CABINET PARTS
1
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
4−09 Litho In U.S.A. (mat)(bay) Part No. W10242314 Rev.A
REFRIGERATOR

CABINET PARTS
2W10242314
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10137643 Use & Care Guide
W10123901 Energy Guide
12827952 Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Cover, Left Hinge
12684201W White
12684201B Black
12684201C Bisque
4 B5759649 Gasket
5 67006118 Roller Assy. (2)
6 67003868 Foot, Brake
7
12566605ED Hinge, Left Top
8 67006611 Bolt, Adjusting
(Front Roller)
9 67006521 Screw
10 Cover, Right Hinge
12684202W White
12684202B Black
12684202C Bisque
11 67005822 Screw
12 67003405 Block, Pivot
13 67006433 Screw
14 67006303 Screw (3)
15 Hinge, Center (LT)
67006277 White
67006442 Black
16
12566604ED Hinge, Right Top
17 Cover, Corner
67003484 White
67003485 Black
67003486 Bisque
18 67001067 Clip, Drain
19 67007174 Bracket, Foot (2)
20 67006564 Screw (4)
21 67006101 Cover, Unit
22 Grille, Toe
67006377 White
67006375 Black
67006376 Bisque
24 67001066 Tube, Drain
25 67006425 Screw
26 67003796 Fiber, Acoustic
27 12479803 Cover, Water Valve
28 67003331 Cover, Water Line
29 M0114003 Clip
30
W10137519 Elbow, Fill Tube
31 12579702 Shim, Top Hinge
32 67006669 Screw, Block
33 Hinge, Center (RT)
67006379 White
67006443 Black
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)

FREEZER LINER PARTS
3
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
W10242314

FREEZER LINER PARTS
4
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
W10242314
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 67001291 Gasket, Foam
3 67005874 Guide, Fill Tube
4 67003905 Cover, Light
5 67003636 Motor, Evaporator
6
Y12570701 Socket, Light
7 12002355 Thermistor
8 67003924 Cover, Thermistor
9 A0282812 Bulb, Light
10 67001035 Housing, Light
11 67005873 Cover, Evaporator
12 67006425 Screw
13
W10121318 Grommet
14 67003906 Module, Light
15
W10167028 Clip, Evap. Motor
16 67005653 Switch, Light
17 67006530 Screw
18 D7753903 Funnel, Drain
19 M0500703 Seal
20 67002492 Gasket, Bottom
21 B8381501 Gasket
22
W10175909 Grille, Fz Air
23
W10167023 Shroud, Evap.Fan
24 2169142 Blade, Fan
(Evaporator)
25 Bracket, Door
W10122147 Left
W10122148 Right
26 67006473 Screw (8)
27 Cradle, Basket
67004014 Left
67004015 Right
28
W10120018 Slide, Drawer (2)
29 Adapter, Slide
W10128118 Left
W10128119 Right
30 67006406 Screw (6)
31 67004017 Shaft
32 12002497 Gear
(Includes LH & RH)
Following Parts Not Illustrated
67006095 Harness, Lights
(Freezer)

REFRIGERATOR LINER PARTS
5
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
W10242314

REFRIGERATOR LINER PARTS
6
Illus. Part
No. No. DESCRIPTION
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
W10242314
1 Liner (Not A
Serviceable Part)
2 67004078 Module, Light
3 67004695 Overlay
4 67004005 Module, Control
5
W10165748 Board, Control
(Incl Instr Sheet)
6 C3680310 Switch, Light (2)
7 67003897 Cover, Light
8 67003901 Housing, Light
9 A0282812 Bulb, Light (2)
10
Y12570701 Socket, Light (2)
11 67003900 Insert,
Damper Cover
12 67006602 Screw
13 67003899 Cover, Damper
14 67006604 Insulation
15
W10127429 Control, Damper
(Includes Harness)
16 12002355 Thermistor
17 61006182 Union, Tube
18
W10117358 Insulation, Water
Tank
19
W10153959 Tank, Water
20
W10158503 Dispenser
21 67006400 Screw
22 67001668 Plate, Filter
23 67006524 Head, Water Filter
Assembly
24 12568001 Cover, Filter
25 67006467 Filter, Water
26 12664501 Plug, Filter
Bypass
27 B8390302 Clip, Waterline
28 67006415 Screw
29 67005674 Facade, Dispenser
30 12575501 Switch, Limit
31 67002742 Plate, Switch
32 67002816 Clip, Water Tube
33 67003728 Guide, Water
34 67003940 Switch, Energy
Following Parts Not Illustrated
67004032 Harness, Controls
(Refrigerator)

REFRIGERATOR DOOR PARTS
7
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
W10242314

REFRIGERATOR DOOR PARTS
8
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
W10242314
Illus. Part
No. No. DESCRIPTION
1 Door, Left
13024018WQ White
13024018BQ Black
13024018QQ Bisque
2 Door, Right
13024017WQ White
13024017BQ Black
13024017QQ Bisque
3 67003637 Door, Dairy
4 67001279 Tray, Dairy
5 Bucket, Door
67003770 Medium (3)
12699207 Gallon (2)
6 Mullion, Door
67003263 White
67003264 Black
7 67006786 Screw
8 Gasket, Door
W10137006 White
W10163895 Black
9 Handle, Door
W10119666 White − LH
W10119663 White − RH
W10119668 Black − LH
W10119665 Black − RH
W10119667 Bisque − LH
W10119664 Bisque − RH
10 67006287 Screw
11 Stop, Door
12968202W White
67007011 Black
12
Y12528501 Nameplate
13 12992902 Mount, Handle
15 Closure, Door
67003638 White
67003639 Black
16 Grippers
67003212 Medium
67005453 Gallon

