Amana AER5712BA User instructions

30” FREE-STANDING ELECTRIC RANGE
1. Provide for 120/208, 120/240 volt outlet per applicable cord in this area.
16" (40.6 cm) W x 5
3/4" (14.6 cm) H, located 7" from side wall.
2. Depth excluding handle. Dimension given is from wall to front of oven door.
3 . May vary slightly depending upon leveling legs.
NOTES:
Style of product may vary from picture
D
C
B
A
53/4"
21 /4"
16"
7"
ELECTRIC
SUPPLY
LOCATION
1
7"
PRODUCT DIMENSIONS
INCHES CENTIMETERS
MODEL SKUs
A2
B
C3
D3
30"
25"
36"
24"
26 1/8 66.4
29 7/8 75.9
36 91.4
46 3/4 118.7
AER5712BAW
AER5712BAB
AER5712BAZ
Important:Because of continuing product improvements, Amana reserves the right to change specifications without notice. Dimensional specifications are provided for
planning purposes only. For complete details see installation instructions that accompany each product before selecting cabinetry, making cutouts or beginning installation.
