Amart Furniture SOPHIE MK2 65524 User manual

SOPHIE MK2 DOUBLE BED
ITEM CODE 65524
65524
1550mm
1120mm
2060mm

Before you start :
1. Choose a clean, level, spacious assembly area. Avoid hard surfaces that may
damage the product.
2. Take care when liing. Product should be assembled as near as possible to
the point of use.
3. Ensure that you have all required contents for complete assembly.
4. Always read the assembly instrucons carefully before beginning assembly.
5. Keep all hardware parts and packaging out of reach of small children.
6. Do not over ghten the screws and bolts as this may damage the threads.
2
X2
ALLOW 20 MINUTES 2 PEOPLE REQUIRED
65524

3 65524
A
Bolt ( pre-assembled )
M8 x 30mm 8 x A
B
Allen Key
M8 1 x B
D
Bolt
M8 x 60mm 1 x D
C
Washer
M8 x 60mm 1 x C
2 FOOTBOARD ( x 1 )
1 HEADBOARD ( x 1 )
4CENTER RAIL ( x 1 )
3 SIDE RAIL ( x 2 )
6 FLAT SLAT 1380mm x 62mm x 14mm ( x 14 )
7 CENTER SUPPORT LEG ( x 1 )
5 WOOD LEGS ( x 4 )

655244
Note : Please ensure the legs are fix and same position according to
diagram 1.
1.
2.
5.
5.
5.
5.
Diagram 1
1 & 2.
5.
Caution : Please make sure the legs in the rightposition.
A. M8 x 30mm ~ 8nos.
A.
Step 1 :
Step 2 : Attach Side Rail (3.) to Headboard (1.) and Footboard (2.) by hooking
the bracket on Side Rail (3.) to pre installed bolts on Headboard (1.) and
Footboard (2.). Do not tighten until center rail attaches.
(Pre-assembled)
Attach the Wood Legs (5.) to the bottom of Headboard (1.) and
Footboard (2.) by screwing in a clockwise direction. Then tighten them
before you continue to the next step.

655245
Please Note: Do not tighten any bolts until all components (Part 1, 2, 3 & 4)
are in place.
4
12&
4
7
D. M8 X 60mm
C. M8 WASHER
A .
C .
Step 3 : Install the Center Support Leg (7.) with D. M8 x 60mm bolt and C. M8
Washer on Center Rail (4.). Connect Center Rail (4.) by slotting each end into
brackets installed on Headboard (1.) and Footboard (2.) by pushing the bracket
down. Please adjust the threaded leg on the Center Support Leg (7.) to level the
center rail with support rail height.
7
B .
Note :Layout bed slats on top of Side Rail (3.) start from the
Footboard (2.) onward.
Step 4 : Secure slats (6.) to Side Rail (3.) using the velcro hook and loops
System. Start from the Footboard (2.) moving towards Headboard (1.).

655246
Note : Please Lift up the bed to move, DO NOT push or pull the bed with
mattress on top.
ASSEMBLY IS COMPLETED

Product Name : SOPHIE MK2 DOUBLE BED
Item Code : 65524
CARE AND MAINTENANCE
Product Care for Fabric Items
REGULAR CARE :
Protect from direct sunlight
Vacuum regularly using low sucon
Rotate reversible cushions regularly
Avoid exposure to new clothing, cushions or throws as this may lead to
dye transfer and permanent staining.
CLEANING :
Do not remove cushion covers for separate cleaning even though they
may have zippers
Do not wash, Do not dry clean, Do not shampoo clean
Clean only with hot water extracon machine. Professional cleaning
recommended
Do not use dishwashing liquid or laundry detergent. Use only upholstery
detergents
Do not wet filling
Dry in shade away from direct heat and sunlight
Allow to dry thoroughly before re-use
SPOT CLEANING :
Do not rub
Do not spot clean with any solvent
Treat spills and stains as soon as possible
Gently scrape off any soil or blot any liquid from the surface of the fabric
before applying cleaner
Apply proprietary cleaning agents strictly according to instrucon to
remove the residue of the spill
Do not saturate the fabric or interior with water or other cleaning liquids
WARNING :
Apply only water-based soil resist (fabric protecon) treatments. Do not use
aerosol products
* PILLING IS NOT A FABRIC DEFECT OR FAULT AND IS NOT COVERED BY
WARRANTY
*PILLING IS NOT A NORMAL OCCURRENCE CAUSED BY WEAR AND TEAR AND
DOES NOT AFFECT THE DURABILITY OR FUNCTIONALITY OF THE FABRIC AND IS
EASILY REMOVED
7 65524
Made In MALAYSIA
Imported By
Amart Furniture Pty Ltd,
Brisbane, Qld, Australia
Item Code: 65524
Product Name: SOPHIE MK2 DOUBLE BED
