.3 12.6 12.9 13.4 13.0 13.3 13.7 14.2 13.7 14.0 14.4 14.9
HI PR 252 271 286 298 282 304 321 335 321 346 365 381 366 394 416 434 412 443 468 488 455 489 517 539
LO PR 113 120 131 139 119 127 138 147 124 132 144 153 130 138 151 161 136 145 158 168 141 150 164 174
1184
MBh 34.4 35.4 38.3 41.1 33.6 34.6 37.4 40.2 32.8 33.7 36.5 39.2 32.0 32.9 35.6 38.2 30.4 31.3 33.8 36.3 28.1 29.0 31.4 33.7
S/T 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.91 0.82 0.62 0.40 0.94 0.84 0.64 0.41 0.98 0.88 0.66 0.43 0.99 0.88 0.67 0.43
∆T 23 21 17 12 23 21 18 12 23 21 18 12 23 22 18 12 23 21 17 12 22 20 16 11
kW 2.39 2.44 2.51 2.59 2.57 2.63 2.71 2.80 2.73 2.79 2.88 2.98 2.87 2.94 3.03 3.13 2.99 3.06 3.16 3.27 3.10 3.17 3.27 3.38
Amps 10.0 10.2 10.5 10.8 10.7 10.9 11.2 11.6 11.5 11.7 12.1 12.5 12.2 12.5 12.8 13.3 12.9 13.2 13.6 14.1 13.6 13.9 14.3 14.8
HI PR 249 268 283 295 280 301 318 331 318 342 361 377 362 390 412 429 408 439 463 483 450 485 512 534
LO PR 112 119 130 138 118 125 137 146 122 130 142 151 129 137 149 159 135 143 157 167 139 148 162 172
1038
MBh 31.7 32.7 35.4 37.9 31.0 31.9 34.5 37.1 30.2 31.1 33.7 36.2 29.5 30.4 32.9 35.3 28.0 28.9 31.2 33.5 26.0 26.7 28.9 31.1
S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41
∆T 23 21 18 12 24 22 18 12 24 22 18 12 24 22 18 12 23 22 18 12 22 20 17 11
kW 2.33 2.38 2.45 2.53 2.51 2.56 2.64 2.73 2.66 2.72 2.81 2.90 2.80 2.86 2.96 3.05 2.92 2.98 3.08 3.18 3.02 3.09 3.19 3.30
Amps 9.7 9.9 10.2 10.6 10.4 10.6 11.0 11.3 11.2 11.5 11.8 12.2 11.9 12.2 12.5 12.9 12.6 12.9 13.2 13.7 13.2 13.5 14.0 14.4
HI PR 242 260 275 287 271 292 308 322 309 332 351 366 351 378 399 416 395 425 449 469 437 470 496 518
LO PR 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
10 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 11
expanded coolinG data — apG1436***M41** (cont.)
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1329
MBh 36.0 36.8 39.3 42.0 35.2 36.0 38.4 41.1 34.4 35.1 37.5 40.1 33.5 34.2 36.6 39.1 31.8 32.5 34.8 37.2 29.5 30.1 32.2 34.4
S/T 1.00 0.93 0.75 0.56 1.00 0.96 0.78 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.86 0.64 1.00 1.00 0.87 0.65
∆T 25 24 21 16 24 24 21 17 24 24 21 17 23 24 21 17 22 23 21 17 20 21 19 15
kW 2.43 2.48 2.56 2.64 2.61 2.67 2.75 2.84 2.78 2.84 2.93 3.03 2.92 2.99 3.08 3.19 3.04 3.11 3.21 3.32 3.15 3.22 3.33 3.44
Amps 10.1 10.3 10.6 11.0 10.9 11.1 11.4 11.8 11.7 11.9 12.3 12.7 12.4 12.7 13.1 13.5 13.1 13.4 13.8 14.3 13.8 14.1 14.6 15.1
HI PR 254 274 289 301 285 307 324 338 324 349 369 385 370 398 420 438 416 447 472 493 459 494 522 544
LO PR 114 121 132 141 120 128 140 149 125 133 145 155 131 140 152 162 138 146 160 170 142 151 165 176
1184
MBh 35.0 35.7 38.2 40.8 34.2 34.9 37.3 39.9 33.4 34.1 36.4 38.9 32.5 33.2 35.5 38.0 30.9 31.6 33.7 36.1 28.6 29.3 31.3 33.4
S/T 0.94 0.88 0.72 0.54 0.98 0.92 0.75 0.56 1.00 0.94 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.83 0.62
∆T 26 25 21 17 26 25 22 17 26 25 22 17 25 25 22 17 24 25 21 17 22 23 20 16
kW 2.41 2.46 2.53 2.62 2.59 2.65 2.73 2.82 2.75 2.81 2.90 3.00 2.90 2.96 3.06 3.16 3.02 3.09 3.19 3.30 3.12 3.19 3.30 3.41
Amps 10.1 10.3 10.6 10.9 10.8 11.0 11.3 11.7 11.6 11.8 12.2 12.6 12.3 12.6 12.9 13.4 13.0 13.3 13.7 14.2 13.7 14.0 14.4 14.9
HI PR 252 271 286 298 282 304 321 335 321 346 365 381 366 394 416 434 412 443 468 488 455 489 517 539
LO PR 113 120 131 139 119 127 138 147 124 132 144 153 130 138 151 161 136 145 158 168 141 150 164 174
1038
MBh 32.3 33.0 35.2 37.7 31.5 32.2 34.4 36.8 30.8 31.5 33.6 35.9 30.0 30.7 32.8 35.0 28.5 29.2 31.1 33.3 26.4 27.0 28.9 30.8
S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.76 0.57 1.03 0.97 0.79 0.59 1.04 0.98 0.80 0.60
∆T 26 25 22 17 26 25 22 18 26 25 22 18 27 25 22 18 26 25 22 17 24 23 20 16
kW 2.35 2.40 2.47 2.55 2.53 2.58 2.66 2.75 2.69 2.74 2.83 2.93 2.83 2.89 2.98 3.08 2.94 3.01 3.11 3.21 3.05 3.11 3.22 3.32
Amps 9.8 10.0 10.3 10.6 10.5 10.7 11.0 11.4 11.3 11.5 11.9 12.3 12.0 12.3 12.6 13.1 12.7 13.0 13.4 13.8 13.4 13.7 14.1 14.6
HI PR 244 263 277 289 274 295 311 325 312 335 354 369 355 382 403 421 399 430 454 473 441 475 501 523
LO PR 109 116 127 135 115 123 134 143 120 128 139 148 126 134 146 156 132 141 153 163 137 145 159 169
85
1329
MBh 36.7 37.4 39.1 41.8 35.8 36.5 38.2 40.8 35.0 35.6 37.3 39.8 34.1 34.8 36.4 38.8 32.4 33.0 34.6 36.9 30.0 30.6 32.0 34.2
S/T 1.00 1.00 0.90 0.73 1.00 1.00 0.94 0.76 1.00 1.00 0.96 0.78 1.00 1.00 0.99 0.80 1.00 1.00 1.00 0.83 1.00 1.00 1.00 0.84
∆T 25 26 24 21 25 25 25 21 24 25 25 21 24 24 25 22 22 23 24 21 21 21 22 20
kW 2.45 2.50 2.58 2.66 2.63 2.69 2.78 2.87 2.80 2.86 2.95 3.05 2.95 3.01 3.11 3.21 3.07 3.14 3.24 3.35 3.18 3.25 3.36 3.47
Amps 10.2 10.4 10.7 11.1 10.9 11.2 11.5 11.9 11.8 12.0 12.4 12.8 12.5 12.8 13.2 13.6 13.2 13.5 13.9 14.4 13.9 14.3 14.7 15.2
HI PR 257 276 292 304 288 310 327 342 328 353 372 388 373 402 424 442 420 452 477 498 464 499 527 550
LO PR 115 122 133 142 121 129 141 150 126 134 147 156 133 141 154 164 139 148 161 172 144 153 167 178
1184
MBh 35.6 36.3 38.0 40.5 34.8 35.4 37.1 39.6 33.9 34.6 36.2 38.7 33.1 33.7 35.3 37.7 31.5 32.1 33.6 35.8 29.1 29.7 31.1 33.2
S/T 0.99 0.95 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.77 1.00 1.00 0.98 0.79 1.00 1.00 0.99 0.80
∆T 27 27 25 22 27 27 26 22 26 27 26 22 26 26 26 22 24 25 26 22 23 23 24 21
kW 2.43 2.48 2.56 2.64 2.61 2.67 2.75 2.84 2.78 2.84 2.93 3.03 2.92 2.99 3.08 3.19 3.04 3.11 3.21 3.32 3.15 3.22 3.33 3.44
Amps 10.1 10.3 10.6 11.0 10.9 11.1 11.4 11.8 11.7 11.9 12.3 12.7 12.4 12.7 13.1 13.5 13.1 13.4 13.8 14.3 13.8 14.1 14.6 15.1
