Amana AGP200VD User instructions

20" (50.8 cm) Freestanding Gas Range
PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS
CABINET OPENING DIMENSIONS
AGP200VD
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice. Dimensions are for planning purposes only. For complete details, see Installation Instructions packed with product. Specifications subject to change without notice.
Gas supply: Provide a gas supply line of ³⁄₄" (1.9 cm) rigid
pipe to the range location. A smaller size pipe on longer runs
may result in insufficient gas supply. Pipe joint compounds
that resist the action of LP gas must be used. Do not use
TEFLON®† tape. With LP gas, piping or tubing size can be ¹⁄₂"
(1.3 cm) minimum. Usually, LP gas suppliers determine the
size and materials used in the system.
If local codes permit, a new CSA design-certified, 4-5 ft
(122-152.4 cm) long, ¹⁄₂" (1.3 cm) or ³⁄₄" (1.9 cm) I.D., flexible
metal appliance connector may be used for connecting range
to the gas supply line.
A ¹⁄₂" (1.3 cm) male pipe thread is needed for connection to the
female pipe threads of the inlet to the appliance gas pressure
regulator.
Must include a shutoff valve:
The supply line must be equipped with a manual shutoff valve.
This valve should be located in the same room but external to
the range. It should be in a location that allows ease of opening
and closing.
Electrical: A 120-volt, 60-Hz, AC-only, 15-amp, fused
electrical circuit is required. A time-delay fuse or circuit breaker
is also recommended. It is recommended that a separate
circuit serving only this range be provided.
Do not use an extension cord.
†®TEFLON is a registered trademark of E.I. Du Pont De Nemours and Company.
Ref. W10173324B
10/8/10
19¹⁄₂"
(49.5 cm)
24¹⁄₂"
(62.2 cm)
42"
(106.7 cm)
36"
(91.5 cm)
For minimum
clearance to
top of cooktop,
see NOTE
This shaded area
recommended for
installation
of gas pipe
18" (45.7 cm)
min. clearance
upper side
cabinet to
countertop
13" (33.0 cm) max.
upper cabinet depth
20¹⁄₈" (51.12 cm)
opening width
20" (50.8 cm) min.
cabinet opening width
5¹⁄₂"
(14 cm)
2"
(5.1 cm)
2¹⁄₂"
(6.4 cm)
4"
(10 cm)
10" (25.4 cm)
3" (7.6 cm) min.
countertop space to
side wall or other
combustible material
Cabinet opening dimensions shown are for 25" (64 cm) countertop
depth, 24" (61 cm) base cabinet depth and 36" (91.4 cm) countertop
height.
If the cabinet depth is greater than 24" (61 cm), the oven frame must
extend beyond cabinet fronts by ¹⁄₂" (13 mm) minimum.
NOTE: 24" (61 cm) minimum when bottom of wood or metal cabinet is
covered by not less than ¹⁄₄" (0.64 cm) flame retardant millboard
covered with not less than No. 28 MSG sheet steel, 0.015" (0.4 mm)
stainless steel, 0.024" (0.6 mm) aluminum or 0.020" (0.5 mm) copper.
30" (76.2 cm) minimum clearance between the top of the cooking
platform and the bottom of an uncovered wood or metal cabinet.
IMPORTANT: If installing a range hood or microwave hood
combination above the range, follow the range hood or microwave hood
combination installation instructions for dimensional clearances above
the cooktop surface.