UNIT PARTS
9
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
W10242314

UNIT PARTS
10
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
W10242314
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 67006433 Screw
2
W10162928 Blade, Fan
3 67005889 Basepan
4 67006425 Screw
5 67005491 Block, Condenser
6 67004700 Tube, Discharge
7
W10119856 Harness, Evap.
Heater
8 67007175 Pan, Drain
9 61004743 Grommet (3)
10 67002493 Heater, Defrost
11 67007052 Clip, Retainer
12 67005560 Relay/Capacitor
13 61003210 Gasket
14
W10165425 Thermostat,
Defrost
15 67005680 Grommet (2)
16 67006573 Screw
17
W10169124 Grommet (4)
18 67006131 Condenser
19 67006432 Screw
20 67002490 Tray, Drip
21 67006737 Screw
22 12002041 Evaporator Kit
(Incl. Evaporator
#67003720, Heat
Shield & Instruct.
Sheet)
23 Dam
67001084 Right Side
67001083 Left Side
24 67004432 Motor, Fan
25 10428101 Clip, Heater
26 13060301 Harness, Unit
with Power Cord
27
W10143759 Drier (service)
28 67005565 Compressor
(Includes items
11,12,17,27)
29 10623002 Clip, Evaporator
30 67006434 Axle, Roller (2)
31
W10158508 Shroud
32 67004953 Bracket, Fan Motor
33 67004954 Screw
34 10547003 Clip, Drier
35 67005149 Roller (2)
36
W10137529 Grommet, Cond. (4)
37 67005562 Capacitor
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.25 Ozs.
(R−134A)

SHELF PARTS
11
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
W10242314

SHELF PARTS
12
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
W10242314
Illus. Part
No. No. DESCRIPTION
1 67004514 Rail, Center
Crisper
2 67004636 Trim, Crisper
3 67006608 Screw
4 67004987 Basket, Freezer
(Upper)
5 67006025 Basket, Freezer
(Lower)
6 67004637 Shelf (4)
7 67006360 Screw
8 67005864 Slide, Humidity
Control (2)
9 67004127 Divider, Basket
(Upper)
10 67006644 Divider, Basket
(Lower)
11 67006400 Screw
16 67004515 Pan, Crisper
17 67002748 Brace, Crisper
18 67003854 Frame, Crisper
19 67006704 Glass, Crisper Cover
20 67001073 Ladder, Center
21 67002489 Ladder, Side
23 12603701 Support, Crisper
Frame
24 67002761 Glass, Pantry
25 67006010 Trim, Pantry Glass
26 67002330 Brace, Pantry (2)
27 67001719 Track, Pantry
28 67002329 Gasket, Pantry
29 67005625 Housing, Control
30 67003793 Slide, Control
31 Endcap, Pantry
67005858 Right
67005863 Left
32 67006287 Screw (4)
33 67007026 Glide, Pantry (2)
34 67006415 Screw (4)
35 67003795 Bar, Temp Cont.
36 67003791 Knob, Control
37 67003531 Drawer, Pantry
38 67005900 Lid, Pantry
39 67002759 Divider, Pantry

ICEMAKER PARTS
13
W10242314
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)

ICEMAKER PARTS
14 W10242314
Illus. Part
No. No. DESCRIPTION
1 2256086 Bracket, Icemaker
2 67003729 Tube, Plastic
3 67003932 Clamp
4 489276 Screw
5 67003753 Valve, Inlet
6 67004028 Arm, Shutoff
7 67004710 Cover, Front
8 A3223101 Insert, Tube
9
W10122527 Mold & Heater
Assembly (Also
Order 542638)
10 628515 Cup, Water Fill
11 627843 Ejector
12 2182124 Ice Stripper
13 2194712 Support
14 2315522 Retainer
15 627985 Thermostat
(Order 542369
Cement
Alumilastic)
16 8533917 Screw
17 489464 Screw
18
W10146389 Harness, Icemaker
19 M0114003 Clip, Speed
20 626678 Module Assembly
(Includes Items
21 & 22)
21 626684 Motor
22 489136 Screw
23
W10137519 Elbow, Fill Tube
24 67005603 Funnel, Fill Tube
25
W10182748 Pan, Ice
100 D7824706 Complete Ice Maker
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)

FREEZER DOOR PARTS
15
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
W10242314
Illus. Part
No. No. DESCRIPTION
1 Door, Freezer
13092203WQ White
13092203BQ Black
13092203QQ Bisque
2 Handle, Door
W10119666 White
W10119668 Black
W10119667 Bisque
3 Gasket, Door
W10133249 White
W10131754 Black
W10164040 Bisque
4 12992902 Screw, Handle

OPTIONAL PARTS
16
For Models: AFD2535DEW14, AFD2535DEB14, AFD2535DEQ14
(White) (Black) (Bisque)
W10242314
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
PAINT, PRESSURIZED SPRAY
(12 oz.)
350942 Primer, White
350930 White
350939 Black
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
PAINT, BULK (1 qt.)
799344 White (Uncut)
799344 Black (Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
833938 Kit, Terminal
Connector
TORX SCREW WRENCH
1117510 Torx Key
ACCESSORIES
31462 Cleaner, 10 oz.
Stainless Steel