HI PR 254 274 289 301 285 307 324 338 324 349 369 385 370 398 420 438 416 447 472 493 459 494 522 544
LO PR 114 121 132 141 120 128 140 149 125 133 145 155 131 140 152 162 138 146 160 170 142 151 165 176
1038
MBh 32.8 33.5 35.1 37.4 32.1 32.7 34.3 36.5 31.3 31.9 33.4 35.7 30.6 31.1 32.6 34.8 29.0 29.6 31.0 33.1 26.9 27.4 28.7 30.6
S/T 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.98 0.88 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.77 1.00 1.00 0.95 0.77
∆T 28 27 26 22 28 28 26 23 28 28 26 23 27 28 26 23 26 26 26 22 24 24 24 21
kW 2.37 2.42 2.49 2.57 2.55 2.60 2.69 2.77 2.71 2.77 2.86 2.95 2.85 2.91 3.01 3.11 2.97 3.03 3.13 3.24 3.07 3.14 3.24 3.35
Amps 9.9 10.1 10.4 10.7 10.6 10.8 11.1 11.5 11.4 11.6 12.0 12.4 12.1 12.4 12.7 13.2 12.8 13.1 13.5 13.9 13.5 13.8 14.2 14.7
HI PR 247 265 280 292 277 298 314 328 315 339 358 373 358 386 407 425 403 434 458 478 446 480 506 528
LO PR 110 117 128 137 117 124 135 144 121 129 141 150 127 135 148 157 133 142 155 165 138 147 160 171
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
12 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 13
expanded coolinG data — apG1442***M41**
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1443
MBh 40.0 41.4 45.4 - 39.0 40.5 44.3 - 38.1 39.5 43.3 - 37.2 38.5 42.2 - 35.3 36.6 40.1 - 32.7 33.9 37.2 -
S/T 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.86 0.72 0.50 -
∆T 19 17 13 - 19 17 13 - 19 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
kW 2.68 2.73 2.82 - 2.88 2.94 3.03 - 3.05 3.12 3.21 - 3.21 3.27 3.38 - 3.34 3.41 3.52 - 3.45 3.53 3.64 -
Amps 12.9 13.1 13.4 - 13.7 13.9 14.3 - 14.6 14.9 15.2 - 15.4 15.7 16.1 - 16.1 16.5 16.9 - 16.9 17.3 17.7 -
HI PR 236 254 269 - 265 285 301 - 302 325 343 - 343 370 390 - 386 416 439 - 427 459 485 -
LO PR 107 113 124 - 113 120 131 - 117 124 136 - 123 131 143 - 129 137 150 - 133 142 155 -
1286
MBh 38.8 40.2 44.1 - 37.9 39.3 43.0 - 37.0 38.3 42.0 - 36.1 37.4 41.0 - 34.3 35.5 38.9 - 31.8 32.9 36.1 -
S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 18 13 - 20 17 13 - 19 16 12 -
kW 2.66 2.71 2.79 - 2.85 2.91 3.00 - 3.03 3.09 3.19 - 3.18 3.25 3.35 - 3.31 3.38 3.49 - 3.42 3.50 3.61 -
Amps 12.8 13.0 13.4 - 13.6 13.8 14.2 - 14.5 14.7 15.1 - 15.3 15.5 16.0 - 16.0 16.3 16.8 - 16.8 17.1 17.6 -
HI PR 234 252 266 - 263 283 298 - 299 321 339 - 340 366 386 - 383 412 435 - 423 455 480 -
LO PR 105 112 123 - 111 119 129 - 116 123 135 - 122 129 141 - 128 136 148 - 132 140 153 -
1128
MBh 35.8 37.1 40.7 - 35.0 36.3 39.7 - 34.1 35.4 38.8 - 33.3 34.5 37.8 - 31.6 32.8 35.9 - 29.3 30.4 33.3 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.41 - 0.74 0.61 0.43 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.79 0.66 0.46 -
∆T 20 17 13 - 20 18 13 - 20 18 13 - 21 18 14 - 20 18 13 - 19 16 12 -
kW 2.60 2.65 2.73 - 2.79 2.84 2.93 - 2.96 3.02 3.11 - 3.10 3.17 3.27 - 3.23 3.30 3.40 - 3.34 3.41 3.52 -
Amps 12.5 12.8 13.1 - 13.3 13.5 13.9 - 14.2 14.4 14.8 - 14.9 15.2 15.6 - 15.7 16.0 16.4 - 16.4 16.7 17.2 -
HI PR 227 244 258 - 255 274 289 - 290 312 329 - 330 355 375 - 371 399 422 - 410 441 466 -
LO PR 102 109 119 - 108 115 126 - 112 120 130 - 118 126 137 - 124 132 144 - 128 136 149 -
75
1443
MBh 40.6 41.8 45.3 48.6 39.7 40.9 44.2 47.5 38.8 39.9 43.2 46.3 37.8 38.9 42.1 45.2 35.9 37.0 40.0 43.0 33.3 34.3 37.1 39.8
S/T 0.86 0.76 0.58 0.37 0.89 0.79 0.60 0.39 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.97 0.87 0.66 0.42 0.98 0.88 0.66 0.43
∆T 22 20 17 12 22 21 17 12 22 21 17 12 23 21 17 12 22 21 17 12 21 19 16 11
kW 2.70 2.75 2.84 2.93 2.90 2.96 3.05 3.15 3.08 3.14 3.24 3.34 3.23 3.30 3.41 3.52 3.36 3.44 3.55 3.67 3.48 3.56 3.67 3.79
Amps 13.0 13.2 13.5 13.9 13.8 14.0 14.4 14.8 14.7 15.0 15.4 15.8 15.5 15.8 16.2 16.7 16.3 16.6 17.0 17.6 17.0 17.4 17.9 18.4
HI PR 239 257 271 283 268 288 304 317 305 328 346 361 347 373 394 411 390 420 444 463 431 464 490 511
LO PR 108 115 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 138 151 161 135 143 156 166
1286
MBh 39.5 40.6 44.0 47.2 38.5 39.7 43.0 46.1 37.6 38.7 41.9 45.0 36.7 37.8 40.9 43.9 34.9 35.9 38.9 41.7 32.3 33.3 36.0 38.6
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.89 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41
∆T 23 21 17 12 23 21 18 12 23 21 18 12 23 22 18 12 23 21 17 12 22 20 16 11
kW 2.68 2.73 2.82 2.90 2.88 2.94 3.03 3.12 3.05 3.12 3.21 3.32 3.21 3.28 3.38 3.49 3.34 3.41 3.52 3.64 3.45 3.53 3.64 3.76
Amps 12.9 13.1 13.4 13.8 13.7 13.9 14.3 14.7 14.6 14.9 15.2 15.7 15.4 15.7 16.1 16.6 16.1 16.5 16.9 17.4 16.9 17.3 17.7 18.3
HI PR 236 254 269 280 265 285 301 314 302 325 343 358 344 370 390 407 387 416 439 458 427 460 485 506
LO PR 107 113 124 132 113 120 131 139 117 124 136 145 123 131 143 152 129 137 150 159 133 142 155 165
1128
MBh 36.4 37.5 40.6 43.6 35.6 36.6 39.6 42.5 34.7 35.8 38.7 41.5 33.9 34.9 37.8 40.5 32.2 33.1 35.9 38.5 29.8 30.7 33.2 35.7
S/T 0.79 0.70 0.53 0.34 0.82 0.73 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39
∆T 23 22 18 12 24 22 18 12 24 22 18 12 24 22 18 12 23 22 18 12 22 20 17 11
kW 2.62 2.67 2.75 2.84 2.81 2.87 2.96 3.05 2.98 3.04 3.14 3.24 3.13 3.20 3.30 3.40 3.26 3.33 3.43 3.55 3.37 3.44 3.55 3.67
Amps 12.6 12.9 13.2 13.5 13.4 13.6 14.0 14.4 14.3 14.5 14.9 15.4 15.0 15.3 15.7 16.2 15.8 16.1 16.5 17.0 16.5 16.9 17.3 17.9
HI PR 229 247 261 272 257 277 292 305 293 315 332 347 333 359 379 395 375 403 426 444 414 446 471 491
LO PR 103 110 120 128 109 116 127 135 114 121 132 140 119 127 138 147 125 133 145 155 129 137 150 160
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
12 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 13
expanded coolinG data — apG1442***M41** (cont.)
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1443
MBh 41.4 42.3 45.2 48.3 40.4 41.3 44.1 47.1 39.4 40.3 43.1 46.0 38.5 39.3 42.0 44.9 36.6 37.4 39.9 42.7 33.9 34.6 37.0 39.5
S/T 0.94 0.88 0.72 0.54 1.00 0.91 0.74 0.55 1.00 0.93 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.82 0.61
∆T 25 24 21 16 26 24 21 17 25 24 21 17 25 24 21 17 23 24 21 17 22 22 19 15
kW 2.72 2.78 2.86 2.95 2.92 2.98 3.08 3.17 3.10 3.17 3.27 3.37 3.26 3.33 3.44 3.55 3.39 3.47 3.58 3.70 3.51 3.59 3.70 3.82
Amps 13.1 13.3 13.6 14.0 13.9 14.1 14.5 14.9 14.8 15.1 15.5 15.9 15.6 15.9 16.3 16.8 16.4 16.7 17.2 17.7 17.2 17.5 18.0 18.6
HI PR 241 260 274 286 271 291 307 321 308 331 350 365 350 377 398 415 394 424 448 467 436 469 495 516
LO PR 109 116 126 134 115 122 133 142 119 127 139 148 125 133 146 155 131 140 153 163 136 145 158 168
1286
MBh 40.2 41.0 43.8 46.9 39.2 40.1 42.8 45.8 38.3 39.1 41.8 44.7 37.4 38.2 40.8 43.6 35.5 36.3 38.7 41.4 32.9 33.6 35.9 38.4
S/T 0.89 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.95 0.89 0.73 0.54 0.98 0.92 0.75 0.56 1.00 0.96 0.78 0.58 1.00 0.96 0.78 0.59
∆T 26 25 21 17 26 25 22 17 26 25 22 17 26 25 22 17 25 25 22 17 24 23 20 16
kW 2.70 2.75 2.84 2.93 2.90 2.96 3.05 3.15 3.08 3.14 3.24 3.35 3.23 3.30 3.41 3.52 3.37 3.44 3.55 3.67 3.48 3.56 3.67 3.79
Amps 13.0 13.2 13.5 13.9 13.8 14.0 14.4 14.8 14.7 15.0 15.4 15.8 15.5 15.8 16.2 16.7 16.3 16.6 17.0 17.6 17.1 17.4 17.9 18.4
HI PR 239 257 271 283 268 288 304 318 305 328 346 361 347 373 394 411 390 420 444 463 431 464 490 511
LO PR 108 115 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 138 151 161 135 143 156 166
1128
MBh 37.1 37.9 40.5 43.3 36.2 37.0 39.5 42.3 35.3 36.1 38.6 41.2 34.5 35.2 37.6 40.2 32.8 33.5 35.8 38.2 30.3 31.0 33.1 35.4
S/T 0.86 0.81 0.66 0.49 0.89 0.84 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.93 0.76 0.57
∆T 26 25 22 17 26 25 22 18 26 25 22 18 27 25 22 18 26 25 22 17 24 23 20 16
kW 2.64 2.69 2.77 2.86 2.83 2.89 2.98 3.07 3.00 3.07 3.16 3.26 3.15 3.22 3.32 3.43 3.28 3.35 3.46 3.57 3.39 3.47 3.58 3.70
Amps 12.7 12.9 13.3 13.6 13.5 13.7 14.1 14.5 14.4 14.6 15.0 15.5 15.1 15.4 15.8 16.3 15.9 16.2 16.7 17.2 16.7 17.0 17.5 18.0
HI PR 232 249 263 274 260 280 295 308 296 318 336 350 337 362 383 399 379 408 430 449 418 450 475 496
LO PR 104 111 121 129 110 117 128 136 115 122 133 142 120 128 140 149 126 134 147 156 131 139 152 161
85
1443
MBh 42.1 42.9 44.9 47.9 41.1 41.9 43.9 46.8 40.1 40.9 42.8 45.7 39.1 39.9 41.8 44.6 37.2 37.9 39.7 42.4 34.5 35.1 36.8 39.2
S/T 0.98 0.95 0.86 0.69 1.00 0.98 0.89 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.97 0.79 1.00 1.00 0.98 0.80
∆T 26 26 25 21 26 26 25 21 26 26 25 21 25 25 25 22 24 24 25 21 22 22 23 20
kW 2.74 2.80 2.88 2.97 2.94 3.01 3.10 3.20 3.13 3.19 3.29 3.40 3.28 3.36 3.46 3.58 3.42 3.49 3.61 3.73 3.54 3.61 3.73 3.86
Amps 13.2 13.4 13.7 14.1 14.0 14.2 14.6 15.0 14.9 15.2 15.6 16.1 15.7 16.0 16.4 16.9 16.5 16.8 17.3 17.8 17.3 17.7 18.1 18.7
HI PR 244 262 277 289 273 294 311 324 311 334 353 368 354 381 402 420 398 429 453 472 440 474 500 522
LO PR 110 117 128 136 116 123 135 144 121 128 140 149 127 135 147 157 133 141 154 164 137 146 159 170
1286
MBh 40.9 41.7 43.6 46.5 39.9 40.7 42.6 45.5 39.0 39.7 41.6 44.4 38.0 38.7 40.6 43.3 36.1 36.8 38.5 41.1 33.4 34.1 35.7 38.1
S/T 0.94 0.90 0.82 0.66 0.97 0.94 0.85 0.69 1.00 0.96 0.87 0.70 1.00 0.99 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.94 0.76
∆T 27 27 25 22 28 27 26 22 28 27 26 22 27 28 26 23 26 26 26 22 24 24 24 21
kW 2.72 2.78 2.86 2.95 2.92 2.98 3.08 3.17 3.10 3.17 3.27 3.37 3.26 3.33 3.44 3.55 3.39 3.47 3.58 3.70 3.51 3.59 3.70 3.82
Amps 13.1 13.3 13.6 14.0 13.9 14.1 14.5 14.9 14.8 15.1 15.5 15.9 15.6 15.9 16.3 16.8 16.4 16.7 17.2 17.7 17.2 17.5 18.0 18.6
HI PR 241 260 274 286 271 291 307 321 308 331 350 365 350 377 398 415 394 424 448 467 436 469 495 516
LO PR 109 116 126 134 115 122 133 142 119 127 139 148 125 133 146 155 131 140 153 163 136 145 158 168
1128
MBh 37.7 38.4 40.3 43.0 36.8 37.5 39.3 42.0 36.0 36.7 38.4 41.0 35.1 35.8 37.5 40.0 33.3 34.0 35.6 38.0 30.9 31.5 33.0 35.2
S/T 0.90 0.87 0.79 0.64 0.94 0.90 0.82 0.66 0.96 0.93 0.84 0.68 0.99 0.96 0.86 0.70 1.00 0.99 0.90 0.73 1.00 1.00 0.90 0.73
∆T 28 27 26 22 28 28 26 23 28 28 26 23 28 28 26 23 27 28 26 23 25 26 24 21
kW 2.66 2.71 2.79 2.88 2.85 2.91 3.00 3.10 3.03 3.09 3.19 3.29 3.18 3.25 3.35 3.46 3.31 3.38 3.49 3.60 3.42 3.50 3.61 3.73
Amps 12.8 13.0 13.3 13.7 13.6 13.8 14.2 14.6 14.5 14.7 15.1 15.6 15.2 15.5 16.0 16.4 16.0 16.3 16.8 17.3 16.8 17.1 17.6 18.1
HI PR 234 252 266 277 262 282 298 311 299 321 339 354 340 366 386 403 382 412 435 453 423 455 480 501
LO PR 105 112 122 130 111 119 129 138 116 123 134 143 122 129 141 150 127 136 148 158 132 140 153 163
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
14 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 15
expanded coolinG data — apG1448***M41**
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1717
MBh 45.9 47.5 52.1 - 44.8 46.4 50.9 - 43.7 45.3 49.7 - 42.7 44.2 48.5 - 40.5 42.0 46.0 - 37.6 38.9 42.6 -
S/T 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.85 0.71 0.49 - 0.88 0.73 0.51 - 0.91 0.76 0.53 - 0.92 0.77 0.53 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
kW 3.18 3.25 3.35 - 3.42 3.49 3.60 - 3.63 3.70 3.82 - 3.81 3.89 4.01 - 3.96 4.05 4.18 - 4.10 4.19 4.32 -
Amps 15.3 15.5 15.9 - 16.2 16.5 16.9 - 17.3 17.6 18.0 - 18.2 18.5 19.0 - 19.1 19.5 20.0 - 20.0 20.4 21.0 -
Hi PR 254 273 288 - 285 306 324 - 324 348 368 - 369 397 419 - 415 446 471 - 458 493 521 -
Lo PR 112 119 130 - 118 126 137 - 123 131 142 - 129 137 150 - 135 144 157 - 140 149 162 -
1529
MBh 44.5 46.2 50.6 - 43.5 45.1 49.4 - 42.5 44.0 48.2 - 41.4 42.9 47.1 - 39.4 40.8 44.7 - 36.5 37.8 41.4 -
S/T 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.83 0.70 0.48 - 0.87 0.72 0.50 - 0.87 0.73 0.51 -
∆T 20 18 13 - 21 18 14 - 21 18 14 - 21 18 14 - 21 18 13 - 19 17 13 -
kW 3.16 3.22 3.32 - 3.39 3.46 3.57 - 3.60 3.67 3.79 - 3.78 3.86 3.98 - 3.93 4.02 4.15 - 4.07 4.15 4.29 -
Amps 15.2 15.4 15.8 - 16.1 16.4 16.8 - 17.1 17.5 17.9 - 18.0 18.4 18.9 - 19.0 19.3 19.8 - 19.9 20.2 20.8 -
Hi PR 251 270 285 - 282 303 320 - 321 345 364 - 365 393 415 - 411 442 467 - 454 488 516 -
Lo PR 111 118 128 - 117 124 136 - 121 129 141 - 128 136 148 - 134 142 155 - 138 147 161 -
1341
MBh 41.1 42.6 46.7 - 40.2 41.6 45.6 - 39.2 40.6 44.5 - 38.2 39.6 43.4 - 36.3 37.7 41.3 - 33.7 34.9 38.2 -
S/T 0.73 0.61 0.42 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.47 - 0.84 0.70 0.48 - 0.84 0.70 0.49 -
∆T 21 18 14 - 21 18 14 - 21 18 14 - 21 18 14 - 21 18 14 - 19 17 13 -
kW 3.09 3.15 3.25 - 3.31 3.38 3.49 - 3.51 3.59 3.70 - 3.69 3.77 3.89 - 3.84 3.92 4.04 - 3.97 4.05 4.18 -
Amps 14.9 15.1 15.5 - 15.7 16.0 16.4 - 16.8 17.1 17.5 - 17.7 18.0 18.5 - 18.5 18.9 19.4 - 19.4 19.8 20.3 -
Hi PR 244 262 277 - 273 294 311 - 311 335 353 - 354 381 402 - 398 429 453 - 440 474 500 -
Lo PR 107 114 125 - 113 121 132 - 118 125 137 - 124 132 144 - 130 138 151 - 134 143 156 -
75
1717
MBh 46.7 48.0 52.0 55.8 45.6 46.9 50.8 54.5 44.5 45.8 49.6 53.2 43.4 44.7 48.4 51.9 41.2 42.4 45.9 49.3 38.2 39.3 42.6 45.7
S/T 0.91 0.81 0.61 0.40 0.94 0.84 0.64 0.41 0.96 0.86 0.65 0.42 0.99 0.89 0.67 0.43 1.00 0.92 0.70 0.45 1.00 0.93 0.70 0.45
∆T 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 22 21 17 12 20 20 16 11
kW 3.21 3.27 3.37 3.48 3.45 3.52 3.63 3.74 3.66 3.73 3.85 3.97 3.84 3.92 4.05 4.18 4.00 4.08 4.21 4.35 4.13 4.22 4.36 4.50
Amps 15.4 15.6 16.0 16.5 16.3 16.6 17.0 17.5 17.4 17.7 18.2 18.7 18.3 18.7 19.2 19.7 19.2 19.6 20.1 20.8 20.2 20.6 21.1 21.8
Hi PR 256 276 291 304 288 310 327 341 327 352 372 388 373 401 423 442 419 451 476 497 463 498 526 549
Lo PR 113 120 131 140 119 127 138 147 124 132 144 153 130 138 151 161 136 145 158 169 141 150 164 175
1529
MBh 45.3 46.6 50.5 54.2 44.2 45.6 49.3 52.9 43.2 44.5 48.1 51.7 42.1 43.4 47.0 50.4 40.0 41.2 44.6 47.9 37.1 38.2 41.3 44.3
S/T 0.87 0.77 0.59 0.38 0.90 0.80 0.61 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.98 0.88 0.67 0.43 0.99 0.89 0.67 0.43
∆T 24 22 18 12 24 22 18 12 24 22 18 12 24 22 18 13 24 22 18 12 22 20 17 12
kW 3.19 3.25 3.35 3.45 3.42 3.49 3.60 3.71 3.63 3.70 3.82 3.94 3.81 3.89 4.01 4.14 3.97 4.05 4.18 4.32 4.10 4.19 4.32 4.47
Amps 15.3 15.5 15.9 16.4 16.2 16.5 16.9 17.4 17.3 17.6 18.0 18.6 18.2 18.5 19.0 19.6 19.1 19.5 20.0 20.6 20.0 20.4 21.0 21.6
Hi PR 254 273 288 301 285 306 324 338 324 349 368 384 369 397 419 437 415 447 472 492 459 493 521 543
Lo PR 112 119 130 138 118 126 137 146 123 131 143 152 129 137 150 159 135 144 157 167 140 149 162 173
1341
MBh 41.8 43.0 46.6 50.0 40.8 42.0 45.5 48.8 39.9 41.0 44.4 47.7 38.9 40.0 43.3 46.5 36.9 38.0 41.2 44.2 34.2 35.2 38.1 40.9
S/T 0.83 0.75 0.56 0.36 0.86 0.77 0.59 0.38 0.89 0.79 0.60 0.39 0.91 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.96 0.86 0.65 0.42
∆T 24 22 18 12 24 22 18 13 24 22 18 13 24 22 18 13 24 22 18 13 22 21 17 12
kW 3.11 3.18 3.27 3.37 3.34 3.41 3.51 3.62 3.54 3.62 3.73 3.85 3.72 3.80 3.92 4.04 3.87 3.95 4.08 4.21 4.00 4.09 4.22 4.35
Amps 15.0 15.2 15.6 16.0 15.9 16.1 16.5 17.0 16.9 17.2 17.6 18.2 17.8 18.1 18.6 19.2 18.7 19.0 19.5 20.1 19.6 19.9 20.5 21.1
Hi PR 246 265 280 292 276 297 314 327 314 338 357 372 358 385 407 424 403 433 457 477 445 479 505 527
Lo PR 108 115 126 134 115 122 133 142 119 127 138 147 125 133 145 155 131 139 152 162 136 144 157 168
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
14 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 15
expanded coolinG data — apG1448***M41** (cont.)
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1717
MBh 47.5 48.5 51.8 55.4 46.4 47.4 50.6 54.1 45.3 46.3 49.4 52.8 44.2 45.1 48.2 51.5 42.0 42.9 45.8 49.0 38.9 39.7 42.4 45.4
S/T 1.00 0.93 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.81 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.86 0.65 1.00 1.00 0.87 0.65
∆T 25 24 21 17 25 25 21 17 24 25 21 17 24 24 22 17 22 23 21 17 21 21 20 16
kW 3.23 3.30 3.40 3.51 3.47 3.55 3.66 3.77 3.68 3.76 3.88 4.01 3.87 3.95 4.08 4.21 4.03 4.12 4.25 4.39 4.17 4.26 4.40 4.54
Amps 15.5 15.8 16.1 16.6 16.4 16.7 17.1 17.6 17.5 17.8 18.3 18.8 18.4 18.8 19.3 19.9 19.4 19.8 20.3 20.9 20.3 20.7 21.3 21.9
Hi PR 259 279 294 307 291 313 330 344 330 356 375 392 376 405 428 446 423 456 481 502 468 503 532 554
Lo PR 114 121 132 141 120 128 140 149 125 133 145 155 131 140 153 163 138 147 160 170 143 152 166 176
1529
MBh 46.1 47.1 50.3 53.8 45.0 46.0 49.2 52.5 44.0 44.9 48.0 51.3 42.9 43.8 46.8 50.0 40.7 41.6 44.5 47.5 37.7 38.6 41.2 44.0
S/T 0.95 0.89 0.72 0.54 0.98 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 0.98 0.79 0.59 1.00 1.00 0.82 0.62 1.00 1.00 0.83 0.62
∆T 26 25 22 18 27 26 22 18 26 26 22 18 26 26 22 18 24 25 22 18 23 23 21 16
kW 3.21 3.28 3.37 3.48 3.45 3.52 3.63 3.74 3.66 3.73 3.85 3.97 3.84 3.92 4.05 4.18 4.00 4.08 4.21 4.35 4.13 4.22 4.36 4.50
Amps 15.4 15.6 16.0 16.5 16.3 16.6 17.0 17.5 17.4 17.7 18.2 18.7 18.3 18.7 19.2 19.7 19.2 19.6 20.1 20.8 20.2 20.6 21.1 21.8
Hi PR 256 276 291 304 288 310 327 341 327 352 372 388 373 401 423 442 419 451 476 497 463 498 526 549
Lo PR 113 120 131 140 119 127 138 148 124 132 144 153 130 138 151 161 136 145 158 169 141 150 164 175
1341
MBh 42.6 43.5 46.5 49.7 41.6 42.5 45.4 48.5 40.6 41.5 44.3 47.3 39.6 40.4 43.2 46.2 37.6 38.4 41.1 43.9 34.8 35.6 38.0 40.6
S/T 0.91 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.77 0.57 1.04 0.98 0.80 0.59 1.05 0.98 0.80 0.60
∆T 27 26 22 18 27 26 23 18 27 26 23 18 27 26 23 18 27 26 22 18 25 24 21 17
kW 3.14 3.20 3.30 3.40 3.37 3.44 3.54 3.65 3.57 3.64 3.76 3.88 3.75 3.83 3.95 4.08 3.90 3.98 4.11 4.25 4.03 4.12 4.25 4.39
Amps 15.1 15.3 15.7 16.1 16.0 16.3 16.7 17.1 17.0 17.3 17.8 18.3 17.9 18.3 18.7 19.3 18.8 19.2 19.7 20.3 19.7 20.1 20.6 21.3
Hi PR 249 268 283 295 279 300 317 331 317 341 361 376 361 389 411 428 407 438 462 482 449 483 510 532
Lo PR 109 116 127 135 116 123 134 143 120 128 140 149 126 134 147 156 132 141 154 164 137 146 159 169
85
1717
MBh 48.3 49.2 51.6 55.0 47.2 48.1 50.4 53.7 46.1 47.0 49.2 52.5 44.9 45.8 48.0 51.2 42.7 43.5 45.6 48.6 39.5 40.3 42.2 45.0
S/T 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.97 0.78 1.00 1.00 1.00 0.81 1.00 1.00 1.00 0.84 1.00 1.00 1.00 0.85
∆T 26 26 25 22 25 26 25 22 25 25 25 22 24 25 26 22 23 23 24 22 21 22 23 20
kW 3.26 3.33 3.43 3.53 3.50 3.57 3.68 3.80 3.71 3.79 3.91 4.04 3.90 3.99 4.11 4.25 4.06 4.15 4.28 4.43 4.20 4.29 4.43 4.58
Amps 15.6 15.9 16.3 16.7 16.5 16.8 17.3 17.8 17.6 18.0 18.4 19.0 18.6 18.9 19.4 20.0 19.5 19.9 20.4 21.1 20.5 20.9 21.4 22.1
Hi PR 261 281 297 310 293 316 333 348 334 359 379 396 380 409 432 450 428 460 486 507 472 508 537 560
Lo PR 115 122 134 142 122 129 141 150 126 135 147 156 133 141 154 164 139 148 162 172 144 153 167 178
1529
MBh 46.9 47.8 50.1 53.4 45.8 46.7 48.9 52.2 44.7 45.6 47.7 50.9 43.6 44.5 46.6 49.7 41.5 42.3 44.3 47.2 38.4 39.1 41.0 43.7
S/T 0.99 0.96 0.87 0.70 1.00 0.99 0.90 0.73 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.99 0.80 1.00 1.00 0.99 0.81
∆T 28 28 26 23 28 28 26 23 27 27 26 23 26 27 27 23 25 25 26 23 23 24 25 21
kW 3.23 3.30 3.40 3.51 3.47 3.55 3.66 3.77 3.68 3.76 3.88 4.01 3.87 3.95 4.08 4.21 4.03 4.12 4.25 4.39 4.17 4.26 4.40 4.54
Amps 15.5 15.8 16.1 16.6 16.4 16.7 17.1 17.6 17.5 17.8 18.3 18.8 18.4 18.8 19.3 19.9 19.4 19.8 20.3 20.9 20.3 20.7 21.3 21.9
Hi PR 259 279 294 307 291 313 330 344 330 356 375 392 376 405 428 446 423 456 481 502 468 503 532 554
Lo PR 114 121 132 141 120 128 140 149 125 133 145 155 131 140 153 163 138 147 160 170 143 152 166 176
1341
MBh 43.3 44.1 46.2 49.3 42.3 43.1 45.1 48.2 41.3 42.1 44.1 47.0 40.3 41.1 43.0 45.9 38.3 39.0 40.8 43.6 35.4 36.1 37.8 40.4
S/T 0.96 0.93 0.84 0.68 0.99 0.96 0.87 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.96 0.78
∆T 28 28 26 23 29 28 27 23 28 28 27 23 28 28 27 23 26 27 27 23 24 25 25 22
kW 3.16 3.22 3.32 3.42 3.39 3.46 3.57 3.68 3.60 3.67 3.79 3.91 3.78 3.86 3.98 4.11 3.93 4.02 4.14 4.28 4.06 4.15 4.29 4.43
Amps 15.2 15.4 15.8 16.3 16.1 16.4 16.8 17.3 17.1 17.4 17.9 18.4 18.0 18.4 18.9 19.4 18.9 19.3 19.8 20.4 19.8 20.2 20.8 21.4
Hi PR 251 270 285 298 282 303 320 334 320 345 364 380 365 393 415 433 411 442 467 487 454 488 516 538
Lo PR 111 118 128 137 117 124 136 145 121 129 141 150 128 136 148 158 134 142 155 165 138 147 161 171
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
16 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 17
expanded Cooling data — apg1460***41a* — low stage
65 75 85 95 105 115
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1463
MBh 40.2 41.6 45.6 - 39.2 40.7 44.6 - 38.3 39.7 43.5 - 37.4 38.7 42.4 - 35.5 36.8 40.3 - 32.9 34.1 37.3 -
S/T 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.82 0.69 0.48 - 0.85 0.71 0.49 - 0.88 0.74 0.51 - 0.89 0.74 0.51 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
kW 2.88 2.94 3.03 - 3.09 3.16 3.25 - 3.28 3.35 3.45 - 3.44 3.52 3.63 - 3.59 3.66 3.78 - 3.71 3.79 3.91 -
Amps 13.6 13.9 14.2 - 14.5 14.7 15.1 - 15.4 15.7 16.2 - 16.3 16.6 17.1 - 17.1 17.5 18.0 - 18.0 18.3 18.8 -
Hi PR 231 248 262 - 259 279 294 - 294 317 335 - 335 361 381 - 377 406 429 - 417 449 474 -
Lo PR 111 118 129 - 117 125 136 - 122 129 141 - 128 136 148 - 134 143 156 - 139 147 161 -
1300
MBh 39.0 40.4 44.3 - 38.1 39.5 43.3 - 37.2 38.5 42.2 - 36.3 37.6 41.2 - 34.5 35.7 39.1 - 31.9 33.1 36.3 -
S/T 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.84 0.70 0.49 - 0.85 0.71 0.49 -
∆T 20 18 13 - 21 18 14 - 21 18 14 - 21 18 14 - 20 18 13 - 19 17 13 -
kW 2.86 2.92 3.00 - 3.07 3.13 3.23 - 3.25 3.32 3.43 - 3.42 3.49 3.60 - 3.56 3.63 3.75 - 3.68 3.76 3.88 -
Amps 13.5 13.8 14.1 - 14.4 14.6 15.0 - 15.3 15.6 16.0 - 16.2 16.5 16.9 - 17.0 17.3 17.8 - 17.8 18.2 18.7 -
Hi PR 228 246 260 - 256 276 291 - 292 314 331 - 332 357 377 - 374 402 424 - 413 444 469 -
Lo PR 110 117 127 - 116 123 135 - 120 128 140 - 127 135 147 - 133 141 154 - 137 146 159 -
1138
MBh 36.0 37.3 40.9 - 35.2 36.4 39.9 - 34.3 35.6 39.0 - 33.5 34.7 38.0 - 31.8 33.0 36.1 - 29.5 30.5 33.5 -
S/T 0.71 0.59 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -
∆T 21 18 14 - 21 18 14 - 21 18 14 - 21 18 14 - 21 18 14 - 19 17 13 -
kW 2.79 2.85 2.93 - 3.00 3.06 3.15 - 3.18 3.24 3.34 - 3.34 3.41 3.51 - 3.47 3.55 3.66 - 3.59 3.67 3.78 -
Amps 13.2 13.5 13.8 - 14.1 14.3 14.7 - 15.0 15.3 15.7 - 15.8 16.1 16.5 - 16.6 17.0 17.4 - 17.4 17.8 18.3 -
Hi PR 222 238 252 - 249 268 283 - 283 304 321 - 322 347 366 - 362 390 412 - 400 431 455 -
Lo PR 106 113 124 - 112 120 131 - 117 124 136 - 123 131 143 - 129 137 149 - 133 142 155 -
75
1463
MBh 40.9 42.1 45.5 48.9 39.9 41.1 44.5 47.7 39.0 40.1 43.4 46.6 38.0 39.1 42.4 45.5 36.1 37.2 40.2 43.2 33.4 34.4 37.3 40.0
S/T 0.88 0.79 0.60 0.38 0.91 0.81 0.62 0.40 0.93 0.84 0.63 0.41 0.96 0.86 0.65 0.42 1.00 0.90 0.68 0.44 1.00 0.90 0.68 0.44
∆T 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 21 20 16 11
kW 2.90 2.96 3.05 3.15 3.12 3.18 3.28 3.38 3.31 3.38 3.48 3.59 3.47 3.55 3.66 3.78 3.62 3.69 3.81 3.94 3.74 3.82 3.94 4.07
Amps 13.7 14.0 14.3 14.7 14.6 14.8 15.2 15.7 15.6 15.9 16.3 16.8 16.4 16.7 17.2 17.7 17.3 17.6 18.1 18.7 18.1 18.5 19.0 19.6
Hi PR 233 251 265 276 262 281 297 310 297 320 338 353 339 365 385 402 381 410 433 452 421 453 479 499
Lo PR 112 119 130 138 118 126 137 146 123 131 143 152 129 137 150 160 135 144 157 167 140 149 163 173
1300
MBh 39.7 40.8 44.2 47.4 38.7 39.9 43.2 46.3 37.8 38.9 42.2 45.2 36.9 38.0 41.1 44.1 35.1 36.1 39.1 41.9 32.5 33.4 36.2 38.8
S/T 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.65 0.42 0.96 0.86 0.65 0.42
∆T 24 22 18 12 24 22 18 12 24 22 18 12 24 22 18 13 24 22 18 12 22 20 17 12
kW 2.88 2.94 3.03 3.12 3.09 3.16 3.25 3.36 3.28 3.35 3.45 3.57 3.45 3.52 3.63 3.75 3.59 3.66 3.78 3.91 3.71 3.79 3.91 4.04
Amps 13.6 13.9 14.2 14.6 14.5 14.7 15.1 15.6 15.4 15.7 16.2 16.6 16.3 16.6 17.1 17.6 17.1 17.5 18.0 18.5 18.0 18.3 18.8 19.4
Hi PR 231 248 262 274 259 279 294 307 294 317 335 349 335 361 381 398 377 406 429 447 417 449 474 494
Lo PR 111 118 129 137 117 125 136 145 122 129 141 151 128 136 149 158 134 143 156 166 139 147 161 171
1138
MBh 36.6 37.7 40.8 43.8 35.8 36.8 39.9 42.8 34.9 35.9 38.9 41.8 34.1 35.1 38.0 40.7 32.4 33.3 36.1 38.7 30.0 30.9 33.4 35.8
S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40
∆T 24 22 18 12 24 22 18 13 24 22 18 13 24 22 18 13 24 22 18 13 22 21 17 12
kW 2.81 2.87 2.96 3.05 3.02 3.08 3.18 3.28 3.20 3.27 3.37 3.48 3.36 3.43 3.54 3.66 3.50 3.57 3.69 3.81 3.62 3.70 3.81 3.94
Amps 13.3 13.6 13.9 14.3 14.2 14.4 14.8 15.2 15.1 15.4 15.8 16.3 15.9 16.2 16.7 17.2 16.7 17.1 17.5 18.1 17.6 17.9 18.4 19.0
Hi PR 224 241 254 265 251 270 285 298 286 307 325 339 325 350 370 386 366 394 416 434 404 435 460 479
Lo PR 108 114 125 133 114 121 132 141 118 126 137 146 124 132 144 153 130 138 151 161 134 143 156 166
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
16 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 17
expanded Cooling data — apg1460***41a* — low stage (Cont.)
65 75 85 95 105 115
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1463
MBh 41.6 42.5 45.4 48.5 40.6 41.5 44.3 47.4 39.6 40.5 43.3 46.3 38.7 39.5 42.2 45.1 36.7 37.6 40.1 42.9 34.0 34.8 37.2 39.7
S/T 0.96 0.90 0.74 0.55 1.00 0.94 0.76 0.57 1.00 0.96 0.78 0.58 1.00 1.00 0.81 0.60 1.00 1.00 0.84 0.63 1.00 1.00 0.84 0.63
∆T 25 24 21 17 26 24 21 17 25 24 21 17 24 25 21 17 23 24 21 17 21 22 20 16
kW 2.92 2.98 3.07 3.17 3.14 3.21 3.31 3.41 3.33 3.40 3.51 3.62 3.50 3.58 3.69 3.81 3.65 3.72 3.84 3.97 3.77 3.85 3.98 4.11
Amps 13.8 14.1 14.4 14.8 14.7 14.9 15.3 15.8 15.7 16.0 16.4 16.9 16.5 16.9 17.3 17.9 17.4 17.7 18.2 18.8 18.2 18.6 19.1 19.8
Hi PR 235 253 268 279 264 284 300 313 300 323 341 356 342 368 389 406 385 414 437 456 425 458 483 504
Lo PR 113 120 131 140 119 127 139 148 124 132 144 154 130 139 152 161 137 145 159 169 141 150 164 175
1300
MBh 40.4 41.3 44.1 47.1 39.4 40.3 43.1 46.0 38.5 39.3 42.0 44.9 37.6 38.4 41.0 43.8 35.7 36.5 39.0 41.6 33.0 33.8 36.1 38.6
S/T 0.92 0.86 0.70 0.52 0.95 0.89 0.73 0.54 0.98 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 0.98 0.80 0.60 1.00 0.99 0.81 0.60
∆T 26 25 22 17 27 25 22 18 27 25 22 18 27 26 22 18 25 25 22 18 23 24 21 16
kW 2.90 2.96 3.05 3.15 3.12 3.18 3.28 3.38 3.31 3.38 3.48 3.59 3.47 3.55 3.66 3.78 3.62 3.69 3.81 3.94 3.74 3.82 3.94 4.07
Amps 13.7 14.0 14.3 14.7 14.6 14.8 15.2 15.7 15.6 15.9 16.3 16.8 16.4 16.7 17.2 17.7 17.3 17.6 18.1 18.7 18.1 18.5 19.0 19.6
Hi PR 233 251 265 276 262 281 297 310 297 320 338 353 339 365 385 402 381 410 433 452 421 453 479 499
Lo PR 112 119 130 139 118 126 137 146 123 131 143 152 129 137 150 160 135 144 157 167 140 149 163 173
1138
MBh 37.3 38.1 40.7 43.5 36.4 37.2 39.7 42.5 35.5 36.3 38.8 41.5 34.7 35.4 37.8 40.5 32.9 33.6 36.0 38.4 30.5 31.2 33.3 35.6
S/T 0.89 0.83 0.68 0.51 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.01 0.95 0.77 0.58 1.02 0.95 0.78 0.58
∆T 27 26 22 18 27 26 23 18 27 26 23 18 27 26 23 18 27 26 22 18 25 24 21 17
kW 2.84 2.89 2.98 3.07 3.04 3.11 3.20 3.30 3.23 3.30 3.40 3.51 3.39 3.46 3.57 3.69 3.53 3.60 3.72 3.84 3.65 3.73 3.85 3.97
Amps 13.4 13.7 14.0 14.4 14.3 14.5 14.9 15.3 15.2 15.5 15.9 16.4 16.0 16.4 16.8 17.3 16.9 17.2 17.7 18.2 17.7 18.1 18.6 19.1
Hi PR 226 243 257 268 254 273 288 301 289 311 328 342 329 354 373 390 370 398 420 438 408 440 464 484
Lo PR 109 116 126 134 115 122 133 142 119 127 139 148 125 133 146 155 131 140 152 162 136 144 158 168
85
1463
MBh 42.3 43.1 45.2 48.2 41.3 42.1 44.1 47.1 40.3 41.1 43.1 45.9 39.4 40.1 42.0 44.8 37.4 38.1 39.9 42.6 34.6 35.3 37.0 39.4
S/T 1.00 0.98 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.97 0.78 1.00 1.00 1.00 0.81 1.00 1.00 1.00 0.82
∆T 27 26 25 22 26 26 25 22 25 26 25 22 25 25 26 22 24 24 25 22 22 22 23 20
kW 2.95 3.01 3.10 3.19 3.17 3.23 3.33 3.44 3.36 3.43 3.54 3.65 3.53 3.61 3.72 3.84 3.67 3.75 3.88 4.00 3.80 3.88 4.01 4.14
Amps 13.9 14.2 14.5 14.9 14.8 15.1 15.4 15.9 15.8 16.1 16.5 17.0 16.7 17.0 17.5 18.0 17.5 17.9 18.4 19.0 18.4 18.8 19.3 19.9
Hi PR 238 256 270 282 267 287 303 316 303 327 345 360 346 372 393 410 389 418 442 461 430 462 488 509
Lo PR 114 122 133 141 121 128 140 149 125 133 146 155 132 140 153 163 138 147 160 171 143 152 166 177
1300
MBh 41.1 41.9 43.9 46.8 40.1 40.9 42.8 45.7 39.2 39.9 41.8 44.6 38.2 39.0 40.8 43.5 36.3 37.0 38.8 41.3 33.6 34.3 35.9 38.3
S/T 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 0.99 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.96 0.78
∆T 28 28 26 23 28 28 26 23 28 28 26 23 27 28 27 23 26 26 26 23 24 24 24 21
kW 2.92 2.98 3.07 3.17 3.14 3.21 3.31 3.41 3.33 3.40 3.51 3.62 3.50 3.58 3.69 3.81 3.65 3.72 3.84 3.97 3.77 3.85 3.98 4.11
Amps 13.8 14.1 14.4 14.8 14.7 14.9 15.3 15.8 15.7 16.0 16.4 16.9 16.5 16.9 17.3 17.9 17.4 17.7 18.2 18.8 18.2 18.6 19.1 19.8
Hi PR 235 253 268 279 264 284 300 313 300 323 341 356 342 368 389 406 385 414 437 456 425 458 483 504
Lo PR 113 120 131 140 119 127 139 148 124 132 144 154 130 139 152 161 137 145 159 169 141 150 164 175
1138
MBh 37.9 38.6 40.5 43.2 37.0 37.7 39.5 42.2 36.2 36.9 38.6 41.2 35.3 36.0 37.7 40.2 33.5 34.2 35.8 38.2 31.0 31.6 33.1 35.4
S/T 0.93 0.90 0.81 0.66 0.96 0.93 0.84 0.68 0.99 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75
∆T 28 28 26 23 29 28 27 23 29 28 27 23 29 29 27 23 27 28 27 23 25 26 25 22
kW 2.86 2.91 3.00 3.10 3.07 3.13 3.23 3.33 3.25 3.32 3.43 3.54 3.42 3.49 3.60 3.72 3.56 3.63 3.75 3.87 3.68 3.76 3.88 4.01
Amps 13.5 13.8 14.1 14.5 14.4 14.6 15.0 15.4 15.3 15.6 16.0 16.5 16.2 16.5 16.9 17.4 17.0 17.3 17.8 18.4 17.8 18.2 18.7 19.3
Hi PR 228 246 260 271 256 276 291 304 291 314 331 345 332 357 377 393 373 402 424 443 413 444 469 489
Lo PR 110 117 127 136 116 123 135 143 120 128 140 149 127 135 147 157 133 141 154 164 137 146 159 170
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
18 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 19
expanded Cooling data — apg1460***41a* — high stage
65 75 85 95 105 115
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
2036
MBh 55.4 57.4 62.9 - 54.1 56.1 61.4 - 52.8 54.7 59.9 - 51.5 53.4 58.5 - 48.9 50.7 55.6 - 45.3 47.0 51.5 -
S/T 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.82 0.69 0.48 - 0.85 0.71 0.49 - 0.88 0.74 0.51 - 0.89 0.74 0.51 -
∆T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
kW 4.41 4.50 4.64 - 4.73 4.83 4.98 - 5.02 5.12 5.28 - 5.27 5.38 5.55 - 5.48 5.60 5.77 - 5.66 5.78 5.97 -
Amps 21.5 21.8 22.4 - 22.7 23.1 23.7 - 24.2 24.6 25.3 - 25.4 25.9 26.6 - 26.7 27.2 27.9 - 28.0 28.5 29.3 -
Hi PR 256 276 291 - 288 310 327 - 327 352 372 - 373 401 424 - 419 451 477 - 463 499 527 -
Lo PR 107 114 124 - 113 120 131 - 118 125 137 - 124 131 144 - 130 138 150 - 134 143 156 -
1810
MBh 53.8 55.7 61.0 - 52.5 54.4 59.6 - 51.3 53.1 58.2 - 50.0 51.8 56.8 - 47.5 49.2 53.9 - 44.0 45.6 50.0 -
S/T 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.84 0.70 0.49 - 0.85 0.71 0.49 -
∆T 20 17 13 - 20 18 13 - 20 18 13 - 21 18 14 - 20 18 13 - 19 16 12 -
kW 4.38 4.47 4.60 - 4.70 4.79 4.94 - 4.98 5.08 5.24 - 5.23 5.34 5.50 - 5.44 5.55 5.73 - 5.62 5.74 5.92 -
Amps 21.3 21.7 22.2 - 22.6 23.0 23.5 - 24.0 24.5 25.1 - 25.3 25.7 26.4 - 26.5 27.0 27.7 - 27.8 28.3 29.1 -
Hi PR 254 273 289 - 285 307 324 - 324 349 368 - 369 397 419 - 415 447 472 - 459 494 521 -
Lo PR 106 113 123 - 112 119 130 - 116 124 135 - 122 130 142 - 128 136 149 - 133 141 154 -
1584
MBh 49.6 51.4 56.3 - 48.5 50.2 55.0 - 47.3 49.0 53.7 - 46.2 47.8 52.4 - 43.8 45.4 49.8 - 40.6 42.1 46.1 -
S/T 0.71 0.59 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -
∆T 20 18 13 - 21 18 14 - 21 18 14 - 21 18 14 - 21 18 14 - 19 17 13 -
kW 4.28 4.37 4.50 - 4.59 4.68 4.82 - 4.86 4.96 5.11 - 5.10 5.21 5.37 - 5.31 5.42 5.59 - 5.48 5.60 5.78 -
Amps 20.9 21.3 21.8 - 22.1 22.5 23.1 - 23.5 24.0 24.6 - 24.7 25.2 25.8 - 25.9 26.4 27.1 - 27.1 27.7 28.4 -
Hi PR 246 265 280 - 276 297 314 - 314 338 357 - 358 385 407 - 403 433 458 - 445 479 506 -
Lo PR 103 109 120 - 109 116 126 - 113 120 131 - 119 126 138 - 124 132 144 - 129 137 149 -
75
2036
MBh 56.3 58.0 62.7 67.3 55.0 56.6 61.3 65.8 53.7 55.3 59.8 64.2 52.4 53.9 58.4 62.6 49.8 51.2 55.5 59.5 46.1 47.5 51.4 55.1
S/T 0.88 0.79 0.60 0.38 0.91 0.81 0.62 0.40 0.93 0.84 0.63 0.41 0.96 0.86 0.65 0.42 1.00 0.90 0.68 0.44 1.00 0.90 0.68 0.44
∆T 22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 22 21 17 12 21 19 16 11
kW 4.45 4.54 4.67 4.81 4.77 4.87 5.02 5.17 5.06 5.16 5.32 5.49 5.31 5.42 5.59 5.77 5.52 5.64 5.82 6.01 5.71 5.83 6.02 6.21
Amps 21.6 22.0 22.5 23.1 22.9 23.3 23.9 24.5 24.4 24.8 25.4 26.2 25.6 26.1 26.8 27.6 26.9 27.4 28.2 29.0 28.2 28.7 29.5 30.4
Hi PR 259 279 294 307 291 313 330 345 331 356 376 392 377 405 428 446 424 456 481 502 468 504 532 555
Lo PR 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
1810
MBh 54.7 56.3 60.9 65.4 53.4 55.0 59.5 63.9 52.1 53.7 58.1 62.3 50.9 52.4 56.7 60.8 48.3 49.7 53.8 57.8 44.7 46.1 49.9 53.5
S/T 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.65 0.42 0.96 0.86 0.65 0.42
∆T 23 21 18 12 24 22 18 12 24 22 18 12 24 22 18 12 23 22 18 12 22 20 17 11
kW 4.41 4.50 4.64 4.78 4.73 4.83 4.98 5.13 5.02 5.12 5.28 5.45 5.27 5.38 5.55 5.72 5.48 5.60 5.77 5.96 5.66 5.78 5.97 6.16
Amps 21.5 21.8 22.4 23.0 22.7 23.1 23.7 24.4 24.2 24.6 25.3 26.0 25.5 25.9 26.6 27.4 26.7 27.2 28.0 28.8 28.0 28.5 29.3 30.2
Hi PR 257 276 292 304 288 310 327 341 327 352 372 388 373 401 424 442 419 451 477 497 463 499 527 549
Lo PR 107 114 124 133 113 120 131 140 118 125 137 146 124 131 144 153 130 138 150 160 134 143 156 166
1584
MBh 50.5 51.9 56.2 60.3 49.3 50.7 54.9 58.9 48.1 49.5 53.6 57.5 46.9 48.3 52.3 56.1 44.6 45.9 49.7 53.3 41.3 42.5 46.0 49.4
S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40
∆T 24 22 18 12 24 22 18 12 24 22 18 12 24 22 18 13 24 22 18 12 22 20 17 12
kW 4.32 4.40 4.53 4.67 4.63 4.72 4.86 5.01 4.90 5.00 5.16 5.32 5.14 5.25 5.41 5.59 5.35 5.46 5.63 5.81 5.53 5.64 5.82 6.01
Amps 21.0 21.4 21.9 22.5 22.3 22.7 23.2 23.9 23.7 24.1 24.7 25.4 24.9 25.4 26.0 26.8 26.1 26.6 27.3 28.2 27.3 27.9 28.6 29.5
Hi PR 249 268 283 295 279 300 317 331 318 342 361 376 362 389 411 429 407 438 462 482 450 484 511 533
Lo PR 104 111 121 129 110 117 128 136 114 121 133 141 120 128 139 148 126 134 146 155 130 138 151 161
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
18 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 19
expanded Cooling data — apg1460***41a* — high stage (Cont.)
65 75 85 95 105 115
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
2036
MBh 57.3 58.6 62.6 66.9 56.0 57.2 61.1 65.3 54.6 55.8 59.6 63.8 53.3 54.5 58.2 62.2 50.6 51.7 55.3 59.1 46.9 47.9 51.2 54.7
S/T 0.96 0.90 0.74 0.55 1.00 0.94 0.76 0.57 1.00 0.96 0.78 0.58 1.00 1.00 0.81 0.60 1.00 1.00 0.84 0.63 1.00 1.00 0.84 0.63
∆T 25 24 21 17 25 24 21 17 25 24 21 17 24 25 21 17 23 23 21 17 21 22 20 16
kW 4.48 4.57 4.71 4.85 4.81 4.91 5.06 5.22 5.10 5.20 5.37 5.54 5.35 5.46 5.64 5.82 5.57 5.69 5.87 6.06 5.75 5.88 6.07 6.27
Amps 21.7 22.1 22.7 23.3 23.0 23.5 24.0 24.7 24.5 25.0 25.6 26.4 25.8 26.3 27.0 27.8 27.1 27.6 28.4 29.2 28.4 28.9 29.7 30.6
Hi PR 262 282 297 310 294 316 334 348 334 359 380 396 380 409 432 451 428 461 486 507 473 509 537 560
Lo PR 109 116 127 135 116 123 134 143 120 128 139 148 126 134 146 156 132 141 153 163 137 145 159 169
1810
MBh 55.6 56.9 60.7 64.9 54.3 55.5 59.3 63.4 53.0 54.2 57.9 61.9 51.8 52.9 56.5 60.4 49.2 50.2 53.7 57.4 45.5 46.5 49.7 53.2
S/T 0.92 0.86 0.70 0.52 0.95 0.89 0.73 0.54 0.98 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 0.98 0.80 0.60 1.00 0.99 0.81 0.60
∆T 26 25 22 17 26 25 22 18 26 25 22 18 26 25 22 18 25 25 22 17 23 23 20 16
kW 4.45 4.54 4.67 4.82 4.77 4.87 5.02 5.17 5.06 5.16 5.32 5.49 5.31 5.42 5.59 5.77 5.52 5.64 5.82 6.01 5.71 5.83 6.02 6.21
Amps 21.6 22.0 22.5 23.1 22.9 23.3 23.9 24.5 24.4 24.8 25.4 26.2 25.6 26.1 26.8 27.6 26.9 27.4 28.2 29.0 28.2 28.7 29.5 30.4
Hi PR 259 279 294 307 291 313 330 345 331 356 376 392 377 405 428 446 424 456 482 502 468 504 532 555
Lo PR 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
1584
MBh 51.4 52.5 56.1 59.9 50.2 51.3 54.8 58.5 49.0 50.0 53.5 57.1 47.8 48.8 52.1 55.7 45.4 46.4 49.5 53.0 42.0 43.0 45.9 49.1
S/T 0.89 0.83 0.68 0.51 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.01 0.95 0.77 0.58 1.02 0.95 0.78 0.58
∆T 26 25 22 18 27 26 22 18 27 26 22 18 27 26 22 18 27 25 22 18 25 24 21 17
kW 4.35 4.43 4.57 4.70 4.66 4.76 4.90 5.05 4.94 5.04 5.20 5.36 5.18 5.29 5.46 5.63 5.39 5.51 5.68 5.86 5.57 5.69 5.87 6.06
Amps 21.2 21.5 22.1 22.7 22.4 22.8 23.4 24.0 23.9 24.3 24.9 25.6 25.1 25.6 26.2 27.0 26.3 26.8 27.5 28.4 27.5 28.1 28.8 29.7
Hi PR 251 270 286 298 282 304 321 334 321 345 365 380 365 393 415 433 411 442 467 487 454 489 516 538
Lo PR 105 112 122 130 111 118 129 137 115 123 134 143 121 129 141 150 127 135 147 157 131 140 152 162
85
2036
MBh 58.3 59.4 62.2 66.4 56.9 58.1 60.8 64.9 55.6 56.7 59.4 63.3 54.2 55.3 57.9 61.8 51.5 52.5 55.0 58.7 47.7 48.7 51.0 54.4
S/T 1.00 0.98 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.97 0.78 1.00 1.00 1.00 0.81 1.00 1.00 1.00 0.82
∆T 26 26 25 21 26 26 25 22 25 26 25 22 24 25 25 22 23 24 25 22 22 22 23 20
kW 4.52 4.61 4.74 4.89 4.85 4.94 5.10 5.26 5.14 5.24 5.41 5.58 5.39 5.51 5.68 5.87 5.61 5.73 5.92 6.11 5.80 5.93 6.12 6.32
Amps 21.9 22.3 22.8 23.4 23.2 23.6 24.2 24.9 24.7 25.2 25.8 26.6 26.0 26.5 27.2 28.0 27.3 27.8 28.6 29.4 28.6 29.2 29.9 30.9
Hi PR 264 284 300 313 297 319 337 352 337 363 383 400 384 413 437 455 432 465 491 512 478 514 543 566
Lo PR 110 117 128 137 117 124 135 144 121 129 141 150 127 135 148 158 133 142 155 165 138 147 160 171
1810
MBh 56.6 57.7 60.4 64.5 55.3 56.4 59.0 63.0 54.0 55.0 57.6 61.5 52.7 53.7 56.2 60.0 50.0 51.0 53.4 57.0 46.3 47.2 49.5 52.8
S/T 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 0.99 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.96 0.78
∆T 28 27 26 22 28 28 26 23 27 28 26 23 27 27 26 23 25 26 26 22 24 24 24 21
kW 4.48 4.57 4.71 4.85 4.81 4.91 5.06 5.22 5.10 5.20 5.37 5.54 5.35 5.46 5.64 5.82 5.57 5.69 5.87 6.06 5.75 5.88 6.07 6.27
Amps 21.7 22.1 22.7 23.3 23.0 23.5 24.0 24.7 24.5 25.0 25.6 26.4 25.8 26.3 27.0 27.8 27.1 27.6 28.4 29.2 28.4 28.9 29.7 30.6
Hi PR 262 282 297 310 294 316 334 348 334 359 380 396 380 409 432 451 428 461 486 507 473 509 537 560
Lo PR 109 116 127 135 116 123 134 143 120 128 139 148 126 134 146 156 132 141 153 163 137 145 159 169
1584
MBh 52.2 53.3 55.8 59.5 51.0 52.0 54.5 58.1 49.8 50.8 53.2 56.7 48.6 49.5 51.9 55.4 46.2 47.1 49.3 52.6 42.8 43.6 45.7 48.7
S/T 0.93 0.90 0.81 0.66 0.96 0.93 0.84 0.68 0.99 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75
∆T 28 28 26 23 29 28 27 23 29 28 27 23 28 28 27 23 27 27 26 23 25 25 25 21
kW 4.38 4.47 4.60 4.74 4.70 4.79 4.94 5.09 4.98 5.08 5.24 5.40 5.22 5.33 5.50 5.68 5.43 5.55 5.73 5.91 5.62 5.74 5.92 6.11
Amps 21.3 21.7 22.2 22.8 22.6 23.0 23.5 24.2 24.0 24.5 25.1 25.8 25.3 25.7 26.4 27.2 26.5 27.0 27.7 28.6 27.7 28.3 29.0 29.9
Hi PR 254 273 288 301 285 307 324 338 324 349 368 384 369 397 419 437 415 447 472 492 459 494 521 544
Lo PR 106 113 123 131 112 119 130 139 116 124 135 144 122 130 142 151 128 136 149 159 133 141 154 164
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions. kW = Total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
Product SPecificationS
20 www.amana-hac.com SS-APG14M SS-APG14M www.amana-hac.com 21
airFlow data
0.1 695 62 44 820 93 37 1,050 167 29 850 100 1,095 198
0.2 650 71 47 785 100 39 1,010 180 30 800 106 1,060 202
0.3 605 77 51 745 108 41 970 186 32 765 116 1,025 214
0.4 565 89 54 700 117 44 935 192 33 730 125 985 217
0.5 480 99 X 665 127 46 890 203 35 680 131 945 227
0.6 415 106 X 575 138 53 850 208 36 610 141 905 233
0.7 365 110 X 510 146 X 815 216 38 550 153 865 237
0.8 320 119 X 455 155 X 755 222 41 490 159 825 246
0.1 695 62 X 820 93 56 1,050 167 44 850 100 1,095 198
0.2 650 71 X 785 100 59 1,010 180 46 800 106 1,060 202
0.3 605 77 X 745 108 X 970 186 48 765 116 1,025 214
0.4 565 89 X 700 117 X 935 192 49 730 125 985 217
0.5 480 99 X 665 127 X 890 203 52 680 131 945 227
0.6 415 106 X 575 138 X 850 208 54 610 141 905 233
0.7 365 110 X 510 146 X 815 216 57 550 153 865 237
0.8 320 119 X 455 155 X 755 222 X 490 159 825 246
0.1 680 61 45 840 103 37 1,035 174 30 1,035 174 1,225 276
0.2 640 72 48 795 109 39 995 184 31 995 184 1,185 275
0.3 605 80 51 750 117 41 960 192 32 960 192 1,150 289
0.4 555 89 X 710 126 43 925 205 33 925 205 1,115 296
0.5 490 93 X 660 132 47 875 200 35 875 200 1,085 303
0.6 455 107 X 615 138 50 840 217 37 840 217 1,045 312
0.7 395 109 X 570 150 54 795 222 39 795 222 1,000 315
0.8 350 119 X 515 157 X 755 226 41 755 226 960 320
0.1 680 61 X 840 103 55 1,035 174 45 1,035 174 1,225 276
0.2 640 72 X 795 109 58 995 184 46 995 184 1,185 275
0.3 605 80 X 750 117 X 960 192 48 960 192 1,150 289
0.4 555 89 X 710 126 X 925 205 50 925 205 1,115 296
0.5 490 93 X 660 132 X 875 200 53 875 200 1,085 303
0.6 455 107 X 615 138 X 840 217 55 840 217 1,045 312
0.7 395 109 X 570 150 X 795 222 58 795 222 1,000 315
0.8 350 119 X 515 157 X 755 226 X 755 226 960 320
Other manuals for APG14 M Series
2
This manual suits for next models
11
Table of contents
Other Amana Air Handler manuals
Amana
Amana AHVE Series Manual
Amana
Amana PBH113G35CC User manual
Amana
Amana ARUF**14 Series Manual
Amana
Amana AVPEC Series Manual
Amana
Amana AVPTC25B14 Manual
Amana
Amana AMVE Manual
Amana
Amana ComfortNet MBVC1200AA-1 User manual
Amana
Amana ACNF180 Series User manual
Amana
Amana AVPEC Series Manual
Amana
Amana AVPTC**14 Series Manual
Popular Air Handler manuals by other brands
Johnson Controls
Johnson Controls MAHP18B21S Installation and maintenance manual
BLAUBERG Ventilatoren
BLAUBERG Ventilatoren KOMFORT EC DB160 R S11 user manual
innovair
innovair 18K User and installation manual
Vents
Vents VUT 350 EH user manual
Aspira
Aspira ASPIRCOMFORT CLASS 620V WI-FI Instructions for installation, use and maintenance manual
Flexit
Flexit Nordic S4 installation instructions
Haier
Haier HB6000VD1M22-EP Installation & operation manual
Vents
Vents VUT 350 EH user manual
IV Produkt
IV Produkt Envistar Flex Assembly instructions
IV Produkt
IV Produkt Flexomix MIE-FB Operation and maintenance manual
IV Produkt
IV Produkt Envistar Top Series Operation and maintenance manual
Fujitsu
Fujitsu FH3617TTSASN installation instructions
Trane
Trane American Standard 4MXD8509A10N0 Installer manual
flowair
flowair ELIS B W 100 2R Technical documentation operation manual
Swegon
Swegon ESENSA Series manual
Ecoer
Ecoer 36K owner's manual
Daikin
Daikin AWSF18SU16 Series installation instructions
valent
valent VX Series Installation, operation and maintenance manual
